Syn th esis a n d Str u ctu r e of
Sem i(tetr a h yd r ofu r a n -O)bisp ota ssiu m
Bis(2,3,4,5-tetr a eth ylstibolid e)
Matthias Westerhausen,* Christian Gu¨ckel, Marcus Warchhold, and
Heinrich No¨th
Department Chemie, Ludwig-Maximilians-Universita¨t Mu¨nchen, Butenandtstrasse 9
(House D), D-81377 Munich, Germany
Received February 18, 2000
Summary: The reaction of bis(cyclopentadienyl)zircona-
2,3,4,5-tetraethylcyclopentadiene (1) with antimony
trichloride yields 1-chloro-2,3,4,5-tetraethyl-1-stibole (2).
The reduction with potassium gives semi(tetrahydrofu-
ran-O)bispotassium bis(2,3,4,5-tetraethylstibolide) (3).
The potassium stibolide columns are linked via K-Sb
contacts of 3.618 Å, thus forming a wavelike layer
structure. The molecular structure shows three crystal-
lographically different metal cations. One potassium
atom is located between two stibolide anions, whereas
the other ones show additional K-O and K-Sb contacts
of 2.681 and 3.618 Å, respectively.
we report on the synthesis and structure of an alkylated
potassium stibolide that exhibits both η5- as well as η1-
coordination to a potassium cation.
Cyclopentadienides of the heavier alkali metals are
of interest not only due to their application as cyclo-
pentadienyl transfer reagents but also due to their
structural and physical properties. Very recently, Cloke
et al.10 published the synthesis of (tetrahydrofuran-O)-
potassium 2,4,5-tri(tert-butyl)-1,3-diphosphacyclopen-
tadienide with its columnar structure. Whereas unsub-
stituted cyclopentadienyllithium, -sodium, and -potassium
are polymeric in the solid state,11 demanding groups and
coordination of neutral coligands lead to the formation
of monomeric or oligomeric molecules.1 On the other
hand, addition of bases such as THF and the use of
substituted cyclopentadienyl groups is necessary to
obtain substances soluble in common organic solvents.
In tr od u ction
Cyclopentadienides of the alkali metals are widely
used synthons for the preparation of metallocenes of the
d-block elements. Their synthesis is straightforward,
and an isolation of these reactive species usually is
unnecessary to perform ligand transfer reactions.1,2 The
formal substitution of a CH unit by a phosphorus atom
gives the well-known phospholides,3 which show proper-
ties similar to those of the hydrocarbon analogues. The
aromaticity within the five-membered cycle based on
NMR data and theoretical investigations lies in the
same order of magnitude,4 and also the structures of
the metallocenes and the phospha-substituted deriva-
tives are often alike.3 However, in addition to the η5-
coordination phospholides can act as η1-ligands prefer-
ably to 16-electron species of d-block metals. For the
alkaline earth metal phospholides, metallocenes5 (η5-
coordination) and 1-phosphacyclopenta-2,4-dien-1-ides6
(η1-coordination) were observed. There are only a few
examples of structurally characterized pentelacyclopen-
tadienides of the heavier penteles (pnictogenes). To our
knowledge for antimony only the molecular structures
of 1,1′-distibaferrocenes have been published.7-9 Here
Resu lts a n d Discu ssion
The reaction of zirconocene dichloride with butyl-
lithium and hex-3-yne at -78 °C in THF yields nearly
quantitatively red 1,1-bis(cyclopentadienyl)-2,3,4,5-tet-
raethyl-1-zirconacyclopenta-2,4-diene (1).12 The trans-
metalation with antimony trichloride gives the corre-
sponding 1-chloro-2,3,4,5-tetraethyl-1-stibole (2) as a
yellow oil according to Scheme 1. The reduction of 2 with
potassium metal in THF and recrystallization from
heptane yields slightly yellow crystals of semi(tetrahy-
drofuran-O)bispotassium bis(2,3,4,5-tetraethyl-1-sti-
bolide) (3).
The molecular structure and the numbering scheme
of 3 are represented in Figure 1. The unit shown in
Figure 1 is part of a column in which potassium cations
and stibolide anions alternate. However, there are three
crystallographically and chemically different metal
centers: K1 lies between two parallel stibolide anions,
and at K3 a THF ligand is bonded (K3-O3 2.68(1) Å)
and enforces a nonparallel orientation of the neighbor-
(1) J utzi, P. J . Organomet. Chem. 1990, 400, 1. J utzi, P. Chem. Rev.
1999, 99, 969.
(2) Burkey, D. J .; Hanusa, T. P. Comments Inorg. Chem. 1995, 17,
41.
(3) Kershner, D. L.; Basolo, F. Coord. Chem. Rev. 1987, 79, 279.
Mathey, F. Chem. Rev. 1988, 88, 429. Mathey, F. Coord. Chem. Rev.
1994, 137, 1.
(7) Ashe, A. J ., III; Diephouse, T. R.; Kampf, J . W.; Al-Taweel, S.
Organometallics 1991, 10, 2068.
(8) Ashe, A. J ., III; Kampf, J . W.; Al-Taweel, S. Organometallics
1992, 11, 1491.
(4) Malar, E. J . P. J . Org. Chem. 1992, 57, 3694. Dransfeld, A.;
Nyula´szi, L.; Schleyer, P. v. R. Inorg. Chem. 1998, 37, 4413. Nyula´szi,
L.; Bergstra¨sser, U.; Regitz, M.; Schleyer, P. v. R. New J . Chem. 1998,
651.
(5) Westerhausen, M.; Digeser, M. H.; Gu¨ckel, C.; No¨th, H.; Knizek,
J .; Ponikwar, W. Organometallics 1999, 18, 2491.
(6) Westerhausen, M.; Digeser, M. H.; No¨th, H.; Ponikwar, W.;
Seifert, T.; Polborn, K. Inorg. Chem. 1999, 38, 3207.
(9) Ashe, A. J ., III; Kampf, J . W.; Pilotek, S.; Rousseau, R. Orga-
nometallics 1994, 13, 4067.
(10) Cloke, F. G. N.; Hitchcock, P. B.; Nixon, J . F.; Wilson, D. J .
Organometallics 2000, 19, 219.
(11) Dinnebier, R. E.; Behrens, U.; Olbrich, F. Organometallics 1997,
16, 3855.
(12) Xi, C.; Huo, S.; Afifi, T. H.; Hara, R.; Takahashi, T. Tetrahedron
Lett. 1997, 38, 4099, and references therein.
10.1021/om000161b CCC: $19.00 © 2000 American Chemical Society
Publication on Web 05/11/2000

2394 Organometallics, Vol. 19, No. 12, 2000
Notes
F igu r e 1. Molecular structure and numbering scheme of
3. The ellipsoids represent a probability of 40%. The
hydrogen atoms are omitted for clarity reasons. The carbon
atoms of the THF ligand are shown with arbitrary radii.
Atoms marked with one prime are generated by an inver-
sion center (-x, -y, -z); those marked with two primes
are generated by C2 symmetry (-x+1, y, -z-0.5).
F igu r e 2. Linkage of two columns in the crystal structure
of 3. All hydrogen atoms are omitted for clarity reasons;
all carbon atoms are represented with arbitrary radii. The
ellipsoids represent a probability of 40%. Linking of the
columns occurs via a K1 and Sb1′′′ of the stibolide gener-
ated by -x+1, -y, -z. The centers of the stibolide anions
are symbolized by Z(n) with n the same number as the
corresponding Sb(n). Environment of the potassium cen-
ters: distances (Å) K1-Z1 2.839, K2-Z1 2.901, K2-Z2
2.893, K3-Z2 2.922; angles (deg) Z1-K1-Z1′ 180.0, Z1-
K2-Z2 139.5, Z1-K2-Sb1′′′ 111.8, Z2-K2-Sb1′′′ 108.6,
Z2-K3-Z2′′ 138.2, O3-K3-Z2 110.9, O3-K3-Z2′′ 110.9.
Sch em e 1. Syn th esis of Stibole 2 a n d Its
Red u ction w ith P ota ssiu m to Stibolid e 3
As expected, the shortening of the Sb-C bond lengths
compared to single bonds is less pronounced. On the
other hand these bonds are clearly longer than observed
for a SbdC double bond (2.06 Å),13 calculated for
stibaethene H-SbdCH2 (2.01 Å)14 or found for stiba-
benzene (stibinine, 2.05 Å).15 Surprisingly, the Sb1-C11
and Sb1-C14 bond lengths of 2.085(8) and 2.087(7) Å
are smaller than the values for Sb2-C21 (2.115(8) Å)
and Sb2-C24 (2.100(7) Å), although the linkage be-
tween the columns leads to a higher coordination
number at Sb1. In 2,2′,5,5′-tetramethyl-7 and octameth-
yl-1,1′-distibaferrocene9 mean endocyclic Sb-C bond
lengths of 2.11 Å were reported.
Another point of interest concerns the delocalization
of the anionic charge within the stibolide anions. Taking
the bond length difference between the endocyclic C-C
bonds as shown in Table 1 as a criterion, the delocal-
ization should be disturbed since the C(n1)-C(n2) and
C(n3)-C(n4) bonds with a mean value of 1.39 Å are
shorter than the C(n2)-C(n3) bonds at approximately
1.44 Å. In contrast to this observation the corresponding
endocyclic C-C bonds in 2,2′,5,5′-tetrakis(trimethylsi-
lyl)-3,3′,4,4′-tetramethyl-1,1′-distibaferrocene8 are alike
(mean value 1.43 Å). For octamethyl-1,1′-distibafer-
ing stibolide substituents, whereas K2 displays close
contacts to the neighboring column, as shown in Figure
2. As a consequence of the lower coordination number
of K1, the distances of K1 to the centers of the neighbor-
ing stibolide cycles with values of 2.839 Å are smaller
than the corresponding contacts between K2 and K3 to
their neighboring anions. The parallel orientation of the
anions bonded to K1 is crystallographically enforced by
an inversion center. The stibolide anions at K2 and K3
show strong deviations from parallelism, and the angles
between the centers of the stibolide cycles show values
of 139.5° and 138.2° at K2 and K3, respectively. Along
with this bending increasing distances between the
stibolide centers and the cations of approximately 290.5
Å are observed. The columns are linked via K2-Sb1′′′
contacts of 3.618 Å, thus forming a wavelike layer
structure rather than a chain structure.
(13) Hitchcock, P. B.; J ones, C.; Nixon, J . F. Angew. Chem. 1995,
107, 522; Angew. Chem., Int. Ed. Engl. 1995, 34, 492.
(14) Dobbs, K. D.; Boggs, J . E.; Cowley, A. H. Chem. Phys. Lett. 1987,
141, 372.
(15) Fong, G. D.; Kuczkowski, R. L.; Ashe, A. J ., III. J . Mol.
Spectrosc. 1978, 70, 197.

Notes
