328
P. Molina et al.
PAPER
(E)-2-Bromo-2'-(triphenylphosphoranylidene)aminostilbene
(5)
and the resulting mixture was stirred for 30 h. The solution was
poured into 5% aq NH4OH (200 mL) and stirring continued for 1 h,
followed by extraction with CH2Cl2 (5 × 100 mL). The combined
organic layers were washed with H2O, brine and dried (MgSO4).
The MgSO4 was removed by filtration, the filtrate concentrated to
dryness and the resulting solid was washed with Et2O, air-dried and
recrystallized from acetone/Et2O to give 8 (0.14 g); 85% yield; mp
239Ð240¡C.
Br2 (0.874 g, 5.47 mml) in anhyd benzene (6 mL) was added drop-
wise to a stirred solution of Ph3P (1.43 g, 5.47 mmol) in the same
solvent (12 mL) at 0¡C under N2. The mixture was stirred for 1 h
and then allowed to warm to r.t. A solution of 4 (1.5 g, 5.47 mmol)
and Et3N (1.11 g, 11.1 mmol) in anhyd benzene (15 mL) was added;
after 5 h of heating under reflux, triethylammonium bromide was
deposited and separated by filtration. The filtrate was concentrated
to dryness, and the residual material was slurried with anhyd Et2O
(2 × 10 mL) and recrystallized from CHCl3/hexane to give 5
(2.54 g); 87% yield; mp 170¡C.
IR (Nujol): n = 1180, 1379, 1469 cmÐ1.
1H NMR (300 MHz, acetone-d6 /TMS): d = 2.30 (s, 3 H, CH3), 7.34
(dm, 2 H, J= 8.6 Hz, Hm), 7.50 (td, 1 H, J = 7.6, 1.0 Hz, H-8), 7.61
(ddd, 1 H, J = 8.0, 6.8, 1.2 Hz, H-2), 7.69 (ddd, 1 H, J = 8.5, 7.3,
1.5 Hz, H-9), 7.83 (ddd, 1 H, J = 8.5, 6.8, 1.5 Hz, H-3), 8.10 (dd,
1 H, J = 8.0, 1.2 Hz, H-1), 8.19 (d, 2 H, J = 8.6 Hz, Ho), 8.21 (dm,
1 H, J = 8.5 Hz, H-4), 8.26 (ddd, 1 H, J =7.8, 1.5, 0.7 Hz, H-7), 8.50
(dt, 1 H, J = 8.5, 0.7 Hz, H-10), 8.97 (s, 1 H, H-11).
13C NMR (50 MHz, DMSO-d6 /TMS): d = 20.5 (CH3), 114.1 (C-
10), 118.2 (C-10a), 121.5 (C-7), 122.1 (C-10b), 123.8 (C-8), 124.9
(C-2), 125.0 (C-11a), 127.0 (Co), 127.8 (C-1), 127.9 (C-11), 128.0
(C-4), 128.9 (C-9), 129.2 (Cm), 129.3 (C-3), 134.9 (Ci), 138.5 (Cp),
144.9 (C-6a), 145.3 (C-4a), 150.1 (C-5a).
IR (Nujol): n = 1108, 1334, 1444, 1588 cmÐ1.
1H NMR (300 MHz, CDCl3/TMS): d = 6.46 (dt, 1 H, J = 8.1 Hz, JP,H
= 1.4 Hz, H-3'), 6.69 (t, 1 H, J = 7.8 Hz, H-5'), 6.82 (td, 1 H, J = 7.8,
1.6 Hz, H-4'), 7.02 (td, 1 H, J = 7.8, 1.6 Hz, H-4), 7.26 (td, 1 H, J =
7.6, 0.6 Hz, H-5), 7.38Ð7.55 (m, 11 H, 6 Hm + 3 Hp + H-3 + H-7),
7.62 (dt, 1 H, J = 7.8 Hz, JP,H =1.9 Hz, H-6' ), 7.73Ð7.80 (m, 7 H,
6Ho + H-6), 8.16 (d, 1 H, J = 16.2 Hz, H-8 ).
13C NMR (75 MHz, CDCl3/TMS): d = 117.8 (C-5'), 122.3 (d, 3JP,C
= 9.8 Hz, C-3'), 123.8 (C-2), 124.2 (C-7), 126.1 (d, 4JP,C = 1.0 Hz, C-
6' ), 126.5 (C-6),127.3 (C-5), 127.6 (C-4), 128.2 (C-4'), 128.6 (d,
MS (EI, 70 eV); m/z (%) = 372 (M+,27), 308 (M+ Ð 64, 100), 217
1
3JP,C = 12.1 Hz, Cm), 131.0 (C-8), 131.3 (d, JP,C = 99.8 Hz, Ci),
(M+ Ð 155, 97).
3
4
131.3 (d, JP,C = 20.1 Hz), 131.7 (d, JP,C = 2.3 Hz, Cp), 132.5 (d,
2JP,C = 9.8 Hz, Co), 132.9 (C-3), 138.7 (C-1), 149.5 (C-2').
Anal. Calcd for C22H16N2SO2: C, 70.95; H, 4.33; N, 7.52; S, 8.61.
Found: C, 71.03; H, 4.38; N, 7.59; S, 8.65.
31P NMR (121 MHz, CDCl3/H3PO4 85%): d = 1.47.
MS (EI, 70 eV); m/z (%) = 535 (M++2, 40), 533 (M+, 40), 454 (M+
Ð Br, 10), 262 (100).
6H-Indolo[2,3-b]quinoline (9)
A solution of indolo[2,3-b]quinoline 8 (0.21 g, 0.56 mmol) in anhyd
THF (40 mL) was heated at reflux temperature for 10 min, then 1M
TBAF in THF (1.4 mL, 1.4 mmol) was added dropwise under N2.
The resultant mixture was stirred at reflux temperature for 6 h. After
cooling, the solvent was removed under reduced pressure and the
solid residue was dissolved in CH2Cl2 (30 mL). The solution was
washed with H2O (2 × 10 mL) and dried (MgSO4). After filtration
the solution was concentrated to 10 mL and the precipitated solid
was collected by filtration, washed with Et2O and air-dried to give
9 (0.11 g); 90% yield; mp > 300¡C (Lit.13 mp 346¡C).
Anal. Calcd for C32H25BrNP: C, 71.92; H, 4.72; N, 2.62; Br, 14.95;
P, 5.80. Found: C, 71.88; H, 4.65; N, 2.69; Br, 15.03; P, 5.75.
3-(2-Bromophenyl)-2-tosylaminoquinoline (7)
To a solution of iminophosphorane 5 (1 g, 1.87 mmol) in anhyd tol-
uene (25 mL) cooled at 0¡C was added dropwise a solution of to-
sylisocyanate (0.384 g, 1.87 mmol) in the same solvent (1 mL)
under N2. Then, the solution was allowed to warm to r.t. and stirring
was continued for 1 h (until the IR spectrum of the crude showed
the total disappearance of a strong band at 2230 cmÐ1 due to the iso-
cyanate and the appearance of a strong band at 2150 cmÐ1 due to the
carbodiimide 6). The mixture was heated at reflux temperature for
14 h. After cooling, the solvent was removed under reduced pres-
sure and the residual material was chromatographed on a silica gel
column using EtOAc/hexane (1:2) as eluent to give 7 (0.61 g); 72%
yield; mp 209Ð210¡C (CH2Cl2/hexane).
IR (Nujol): n = 1237, 1411, 1616, 3148 cmÐ1.
1H NMR (300 MHz, DMSO-d6 /TMS): d = 7.27 (tm, 1 H, H-9), 7.48
(td, 1 H, J = 7.3, 1.0 Hz, H-2), 7.50 (d, 1 H, J = 6.8 Hz, H-7), 7.53
(td, 1 H, J = 8.1, 1.0 Hz, H-8), 7.72 (ddd, 1 H, J = 8.5, 6.8, 1.0 Hz,
H-3), 7.98 (d, 1 H, J = 7.9 Hz, H-9), 8.11 (dd, 1 H, J = 8.1, 1.0 Hz,
H-1), 8.26 (d, 1 H, J = 7.7 Hz, H-10), 9.05 (s, 1 H, H-11), 11.70 (s,
1 H, NH).
13C NMR (50 MHz, DMSO-d6 /TMS): d = 111.1 (C-7), 118.1 (C-
10b), 119.9 (C-9), 120.5 (C-11a), 122.0 (C-10), 122.9 (C-2), 123.9
(C-10a), 127.1 (C-1), 127.7 (C-11), 128.4 (C-4), 128.8 (C-8 + C-3),
141.7 (C-6a), 146.5 (C-4a), 153.1 (C-5a).
IR (Nujol): n = 1080, 1547, 1610, 1635, 3212, 3244 cmÐ1.
1H NMR (300 MHz, DMSO-d6 /TMS): d = 2.32 (s, 3 H, CH3), 7.20Ð
7.52 (m, 6 H), 7.60Ð7.78 (m, 4 H), 7.85 (d, 1 H, J = 7.7 Hz, H-5),
8.02 (d, 1 H, J = 8.1 Hz, H-8), 8.16 (s, 1 H, H-4), 12.26 (s, 1 H, NH).
13C NMR (75 MHz, CDCl3/TMS): d = 21.4 (CH3), 116.6 (C-8),
120.8 (C-3), 123.8 (C-2'), 124.7 (Co), 126.2 (C-6), 127.2 (C-5),
128.2 (C-5Õ), 129.0 (Cm), 129.8, 131.5, 132.6 133.2 (C-4a), 136.0
(C-8a), 136.7 ( C-1Õ), 139.9 (Ci), 140.7 (C-4), 142.4 (Cp), 152.7 (C-
2).
MS (EI, 70 eV); m/z (%) = 219 (M++1, 36), 218 (M+ +100), 190
(22).
Cryptotackieine (1)
6H-Indolo[2,3-b]quinoline (9; 50 mg, 0.23 mmol) and dimethyl
sulfate (0.45 g, 3.6 mmol) were dissolved in anhyd DMF (4 mL) in
a glass tube which was placed in a Synthewave 402 reactor and ir-
radiated for 5 min at 140¡C. After cooling, the reaction mixture was
poured into H2O (4 mL) and a solution of 2 N NaOH was added un-
til basic pH. The precipitated solid was collected by filtration,
washed with H2O, air-dried and recrystallized from hexane to give
1 (39.9 mg); 75% yield; mp 107Ð109¡C (Lit14 mp 108Ð110¡C).
MS (EI, 70 eV); m/z (%) = 454 (M++2, 3), 452 (M+, 3), 373 (M+ Ð
Br, 55), 218 (M+ Ð 234, 100).
Anal. Calcd for C22H17BrN2SO2: C, 58.29; H, 3.78; N, 6.18; Br,
17.60; S, 7.07. Found: C, 58.32; H, 3.85; N, 6.22; Br, 17.68; S, 7.13.
6-Tosyl-6H-indolo[2,3-b]quinoline (8)
To a solution of quinoline 7 (0.2 g , 0.44 mmol) in diglyme (20 mL)
was added CuI (0.4 g, 2.12 mmol) under N2. The mixture was
stirred at r.t. for 30 min. Then, NaH (0.061 g, 2.42 mmol) was added
Spectral data (IR, 1H and 13C NMR) were identical to those reported
for the natural product.3,4
