2530 Organometallics, Vol. 19, No. 13, 2000
Liang et al.
[MesNON]Ti(NMe2)2. Butyllithium (0.92 mL, 2.5 M in
hexane, 2.3 mmol) was added to a diethyl ether solution (12
mL) of H2[MesNON] (500 mg, 1.15 mmol) at -30 °C. The
solution was stirred at room temperature for 1.5 h and cooled
to -30 °C. Solid TiCl2(NMe2)2 (237 mg, 1.15 mmol) was added.
The reaction mixture was stirred at room temperature over-
night (∼14 h). Insoluble materials were removed by filtration
through Celite and washed with diethyl ether (5 mL). The
filtrate was concentrated in vacuo until the volume was ∼2
mL. Pentane (∼1 mL) was layered on top, and the mixture
was cooled to -30 °C to give a dark red needlelike crystalline
solid. The supernatant was decanted, and the solid was dried
in vacuo; yield 475 mg (73%): 1H NMR (C6D6) δ 7.63 (d, 2,
Aryl), 6.87 (s, 4, Aryl), 6.86 (t, 2, Aryl), 6.60 (t, 2, Aryl), 6.22
(d, 2, Aryl), 2.77 (s, 12, TiNMe2), 2.20 (s, 6, Mep), 2.16 (s, 12,
Meo); 13C NMR (C6D6) δ 148.61 (CAr), 147.28 (CAr), 147.14 (CAr),
134.13 (CAr), 133.63 (CAr), 129.68 (CArH), 126.08 (CArH), 116.62
(CArH), 116.24 (CArH, 113.68 (CArH), 45.56 (NMe2), 21.31 (Mep),
19.67 (Meo). Anal. Calcd for C34H42N4OTi: C, 71.57; H, 7.42;
N; 9.82. Found: C, 71.69; H, 7.48; N, 9.71.
(s, 12, Meo), 2.10 (s, 6, Mep); 13C NMR (C6D6) δ 148.29 (CAr),
145.91 (CAr), 139.50 (CAr), 137.64 (CAr), 135.68 (CAr), 130.91
(CArH), 127.22 (CArH), 119.50 (CArH), 116.69 (CArH), 114.12
(CArH), 21.37 (Mep), 19.10 (Meo). Anal. Calcd for C30H30Cl2N2-
OZr(ether)0.67: C, 60.73; H, 5.72; N, 4.33. Found: C, 60.85; H,
5.86; N, 4.27.
[MesNON]Zr Me2. MeMgI (0.10 mL, 3.0 M in diethyl ether,
0.30 mmol) was added to a diethyl ether solution (4 mL) of
[MesNON]ZrCl2 (98 mg, 0.15 mmol) at -30 °C. The reaction
mixture was stirred at room temperature for 2.5 h, and the
solvent was removed in vacuo. The solid residue was extracted
with pentane (10 mL). Insoluble materials were removed by
filtration through Celite. The colorless filtrate was concen-
trated in vacuo until the volume was ∼2 mL and was cooled
to -30 °C to give colorless crystals. The supernatant was
decanted, and the crystals were dried in vacuo; yield 71 mg
(85%): 1H NMR (C6D6) δ 7.53 (d, 2, Aryl), 6.92 (s, 4, Aryl),
6.82 (t, 2, Aryl), 6.52 (t, 2, Aryl), 6.20 (d, 2, Aryl), 2.27 (s, 12,
1
Meo), 2.16 (s, 6, Mep), 0.58 (s, 6, ZrMe); H NMR (toluene-d8)
δ 7.47 (d, 2, Aryl), 6.87 (s, 4, Aryl), 6.77 (t, 2, Aryl), 6.49 (t, 2,
Aryl), 6.12 (d, 2, Aryl), 2.23 (s, 12, Meo), 2.14 (s, 6, Mep), 0.49
[MesNON]TiCl(NMe2). A toluene solution (5 mL) of [Mes-
NON]Ti(NMe2)2 (104 mg, 0.182 mmol) and Me3SiCl (0.07 mL,
0.552 mmol) was heated to 105 °C for 6 days in a Teflon-sealed
Schlenk tube. All volatile materials were removed in vacuo at
∼40 °C to give a deep red solid, which is pure [MesNON]TiCl-
(NMe2), according to its 1H NMR spectrum. The solid was
recrystallized from a concentrated diethyl ether solution at
-30 °C to give blood red crystals; yield 102 mg (100%): 1H
NMR (C6D6) δ 7.53 (d, 2, Aryl), 6.83 (s, 2, Aryl), 6.79 (t, 2, Aryl),
6.76 (s, 2, Aryl), 6.56 (t, 2, Aryl), 6.02 (d, 2, Aryl), 2.58 (s, 6,
1
(s, 6, ZrMe); H NMR (toluene-d8, -80 °C) δ 7.33 (d, 2, Aryl),
6.73 (s, 4, Aryl), 6.70 (t, 2, Aryl), 6.38 (t, 2, Aryl), 6.11 (d, 2,
1
Aryl), 2.20 (s, 12, Meo), 2.00 (s, 6, Mep), 0.58 (s, 6, ZrMe); H
NMR (toluene-d8, 90 °C) δ 7.53 (d, 2, Aryl), 6.91 (s, 4, Aryl),
6.79 (t, 2, Aryl), 6.53 (t, 2, Aryl), 6.13 (d, 2, Aryl), 2.25 (s, 12,
Meo), 2.17 (s, 6, Mep), 0.45 (s, 6, ZrMe); 13C NMR (C6D6) δ
147.03 (CAr), 146.19 (CAr), 138.43 (CAr), 136.87 (CAr), 136.65
(CAr), 130.75 (CArH), 126.43 (CArH), 117.31 (CArH), 115.18
(CArH), 113.80 (CArH), 49.85 (ZrMe), 21.42 (Mep), 19.00 (Meo).
Anal. Calcd for C32H36N2OZr: C, 69.14; H, 6.53; N; 5.04.
Found: C, 69.26; H, 6.37; N, 5.11.
[MesNON]Zr (CH2CMe3)2. A diethyl ether solution (2 mL)
of LiCH2CMe3 (28 mg, 0.36 mmol) at -30 °C was added to a
diethyl ether suspension (4 mL) of [MesNON]ZrCl2 (116 mg,
0.179 mmol) at -30 °C. The reaction mixture was stirred at
room temperature for 1 h, and the solvent was removed in
vacuo. The solid residue was extracted with pentane (10 mL),
and insoluble materials were removed by filtration through
Celite. The solvent was removed from the filtrate in vacuo to
give a pale yellow solid; yield 100 mg (83%): 1H NMR (C6D6)
δ 7.60 (d, 2, Aryl), 6.91 (s, 4, Aryl), 6.81 (t, 2, Aryl), 6.55 (t, 2,
Aryl), 6.23 (d, 2, Aryl), 2.37 (s, 12, Meo), 2.17 (s, 6, Mep), 1.29
(s, 4, CH2CMe3), 0.90 (s, 18, CH2CMe3); 13C NMR (C6D6) δ
147.24 (CAr), 147.11 (CAr), 141.90 (CAr), 136.37 (CAr), 135.99
(CAr), 130.80 (CArH), 126.47 (CArH), 117.58 (CArH), 116.30
(CArH), 114.43 (CArH), 96.57 (ZrCH2CMe3), 36.99 (ZrCH2CMe3),
34.52 (ZrCH2CMe3), 21.32 (Mep), 19.64 (Meo).
[MesNON]Zr P h 2. PhMgBr (0.10 mL, 3.0 M in diethyl ether,
0.30 mmol) was added to a diethyl ether suspension (4 mL) of
[MesNON]ZrCl2(ether)0.67 (97.0 mg, 0.150 mmol) at -30 °C.
The color of the suspension changed immediately from green
to yellow. The reaction mixture was stirred at room temper-
ature for 1.5 h, and 1,4-dioxane (5 drops) was added. Insoluble
materials were removed by filtration through Celite, and the
filtrate was concentrated in vacuo until the volume was ∼1
mL. The concentrated solution was cooled to -30 °C overnight
to give a yellow crystalline solid. The supernatant was
decanted, and the product was dried in vacuo; yield 94 mg
(92%): 1H NMR (C6D6) δ 7.62 (d, 2, Aryl), 7.52 (m, 4, Aryl),
7.00 (m, 6, Aryl), 6.80 (t, 2, Aryl), 6.75 (s, 4, Aryl), 6.61 (t, 2,
Aryl), 6.19 (d, 2, Aryl), 2.15 (s, 6, Mep), 2.05 (s, 12, Meo); 13C
NMR (C6D6) δ 191.70 (ZrCipso), 147.29 (CAr), 147.08 (CAr),
139.72 (CAr), 136.76 (CAr), 136.67 (CAr), 133.94 (CArH), 130.59
(CArH), 129.68 (CArH), 127.37 (CArH), 126.62 (CArH), 118.15
(CArH), 116.17 (CArH), 114.04 (CArH), 21.31 (Mep), 19.17 (Meo).
Anal. Calcd for C42H40N2OZr: C, 74.18; H, 5.93; N; 4.12.
Found: C, 74.08; H, 6.05; N, 4.18.
TiNMe2), 2.37 (s, 6, Mep), 2.15 (s, 6, Meo), 1.98 (s, 6, Meo); 13
C
NMR (C6D6) δ 149.15 (CAr), 148.17 (CAr), 146.67 (CAr), 135.04
(CAr), 134.70 (CAr), 131.98 (CAr), 130.10 (CArH), 129.66 (CArH),
126.23 (CArH), 118.37 (CArH), 117.09 (CArH), 112.30 (CArH),
46.09 (NMe2), 21.24 (Mep), 19.54 (Meo), 18.81 (Meo). Anal. Calcd
for C32H36ClN3OTi: C, 68.39; H, 6.46; N; 7.48. Found: C, 68.48;
H, 6.35; N, 7.39.
[MesNON]Zr (NMe2)2. Diethyl ether (10 mL) was added to
a solid mixture of H2[MesNON] (1.03 g, 2.36 mmol) and Zr-
(NMe2)4 (0.632 g, 2.36 mmol) at room temperature. The
solution was stirred at room temperature overnight (∼13 h).
All volatile components were removed in vacuo to give a pale
yellow solid, which was pure [MesNON]Zr(NMe2)2, according
1
to its H NMR spectrum. Colorless crystals were obtained from
a concentrated diethyl ether solution at -30 °C. The crystals
were collected by filtration and dried in vacuo; yield 1.43 g
(98%): 1H NMR (C6D6) δ 7.60 (d, 2, Aryl), 6.89 (s, 4, Aryl),
6.86 (t, 2, Aryl), 6.56 (t, 2, Aryl), 6.25 (d, 2, Aryl), 2.57 (s, 12,
Meo), 2.20 (s, 18, containing 6H from Mep and 12H from
1
ZrNMe2); H NMR (toluene-d8) δ 7.56 (d, 2, Aryl), 6.85 (s, 4,
Aryl), 6.79 (t, 2, Aryl), 6.52 (t, 2, Aryl), 6.17 (d, 2, Aryl), 2.54
(s, 12, Meo), 2.17 (s, 6, Mep), 2.16 (s, 12, ZrNMe2); 13C NMR
(C6D6) δ 147.56 (CAr), 146.57 (CAr), 143.40 (CAr), 135.17 (CAr),
134.08 (CAr), 129.97 (CArH), 126.60 (CArH), 116.89 (CArH),
116.12 (CArH), 114.35 (CArH), 41.64 (ZrNMe2), 21.36 (Mep),
18.93 (Meo). Anal. Calcd for C34H42N4OZr: C, 66.52; H, 6.90;
N, 9.13. Found: C, 66.64; H, 6.82; N, 9.05.
[MesNON]Zr Cl2. Neat Me3SiCl (0.640 mL, 5.07) was added
to a toluene solution (20 mL) of [MesNON]Zr(NMe2)2 (1.04 g,
1.69 mmol) at room temperature. The reaction mixture was
stirred at room temperature for 24 h. All volatile components
were removed in vacuo at ∼40 °C to give a viscous brown oil.
Diethyl ether was added dropwise to the oil to initiate
crystallization. A crop of yellow crystalline solid (696 mg) was
obtained from ∼5 mL of diethyl ether solution at room
temperature. A second crop (225 mg) was obtained by cooling
the mother liquor to -30 °C; total yield 921 mg (91%). Diethyl
ether (∼0.67 equiv per zirconium) was usually found in the
1
crystalline product, according to H NMR spectra: 1H NMR
[MesNON]Hf(NMe2)2 a n d [MesNON]HfCl2. Diethyl ether
(20 mL) was added to a solid mixture of H2[MesNON] (1.30 g,
2.98 mmol) and Hf(NMe2)4 (1.06 g, 2.98 mmol) at room
(C6D6; ether resonaces excluded) δ 7.34 (d, 2, Aryl), 6.81 (s, 4,
Aryl), 6.75 (t, 2, Aryl), 6.52 (t, 2, Aryl), 6.06 (d, 2, Aryl), 2.30
