Syn th esis a n d Str u ctu r e-Activity Rela tion sh ip s of a Novel Ser ies of Tr icyclic
Dih yd r op yr id in e-Ba sed KATP Op en er s Th a t P oten tly In h ibit Bla d d er
Con tr a ction s in Vitr o
William A. Carroll,* Konstantinos A. Agrios, Robert J . Altenbach, Steven A. Buckner, Yiyuan Chen,
Michael J . Coghlan, Anthony V. Daza, Irene Drizin, Murali Gopalakrishnan, Rodger F. Henry, Michael E. Kort,
Philip R. Kym, Ivan Milicic, J amie C. Smith, Rui Tang, Sean C. Turner, Kristi L. Whiteaker, Henry Zhang, and
J ames P. Sullivan
Abbott Laboratories, Neuroscience Research, Global Pharmaceutical Research and Development,
Abbott Park, Illinois 60064-6101
Received J uly 24, 2003
Structure-activity relationships were investigated on a novel series of tricyclic dihydropyridine-
containing KATP openers. This diverse group of analogues, comprising a variety of heterocyclic
rings fused to the dihydropyridine nucleus, was designed to determine the influence on activity
of hydrogen-bond-donating and -accepting groups and their stereochemical disposition.
Compounds were evaluated for KATP activity in guinea pig bladder cells using a fluorescence-
based membrane potential assay and in a pig bladder strip assay. The inhibition of spontaneous
bladder contractions in vitro was also examined for a subset of compounds. All compounds
studied showed greater potency to inhibit spontaneous bladder contractions relative to their
potencies to inhibit contractions elicited by electrical stimulation.
In tr od u ction
definitive proof of efficacy in a placebo-controlled trial
has not been demonstrated for either agent.8 Cro-
makalim was dropped from further study due to un-
specified animal toxicity, and 2 was also reportedly
discontinued from development in favor of another KATP
opener, ZD0947.9 Thus, it remains to be established
whether the KATP-opening mechanism can ameliorate
the symptoms of OAB. Also, given the initial interest
in KATP openers as antihypertensives, it is expected that
hypotensive effects may limit dosing.
ATP-sensitive potassium (KATP) channels play a criti-
cal role in linking cellular energy metabolism to mem-
brane potential and cellular excitability.1,2 Opening of
KATP channels results in an efflux of potassium ions
from the cell and an accompanying reduction in mem-
brane potential (hyperpolarization) that restricts cal-
cium entry through L-type calcium channels and damp-
ens cellular excitability. KATP channels are heteroocta-
meric complexes composed of four inwardly rectifying
potassium channel (Kir) subunits that form the pore and
four regulatory sulfonylurea receptor (SUR) subunits.3,4
KATP channels are located in the pancreas, central
nervous system, heart, skeletal muscle, and diverse
smooth muscle tissues such as the bladder and periph-
eral vasculature. Recent molecular biological advances
have resulted in the subclassification of the Kir and
SUR subunits, with distinct combinations found in
different tissues. For example, the pancreatic â-cell KATP
that regulates insulin release is composed of the com-
bination of SUR1 with Kir6.2. The SUR2A/Kir6.2 com-
bination has been identified as the cardiac KATP, whereas
the smooth muscle KATP consists of SUR2B with either
Kir6.1 or Kir6.2. Additional splice variants of SUR1 and
SUR25 have also been described.
Preclinically, the focus continues to be directed toward
identifying agents with selective actions on the bladder
and minimal cardiovascular effects. The arylsquarate
KATP openers WAY-133537 (3)10 and WAY-151616 (4)11
have been reported to inhibit spontaneous, diseased
bladder contractions in rats and to have improved
therapeutic indexes (TIs) with respect to hypotensive
effects compared to 2. The acridinedione ZM244085 (5)
has also been reported to inhibit bladder function in rats
without effects on blood pressure.12
The reported bladder selective actions of 5 make it
an attractive lead from which to design novel KATP
openers. In our accompanying paper we describe initial
SAR studies in this area that led to the discovery of 6
(A-278637). Those efforts focused on extensive modifica-
tions of the aromatic ring substitution as well as an
examination of ring sizes and stereochemistry. The
present studies greatly extend the SAR of the tricyclic
dihydropyridine (DHP) core structure in the form of
diverse heterocyclic ring combinations. The SAR studies
described herein were conducted exclusively with the
3-bromo-4-fluoro substitution pattern on the aromatic
ring as this had previously been found to impart high
potency. The primary focus of these investigations was
to examine the effect of insertion of hydrogen-bond-
donating or -accepting groups in the rings flanking the
There has been considerable interest in exploring
KATP openers as therapeutic agents in the treatment of
bladder overactivity, a condition that may be associated,
in part, with the hyperexcitability of diseased bladder
smooth muscle cells.6,7 Although the KATP openers
cromakalim (1, Figure 1) and ZD6169 (2) have both been
studied in clinical trials for overactive bladder (OAB),
* Address for correspondence: Abbott Laboratories, Neuroscience
Research, R4PM, AP10, 100 Abbott Park Road, Abbott Park, IL
60064-6101. Tel: (847)-938-6041. Fax: (847)-935-5466. E-mail:
william.a.carroll@abbott.com.
10.1021/jm030357o CCC: $27.50 © 2004 American Chemical Society
Published on Web 05/04/2004

Tricyclic Dihydropyridine-Containing KATP Openers
J ournal of Medicinal Chemistry, 2004, Vol. 47, No. 12 3181
F igu r e 1.
F igu r e 2.
piperidine-containing compounds (37, 38, 48, 51, 56)
encountered in this discussion were prepared via the
intermediacy of an N-benzyl derivative that was deben-
zylated via the respective vinylchloroformates (see the
Experimental Section for details). In the preparation of
32 and 33, the initial Hantzsch reaction provided an
intermediate that necessitated treatment with HCl to
effect conversion to the racemic dihydropyridine (method
B). Certain symmetrical target compounds (40, 47, 48)
were prepared directly through reaction of 2 equiv of
the cyclic dione with an aldehyde and ammonia source
(see method C in the Experimental Section).
Final compounds containing a γ-lactone were pre-
pared by bromination and cyclization of an intermediate
bicyclic dihydropyridine (Scheme 2, method D). Simi-
larly, γ-lactams were prepared from the same interme-
diates by reacting the bromo intermediate with a
primary amine or ammonia (method E). Final com-
pounds prepared by these methods are shown in Scheme
2. For the preparation of single enantiomers containing
either a γ-lactone or γ-lactam, a bicyclic intermediate
was derivatized as the ester with mandelic acid to
produce a mixture of diastereomers that were separable
through silica gel chromatography (Scheme 3, method
F). Transesterification led to the enantiomerically pure
methyl ester intermediate that was transformed to the
γ-lactones and γ-lactams using methods D and E,
respectively, from Scheme 2. The combination of meth-
ods F and E was utilized in parallel fashion to explore
F igu r e 3.
dihydropyridine but in positions other than the 2-, 3-,
5-, or 6-position of the dihydropyridine. A variety of
unique combinations of heteroatoms either on one or
both sides of the dihydropyridine core (see Figures 2 and
3 and the structures accompanying Tables 1-3 for the
types of ring systems to be discussed) were prepared
and evaluated for KATP activity in both cell- and tissue-
based assays.
Ch em istr y
Final compounds and intermediates containing a
dihydropyridine ring were prepared using the Hantzsch
dihydropyridine synthesis (Scheme 1, method A). An
array of carbonyl (c1-c11) and enamine (e1-e5) mono-
mers (Figure 2) were reacted to create diverse combina-
tions of the core structure, with the final compounds
obtained by this method indicated in Scheme 1. Several

3182 J ournal of Medicinal Chemistry, 2004, Vol. 47, No. 12
Carroll et al.
Ta ble 1
Ta ble 3
