New phenylfluorenyl based linkers for solid phase synthesis
Konrad H. Bleicher,* Christian Lutz and Yves Wu¨thrich
F. Hoffmann-La Roche AG, Pharma Research, CH-4070 Basel, Switzerland
Received 30 August 2000; accepted 21 September 2000
Abstract
The synthesis of 9-(4-hydroxyphenyl)-9-H-fluoren-9-ol and 5-(4-(9-hydroxy-9H-fluoren-9-yl)-phenoxy)-
pentanoic acid and their applications as new linkers for solid phase synthesis is reported. These supports
show higher acid stability compared to standard trityl resins. Carboxylic acids and amines are immobi-
lized and cleaved off after further modifications. TFA treatment releases the products in high yield and
excellent purity. © 2000 Elsevier Science Ltd. All rights reserved.
Keywords: linkers; solid phase synthesis; peptide synthesis; inverse peptide synthesis; 2-aminothiazoles.
Solid phase organic synthesis (SPOS) has become a useful tool for the generation of diverse
compound libraries in the drug discovery and lead optimization process.1 In recent publications
an increasing number of solution phase methodologies were transferred successfully to solid
phase synthesis.2 One of the key issues in SPOS is to find a proper linker system for the
attachment of the first building block to the solid support. Trityl resins were described for the
immobilization of various nucleophiles like carboxylic acids,3 alcohols4 and amines.5 The
convenient loading of amino acids and the mild cleaving conditions make these resins very
attractive for the syntheses of peptides and protected peptide fragments.3,6 For solid phase
synthesis of small molecules the acid sensitivity of trityl resins often turns out to be a drawback,
therefore they can only be used for a limited range of reactions. The 9-phenylfluoren-9-yl group
(PhFl) has been described for the protection of primary and secondary amines7 as a more acid
stable alternative to the trityl group. This protecting group shows a 6000 times higher stability
than trityl due to the antiaromatic character of the fluorenyl cation produced upon acidic
treatment.8 We have investigated the phenylfluorenyl protecting strategy as a linkage approach
in SPOS for several nucleophiles as disclosed in earlier publications.9 Henkel et al. describe an
analogous approach for the immobilization of amino acids10 and recently a publication
appeared using the PhFl linker concept for soluble polymer supported chemistry.11
* Corresponding author.
0040-4039/00/$ - see front matter © 2000 Elsevier Science Ltd. All rights reserved.
PII: S0040-4039(00)01654-3

9038
Herein we wish to report new phenylfluorenyl based linkers as interesting alternatives to the
trityl- and PhFl-modified resins published so far. The syntheses of two derivatives are described
that can be used for the modification of either chloromethyl polystyrene or any aminomethyl
modified resins12 (Scheme 1).
Scheme 1. (i) n-BuLi, THF −78°C; (ii) 9-fluorenone −78°C to rt; (iii) NH4Cl sat.; (iv) For R=TIPS: TBAF (1M) in
