Langmuir Film Polymerization of
1,22-Bis(2-aminophenyl)docosane: A
Two-Dimensional Cross-linked Polyalkylaniline
L. J. Kloeppner and R. S. Duran*
Center for Macromolecular Science and Engineering
Department of Chemistry, UniVersity of Florida
GainesVille, Florida 32611
ReceiVed January 14, 1999
Ultrathin films have been proposed for many applications such
as in nonlinear optical1-5 and electroluminescent devices6,7 and
sensors.8,9 However, most applications require the films to be
mechanically, thermally, and chemically stable under environ-
mental conditions, which is often difficult to achieve. Polymeric
systems are usually more stable than low molar mass analogues
due to covalent bonding in the film plane and are often preferred.10
Further, network polymers in 3-dimensions are generally more
stable to thermal and physical stress than their non-cross-linked
counterparts, and therefore, free-standing monolayers of this type
should also have improved stability. Though the potential for these
types of films is great, there are few published reports that deal
with Langmuir films that form 2-dimensional network poly-
mers.11-15 Self-assembled organic monolayers on solid substrates
show some of these characteristics, but require specific substrates
and therefore cannot be a general method to produce stable, free-
standing films.16-18
(i) TsCl, pyridine, and CHCl3; (ii) LiBr, acetone, and heat; (iii) PPh3
CH3CN, and heat; (iv) potassium tert-butoxide, 2-nitrobenzaldehyde, and
THF; (v) H2, 10% Pd on carbon, and 95% ethanol.
This communication presents the Langmuir film polymerization
of a dipolar monomer, 1,22-bis(2-aminophenyl)docosane (BAD),
which forms a 2-dimensional network polymer of polyalkylaniline.
The surface behavior of BAD is presented and compared with
that of the monopolar surfactant, 2-pentadecylaniline (PDA),
which is routinely polymerized in Langmuir films.19-21
