Schmidt laboratories demonstrated the combination of pho-
À
tocatalytic C H functionalization with benzaldehyde lyases,
ene-reductases, ketoreductases and aminotransferases; how-
ever, this chemistry was limited to low conversion and
restricted substrate classes.[16]
Additionally, both photoredox and enzymatic catalysis
have attracted great attention in the pharmaceutical industry
for the synthesis of active pharmaceutical ingredients.[17]
Notwithstanding the potential of photocatalytic/enzymatic
chemoenzymatic catalysis, this merger provides new oppor-
tunities to develop selective and valuable chemical trans-
formations. Despite the established capabilities of photo-
À
chemical methods for C H oxidations and enzymatic car-
bonyl reductions, the union of these two distinct chemistries
has not yet been realized to its fullest potential. Of particular
value is that this sequential catalytic reactivity affords not
only a powerful bond transformation, but also is attractive
because of the decreased operation costs and waste gener-
ation associated with a two-step procedure, as well as
minimizing the need for purification/isolation of intermedi-
ates. Herein we report the realization of this approach using
combined, single-flask photoredox/enzymatic catalysis for
Figure 2. Optimization of reaction conditions.
À
enantioselective hydroxylation of benzylic C H bonds (Fig-
ure 1C).
With optimal catalysts for both reactions, we turned to the
optimization of a process that would allow for both of these
operations to occur in a single flask. After considerable
experimentation, we found that IPA was deleterious to the
photoredox oxidation, and irradiation resulted in the enan-
tioenriched alcohol being reverted to the aromatic ketone
(Figure 2A). We circumvented this issue by delayed addition
of IPA after complete conversion of 1a with cessation of
irradiation, allowing for isolation of 3a in 85% yield with
> 99:1 er (Figure 2C). Control experiments demonstrated
that no conversion was observed when Acr+-Mes ClO4À, O2,
or light were omitted, and only aromatic ketone was observed
in the absence of either the KRED or NADPH (Figure 2B).
We envisioned 9-mesityl-10-methylacridinium ion (Acr+-
Mes ClO4 )[18] as an ideal catalyst for the photocatalytic
À
À
oxygenation of a C H bond due to its strong oxidizing ability
(E1/2 = 2.06 V vs. SCE). Mechanistically, we hypothesize that
the photocatalyst Acr+-Mes ClO4À is excited by blue LEDs to
generate [Acr+-MesClO4 ]* which undergoes single electron
À
À
transfer (SET) with the electronically benzylic C H bond to
generate the [Acr+-MesClO4 ] radical anion and the benzylic
À
radical cation.[19] The [Acr+-MesClO4 ]CÀ is subsequently
À
oxidized by O2 to regenerate Acr+-Mes ClO4 and form
À
O2CÀ, while the benzylic radical cation loses one proton to
form the benzylic radical. The benzylic radical may then react
with either an additional equivalent of O2 or O2CÀ to form the
hydroperoxidate intermediate, which upon dehydration ren-
ders the desired ketone product. Alternatively, the hydro-
peroxidate intermediate may also disproportionate to the
benzyl alcohol, which is subsequently oxidized by Acr+-Mes
ClO4À. The ketone is then reduced by a KRED using
NAD(P)H as the hydride source to provide the alcohol
product and NAD(P), which is regenerated to NAD(P)H
using isopropyl alcohol (IPA). Before attempting a single
flask photoredox/enzymatic procedure, we sought to identify
suitable conditions for the photoredox and enzymatic reac-
tion steps independently (Figure 2). The independent photo-
À
With this single flask C H hydroxylation process firmly
developed, we investigated the scope of this process (Table 1).
We surveyed a variety of substituted ethylbenzenes, and the
desired products were obtained in excellent yields and
enantioselectivities. Substrates bearing either electron-rich
or electron-neutral substituents were well tolerated across
substitution patterns on the aromatic ring (3a–3j). Unsur-
prisingly, unstabilized or electron-poor ethylbenzenes showed
no conversion under our optimized conditions, presumably
because the Acr+-Mes ClO4À is unable to oxidize the benzylic
methylene (E1/2 = 2.21 V vs. SCE for ethylbenzene). How-
ever, substituting for the more strongly oxidizing 4-mesityl-
redox reaction with Acr+-Mes ClO4 and O2 in 1:9
2,6-diphenylpyrylium tetrafluoroborate photocatalyst (E1/2 =
À
CH3CN:H2O provided 2a in 89% isolated yield after 4
hours. With these optimized photoredox oxidation conditions,
we evaluated the enzymatic reduction with 2a by surveying
a panel of isolated enzymes from Codexis Inc. (see the
Supporting Information for experimental details). We were
pleased to find that KRED-P1-A04 delivered 3a in 94%
isolated yield with > 99:1 er from 2a. Notably, no loss of
KRED activity was observed in the presence of 10% v/v
CH3CN, indicating the compatibility of the two reaction
processes.
2.62 V vs. SCE) provided facile oxidation of these substrates,
allowing for synthesis of the alcohols in good yields and
enantioselectivities (3k–3m).[20] A variety of diarylmethane
substrates were investigated, allowing access to diarylmetha-
nols.[21] Diarylmethanols are precursors for compounds with
physiologically interesting properties.[22] Electron-rich and
electron-poor substituents were well tolerated on either
aromatic ring (5a–5i). In addition, two substrates, 1a and
4a, were demonstrated on gram scale.g (7a–7d), d-lactones
(9a–9d) and a-hydroxy esters (11a–11d) were accessible in
