2166 J ournal of Medicinal Chemistry, 1998, Vol. 41, No. 12
Posner et al.
J ) 6.4), 2.6 (m, 1 H), 6.82 (dd, 1 H, J ) 1.6, 15.6), 7.04 (dd,
1 H, J ) 6.8, 15.6 Hz), 7.6-7.4 (m, 3 H), 7.95-7.90 (m, 2 H);
13C NMR (CDCl3) δ 21.4, 31.5, 123.0, 128.41, 128.44, 132.5,
138.0, 156.0, 191.3; FT-IR (neat, cm-1) 1672, 1619.
Exp er im en ta l Section
Gen er a l. Unless otherwise noted, reactions were run in
oven-dried glassware under an atmosphere of argon. Diethyl
ether (ether) and tetrahydrofuran (THF) were distilled from
sodium benzophenone ketyl prior to use. Methylene chloride
(CH2Cl2) was distilled from calcium hydride prior to use. All
other compounds were purchased from Aldrich Chemical Co.
and used without further purification. Analytical thin-layer
chromatography (TLC) was conducted with silica gel 60 F254
plates (250 mm thickness, Merck). Column chromatography
was performed using flash silica gel (partical size 400-230
mesh). Yields are not optimized. Purity of final products was
judged to be >95% based on their chromatographic homogene-
ity. High-performance liquid chromatography (HPLC) was
carried out with a Rainin HPLX system equipped with two 25
mL/min preparative pump heads using a Rainin Dynamax 10
mm × 250 mm (semipreparative) column packed with 60 Å
silica gel (8 µm pore size) as bare silica. Melting points were
measured using a Mel-Temp metal-block apparatus and are
uncorrected. Nuclear magnetic resonance (NMR) spectra were
obtained either on a Varian XL-400 spectrometer, operating
at 400 MHz for 1H and 100 MHz for 13C. Chemical shifts are
reported in parts per million (ppm, δ) downfield from tetra-
methylsilane. Splitting patterns are described as singlet (s),
doublet (d), triplet (t), quartet (q), multiplet (m), and broad
(br). Infrared (IR) spectra were obtained using a Perkin-Elmer
1600 FT-IR spectrometer. Resonances are reported in wave-
numbers (cm-1). Low- and high-resolution mass spectra
(LRMS and HRMS) were obtained with electronic or chemical
ioniztion (EI or CI) either (1) at J ohns Hopkins University on
a VG Instruments 70-S spectrometer run at 70 eV for EI and
run with ammonia (NH3), butane (C4H10), or methane (CH4)
as carrier gas for CI or (2) at the University of Illinois at
Champaign-Urbana on a Finnigan-MAT CH5, a Finnigan-
MAT 731, or a VG Instruments 70-VSE spectrometer run at
70 eV for EI and run with methane (CH4) for CI. Combustion
analyses were conducted by Atlantic Microlab (Norcross, GA).
Dim eth yl P h en yl P er oxy Keta l 1a . Phenyl enone 4a
(247 mg, 1.42 mmol) and copper(II) sulfate (20 mg) were
irradiated for 17 h according to general procedure 2. Flash
column chromatography of the crude product using 5% EtOAc/
hexanes on silica gel gave desired peroxide 1a (119 mg, 0.54
mmol, 38%) as a white solid: mp 35-38 °C; 1H NMR (CDCl3)
δ 1.33 (s, 3), 3.38 (s, 3), 5.78 (d, 1, J ) 10 Hz), 5.98 (d, 1, J )
10 Hz), 7.4-7.3 (m, 3), 7.5 (m, 2); 13C NMR (CDCl3) δ 24.53,
24.60, 51.4, 76.9, 99.6, 125.7, 126.4, 128.5, 128.6, 134.1, 138.0;
HRMS m/z (M + H+) calcd. 221.1178, found 221.1179. Ketal
1a was further purified using HPLC prior to antimalarial
testing (10% EtOAc/hexanes, 3.0 mL/min, 254 nm, tR ) 9.9
min).
Ack n ow led gm en t. We thank the NIH (AI-34885
and NCRR OPD-GCRC RR 00722) and the Burroughs
Wellcome Fund for financial support.
Su p p or tin g In for m a tion Ava ila ble: 1H and 13C NMR,
IR, and mass spectral data for peroxy ketals 1b-t and for
hemiketal 5 and propoxy ketal 6 (8 pages). Ordering informa-
tion is given on any current masthead page.
Refer en ces
(1) Meshnick, S. R.; Taylor, T. E.; Kamchonwongpaisan, S. Arte-
misinin and the antimalarial endoperoxides: from herbal rem-
edy to targeted chemotherapy. Microbiol. Rev. 1996, 60, 301-
315.
(2) Cumming, J . N.; Ploypradith, P.; Posner, G. H. Antimalarial
activity of artemisinin (qinghaosu) and related trioxanes: mech-
anism(s) of action. Adv. Pharmacol. 1997, 37, 2253-297.
(3) Zhou, W.-S.; Xu, X. X. Total synthesis of the antimalarial
sesquiterpene peroxide qinghaosu and yingzhaosu A. Acc. Chem.
Res. 1994, 27, 211-216.
Gen er a l P r oced u r e 1: En on e Syn th esis (Ald ol Con -
d en sa tion , Deh yd r a tion ). An LDA solution (1.1 equiv based
on 1.0 equiv of acetophenone substrate) was prepared by
treating diisopropylamine (1.1 equiv) in THF (volume needed
to make final concentration of LDA 0.3-0.5 M) at -78 °C with
n-BuLi (1.7 M solution in hexanes, 1.1 equiv). The LDA
solution was stirred at -78 °C for 10 min and then at room
temperature for 10 min, then re-cooled to -78 °C. Acetophe-
none (1.0 equiv, either neat in the case of liquids or as a 0.5-
1.0 M solution in THF) was added to the LDA solution and
stirred at -78 °C for 15 min and then at room temperature
for 10 min. The reaction was cooled to -78 °C, and aldehyde
(1.0-1.2 equiv) was added. The reaction was stirred at -78
°C for 1 h and then at room temperature for 1 h. The reaction
was quenched (saturated aqueous NH4Cl), extracted (ether),
washed (H2O, brine), dried (Na2SO4), and concentrated under
reduced pressure to give crude product.
(4) Haynes, R. K.; Vonwiller, S. C. From qinghao, marvelous herb
of antiquity, to the antimalarial trioxane qinghaosusand some
remarkable new chemistry. Acc. Chem. Res. 1997, 30, 73.
(5) Ziffer, H.; Highet, R. J .; Klayman, D. L. Artemisinin: An
Endoperoxidic Antimalarial from Artemisia annua L. Prog.
Chem. Org. Nat. Prod. 1997, 72, 123-214.
(6) Hien, T. T.; White, N. J . Qinghaosu. Lancet 1993, 341, 603-
608.
(7) Haraldson, C. A.; Karle, J . M.; Freeman, S. G.; Davadie, R. K.;
Avery, M. A. The synthesis of 8,8-disubstituted tricyclic analogs
of artemisinin. Bioorg. Med. Chem. Lett. 1997, 7, 2357-2362.
(8) Avery, M. A.; Bonk, J . D.; Chong, W. K. M.; Mehrotra, S.; Miller
R.; Milhous, W.; Goins, D. K.; Venhkatesan, S.; Wyandt, C.;
Khan, I.; Avery, B. A. Structure-activity relationships of the
antimalarial agent artemisinin. 2. Effect of heteroatom substitu-
tion at 0-11: Synthesis and bioassay of N-alkyl-11-aza-9-
desmethylartemisinins. J . Med. Chem. 1995, 38, 5038-5044.
(9) Torok, D. S.; Ziffer, H.; Meshnick. S. R.; Pan, X.-Q.; Ager, A.
Syntheses and antimalarial activities of N-substituted 11-
azaartemisinins. J . Med. Chem. 1995, 38, 5045-5050.
(10) MeKonnen, B.; Ziffer, H. A new route to N-substituted 11-aza
artemisinins. Tetrahedron Lett. 1997, 38, 731-734.
(11) J ung, M.; Lee, S. An efficient synthesis of novel spiro deoxoar-
temisinin with 2-pyrazoline ring. Heterocycles 1997, 45, 1907-
1912.
Gen er a l P r oced u r e 2: P er oxy Keta l Syn th esis (P h o-
toen oliza tion , Oxygen a tion ). In a 125 mL three-necked
sulfonation flask equipped with a screw-cap, oxygen inlet, and
a 13 cm Vigreux distilling column with a gas outlet to a
mineral oil bubbler, a solution of enone (75-350 mg) and
CuSO4 (15-40 mg) in CH2Cl2 (100 mL) and MeOH (10 mL)
was irradiated at room temperature by a 275 W sun lamp
(placed ca. 10 cm from reaction vessel) while ultrahigh purity
grade oxygen was bubbled through the solution at a rate of
20 mL/min. The flask was cooled by a fan, and solvent was
refilled as required. After 14-17 h the reaction was stopped,
washed (water), dried (Na2SO4), and concentrated to give crude
product.
(12) J ung, M. Synthesis and cytotoxicity of novel artemisinin analogs.
Bioorg. Med. Chem. Lett. 1997, 7, 1091-1094.
(13) J efford, C. W. The design and synthesis of new artemisinin
analogues. J pn. J . Trop. Med. Hyg. 1996, 24, 7-11.
(14) Peters, W.; Robinson, B. L.; Tovey, G.; Rossier, J . C.; J efford, C.
W. The Chemotherapy of Rodent Malaria. L. The activities of
some synthetic 1,2,4-trioxanes against chloroquine-sensitive and
chloroquine-resistant parasites. part 3: Observations on ‘feno-
zan-50f ’, a difluorinated 3,3′-spirocyclopentane 1,2,4-trioxane.
Ann. Trop. Med. Parasitol. 1993, 87, 111-123.
(15) Posner, G. H.; Ploypradith, P.; Hapangama, W.; Wang, D.;
Cumming, J . N.; Klinedinst, D.; Shapiro, T. A.; Dolan, P.;
Kensler, T. W.; Daughenbaugh, R.; Murray, C. K.; Zheng, Q. Y.
Trioxane dimers have potent antimalarial, antiproliferative, and
antitumor activities in vitro. Bioorg. Med. Chem. 1997, 5, 1257-
1265.
Dim eth yl P h en yl En on e 4a . Acetophenone (0.93 mL, 8.0
mmol) was treated with LDA (9.0 mmol) followed by isobu-
tyraldehyde (0.91 mL, 10 mmol) according to general procedure
1. Flash column chromatography of the crude product using
5% EtOAc/hexanes on silica gel gave desired enone 4a (0.70
g, 4.0 mmol, 50%) as an oil: 1H NMR (CDCl3) δ 1.13 (d, 6 H,
(16) Posner, G. H.; O’Dowd, H. An antimalarially active cyclic peroxy
ketal. Heterocycles 1998, 47, 643-646.
