Solution-phase synthesis of the fluorogenic TGase 2 acyl donor Z-Glu(HMC)-Gly-OH and its use for inhibitor and amine substrate characterisation

Article abstract of DOI:10.1016/j.ab.2020.113612

A reliable solution-phase synthesis of the water-soluble dipeptidic fluorogenic transglutaminase substrate Z-Glu(HMC)-Gly-OH is presented. The route started from Z-Glu-OH, which was converted into the corresponding cyclic anhydride. This building block was transformed into the regioisomeric α- and γ-dipeptides. The key step was the esterification of Z-Glu-Gly-OtBu with 4-methylumbelliferone. The final substrate compound was obtained in an acceptable yield and excellent purity without the need of purification by RP-HPLC. The advantage of this acyl donor substrate for the kinetic characterisation of inhibitors and amine-type acyl acceptor substrates is demonstrated by evaluating commercially available or literature-known irreversible inhibitors and the biogenic amines serotonin, histamine and dopamine, respectively.

Full text of DOI:10.1016/j.ab.2020.113612

Journal Pre-proof
Solution-phase synthesis of the fluorogenic TGase 2 acyl donor Z-Glu(HMC)-Gly-OH
and its use for inhibitor and amine substrate characterisation
Robert Wodtke, Markus Pietsch, Reik Löser
PII:
S0003-2697(19)31241-2
https://doi.org/10.1016/j.ab.2020.113612
YABIO 113612
DOI:
Reference:
To appear in: Analytical Biochemistry
Received Date: 12 December 2019
Revised Date: 3 February 2020
Accepted Date: 3 February 2020
Please cite this article as: R. Wodtke, M. Pietsch, R. Löser, Solution-phase synthesis of the fluorogenic
TGase 2 acyl donor Z-Glu(HMC)-Gly-OH and its use for inhibitor and amine substrate characterisation,
Analytical Biochemistry (2020), doi: https://doi.org/10.1016/j.ab.2020.113612.
This is a PDF file of an article that has undergone enhancements after acceptance, such as the addition
of a cover page and metadata, and formatting for readability, but it is not yet the definitive version of
record. This version will undergo additional copyediting, typesetting and review before it is published
in its final form, but we are providing this version to give early visibility of the article. Please note that,
during the production process, errors may be discovered which could affect the content, and all legal
disclaimers that apply to the journal pertain.
© 2020 Published by Elsevier Inc.

Author contribution
RW: Conceptualization, Investigation, Methodology, Formal Analysis, Writing- Reviewing and Editing,
Funding Acquisition; MP: Conceptualization, Formal Analysis, Writing- Reviewing and Editing, Funding
Acquisition, Supervision; RL: Conceptualization, Investigation, Formal Analysis, Writing- Original draft
preparation, Funding Acquisition, Supervision.

Z-Glu-OH
reliable synthesis
in solution
Transglutaminase 2
Z-Glu(HMC)-Gly-OH
H2O
or
RNH2
kinetic characterization of
amine substrates and
inhibitors enabled by
fluorogenic substrate
inhibitors

1
2
3
Solution-Phase Synthesis of the Fluorogenic TGase 2
Acyl Donor Z-Glu(HMC)-Gly-OH and its Use for
Inhibitor and Amine Substrate Characterisation
4
Robert Wodtke 1*, Markus Pietsch 2 and Reik Löser 1,3
*
5
6
1
2
3
Helmholtz-Zentrum Dresden-Rossendorf, Institute of Radiopharmaceutical Cancer Research; Bautzner
Landstrasse 400, 01328 Dresden, Germany
7
Institute II of Pharmacology, Centre of Pharmacology, Medical Faculty, University of Cologne, Gleueler
Strasse 24, 50931 Cologne, Germany
8
9
10
11
Faculty of Chemistry and Food Chemistry, School of Science, Technische Universität Dresden,
Mommsenstraße 4, 01062 Dresden, Germany
12
13
14
15
16
17
18
19
20
Abstract: A reliable solution-phase synthesis of the water-soluble dipeptidic fluorogenic
transglutaminase substrate Z-Glu(HMC)-Gly-OH is presented. The route started from Z-Glu-OH,
which was converted into the corresponding cyclic anhydride. This building block was
transformed into the regioisomeric α- and γ-dipeptides. The key step was the esterification of
Z-Glu-Gly-OtBu with 4-methylumbelliferone. The final substrate compound was obtained in an
acceptable yield and excellent purity without the need of purification by RP-HPLC. The advantage
of this acyl donor substrate for the kinetic characterisation of inhibitors and amine-type acyl
acceptor substrates is demonstrated by evaluating commercially available or literature-known
irreversible inhibitors and the biogenic amines serotonin, histamine and dopamine, respectively.
21
22
23
Keywords: fluorogenic enzyme substrates; side-chain esterified peptides; aryl esters; peptide
synthesis; enzyme kinetics; biogenic amines
24
1. Introduction
25
26
27
28
29
30
Transglutaminase 2 is a multifunctional enzyme whose distinct physiological roles are
incompletely understood [1, 2]. Its eponymous and best-characterised function represents the
catalysis of the acyl transfer between glutamine residues and a variety of primary amines [3]. To
assess the significance of this enzymatic activity in cells, substrates (especially low molecular weight
polyamines) [4, 5] and inhibitors [6] were applied amongst other biochemical techniques [7, 8]. The
prerequisite for an accurate interpretation of potential effects mediated by those TGase 2-targeting
*Correspondence: r.wodtke@hzdr.de, r.loeser@hzdr.de ; Tel.: +49-351-260-3658
Abbreviations
d…doublet, DIPEA…N,N-diisopropylethylamine, EDTA…N,N’-ethylenediamine tetraacetic acid, GDH…glutamate
dehydrogenase,
hTGase 2…human
TGase 2;
HMC…7-hydroxy-4-methylcoumarin
(=4-methylumbelliferone),
HATU…(1-[bis(dimethylamino)methylene]-1H-1,2,3-triazolo[4,5-b]pyridinium 3-oxide hexafluorophosphate, HPLC…high
performance liquid chromatography, Hsp…heat shock protein, LC…liquid chromatography, m…multiplet, MES…
2-(N-morpholino)ethanesulfonic acid, MOPS…(3-(N-morpholino)propanesulfonic acid), MS…mass spectrometry,
NMM…N-methylmorpholine,
NMR…nuclear
magnetic
resonance,
Np…4-nitrophenyl,
PyBOP…benzotriazol-1-yl-oxytripyrrolidinophosphonium hexafluorophosphate, q…quadruplet, RP…reversed phase,
s…singlet, t…triplet, TCEP… tris(2-carboxyethyl)phosphine, TLC…thin layer chromatography, UPLC…Ultra Performance
Liquid Chromatography, Z…benzyloxycarbonyl (=carbobenzoxy, Cbz); all other abbreviations are in accordance to the
recommendations of the IUPAC-IUB commission on biochemical nomenclature, see Eur. J. Biochem. 15 (1970) 203-208 and
Eur. J. Biochem. 138 (1984) 9-37

Wodtke et al.
2 of 17
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
molecules is the knowledge of their kinetic properties towards the isolated protein and also towards
the other members of the transglutaminase family. The other main function of TGase 2 is dealing
with the binding of GDP and GTP and catalysis of hydrolysis of the latter [9]. Both functions are
mutually exclusive as they are associated with distinct conformational states of the enzyme molecule
[10]. Therefore, occupation of the guanine nucleotide binding site of TGase 2 can be analysed via
detection of its acyltransferase activity [11, 12], which indicates the value of robust assay methods
that allow for the monitoring of this activity [13]. A rigorous kinetic assessment of the enzyme’s
acyltransferase activity is enabled by the dipeptidic coumarinyl ester Z-Glu(HMC)-Gly-OH as
fluorogenic substrate. In addition to its suitable kinetic and spectral properties, the compound’s
utility is owed to its propitious water solubility [14]. Favourably, this compound can be also used for
the assay of other transglutaminase isoforms [15]. The synthesis of peptides containing glutamate
coumarinyl esters was achieved by solid-phase peptide synthesis using the chlorotrityl linker for
attachment to the solid support. The ester moiety in the glutamate side-chain was installed after
deblocking the allyl ester-protected γ-carboxylic acid function prior to acidic cleavage from the resin
[14]. Although this synthesis strategy is advantageous for obtaining various peptidic substrates, the
product scale is limited by the use of the costly polymeric resin and the need of preparative
RP-HPLC for purification. Efficient solution-phase methods have been described by Chung et al. [16]
and Leblanc et al. [17] for the synthesis of the corresponding chromogenic dipeptidic substrate
Z-Glu(ONp)-Gly-OH, which bears a nitrophenyl group attached to the identical peptidic scaffold.
This pathway was adopted by us for an efficient access to Z-Glu(HMC)-Gly-OH, which will be
reported herein together with its kinetic evaluation towards TGase 2-catalysed hydrolysis. In this
context, it was envisaged to re-prove the fluorogenic substrate’s previously established value for
TGase 2 inhibitor and substrate characterisation exemplarily for commercially available irreversible
inhibitors for which robust second-order inactivation constants kinact/K have not been reported so far.
I
Furthermore, kinetic parameters for selected physiologically relevant amine substrates were
determined by taking advantage of the title compound.
58
59
2. Materials and Methods
2.1. General
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
All starting materials, reagents and solvents were commercially obtained and used without
further purification. Compound 5, N-monodansylpiperazine and N-acryloxysuccinimide were
synthesised as previously published [15]. Chromatographic separations and TLC detections were
carried out with Merck Silica Gel 60 (63–200 μm) and Merck Silica Gel 60 F254 sheets, respectively.
TLCs were visualised under UV light (λ = 254 nm or 365 nm). Analytical RP-HPLC was carried out
with a system consisting of a Merck Hitachi L7100 gradient pump combined with a Jasco DG2080
four-line degasser with UV detection with a Merck Hitachi L7450 diode array detector. The system
was operated with D-700 HSM software and use of a Merck Hitachi D7000 interface. A Luna C18 5
μm column (Phenomenex, 250×4.6 mm) served as stationary phase. A binary gradient system of
0.1% CF
3
COOH/water (solvent A) and 0.1% CF
3
COOH/CH CN (solvent B) at a flow rate of 1
3
mL/min served as the eluent. The following elution programme was run to separate the
components: 0–3 min 80% A, 3–45 min gradient to 70% B, 45–46 min gradient to 95% B, 46–50 min
95% B, 50–55 min gradient back to 80% A, 55–60 min 80% A. For purification of compound 7,
preparative HPLC were performed on a Varian Prepstar system equipped with a UV detector
(Prostar, Varian). A Microsorb C18 60−8 column (Varian Dynamax 250 mm × 21.4 mm) was used as
the stationary phase. The same binary gradient system as for the analytical RP-HPLC was applied
using an appropriate gradient from low to high percentage of B with a slope of 1% per min.
Melting points were determined on a Galen III Boetius apparatus from Cambridge Instruments.
NMR spectra were recorded on a Varian Unity 400 MHz or an Agilent DD2 600 MHz spectrometer
equipped with ProbeOne probe. Chemical shifts of the 1H and 13C spectra were reported in parts per
million (ppm) referenced to the (residual) solvent resonances relative to tetramethylsilane.

Wodtke et al.
3 of 17
81
82
83
84
85
86
87
UPLC-MS was performed on a Waters ACQUITY UPLC I-Class system including an ACQUITY
UPLC PDA eλ setector coupled to a Xevo TQ-S mass spectrometer High-resolution mass spectra
were obtained on an Agilent UHD Accurate-Mass Q-TOF LC MS G6538A mass spectrometer
operated in combination with coupled with the Agilent 1260 Infinity II HPLC system. Elemental
microanalysis was performed on a Euro EA 3000 Elemental Analyzer (Euro Vector Instruments &
Software).
88
2.2. Benzyl (S)-(2,6-dioxotetrahydro-2H-pyran-3-yl)carbamate (1, N-Carbobenzoxyglutamic anhydride)
89
90
91
92
93
94
95
96
97
Z-Glu-OH (2.5 g, 8.89 mmol) was suspended in acetic anhydride (20 mL) and the temperature
was slowly raised to 55 °C (oil bath temperature), whereupon a clear solution was formed. From the
time of complete dissolution, stirring was continued for additional 10 min. The solution was
concentrated under high vacuum (rotary evaporator equipped with hybrid vacuum pump) to obtain a
nearly colourless oil. Ether (30 mL) was added to the crude product and ethyl acetate (5-10 mL) was
added until a homogeneous solution was obtained upon heating. The solution was transferred to an
Erlenmeyer flask and cyclohexane (15-20 mL) was added until the solution became turbid. The
mixture was kept at -20 °C over night, whereupon an oil separated. Crystallisation was initiated by
scratching with a glass rod. More cyclohexane (10 mL) was added and the mixture was kept again at
-20 °C over night. The crystalline material was collected by vacuum filtration and dried in vacuo to
obtain 1 (2.1 g, 0.80 mmol, 90%) as a white powder; Mp 82-86 °C (lit 86-88 °C [18]); 1H NMR (400 MHz,
98
99
2
3
100
101
102
103
104
105
106
CDCl
2J=18.9 Hz, 3J=13.0 Hz, 3J=6.2 Hz, 1H, Cγ-HH), 3.06 (ddd, 2J=18.7 Hz, 3J=5.6 Hz, 3J=2.2 Hz, 1H, Cγ-HH),
4.38-4.52 (m, 1H, Cα-H), 5.15 (s, 2H, CH
O), 5.57 (br s, 1H, NH), 7.30-7.42 (m, 5H, Ph-H); 13C NMR (100
MHz, CDCl ), δ (ppm): 23.72 (Cβ), 29.83 (Cγ), 51.48 (Cα), 67.77 (CH O), 128.39, 128.64, 128.80, 135.80,
(Carom), 155.81, OCONH), 164.53, 166.65 (2×C=O anhydride). NMR data are in agreement to those
3
), δ (ppm): 1.94 (qd, J=13.1 Hz, J=5.6 Hz, 1H, Cβ-HH), 2.45-2.59 (m, 1H, Cβ-HH), 2.90 (ddd,
2
3
2
reported in [17]. Elemental analysis C13
58.33%, H: 5.15%, N: 5.16%.
H
13NO , calcd. C: 59.31%, H: 4.98%, N: 5.32%, found: C:
5
107
108
2.3. (S)-4-(((Benzyloxy)carbonyl)amino)-5-((2-(tert-butoxy)-2-oxoethyl)amino)-5-oxopentanoic acid (2,
Z-Glu-Gly-OtBu)
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
To a solution of compound 1 (0.5 g, 1.90 mmol) in chloroform (20 mL) was added glycine
tert-butyl ester hydrochloride (H-Gly-OtBu×HCl; 0.32 g, 1.90 mmol) as a solid followed by triethyl
amine (0.19 g, 0.26 mL, 1.90 mmol). The resulting solution was stirred for 30 min at room temperature.
The solvent was removed in vacuo and the obtained crude product mixture was adsorbed on silica gel
and loaded onto a silica column. Product 2 was obtained by elution with ether/ethyl acetate/acetic acid
1:1:0.01. As the UV absorption of both products is rather low, visualisation of compound spots during
monitoring of the chromatographic purification by TLC analysis of distinct fractions was done by
using Hanessian’s stain [19]. The product-containing fraction were combined and brought to dryness
in vacuo. The obtained oily residue was crystallised by dissolving in a minimum amount of ethyl
acetate and subsequent addition of a larger volume of cyclohexane. The oil which separated from the
solvent mixture solidified at -20 °C. The solid was collected by vacuum filtration to obtain 373 mg (50
%) of compound 2. R
[20]); 1H NMR (400 MHz, CDCl
f
0.35 (n-hexane/ethyl acetate/acetic acid 1:4:0.01); Mp 96-103 °C (lit 106- 107 °C
), δ (ppm): 1.45 (s, 9H, (CH C), 1.88 – 2.01 (m, 1H, Cβ-HH), 2.09 – 2.20
), 3.83 – 4.00 (m, 2H, GlyCα-H ), 4.41 – 4.49 (m, 1H, GluCα-H),
3
3)3
(m, 1H, Cβ-HH), 2.41 – 2.59 (m, 2H, Cγ-H
2
2
3
5.05-5.17 (m, 2H, CH
2
O), 5.88 (d, J=8.6 Hz, 1H, Glu-NH), 7.10-7.16 (br s, 1H, Gly-NH), 7.27-7.39 (m,
5H, Ph-H); 13C NMR (100 MHz, CDCl
53.85 (GluCα), 67.44 (CH
O), 82.75 ((CH
169.06, 171.93, 176.71 (3×C=O). NMR data are in agreement to those reported in [17]. Elemental
analysis C19 : calcd. C: 57.86%, H: 6.64%, N: 7.10%, found: C: 58.97%, H: 6.79%, N: 6.94%.
3
), δ (ppm): 28.16 (3×CH
3
), 28.28 (Cβ), 29.91 (Cγ) 42.25 (GlyCα),
2
3)3C), 128.20, 128.37, 128.68, 136.14 (4×Carom), 156.70 (OCONH),
H26
N
2
O7
128
2.4. N2-((Benzyloxy)carbonyl)-N5-(2-(tert-butoxy)-2-oxoethyl)-L-glutamine (2a)

Wodtke et al.
4 of 17
129
130
131
132
133
134
135
136
137
138
139
140
Compound 2a was obtained by further elution of the chromatographic column described above
with ether/ethyl acetate/acetic acid 1:4:0.01. The product-containing fractions were combined and
brought to dryness in vacuo. The obtained oily residue was washed with cyclohexane under
ultrasonification to remove residual acetic acid, which was followed by washing with n-pentane. The
oil was dried under very low pressure (< 0.1 mbar) to obtain 223 mg (30%) of compound 2a as a white
foam. R
9H, (CH
3.96 (m, 2H, GlyCα-H
6.77 (t, 3J=4.9 Hz, 1H, Gly-NH), 7.27 – 7.35 (m, 5H, Ph-H), 13C NMR (100 MHz, CDCl
(3×CH O), 82.91 ((CH C), 128.19, 128.31,
), 28.50 (Cβ), 32.13 (Cγ), 42.35 (GlyCα), 53.48 (GluCα), 67.24 (CH
128.65, 136.28 (4×Carom), 156.61 (OCONH), 169.39, 173.61, 174.34 (3×C=O). Elemental analysis
: calcd. C: 57.86%, H: 6.64%, N: 7.10%, found: C: 57.36%, H: 6.74%, N: 6.58%.
f
0.17 (n-hexane/ethyl acetate/acetic acid 1:4:0.01); 1H NMR (400 MHz, CDCl
C), 1.99 – 2.09 (m, 1H, Cβ-HH), 2.15 – 2.27 (m, Cβ-HH, 1H), 2.30 – 2.49 (m, 2H, Cγ-H
), 4.32 – 4.43 (m, 1H, GluCα-H), 5.08 (s, 2H, CH O), 6.02 (d, 3J=7.5 Hz, 1H, Glu-NH),
) δ (ppm): 28.12
3
) δ (ppm): 1.45 (s,
3)3
2), 3.84 –
2
2
3
3
2
3)3
C
19
H26
N
2
O7
141
142
143
2.5. 4-Methyl-2-oxo-2H-chromen-7-yl
(S)-4-(((benzyloxy)carbonyl)amino)-5-((2-(tert-butoxy)-2-oxoethyl)amino)-5-oxopentanoate (3,
Z-Glu(HMC)-Gly-OtBu)
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
Compound 2 (0.373 g, 0.95 mmol) and HATU (0.361 g, 0.95 mmol) were dissolved in DMF (3 mL)
under a N
0.95 mmol) in DMF (1 mL) were added to this mixture. The resulting yellow solution was stirred for 2
h at room temperature. Subsequently, the solution was diluted with CH Cl (15 mL), transferred to a
separatory funnel and washed with 1 M HCl (1×3 mL), sat. NaHCO (2×3 mL), H O (1×3 mL) and brine
(1×1 mL). The organic layer was dried over Na SO and evaporated in vacuo (the remaining DMF was
2
atmosphere. DIPEA (282 μL, 1.88 mmol) and a solution of 4-methylumbelliferone (0.168 g,
2
2
3
2
2
4
removed using a rotary evaporator equipped with hybrid pump for very low pressure) to obtain a
yellow viscous oil. The crude product was purified by column chromatography on silica gel using a
mixture of n-hexane and ethyl acetate of increasing polarity (ratio starting from 6:4 over 1:1 to 4:6; the
final ratio was adjusted 20 fractions after unconverted 4-methylumbelliferone eluted). The
product-containing fractions were collected and evaporated in vacuo to obtain 243 mg of compound 3
as an off-white solid. As the product still contained 4-methylumbelliferone as trace impurity, the
material was recrystallised by adding ethyl acetate (3.2 mL) to a refluxing suspension of the product in
cyclohexane (4 mL). Upon keeping the solution at 4 °C overnight, a precipitate was formed, which was
collected by vacuum filtration, washed with cyclohexane and n-hexane and dried in vacuo to obtain
compound 3 (134 mg, 26%) as a white granulous solid. R
°C; 1H NMR (400 MHz, CDCl
), δ (ppm): 1.47 (s, 9H, (CH
1H, Cβ-HH), 2.43 (d, 4J = 1.3 Hz, 3H, CH
f
0.16 (n-hexane/ethyl acetate 1:1); Mp 61-63
3
3)3
C), 2.02 – 2.14 (m, 1H, Cβ-HH), 2.26-2.38 (m,
3
-coumarin), 2.67-2.90 (m, 2H, Cγ-H
), 3.90 (dd, 2J=18.2 Hz, 3J=5.1
2
Hz, 1H, Cα-HH of Gly), 3.98 (dd, 2J=18.3 Hz, 3J=5.4 Hz, 1H, Cα-HH of Gly), 4.37 – 4.44 (m, 1H, Cα-H of
Glu) 5.11 (d, 2J=12.3 Hz, 1H, CHHO), 5.15 (d, 2J=12.9 Hz, 1H, CHHO), 5.58 (d, 3J=8.0 Hz, 1H, Glu-NH),
6.27 (q, 4J=1.3 Hz, 1H, H-3 of coumarin), 6.51 (br s, 1H, Gly-NH) 7.07 – 7.11 (m, 1H, H-6 of coumarin),
4
3
7.13 (d, J=1.8 Hz, 1H, H-8 of coumarin), 7.28 – 7.38 (m, 5H, Ph-H), 7.57 (d, J=8.6 Hz, 1H, H-5 of
coumarin). 13C NMR (100 MHz, CDCl
), δ (ppm): 18.88 (CH of coumarin), 28.20 (3×CH ), 28.30 (Cβ),
30.52 (Cγ), 42.18 (Cα of Gly), 53.92 (Cα of Glu), 67.43 (CH O), 82.75 ((CH C), 110.65 (C8 of coumarin),
3
3
3
2
3)3
114.76 (C3 of coumarin), 118.09, 118.27 (C4a and C6 of coumarin), 125.53 (C5 of coumarin), 128.30,
128.42, 128.73 (3×CH of phenyl), 136.18 (C1 of phenyl), 151.99, 153.10, 154.34 (C4, C7 and C8a of
coumarin), 156.37 (OCONH), 160.61 (C2 of coumarin), 168.62, 171.00, 171.54 (3×C=O). HR-MS (ESI+):
[M+NH
4
]+ calculated: 570.2451, found: 570.2445 (90%), [2M+NH
4
]+ calculated: 1122.4559, found:
1122.4565 (100%). Elemental analysis C29
62.48%, H: 5.82%, N: 4.73%.
H32
N
2
O9
: calcd. C: 63.04%, H: 5.84%, N: 5.07%, found: C:
175
176
2.6. (S)-(2-(((Benzyloxy)carbonyl)amino)-5-((4-methyl-2-oxo-2H-chromen-7-yl)oxy)-5-oxopentanoyl)glycine
(4, Z-Glu(HMC)-Gly-OH)
177
178
To a solution of compound 3 (130 mg, 0.24 mmol) in CH
2
Cl (0.5 mL) was added slowly
2
trifluoroacetic acid (4 mL) under ice cooling. After stirring for 2 h under ice cooling the solvents were

Wodtke et al.
removed under a N
5 of 17
Cl (20
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
2
stream under ambient pressure. The oily residue was taken up into CH
2
2
mL) and washed with 0.1 M HCl (5 mL). As addition of HCl resulted in the formation of an emulsion,
brine (3 mL) was added, whereupon a white precipitate was formed, which was filtered off and
redissolved in ethyl acetate (15 mL). The aqueous layer was separated from the combined biphasic
mixture and the organic layer was dried over Na
2
SO
4
and evaporated in vacuo to obtain 112 mg of a
1
white solid. Since an impurity was detectable in the H NMR spectrum, the crude product was
recrystallised. To this end, the solid was dissolved in a mixture of ethyl acetate (4 mL) and acetonitrile
(2 mL) under heating. Cyclohexane (6 mL) was added and the resulting solution was kept at 4 °C for
30 min, whereupon a gelatinous precipitate formed. The material was collected by vacuum filtration,
washed with cyclohexane and n-pentane and dried in vacuo to obtain compound 4 (77 mg, 65%) as a
1
white solid. R
f
0.01 (n-hexane/ethyl acetate 2:8); Mp 167-171 °C; H NMR (400 MHz, DMSO-d
6) δ
(ppm): 1.88 – 1.98 (m, 1H, Cβ-HH), 2.02 – 2.14 (m, 1H, Cβ-HH), 2.44 (d, 4J=1.3 Hz, 3H, CH
3
-coumarin),
2
3
2
3
2.68 – 2.75 (m, 2H, Cγ-H
2
), 3.73 (dd, J=17.5, J=5.6 Hz, 1H, Cα-HH of Gly), 3.83 (dd, J=17.5, J=6.0 Hz,
1H, Cα-HH of Gly), 4.15-4.21 (m, 1H, Cα-H of Glu), 5.02 (d, 2J=12.6 Hz, 1H, CHHO), 5.07 (d, 2J=12.6 Hz,
1H, CHHO), 6.39 (d, 4J=1.3 Hz, 1H, H-3 of coumarin), 7.18 (dd, 3J=8.7, 2.3 Hz, 1H, H-6 of coumarin), 7.26
(d, 4J=2.3 Hz, 1H, H-8 of coumarin), 7.28 – 7.39 (m, 5H, Ph-H), 7.54 (d, 3J=8.3 Hz, 1H, Glu-NH), 7.81 (d,
3J=8.7 Hz, 1H, H-5 of coumarin), 8.29 (t, 3J=5.8 Hz, 1H, Gly-NH). 13C NMR (100 MHz, CDCl
18.11 (CH of coumarin), 26.98 (Cβ), 30.00 (Cγ), 40.66 (Cα of Gly), 53.49 (Cα of Glu), 65.51 (CH
3
), δ (ppm):
O),
3
2
110.04 (C8 of coumarin), 113.69 (C3 of coumarin), 117.47 (C4a of coumarin), 118.34 (C6 of coumarin),
126.32 (C5 of coumarin), 127.66, 127.74, 128.27 (3×CH of phenyl), 136.88 (C1 of phenyl), 152.82,
152.90, 153.48 (C4, C7 and C8a of coumarin), 155.92 (OCONH), 159.55 (C2 of coumarin), 170.82,
171.03, 171.51 (3×C=O). NMR data are in agreement to those reported in [14]. HR-MS (ESI+): m/z
calculated for [M+NH
1010.3313 (57.2%), [3M+NH
O calcd. C: 58.36%, H: 5.09%, N: 5.45%, found: C: 58.36%, H: 4.92%, N: 5.23%.
4
]+: 514.1825, found: 514.1821 (100%), [2M+NH
4
]+: calculated: 1010.3307, found:
]+: calculated: 1506.4789, found: 1506.4799 (80.52%). Elemental analysis:
4
C
25
H24
N
2
O9
H2
Chromatograms for UPLC-MS analysis of Z-Glu(HMC)-Gly-OH (4) are shown in Figure S2
(Supporting Information).
207
208
2.7. tert-Butyl (2-(4-((5-(dimethylamino)naphthalen-1-yl)sulfonyl)piperazin-1-yl)-2-oxoethyl)carbamate (6a,
N-Boc-glycine-4-dansylpiperazide)
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
To a solution of Boc-glycine (98.8 mg, 0.56 mmol) and DIPEA (196.5 μL, 0.12 mmol) in DMF
(5 mL) was added PyBOP (293 mg, 0.56 mmol). The solution was stirred for 5 min at room
temperature and, subsequently, N-monodansylpiperazine (90 mg, 0.28 mmol) was added. After
stirring for 3 h, the solvent of the reaction mixture was removed in vacuo and the obtained residue
was dissolved in ethyl acetate (15 mL). The organic phase was washed with sat. NaHCO
and brine (1×10 mL), dried over Na SO and evaporated to dryness. The obtained crude product was
subjected to column chromatography (silica; eluent: petroleum ether/ethyl acetate (25 ‰ 50%)) to
3
(2×10 mL)
2
4
obtain 6a (133 mg, 100%) as a light-green solid; 1H NMR (400 MHz, CDCl
Boc), 2.90 (s, 6H, 2×CH of dansyl), 3.23–3.15 (m, 4H, 2×CH of piperazine), 3.45–3.39 (m, 2H, CH
piperazine), 3.69–3.62 (m, 2H, CH
7.21 (d, 3J=7.5 Hz, 1H, HDansyl), 7.55 (dd, 3J=8.6, 7.6 Hz, 2H, 2×HDansyl), 8.20 (dd, 3J=7.3 Hz, 4J=1.2 Hz, 1H,
3
): δ=1.41 (s, 9H, 3×CH
3
of
of
3
2
2
3
2
of piperazine), 3.86 (d, J=4.5 Hz, 2H, CH Gly), 5.36 (br s, NH),
2
3
3
H
Dansyl), 8.37 (d, J=8.7 Hz, 1H, HDansyl), 8.59 (d, J=8.5 Hz, 1H, HDansyl); 13C NMR (100 MHz, CDCl
δ=28.45 (3×CH Boc), 41.68 (CH of piperazine), 42.28 (CH of Gly), 44.24 (CH of piperazine), 45.48
(CH of piperazine), 45.63 (CH of piperazine), 45.65 (2×CH dansyl), 80.03 (Cquartär of Boc), 115.67,
3
):
3
2
2
2
2
2
3
119.65, 123.45, 128.45, 130.16 (Cquart of dansyl), 130.44 (Cquart of dansyl), 131.03, 131.16, 132.30 (Cquart of
1
dansyl), 151.68 (Cquart of dansyl), 155.87 (CO of Boc), 167.07; MS (ESI+) 477.3 ([M+H]+). H and 13C
NMR spectra in agreement to published data [21].
227
228
2.8. 2-Amino-1-(4-((5-(dimethylamino)naphthalen-1-yl)sulfonyl)piperazin-1-yl)ethan-1-one (6b,
Glycine-4-dansylpiperazide)

Wodtke et al.
Compound 6a (167 mg, 0.35 mmol) was dissolved in a mixture of TFA and CH
6 of 17
229
230
231
232
233
234
235
236
237
238
239
240
241
2
Cl
2
(10 mL; 1:1,
v/v) and stirred for 2 h at room temperature. The volatiles were removed at ambient pressure in a
nitrogen stream. The residue was dissolved in sat. NaHCO (20 mL) and extracted with CH Cl
(5×5 mL). The organic phase was dried over Na SO and subsequently evaporated to dryness to
obtain 6b (131 mg, 100%) as a light-green solid; 1H NMR (400 MHz, DMSO-d
): δ=2.83 (s, 6H, 2×CH
of dansyl), 3.12–3.05 (m, 4H, 2×CH of piperazine), 3.53–3.20 (m, 6H, 2×CH of piperazine, CH Gly),
7.27 (d, 3J=7.5 Hz, 1H, HDansyl), 7.70–7.59 (m, 2H, 2×HDansyl), 8.13 (dd, 3J=7.4 Hz, 4J=1.2 Hz, 1H, HDansyl),
8.30 (d, 3J=8.7 Hz, 1H, HDansyl), 8.53 (d, 3J=8.5 Hz, 1H, HDansyl), signal for NH not detectable; 13C NMR
(100 MHz, DMSO-d ): δ=40.89 (CH of piperazine), 42.53 (CH Gly), 43.39 (CH of piperazine), 45.04
(2×CH of dansyl), 45.37 (2×CH of piperazine), 115.33, 118.86, 123.70, 129.20 (Cquart of dansyl), 129.62
3
2
2
2
4
6
3
2
2
2
2
6
2
2
2
3
2
(Cquart of dansyl), 130.06, 130.39, 132.48 (Cquart of dansyl), 151.42 (Cquart of dansyl), 171.55 (CO); MS
(ESI+) 377.2 ([M+H]+) 1H and 13C NMR spectra are in agreement to published data [21].
242
243
2.9. N-(2-(4-((5-(Dimethylamino)naphthalen-1-yl)sulfonyl)piperazin-1-yl)-2-oxoethyl)acrylamide (7,
N-Acryloylglycine-4-dansylpiperazide)
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
To a solution of compound 6b (112 mg, 0.30 mmol) and TEA (82.5 μL, 0,60 mmol) in CH
2
Cl
2
(10 mL) was added N-acryloxysuccinimide (50.3 mg, 0,30 mmol) as solid. After 1 h, the same amount
of N-acryloxysuccinimide was added again and the mixture was stirred for additional 1 h at room
temperature. The solution was washed with sat. NaHCO
Na SO and evaporated to dryness. The crude product was purified by preparative RP-HPLC to
obtain 7 (10.9 mg, 7%) as a white solid; 1H NMR (400 MHz, CDCl
): δ=3.01 (s, 6H, 2×CH of dansyl),
3
(2×10 mL), brine (1×10 mL); dried over
2
4
3
3
3.27–3.18 (m, 4H, 2×CH
2
of piperazine), 3.52–3.45 (m, 2H, CH
2
of piperazine), 3.72–3.66 (m, 2H, CH
2
3
3
2
of piperazine), 4.08 (d, J=4.2 Hz, 2H, CH
2
Gly), 5.68 (dd, J=10.2 Hz, J=1.4 Hz, 1H, CH=CHH), 8.62
(d, 3J=8.6 Hz, 1H, HDansyl), 6.15 (dd, 3J=17.0, 10.2 Hz, 1H, CH=CH
CH=CHH), 6.74 (bs, 1H, N
H of Gly), 7.31 (d, 3J=7.6 Hz, 1H, HDansyl), 7.64–7.56 (m, 2H, 2×HDansyl), 8.24
(dd, 3J=7.4 Hz, 4J=1.1 Hz, 1H, HDansyl), 8.48 (d, 3J=8.7 Hz, 1H, HDansyl), 8.62 (d, 3J=8.6 Hz, 1H, HDansyl); 13C
NMR (100 MHz, CDCl ): δ=41.38 (CH of Gly), 41.86 (CH of piperazine), 44.36 (CH of piperazine),
45.41 (CH of piperazine), 45.59 (CH of piperazine), 45.84 (2×CH
127.71 (CH=CH ), 128.30, 129.57 (Cquart of dansyl), 130.01 (CH=CH
2
), 6.28 (dd, 3J=17.0 Hz, 2J=1.4 Hz, 1H,
α
3
2
2
2
2
2
3
of dansyl), 116.22, 121.07, 124.15,
2
2
), 130.43 (Cquart of dansyl), 130.57,
1
131.26, 132.59 (Cquart of dansyl), 149.58 (Cquart of dansyl), 165.92, 166.56. H and 13C NMR spectra in
agreement to published data [21].
260
2.10. General assay procedure and analysis
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
All measurements were conducted at 30 °C over 900 s (interval of 8 or 10 s) using a Cytation 5
Microplate Reader (BioTek Instruments) and black 96-well microplates with μCLEAR® bottom
(greiner bio-one). Fluorescence was detected in bottom read mode and predefined settings for
excitation (360±20 nm) and emission (450±20 nm) of 7-HMC were chosen. Measurements at pH=8.0
and pH=6.5 were conducted with a sensitivity of 45 and 50, respectively. The assay mixture (200 μL)
contained 190 μL aqueous solution and 10 μL DMSO (5% v/v). The following three buffer systems
were used: assay buffer I (100 mM MES, 3 mM CaCl
NaOH), assay buffer II (100 mM MOPS, 3 mM CaCl
NaOH) and enzyme buffer (100 mM MOPS, 3 mM CaCl
2
, 50 μM EDTA, adjusted to pH 6.5 with 1 M
, 50 μM EDTA, adjusted to pH 8.0 with 1 M
, 10 mM TCEP, 20% (v/v) glycerol). The
2
2
buffers were stored at 0 °C for periods of up to 2 weeks and freshly prepared after that period. The
concentration of the hTGase 2 stock solution was 1 mg/mL. All regression analyses were
accomplished using GraphPad Prism (version 8.2.1, August 20, 2019). To provide values of mean
and SEM, the respective regression analyses were separately accomplished for each experiment and
the obtained fit values were collected and statistically analysed. hTGase 2 (T022) and inhibitors Z006
and Z013 were purchased from Zedira (Darmstadt, Germany).
Detailed descriptions of the assay procedures and the kinetic analyses for the characterisation of
Z-Glu(HMC)-Gly-OH (4) towards enzymatic hydrolysis at pH 6.5 and 8.0 as well as for the kinetic
characterisation of amines and irreversible inhibitors are given in recent publications of our group

Wodtke et al.
7 of 17
279
280
281
282
283
284
285
[14, 15]. In brief, the recorded time courses of type (RFU-RFU
0
)=f(t) for the enzymatic and
spontaneous conversion were analysed by nonlinear (one-phase association) and linear regressions
to the experimental data. Subsequently, initial rates v0total (in the presence of enzyme) and v0control
(spontaneous reaction in the absence of enzyme) were derived. Both data sets were globally
analysed by applying the model of total and nonspecific binding (implemented in GraphPad Prism)
to obtain the kinetic parameters for the enzymatic reaction. According to that model, the following
rule was defined:
286
vꢀꢁꢂꢁꢃꢄ(enzymatic + spontaneous) = vꢀꢅꢂꢆꢆ(enzymatic) + vꢀꢅꢂꢇꢁꢆꢂꢄ(spontaneous)
(1)
287
288
289
where v0corr represents the rates for the enzymatic conversions (without spontaneous reaction). The
spontaneous and enzymatic conversions are mathematically defined within this model by the
following equations:
290
291
vꢀꢅꢂꢇꢁꢆꢂꢄ = ꢈꢂꢉꢊ ∗ [S]
(2)
(3)
ꢋ
ꢌꢍꢎ
∗[ꢏ]
vꢀꢅꢂꢆꢆ
=
ꢐ
ꢑ[ꢏ]
ꢌ
292
293
Accordingly, v0total is defined by the sum function of equations (2) and (3). Due to negligible
spontaneous reaction of 4 at pH 6.5, the above mentioned rule simplifies as follows:
294
vꢀꢁꢂꢁꢃꢄ = vꢀꢅꢂꢆꢆ
(4)
295
296
297
298
299
300
301
302
303
304
305
However, concerning the kinetic analyses the previously published procedures were slightly
adjusted, as detailed below.
Concerning the enzymatic hydrolysis of Z-Glu(HMC)-Gly-OH (4) at pH 6.5, the recorded time
courses of type (RFU-RFU )=f(t) were analysed by either nonlinear (one-phase association) or linear
0
regression over the entire measurement period of 900 s (instead of only the first 300 s) to the
experimental data depending on the shape of the curve.
Concerning the kinetic characterisation of the biogenic amines, the two sets of initial rates
(v0total=f([amine]) and v0control=f([amine])) were also globally analysed using the model of total and
nonspecific binding (instead of simple subtraction of v0control from vototal values) as conducted for the
analysis of the enzymatic hydrolyes).
306
3. Results and Discussion
307
308
309
310
311
312
313
314
315
316
317
318
319
320
321
322
323
The four-step synthesis started from commercially available Z-Glu-OH and the first two steps
followed mainly the procedures published by Leblanc et al. [17] (Scheme 1). Treatment of Z-Glu-OH
with acetic anhydride, which acts both as solvent and condensation agent, at elevated temperature
led to the corresponding cyclic anhydride 1. The oily crude product obtained by concentration of the
reaction mixture could be crystallised by treatment with ether, ethyl acetate and cyclohexane (see
Material and Methods section), which resulted in an almost quantitative yield of 90%. From a
historical point of view, it is worth to mention that glutamic anhydride 1 has been used as building
block for the synthesis of glutamate-containing peptides when peptide chemistry was still in its
infancy [22]. Compound 1 was subjected to ring opening with glycine tert-butyl ester, which resulted
in quantitative consumption of the anhydride within 30 min under the formation of the
regioisomeric α- and γ-dipeptides 2 and 2a. The ratio of both isomers was determined to be 7:3 in the
favour to the desired product 2 by HPLC analysis (see Figure S1, Supporting Information). As
reported by Leblanc et al., both products were conveniently separated by chromatography on silica
gel. By-product 2a was characterised and could – in its Nα-Fmoc-protected version – be a useful
building block for solid-phase peptide synthesis as it represents an extended glutamate analogue.
Dipeptide Z-Glu-Gly-OtBu (2) was esterified with the fluorophore 4-methylumbelliferone by
applying conditions that have been elaborated by Twibanire and Grindley for the efficient acylation

Wodtke et al.
8 of 17
324
325
326
327
328
329
330
331
332
333
of alcohols of varying reactivity using HATU as activating agent [23], which provided compound 3.
Column chromatographic purification of the crude product yielded the product, which contained an
unknown impurity according to the 1H NMR spectrum beside trace amounts of unreacted
4-methylumbelliferone. As these impurities would be more difficult to remove after the final step
considering the higher polarity of the free carboxylic acid, the obtained material was recrystallised to
furnish highly pure compound 3. In the final step, tert-butyl ester 3 was cleaved by treatment with
trifluoroacetic acid. During work-up, excessive TFA was efficiently removed by acidic aqueous
washing to obtain the crude product in crystalline state. This material was recrystallised form ethyl
acetate/acetonitrile/cyclohexane to obtain compound 4 as monohydrate, according to results of
elementary microanalysis. Its purity has been confirmed by RP-HPLC/MS analysis.
334
335
336
337
338
Scheme 1: Four-step synthesis of Z-Glu(HMC)-Gly-OH (4) starting from Z-Glu-OH. Reagents and conditions:
a) acetic anhydride, 55 °C, 10 min; b) H-Gly-OtBu×HCl, triethylamine, CHCl
3, room temperature; c) HATU,
DIPEA, 4-methylumbelliferone, DMF, room temperature; d) TFA, CH Cl , room temperature.
2
2
339
340
341
342
343
344
345
346
Compound 4 was investigated regarding the kinetics of hTGase 2-catalysed hydrolysis both at
pH 6.5 and pH 8.0. The results are shown in Figure 1 and Table 1 (see also Figure S19 in Supporting
Information). The obtained catalytic and Michaelis constants are in good agreement with the
recently published values [14]. The fact that the determined K values are slightly lower than those
m
recently published can be attributed to the better-defined composition of the crystalline compound
material obtained herein whereas previously obtained substrate preparations furnished amorphous
and slightly hygroscopic material after lyophilisation.

Wodtke et al.
9 of 17
347
348
349
350
351
352
Figure 1: hTGase 2-catalysed hydrolysis of Z-Glu(HMC)-Gly-OH (4) at pH=8.0 and pH 6.5. Plots of v0corr=f([4])
for pH 8.0 and pH 6.5 with the nonlinear regressions (―) using Equation (3) (Michaelis-Menten equation,
Materials and Methods section). Data shown are mean values ±SEM of 3 separate experiments, each performed
in duplicate. When not apparent, error bars are smaller than the symbols. Conditions: pH=8.0 or 6.5, 30 °C, 5%
DMSO, 500 μM TCEP, 3 μg/ml of hTGase 2.
353
Table 1: Kinetic parameters for the hTGase 2-catalysed hydrolyses of Z-Glu(HMC)-Gly-OH (4) at pH 6.5 and 8.0
pH value
6.5
Km (µM)
4.05 (0.23)
3.93 (0.48)
kcat (s-1)
0.30 (0.01)
0.61 (0.03)
kcat/Km (M-1s-1)
74,100
8.0
155,000
354
355
Rate constant for spontaneous hydrolysis: kobs (TCEP, pH 8.0) = 16.8 (0.5) × 10-3 min-1
For details on calculation of the kinetic parameters see Materials and Methods Section. Data shown are mean
356
357
values (±SEM) of three separate experiments, each performed in duplicate. Active concentrations of hTGase 2
(E
T=30.8 nM) were determined by active site titration as recently described [24].
358
359
360
361
362
363
364
365
366
367
368
Following the hTGase 2-catalysed hydrolysis at pH 6.5, the utility of substrate 4 for the kinetic
characterisation of irreversible inhibitors was demonstrated/validated by investigating three
inhibitors which were reported in the literature. The selected compounds comprised the
commercially available peptidic inhibitors Z006 and Z013, which bear a diazomethyl ketone or an
α,β-unsaturated carboxylic ester as electrophilic warhead, respectively. Furthermore, the
nonpeptidic acrylamide 1-155 (compound 7), which was recently published by Badarau et al. [21,
25], was synthesised according to Scheme 2 in orientation to the described procedure. In contrast to
the former two compounds, a second-order inactivation constant kinact/K
I
has been reported for the
latter. The results of the inhibitor characterisation are included in Table 2.
Table 2: Second-order inactivation constants (kinact/K
I
) and K values of different literature-known irreversible
i
369
inhibitors of hTGase 2 at pH 6.5 compared to their reported inhibitory parameters
compound
structure
kinact/KI (M-1s-1)a* Ki (µM)a*
IC50 (nM)

Wodtke et al.
10 of 17
310[15]b
14 (8.2)[26]c
4,880 (20)[15]
5.73 (0.77)[15]
5
20[27]c
Z006
191,000 (3,000)
0.096 (0.01)
Z013
51,500 (5,800)
0.45 (0,02)
1.43 (0,01)
200[28]d
12,700 (700)
4,962[21]f
6.1 (0.4)[21]e
1-155 (7)
aData shown are mean values (±SEM) of two separate experiments, each performed in duplicate.
bTGase 2-catalysed incorporation of R-I-Cad in DMC (transamidation) at pH 8.0 (5 min preincubation period
of enzyme and inhibitor). cTGase 2-catalysed incorporation of Boc-K-NH(CH
NH-Dns in DMC
2)2
(transamidation) at pH 7.4 (30 min preincubation period of enzyme and inhibitor). dIsopeptidase-assay using
the substrate Abz-NE(CAD-DNP)EQVSPLTLLK-OH (A101, Zedira). eTGase 2-catalysed incorporation of
N-(biotinyl)cadaverine in immobilised DMC (transamidation) at pH 8.5 (30 min preincubation period of
enzyme and inhibitor. fGDH-coupled assay (deamidation) at pH 7.2.
*
KI=(koff+kinact)/kon, Ki=koff/kon
370
371
372
373
374
375
376
377
378
379
380
381
382
383
384
385
386
387
388
389
390
391
392
393
Schaertl et al. have determined an IC50 value of 20 nM for Z006 together with various other
compounds by employing
a
fluorescence-based transamidase-detecting assay using
N,N-dimethylcasein as acyl donor and N-monodansylcadaverin as acyl acceptor substrate,
respectively [27]. In a later study, Nε-acryloyllysine-based irreversible inhibitor 5 has been
synthesised, which was investigated in the same assay [26]. The IC50 value of 5 was 14 nM under
these conditions, which suggests that it should be equipotent to Z006. However, the kinact/K value of
I
Z006 determined herein (191 000 M-1s-1) is 37-fold greater than that of 5. Even though the applied
assay methods detect different TGase 2-catalysed reactions (transamidation in Schaertl et al. vs.
hydrolysis herein) and the pH values are different (6.5 vs. 7.4), the potencies of Z006 and 5 should
not be influenced to such extent. In agreement with the value of kinact/K determined for Z006,
I
Khosla’s group reported inactivation constants of 48 000 M-1s-1 [29] and 139 000 M-1s-1 [30] for
structurally related peptidic diazomethyl ketones, which have been determined using the
GDH-coupled assay. The higher reactivity of Z006 towards TGase 2 in comparison to 5 is reasonable,
as diazomethyl ketones are inherently more reactive towards thiols than acrylamides. Moreover, as
the peptidic structures of Z006 and Z013 are based on gliadin peptides, which are natural substrates
of TGase 2, they can probably be better accommodated by the active site, which in turn results in
stronger non-covalent interactions. This is reflected in the low K value of 96 nM for Z006. The similar
i
IC50 values of Z006 and 5 and the drastically differing inactivation constants can be rationalised
when the assay conditions are considered. The IC50 values were determined using a TGase 2
concentration of 20 nM and a preincubation time of 30 min [27]. Therefore, the IC50 limit, which
corresponds to half of the employed active enzyme concentration ([E]
reached for both compounds. In this context, it should be pointed out that the IC50 value of an
irreversible inhibitor in general will always be equal to [E] /2, provided that [inhibitor] ≥ [enzyme]/2
T
/2) [31, 32], might have been
T

Wodtke et al.
11 of 17
394
395
396
397
398
399
400
401
and enough incubation time is given. The other investigated peptidic inhibitor Z013 exhibits a
of 51 500 M-1s-1, which is significantly more potent than 5. As for Z006, the higher inhibitory
k
inact/K
I
potency of Z013 can be attributed to the more reactive electrophilic warhead and the peptidic
structure, which corresponds to that of Z006, apart from one amino acid side chain. An IC50 value of
200 nM has been reported for Z013; however, no information on enzyme concentration and
preincubation time were provided [28]. Again, the comparison to the kinetic parameter kinact/K
I
indicates that IC50 values are not suitable for evaluating the potency of irreversible inhibitors, unless
identical conditions and carefully adjusted preincubation times are used [33].
402
403
Scheme 2: Synthesis of inhibitor 1-155
404
405
406
407
408
409
410
411
412
413
414
415
416
417
418
419
420
421
422
423
424
425
426
427
428
429
430
431
432
433
434
435
436
437
438
439
440
Reagents and conditions: a) PyBOP, DIPEA, DMF, 3 h; b) TFA/CH
2
Cl
2
(1:1, v/v), 2 h; c) TEA, CH
2
Cl , 2 h.
2
The synthesis of 1-155 (compound 7) started with the amide bond coupling between
Boc-Gly-OH and N-monodansylpiperazine to 6a using PyBOP and DIPEA, in difference to the
published procedure, which used EDC, HOBt and NMM as coupling reagents (Scheme 2) [21]. After
TFA-mediated Boc cleavage the acryloyl moiety was introduced by reacting 6b with
N-acryloxysuccinimide. The last step proceeded in low yield and should better be performed with
acryloyl chloride as acylating agent. A kinact/K
of 12 700 M-1s-1 was determined for 1-155. This value is
I
approximately 2.5-fold higher than both that for the Nε-acryloyllysine 5 and that of 1-155 determined
by Badarau et al. using the GDH-coupled assay. However, taking into account that the two assay
methods work at different pH values (6.5 vs. 7.2) the results can be considered comparable. The
higher efficiency of 1-155 compared to 5 as determined in the fluorimetric assay is remarkable. This
is probably the result of well-balanced conformational flexibility/rigidity and targeting of interaction
partners in the enzymes binding site for 1-155. Considering its smaller size (30 vs. 35 non-hydrogen
atoms), binding of 1-155 might be entropically more favoured than that of 5.
In addition to the kinetic characterisation of inhibitors, a further asset of the fluorogenic
substrate 4 is the convenient investigation of amine-based acyl acceptor substrates, which are
interesting for the development of TGase 2-directed imaging agents [34]. Moreover, their substrate
properties are of general interest. Therefore, we decided to determine exemplarily the kinetic
parameters of histamine, serotonin and dopamine as common biogenic amines of the primary
arylethylamine type. These compounds are known as classical neurotransmitters and the former two
are important mediators in non-neuronal cells and tissues as well. They have been known for 60
years to be substrates of TGase 2 [35]. However, the physiological significance of TGase-mediated
aminylation as an important post-translational modification has been recognised only in the recent
decades [36-39]. In particular, the TGase 2-catalysed serotonylation of small GTPases such as RhoA
and Rab4 in thrombocytes has been shown to be critical for blood haemostasis. Worth of note,
serotonylation of Gln63 in RhoA renders its GTPase activity permanently active [40]. A similar
mechanism has been identified for the constitutive activation of Rac1 in the central nervous system
[41, 42]. In particular, activation of the Gq/11-coupled 5-HT2A receptors in rat cortical cells raises the
cytosolic Ca2+ level, which in turn activates TGase 2 for catalysing the serotonylation of Rac1 [42].
Apart from small GTPases, other proteins have been identified as substrates for TGase 2–mediated
serotonylation [43] and, most recently, the transamidation of Gln5 of histone H3 to serotonin has
been discovered as a transcription-permissive modification [44]. Similar to serotonylation, TGase
2-mediated histaminylation leads to the constitutive activation of small and heterotrimeric G
proteins [45]. Histamine transfer to extracellular proteins such as fibrinogen has been suggested as a
mechanism for attenuating the pro-inflammatory effects of this endogenous mediator [46].
Furthermore, fibronectin, another extracellular TGase 2 substrate, has been shown to undergo

Wodtke et al.
12 of 17
441
442
443
monoaminylation, including dopaminylation [47, 48]. Despite this overwhelming body of evidence
for the biological relevance of TGase 2-catalysed protein acyl transfer to biogenic monoamines, exact
kinetic data on their substrate properties are scarce or have not been determined at all.
444
445
446
447
448
449
450
451
Figure 2. hTGase 2-catalysed incorporation of different biogenic amines into compound Z-Glu(HMC)-Gly-OH
(4). Plots of v0corr/[hTGase 2]=f([amine]) with nonlinear regressions (―) using Equation (3) (Michaelis-Menten
equation, Materials and Methods section). Data shown are mean values ±SEM of two separate experiments,
each performed in duplicate. When not apparent, error bars are smaller than the symbols. Conditions: pH=8.0
(100 mM MOPS was used, which ensures that the pH value is maintained over the entire range of amine
concentrations), 30 °C, 5% DMSO, 100 μM Z-Glu(HMC)-Gly-OH (4), 500 μM TCEP, 0.6, 2 and 3 μg/mL of
hTGase 2 for histamine, dopamine and serotonin, respectively.
452
Table 3. Kinetic parameters of different biogenic amines as acyl acceptors for hTGase 2 at pH=8.0
ꢔꢕꢕ
ꢗꢔꢘ
ꢒꢔꢓꢕꢕ (mM)
0.08 (0.01)
0.96 (0.06)
0.50 (0.17)
ꢖ
(s-1)
biogenic amine
histamine
kcat/Km (M-1s-1)
66,900
5.35 (0.58)
2.90 (0.04)
1.35 (0.04)
dopamine
3,000
serotonin
2,700
453
454
455
456
For details on calculation of the kinetic parameters see Experimental section. Data shown are mean values
(±SEM) of two separate experiments, each performed in duplicate. Active concentrations of hTGase 2
(ET=6.15 nM for histamine, 20.5 nM for dopamine and 30.8 nM for serotonin) were determined by active site
titration as recently described [24].
457
458
459
460
461
462
463
464
465
466
The results on the kinetic characterisation of histamine, serotonin and dopamine are shown in
Figure 2 and the calculated parameters are included in Table 3 (see also Figure S20 in Supporting
Information). The substrate concentration range and the employed enzyme concentration were
adjusted for each substrate in preliminary tests. Notably, no substrate inhibition occurred for any of
the amine substrates. The formation of the corresponding secondary amide products upon TGase
2-catalysed substrate conversion was confirmed by LC-MS/MS analysis (see Figures S21-S26 in
Supporting Information). In agreement with previously published data using the GDH-coupled
assay and the gluten-derived heptapeptide Ac-PQPQLPF-NH as acyl donor, histamine is a very
2
efficient acyl acceptor substrate for TGase 2 [49]. In contrast, the second-order performance constants
for both serotonin and dopamine are approximately 20-fold lower. In the GDH-assay mentioned

Wodtke et al.
13 of 17
467
468
469
470
471
472
473
474
475
476
477
478
479
480
481
482
483
484
485
486
487
488
489
490
491
492
493
494
495
496
497
498
499
500
501
before, which employs TGase 2 at a concentration as high as 50 μg/mL (640 nM), conversion of
serotonin was not detectable. This enzyme concentration is approximately 20-fold higher than that
applied herein for the analysis of serotonin. This demonstrates the value of activated fluorogenic
acyl donors such as compound 4 as even poor acyl acceptor substrates can be analysed and the
consumption of valuable enzyme material is minimised. According to its kcat/K , dopamine is a
m
slightly more efficient amine substrate for TGase 2 than serotonin, even though the apparent
Michaelis constant is lower for serotonin. Considering that all three studied biogenic amines share
the 2-aminoethyl chain and an (hetero)aromatic core, the distinct substrate properties of histamine
are remarkable. One could argue that its imidazole ring could assist in the deacylation step of the
catalytic cycle by acting as general base in the proton transfer from the amine nitrogen, as
intramolecular hydrogen bonds have been identified in both the neutral and side-chain protonated
form of histamine [50]. Thus, the imidazole ring of the substrate would fulfil the same function
during attack of the neutral amino group on the thioester intermediate as the imidazole of active-site
His335 [51]. However, its K
app of 80 μM, which is significantly lower than the corresponding values
m
for dopamine and serotonin, suggests specific interactions within the enzyme’s active site.
Furthermore, it is surprising that serotonin is the least efficient substrate of the investigated amines
even though the most findings on physiologically relevant protein monoaminylation have been
obtained for this biogenic amine [52]. In this context, it is worth to consider that beside availability of
the particular monoamine substrate, which can vary from cell type and depends on the subcellular
localisation, the sequence in which the Gln substrate residue is embedded should also influence the
substrate specificity towards the amine-based acyl acceptor substrate. This is evidenced by
investigations on the sequence dependence of TGase 2-catalysed modification of Hsp20, which
occurs at two of its five Gln residues, Gln31 and Gln66. Interestingly, concerning the differentiation
between the acyl acceptor the outcome is different for both residues as Gln31 is exclusively
transamidated whereas Gln66 is exclusively deamidated. However, when the isolated
undecapeptides of the sequences in which both residues are embedded are considered, Gln31 is not
converted at all whereas Gln66 undergoes both transamidation and deamidation [53]. This indicates
that the results on the substrate properties of the biogenic monoamines obtained with
Z-Glu(HMC)-Gly-OH (4) as acyl donor substrate should be extrapolated with care towards large
protein substrates. Therefore, we would like to define the elucidation of the molecular mechanisms
that lead to the coupling between acyl donor and acyl acceptor substrate specificity as a future
challenge for TGase research. In this context, the influence of the acceptor nucleophile on the
mechanism of the acylation step in TGase 2 catalysis has been established very recently on the basis
of 14N/15N kinetic isotope effects [54].
502
4. Conclusions
503
504
505
506
507
508
A reliable solution phase synthesis of the title substrate compound 4 has been established,
which will support its use in transglutaminase research. Its value for the evaluation of TGase 2
inhibitors based on meaningful kinetic parameters has been demonstrated. The compound’s utility
for the characterisation of amine substrates as exemplified by the biogenic amines histamine,
serotonin and dopamine has been shown, which allows for the first time their comparison on a
robust kinetic basis.
509
510
511
Supporting Information: Supplementary data associated with this article (chromatograms for synthesis, NMR
spectra for compounds 1-4, kinetic data, identification of reaction products for biogenic amines) can be found in
the online version at doi:
512
513
514
515
Acknowledgments: We highly appreciate the skilful assistance of Ms. Peggy Nehring and Mr. Kay Fischer in
substrate synthesis and that of Mr. David Bauer in that of inhibitor 1-155. Dr. Markus Laube and Ms. Karin
Landrock are kindly acknowledged for the measurement of HR-MS spectra and elemental microanalyses,
respectively.
516

Wodtke et al.
14 of 17
517
References
518
519
[1] N. Agnihotri, K. Mehta, Transglutaminase-2: Evolution from pedestrian protein to a promising therapeutic
target, Amino Acids, 49 (2017) 425-439.
520
521
522
523
524
525
526
527
528
529
530
531
532
533
534
535
536
537
538
539
540
541
542
543
544
545
546
547
548
549
550
551
552
553
554
555
556
557
558
[2] R.L. Eckert, Transglutaminase 2 takes center stage as a cancer cell survival factor and therapy target, Mol.
Carcinog., 58 (2019) 837-853.
[3] J.E. Folk, J.S. Finlayson, The ε-(γ-glutamyl)lysine crosslink and the catalytic role of transglutaminases, Adv.
Protein Chem., 31 (1977) 1-133.
[4] R. van Geel, M.F. Debets, D.W. Lowik, G.J. Pruijn, W.C. Boelens, Detection of transglutaminase activity
using click chemistry, Amino Acids, 43 (2012) 1251-1263.
[5] S. Hauser, R. Wodtke, C. Tondera, J. Wodtke, A.T. Neffe, J. Hampe, A. Lendlein, R. Löser, J. Pietzsch,
Characterization of tissue transglutaminase as a potential biomarker for tissue response toward biomaterials,
ACS Biomater. Sci. Eng., 5 (2019) 5979-5989.
[6] K. Jambrovics, I.P. Uray, Z. Keresztessy, J.W. Keillor, L. Fesus, Z. Balajthy, Transglutaminase 2 programs
differentiating acute promyelocytic leukemia cells in all-trans retinoic acid treatment to inflammatory stage
through NF-κB activation, Haematologica, 104 (2019) 505-515.
[7] M.S. Pavlyukov, N.V. Antipova, M.V. Balashova, M.I. Shakhparonov, Detection of transglutaminase 2
conformational changes in living cell, Biochem. Biophys. Res. Commun., 421 (2012) 773-779.
[8] N.S. Caron, L.N. Munsie, J.W. Keillor, R. Truant, Using FLIM-FRET to measure conformational changes of
transglutaminase type 2 in live cells, PLoS One, 7 (2012) e44159.
[9] S. Liu, R.A. Cerione, J. Clardy, Structural basis for the guanine nucleotide-binding activity of tissue
transglutaminase and its regulation of transamidation activity, Proc. Natl. Acad. Sci. USA, 99 (2002) 2743–2747.
[10] W.P. Katt, M.A. Antonyak, R.A. Cerione, Opening up about tissue transglutaminase: When conformation
matters more than enzymatic activity, Med One, 3 (2018).
[11] A. Case, R.L. Stein, Kinetic analysis of the interaction of tissue transglutaminase with a nonpeptidic
slow-binding inhibitor, Biochemistry, 46 (2007) 1106-1115.
[12] K. Thangaraju, B. Biri, G. Schlosser, B. Kiss, L. Nyitray, L. Fesus, R. Kiraly, Real-time kinetic method to
monitor isopeptidase activity of transglutaminase 2 on protein substrate, Anal. Biochem., 505 (2016) 36-42.
[13] M. Pietsch, R. Wodtke, J. Pietzsch, R. Löser, Tissue transglutaminase: An emerging target for therapy and
imaging, Bioorg. Med. Chem. Lett., 23 (2013) 6528-6543.
[14] R. Wodtke, G. Schramm, J. Pietzsch, M. Pietsch, R. Löser, Synthesis and kinetic characterisation of
water-soluble fluorogenic acyl donors for transglutaminase 2, ChemBioChem, 17 (2016) 1263-1281.
[15] R. Wodtke, C. Hauser, G. Ruiz-Gómez, E. Jäckel, D. Bauer, M. Lohse, A. Wong, J. Pufe, F.-A. Ludwig, S.
Fischer, S. Hauser, D. Greif, M.T. Pisabarro, J. Pietzsch, M. Pietsch, R. Löser, Nε-Acryloyllysine piperazides as
irreversible inhibitors of transglutaminase 2: Synthesis, structure–activity relationships, and pharmacokinetic
profiling, J. Med. Chem., 61 (2018) 4528-4560.
[16] S.I. Chung, R.I. Shrager, J.E. Folk, Mechanism of action of guinea pig liver transglutaminase. VII. Chemical
and stereochemical aspects of substrate binding and catalysis, J. Biol. Chem., 245 (1970) 6424-6435.
[17] A. Leblanc, C. Gravel, J. Labelle, J.W. Keillor, Kinetic studies of guinea pig liver transglutaminase reveal a
general-base-catalyzed deacylation mechanism, Biochemistry, 40 (2001) 8335-8342.
[18] N.J. Manesis, M. Goodman, Synthesis of a novel class of peptides: Dilactam-bridged tetrapeptides, J. Org.
Chem., 52 (1987) 5331-5341.

Wodtke et al.
[19] D.S.
15 of 17
2006.
559
560
561
562
563
564
565
566
567
568
569
570
571
572
573
574
575
576
577
578
579
580
581
582
583
584
585
586
587
588
589
590
591
592
593
594
595
596
597
598
599
600
Pedersen,
Let's
talk
about
TLCs.
Part
2
-
hanessian's
stain,
http://curlyarrow.blogspot.com/2006/11/lets-talk-about-tlcs-part-2-hanessians.html; accessed on 10/12/2019.
[20] E. Klieger, E. Schröder, Synthese von α-Glutamyl-Peptiden
Carbobenzoxy-L-glutaminsäure-α-phenylester, Liebigs Ann. Chem., 661 (1963) 193-201.
mit
[21] E. Badarau, Z. Wang, D.L. Rathbone, A. Costanzi, T. Thibault, C.E. Murdoch, S. El Alaoui, M. Bartkeviciute,
M. Griffin, Development of potent and selective tissue transglutaminase inhibitors: Their effect on TG2 function
and application in pathological conditions, Chem. Biol., 22 (2015) 1347-1361.
[22] M. Bergmann, L. Zervas, Über ein allgemeines Verfahren der Peptid-Synthese, Ber. Dtsch. Chem. Ges., 65
(1932) 1192-1201.
[23] J.D. Twibanire, T.B. Grindley, Efficient and controllably selective preparation of esters using
uronium-based coupling agents, Org. Lett., 13 (2011) 2988-2991.
[24] C. Hauser, R. Wodtke, R. Löser, M. Pietsch, A fluorescence anisotropy-based assay for determining the
activity of tissue transglutaminase, Amino Acids, 49 (2017) 567-583.
[25] M. Griffin, D. Rathbone, B.L. Eduard, Acylpiperazines as inhibitors of transglutaminase and their use in
medicine. WIPO Patent WO 2014/057266 A1, April 17, 2014.
[26] J. Wityak, M.E. Prime, F.A. Brookfield, S.M. Courtney, S. Erfan, S. Johnsen, P.D. Johnson, M. Li, R.W.
Marston, L. Reed, D. Vaidya, S. Schaertl, A. Pedret-Dunn, M. Beconi, D. Macdonald, I. Muñoz-Sanjuan, C.
Dominguez, SAR development of lysine-based irreversible inhibitors of transglutaminase 2 for huntington's
disease, ACS Med. Chem. Lett., 3 (2012) 1024-1028.
[27] S. Schaertl, M. Prime, J. Wityak, C. Dominguez, I. Muñoz-Sanjuan, R.E. Pacifici, S. Courtney, A. Scheel, D.
Macdonald, A profiling platform for the characterization of transglutaminase 2 (TG2) inhibitors, J. Biomol.
Screen., 15 (2010) 478-487.
[28]
Zedira
-
Z-MA-QPL-OMe,
https://zedira.com/Mechanism-of-TG-inhibitors/Michael-acceptor-peptidomimetics/Z-MA-QPL-OMe_Z013;
accessed on 10/12/2019.
[29] F. Hausch, T. Halttunen, M. Mäki, C. Khosla, Design, synthesis, and evaluation of gluten peptide analogs as
selective inhibitors of human tissue transglutaminase, Chem. Biol., 10 (2003) 225-231.
[30] D.M. Pinkas, P. Strop, A.T. Brunger, C. Khosla, Transglutaminase 2 undergoes a large conformational
change upon activation, PLoS Biol., 5 (2007) e327.
[31] J.W. Williams, J.F. Morrison, The kinetics of reversible tight-binding inhibition, Methods Enzymol., 63
(1979) 437-467.
[32] P.F. Cook, W.W. Cleland, Enzyme kinetics and mechanism, Garland Science Publishing, London, New
York, 2007, p. 203.
[33] R.A. Copeland, Evaluation of enzyme inhbitors in drug discovery, 2nd ed., John Wiley & Sons, Hoboken, NJ,
2013, p. 350.
[34] B. van der Wildt, A.A. Lammertsma, B. Drukarch, A.D. Windhorst, Strategies towards in vivo imaging of
active transglutaminase type 2 using positron emission tomography, Amino Acids, 49 (2017) 585-595.
[35] D.D. Clarke, M.J. Mycek, A. Neidle, H. Waelsch, The incorporation of amines into protein, Arch. Biochem.
Biophys., 79 (1959) 338-354.
[36] D.J. Walther, S. Stahlberg, J. Vowinckel, Novel roles for biogenic monoamines: From monoamines in
transglutaminase-mediated post-translational protein modification to monoaminylation deregulation diseases,
FEBS J., 278 (2011) 4740-4755.

Wodtke et al.
16 of 17
601
602
603
604
605
606
607
608
609
610
611
612
613
614
615
616
617
618
619
620
621
622
623
624
625
626
627
628
629
630
631
632
633
634
635
636
637
638
639
640
641
642
[37] N.A. Muma, Z. Mi, Serotonylation and transamidation of other monoamines, ACS Chem. Neurosci., 6
(2015) 961-969.
[38] T.S. Lai, C.J. Lin, C.S. Greenberg, Role of tissue transglutaminase-2 (TG2)-mediated aminylation in
biological processes, Amino Acids, 49 (2017) 501-515.
[39] N.A. Muma, Transglutaminase in receptor and neurotransmitter-regulated functions, Med One, 3 (2018).
[40] D.J. Walther, J.-U. Peter, S. Winter, M. Höltje, N. Paulmann, M. Grohmann, J. Vowinckel, V.
Alamo-Bethencourt, C.S. Wilhelm, G. Ahnert-Hilger, M. Bader, Serotonylation of small GTPases is a signal
transduction pathway that triggers platelet α-granule release, Cell, 115 (2003) 851-862.
[41] Y. Dai, N.L. Dudek, T.B. Patel, N.A. Muma, Transglutaminase-catalyzed transamidation: A novel
mechanism for Rac1 activation by 5-HT2a receptor stimulation, J. Pharmacol. Exp Ther., 326 (2008) 153-162.
[42] Y. Dai, N.L. Dudek, Q. Li, N.A. Muma, Phospholipase C, Ca2+, and calmodulin signaling are required for
5-HT2a receptor-mediated transamidation of Rac1 by transglutaminase, Psychopharmacology (Berlin), 213
(2011) 403-412.
[43] J.C. Lin, C.C. Chou, Z. Tu, L.F. Yeh, S.C. Wu, K.H. Khoo, C.H. Lin, Characterization of protein
serotonylation via bioorthogonal labeling and enrichment, J. Proteome Res., 13 (2014) 3523-3529.
[44] L.A. Farrelly, R.E. Thompson, S. Zhao, A.E. Lepack, Y. Lyu, N.V. Bhanu, B. Zhang, Y.E. Loh, A.
Ramakrishnan, K.C. Vadodaria, K.J. Heard, G. Erikson, T. Nakadai, R.M. Bastle, B.J. Lukasak, H. Zebroski, 3rd,
N. Alenina, M. Bader, O. Berton, R.G. Roeder, H. Molina, F.H. Gage, L. Shen, B.A. Garcia, H. Li, T.W. Muir, I.
Maze, Histone serotonylation is a permissive modification that enhances TFIID binding to H3K4me3, Nature,
567 (2019) 535-539.
[45] J. Vowinckel, S. Stahlberg, N. Paulmann, K. Bluemlein, M. Grohmann, M. Ralser, D.J. Walther,
Histaminylation of glutamine residues is a novel posttranslational modification implicated in G-protein
signaling, FEBS Lett., 586 (2012) 3819-3824.
[46] T.S. Lai, C.S. Greenberg, Histaminylation of fibrinogen by tissue transglutaminase-2 (TGM-2): Potential role
in modulating inflammation, Amino Acids, 45 (2013) 857-864.
[47] R. Hummerich, J.O. Thumfart, P. Findeisen, D. Bartsch, P. Schloss, Transglutaminase-mediated
transamidation of serotonin, dopamine and noradrenaline to fibronectin: Evidence for a general mechanism of
monoaminylation, FEBS Lett., 586 (2012) 3421-3428.
[48] R. Hummerich, V. Costina, P. Findeisen, P. Schloss, Monoaminylation of fibrinogen and glia-derived
proteins: Indication for similar mechanisms in posttranslational protein modification in blood and brain, ACS
Chem. Neurosci., 6 (2015) 1130-1136.
[49] S.W. Qiao, J. Piper, G. Haraldsen, I. Oynebraten, B. Fleckenstein, O. Molberg, C. Khosla, L.M. Sollid, Tissue
transglutaminase-mediated formation and cleavage of histamine-gliadin complexes: Biological effects and
implications for celiac disease, J. Immunol., 174 (2005) 1657-1663.
[50] P.I. Nagy, Competing intramolecular vs. Intermolecular hydrogen bonds in solution, Int. J. Mol. Sci., 15
(2014) 19562-19633.
[51] J.W. Keillor, C.M. Clouthier, K.Y. Apperley, A. Akbar, A. Mulani, Acyl transfer mechanisms of tissue
transglutaminase, Bioorg. Chem., 57 (2014) 186-197.
[52] M. Bader, Serotonylation: Serotonin signaling and epigenetics, Front. Mol. Neurosci., 12 (2019) 288.
[53] J. Stamnaes, B. Fleckenstein, L.M. Sollid, The propensity for deamidation and transamidation of peptides
by transglutaminase 2 is dependent on substrate affinity and reaction conditions, Biochim. Biophys. Acta, 1784
(2008) 1804-1811.

Wodtke et al.
17 of 17
643
644
645
646
[54] E.A. Wells, M.A. Anderson, T.N. Zeczycki, (15)(V/K) kinetic isotope effect and steady-state kinetic analysis
for the transglutaminase 2 catalyzed deamidation and transamidation reactions, Arch. Biochem. Biophys., 643
(2018) 57-61.

Highlights
•
Reliable and scalable solution-phase synthesis of the fluorogenic acyl donor substrate Z-
Glu(HMC)-Gly-OH was established
•
•
Substrate properties towards TGase 2-catalysed hydrolysis were confirmed
Suitability of the substrate for the kinetic characterization of irreversible inhibitors that were
recently reported in the literature is demonstrated
•
Kinetic investigation of histamine, serotonin and dopamine as acyl acceptors using Z-
Glu(HMC)-Gly-OH allows for the first time the comparison of their substrate properties
towards TGase 2
