Magnetic Glyco-Nanoparticles: A Tool To Detect, Differentiate,
and Unlock the Glyco-Codes of Cancer via Magnetic
Resonance Imaging
Kheireddine El-Boubbou,† David C. Zhu,‡ Chrysoula Vasileiou,† Babak Borhan,†
Davide Prosperi,§ Wei Li,⊥ and Xuefei Huang*,†
Departments of Chemistry, Radiology, and Psychology, Michigan State UniVersity, East Lansing,
Michigan 48824, Department of Biotechnology and Bioscience, UniVersity of Milano-Bicocca,
Piazza della Scienza 2, 20126 Milan, Italy, and College of Pharmacy, UniVersity of Tennessee
Health Science Center, 847 Monroe AVenue, Memphis, Tennessee 38163
Received January 18, 2010; E-mail: xuefei@chemistry.msu.edu
Abstract: Within cancer, there is a large wealth of diversity, complexity, and information that nature has
engineered rendering it challenging to identify reliable detection methods. Therefore, the development of
simple and effective techniques to delineate the fine characteristics of cancer cells can have great potential
impacts on cancer diagnosis and treatment. Herein, we report a magnetic glyco-nanoparticle (MGNP) based
nanosensor system bearing carbohydrates as the ligands, not only to detect and differentiate cancer cells
but also to quantitatively profile their carbohydrate binding abilities by magnetic resonance imaging (MRI).
Using an array of MGNPs, a range of cells including closely related isogenic tumor cells, cells with different
metastatic potential and malignant vs normal cells can be readily distinguished based on their respective
“MRI signatures”. Furthermore, the information obtained from such studies helped guide the establishment
of strongly binding MGNPs as antiadhesive agents against tumors. As the interactions between glyco-
conjugates and endogenous lectins present on cancer cell surface are crucial for cancer development and
metastasis, the ability to characterize and unlock the glyco-code of individual cell lines can facilitate both
the understanding of the roles of carbohydrates as well as the expansion of diagnostic and therapeutic
tools for cancer.
tendencies to mutate,7,8 their antigenic variants may escape the
detection leading to false negative results. An appealing
Introduction
Cancer is a complex group of diseases that affect the lives
of millions of people worldwide. Each malignant cell type has
molecular signatures that distinguish it from its healthy coun-
terpart. The availability of simple and fast methods to identify
the unique cellular characteristics can greatly benefit cancer
treatment and improve the clinical outcomes for patients.1-3
Currently, the majority of methods for cancer detection target
biomarkers such as mutated DNA/RNA and overexpressed
antigens.1,3–5 This requires extensive prior knowledge on the
presence of the specific markers,4,6 which can be very time-
consuming to acquire. Furthermore, as tumor cells have high
alternative is to take advantage of cell surface receptor mediated
recognition events. Receptor binding is often critical to cell
functions and usually cannot be abolished without affecting cell
viability. In addition, cell surface receptors would be easier to
target without requiring the probes to cross the cellular
membrane as compared to intracellular markers.
An attractive target for receptor-mediated interaction is
carbohydrates and, in particular glycoconjugates, which play
important roles in cancer development and metastasis.9-12
Carbohydrates are uniquely suited for encoding biological
information because of their rich structural variations.13-15
Aberrant glycosylations on tumor cell surfaces have been
† Department of Chemistry, Michigan State University.
‡ Departments of Radiology and Psychology, Michigan State University.
§ University of Milano-Bicocca.
(7) Hynes, N. E.; MacDonald, G. Curr. Opin. Cell Biol. 2009, 21, 177–
184.
⊥ University of Tennessee Health Science Center.
(1) Lee, H.; Yoon, T.-J.; Figueiredo, J.-L.; Swirski, F. K.; Weissleder, R.
Proc. Natl. Acad. Sci. U.S.A. 2009, 106, 12459–12464.
(2) Bajaj, A.; Miranda, O. R.; Kim, I.-B.; Phillips, R. L.; Jerry, D. J.;
Bunz, U. H. F.; Rotello, V. M. Proc. Natl. Acad. Sci. U.S.A. 2009,
106, 10912–10916, and references therein.
(8) Klein, C. A.; Blankenstein, T. J. F.; Schmidt-Kittler, O.; Petronio,
M.; Polzer, B.; Stoecklein, N. H.; Riethmu¨ller, G. Lancet 2002, 360,
683–689.
(9) Freire, T.; Bay, S.; Vichier-Guerre, S.; Lo-Man, R.; Leclerc, C. Mini-
ReV. Med. Chem. 2006, 6, 1357–1373.
(3) Nagrath, S.; Sequist, L. V.; Maheswaran, S.; Bell, D. W.; Irimia, D.;
Ulkus, L.; Smith, M. R.; Kwak, E. L.; Digumarthy, S.; Muzikansky,
A.; Ryan, P.; Balis, U. J.; Tompkins, R. G.; Haber, D. A.; Toner, M.
Nature 2007, 450, 1235–1239.
(10) Hakomori, S. Proc. Natl. Acad. Sci. U.S.A. 2002, 99, 10231–10233.
(11) Danishefsky, S. J.; Allen, J. R. Angew. Chem., Int. Ed. 2000, 39, 836–
863, and references therein.
(12) Hakomori, S.; Zhang, Y. Chem. Biol. 1997, 4, 97–104.
(13) Gabius, H.-J. Biochem. Soc. Trans. 2008, 36, 1491–1496.
(14) Gabius, H.-J.; Siebert, H.-C.; Andre´, S.; Jime´nez-Barbero, J.; Ru¨diger,
H. ChemBioChem 2004, 5, 740–764.
(4) Pantel, K.; Brakenhoff, R. H.; Brandt, B. Nat. ReV. Cancer 2008, 8,
329–340.
(5) Ludwig, J. A.; Weinstein, J. N. Nat. ReV. Cancer 2005, 5, 845–856.
(6) Ferrari, M. Nat. ReV. Cancer 2005, 5, 161–171.
(15) Varki, A. Glycobiology 1993, 3, 97–130.
9
4490 J. AM. CHEM. SOC. 2010, 132, 4490–4499
10.1021/ja100455c  2010 American Chemical Society

Magnetic Glyco-Nanoparticles To Detect Tumor Cells
A R T I C L E S
extensively probed by antibodies and plant-derived lectins.12,16
This led to the identification of characteristic tumor-associated
carbohydrate molecules,11,12 which has greatly facilitated the
development of carbohydrate-based anticancer vaccine studies.9,17
In comparison, the understanding of carbohydrate-binding
properties of tumors is not as advanced. Cancer cells can interact
with the extracellular matrix in their microenvironment through
endogenous receptors binding with carbohydrates.18-20 These
interactions vary, depending on the physiological state of the
cells, as supported by the ground-breaking histological studies
of tumor tissues.21-23 Therefore, the ability to characterize and
distinguish carbohydrate binding profiles of a variety of cells
can expedite both the mechanistic understanding of their roles
in disease development and the expansion of diagnostic and
therapeutic tools.24-26 As the distinctions among cancer cell
subtypes and malignant vs normal cells can often be subtle, a
suitable tool is needed to quantitatiVely analyze the fine
characteristics in carbohydrate binding of various cell types.
MGNPs can allow cell detection via magnetic resonance
imaging (MRI) without the need to prelabel the cells.31–33
One challenge, however, in using MGNPs and carbohydrates
for molecular recognition is that multiple cell types may bind
with the same carbohydrate structure albeit in different affinities.
To address this issue, we envision that by pooling the responses
from an array of MGNPs, the various cell types may be
differentiated through pattern recognition.2,34-36 Furthermore,
the information obtained on the physiologically relevant
carbohydrate-receptor interaction can not only enhance our
understanding of the roles carbohydrate play in cancer but also
guide the development of potential therapeutics such as agents
against cancer adhesion. Although glyco-nanoparticles have been
previously employed for elegant studies of carbohydrate-
mediated biological recognitions,37-48 MGNPs have not been
utilized to detect and systematically profile mammalian cells.
