Suzuki Porphyrins: New Synthons for the
Fabrication of Porphyrin-Containing Supramolecular
Assemblies
Alison G. Hyslop, Matthew A. Kellett, Peter M. Iovine, and
Michael J. Therien*
Department of Chemistry, UniVersity of PennsylVania,
Philadelphia, PennsylVania 19104-6323
ReceiVed July 9, 1998
Palladium-catalyzed cross-coupling reactions that employ
halogenated porphyrin templates and a wide range of organome-
tallic moieties have provided synthetic entre´e into new families
of unusually elaborated porphyrin macrocyles.1-3 General,
economic syntheses of porphyryl organometallic reagents4 would
expand the scope of this methodology5,6 and aid in the design of
new classes of porphyrin-containing supramolecular assemblies
and tetraazamacrocycles with unconventional peripheral substit-
uents. Reported herein are the first examples of meso ring-
metalated porphyrin species in which boronic esters are appended
to a (porphinato)zinc(II) framework; we structurally characterize
the archetypal members of this new class of macrocycle-
derivatized porphyrins and briefly illustrate their utility in carbon-
carbon bond-forming reactions.
Masuda recently described a series of reactions in which
pinacolborane functions as a transmetalating reagent in Pd-
catalyzed cross-coupling reactions, enabling the synthesis of a
wide range of arylboronates from aryl halide precursors.7 Ap-
plication of this reaction to halogenated (porphinato)zinc(II)
complexes such as (5-bromo-10,20-diphenylporphinato)zinc(II)
and (5,15-dibromo-10,20-diphenylporphinato)zinc(II)1 gives the
corresponding [5-(4′,4′,5′,5′-tetramethyl[1′,3′,2′]dioxaborolan-2′-
yl)-10,20-diphenylporphinato]zinc(II) (I) and [5,15-bis(4′,4′,5′,5′-
tetramethyl[1′,3′,2′]dioxaborolan-2′-yl)-10,20-diphenylporphinato]-
zinc(II) (II) complexes in respective yields of 86 and 79%.8 These
compounds were structurally analyzed; the results of our single-
crystal X-ray crystallographic studies of I‚(benzene) and II‚
(pyridine) are shown in Figure 1.
In II‚(pyridine), the metal-ligand bond lengths and the
magnitude of the Zn atom displacement from the least-squares
plane defined by the macrocycle’s four Npyrrolyl atoms (0.35 Å)
typify that seen for other crystallographically characterized
(porphinato)zinc(II)‚(py) complexes.1b Interestingly, II’s axial
(1) (a) DiMagno, S. G.; Lin, V. S.-Y.; Therien, M. J. J. Am. Chem. Soc.
1993, 115, 2513-2515. (b) DiMagno, S. G.; Lin, V. S.-Y.; Therien, M. J. J.
Org. Chem. 1993, 58, 5983-5993.
(2) (a) Lin, V. S.-Y.; DiMagno, S. G.; Therien, M. J. Science 1994, 264,
1105-1111. (b) Lin, V. S.-Y.; Therien, M. J. Chem.-Eur. J. 1995, 1, 645-
651. (c) LeCours, S. M.; Guan, H.-W.; DiMagno, S. G.; Wang, C. H.; Therien,
M. J. J. Am. Chem. Soc. 1996, 118, 1497-1503. (d) LeCours, S. M.; DiMagno,
S. G.; Therien, M. J. J. Am. Chem. Soc. 1996, 118, 11854-11864.
(3) (a) Zhou, X.; Tse, M. K.; Wan, T. S. M.; Chan, K. S. J. Org. Chem.
1996, 61, 3590-3593. (b) Shultz, D. A.; Gwaltney, K. P.; Lee, H J. Org.
Chem. 1998, 63, 769-774.
(9) (a) Hunter, C. A.; Sanders, J. K. M. J. Am. Chem. Soc. 1990, 112,
5525-5534. (b) Hunter, C. A. Chem. Soc. ReV. 1994, 101-109.
(10) (a) de Rege, F. M. G.; Davis, W. M.; Buchwald, S. L. Organometallics
1995, 14, 4799-4807.
(11) Note that the O-â-H distance in a hypothetical structure in which the
pinacolborane and porphyrin moieties are coplanar (porphyrin structure
constant) is 2.14 Å.
(12) Pauling, L. The Nature of the Chemical Bond and the Structure of
Molecules and Crystals, an Introduction to Modern Structural Chemistry, 3d
ed.; Cornell University Press: Ithaca, NY, 1960.
(4) Few examples of a ring-metalated porphyrins have been reported; these
species include [2-(triphenylarsonium)-5,10,15,20-tetraphenylporphinato]zinc-
(II) perchlorate and 2,4-bis(chloromercuro)deuteroporphyrin IX dimethyl ester.
See: (a) Shine, H. J.; Padilla, G. A.; Wu, S.-M. J. Org. Chem. 1979, 44,
4069-4075. (b) Minnetian, O. M.; Morris, I. K.; Snow, K. M.; Smith, K. M.
J. Org. Chem. 1989, 54, 5567-5574.
(5) (a) Heck, R. F. Acc. Chem. Res. 1979, 12, 146-151. (b) Kumada, M.
Pure Appl. Chem. 1980, 52, 669-679. (c) Negishi, E.-I.; Luo, F. T.; Frisbee,
R.; Matsushita, H. Heterocycles 1982, 18, 117-122. (d) Stille, J. K. Angew.
Chem., Int. Ed. Engl. 1986, 25, 508-524.
(6) Miyaura, N.; Suzuki, A. Chem. ReV. 1995, 95, 2457-2483.
(7) Murata, M.; Watanabe, S.; Masuda, Y. J. Org. Chem. 1997, 62, 6458-
6459.
(8) Porphyrylboronates such as I and II can also be fabricated using
synthetic approaches reported by Miyaura which utilize the pinacol ester of
diboronic acid as a transmetalating reagent; see: Ishiyama, T.; Murata, M.;
Miyaura, N. J. Org. Chem. 1995, 60, 7508-7510. At least for these
halogenated porphyrinic substrates, this method afforded the porphyrylboronate
products in slightly lower yield with respect to that obtained using the approach
outlined in ref 7.
(13) Scheidt, W. R.; Kastner, M. E.; Hatano, K. Inorg. Chem. 1978, 17,
706-710.
(14) (a) Gupta, A.; Kirfel, A.; Will, G.; Wulff, G. Acta Crystallogr., Sect.
B 1977, B33, 637-641. (b) Schilling, B.; Kaiser, V.; Kaufmann, D. E. Chem.
Ber./Recl. 1997, 130, 923-932.
(15) Reaction conditions are similar to those developed for coupling
reactions utilizing arylboronic acids (see ref 6); details are provided as
Supporting Information.
(16) (a) Osuka, A.; Maruyama, K.; Mataga, N.; Asahi, T.; Yamazaki, I.;
Tamai, N. J. Am. Chem. Soc. 1990, 112, 4958-4959. (b) Helms, A.; Heiler,
D.; McLendon, G. J. Am. Chem. Soc. 1992, 114, 6227-6238. (c) de Rege, P.
J. F.; Williams, S. A.; Therien, M. J. Science 1995, 269, 1409-1413.
10.1021/ja982410h CCC: $15.00 © 1998 American Chemical Society
Published on Web 11/21/1998

Communications to the Editor
J. Am. Chem. Soc., Vol. 120, No. 48, 1998 12677
Figure 1. ORTEP views of (a) [5-(4′,4′,5′,5′-tetramethyl[1′,3′,2′]dioxaborolan-2′-yl)-10,20-diphenylporphinato]zinc(II)‚(benzene) and (b) [5,15-bis-
