F. Werner, N. Blank, T. Opatz
FULL PAPER
the warm solution. After cooling to 0 °C, formic acid/triethylamine
azeotrope (5:2, 0.5 mL) was added and the mixture was stirred for
3 h at ambient temperature. After addition of saturated aq. K2CO3
solution (9 mL) and water (6 mL), the reaction mixture was ex-
tracted with ethyl acetate (3ϫ15 mL) and the combined organic
layers were washed with brine and dried with Na2SO4. Removal of
the solvent in vacuo gave the crude product (156.3 mg) as a brown-
ish oil. A portion (45.6 mg) of this material was purified by column
chromatography (silica, petroleum ether/EtOAc/Et2NH 8:3:1, Rf =
0.13) to give 10b as a colorless oil (28.3 mg, 51.1%). [α]2D5 = +56.5
(c = 1, CHCl3); ref.[24] –59.5 (S enantiomer, c = 1, CHCl3). 1H
NMR (300 MHz, CDCl3): δ = 1.42 (d, J = 6.6 Hz, 3 H, CH3), 1.80
(br. s, 1 H, NH), 2.58–2.67, 2.72–2.82 (2 m, 2ϫ1 H, 4-Ha,b), 2.93–
3.02, 3.19–3.27 (2 m, 2ϫ1 H, 3-Ha,b), 3.83, 3.84 (2 s, 2ϫ3 H,
OCH3), 4.01 (q, J = 6.6 Hz, 1 H, 1-H), 6.55 (s, 1 H, 8-H), 6.61 (s,
1 H, 5-H) ppm. 13C NMR (75.5 MHz, CDCl3): δ = 22.8 (CH3),
29.5 (C-4), 41.8 (C-3), 51.2 (C-1), 55.8, 55.9 (OCH3), 109.0, 111.7
(C-5, C-8), 126.8, 132.4 (C-4a, C-8a), 147.2, 147.3 (C-6, C-7) ppm.
CDCl3): δ = 29.6 (C-4), 41.0, 42.3 (ArCH2, C-3), 55.83, 55.85, 55.9,
56.0 (OCH3), 56.9 (C-1), 109.3 (C-8), 111.3, 111.8, 112.4 (C-5, C-
2Ј, C-5Ј), 121.4 (C-6Ј), 127.5 (C-4a), 130.5 (C-8a), 131.5 (C-1Ј),
147.0, 147.4, 147.6, 148.9 (C-6, C-7, C-3Ј, C-4Ј) ppm. IR (film): ν
˜
= 3327, 3010, 2935, 2833, 1609, 1590, 1515, 1464 (sh), 1262, 1235
(sh), 1112, 1028 cm–1. FD-MS: m/z = 366.2 [M + Na]+ (75%),
344.2 [M + H]+ (100%). These data are in accordance with the
values reported in the literature.[7]
Determination of the enantiomeric excess was carried out by 1H
NMR spectroscopy after derivatization with (S)-(α)-methylbenzyl
isocyanate (er Ͼ 99.5:0.5). Enantiomeric ratio: 26.7:1, ee = 93%.
Supporting Information (see also the footnote on the first page of
this article): 1H and 13C NMR spectra, as well as HPLC chromato-
grams.
Acknowledgments
IR (film): ν = 3315, 2933 (sh), 2832, 1610, 1511, 1464 (sh), 1372,
˜
1293, 1256, 1223, 1118 (sh), 1030, 858, 790 cm–1.These data are in
accordance with the values reported in the literature.[34]
This work was supported by the Deutsche Forschungsgemeinschaft
(DFG) and the University of Mainz.
Determination of the enantiomeric excess was carried out by
derivatization with 2,3,4,6-tetra-O-acetyl-β--glucopyranosyl iso-
thiocyanate and analytical HPLC. Eluent CH3CN/H2O 35:65,
1 mLmin–1, Rt ((R) derivative): 64.7 min, Rt ((S) derivative):
68.0 min. Enantiomeric ratio = 20.9:1, ee = 91%.
[1] T. Henkel, R. M. Brunne, H. Müller, F. Reichel, Angew. Chem.
1999, 111, 688–691; Angew. Chem. Int. Ed. 1999, 38, 643–647.
[2] C. Kibayashi, Chem. Pharm. Bull. 2005, 53, 1375–1386.
[3] M. Chrzanowska, M. D. Rozwadowska, Chem. Rev. 2004, 104,
3341–3370.
(–)-(S)-Norlaudanosine (10c): A solution of KHMDS (301.6 mg, [4] V. G. Kartsev, Med. Chem. Res. 2004, 13, 325–336.
[5] K. W. Bentley, in Rodd’s Chemistry of Carbon Compounds, 2nd
ed., vol. 4 (Ed.: M. Sainsbury), Elsevier, Amsterdam, 1998, pp.
507–587.
1.51 mmol) in dry THF (2.3 mL) was added at –78 °C to a solution
of 6 (300 mg, 1.38 mmol) in dry THF (10.5 mL). After 4 min, a
solution of 3,4-dimethoxybenzyl bromide (333.6 mg, 1.44 mmol) in
dry THF (2.3 mL) was added. After stirring for 3 h at –78 °C, the
mixture was warmed to ambient temperature. As TLC indicated
incomplete conversion, another portion of KHMDS (274.2 mg,
1.38 mmol) in dry THF (2.3 mL) was added after 30 min and stir-
ring was continued for further 20 min. The reaction mixture was
poured into NaOH solution (1 , 45 mL) and the organic layer was
separated. The aqueous layer was extracted with CH2Cl2
(4ϫ25 mL) containing MeOH (10%).[35] The combined organic
layers were washed with a solution of NiCl2·6H2O (300 mg) in
water (30 mL), a solution of ammonia (10%, 30 mL), and brine
(30 mL). After drying over Na2SO4, the solvent was removed in
vacuo to yield the crude imine 8c as an orange oil (557.6 mg). Tri-
ethylamine (28.2 µL, 206 µmol) was added to a solution of
dichloro-p-cymene-ruthenium(II)-dimer (12.6 mg, 20.6 µmol) and
(1R,2R)-N-(4-tolylsulfonyl)-1,2-diphenylethylenediamine (15.2 mg,
41.2 µmol) in dry DMF (1.1 mL). The solution was degassed by
ultrasonication under a slow stream of argon and was subsequently
heated to 80 °C for 1 h.[36] The crude imine 8c, dissolved in de-
gassed dry DMF (3.8 mL), was added to the warm solution. After
cooling to 0 °C, formic acid/triethylamine azeotrope (5:2, 0.72 mL)
was added and the mixture was stirred for 4.5 h at ambient tem-
perature. Saturated aq. K2CO3 solution (9 mL) and water (6 mL)
were added and the mixture was extracted with ethyl acetate
(3ϫ10 mL). The combined organic layers were dried with Na2SO4
and the solvent was removed in vacuo to furnish a slightly brown
oil (514 mg), which was purified by column chromatography (silica,
eluent petroleum ether/EtOAc/Et2NH 8:2:1, Rf = 0.20) to give 10c
as a light yellow oil (368.1 mg, 77.9%). [α]2D5 = –21.9 (c = 1, CHCl3);
[6] K. W. Bentley, Nat. Prod. Rep. 2005, 22, 249–268.
[7] D. Mujahidin, S. Doye, Eur. J. Org. Chem. 2005, 2689–2693.
[8] D. Seebach, D. Enders, Angew. Chem. 1975, 87, 1–18; Angew.
Chem. Int. Ed. Engl. 1975, 14, 15–32.
[9] G. Stork, R. M. Jacobson, R. Levitz, Tetrahedron Lett. 1979,
9, 771–774.
[10] D. Enders, J. P. Shilvock, Chem. Soc. Rev. 2000, 29, 359–373.
[11] W. von Miller, J. Plöchl, Ber. Dtsch. Chem. Ges. 1898, 31, 2718–
2720.
[12] N. Meyer, F. Werner, T. Opatz, Synthesis 2005, 945–956.
[13] N. Meyer, T. Opatz, Eur. J. Org. Chem. 2006, 3997–4002.
[14] C. Kison, T. Opatz, Synthesis 2006, 3727–3738.
[15] C. Kison, N. Meyer, T. Opatz, Angew. Chem. 2005, 117, 5807–
5809; Angew. Chem. Int. Ed. 2005, 44, 5662–5664.
[16] T. Opatz, D. Ferenc, Org. Lett. 2006, 8, 4473–4475.
[17] J.-M. Mattalia, C. Marchi-Delapierre, H. Hazimeh, M.
Chanon, ARKIVOC 2006, 90–118.
[18] J. M. Brunel, Rect. Res. Devel. Org. Chem. 2003, 7, 155–190.
[19] J. Kobor, K. Koczka, Szegedi Tanarkepzo Foiskola Tudomanyos
Kozlemenyei 1969, 179–183.
[20] A. Bischler, B. Napieralski, Ber. Dtsch. Chem. Ges. 1893, 26,
1903–1908.
[21] T. Kanemitsu, Y. Yamashita, K. Nagata, T. Itoh, Synlett 2006,
1595–1597.
[22] K. Yamada, M. Takeda, T. Iwakuma, Tetrahedron Lett. 1981,
22, 3869–3872.
[23] S. Philipov, N. Ivanovska, R. Istatkova, M. Velikova, P. Tuleva,
Pharmazie 2000, 55, 688–689.
[24] A. R. Hajipour, M. Hantehzadeh, J. Org. Chem. 1999, 64,
8475–8478.
[25] N. Uematsu, A. Fujii, S. Hashiguchi, T. Ikariya, R. Noyori, J.
Am. Chem. Soc. 1996, 118, 4916–4917.
[26] J. B. Perales, F. Makino Narubumi, D. L. Van Vranken, J. Org.
Chem. 2002, 67, 6711–6717.
1
ref.[37] –21 (c = 1, CHCl3). H NMR (400 MHz, CDCl3): δ = 1.66
(br. s, 1 H, NH), 2.61–2.73, 2.77–2.92 (2 m, 2ϫ2 H, ArCH2, 4-
H2), 3.12–3.22 (m, 2 H, 3-H2), 3.81, 3.83, 3.83, 3.85 (4 s, 4ϫ3 H,
OCH3), 4.09 (mc, 1 H, 1-H), 6.57, 6.64 (2 s, 2ϫ1 H, 5-H, 8-H),
[27] M. Pinza, L. Dorigotti, G. Pifferi, Eur. J. Med. Chem. 1976,
11, 395–398.
6.73–6.82 (m, 3 H, 2Ј-H, 5Ј-H, 6Ј-H) ppm. 13C NMR (100.6 MHz, [28] H. Ogura, H. Takahashi, Heterocycles 1982, 17, 87–90.
3914
www.eurjoc.org
© 2007 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
Eur. J. Org. Chem. 2007, 3911–3915
