Photochemical and thermal synthesis and characterization of
polypyridine ruthenium(II) complexes containing different
monodentate ligands†
Sylvestre Bonnet,a Jean-Paul Collin,*a Nathalie Gruber,b Jean-Pierre Sauvagea and
Emma R. Schofield‡a
a Laboratoire de Chimie Organo-Minérale, UMR 7513 du CNRS, Université Louis Pasteur,
Faculté de Chimie, 4, rue Blaise Pascal, 67070 Strasbourg Cedex, France
b Service Commun des rayons X, Université Louis Pasteur, Faculté de Chimie, 4,
rue Blaise Pascal, 67070 Strasbourg Cedex, France. E-mail: jpcollin@chimie.u-strasbg.fr
Received 26th August 2003, Accepted 23rd October 2003
First published as an Advance Article on the web 10th November 2003
The photochemical and thermal synthesis of a series of [Ru(tpy)(phen)L]2ϩ complexes where terpy = 2,2Ј:6Ј,2Љ–
terpyridine (terpy) or 4-(3,5-di-tert-butyl)phenyl-2,2Ј;6Ј,2Љ-terpyridine (terpy*), phen = 1,10-phenanthroline and L
monodentate ligands such as ClϪ, NCϪ, CH3CN, pyridine, isoquinoline (iq), 4-dimethylaminopyridine (dmap),
4-(4Ј-methylpyridinium)pyridine (mqt), phenothiazine (ptz), 3,5-lutidine(lut) and H2O are described. The complexes
have been characterized by 1H (COSY and ROESY) NMR spectroscopy, mass spectrometry (FAB and ES-MS),
cyclic voltammetry, UV-vis absorption and emission spectroscopy and single-crystal X-ray diffraction.
Photochemical experiments have shown that the ligands L can be photochemically expelled and replaced by CH3CN
molecules used as solvent. This type of ligand interchange occurs efficiently and very selectively. The reaction has the
potential to be applied to a wide range of entering ligands (thioethers, ethers, pyridines, sulfoxides, nitriles, amides)
and indicates the high stability of the Ru(terpy)(phen) core under the irradiation conditions.
is probably the result of the conjunction of unfavourable
Introduction
parameters such as low quantum yields and poor selectivity.
Current interest in the chemistry and particularly in the photo-
A few representative examples11 involve the Ru(bidentate)2
chemistry of ruthenium() complexes arises from their poten-
core, one of the most frequently used chemical subunits in
ruthenium() chemistry. In this work, photochemical and
thermal reactions have both been employed to prepare
tial use in solar energy conversion processes,1 or as components
of luminescent sensors,2 light emitting diodes3 and more gener-
ally photoswitchable molecular devices.4 In this latter field,
ruthenium complexes in good yields. The classical thermal
reversible light-driven reactions such as photoisomerisation5 or
route described in the literature12 allows the preparation of the
photosubstitution6 occurs and could permit the control of
intermediate compounds Ru(terpyridine)Cl3, [Ru(terpyrid-
large amplitude motion in specially designed systems.7 In
ine)(phen)Cl]ϩ and [Ru(terpyridine)(phen)(CH3CN)]2ϩ as well
our efforts to develop molecular machines which operate under
light irradiation, we recently described different ruthenium
as the complex 10 (terpyridine = terpy or terpy*). Chart 1 gives
the chemical formulae of the compounds synthesized.
systems based on the expulsion of bipyridine or pyridine
By reaction with AgBF4, the precursor of the type [Ru(terpy)-
ligands.8 As already demonstrated in several ruthenium com-
plexes, the excitation of the MLCT band allows the thermal
(phen)Cl]ϩ leads to compounds 2 and 9, conducting the reac-
tion in acetonitrile–H2O or acetone–H2O mixture, respectively.
Surprisingly, these reaction conditions afforded also, in the
population of low-lying d–d states from the MLCT excited
state and subsequent expulsion of the weaker ligand.9 In the
case of 2, a by-product which was identified as [Ru(terpy)-
[Ru(terpy)(6,6Ј-dmbp)L]2ϩ type complex (terpy = 2,2Ј:6Ј,2Љ-
(phen)(CN)]ϩ by determining its X-ray structure. The condi-
terpyridine, 6,6Ј-dmbp = 6,6Ј-dimethyl-2,2Ј-bipyridine) where L
tions of formation of this compound remain unclear at the
moment. In order to avoid this side reaction some photo-
is acetonitrile or pyridine,8b a reversible interchange of ligand
occurs efficiently and quantitatively. In this paper we will extend
the previous study to a series of L ligands including iso-
quinoline (iq), 4-dimethylaminopyridine (dmap), 4-(4Ј-methyl-
pyridinium)pyridine (mqt), phenothiazine (ptz), 3,5-lutidine
(lut) and H2O in complexes containing 1,10-phenanthroline
and two types of terpyridine: terpy and 4-(3,5-di-tert-butyl)-
phenyl-2,2Ј;6Ј,2Љ-terpyridine (terpy*).
chemical attempts were made starting from [Ru(terpy)-
(phen)Cl]ϩ. Irradiation of 1 in CH3CN–H2O mixture with
white light from a slide projector led to 2 without an isolable
amount of 3. This method turned out to be very efficient and
compounds 4–8 have been prepared using 10 equivalents excess
of the ligand L in deoxygenated acetone. The only exception
was the synthesis of 4 which was carried out in neat pyridine.
Crystal structures
Results and discussion
The structures of each of the ten cationic complexes have been
determined by X-ray crystallography at 173 K. The ORTEP
Synthesis
diagrams of compounds 1–10 are shown in Fig. 1.
Selected bond lengths and bond angles are given in Tables
1–4.
Photochemical methods for preparing polypyridine ruthenium
complexes are relatively scarce in the literature.10 This situation
A number of structures have been published with the general
formula [Ru(terpy)(N–N)L]nϩ where N–N is bipyridine,9a,13 bi-
quinoline,14 or bipyrazine15 and L is a monodentate ligand.
Only one structure involves a phenanthroline derivative16 as
bidentate ligand and this is the first time that a systematic series
† Electronic supplementary information (ESI) available: View of the
dimeric units of 8 and proton indexation used in the 1H NMR data. See
http://www.rsc.org/suppdata/dt/b3/b310198c/
‡ Present address: Department of Chemistry, Trinity College, College
Green, Dublin 2, Ireland.
D a l t o n T r a n s . , 2 0 0 3 , 4 6 5 4 – 4 6 6 2
T h i s j o u r n a l i s © T h e R o y a l S o c i e t y o f C h e m i s t r y 2 0 0 3
4654

View Article Online
Chart 1
Table 1 Bond lengths (Å) from the ruthenium ion to the coordinating
atoms for the complexes 1 to 5
Table 2 Bond lengths (Å) from the ruthenium ion to the coordinating
atoms for the complexes 6–10
1
2
3
4
5
6
7
8
9
10
Ru–N1
Ru–N2
Ru–N3
Ru–N4
Ru–N5
Ru–La
2.105(2)
2.051(3)
2.074(3)
1.961(2)
2.084(3)
2.4180(8)
2.093(4)
2.054(4)
2.081(4)
1.973(4)
2.075(4)
2.041(5)
2.104(2)
2.121(2)
2.076(2)
1.973(2)
2.090(2)
2.004(3)
2.112(4)
2.074(4)
2.088(4)
1.981(4)
2.078(4)
2.113(4)
2.107(4)
2.060(4)
2.057(4)
1.953(4)
2.082(4)
2.091(4)
Ru–N1
Ru–N2
Ru–N3
Ru–N4
Ru–N5
Ru–La
2.111(2)
2.062(2)
2.079(2)
1.967(2)
2.079(3)
2.107(2)
2.104(8)
2.069(8)
2.068(9)
1.956(8)
2.056(9)
2.375(3)
2.101(9)
2.049(8)
2.072(8)
1.951(9)
2.072(9)
2.100(8)
2.072(6)
2.024(6)
2.066(7)
1.966(6)
2.077(6)
2.142(5)
2.106(4)
2.056(4)
2.070(4)
1.963(4)
2.068(4)
2.118(4)
a L = Cl for 1; L = C28 for 3 and L = N6 for 2, 4 and 5.
a L = S for 7; L = O1 for 9 and L = N6 for 6,8 and 10.
of structures has been investigated. In all the structures of the
present series, the Ru() ions are in pseudo-octahedral
environments with noticeable asymmetric bond distances to the
different coordinated atoms. Characteristic of the Ru()–terpy-
ridine complexes, the Ru()–nitrogen bond to the central
pyridine is shorter than those to the outer two pyridines by 0.1–
0.12 Å, as a result of the steric constraint imposed by the tri-
dentate ligand. For a similar reason, the bite angle between the
metal and the two outer pyridine rings of the terpy is 158.6–
159.3Њ, i.e. significantly smaller than the 180Њ required for ideal
octahedral geometry. Only minor variations in the Ru–N(terpy)
bond lengths are observed throughout the series, none of which
suggest any significant perturbation by ligand L.
length is 2.067 Å.17 However, looking at this structure in more
detail it is apparent that one of the three phen ligands has one
short and one long bond to the Ru(), 2.058 and 2.082 Å,
respectively. This is as a result of steric congestion around the
metal centre. In the series of structures presented here the two
Ru()–N(phen) bond lengths are also noticeably different:
between the elongated Ru–N bond lengths (2.093–2.112 Å) and
the standard axial bond lengths (2.049–2.074 Å) a difference of
0.038–0.052 Å is observed in all complexes except 3. The obser-
vation of one shorter and one longer Ru()–N(phen) bond in
complexes such as these was originally made for [Ru(terpy)-
(bpy)(py)]2ϩ, in which the difference between the Ru–N bond
lengths in the bpy ligand is about 0.04 Å. In this complex, as
well as in the novel series discussed here, the longer bond is the
one trans to the central pyridine of the terpy ligand.9a This is
A more significant variation is observed in the Ru–N(phen)
bond lengths. In [Ru(phen)3]2ϩ the average Ru–N(phen) bond
