Palladium(II)-catalyzed intramolecular diamination of unfunctionalized alkenes

Article abstract of DOI:10.1021/ja055190y

Intramolecular diamination reactions are described which yield cyclic ureas as direct products of an oxidative alkene transformation in the presence of palladium acetate and iodosobenzene diacetate as terminal oxidant. The reaction is truly catalytic in metal catalyst and represents the proof of principle for this elusive type of alkene oxidation. Copyright

Full text of DOI:10.1021/ja055190y

Published on Web 10/04/2005
Palladium(II)-Catalyzed Intramolecular Diamination of Unfunctionalized
Alkenes
Jan Streuff, Claas H. Ho¨velmann, Martin Nieger, and Kilian Mun˜iz*
Kekule´-Institut fu¨r Organische Chemie und Biochemie, Gerhard-Domagk-Str. 1, D-53121 Bonn, Germany
Received July 31, 2005; E-mail: kilian.muniz@uni-bonn.de
Table 1. Palladium-Catalyzed Intramolecular Diamination of
Alkenes
The development of efficient nitrogen transfer to carbon bonds
constitutes an important endeavor in both academia and industry.1
Such amination reactions have recently been greatly advanced
through intramolecular reaction courses. Elegant examples in this
area include hydroamination,2 aminohydroxylation,3,4 allylic ami-
nation,5 aziridination,6 alkane amination,7 and aza-Wacker8 reac-
tions. We here describe the first realization of catalytic diamination
of unfunctionalized alkenes, which relies on intramolecular reaction
control.
The oxidative catalytic diamination of alkenes represents an
elusive reaction in modern oxidation catalysis. Starting with
pioneering work by Barluenga in 1974,9 initial investigation devised
oxidation reactions that were stoichiometric in metals.10,11 The
development of an efficient catalysis is usually hampered by the
fact that diamines coordinate to almost all transition metals, which
results in poisoning of a potential catalyst. A pronounced example
is given for imidoosmium reagents, which generate stable mono-
meric osmaimidazolidines.11
Earlier attempts by us for diamination catalysis in palladium,
again, experienced the drawback of metal deactivation by the
diamine products.12 It became obvious that, without preventing the
product from metal coordination, palladium catalysis would remain
inefficient.13 To this end, our initial approach started from the
assumption that ω-alkenyl-substituted urea molecules should un-
dergo cyclization in the presence of an electrophilic palladium(II)
catalyst, leading to an intermediary vicinal amino pallada compound.
Palladium replacement through the second amino group of the
urea under oxidative conditions should then regenerate the
palladium(II) catalyst and release the diamination product as a cyclic
urea:
Oxidative diamination following this concept was found to take
place for a range of different starting materials (Table 1). In all
cases, the appropriate choice of reoxidant was crucial, and among
various reoxidants tested, only the hypervalent iodine reagent PhI-
(OAc)2 was highly efficient. With Pd(OAc)2 as precatalyst and
under mild conditions (CH2Cl2, room temperature), diamination and
concomitant formation of five-, six-, and seven-membered fused
rings was conveniently accomplished (Table 1). All reactions
reached high to full conversion, and no compounds other than the
diamination products were produced. Depending on the final ring
size, three different protocols were developed. Protocol A, which
is most suitable for pyrrolidine formation, employs a catalyst loading
of 5 mol % and calls for a stoichiometric amount of base. The
latter accelerates the reaction and leads to full conversion after 12
h (entry 1). Lowering the catalyst loading to 2 mol % requires an
a Procedure A: 5 mol % of Pd(OAc)2, PhI(OAc)2 (2.2 equiv), NMe4Cl/
NaOAc (1 equiv), CH2Cl2, RT, 12 h. Procedure B: 25 mol % of Pd(OAc)2,
PhI(OAc)2 (2.2 equiv), CH2Cl2, RT, 48 h. Procedure C: 10 mol % of
Pd(OAc)2, PhI(OAc)2 (2.2 equiv), CH2Cl2, RT, 12 h. b Determined from
crude 1H NMR spectra and TLC control. c Given yields refer to isolated
analytically pure material after column chromatography.
enhanced reaction period of up to 48 h, but does not effect the
reaction selectivity. The diamination proceeds well for a variety of
further substrates bearing additional substitution at the carbon
skeleton (entries 2-4). Formation of the seven-membered ring
annulation was slightly slower, and the reaction proceeded best with
10 mol % of palladium catalyst (Procedure C, entry 8). In contrast,
9
14586
J. AM. CHEM. SOC. 2005, 127, 14586-14587
10.1021/ja055190y CCC: $30.25 © 2005 American Chemical Society

C O M M U N I C A T I O N S
Scheme 1. Palladium-Catalyzed Synthesis of Tricyclic
Heterocycles 2a,b
reductive conditions (LiAlH4, then HCl) and furnished the free
diamine in 95% yield from nondeuterated 4. In contrast to earlier
work with preformed imidoosmium oxidants10c,11 or the stoichio-
metric palladium10a,b and thallium9a diaminations, the intramolecular
reactions described herein afford diamines with predictable dif-
ferentiation of the nitrogen substituents.
In summary, we have described intramolecular diamination
reactions of alkenes, which afford a conceptually novel synthesis
of cyclic ureas and diamines, respectively. This process establishes
the principle of oxidative intramolecular diamination reactions,
which are truly catalytic in metal.
Acknowledgment. Financial support from the Fonds der
Chemischen Industrie and the German-Israeli Foundation to K.M.
is gratefully acknowledged.
Supporting Information Available: Experimental procedures,
X-ray data for 2a, and spectral characterization (1H and 13C NMR) for
reaction products. This material is available free of charge via the
Internet at http://pubs.acs.org.
Scheme 2. Mechanistic Proposal
References
(1) Modern Amination Reactions; Ricci, A., Ed.; Wiley-VCH: Weinheim,
Germany, 2000.
(2) (a) Hong, S.; Marks, T. J. Acc. Chem. Res. 2004, 37, 673. (b) Hultzsch,
K. C. AdV. Synth. Catal. 2005, 347, 367.
(3) (a) Donohoe, T. J.; Johnson, P. D.; Cowley, A.; Keenan, M. J. Am. Chem.
Soc. 2002, 124, 12934. (b) Donohoe, T. J.; Johnson, P. D.; Pye, R. J.
Org. Biomol. Chem. 2003, 1, 2025. (c) Donohoe, T. J.; Johnson, P. D.;
Pye, R. J.; Keenan, M. Org. Lett. 2004, 6, 2583. (d) Kenworthy, M. N.;
Taylor, R. J. K. Org. Biomol. Chem. 2005, 3, 603.
(4) Alexanian, E. J.; Lee, C.; So¨rensen, E. J. J. Am. Chem. Soc. 2005, 127,
7690.
piperidine formation required a catalyst loading of 25 mol %, and
a beneficial effect of base was not observed (Procedure B, entries
5-7). For all reactions, the overall conformation of the products
was established from their respective NMR spectra and MS data.14
Formation of a quaternary stereocenter was accomplished with the
expected complete selectivity and in high yield (entry 9).15
Tricyclic heterocycles are accessible from this reaction, as well.
Here, urea 1 underwent clean diamination to yield two products,
2a and 2b, in the absence of base (Scheme 1). The latter one is
believed to derive from regioselective additional Pd-catalyzed
oxidation at the arene ring.16 Applying the conditions of Procedure
A, compound 2a is obtained as sole product (78%). It was
characterized by X-ray analysis, which confirmed the expected
concave surface of the tricyclic core.
To probe the underlying mechanism, diamination of selectively
deuterated 3 was investigated, and the obtained diastereomerically
pure product 4 showed selective deuterium incorporation. The
observed coupling constant of 3J ) 8.6 Hz between the remaining
two hydrogen atoms at the urea core confirms a trans-arrangement
of these two atoms and proves that the E-stereochemistry of the
alkene was transferred to the product. The simplest mechanistic
scenario for such a result is in agreement with our initial working
hypothesis and should consist of a trans-selective amino-palladation
to yield intermediate 5. Finally, Pd oxidation16 and concomitant
second amination forms the cyclic urea core and displaces the
palladium. This final step is obviously kinetically preferred over
potentially competing â-hydride elimination.8,17 The presence of
oxidant is required, as a control reaction stoichiometric in metal
was reversible, leading to recovered starting material and did not
give any detectable diamination product without PhI(OAc)2. Due
to this result, an alternative Pd(II)/Pd(0) cycle result is less probable.
Liberation of the respective diamine core was accomplished under
(5) (a) Welter, C.; Koch, O.; Lipowsky, G.; Helmchen, G. Chem. Commun.
2004, 896. (b) Welter, C.; Dahnz, A.; Brunner, B.; Streiff, S.; Du¨bon, P.;
Helmchen, G. Org. Lett. 2005, 7, 1239. (c) For an allylic amination as
the final step in catalytic diamination of 1,3-dienes, see: Bar, G. L J.;
Lloyd-Jones, G. C.; Booker-Milburn, K. I. J. Am. Chem. Soc. 2005, 127,
7308.
(6) (a) Dauban, P.; Sanie´re, L.; Tarrade, A.; Dodd, R. H. J. Am. Chem. Soc.
2001, 123, 7707. (b) Duran, F.; Leman, L.; Ghini, A.; Burton, G.; Dauban,
P.; Dodd, R. H. Org. Lett. 2002, 4, 2481.
(7) (a) Espino, C. G.; Du Bois, J. Angew. Chem., Int. Ed. 2001, 40, 598. (b)
Espino, C. G.; Wehn, P. M.; Chow, J.; Du Bois, J. J. Am. Chem. Soc.
2001, 123, 6935. (c) Fleming, J. J.; Fiori, K. W.; Du Bois, J. J. Am. Chem.
Soc. 2003, 125, 2028. (d) Fiori, K. W.; Fleming, J. J.; Du Bois, J. Angew.
Chem., Int. Ed. 2004, 43, 4349. (e) Espino, C. G.; Fiori, K. W.; Kim, M.;
Du Bois, J. J. Am. Chem. Soc. 2004, 126, 15378. (f) Liang, J. L.; Yuan,
S. X.; Huang, J.-S.; Yu, W.-Y.; Che, C.-M. Angew. Chem., Int. Ed. 2002,
41, 3465.
(8) Fix, S. R.; Brice, J. L.; Stahl, S. S. Angew. Chem., Int. Ed. 2002, 41, 164.
(9) (a) Go´mez Aranda, V.; Barluenga, J.; Aznar, F. Synthesis 1974, 504. (b)
Barluenga, J.; Alonso-Cires, L.; Asensio, G. Synthesis 1979, 962.
(10) (a) Ba¨ckvall, J. E. Tetrahedron Lett. 1977, 163. (b) Ba¨ckvall, J. E.
Tetrahedron Lett. 1975, 2225. (c) Chong, A. O.; Oshima, K.; Sharpless,
K. B. J. Am. Chem. Soc. 1977, 99, 3420. (d) Anhaus, J. T.; Kee, T. P.;
Schofield, M.; Schrock, R. R. J. Am. Chem. Soc. 1990, 112, 1642. (e)
Zabawa, T. P.; Kasi, D.; Chemler, S. R. J. Am. Chem. Soc. 2005, 127,
11250.
(11) (a) Mun˜iz, K.; Iesato, A.; Nieger, M. Chem.sEur. J. 2003, 9, 5581. (b)
Mun˜iz, K.; Nieger, M.; Mansikkama¨ki, H. Angew. Chem., Int. Ed. 2003,
42, 5958. (c) Mun˜iz, K.; Nieger, M. Chem. Commun. 2005, 2729.
(12) Mun˜iz, K. Habilitation Thesis, Universita¨t Bonn, 2004.
(13) For a diamination relying on solvent incorporation and subsequent Ritter-
type cyclization to yield imidazolidines, see: (a) Li, G.; Wei, H.-X.; Kim,
S. H.; Carducci, M. Angew. Chem., Int. Ed. 2001, 40, 4277. (b) Wei,
H.-X.; Kim, S. H.; Li, G. J. Org. Chem. 2002, 67, 4777.
(14) See Supporting Information for full details.
(15) Even under conditions B, internal olefins react only at very low rate.
Current work is directed to understand and overcome these limitations.
(16) (a) Yoneyama, T.; Crabtree, R. H. J. Mol. Catal. A 1996, 108, 96. (b)
Dick, A. R.; Hull, K. L.; Sanford, M. S. J. Am. Chem. Soc. 2004, 126,
2300. (c) Desai, L. V.; Hull, K. L.; Sanford, M. S. J. Am. Chem. Soc.
2004, 126, 9542.
(17) (a) Timokhin, V. I.; Anastasi, N. R.; Stahl, S. S. J. Am. Chem. Soc. 2003,
125, 12996. (b) Brice, J. L.; Harang, J. E. Timokhin, V. I.; Anastasi, N.
R.; Stahl, S. S. J. Am. Chem. Soc. 2005, 127, 2868.
JA055190Y
9
J. AM. CHEM. SOC. VOL. 127, NO. 42, 2005 14587
