8184 J . Org. Chem., Vol. 61, No. 23, 1996
Majetich et al.
were added, and the mixture was warmed to rt and stirred
for a 2-h period. Standard ethereal workup, followed by
chromatography (H:E, 4:1), gave 110 mg (24%) of alcohol 66
which was homogeneous by TLC analysis (H:E, 1:1, Rf 66 )
0.31): 1H NMR (250 MHz) δ 0.72 (s, 3 H), 0.94 (s, 3 H), 1.10-
1.21 (m, 2 H), 1.23-1.40 (m, 6 H), 1.45-1.60 (m, 3 H), 2.19 (s,
3 H), 2.65-2.75 (m, 2 H), 3.85 (s, 3 H), 4.64 (d, 1 H, J ) 8.3
Hz), 6.85 (s, 1 H), 7.08 (s, 1 H).
202 (25%), 43 (100%). Anal. Calcd for C21H28O4: C, 73.2; H,
8.19. Found: C, 73.14; H, 8.21.
4a (R *),5(R *),11a (R *)-5-Ace t oxy-7-m e t h oxy-1,1,8-t r i-
m et h yl-1,2,3,4,4a ,10,11,11a -oct a h yd r o-5H -d ib en zo[a ,d ]-
cycloh ep ten -10-on e (68). To a solution of acetate 67 (100
mg, 0.303 mmol) in 3 mL of CH2Cl2 were added PCC (489 mg,
2.27 mmol) and Celite (489 mg). The mixture was refluxed
for 24 h. Standard ethereal workup, followed by chromatog-
raphy (elution with H:E, 4:1), gave 27 mg of unreacted 67
(27%) and 34 mg of ketone 68 (33% yield, 60% based on mass
balance) which was homogeneous by TLC analysis (H:E, 2:1,
Rf 68 ) 0.31). An analytical sample was recrystallized
isothermally from ether: mp 124-126 °C; 1H NMR (250 MHz)
δ 0.88 (s, 6 H), 1.00-1.75 (m, 6 H), 1.85-2.05 (m, 2 H), 1.94
(s, 3 H), 2.22 (s, 3 H), 2.62-2.86 (m, 2 H), 3.90 (s, 3 H), 5.60
(s, 1 H), 6.67 (s, 1 H), 7.49 (s, 1 H); 13C NMR (62.9 MHz) 206.0
(s), 169.8 (s), 160.1 (s), 135.9 (s), 131.5 (s), 129.8 (s), 127.2 (s),
110.8 (d), 81.6 (d), 55.6 (q), 46.1 (d), 43.1 (d), 41.0 (t), 40.9 (t),
33.4 (s), 31.5 (t), 30.1 (q), 22.4 (t), 21.3 (q), 19.8 (q), 15.8 (q)
ppm; IR (KBr pellet) 1735, 1669, 1606, 1236 cm-1; GC-MS (m/
z) 344 (15%), 302 (33%), 284 (17%), 149 (22%), 43 (100%). Anal.
Calcd for C21H28O4: C, 73.2; H, 8.19. Found: C, 73.15; H, 8.20.
11a (R*),4(S*),4a (S*)-5-H yd r oxy-7-m e t h oxy-1,1,8-t r i-
m et h yl-1,2,3,4,4a ,10,11,11a -oct a h yd r o-5H -d ib en zo[a ,d ]-
cycloh ep ten -10-on e (64). To a solution of acetate 63 (19 mg,
0.055 mmol) was added 3 mL of a 2% solution of KOH in
methanol, and the mixture was stirred at rt for 2 h. The
solvent was removed at reduced pressure, and the residue was
chromatographed (elution with H:E, 5:1) to give 15 mg of
alcohol 64 (90%) which was homogeneous by TLC analysis (H:
E, 1:1, Rf 64 ) 0.36): 1H NMR (250 MHz) δ 0.87 (s, 3 H), 0.92
(s, 3 H), 1.05-2.10 (m, 9 H), 2.21 (s, 3 H) 2.40-2.70 (m, 2 H),
3.93 (s, 3 H), 4.43 (d, 1 H, J ) 9.0 Hz), 7.12 (s, 1 H), 7.53 (s, 1
H).
4a (R*),5(R*),11a (R*)-5-H yd r oxy-7-m et h oxy-1,1,8-t r i-
m et h yl-1,2,3,4,4a ,10,11,11a -oct a h yd r o-5H -d ib en zo[a ,d ]-
cycloh ep ten -10-on e (69). Thirty-five milligrams of acetate
68 (0.102 mmol) were dissolved in 1 mL of a 2% solution of
KOH in methanol, and the mixture was stirred at rt for a 30-
min period. The solvent was removed at reduced pressure,
and the residue was chromatographed (elution with H:E, 1:1)
to give 29 mg of alcohol 69 (85%) which was homogeneous by
TLC analysis (H:E, 1:2, Rf 69 ) 0.47): 1H NMR (250 MHz) δ
0.85 (s, 3 H), 0.89 (s, 3 H), 0.95-2.06 (m, 8 H), 2.45-3.00 (m,
2 H), 3.88 (s, 8 H), 4.60 (s, 1 H), 6.55 (s, 1 H), 7.45 (s, 1 H).
(()-F a velin e Meth yl Eth er (57) by Deh yd r a tion of (64).
To a solution of alcohol 64 (14 mg, 0.046 mmol) and DCC (13
mg, 0.064 mmol) in 0.1 mL of THF was added CuCl (1 mg,
0.009 mmol). The solvent was removed under reduced pres-
sure, and the residue was heated to 90 °C for 4 h. Chroma-
tography of the crude residue (elution with H:E, 10:1) provided
10 mg of faveline methyl ether (57) (76%) which was homo-
geneous by TLC analysis (H:E, 1:1, Rf 57 ) 0.82): mp 136-
138 °C [lit. for (()-4 is 139-140 °C;22 135-136 °C for (-)-47]:
1H NMR (250 MHz) δ 0.76 (s, 3 H), 1.13 (s, 3 H), 1.40-1.51
(m, 2 H), 1.55-1.85 (m, 2 H), 1.60 (s, 3 H), 2.19 (s, 3 H), 2.20-
2.50 (m, 3 H), 3.03 (dd, 2 H, J ) 6.1 Hz, 1.1 Hz), 3.88 (s, 3 H),
6.30 (s, 1 H), 7.63 (s, 1 H); GC-MS (m/z) 284 (69%), 215 (73%),
202 (100%), 173 (85%).
Continued elution (H:E, 1:1) provided 230 mg of alcohol 61
(50%) which was homogeneous by TLC analysis (H:E, 3:1, Rf
61 ) 0.22): 1H NMR (300 MHz) δ 0.86 (br s, 3 H), 1.01 (br s,
3 H), 1.05-1.15 (m, 2 H), 1.16-1.40 (m, 4 H), 1.42-1.60 (m, 5
H), 1.75 (br s, 1 H), 2.18 (s, 3 H), 3.82 (s, 1 H), 4.57 (d, 1 H, J
) 6.3 Hz), 6.72 (br s, 1 H), 6.85 (s, 1 H).
11a (R *),4(S *),4a (S *)-5-Ace t oxy-7-m e t h oxy-1,1,8-t r i-
m et h yl-1,2,3,4,4a ,10,11,11a -oct a h yd r o-5H -d ib en zo[a ,d ]-
cycloh ep ten e (62). To a solution of alcohol 61 (196 mg, 0.680
mmol) in 6 mL of CH2Cl2 were added TEA (0.2 mL), DMAP (4
mg, 0.036 mmol), and acetic anhydride (128 µL, 0.88 mmol).
The resulting mixture was stirred for 2 h. Standard ethereal
workup, followed by chromatography (H:E, 5:1), gave 209 mg
(93%) of the 62, an oil which was homogeneous by TLC
analysis (H:E, 2:1, Rf 62 ) 0.72): 1H NMR (250 MHz) δ 0.89
(s, 3 H), 1.00 (s, 3 H), 1.05-2.00 (m, 10 H), 2.09 (s, 3 H), 2.17
(s, 3 H), 3.81 (s, 3 H), 5.67 (d, 1 H, J ) 6.3 Hz), 6.67 (s, 3 H),
6.86 (s, 1 H); 13C NMR (62.9 MHz) 155.3 (s), 134.5 (s), 131.8
(d), 125.8 (s), 81.2 (br), 55.4 (q), 45.7 (br), 36.7 (br), 34.0 (t),
32.8 (br), 30.4 (q), 27.3 (q), 24.3 (br), 23.4 (br), 22.0 (t), 21.3
(q), 15.7 (q) ppm. Note: Six peaks observed were so broadened
by conformational interconversion that they were not detected
by DEPT for determination of the multiplicity. The four
remaining signals were not detected. IR (film) 1736, 1511,
1368, 1238, 733 cm-1; GC-MS (m/z) 330 (0.4%), 270 (39%), 201
(37%), 43 (100%). Anal. Calcd for C21H30O3: C, 76.3; H, 9.15.
Found: C, 76.26; H, 9.13.
4a (R *),5(R *),11a (R *)-5-Ace t oxy-7-m e t h oxy-1,1,8-t r i-
m et h yl-1,2,3,4,4a ,10,11,11a -oct a h yd r o-5H -d ib en zo[a ,d ]-
cycloh ep ten e (67). To a solution of alcohol 66 (127 mg, 0.44
mmol) in 3 mL of CH2Cl2 were added TEA (0.1 mL), DMAP (4
mg, 0.034 mmol), and acetic anhydride (83 µL, 0.88 mmol).
The resulting mixture was stirred at rt for a 30-min period.
Standard ethereal workup, followed by chromatography (H:
E, 4:1), gave 112 mg (77%) of acetate 67 which was homoge-
neous by TLC analysis (H:E, 2:1, Rf 67 ) 0.72). An analytical
sample was recrystallized isothermally from ether: mp 137-
138 °C; 1H NMR (300 MHz) δ 0.73 (s, 3 H), 0.93 (s, 3 H), 0.95-
1.80 (m, 8 H), 1.95-2.15 (m, 2 H), 2.17 (s, 6 H), 2.70-2.92 (m,
2 H), 3.82 (s, 3 H), 5.79 (d, 1 H, J ) 7.6 Hz); 13C NMR (62.9
MHz) 169.9 (s), 155.8 (s), 137.8 (s), 132.6 (s), 131.2 (d), 124.9
(s), 107.0 (d), 77.5 (d), 55.4 (q), 52.2 (d), 43.0 (d), 42.2 (t), 34.1
(s), 32.4 (t), 30.9 (q), 30.2 (t), 27.0 (t), 21.7 (t), 21.1 (q), 20.4
(q), 15.7 (q) (the benzylic methine at 77.5 overlaps the CDCl3
triplet, but is detected by DEPT) ppm; IR (KBr pellet) 1734,
1503, 1277, 1244, 1094 cm-1; GC-MS (m/z) 330 (M+, 0.1%), 270
(27%), 201 (19%), 43 (100%). Anal. Calcd for C21H30O3: C,
76.3; H, 9.15. Found: C, 76.22; H, 9.11.
11a (R *),4(S *),4a (S *)-5-Ace t oxy-7-m e t h oxy-1,1,8-t r i-
m et h yl-1,2,3,4,4a ,10,11,11a -oct a h yd r o-5H -d ib en zo[a ,d ]-
cycloh ep ten -10-on e (63). To a solution of acetate 62 (66 mg,
0.200 mmol) in 3 mL of CH2Cl2 were added PCC (323 mg, 1.50
mmol) and Celite (323 mg). The mixture was refluxed for 48
h. Standard ethereal workup, followed by chromatography
(elution with H:E, 4:1), gave 13 mg (20%) of unreacted 62 and
25 mg (36% yield, 56% based on mass balance) of ketone 63
which was homogeneous by TLC analysis (H:E, 2:1, Rf 63 )
0.31). An analytical sample was recrystallized isothermally
(()-F a velin e Meth yl Eth er (57) by Deh yd r a tion of (69).
To a solution of alcohol 69 (20 mg, 0.066 mmol) and DCC (19
mg, 0.092 mmol) in 0.1 mL of THF was added CuCl (1 mg,
0.009 mmol). The solvent was removed at reduced pressure,
and the residue was heated to 90 °C for a 14-h period.
Chromatography of the resulting residue (elution with H:E,
10:1) gave 12 mg of 57 (64%) which was identical to that
prepared from 64.
1
from ether: mp 177-179 °C; H NMR (250 MHz) δ 0.90 (s, 3
11a (R *),4(S *),4a (S *)-5,7-Dih yd r oxy-1,1,8-t r im e t h yl-
1,2,3,4,4a ,10,11,11a -octa h yd r o-5H-d iben zo[a ,d ]cycloh ep -
ten -10-on e (65). Sodium hydride (36 mg, 0.90 mmol of 60%
dispersion in mineral oil) was suspended in 1.5 mL of DMF.
Ethanethiol (111 µL, 1.50 mmol) was then added to the
H), 0.94 (s, 3 H), 1.10-1.90 (m, 6 H), 2.11-2.33 (m, 2 H), 2.19
(s, 3 H), 2.20 (s, 3 H), 2.56-2.82 (m, 2 H), 3.88 (s, 3 H), 5.74
(d, 1 H, J ) 9.4 Hz), 6.72 (s, 1 H), 7.47 (d, 1 H, J ) 0.5 Hz); 13
C
NMR (62.9 MHz) 204.5 (s), 169.9 (s), 161.0 (s), 137.4 (s), 130.9
(d), 128.3 (s), 126.0 (s), 104.8 (d), 77.7 (d), 55.3 (q), 41.4 (d),
38.9 (t), 38.6 (d), 34.4 (t), 33.1 (s), 29.9 (q), 26.9 (q), 24.9 (t),
21.0 (q), 20.8 (t), 15.6 (q) ppm; IR (KBr pellet) 1734, 1666, 1603,
1236, 1051 cm-1; GC-MS (m/z) 344 (4%), 302 (14%), 284 (38%),
reaction, and the resulting mixture was stirred for 1 h.
A
solution of ether 63 (52 mg, 0.150 mmol) dissolved in 1.5 mL
of DMF was added, and the mixture was heated to 135 °C for
3 h and then acidified by addition of 10% aqueous HCl.
