Preparation of Annulated Carbohydrates
J . Org. Chem., Vol. 65, No. 2, 2000 491
C2), 78.6 (CH, C4), 99.8 (CH, C1), 101.8 (CH, C10), 118.2 (CH2,
C9), 126.5 (CH, Ph), 128.7 (CH, Ph), 129.3 (CH, Ph), 135.1 (CH,
C8), 138.0 (C, Ph); m/z (FAB) 307 (MH+, 54) (found MH+,
307.1546; C17H23O5 requires 307.1546). Anal. Found: C, 65.94;
H, 7.12. C17H22O5 requires C, 66.65; H, 7.24%.
79%: mp 66 °C; [R]21 +40.6° (c 0.80, CHCl3); δH (300 MHz,
D
CDCl3) 1.79 (3H, s, C8-Me), 2.34 (1H, m), 2.48 (2H, m, 10-H),
3.33 (2H, m), 3.44 (3H, s, OMe), 3.66 (1H, t, J 10.1, 6ax-H),
3.80 (1H, m), 3.91 (1H, d, J 12.0, CHH, H-7), 3.96 (1H, d, J
12.0 CHH, H-7), 4.26 (1H, dd, J 4.6, 10.1, 6eq-H), 4.80 (1H, d,
J 3.3, 1-H), 4.91-5.14 (4H, 9-H and 12-H), 5.48 (1H, s, 13-H),
5.89 (1H, m, 11-H), 7.34-7.49 (5H, Ph); δC (75 MHz, CDCl3)
19.9 (CH3, C8-Me), 29.8 (CH2, C10), 40.0 (CH, C3), 55.5 (CH3,
OMe), 63.8 (CH, C5), 69.7 (CH2, C6), 74.9 (CH2, C7), 77.2 (CH,
C2), 78.7 (CH, C4), 97.9 (CH, C1), 101.8 (CH, C13), 113.5 (CH2,
C9), 118.1 (CH2, C12), 126.4 (CH, Ph), 128.6 (CH, Ph), 129.2
(CH, Ph), 134.9 (CH, C8), 138.0 (C, Ph), 142.5 (CH, C11). Anal.
Found: C, 69.84; H, 7.53. C21H28O5 requires C, 69.98; H, 7.83%.
Meth yl (R)-4,6-O-Ben zyliden e-2-O-p en t-4-en yl-3-d eoxy-
3-C-p r op en yl-r-D-glu cop yr a n osid e (30). Prepared by the
Meth yl (R)-4,6-O-Ben zylid en e-2-C-m eth yl-3-d eoxy-3-C-
p r op en yl-r-D-glu cop yr a n osid e (27b). To an ice-cold solu-
tion of the ketone 2a (100 mg, 0.33 mmol) in THF (5 mL) was
added MeLi (500 µL, 0.66 mmol, 1.3 M in diethyl ether) with
stirring. The reaction mixture was then allowed to warm to
room temperature and stirred for 6 h. It was then quenched
by addition of saturated aqueous ammonium chloride solution.
The organic layer was separated, and the aqueous layer was
extracted with diethyl ether (3 × 10 mL). The combined
organic extracts were dried (Na2SO4) and concentrated to yield
the carbinol 27b (90 mg, 86%): mp 143 °C; [R]21 +38.4° (c
procedure described for 28a . Yield: 83%: mp 84 °C; [R]21
D
D
0.29, CHCl3); δH (300 MHz, CDCl3) 1.25 (3H, s, C2-Me), 1.59
(1H, br s, OH), 2.13 (1H, m, 3-H), 2.34-2.50 (2H, m, 7-H), 3.38
(1H, dd, J 9.0, 12.0, 4-H), 3.44 (3H, s, OMe), 3.54-3.85 (2H,
5-H and 6ax-H), 4.25 (1H, dd, J 6.0, 15.0, 6eq-H), 4.29 (1H, s,
1-H), 4.94 (1H, d, J 9.0, 9-Hcis), 5.05 (1H, d, J 18.0, 9-Htrans),
5.49 (1H, s, 10-H), 6.02 (1H, m, 8-H), 7.34-7.49 (5H, Ph); δC
(75 MHz, CDCl3) 20.2 (CH3, C2-Me), 31.5 (CH2, C7), 46.2 (CH,
C3), 55.7 (CH3, OMe), 65.0 (CH, C5), 69.7 (CH2, C6), 73.5 (C,
C2), 81.4 (CH, C4), 101.8 (CH, C1), 104.6 (CH, C10), 115.2
(CH2, C9), 126.4 (CH, Ph), 128.6 (CH, Ph), 129.2 (CH, Ph),
138.0 (C, Ph), 139.3 (CH, C8). Anal. Found: C, 67.68; H, 7.48.
+45.0° (c 0.50, CHCl3); δH (300 MHz, CDCl3) 1.72 (1H, m), 2.16
(2H, m), 2.28 (1H, m), 2.47 (2H, m), 3.21-3.44 (4H, m), 3.45
(3H, s, OMe), 3.66 (2H, m), 3.79 (1H, dt, J 4.6, 10.0, 5-H), 4.26
(1H, dd, J 4.6, 10.0, 6eq-H), 4.81 (1H, d, J 3.3, 1-H), 4.95-
5.13 (4H, 11-H and 14-H), 5.48 (1H, s, 15-H), 5.84 (2H, 10-H
and 13-H), 7.33-7.50 (5H, Ph); δC (75 MHz, CDCl3) 29.2 (CH2,
C8), 29.4 (CH2, C12), 30.2 (CH2, C9), 39.6 (CH, C3), 55.1 (CH3,
OMe), 63.5 (CH, C5), 69.4 (CH2, C7), 69.5 (CH2, C6), 77.2 (CH,
C2), 78.3 (CH, C4), 97.4 (CH, C1), 101.4 (CH, C15), 114.9 (CH2,
C11), 117.7 (CH2, C14), 126.0 (CH, Ph), 128.2 (CH, Ph), 128.9
(CH, Ph), 134.5 (CH, C10), 137.6 (C, Ph), 138.1 (CH, C13).
Anal. Found: C, 70.28; H, 8.91. C22H30O5 requires C, 70.56;
H, 8.07%.
C
18H24O5 requires C, 67.48; H, 7.55%.
Met h yl (R)-4,6-O-Ben zylid en e-2-O-p r op en yl-3-d eoxy-
3-C-p r op en yl-r-D-glu cop yr a n osid e (28a ). To a suspension
of NaH (40 mg, 40% suspension in mineral oil, 0.67 mmol,
prewashed with petroleum ether to free it from mineral oil)
in dry THF (4.0 mL) was added a solution of the alcohol 27a
(80 mg, 0.26 mmol) in dry THF (2.0 mL). The resulting mixture
was refluxed for 2 h and cooled to room temperature, and then
allyl bromide (63 mg, 0.52 mmol) and HMPA (150 µL) were
added. The mixture was again refluxed for 2 h, cooled to room
temperature, and quenched by addition of cold water. The
mixture was then extracted with diethyl ether (3 × 10 mL).
The combined organic extracts were then washed with satu-
rated sodium chloride solution (30 mL), dried (Na2SO4), and
concentrated. Chromatography on silica gel with petroleum
ether-diethyl ether (4:1) as the eluent yielded ether 28a (70
Met h yl (R)-4,6-O-Ben zylid en e-2-O-3-C-(b u t -2-en e-1,4-
d iyl)-3-d eoxy-r-D-glu cop yr a n osid e (29a ). Nitrogen gas was
bubbled through a solution of the diene 28a (50 mg, 0.16 mmol)
in benzene (5 mL) for 2-3 min. The catalyst 1 (5 mg, 0.006
mmol, 3.9 mol %) was then added and the solution heated at
60 °C for 6 h. The solvent was then removed under reduced
pressure to leave a dark brown oil. Chromatography on silica
gel with petroleum ether-diethyl ether (3:1) as the eluent
yielded 29a as a white solid (40 mg, 87%): mp 99 °C; [R]21
D
+50.0° (c 0.35, CHCl3); δH (300 MHz, CDCl3) 2.06 (1H, m,
CHH, 10-H), 2.37 (1H, dq, J 2.7, 10.5, 3-H), 2.83 (1H, dd, J
6.9, 15.0, CHH, 10-H), 3.22 (1H, t, J 9.6, 4-H), 3.46 (3H, s,
OMe), 3.56 (1H, dd, J 3.6, 10.5, 2-H), 3.68 (1H, t, J 10.2, 6ax-
H), 3.84 (1H, dt, J 4.8, 10.2, 5-H), 4.04 (1H, br d, J 14.0, CHH,
7-H), 4.27 (1H, dd, J 4.5, 10.2, 6eq-H), 4.46 (1H, dd, J 4.2,
14.0, CHH, 7-H), 4.73 (1H, d, J 3.6, 1-H), 5.49 (1H, s, 11-H),
5.88 (2H, 8-H and 9-H), 7.36-7.51 (5H, Ph); δC (75 MHz,
CDCl3) 28.9 (CH2, C10), 39.1 (CH, C3), 55.0 (CH3, OMe), 63.2
(CH, C5), 66.9 (CH2, C7), 69.3 (CH2, C6), 80.2 (CH, C2), 83.0
(CH, C4), 99.5 (CH, C1), 101.7 (CH, C11), 126.0 (CH, Ph), 128.2
(CH, Ph), 128.9 (CH, Ph), 130.9 (CH, C8), 131.4 (CH, C9), 137.4
(C, Ph). Anal. Found: C, 67.20; H, 6.90. C18H22O5 requires C,
67.91; H, 6.96%.
mg, 78%): mp 72 °C; [R]21 +31.5° (c 0.10, CHCl3); δH (300
D
MHz, CDCl3) 2.34 (1H, m), 2.48 (2H, m), 3.36 (2H, m), 3.46
(3H, s, OMe), 3.67 (1H, t, J 10.0, 6ax-H), 3.80 (1H, m), 4.09
(2H, m), 4.27 (1H, dd, J 4.5, 10.0, 6eq-H), 4.81 (1H, d, J 3.3,
1-H), 5.09-5.34 (4H, 9-H and 12-H), 5.49 (1H, s, 13-H), 5.91
(2H, 8-H and 11-H), 7.36-7.51 (5H, Ph); δC (75 MHz, CDCl3)
29.5 (CH2, C10), 39.7 (CH, C3), 55.3 (CH3, OMe), 63.5 (CH,
C5), 69.5 (CH2, C6), 71.5 (CH2, C7), 76.6 (CH, C2), 78.4 (CH,
C4), 97.6 (CH, C1), 101.5 (CH, C13), 117.7 (CH2, C9), 117.8
(CH2, C12), 126.1 (CH, Ph), 128.3 (CH, Ph), 129.0 (CH, Ph),
134.6 (CH, C8), 134.8 (CH, C11), 138.0 (C, Ph). Anal. Found:
C, 69.43; H, 7.52. C20H26O5 requires C, 69.34; H, 7.56%.
Meth yl (R)-4,6-O-Ben zylid en e-2-C-m eth yl-2-O-p r op e-
n yl-3-deoxy-3-C-pr open yl-r-D-glu copyr an oside (28b). Pre-
pared by the procedure described for 28a . Yield 87%: mp 125
Met h yl (R)-4,6-O-Ben zylid en e-2-m et h yl-2-O-3-C-(b u t -
2-en e-1,4-d iyl)-3-d eoxy-r-D-glu cop yr a n osid e (29b). Pre-
pared by the procedure described for 29a . Yield 87%: mp 154
°C; [R]21 +60.2° (c 0.40, CHCl3); δH (300 MHz, CDCl3) 1.34
D
(3H, s, C2-Me), 2.24 (1H, m, CHH, 10-H), 2.69 (1H, br d, J
18.0, CHH, 10-H), 2.90 (1H, dt, J 2.4, 11.7, 3-H), 3.40 (1H, t,
J 9.0, 4-H), 3.48 (3H, s, OMe), 3.75 (1H, t, J 10.0, 6ax-H), 3.87
(1H, dt, J 4.5, 10.0, 5-H), 4.05 (1H, br d, J 15.6, CHH, 7-H),
4.29 (1H, dd, J 4.5, 10.0, 6eq-H), 4.39 (1H, s, 1-H), 4.74 (1H,
dd, J 2.4, 15.6, CHH, 7-H), 5.52 (1H, s, 11-H), 5.68 (2H, 8-H
and 9-H), 7.37-7.52 (5H, Ph); δC (75 MHz, CDCl3) 19.6 (CH3,
C2-Me), 25.7 (CH2, C10), 40.7 (CH, C3), 55.1 (CH3, OMe), 62.9
(CH2, C7), 64.5 (CH, C5), 69.4 (CH2, C6), 77.5 (C, C2), 79.5
(CH, C4), 101.7 (CH, C1), 105.3 (CH, C11), 126.0 (CH, Ph),
128.2 (CH, Ph), 128.9 (CH, Ph), 129.1 (CH, C8), 129.8 (CH,
C9), 137.5 (C, Ph). Anal. Found: C, 68.65; H, 7.08. C19H24O5
requires C, 68.66; H, 7.28%.
°C; [R]21 +64.2° (c 0.22, CHCl3); δH (300 MHz, CDCl3) 1.28
D
(3H, s, C2-Me), 2.30 (1H, dd, J 6.4, 13.2), 2.43 (2H, m, 10-H),
3.44 (3H, s, OMe), 3.49 (1H, t, J 10.2, 4-H), 3.69-3.96 (3H,
m), 4.16 (1H, dd, J 5.0, 12.5), 4.25 (1H, dd, J 4.3, 9.8, 6eq-H),
4.44 (1H, s, 1-H), 4.89-5.31 (4H, 9-H and 12-H), 5.52 (1H, s,
13-H), 5.95 (2H, 8-H and 11-H), 7.33-7.50 (5H, Ph); δC (75
MHz, CDCl3) 18.6 (CH3, C2-Me), 31.5 (CH2, C10), 42.5 (CH,
C3), 54.9 (CH3, OMe), 63.5 (CH2, C7), 64.4 (CH, C5), 69.5 (CH2,
C6), 77.0 (C, C2), 81.7 (CH, C4), 101.6 (CH, C1), 103.4 (CH,
C13), 114.7 (CH2, C9), 115.7 (CH2, C12), 126.1 (CH, Ph), 128.3
(CH, Ph), 128.9 (CH, Ph), 135.7 (CH, C8), 138.0 (C, Ph), 138.8
(CH, C11). Anal. Found: C, 69.75; H, 7.64. C21H28O5 requires
C, 69.98; H, 7.83%.
Met h yl (R)-4,6-O-Ben zylid en e-2-O-3-C-(2-m et h yl-b u t -
2-en e-1,4-d iyl)-3-d eoxy-r-D-glu cop yr a n osid e (29c). Pre-
pared by the procedure described for 29a . Yield: 87%: mp 104
Meth yl (R)-4,6-O-Ben zylid en e-2-O-(2-m eth ylp r op en yl)-
3-d eoxy-3-C-p r op en yl-r-D-glu cop yr a n osid e (28c). Pre-
pared by the procedure described for 28a . Ether 28c was
obtained using methallyl chloride as alkylating agent. Yield:
°C; [R]21 +61.5° (c 1.10, CHCl3); δH (300 MHz, CDCl3) 1.69
D
(3H, s, C8-Me), 1.99 (1H, m, CHH, 10-H), 2.39 (1H, dq, J 2.2,
10.5, 3-H), 2.71 (1H, ddd, J 2.0, 8.0, 15.7, CHH, 10-H), 3.18
