Heterocyclic o-aminonitriles: Preparation of pyrazolo[3,4-d]-pyrimidines with modification of the substituents at the 1-position

Article abstract of DOI:10.3390/60700621

Novel 1-[6-(p-tolyl) pyridazin-3-yl]pyrazole-o-aminonitriles (3a-c) were formed using 3-hydrazino-6-(p-tolyl)pyridazine (2) and ketene S,S-acetals (1a), S,N-acetals (1b) or tetracyanoethylene (1c). The pyrazole-o-aminonitriles (3a-c) were in turn used as precursors for the preparation of previously unreported 1-[6-(p-tolyl)-pyridazin-3-yl]pyrazolo[3,4-d]pyrimidines (8, 9, 13-20) and 7-[6-(p-tolyl) pyridazin-3-yl]2-arylpyrazolo[3,4-d]1,2,4-triazolo[5,1-f] pyrimidines (10-12) which are expected to possess considerable chemical and pharmacological activities.

Full text of DOI:10.3390/60700621

Molecules 2001, 6, 621-638
molecules
ISSN 1420-3049
http://www.mdpi.org
Heterocyclic o-Aminonitriles: Preparation of Pyrazolo[3,4-d]-
pyrimidines with Modification of the Substituents at the 1-
Position
Eljazi I. Al-Afaleq* and Samar A. Abubshait
Chemistry Department, Faculty of Science-Girls College 838, Dammam 31113, Saudi Arabia. Tel.
(+966)-3-8647651, Fax (+966)-3-8951780.
*Author to whom correspondence should be addressed; e-mail: eljazii@yahoo.com
Received: 19 February 2001; in revised form 4 June 2001 / Accepted: 7 June 2001/ Published: 30
June 2001
Abstract: Novel 1-[6-(p-tolyl) pyridazin-3-yl]pyrazole-o-aminonitriles (3a-c) were
formed using 3-hydrazino-6-(p-tolyl)pyridazine (2) and ketene S,S-acetals (1a), S,N-
acetals (1b) or tetracyanoethylene (1c). The pyrazole-o-aminonitriles (3a-c) were in
turn used as precursors for the preparation of previously unreported 1-[6-(p-tolyl)-
pyridazin-3-yl]pyrazolo[3,4-d]pyrimidines (8, 9, 13-20) and 7-[6-( p-tolyl) pyridazin-
3-yl]2-arylpyrazolo[3,4-d]1,2,4-triazolo[5,1-f]pyrimidines (10-12) which are expected
to possess considerable chemical and pharmacological activities.
Keywords: ο-Aminonitriles; ketene acetals; pyrazolopyrimidines.
Introduction
Pyrazolo[3,4-d]pyrimidines are of considerable chemical and pharmacological importance as
purine analogs [1-3]. Various compounds with related structures also possess anti-tumor and anti-
leukemia activities [4,5]. On the other hand, substituted pyridazines are often used in medicine
thanks to their pronounced bactericidal and fungicidal effects [6]. As a continuation of our work on
azoloazines [7], we aimed to incorporate the pyridazine moiety into the 1-position of the

Molecules 2001, 6
622
pyrazolo[3,4-d]pyrimidine ring system to thus obtain a new heterocyclic system which is expected
to possess notable chemical and pharmacological activities.
Results and Discussion
The key pyrazole-o-aminonitrile precursors (3a-c) were prepared by the reaction of 3-hydrazino-
6-(p-tolyl)pyridazine (2) [8] with ketene S,S- and S,N-acetals (1a,b) which were prepared using
Phase Transfer Catalysis (PTC) [9], or tetracyanoethylene (1c).
CN
R
N
NH2
R
CN
CN
Ar
N
N
N
NHNH 2
Me
+
(4)
R1
CN
R
(1)
(2)
N
N
C4'
C3
C4
N
NH2
C1'
C6
Ar = Me
a: R = R1 = SMe
N
b: R = NHPh, R1 = SMe
c: R = R1 = CN
C3'
H3'
C2'
H2'
C5
H5
Ar
H4
(3)
Scheme 1
The reaction sequence shown in Scheme 1 yielded only one product (3) instead of a mixture of
the two possible isomeric pyrazole-o-aminonitriles 3 and 4. This fact was confirmed by the several
strategies. First, by using the technique of Hecht et al. [10], who found it was possible to
differentiate between the isomeric pyrazoles 5 and 6 based on their different reactivity; thus,
treatment of 6 with acetic anhydride in pyridine at room temperature afforded the corresponding N-
acetyl derivative, but pyrazole 5 did not form the corresponding derivative under the same
conditions, although it did form at 50-60oC (Scheme 2).
NC
CN
(27%)
N
NH2
N
CH3
(5)
CN
CN
NC
NC
CH3NHNH2
+
NC
CN
(53%)
N
NH2
H3C
N
(6)
Scheme 2

Molecules 2001, 6
623
By analogy with the results of Hecht et al, when our product was treated with acetic anhydride,
it formed the corresponding acetyl derivative only at higher temperatures and not at room
temperature, due to the electronic and steric factors of the substituents (Ar and CN). Secondly,
only one spot was obtained in TLC. Third, the structure of the product was identified as that of 3 on
the basis of the X-ray crystal structure analysis, which confirmed the substituted nitrogen of the
pyrazole ring is adjacent to the amino group (Figure 1). Finally, the structural assignment of 3 was
also based on spectral evidence (IR, 1H-NMR, 13C-NMR and Mass spectrometry, while COSY- 2D
experiments indicated the (C-H) and (H-H) correlations).
Fig. 1 Single-crystal X-ray analysis. ORTEP view of 3a
showing the atom numbering scheme,
The above mentioned pyrazoles were used as intermediates for the synthesis of new
pyrazolo[3,4-d]pyrimidines because they contain the ß-enaminonitrile moiety which is well known
to be highly reactive. Thus, condensation of 3a-c with triethylorthoformate in refluxing acetic
anhydride afforded the intermediate ethoxymethyleneamino derivatives (7a-c) (Scheme 3), which
were isolated and used without purification in the next step. Treatment of 7a-c with cold aqueous
alcoholic ammonia yielded 4-aminopyrazolo[3,4-d]pyrimidines (8a-c). The IR spectrum of 8a,b
displayed no absorption for the cyano group. We also attempted a direct synthesis of compounds
8a-c by treating pyrazoles 3a-c with formamide. When cooled compounds 7a-c were stirred with
hydrazine hydrate in ethanol and then warmed to room temperature for 6h, they yielded 5-amino-4-
iminopyrazolo[3,4-d]-pyrimidines (9a-c) in good yield. The proposed structures for the products
9a-c were supported by their elemental analysis and spectral data (see Experimental).
The imidates 7a-c gave 2-arylpyrazolo[3,4-d]-1,2,4-triazolo[5,1-f] pyrimidine systems (10-12)
when reacted with 2-furancarboxylic acid hydrazide, 2-thiophenecarboxylic acid hydrazide and 4-
pyridinecarboxylic acid hydrazide, respectively. The structures of the reaction products were
assigned based on correct elemental analysis and spectral data (for example, the IR spectrum shows
the absence of nitrile and amino bands, while the 1H-NMR spectrum shows the signals of hydrogen
atoms respectively characteristic of the aryl moiety in 2-position).

Molecules 2001, 6
624
O
N
R
N
H
N
N
S
NH2
Ar
R
N
H
R
N
(13)
N
N
S
N
N
H
(14)
X
N
N
HCOOH
CN
Ar
H
X=C(NH2)2
Ar
R
CS2
(18-20)
a: R= SMe
b: R= NHPh
c: R=CN
a
b
c
N
NH2
N
R
X
O
R
X
S
R
X
18: SMe
SMe
SMe NH
Ar
19: NHPh O NHPh S NHPh NH
20: CN
O
CN
NH
S
CN
NH
PhNCX
(3)
HCONH2
R
NH2
N
HC(OEt)3
CN
R
N
Ph
N
N
R
OEt
CH
N
N
NH4OH
X
N
H
N
N
N
Ar
Ar (8)
N
(15-17)
Ar
a
b
a: R= SMe
R
X
R
X
(7)
b: R= NHPh
c: R=CN
SMe
O
SMe
S
15:
16: NHPh O NHPh
S
NH
17: CN
O
CN
N
S
a: R= SMe
b: R= NHPh
c: R=CN
R
2
R
NH2
N
2
R CONHNH2
NH2NH2
N
N
N
N
R
N
Ar =Me
N
N
Ar
N
(9)
N
N
a: R= SMe
Ar
b: R= NHPh
c: R=CN
(10-12)
a
b
c
2
2
2
R
R
R
R
R
R
10: SMe furyl SMe thienyl SMe 4-pyridinyl
11: NHPh furyl NHPh thienyl NHPh 4-pyridinyl
12 :CN
furyl CN
thienyl CN 4-pyridinyl
Scheme 3
The pyrazole derivatives 3a-c undergo cyclization to afford several other new pyrazolo [3,4-d]
pyrimidines (13-20) when reacted with formic acid, carbon disulfide, phenylisocyanate,
phenylisothiocyanate, urea, thiourea and guanidine respectively. The structures of the synthesized
compounds were established by elemental analysis and spectral data. (see Experimental).

Molecules 2001, 6
625
Conclusions
We have presented various methods for synthesis of novel pyrazolo[3,4-d]pyrimidines with a
pyridazine moiety at the1-position.
Acknowledgments
The authors thank Dr. M. Fettouhi, King Fahad University of Petroleum and Minerals, for his
efforts in facilitating the analysis of the X-ray analysis and the laboratory of Dr. Lahcene Ouahab,
LCISM, UMR 6511, Rennes l University, France, for providing the X-ray structure analysis. The
author extend their gratitude to the General Presidency for Girls Education for their partial financial
support of this study.
Experimental
General
Melting points were determined on a Reichert hot stage microscope and are uncorrected. IR
spectra were measured with a Nicolet Magna 520 instrument, using potassium bromide and results
1
are given in cm-1. H-, 13C NMR and 2D H-H, C-H, Cosy NMR spectra were recorded in DMSO-
d6 on either a JEOL JNM-GX270, (1H-NMR at 270 MHz), (13C-NMR at 52.89MHz) or a Varian
Gemini (1H-NMR at 200 MHz), (13C-NMR at 90.56 MHz ) spectrometer. The chemical shifts are
reported in part per million (ppm) downfield from internal tetramethylsilane. Electron impact MS
spectra were obtained on a JEOL JMS-HX 100 at 70 eV. Elemental microanalysis were done on a
CARLO Erba analyzer model 110. The progress of all reactions was monitored by TLC on 2.0 cm
x 6.0 cm aluminium sheets precoated with silica gel 60 containing a fluorescent indicator (Alugram
SIL G/UV254 fur die DC Macherey-Nagel/ Germany), to a thickness of 0.25 mm. The developed
chromatograms were viewed under ultraviolet light. Column chromatography was performed on
[Merck] silica gel (70-230 mesh) (elution with 1:1 cyclohexane-ethyl acetate). The X-ray structure
was determined using a NONIUS Kappa Diffractomer. Suitable crystals were grown by slow
crystallization from ethanol.
General Procedure for the Preparation of 5-Amino-3-substituted-1-[6-(p-tolyl) pyridazin-3-yl]-
pyrazole-4-carbonitriles (3a-c).
To a cold solution of hydrazine 2 (2.0g , 10 mmol) in methanol (100 mL) was added 1 (10 mmol).
The reaction mixtures were then stirred at room temperature for 3-6h, left overnight, then the
solvent was evaporated and the residue recrystallized from a suitable solvent.

Molecules 2001, 6
626
5-Amino-3-methylthio-1-[6-(p-tolyl)pyridazin-3-yl]-pyrazole-4-carbonitrile (3a).
o
Yield: 89 %; colorless needle-like crystals; mp 259-260 C (from EtOH); IR: ν max cm-1 3379,
1
3279 (NH2); 2210 (CN); H-NMR: δ: 2.41 (s, 3H, CH3-S), 2.60 (s, 3H, p-CH3-tolyl), 7.02 (bs, 2H,
NH2, D2O exchangeable), 7.31 (d, 2H, H3, H5 – tolyl, J = 8.0 Hz), 7.90 (d, 2H, H2, H6- tolyl, J =
8.0 Hz), 8.13 (d, 1H, H5-pyridazine, J = 9.1 Hz), 8.36 (d, 1H, H4-pyridazine, J = 9.1 Hz); 13C-
NMR: δ 15 (CH3-S), 20 (p-CH3-tolyl), 79 (CN), 134 (C-CN), 140 (C-SCH3), 113, 127, 129, 153
(C4,C3,C2 and C1 of tolyl); 118, 126, 154, 156 (pyridazine C5, C4, C6 and C3); 157 (C-NH2); MS
m/z (%): M+ 322 (100), 275 (77), 250 (69), 115 (54), 78 (7.7); Anal. Calc. for C16H14N6S (322.39):
C 59.61, H 4.38, N 26.07, S 9.94; Found: C 59.25, H 4.26, N 26.10, S 9.95.
Single-Crystal X-ray Structure Analysis of 3a: Crystallographic Data and Refinement.
Crystal Orthorhombic, space group P212121, a= 4.97330(10)Å, b= 11.1882(3)Å, c= 28.0997(8) Å.
CELL 4.97330 11.18820 28.09970 90.0000 90.0000 90.0000.
ZERR 4 0.00010 0.00029 0.00080 0.000 0.000 0.000.
LATT –1.
SYMM 0.5-X, -Y, 0.5+Z. SYMM 0.5+X, 0.5-Y, -Z. SYMM –X, 0.5+Y, 0.5-Z.
Volume 1563.53(7) Å3 .
Z, calculated density 4, 1.370 /m3.
Absorption coefficient 0.215 mm-1.
F(000) 672.
Theta range for data collection 1.96 to 27.49 deg.
Limiting indices –6<=h<=6, -14<=k<=14, -35<=1<=35.
Reflections collected/unique 3468/3468 [R(int) = 0.0000].
Refinement method full-matrix least-squares on F2.
Goodness-of-fit on F2 0.978.
Final R indices [I>2sigma(I)] R1 = 0.0498, wR2 = 0.1134.
R indices (all data) R1 = 0.1182, wR2 = 0.1374.
5-Amino-3-N-phenylamino-1-[6-(p-tolyl)pyridazin-3-yl]-pyrazole-4-carbonitrile (3b).
o
Yield: 70 %; white solid, mp 297 C (from EtOH); IR: ν max cm-1 3461-3311 (NH2/NH); 2213
1
(CN); H-NMR δ: 2.45 (s, 3H, p-CH3-tolyl), 6.82 (bs, 2H, NH2, D2O exchangeable), 7.18 (t, 1H,
H4-Ph, J = 7.4 Hz), 7.34 (t, 2H, H3, H5-Ph, J = 7.6 Hz), 8.21 (d, 2H, H2, H6-Ph, J = 7.9 Hz), 7.61
(d, 2H, H3, H5- tolyl, J = 8.0 Hz), 8.04 (d, 2H, H2, H6-tolyl, J = 8.0 Hz), 8.26 (d, 1H, H5–
pyridazine, J = 9.1 Hz ), 8.42 (d, 1H, H4-pyridazine, J = 9.1 Hz), 9.22 (bs, 1H, NH, D2O
exchangeable); MS: m/z (%); M+ 367 (75), 270 (100 ), 115 (42), 78 (8.1); Anal. Calc. for C21H17N7
(367.41): C 68.65, H 4.66, N 26.69; Found: C 68.49, H 4.68, N 26.70.

Molecules 2001, 6
627
5-Amino-1-[6-(p-tolyl)pyridazin-3-yl]-pyrazole-3,4-dicarbonitrile (3c).
Yield: 86 %; pale brown solid; mp 289-292oC (from n-BuOH); IR: ν max cm-1 3369, 3282 (NH2);
1
2239, 3231(2CN); H-NMR δ: 2.43 (s, 3H, p-CH3-tolyl), 7.42 (d, 2H, H3, H5-tolyl, J = 8.0 Hz),
8.04 (d, 2H, H2, H6-tolyl, J = 8.0 Hz), 8.17 (d, 2H, H5-pyridazine, J = 9.1 Hz), 8.51 (d, 2H, H4-
pyridazine, J = 9.1 Hz), 8.61 (bs, 2H, NH2, D2O exchangeable); MS: m/z (%); M+ 301(88), 275
(100 ), 78 (52), 65 (65); Anal. Calc. for C16 H11N7 (301.31): C 63.78, H 3.68, N 32.54; Found: C
64.02, H 3.68, N 32.39.
General Procedure for Preparation of 5-Methoxymethyleneamino-3-substituted-1-[6-(p-tolyl)-
pyridazin-3-yl]-pyrazole-4-carbonitrilse (7a-c).
A mixture of pyrazole-o-aminonitriles 3a-c (10 mmol), triethylorthoformate (3mL) and acetic
anhydride (3 mL) was refluxed for 6h. The solvent was removed under reduced pressure and the
resulting solid was recrystalized from ethanol.
5-Methoxymethyleneamino-3-methylthio-1-[6-(p-tolyl)pyridazin-3-yl]-pyrazole-4-carbonitrile (7a).
Yield: 75 %; white solid, mp 132 oC ; IR ν max cm-1: 3380 (NH), 2920, 2827 (CH), 2218 (CN).
5-Methoxymethyleneamino-3-N-phenylamino-1-[6-(p-tolyl)pyridazin-3-yl]-pyrazole-4-yl-
carbonitrile (7b).
Yield: 61 %; white solid, mp 230 oC; IR: ν max cm-1: 3326 (NH), 2917, 2849 (CH), 2225 (CN)
5-Methoxymethyleneamino-1-[6-(p-tolyl)pyridazin-3-yl]-pyrazole-3,4-yl-dicarbonitrile (7c).
Yield: 66% yield; white solid, mp 209-210 oC; IR ν max cm-1: 3416 (NH), 2933, 2860 (CH), 2229,
2225 (2CN).
General procedure for the Preparation of 3-Substituted-1-[6-(p-tolyl)pyridazin-3-yl]- pyrazolo[3,4-
d]pyrimidine-4-amines (8a-c).
Methanimidates 7a-c (3 mmol) were added to methanol (20 mL) saturated with ammonia at 0oC for
1h, warmed to room temperature and the reaction mixture stirred for 6h. The solid which
precipitated was collected and recrystallized from an appropriate solvent.
3-Methylthio-1-[6-(p-tolyl)pyridazin-3-yl]pyrazolo[3,4-d]pyrimidine-4-amine (8a).
Yield: 81 %; pale yellow solid, mp 275 oC (from n-BuOH); IR ν max cm-1: 3410, 3362 (NH2); 1H-
NMR δ: 2.46 (s, 3H, S-CH3), 2.60 (s, 3H, p-CH3-tolyl), 7.43 (d, 2H, H3,H5-tolyl, J = 8.0 Hz), 7.71

Molecules 2001, 6
628
(bs, 2H, NH2, D2O exchangeable), 8.00 (d, 2H, H2,H6-tolyl, J = 8.0 Hz), 8.20 (d, 2H, H5-
pyridazine, J = 9.1 Hz), 8.42 (d, 2H, H4-pyridazine, J = 9.1 Hz); 13C-NMR δ: 18 (S—CH3-tolyl), 20
(p-CH3-tolyl), 112, 118, 124, 128, 131, 133, 138, 151, 155, 156, 158, 159, 160 (aromatic); MS: m/z
(%); M+ 349(100), 334(27), 274(94), 244 (49). Anal. Calc. for C17 H15N7S (349.41); C 58.44, H
4.33, N 28.06, S 9.18; Found : C 58.29, H 4.34, N 27.98, S 9.20.
3-N-Phenylamino-1-[6-(p-tolyl)pyridazin-3-yl]pyrazolo[3,4-d]pyrimidine-4-amine (8b).
o
Yield 34 %; light brown solid, mp 285-287 C (from dioxane); IR ν max cm-1: 3370-3180
1
(NH2/NH); H-NMR δ: 2.52 (s, 3H, p-CH3-tolyl), 7.04 (t, 1H, H4-Ph, J = 7.4 Hz), 7.30 (t, 2H,
H3,H5- Ph, J = 7.6 Hz), 7.41 (d, 2H, H3,H5- tolyl, J = 8.0 Hz), 7.85 (bs, 2H, NH2, D2O
exchangeable), 7.90 (d, 2H, H2-Ph, H6-Ph, J = 7.9 Hz), 8.16 (d, 2H, H4. H6-tolyl, J = 8.0 Hz),
8.20 (d, 1H, H5-pyridazine, J = 9.1 Hz), 8.33 ( bs , 1H, NH, D2O exchangeable), 8.40 (d, 1H, H4-
pyridazine, J = 9.1Hz), 8.64 (s, 1H, pyrimidine); 13C-NMR δ: 20 (p-CH3-tolyl), 114, 121, 122, 123,
124, 128, 130, 131, 133, 135, 138, 151, 155, 156, 158, 159, 160 (aromatic); MS: m/z (%); M+
394(86), 378(52), 288(100), 244 (73), 77(15); Anal. Calc. for C22 H18N8 (394.44); C 66.99, H 4.60,
N 28.41; Found : C 67.05, H 4.60, N 28.39.
4-Amino-1-[6-(p-tolyl)pyridazin-3-yl]pyrazolo[3,4-d]pyrimidine-3-carbonitrile (8c).
o
Yield: 65 %; yellow crystals, mp >320 C (from EtOH); IR ν max cm-1: 3397, 3276 (NH2), 2240
(CN); 1H-NMR δ: 2.45 (s, 3H, p-CH3-tolyl), 7.40 (d, 2H, H3, H5- tolyl, J = 8.0 Hz), 7.93 (bs, 2H,
NH2, D2O exchangeable), 8.00 (d, 2H, , H2, H6-tolyl, J = 8.0 Hz), 8.12 (d, 1H, H5-pyridazine, J =
9.1 Hz), 8.51 (d, 1H, H4-pyridazine, J = 9.1Hz); MS m/z (%): M+ 328(95), 312(100), 302(44);
Anal. Calc. for C17 H12N8 (328.34); C 62.19, H 3.68, N 34.13; Found: C 62.16, H 3.71, N 34.18.
General Procedure for the Preparation of 4-imino-3-substituted-1-[6-(p-tolyl)pyridazin-3-yl]-4,5-
dihydropyrazolo[3,4-d]- pyrimidine-5-amines (9a-c).
To a well stirred cold solution of methanimidate 7a-c (20 mmol) in ethanol (10 mL), 99 %
hydrazine hydrate (3 mL) was added over 2h, then the mixture was stirred at room temperature for
6h and left overnight. The solid that precipitated was filtered off and purified by passage though a
column of silica gel with cyclohexane -ethyl acetate (1:1) as eluent.
4-Imino-3-methylthio-1-[6-(p-tolyl)pyridazin-3-yl]-4,5-dihydropyrazolo[3,4-d] pyrimidine-5-amine
(9a).
o
1
Yield: 96 %; white solid, mp 238 C; IR ν max cm-1: 3352-3204 (NH2/NH); H-NMR δ: 2.37 (s,
3H, S-CH3), 2.66 ( s, 3H, p-CH3-tolyl), 6.35 (bs, 2H, NH2, D2O exchangeable), 7.41 (d, 2H, H3,
H5-tolyl, J = 8.0 Hz), 8.06 (d, 2H, H3, H5- tolyl, J = 8.0 Hz), 8.22 (d, 1H, H5-pyridazine, J = 9.1
Hz), 8.30 (bs, 1H, NH, D2O exchangeable), 8.41 (d, 1H, , H4-pyridazine, J = 9.1Hz) , 8.54 (s, 1H,

Molecules 2001, 6
629
pyrimidine); MS: m/z (%); M+ 364(95), 348(100), 317(33), 301 (58); Anal. Calc. for C17 H16N8S
(364.43): C 56.03, H 4.43, N 30.75, S 8.80; Found: C 55.96, H 4.46, N 30.70, S 8.74.
4-Imino-3-N-phenylamino-1-[6-(p-tolyl)pyridazin-3-yl]-4,5-dihydropyrazolo[3,4-d]- pyrimidine-5-
amine (9b).
o
1
Yield: 70 %; yellow solid, mp 279-281 C; IRν max cm-1: 3458-3120, (NH2/2NH); H-NMR δ:
2.51 (s, 3H, p-CH3-tolyl), 6.91 (t, 1H, H4-Ph, J = 7.4 Hz), 7.23 (t, 2H, H3, H5-Ph, J = 7.6 Hz), 7.36
(d, 2H, H3, H5-tolyl, J = 8.0 Hz), 7.42 (bs, 2H, NH2, D2O exchangeable), 7.64 (d, 2H, H2, H6-Ph, J
= 7.9 Hz), 8.00 (d, 1H, H2, H6-tolyl, J = 8.0 Hz), 8.10 (d, 1H, , H5-pyridazine, J = 9.1 Hz), 8.41 (d,
1H, H4-pyridazine, J = 9.1Hz), 8.55 (s, 1H, pyrimidine), 9.03 (bs, 1H, NH, D2O exchangeable);
MS: m/z (%); M+ 409 (100), 394 (51), 288 (84). Anal. Calc. for C22 H19N9 (409.45): C 64.54, H
4.68, N 30.79; Found: C 64.18, H 4.67, N 31.01.
5-amino-4-imino-1-[6-(p-tolyl)pyridazin-3-yl]-4,5-dihydropyrazolo[3,4-d]pyrimidine-3-
carbonitrile (9c).
1
Yield: 89 %; beige solid, mp 271-273 oC; IR ν max cm-1 3420-3230 (NH2, 2NH); 2236 (CN); H-
NMR δ 2.42 (3H, s, p-CH3-tolyl), 7.33 (d, 2H, H3, H5-tolyl, J = 8.0 Hz), 7.65 (2H, bs, NH2, D2O
exchangeable), 8.00 (d, 2H, H2, H6-tolyl, J = 8.0 Hz), 8.21 (d, 1H, H5-pyridazine, J = 9.1 Hz),
8.42 (d, 1H, H4-pyridazine, J = 9.1Hz), 8.77 (1H, bs, NH, D2O exchangeable); MS m/z (%): M+
343 (100), 237 (66), 211 (87).Anal. Calc. for C17H13N9 (343.35): C 59.47; H 3.82 ; N 36.71; Found:
C 59.47, H 3.84, N 36.70.
General procedure for the Preparation of 2-Aryl-9-substituted-7-[6-(p-tolyl) pyridazin-3-yl]-
pyrazolo[3,4-d]-1,2,4-triazolo[5,1-f] pyrimidines (10-12).
Methanimidates 7a-c (20 mmol) were dissolved in dioxane (20 mL), and 2-furancarboxylic acid
hydrazide, 2-thiophenecarboxylic acid hydrazide or 4-pyridinecarboxylic acid hydrazide (22 mmol)
was added. The mixture was refluxed for 6-14 h, cooled, the solvent removed under reduced
pressure and the resulting precipitate was purified by recrystallization or column chromatography.
2-(2-Furyl)-9-methylthio-7-[6-(p-tolyl)pyridazin-3-yl]-pyrazolo[3,4-d]-1,2,4-triazolo[5,1-f]-
pyrimidine (10a).
o
Yield: 78 %; pale yellow solid, mp 215-216 C (from DMF/H2O); IR ν max cm-1: 3096, 2919,
1628; 1H-NMR δ: 2.54 (s, 3H, S-CH3), 2.66 ( s, 3H, p-CH3-tolyl), 6.81 (m, 1H, furyl), 7.42 (m, 2H
+ 1H, H-tolyl+ 1H-furyl), 7.65 (d, 2H, H3, H5- tolyl, J = 8.0 Hz), 7.87 (m, 1H, furyl), 8.01 (d, 1H,
H5-pyridazine, J = 9.1 Hz), 8.32 (d, 1H, , H4-pyridazine, J = 9.1 Hz), 8.65 (s, 1H, pyrimidine); MS
m/z (%): M+ 440 (95), 393 (100), 326 (39); Anal. Calc. for C22 H16N8SO (440.48): C 59.99, H 3.66,
N 25.44, S 7.28; Found : C 59.85, H 3.61, N 25.40, S 7.29.

Molecules 2001, 6
630
2-(2-Thienyl)-9-methylthio-7-[6-(p-tolyl)pyridazin-3-yl]-pyrazolo[3,4-d]-1,2,4-triazolo[5,1-f]
pyrimidine (10b).
1
Yield: 47 %; beige solid, mp 247-249 oC (from DMF/ H2O); IR ν max cm-1: 3101, 2918, 1625; H-
NMR δ: 2.53 (s, 3H, S-CH3), 2.64 ( s, 3H, p-CH3-tolyl), 7.21 (m, 1H, thienyl), 7.55 (m, 2H + 1H,
H-tolyl+1H-thienyl), 7.76 (d, 2H, H3, H5- tolyl, J = 8.0 Hz), 7.87 (m, 1H, thienyl), 8.21 (d, 1H,
H5- pyridazine, J = 9.1Hz), 8.43 (d,1H, H4-pyridazine, J = 9.1 Hz), 8.71 (s, 1H, pyrimidine); MS
m/z (%):M+ 456 (95), 409 (100), 326 (57); Anal. Calc. for C22 H16N8S2 (456.55): C 57.88, H 3.53,
N 24.54, S 14.04; Found : C 57.87, H 3.56, N 24.51, S 13.99.
2-(4-pyridyl)-9-methylthio-7-[6-(p-tolyl)pyridazin-3-yl]-pyrazolo[3,4-d]-1,2,4-triazolo[5,1-f]
pyrimidine (10c).
o
Yield: 71 %; white solid, mp 240-243 C [column chromatography, (5:1) cyclohexane/ethyl
1
acetate]; IR ν max cm-1: 3084, 2926, 1627; H-NMR δ: 2.42 (s, 3H, S-CH3), 2.60 ( s, 3H, p-CH3-
tolyl), 7.43 (d, 2H, H3, H5-tolyl, J = 8.0 Hz), 7.81 (d, 2H, pyridyl, J = 8.0 Hz), 8.10 (d, 2H, H2,
H6-tolyl, J = 8.0 Hz), 8.46 (d, 1H, H5- pyridazine, J = 9.1 Hz ), 8.55 (d, 1H, H4-pyridazine, J =
9.1, Hz), 8.67 (s, 1H, pyrimidine), 8.71 (d, 2H, pyridyl J = 8.0 Hz); MS m/z (%): M+ 451 (68), 404
(100), 326 (51); Anal. Calc. for C23 H17N9S (451.51): C 61.18, H 3.79, N 27.92, S 7.10; Found : C
61.16, H 3.77, N 27.94, S 6.99.
2-(2-Furyl)-9-N-phenylamino-7-[6-(p-tolyl)pyridazin-3-yl]-pyrazolo[3,4-d]-1,2,4-triazolo-[5,1-f]
pyrimidine (11a).
Yield: 64 %; white solid, mp 285 oC [column chromatography, (5:1) cyclohexane/ethyl acetate]; IR
1
ν max cm-1: 3415, 3086, 2921, 1616; H-NMR δ: 2.50 ( s, 3H, p-CH3-tolyl), 6.82 (m, 1H, furyl),
6.90 (t, 1H, H4-Ph, J = 7.4 Hz), 7.27 (m, 2H + 2H+ 1H, H-tolyl + H-phenyl + H-furyl), 7.65 (d,
2H, H2, H6-tolyl, J = 8.0 Hz), 8.00 (m, 1H+ 2H, H-furyl, H-phenyl), 8.19 (d, 1H, H5-pyridazine, J
= 9.1 Hz), 8.34 (d, 1H, H4-pyridazine, J = 9.1 Hz), 8.52 (s, 1H, pyrimidine); MS m/z (%): M+ 485
(93), 393 (100), 326 (69); Anal. Calc. for C27 H19N9O (485.50): C 66.80, H 3.94, N 25.96; Found :
C 66.80, H 3.97, N 25.98.
2-(2-Thienyl)-9-N-phenylamino-7-[6-(p-tolyl)pyridazin-3-yl]-pyrazolo[3,4-d]-1,2,4-triazolo- [5,1-
f] pyrimidine (11b).
o
Yield: 83 %; pale brown solid, mp >320 C (from dioxane); IR ν max cm-1: 3413, 3110, 2921,
1607; 1H-NMR δ: 2.52 (s, 3H, p-CH3-tolyl), 6.91 (t, 1H, H4-Ph, J = 7.4 Hz), 7.15 (m, 1H, thienyl),
7.40 (m, 2H , H-tolyl+ H-phenyl+ 1H-thienyl), 7.69 (d, 2H, H2, H6- tolyl, J = 8.4 Hz), 7.82 (m,
1H, thienyl), 8.02 (m, 2H-phenyl,1H-pyridazine), 8.36 (d, 1H, H4-pyridazine), 8.50 (s, 1H,
pyrimidine); MS m/z (%): M+ 501 (94), 418 (100), 326 (90); Anal. Calc. for C27 H19N9S (501.57):
C 64.66, H 3.82, N 25.13, S 6.39; Found : C 64.66, H 3.80, N 25.09, S 6.36.

Molecules 2001, 6
631
2-(4-Pyridyl)-9-N-phenylamino-7-[6-(p-tolyl)pyridazin-3-yl]-pyrazolo[3,4-d]-1,2,4-triazolo-[5,1-f]
pyrimidine (11c).
o
Yield: 61 %; yellow flakes, mp >320 C (from dioxane); IR ν max cm-1: 3375, 3095, 2921, 1599;
1H-NMR δ: 2.53 (d, 3H, p-CH3-tolyl), 7.08 (t, 1H, H4-Ph, J = 7.4 Hz), 7.30 (m, 2H+2H, H-toly+
H-phenyl), 7.50 (d, 2H, pyridyl, J = 8.0 Hz), 7.82 (d, 2H, H2, H6-tolyl, J = 8.0 Hz), 8.06 (d, 2H,
H2, H6- Ph, J = 7.9 Hz), 8.25 (d, 1H, H5-pyridazine, J = 9.1 Hz), 8.39 (d, 1H, H4-pyridazine, J =
9.1 Hz), 8.47 (s, 1H, pyrimidine), 8.70 (d, 2H, pyridyl J = 8.0Hz): MS m/z (%): M+ 496 (100), 404
(70), 418 (61); Anal. Calc. for C28 H20N10 (496.53); C 67.73, H 4.00, N 28.21; Found : C 67.79, H
4.06, N 28.26.
2-(2-Furyl)-7-[6-(p-tolyl)pyridazin-3-yl]-pyrazolo[3,4-d]-1,2,4-triazolo[5,1-f]pyrimidine-9-
carbonitrile (12a).
o
1
Yield: 46 %; beige solid, mp 230 C (from dioxane); IR ν max cm-1: 3089, 2918, 2229, 1633. H-
NMR δ: 2.35 ( s, 3H, p-CH3-tolyl), 7.07 (m, 1H, furyl), 7.31 (m, 2H-tolyl+1H-furyl), 8.09 (d, 2H,
H2, H6-tolyl, J = 8.0 Hz), 8.15 (m, 1H, furyl), 8.28 (d, 1H, H5-pyridazine, J = 9.1 Hz), 8.45 (d, 1H,
H4-pyridazine, J = 9.1 Hz), 8.70 (s, 1H, pyrimidine); MS m/z (%): M+ 419 (100), 393 (60), 352
(45); Anal. Calc. for C22 H13N9O (419.41); C 63.00, H 3.12, N 30.06; Found : C 62.99, H 3.15, N
30.02.
2-(2-Thienyl)-7-[6-(p-tolyl)pyridazin-3-yl]-pyrazolo[3,4-d]-1,2,4-triazolo[5,1-f]pyrimidine-9-
carbonitrile (12b).
o
1
Yield: 40 %; beige solid, mp 262 C (from dioxane); IR ν max cm-1:3104, 2917, 2224, 1630; H-
NMR δ: 2.35 ( s, 3H, p-CH3-tolyl), 7.38 (m, 1H, thienyl), 7.44 (d, 2H, H3, H5-tolyl, J = 8.0 Hz),
7.80 (m, 1H, H-thienyl), 7.92 (m, 1H, thienyl), 8.05 (d, 2H, H2, H6- tolyl, J = 8.0 Hz ), 8.15 (d, 1H,
H5- pyridazine, J = 9.1 Hz), 8.45 (d, 2H, H4-pyridazine, J = 9.1 Hz), 8.70 (s, 1H, pyrimidine); MS
m/z (%): M+ 435 (91), 409 (100), 352 (70); Anal. Calc. for C22 H13N9S (435.47): C 60.68, H 3.01,
N 28.95, S 7.36; Found : C 60.59, H 3.08, N 28.91, S 7.33.
2-(4-Pyridyl)-7-[6-(p-tolyl)pyridazin-3-yl]-pyrazolo[3,4-d]-1,2,4-triazolo[5,1-f]pyrimidine-9-
carbonitrile (12c).
Yield: 70 %; pale brown crystals, mp 320 oC (from EtOH); IR ν max cm-1: 3090, 2933, 2228, 1635;
1H-NMR δ: 2.44 (d, 3H, p-CH3-tolyl), 7.31 (d, 2H, H3, H5-tolyl, J = 8.0 Hz), 7.72 (d, 2H, pyridyl,
J = 8.0 Hz), 8.06 (d, 2H, H2, H6-tolyl, J = 8.4 Hz), 8.13(d, 1H, H5-pyridazine, , J = 9.1 Hz), 8.52
(d, 1H, H4-pyridazine, J = 9.1 Hz), 8.62 (s, 1H, pyrimidine), 8.75 (d, 2H, pyridyl J = 8.0 Hz); MS
m/z (%): M+ 430 (100), 404 (78), 352 (60); Anal. Calc. for C23 H14N10 (430.43): C 64.18, H 3.28, N
32.54; Found : C 64.22, H 3.20, N 32.55.

Molecules 2001, 6
632
General Procedure for the Preparation of 3-Substituted-1-[6-(p-tolyl)pyridazin-3-yl]-pyrazolo[3,4-
d]pyrimidine-4(5H)-ones (13a-c).
Compound 3a-c (5 mmol) was added to formic acid (5 mL, 85%) and the mixture was refluxed for
6h. The solid that precipitated was collected and recrystallized.
3-Methylthio-1-[6-(p-tolyl)pyridazin-3-yl]-pyrazolo[3,4-d]pyrimidine-4(5H)-one (13a).
o
Yield: 62 %; colorless needle-like crystals, mp 244 C (from EtOH); IR ν max cm-1: 3381 (NH),
1658 (CO); 1H-NMR δ: 2.44 (s, 3H, S-CH3), 2.60 (s, 3H, p-CH3-tolyl), 7.42 (d, 2H, H3, H5-tolyl, J
= 8.0 Hz), 8.00 (d, 2H, H2, H6-tolyl, J = 8.0 Hz), 8.14 (d, 1H, H5-pyridazine, J = 9.1 Hz), 8.35 (d,
1H, H4-pyridazine, J = 9.1 Hz), 8.53 (s, 1H, pyrimidine), 11.16 (s, 1H, NH, D2O exchangable);
13C-NMR δ: 14 (S—CH3), 20 (p-CH3-tolyl), 114–158 (aromatic), 131 (C-S-CH3), 163 (CO,
pyrimidine); MS m/z (%): M+ 350 (72), 323 (100), 275 (96), 129 (84); Anal. Calc. for C17 H14N6OS
(350.39): C 58.27, H 4.03, N 23.98, S 9.15; Found: C 57.95, H 4.14, N 24.02, S 9.20.
3-N-Phenylamino-1-[6-(p-tolyl)pyridazin-3-yl]-pyrazolo[3,4-d]pyrimidine-4(5H)-one (13b).
o
Yield: 34 %; colorless needle-like crystals, mp>320 C (from EtOH); IR ν max cm-1: 3337, 3265
(2NH), 1660 (CO); 1H-NMR δ: 2.60 (s, 3H, p-CH3-tolyl), 6.88 (t, 1H, H4-Ph, J = 7.4 Hz), 7.22 (d,
2H, H3, H5-tolyl, J = 8.0 Hz), 7.51 (t, 2H, H3, H5-Ph, J = 7.6 Hz) 8.01 (m, 2H+ 2H, H-tolyl + H-
phenyl), 8.24 (d, 1H, H5- pyridazine, J = 9.1 Hz), 8.33 (s, 1H, NH, D2O exchangable) 8.48 (d, 1H,
13
H4 – pyridazine, J = 9.1 Hz), 8.60 (s, 1H, pyrimidine), 11.09 (s, 1H, NH, D2O exchangable); C-
NMR (DMSO) δ: 15 (p-CH3-tolyl), 117-158 (aromatic), 131 (C-S-CH3), 169 (CO pyrimidine); MS
m/z (%): M+ 395 (100), 323 (85), 292 (75); Anal. Calc. for C22 H17N7O (395.42): C 66.83, H 4.33,
N 24.80; Found: C 66.81, H 4.34, N 24.78.
4(5H)-Oxo-1-[6-(p-tolyl)pyridazin-3-yl]-pyrazolo[3,4-d]pyrimidine-3-carbonitrile (13c).
Yield: 55 %; colorless needle-like crystals, mp>320 oC (from dioxane); IR ν max cm-1: 3367 (NH),
1
1645 (CO); H-NMR δ: 2.63 (s, 3H, p-CH3-tolyl), 7.38 (d, 2H, H3, H5-tolyl, J = 8.0 Hz), 8.16 (d,
2H, H2, H6-tolyl, J = 8.0 Hz), 8.22 (d, 1H, H5- pyridazine, J = 9.1 Hz), 8.40 (d, 1H, H4-
13
pyridazine, J = 8.0 Hz), 8.65 (s, 1H, pyrimidine), 12.50 (s, 1H, NH, D2O exchangable); C-NMR
(DMSO) δ: 13 (p-CH3-tolyl), 84 (CN), (115–157 aromatic), (168, CO), pyrimidine]; MS m/z (%):
M+ 329(90), 303(100), 271(81); Anal. Calc. for C17 H11N7O (329.39): C 62.00, H 3.37, N 29.77;
Found: C 62.01, H 3.40, N 29.74.
General procedure for the Preparation of 3-Substituted-1-[6-(p-tolyl)pyridazin-3-yl]-pyrazolo-
[3,4-d]pyrimidine-4,6(5H,7H)-dithiones (14a-c).

Molecules 2001, 6
633
To a solution of 3a-c (10 mmol) in DMF (20 mL), carbon disulfide (10 mL,15 mmol) and 10 mL
sodium methoxide (prepared from 0.59g of sodium metal and 30 mL methanol) were added. The
mixture was refluxed for 15h, and then poured into ice cold water. A solution of sodium hydroxide
(10 mL, 1M) was added to it and left overnight. The solution was filtered and acidified with dilute
acetic acid to give a yellow precipitate. It was collected, washed with dilute acetic acid, dried and
recrystallized from ethanol.
3-Methythio1-[6-(p-tolyl)pyridazin-3-yl]-pyrazolo[3,4-d]pyrimidine-4,6(5H,7H)-dithione (14a).
1
Yield: 50 %; yellow needle crystals, mp 269oC; IR ν max cm-1: 3344, 3320 (2NH); H-NMR δ:
2.45 (s, 3H, S-CH3), 2.62 (s, 3H, p-CH3-tolyl), 7.50 (d, 2H, H3, H5-tolyl, J = 8.0 Hz), 8.14 (d, 2H,
H2, H6-tolyl, J = 8.0 Hz), 8.21 (d, 1H, H5- pyridazine, J = 9.1 Hz), 8.52 (d, 1H, H4-pyridazine, J =
9.1 Hz), 8.70 (s, 1H, NH, D2O exchangable), 8.90 (s, 1H, NH, D2O exchangable); MS m/z (%): M+
398 (72), 372 (100), 325 (96); Anal. Calc. for C17H14N6S3 (398.52): C 51.24, H 3.54, N 21.09, S
24.13; Found: 50.97, H 3.29, N 21.10, S 24.12.
3-N-Phenylamino-1-[6-(p-tolyl)pyridazin-3-yl]-pyrazolo[3,4-d]pyrimidine-4,6(5H,7H)-dithione
(14b).
Yield: 35 %; yellow solid, mp 260 oC; IR ν max cm-1: 3376 - 3265 (3NH); 1H-NMR δ: 2.52 (s, 3H,
p-CH3-tolyl), 6.90 (t, 1H, H4-Ph, J = 7.4 Hz), 7.16 (d, 2H, H3, H5-tolyl, J = 8.0 Hz), 7.52 (t, 2H,
H3, H5- Ph, J = 7.6 Hz) 8.00 (m, 2H+ 2H, tolyl + H-phenyl), 8.14 (d, 1H, H5-pyridazine, J = 9.1
Hz), 8.36 (s, 1H, NH, D2O exchangable) 8.50 (d, 1H, H4-pyridazine, J = 9.1 Hz), 9.04 (s, 1H, NH,
D2O exchangable), 9.77 (s, 1H, NH, D2O exchangable); MS m/z (%): M+ 443(100), 340(95),
308(81); Anal. Calc. for C22 H17N7S2 (443.54); C 59.58, H 3.86, N 22.11, S 14.46; Found: C 59.57,
H 3.90, N 21.97, S 14.46.
1-[6-(p-tolyl)pyridazin-3-yl]-4,6-Dithioxo-4,5,6,7-tetrahydropyrazolo[3,4-d]pyrimidine-3-
carbonitrile (14c).
Yield: 32 %; yellow solid, mp 239 oC; IR ν max cm-1: 3340- 3300 (2NH), 2220 (CN); 1H-NMR δ:
2.62 (s, 3H, p-CH3-tolyl), 7.10 (d, 2H, H3, H5- tolyl, J = 8.0 Hz), 7.81 (d, 2H, H2, H6-tolyl, J =
8.0 Hz), 8.06 (d, 1H, H5-pyridazine, J = 9.1 Hz), 8.42 (d, 1H, H4-pyridazine, J = 9.1 Hz), 9.27 (s,
1H, NH, D2O exchangable), 10.00 (s, 1H, NH, D2O exchangable); MS m/z (%): M+ 377 (100), 351
(98), 325 (75); Anal. Calc. for C17 H11N7S2 (377.44); C 54.10, H 2.94, N 25.98, S 16.99; Found: C
53.88, H 3.03, N 26.07, S 17.07.
General Procedure for the Preparation of 4-Imino-5-phenyl-3-substituted-1-[6-(p-tolyl)pyridazin-
3-yl]-4,5-dihydropyrazolo[3,4-d]- pyrimidine-6(7H)-thiones/ones (15-17).

Molecules 2001, 6
634
A mixture of 3a-c (10 mmol) and phenylisocyanate or phenylisothiocyanate (10 mmol) in pyridine
(20 mL) was refluxed for 5h. The reaction mixture was cooled and poured onto ice/water and
neutralized with diluted HCl. The solid product so formed was collected by filtration and
recrystallized from ethanol.
4-Imino-5-phenyl-3-methylthio-1-[6-(p-tolyl)pyridazin-3-yl]-4,5-dihydropyrazolo[3,4-d]-
pyrimidine-6(7H)-one (15a).
o
1
Yield: 90 %; white solid, mp 229 C; IR ν max cm-1: 3395, 3326 (2NH), 1649 (CO); H-NMR δ:
2.44 (s, 3H, S-CH3), 2.56 (s, 3H, p-CH3-tolyl), 6.65 (t, 1H, phenyl, J = 6.6 Hz), 7.00 (d, 2H, H3,
H5-tolyl, J = 8.0 Hz), 7.50 (m, 2H+ 2H, H-phenyl + H-tolyl), 7.81 (m, 2H + 2H, H-tolyl +H-
phenyl), 8.06 (d, 1H, H5- pyridazine, J = 9.1Hz), 8.32 (d, 1H, H4-pyridazine, J = 9.1Hz), 8.80 (bs,
1H, NH, D2O exchangeable), 9.05 (bs, 1H, NH, D2O exchangeable); MS m/z (%): M+ 441 (90), 426
(100), 365 (42); Anal. Calc. for C23H19N7OS (441.50): C 62.57, H 4.34, N 22.21, S 7.26; Found: C
62.55, H 4.33, N 22.20, S 7.17.
4-Imino-5-phenyl-3-methylthio-1-[6-(p-tolyl)pyridazin-3-yl]-4,5-dihydropyrazolo-[3,4-d]-
pyrimidine-6(7H)-thione (15b).
o
1
Yield: 79 %; beige solid, mp 275-276 C; IR ν max cm-1: 3389-3279 (2NH); H-NMR δ: 2.36 (s,
3H, S-CH3), 2.60 (s, 3H, p-CH3-tolyl), 6.77 (t,1H,phenyl. J = 6.6 Hz), 7.00 (m, 2H, phenyl +
tolyl), 7.44 (m, 2H+ 2H, phenyl + tolyl), 8.22 (d, 2H, H5-pyridazine, J = 9.1Hz), 8.42 (bs, 1H, NH,
D2O exchangeable), 8.53 (d, 1H, H4-pyridazine, J = 9.1Hz), 9.33 (bs, 1H, NH, D2O exchangeable);
MS m/z (%): M+ 457 (100), 365 (76), 318 (39); Anal. Calc. for C23H19N7S2 (457.57): C 60.37, H
4.19, N 21.43, S 14.01; Found: C 60.35, H 4.10,N 21.26, S 13.98.
4-Imino-5-phenyl-3-N-phenylamino-1-[6-(p-tolyl)pyridazin-3-yl]-4,5-dihydropyrazolo[3,4-d]
pyrimidine-6(7H)-one (16a).
o
1
Yield: 44 %; white solid, mp 255 C; IR ν max cm-1: 3380-3210(3NH), 1648 (CO); H-NMR δ:
2.51 (s, 3H, p-CH3-tolyl), 6.90-8.41 (m, 16H, aromatic), 8.55 (bs, 1H, NH, D2O exchangeable),
9.09 (bs, 1H, NH, D2O exchangeable), 11.08 (bs, 1H, NH, D2O exchangeable); MS m/z (%): M+
486 (100), 394 (82), 317 (54); Anal. Calc. for C28 H22N8O (486.53): C 69.12, H 4.56, N 23.03;
Found: C 69.12, H 4.57, N 23.02.
4-Imino-5-phenyl-3-N-phenylamino-1-[6-(p-tolyl)pyridazin-3-yl]-4,5-dihydropyrazolo[3,4-d]
pyrimidine-6(7H)-thione (16b).
Yield: 46 %; beige solid, mp 306 oC; IR ν max cm-1: 3460-3298 (3NH); 1H-NMR δ: 2.45 (s, 3H, p-
CH3-tolyl), 7.00-8.35 (m, 16H, aromatic), 8.60 (bs, 1H, NH, D2O exchangeable), 9.18 (bs, 1H, NH,
D2O exchangeable), 11.13 (bs, 1H, NH, D2O exchangeable); MS m/z (%): M+ 502 (98), 410 (100),

Molecules 2001, 6
635
333 (56); Anal. Calc. for C28H22N8S (502.60): C 66.91, H 4.41, N 22.29, S 6.38; Found: C 66.75, H
4.40, N 22.25, S 6.35.
4-Imino-5-phenyl-1-[6-(p-tolyl)pyridazin-3-yl]-4,5-dihydro-6(7H)-oxo-pyrazolo[3,4-d]-
pyrimidine-3-carbonitrile (17a).
o
1
Yield: 43 %; beige solid, mp >320 C; IR ν max cm-1: 3368-3307 (2NH), 2247 (CN); H-NMR δ:
2.42 (s, 3H, p-CH3-tolyl), 6.80 (t, 1H, phenyl, J = 6.6 Hz), 7.33-7.50 (m, 6H, phenyl + tolyl), 7.80
(d, 2H, H2, H6-tolyl, J = 8.0 Hz), 8.06 (d, 1H, H5-pyridazine, J= 9.1 Hz), 8.38 (d, 1H, H4-
pyridazine, J = 9.1 Hz), 8.80 (bs, 1H, NH, D2O exchangeable), 11.07 (bs, 1H, NH, D2O
exchangeable); MS m/z (%): M+ 420 (100), 394 (68), 333 (66); Anal. Calc. for C23H16N8O
(420.43): C 65.71, H 3.84, N 26.65; Found: C 65.71, H 3.97, N 26.61.
4-Imino-5-phenyl-3-carbonitrile-1-[6-(p-tolyl)pyridazin-3-yl]-4,5-dihydropyrazolo-[3,4-d]-
pyrimidine-6(7H)-thione (17b).
Yield: 42 %; yellow solid, mp >320 oC; IR ν max cm-1: 3343-3222 (2NH), 2247(CN); 1H-NMR δ:
2.44 (s, 3H, p-CH3-tolyl), 7.10 (t, 1H, phenyl, J = 6.6 Hz), 7.23-7.40 (m, 6H, phenyl + tolyl), 7.85
(d, 2H, H2, H6-tolyl, J = 8.0 Hz), 8.03 (d, 1H, pyridazine, J= 9.1 Hz), 8.36 (d, 1H, pyridazine, J =
9.1 Hz), 8.60 (bs, 1H, NH, D2O exchangeable), 11.13 (bs, 1H, NH, D2O exchangeable); MS m/z
(%): M+ 436 (92), 369 (100), 353 (34); Anal. Calc. for C23H16N8S (436.49): C 63.29, H 3.69, N
25.67, S 7.34; Found: C 63.16, H 3.66, N 25.68, S 7.33.
General Procedure for the Preparation of 4-Amino-3-substituted-1-[6-(p-tolyl)pyridazin-3-yl]-
pyrazolo[3,4-d]pyrimidine-6-ones/thiones/amines (18-20).
Compound 3a-c (5 mmol) and urea (10 mmol) or thiourea (10 mmol) or guanidine carbonate (5
o
mmol) were mixed in a mortar, The mixture was then heated at 180 C in an oil bath for 20
minutes, heating was continued 2h, at the melting point of the pyrazole derivatives using reduced
pressure. The molten product was boiled 10 minutes with water, cooled and filtered. The product
was finally recrystallized from a suitable solvent.
4-Amino-3-methylthio-1-[6-(p-tolyl)pyridazin-3-yl]-pyrazolo[3,4-d]pyrimidine-6(7H)-one (18a).
o
Yield: 54 %; white solid, mp 275 C (from dioxane); IR ν max cm-1: 3466-3206 (NH2/NH), 1685
(CO); 1H-NMR δ: 2.42 (s, 3H, S-CH3), 2.50 (s, 3H, p-CH3-tolyl), 7.35 (d, 2H, H3, H5-tolyl, J =8.0
Hz), 7.70 (d, 2H, H2,H6-tolyl, J = 8.0 Hz), 8.12 (bs, 2H, NH2, D2O exchangeable), 8.38 (d, 1H,H5-
pyridazine, J = 9.1 Hz), 8.55 (d, 1H, H4-pyridazine, J = 9.1 Hz), 11.02, (bs, 1H, NH, D2O
exchangeable); MS m/z (%): M+ 365 (100), 316 (87), 318 (56); Anal. Calc. for C17 H15N7OS
(365.41): C 55.88, H 4.14, N 26.83, S 8.77; Found: C 55.87, H 4.08,N 26.90, S 8.75.

Molecules 2001, 6
636
4-Amino-3-methylthio-1-[6-(p-tolyl)pyridazin-3-yl]-pyrazolo[3,4-d]pyrimidine-6(7H)-thione (18b).
o
Yield: 63 %; yellow solid, mp >320 C (from DMF/H2O); IR ν max cm-1: 3402-3180, (NH2/NH);
1H-NMR δ: 2.54 (s, 3H, S-CH3), 2.62 ( s, 3H, p-CH3-tolyl), 7.22 (d, 2H, H3, H5-tolyl, J = 8.0 Hz),
7.64 (d, 2H, H2, H6-tolyl, J = 8.0 Hz), 7.81 (bs, 2H, NH2, D2O exchangeable), 8.08 (d, 2H, H5-
pyridazine), 8.54 (d, 1H, H4-pyridazine, J = 9.1Hz), 9.06 (bs, 1H, NH, D2O exchangeable); MS m/z
(%): M+ 381 (93), 365 (100), 334 (39); Anal. Calc. for C17 H15N7S2 (381.47): C 53.53, H 3.96, N
25.70, S 16.81; Found: C 53.53, H 4.02, N 25.70, S 16.79.
4,6-Diamino-3-methylthio-1-[6-(p-tolyl)pyridazin-3-yl]-pyrazolo[3,4-d]pyrimidine (18c).
o
Yield: 46 % yield; brown solid, mp 266 C (from DMF/H2O); IR ν max cm-1: 3410-3254 (2NH2);
1H NMR δ: 2.53 (s, 3H, S-CH3), 2.60 (s, 3H, p-CH3-tolyl), 7.04 (d, 2H, H3, H5-tolyl, J = 8.0 Hz),
7.44 (d, 2H, H2, H6-tolyl, J = 8.0 Hz), 7.70 (bs, 2H, NH2, D2O exchangeable), 8.22 (d, 2H, H5-
pyridazine, J = 9.1 Hz), 8.41 (bs, 1H, NH, D2O exchangeable), 8.66 (d, 1H, H4-pyridazine, J = 9.1
Hz),. MS: m/z (%); M+ 364(100), 348(56), 301(48); Anal. Calc. for C17 H16N8S (364.43): C 56.03,
H 4.43, N 30.75, S 8.80; Found: C 56.00, H 4.41, N 30.72, S 8.79.
4-Amino-3-N-phenylamino-1-[6-(p-tolyl)pyridazin-3-yl]-pyrazolo[3,4-d]yrimidine-6(7H)-one
(19a).
o
Yield: 43 %; white solid, mp 270 C (from DMF/H2O); IR ν max cm-1: 3411-3160 (NH2/2NH),
1675 (CO); 1H-NMR δ: 2.53 (s, 3H, p-CH3-tolyl), 6.74(t, 1H,H4-phenyl, J = 7.4 Hz), 7.22 (m, 4H,
H3, H5-phenyl+H3, H5-tolyl), 7.77 (t, 2H, H2, H6-phenyl, J = 7.9 Hz), 8.00(d, 2H, H2, H6-tolyl, J
= 8.0 Hz), 8.15 (bs, 2H, NH2, D2O exchangeable), 8.33 (d, 1H, H5-pyridazine, J = 9.1 Hz), 8.54 (d,
2H, H4-pyridazine, J = 9.1 Hz), 12.36 (bs, 1H, NH, D2O exchangeable); MS m/z (%): M+ 410 (95),
394 (100), 318 (74); Anal. Calc. for C22H18N8O (410.43): C 64.38, H 4.42, N 27.30; Found: C
64.36, H 4.46, N 27.30.
4-Amino-3-N-phenylamino-1-[6-(p-tolyl)pyridazin-3-yl]-pyrazolo[3,4-d]pyrimidine-6(7H)-thione
(19b).
Yield: 44 % yield; yellow solid, mp 276 oC (from EtOH); IR ν max cm-1: 3411-3160 (NH2/2NH);
1H-NMR δ: 2.54 (s, 3H, p-CH3-tolyl), 6.90(t, 1H, H4- phenyl, J = 7.4 Hz), 7.20 (m, 4H, H3, H5-
phenyl+ H3, H5-tolyl), 7.66 (m, 4H, H2, H6-phenyl +H2, H6-tolyl), 8.09 (bs, 2H, NH2, D2O
exchangeable), 8.26 (d, 1H, H5-pyridazine, J = 9.1Hz), 8.40 (d, 1H, H4-pyridazine, J = 9.1 Hz),
11.45 (bs, 1H, NH, D2O exchangeable); MS m/z (%): M+ 426 (95), 334 (100), 318 (64); Anal. Calc.
for C22 H18N8S (426.50); C 61.96, H 4.25, N 26.27, S 7.52; Found: C 62.01, H 4.33, N 26.25, S
7.50.

Molecules 2001, 6
637
4,6-Diamino-3-N-phenylamino-1-[6-(p-tolyl)pyridazin-3-yl]-pyrazolo[3,4-d]-pyrimidine (19c).
Yield: 52 %; yellow solid, mp>320 oC (from dioxane); IR ν max cm-1: 3397 -3110 (2NH2/NH); 1H-
NMR δ: 2.61 (s, 3H, p-CH3-tolyl), 6.80 (t, 1H, H4-phenyl, J = 7.4 Hz), 7.22 (m, 4H, H3, H5-
phenyl + H3, H5-tolyl), 7.45 (bs, 2H, NH2, D2O exchangeable) 7.60 (m, 4H, H2, H6 -phenyl + H2,
H6-tolyl), 7.90 (bs, 2H, NH2, D2O exchangeable), 8.26 (d, 2H, H5-pyridazine, J = 9.1Hz), 8.50 (bs,
1H, NH, D2O exchangeable), 8.63 (d, 1H, H4”-pyridazine, J = 9.1Hz); MS m/z (%): M+ 409 (100),
317 (80), 301 (91); Anal. Calc. for C22H19N9 (409.45); C 64.54, H 4.68, N 30.79; Found: C 64.54,
H 4.70, N 30.91.
4-Amino-3-carbonitrile-1-[6-(p-tolyl)pyridazin-3-yl]-pyrazolo[3,4-d]pyrimidine-6(7H)-one (20a).
o
Yield: 35 % yield; beige solid, mp >320 C (from EtOH); IR ν max cm-1: 3421-3368 (NH2/NH),
1
2221 (CN), 1669 (CO); H-NMR δ: 2.50 (s, 3H, S-CH3), 2.63 (s, 3H, p-CH3-tolyl), 7.24 (d, 2H,
H3, H5-tolyl, J = 8.0 Hz), 7.56 (d, 2H,H2, H6- tolyl, J = 8.0 Hz), 8.03 (bs, 2H, NH2, D2O
exchangeable), 8.28 (d, 1H, H5-pyridazine, J = 9.1Hz), 8.40 (d, 1H, H4-pyridazine, J = 9.1Hz),
12.00 (bs, 1H, NH, D2O exchangeable); MS m/z (%): M+ 344 (95), 328 (100), 318 (62); Anal. Calc.
for C17H12N8O (344.33): C 59.30, H 3.51, N 32.51; Found: C 59.29, H 3.46, N 32.50.
4-Amino-1-[6-(p-tolyl)pyridazin-3-yl]-pyrazolo[3,4-d]-6(7H)-thioxopyrimidine-3-carbonitrile
(20b).
o
Yield: 38 %; yellow solid, mp 280 C (from EtOH); IR ν max cm-1: 3399-3260 (NH2/NH), 2234
1
(CN); H-NMR δ: 2.45 (s, 3H, S-CH3), 2.61 (s, 3H, p-CH3-tolyl), 7.06 (d, 2H, H3, H5-tolyl, J =
8.0 Hz), 7.47 (d, 2H, H2, H6-tolyl, J = 8.0 Hz), 7.55 (bs, 2H, NH2, D2O exchangeable), 8.20 (d, 2H,
H5-pyridazine, J = 9.1 Hz), 8.43 (d, 1H, H4-pyridazine, J = 9.1 Hz), 9.06 (bs, 1H, NH, D2O
exchangeable); MS m/z (%): M+ 360 (92), 344 (100), 318 (39); Anal. Calc. for C17H12N8S
(360.40): C 56.66, H 3.36, N 31.09, S 8.90; Found: C 56.90, H 3.42, N 30.99, S 8.79.
4,6-Diamino-3-carbonitrile-1-[6-(p-tolyl)pyridazin-3-yl]-pyrazolo[3,4-d] pyrimidine (20c).
o
Yield: 42 %; beige solid, mp >320 C (from DMF/H2O); IR ν max cm-1: 3411-3270 (2 x NH2),
2218 (CN); 1H-NMR δ: 2.44 (s, 3H, S-CH3), 2.61 (s, 3H, p-CH3-tolyl), 7.38 (d, 2H, H3, H5-tolyl, J
= 8.0 Hz), 7.53 (d, 2H, H2, H6-tolyl, J = 8.0 Hz), 8.05 (bs, 2H, NH2, D2O exchangeable), 8.22 (d,
1H, H5-pyridazine, J = 9.1Hz), 8.53 (d, 1H, H4-pyridazine, J = 9.1Hz), 8.64 (bs, 1H, NH, D2O
exchangeable); MS m/z (%): M+ 343 (87), 311 (100), 285 (55); Anal. Calc. for C17 H13N9 (343.35):
C 59.47, H 3.82, N 36.71; Found: C 59.49, H 3.80, N 36.71.

Molecules 2001, 6
638
References and Notes
1. Petrie, III, C. R.; Cottam, H.B.; McKernan, P.A.; Robins, R.K.; Revankar, G.R. Synthesis
and biological activity of 6-azacadeguomycin and certain 3,4,6-trisubstituted pyrazolo[3,4-
d] pyrimidine ribonucleosides. J. Med. Chem.. 1985, 28,1010-1016.
2. Bhat, G. A;. Montero, J. G.; Panzica, R. P.; Worting, L.L. ; Towsend, L. B. Pyrazolo-
pyrimidine Nucleosides. 12. Synthesis and biological activity of certain pyrazolo[3,4-d]-
pyrimidine nucleosides related to adenosine. . J. Med.Chem. 1981 24, 1165 -1172.
3. Zacharie, B.; Connolly, T.P.; Rej, R.; Attardo, G.; Penney, C.L. A short synthesis of 4-
substituted 1-(hydroxyalkyl)-1H-pyrazolo[3,4-d]pyrimidines. Tetrahedron 1996, 52,
2271-2278.
4. Anderson, J. D.; Cottam, H. B.; Larson, S. B.; Nord, L. D.; Revankar, G. R.; Robins, R. K.
J. Heterocyclic Chem. 1990, 27, 439-453.
5. Avila, J. L.; Polegre, M. A.; Avila, A. R.; Robins, K. Action of pyrazolopyrimidine
derivatives on american Leiishmania SPP Promastigotes, Comp. Biochem. Physiol. 1986,
83C, 285-289
6. Contreras, J.; Rival, Y.; Chayer, S.;Bourguignon, J.; Wermuth, C.. J. Med. Chem., 1999, 42,
730-741 and references therein.
7. Al-Afaleq, E. I. Heterocyclic synthesis via enaminonitriles: An efficient, one step synthesis
of some novel azolo[1,5-a]pyrimidine, pyrimido[1,2-a]benzimidazole, pyrido[1,2-a]benz-
imidazole pyrimidine and pyrazole derivatives. Synth. Commun., 2000, 30, 1985-1999.
8. Jahine, H.; Sayed, A.; Zaher, H.A.; Sherif, O. Reactions of 3-chloro-& 3-hydrazino-6-(p-
tolyl)pyridazines.Ind. J. Chem. 1977, 15B, 250-251.
9. El-Shafei, Soliman, A.M.; Sultan, A.A.;El-Saghier, A.M. A Synthesis of some new hetero-
cycles containing a bridghead nitrogen atom under PTC conditions. A new application of
cyanoketene S,S-acetals. Gazz. Chim. Ital., 1995, 125, 115-118.
10. S. M. Hecht, S.M.; Werner, D.; Traficante, D.D. Structure determination of the N-methyl
isomers of 5-amino-3,4-dicyanopyrazole and certain Related pyrazolo[3,4-d]pyrimidines. J.
Org. Chem., 1975, 40, 1815-1822.
Sample availability: Not available
© 2001 by MDPI (http://www.mdpi.org). Reproduction is permitted for noncommercial purposes.
