Convenient synthesis of chiral cyclophanes that can coordinate to metals

Article abstract of DOI:10.1021/ja983907u

Optically pure cyclophanes possessing a 1,3-dicarbonyl moiety were conveniently synthesized from alkanedioyl dichloride in four steps. The intramolecular [4+2]cycloaddition of bis(acylketene)s generated by thermal decomposition of bis(4,6-dioxo-1,3-dioxane) proceeded smoothly, giving cyclophane pyranones in high yields. The compounds possessing 7-10 bridging methylenes were resolved by imine formation with (R)-1-phenylethylamine, followed by basic hydrolysis. These cyclophanes are optically active versions of acetylacetone or salicylaldehyde and formed complexes with metals such as copper and europium. X-ray analysis of the chiral copper complex indicated the pentacoordinated structure of the copper metal with syn configuration of the two bridging chains.

Full text of DOI:10.1021/ja983907u

8270
J. Am. Chem. Soc. 1999, 121, 8270-8276
Convenient Synthesis of Chiral Cyclophanes that Can Coordinate to
Metals
Masayuki Sato,*,† Fumiaki Uehara, Kayo Sato, Masahiko Yamaguchi,* and
Chizuko Kabuto‡
Contribution from the Department of Organic Chemistry, Graduate School of Pharmaceutical Sciences,
Tohoku UniVersity, Aoba, Sendai 980-8578, Japan
ReceiVed NoVember 12, 1998
Abstract: Optically pure cyclophanes possessing a 1,3-dicarbonyl moiety were conveniently synthesized from
alkanedioyl dichloride in four steps. The intramolecular [4+2]cycloaddition of bis(acylketene)s generated by
thermal decomposition of bis(4,6-dioxo-1,3-dioxane) proceeded smoothly, giving cyclophane pyranones in
high yields. The compounds possessing 7-10 bridging methylenes were resolved by imine formation with
(R)-1-phenylethylamine, followed by basic hydrolysis. These cyclophanes are optically active versions of
acetylacetone or salicylaldehyde and formed complexes with metals such as copper and europium. X-ray analysis
of the chiral copper complex indicated the pentacoordinated structure of the copper metal with syn configuration
of the two bridging chains.
Cyclophanes, some of which can be chiral, are an interesting
group of compounds.1 When the ansa chain is sufficiently short,
cyclophanes exhibit planar chirality due to the restricted rotation
of the aromatic ring. The chirality might show chemical and
physical properties different from those of the tetrahedral or
the axial chirality. For example, since an enantioface of the
aromatic ring in the cyclophane is shielded by the ansa chain,
it can provide an effective chiral environment for asymmetric
catalysis. It should also be noted that cyclophanes are a chiral
equivalent of aromatic compounds. Since materials very often
possess aromatic rings in their structure, substitution of such
group with cyclophane converts achiral compounds to chiral,
which can be an interesting approach for chiral materials. Quite
a limited number of reports, however, appeared on the studies
of chiral cyclophanes.2,3 It may be due to the lack of an efficient
synthetic method for optically pure cyclophanes with suitable
functionalities. The syntheses have been rather lengthy, and
therefore, introduction of functionalized groups was not facile.
Described here is a convenient method for synthesizing cyclo-
phanes 1, which have a pyranone ring as the aromatic moiety
(Figure 1). Optically pure 1 can be prepared from commercially
available diacid dichlorides in a few steps using the intramo-
lecular [4+2]cycloaddition of bis(acylketene)s4-6 as the key
step. These cyclophanes possessing a 1,3-dicarbonyl moiety are
a chiral equivalent of acetylacetone or salicylaldehyde and are
capable of coordinating to metals.
Figure 1. Chiral cyclophanes.
Bis(4,6-dioxo-1,3-dioxane)s 4 (n ) 6-12, 16) were synthe-
sized from the corresponding diacid dichlorides 2 (n ) 6-12,
16) and Meldrum’s acid 3 (Scheme 1 and Table 1) in the
presence of pyridine at 0 °C to room temperature.7 Then slow
addition of 4 (n ) 7-12, 16) to refluxing chlorobenzene under
highly diluted conditions (1 × 10-4 M) gave (()-1 (n ) 7-12,
16) generally in high yields. At temperatures higher than 130
°C, 4 (n ) 7-12, 16) lost acetone and carbon dioxide generating
bis(acylketene)s 5 (n ) 7-12, 16),6 which cyclized via [4+2]-
cycloaddition. The high efficiency of the cyclophane formation
may be ascribed to the very rapid reaction rate of the cycload-
dition. The synthesis could be carried out on a 10 mmol scale,
and the cyclophanes (()-1 (n ) 7-11) were readily separated
from oligomeric compounds by distillation. Higher homologues
(()-1 (n ) 12, 16) were isolated by chromatography on neutral
silica gel, which contains a lower quantity of metal cations
compared to the usual silica gel. Chromatography of 1 on the
latter resulted in strong adsorption, and 1 was obtained as an
orange material, probably due to chelation with metal cations
† School of Pharmaceutical Sciences, University of Shizuoka, Yada,
Shizuoka 422-8526, Japan.
‡ Instrumental Analysis Center for Chemistry, Graduate School of
Science, Tohoku University, Aoba, Sendai 980-8578, Japan.
(1) Review. Cram, D. J.; Cram, J. M. Acc. Chem. Res. 1971, 4, 204.
Bodwell, G. J. Angew. Chem., Int. Ed. Engl. 1996, 35, 2085.
(2) Asymmetric synthesis. Tachibana, Y.; Ando, M.; Kuzuhara, H. Chem.
Lett. 1982, 1765. Reich, H. J.; Yelm, K. E. J. Org. Chem. 1991, 56, 5672.
Antonov, D. Y.; Belokon, Y. N.; Ikonnikov, N. S.; Oelova, S. A.; Pisarevsky,
A. P.; Raevski, N. I.; Rozenberg, V. I.; Sergeeva, E. V.; Stuchkov, Y. T.;
Tararov, V. I.; Vorontsov, E. V. J. Chem. Soc., Perkin Trans I 1995, 1873.
Kanomata, N.; Nakata, T. Angew. Chem., Int. Ed. Engl. 1997, 36, 1207.
Pye, P. J.; Rossen, K.; Reamer, R. A.; Tsou, N. N.; Volante, R. P.; Reider,
P. J. J. Am. Chem. Soc. 1997, 119, 6207.
(4) Reviews for acylketene: Tidwell, T. T. Ketenes; John Wiley &
Sons: New York, 1995. Wentrup, C.; Heilmayer, W.; Kollenz, G. Synthesis
1994, 1219. Kaneko, C.; Sato, M.; Sakaki, J.; Abe, Y. J. Heterocycl. Chem.
1990, 27, 25.
(5) Carrol, M. F.; Bader, A. R. J. Am. Chem. Soc. 1952, 74, 6305. Carrol,
M. F.; Bader, A. R. J. Am. Chem. Soc. 1953, 75, 5400. Ja¨ger, G.;
Wenzelbuger, J. Liebigs Ann. Chem. 1976, 1689.
(6) Sato. M.; Ogasawara, H.; Kato, T. Chem. Pharm. Bull. 1984, 32,
2602. Sato. M.; Sekiguchi, K.; Ogasawara, H.; Kaneko, C. Synthesis 1985,
224. Sato. M.; Yoneda, N.; Katagiri, N.; Watanabe, N.; Kaneko, C. Synthesis
1986, 672. Sato, M.; Ban, H.; Kaneko, C. Tetrahedron Lett. 1997, 38, 6689.
(7) Oikawa, Y.; Sugano, K.; Yonemitsu, O. J. Org. Chem. 1978, 43,
2087.
(3) Chiral polymer. Fiesel, R.; Huber, J.; Scherf, U. Angew. Chem., Int.
Ed. Engl. 1996, 35, 2111.
10.1021/ja983907u CCC: $18.00 © 1999 American Chemical Society
Published on Web 08/31/1999

Chiral Cyclophanes that Can Coordinate to Metals
J. Am. Chem. Soc., Vol. 121, No. 36, 1999 8271
Scheme 1
Figure 2. ORTEP drawing of (R,R)-6 (n ) 10) along with the atomic
numbering scheme. Thermal ellipsoids are drawn at the 30% probability
level.
Scheme 2
(n ) 6, 7, 8) and 7b (n ) 6, 7, 8), while such dimers were not
detected in the higher homologues (Table 1, Scheme 2). The
structures of 7a (n ) 8) and 7b (n ) 8) were determined by
chemical transformations: The treatment of 7a (n ) 8) with
90% sulfuric acid at 130 °C gave pyranonenonanoic acid 8.
Bis(pyranone) 9 and decanedioic acid 10 were obtained from
7b (n ) 8).
The cyclophanes (()-1 (n ) 7-10) were resolved by
treatment with (R)-1-phenylethylamine, followed by chromato-
graphic separation to give diastereomeric imines (S,R)-6 (n )
7-10) and (R,R)-6 (n ) 7-10) (Scheme 1 and Table 1).
Although diastereomeric imines (S,R)-6 (n ) 11) and (R,R)-6
(n ) 11), which possessed a longer ansa chain, could be
observed by 1H NMR, they were not stable enough to be
separated at room temperature. TLC of this mixture showed
two spots only when the chromatography was conducted at -15
°C. A single imine compound was obtained from 6 (n ) 12,
16). The relationship between the bridging chain length and the
stability of the planar chirality is similar to that of known
benzene and pyridine cyclophanes.8 The configuration of (R,R)-6
(n ) 10) was determined by X-ray crystallographic analysis
based on the (R)-configuration of the amine moiety (Figure 2
and Table 2).
Table 1. Synthesis of Chiral Cyclophanes
yield (%)
n
4
(()-1
7a/7b
(R,R)-6/(S,R)-6
(R)-1
(S)-1
6
76
88
74
74
75
71
70
87
18 (1:1)a
28 (1:1)a
6 (1:1)a
7
8
27
68
88
90
87
82
83
41:43
41:36
41:40
50:48
57:43b
99
100
85
92
100
97
9
10
11
12
16
87
99
a Isomer ratio is shown in parentheses. b The diastereomers were
1
detected by H NMR, although not isolable.
such as Fe3+. The observations indicated the high affinity of 1
toward metals.
The yield of (()-1 (n ) 7) decreased, and (()-1 (n ) 6)
could not be obtained under the present reaction conditions,
which presumably was due to their strained nature. One of the
bridging methylene protons of (()-1 (n ) 7) appeared at δ 0.18
in 1H NMR spectra, reflecting the close proximity of the proton
to the pyranone ring. Dimeric products were obtained in the
reactions of (()-4 (n ) 6, 7, 8) as mixtures of two isomers 7a
(8) For example, see, Lu¨ttringhaus, A.; Eyring, G. Liebigs Ann. Chem.
1957, 604, 111. Blomquist, A. T.; Roland, E. S.; Meinwald, Y. C.; Smith,
B. H. J. Org. Chem. 1961, 26, 1687. Nakazaki, M.; Yamamoto, K.;
Okamoto, S. Tetrahedron Lett. 1969, 4597.
