A R T I C L E S
Evarts et al.
product can be further recrystallized from chloroform and hexanes to
separate the diastereomers.
22.0, 17.9, -4.7, -5.0. LRMS: (CI) highest mass 411 (M + H), base
peak 137. HRMS: (CI) calculated for C21H34O4SSi 411.2025, found
411.2005. [R]D (c 38.0, CHCl3) ) -1°.
(1R,3S,4S,5R,6R)-5-Benzenesulfonyl-4-methyl-7-oxabicyclo[4.1.0]-
heptan-3-ol (23Me a). 99% yield 6:1 ratio, after recrystallization 83%
General Procedure for Base-Induced Epoxide Opening Followed
by Etherification of γ-Hydroxy Vinyl Sulfones. To a solution of the
silylated epoxy sulfone (0.25 mmol) in THF (2.5 mL) was added DBU
(0.30 mmol). The stirring solution was heated to reflux for 1 h. The
temperature was lowered to room temperature, and diethyl ether (5
mL) was added to the mixture followed by water (5 mL). The organic
phase was separated and concentrated. The resulting mixture was filtered
through a 1 in. silica gel plug eluting with a 1:1 solution of ethyl acetate/
hexanes, which upon concentration gives the vinyl sulfone in high yield.
Etherification is performed as explained previously.
1
yield 30:1 ratio. H NMR (CDCl3): δ 7.96 (m, 2H), 7.67 (m, 3H),
3.64 (m, 1H), 3.58 (d, J ) 3.8 Hz, 1H), 3.51 (d, J ) 9.3 Hz, 1H), 3.40
(m, 1H), 2.68 (d, J ) 10.8 Hz, 1H, (OH)), 2.40 (ddd, J ) 15.7 Hz, 5.6
Hz, 2.7 Hz, 1H), 2.03 (m, 1H), 1.90 (dddd, 15.7 Hz, 5.0 Hz, 3.8 Hz,
1.2 Hz, 1H), 1.25 (d, J ) 6.9 Hz, 3H). 13C NMR (CDCl3): δ 137.9,
134.3, 129.6, 128.7, 69.2, 64.0, 53.4, 51.2, 32.4, 29.8, 18.8. LRMS:
(CI) highest mass 269 (M + H), base peak 233. HRMS: (CI) calculated
for C13H16O4S 269.0848, found 269.0852. mp 133.5-134.0 °C. [R]D
(c 2.90, CHCl3) ) +27°.
(1R,4S,5S)-3-Benzenesulfonyl-5-(tert-butyldimethylsilanyloxy)-4-
methylcyclohex-2-enol (24Me a). 96% yield. H NMR (CDCl3): δ
(1R,3S,4S,5R,6R)-5-Benzenesulfonyl-4-isopropyl-7-oxabicyclo-
[4.1.0]heptan-3-ol (23Pr a). 95% >50:1 ratio. H NMR (CDCl3): δ
1
1
7.88 (m, 2H), 7.58 (m, 3H), 6.92 (d, J ) 3.2 Hz, 1H), 4.43 (m, 1H),
3.75 (m, 1H), 2.60 (m, 1H), 1.98 (m, 1H), 1.83 (m, 1H), 1.02 (d, J )
6.9 Hz, 3H), 0.82 (s, 9H), 0.01 (s, 3H), -0.04 (s, 3H). 13C NMR
(CDCl3): δ 145.1, 139.9, 138.7, 133.4, 129.2, 128.0, 69.0, 66.0, 35.3,
35.2, 25.7, 18.0, 13.7, -4.8, -5.0. LRMS: (CI) highest mass 383 (M
+ H), base peak 365. HRMS: (CI) calculated for C19H30O4SSi (M +
H - H2O) 365.1607, found 365.1595. [R]D (c 88.0, CHCl3) ) -2°.
(2S,3S,5R)-(3-Benzenesulfonyl-5-methoxy-2-methylcyclohex-3-
enyloxy)-tert-butyldimethylsilane (24Me b). Reaction time: 10 min;
98% yield. 1H NMR (CDCl3): δ 7.87 (m, 2H), 7.57 (m, 3H), 6.92 (d,
J ) 2.4 Hz, 1H), 4.03 (m, 1H), 3.65 (m, 1H), 3.40 (s, 3H), 2.59 (m,
1H), 1.97 (m, 1H), 1.70 (m, 1H), 0.95 (d, J ) 6.9 Hz, 3H), 0.83 (s,
9H), -0.03 (s, 3H), -0.04 (s, 3H). 13C NMR (CDCl3): δ 146.4, 139.8,
136.0, 133.4, 129.2, 128.1, 68.4, 56.3, 35.0, 31.6, 25.6, 18.0, 13.1, -4.9.
LRΜS: (CI) highest mass 397 (M + H), base peak 263. HRMS: (CI)
calculated for C20H32O4SSi 396.1791, found 396.1787. [R]D (c 27.0,
CHCl3) ) -0.5°.
(1R,4S,5S)-3-Benzenesulfonyl-5-(tert-butyldimethylsilanyloxy)-4-
isopropylcyclohex-2-enol (24Pr a). 99% yield. 1H NMR (CDCl3): δ
7.85 (m, 2H), 7.58 (m, 3H), 6.88 (d, J ) 3.4 Hz, 1H), 4.45 (m, 1H),
3.40 (dt, J ) 12.7 Hz, 4.0 Hz, 1H), 2.27 (m, 1H), 2.01 (m, 2H), 1.74
(m, 1H), 1.14 (d, J ) 7.0 Hz, 3H), 0.97 (d, J ) 7.3 Hz, 3H), 0.80 (s,
9H), -0.13 (s, 3H), -0.16 (s, 3H). 13C NMR (CDCl3): δ 144.1, 139.1,
133.4, 129.2, 128.4, 70.4, 66.2, 46.0, 35.8, 25.7, 25.2, 24.4, 21.8, 18.0,
-5.1, -5.2. LRMS: (CI) highest mass 411 (M + H), base peak 137.
HRMS: (CI) calculated for C21H34O4SSi 411.2025, found 411.2012.
mp 133.5-134.5 °C. [R]D (c 5.0, CHCl3) ) -60°.
7.94 (m, 2H), 7.67 (m, 3H), 4.05 (m, 1H), 3.89 (d, J ) 8.4 Hz, 1H),
3.61 (d, J ) 3.7 Hz, 1H), 3.38 (m, 1H), 2.28 (m, 2H), 1.88 (m, 1H),
1.74 (m, 1H), 1.06 (d, J ) 7.5 Hz, 3H), 1.03 (d, J ) 7.5 Hz, 3H). 13
C
NMR (CDCl3): δ 138.0 134.2, 129.5, 128.7, 64.8, 60.7, 53.4, 51.7,
30.2, 29.5, 20.6, 18.3. LRMS: (CI) highest mass 269 (M + H), base
peak 233. HRMS: (CI) calculated for C15H20O4S 297.1161, found
297.1173. mp 147.5-148.0 °C. >99% ee HPLC Chiralcel OD 1.0 mL/
min 90:10 Hex:2-propanol. 16.04 min minor enantiomer, 14.60 min
major enantiomer. [R]D (c 3.1, CHCl3) ) +63°.
(1R,2R,3R,4S,7R)-(2-Benzenesulfonyl-3-methyl-8-oxabicyclo[5.1.0]-
oct-4-yloxy)-tert-butyldimethylsilane (31). To a stirring solution of
allyl sulfone 30 (0.884 g, 2.33 mmol) in CH2Cl2 (23 mL) at room
temperature was added m-CPBA (1.56 g, 6.33 mmol). The mixture
was stirred for 18 h, at which point diethyl ether (20 mL) was added
followed by a saturated solution of sodium bisulfite (20 mL). The
organic phase was separated and washed with 10% NaOH (2 × 20
mL), and then dried over MgSO4 and concentrated to give 0.848 g of
1
the desired epoxy sulfone as a single diastereomer in 92% yield. H
NMR (CDCl3): δ 7.92 (m, 2H), 7.61 (m, 3H), 3.86 (m, 1H), 3.42 (m,
2H), 3.06 (m, 1H), 2.68 (m, 1H), 1.91 (m, 1H), 1.75 (m, 1H), 1.53 (m,
2H), 1.25 (d, J ) 7.5 Hz, 3H), 0.84 (s, 9H), 0.00 (s, 3H), -0.01 (s,
3H). 13C NMR (CDCl3): δ 139.4, 133.7, 129.2, 128.5, 72.2, 63.6, 53.2,
51.6, 37.6, 26.3, 25.6, 22.1, 17.8, 13.0, -5.1, -5.2. LRMS: (EI) highest
mass 359 (M - C4H9), base peak 73. HRMS: (EI) calculated for
C20H32O4SSi 396.1791, found 396.1782.
General Procedure for Silyl Protection of the Epoxy Alcohols.
To a stirring solution of the epoxy sulfone (0.42 mmol) and triethyl-
amine (0.63 mmol) in CH2Cl2 (4.0 mL) at room temperature was added
tert-butyldimethylsilyl triflouromethylsulfonate (0.50 mmol). The solu-
tion was stirred for 30 min. Diethyl ether (10 mL) was added, and the
crude mixture was concentrated. The mixture was then filtered through
a 1 in. silica plug eluting with a 1:3 solution of ethyl acetate/hexanes
to give, after concentration, the desired protected alcohol in quantitative
yield.
(1R,3S,4S,5R,6R)-(5-Benzenesulfonyl-4-methyl-7-oxa-bicyclo[4.1.0]-
hept-3-yloxy)-tert-butyldimethylsilane (23Me b). Quantitative yield.
1H NMR (CDCl3): δ 7.91 (m, 2H), 7.62 (m, 3H), 4.15 (ddd, J ) 10.4
Hz, 6.3 Hz, 4.4 Hz, 1H), 3.59 (d, J ) 2.4 Hz, 1H), 3.35 (d, J ) 3.5
Hz, 1H), 3.25 (dd, J ) 5.0 Hz, 4.3 Hz, 1H), 2.32 (m, 1H), 1.98 (m,
2H), 1.01 (d, J ) 7.2 Hz, 3H), 0.86 (s, 9H), 0.05 (s, 6H). 13C NMR
(CDCl3): δ 138.3 134.0, 129.4, 128.4, 65.7, 65.3, 52.1, 49.4, 31.8,
28.5, 14.1, -4.8, -4.9. LRMS: (CI) highest mass 383 (M + H), base
peak 383. HRMS: (CI) calculated for C19H30O4SSi 383.1712, found
383.1700. [R]D (c 5.0, CHCl3) ) +16°.
(1S,2S,5R)-(3-Benzenesulfonyl-2-isopropyl-5-methoxycyclohex-3-
enyloxy)-tert-butyldimethylsilane (24Pr b). Reaction time: 10 min;
1
98% yield. mp 133.5-134.5 °C. H NMR (CDCl3): δ 7.85 (m, 2H),
7.57 (m, 3H), 6.97 (d, J ) 3.5 Hz, 1H), 4.01 (m, 1H), 3.41 (s, 3H),
3.38 (m, 1H), 2.24 (m, 2H), 1.97 (m, 1H), 1.74 (m, 1H), 1.13 (d, J )
6.9 Hz, 3H), 0.94 (d, J ) 6.9 Hz, 3H), 0.80 (s, 9H), -0.13 (s, 3H),
-0.16 (s, 3H). 13C NMR (CDCl3): δ 144.7, 139.2, 136.6, 133.3, 129.1,
128.4, 74.6, 70.5, 56.6, 49.1, 32.8, 25.7, 25.3, 24.5, 21.6, 18.0, -5.1,
-5.2. LRMS: (CI) highest mass 424 (M + H), base peak 133.
HRMS: (CI) calculated for C21H34O4SSi 425.2182, found 425.2176.
[R]D (c 3.0, CHCl3) ) -39°.
(1R,4R,5S)-3-Benzenesulfonyl-5-(tert-butyldimethylsilanyloxy)-4-
methylcyclohept-2-enol (32). Reaction time: 5 h; 97% yield. 1H NMR
(CDCl3): δ 7.87 (m, 2H), 7.55 (m, 3H), 7.19 (d, J ) 3.5 Hz, 1H),
4.51 (m, 1H), 3.80 (ddd, J ) 7.2 Hz, 4.6 Hz, 2.3 Hz, 1H), 2.86 (dq, J
) 7.3 Hz, 2.1 Hz, 1H), 2.65 (d, J ) 6.6 Hz, 1H, (OH)), 2.14 (m, 1H),
1.92 (m, 1H), 1.80 (m, 1H), 1.69 (m, 1H), 0.97 (d, J ) 7.3 Hz, 3H),
0.75 (s, 9H), -0.07 (s, 3H), -0.19 (s, 3H). 13C NMR (CDCl3): δ 145.5,
142.5, 139.5, 133.1, 129.1, 128.5, 71.0, 70.0, 40.0, 28.6, 28.0, 25.8,
18.0, 16.3, -5.0, -5.5. LRMS: (EI) highest mass 339 (M - C4H9),
base peak 75. (CI) highest mass 397 (M + H), base peak 379. HRMS:
(EI) calculated for C20H32O4SSi 396.1791, found 396.1772.
(1R,3S,4S,5R,6R)-(5-Benzenesulfonyl-4-isopropyl-7-oxa-bicyclo-
[4.1.0]hept-3-yloxy)-tert-butyldimethylsilane (23Pr b). Quantitative
1
yield. H NMR (CDCl3): δ 7.93 (m, 2H), 7.64 (m, 3H), 4.41 (ddd, J
) 11.1 Hz, 6.9 Hz, 4.3 Hz, 1H), 3.84 (m, 1H), 3.42 (m, 1H), 3.31 (m,
1H), 1.98 (m, 4H), 0.91 (d, J ) 6.6 Hz, 3H), 0.88 (s, 9H), 0.66 (d, J
) 6.4 Hz, 3H), 0.11 (s, 3H), 0.10 (s, 3H). 13C NMR (CDCl3): δ 138.3,
134.0, 129.4, 128.5, 67.0, 62.6, 52.5, 48.8, 42.6, 29.0, 26.9, 25.8, 23.5,
(1S,2R,5R)-(3-Benzenesulfonyl-5-methoxy-2-methylcyclohept-3-
enyloxy)-tert-butyldimethylsilane (33). Reaction time: 10 min; 98%
9
11100 J. AM. CHEM. SOC. VOL. 124, NO. 37, 2002
