10.1002/adsc.201901457
Advanced Synthesis & Catalysis
Experimental Section
substantially improved diastereocontrol of the reaction
was achieved via the application of heteroaromatic
ketones. As shown in Scheme 1, zinc complex
promoted the reaction of 2-acetylfuran (3k, 3l) in
enantioselective (up to 86% ee) and anti-
diastereoselective manner (dr up to 1.5:1 for anti-3k).
While the actual cause of such reversal is not fully
understood, the similar tendency in terms of dr and ee
was observed for product formation of reaction
between 2-acetylthiophene and methyl acrylate (3m).
Surprisingly, a methyl-group exchange in larger ethyl
group in the acrylate fragment of 3n, resulted in
General procedure for Asymmetric Reductive Aldol
Reaction of Ketones with Acrylates
Under an argon atmosphere at room temperature, Zn(OAc)2
(13.8 mg, 0.075 mmol) and diamine ligand (45.0 mg, 0.075
mmol) were dissolved in anhydrous m-xylene (1 mL) and
stirred for 60 min. Triethoxysilane (0.185 mL, 1.0 mmol)
was then added, the mixture was cooled down to –30 °C and
stirred for additional 5 min. Then, the corresponding ketone
(0.5 mmol) followed by methyl acrylate (0.6 mmol) were
added to the solution. After specified time, the reaction
reversal of diastereoselectivity in favor of syn-isomer mixture was quenched by addition of 5 mL of saturated
K2CO3 in methanol. The resulting mixture was stirred for 30
min, then 10 mL of ethyl acetate was added and the aqueous
layer was extracted three times. The combined organic
layers were washed with brine, then dried over anhydrous
MgSO4. The residue obtained after evaporation of the
solvent under reduced pressure was purified by column
chromatography on silica gel using hexane-ethyl acetate (6:1,
v/v) as eluent. The ee values and dr ratios were then
determined by HPLC methods and NMR spectroscopy. Part
of isolated mixtures of diastereomers were separated by
additional column chromatography on silica gel, eluted with
hexanes-ethyl acetate (9:1, v/v) and the ee values of
particular diastereomers were determined by chiral HPLC
analysis.
once again and decrease in enantioselectivity to 80%
ee. In contrast to reactivity of furan- and thiophene-
type ketones, similar investigation made for pyrrole
(3p) and pyridine (3q) derivatives were unsuccessful.
Finally, we determined an absolute configuration
of isolated anti-β-hydroxy ester 3a by conversion to
described in literature alcohol 7 with a single chiral
center at C-3 position (Scheme 2).[8b,14] Based on
comparison of the optical rotation of reduced (S)-3-
methyl-2-phenyl-butan-2-ol (7) with the literature
value, the absolute configuration of anti-3a was
determined to be (2R,3S).
Acknowledgements
Financial support from the Polish National Science Centre (OPUS
Grant No. NCN 2017/27/B/ST5/01111) is gratefully acknowledged.
Scheme 2. Absolute configuration of anti-3a product.
References
[1] For selected examples, see: a) A. B. Smith, T. J.
Beauchamp, M. J. LaMarche, M. D. Kaufman, Y. Qui,
H. Arimoto, D. R. Jones, K. Kobayashi, J. Am. Chem.
Soc. 2000, 122, 8654–8664; b) M. O. Duffey, A. LeTiran,
J. P. Morken, J. Am. Chem. Soc. 2003, 125, 1458–1459;
c) J. R. Dunetz, L. D. Julian, J. S. Newcom, W. R. Roush,
J. Am. Chem. Soc. 2008, 130, 16407–16416; d)
S.Yamakoshi, E. Kawanishi, Tetrahedron Lett. 2014, 55,
1175–1177; e) P. Wu, W. Cai, Q. Y. Chen, S. Xu, R. Yin,
Y. Li, W. Zhang, H. Luesch, Org. Lett. 2018, 18, 5400–
5403.
In summary, we have developed a new strategy
for the asymmetric reductive aldol reaction of ketones
with α,β-unsaturated esters promoted by the chiral zinc
catalyst. This is also the first successful application of
zinc hydride reagent in stereoselective reductive aldol
reaction of ketones. The elaborated catalytic system is
based on cost-effective, environmentally benign and
easily accessible zinc acetate complex with the readily
available chiral diamine ligands. Furthermore,
presented method provides a facile access to a broad
range of highly functionalized enantioenriched β-
hydroxy esters with very good yields and high
[2] a) D. J. Ramón, M. Yus, Angew. Chem. Int. Ed. 2004, 43,
284–287; b) Y. L. Liu, X. T. Li, Adv. Synth. Catal. 2018,
361, 876–918.
enantioselectivities.
Although
the
reaction
diastereoselectivity is substrate-dependent and
requires further improvement, this efficient protocol
offers application of various aryl and heteroaromatic
ketones without the use of high-priced catalysts
previously reported.
[3] a) T. Shiomi, H. Nishiyama in Metal Catalyzed
Reductive C-C Bond Formation. Topics in Current
Chemistry, Vol. 279 (Eds.: M. J. Krische), Springer,
Berlin, Heidelberg, 2007, pp. 107–130; b) Y. Yamashita,
T. Yasukawa, W. J. Yoo, T. Kitanosono, S. Kobayashi,
Chem. Soc. Rev. 2018, 47, 4388–4480.
[4] For selected examples of rhodium-catalyzed reductive
aldol reaction with aldehydes, see: a) S. J. Taylor, M. O.
Duffey, J. P. Morken, J. Am. Chem. Soc. 2000, 122,
4
