SYNTHETIC COMMUNICATIONSw
Vol. 34, No. 12, pp. 2215–2221, 2004
Microwave Assisted Condensation
of Aromatic Methyl Groups with
Aromatic Aldehydes
Kasper Moth-Poulsen,1,2 Theis Reenberg,1
Thomas Bjørnholm,2 and Jørn B. Christensen1,
*
1Chemical Laboratory II, Department of Chemistry and
2Nano-Science Center, University of Copenhagen, Denmark
ABSTRACT
Aromatic aldehydes are condensed with 2,4-dinitro-1,5-dimethylbenzene
in a Siegrist type coupling. The reported method features micro-
wave irradiation, solvent-free conditions, and a catalytic amount of
piperidine to give a high yield of the corresponding 1,3-bisstyryl-4,6-
dinitrobenzenes within a few minutes.
Key Words: Microwave irradiation; Solvent-free conditions; Distyryl
benzenes.
*
Correspondence: Jørn B. Christensen, Chemical Laboratory II, Department of
Chemistry, University of Copenhagen, Universitetsparken 5, DK-2100, Copenhagen,
Denmark; E-mail: jbc@kiku.dk.
2215
DOI: 10.1081/SCC-120038503
0039-7911 (Print); 1532-2432 (Online)
www.dekker.com
Copyright # 2004 by Marcel Dekker, Inc.

ORDER
REPRINTS
2216
Moth-Poulsen et al.
INTRODUCTION
Conjugated aryl alkenes have over the last decade proven their usefulness
as new materials for molecular electronics and non-linear optics.[1–4] In
connection with an ongoing project, a number of substituted bisstyryl dinitro-
benzenes were needed. The p-methoxystyryl member of this series was a
known compound. The classical synthesis proceeds under solvent-free
conditions by heating a mixture of anisaldehyde 2a and dinitroxylene 1 in
the presence of a catalytic amount of piperidine.[5] However, the long reaction
times and the somewhat low yields made a more efficient synthesis desirable.
Microwave-assisted organic synthesis is a technique, which has been shown
to be highly useful for thermal reactions.[6–8] The homogenous nature of micro-
wave heating allows a fast heating of a reaction mixture without local overheating
at the walls of the reaction flask. This can be a problem especially in the case of a
viscous reaction mixture. There is, however, still an ongoing debate in the literature
concerning whether a specific, non-thermal “microwave effect” exists or not.[9]
RESULTS AND DISCUSSION
The use of microwave heating on the neat reaction mixture of 1,5 dinitro-
m-xylene 1 and a number of aldehydes (2a–h) afforded the corresponding
bisstyryl benzenes (3a–h) in good to acceptable yields (36–90%) (Sch. 1).
Typically, the reaction were heated at 350 W for 3 min and then allowed to
cool for 15 min, the heating was repeated 1–3 times. The crude reaction mix-
ture was purified by dry column chromatography.[10] This procedure gave
(E,E)-1,3-bis(4-methoxystyryl)-4,6-dinitrobenzene, 3a in 90% yield (the use
of conventional heating as reported by Ruggli Zimmermann,[5] afforded typi-
cally 40%). The condensation of aldehydes 2b–h afforded the new bisstyryl
benzenes 3b–h in 32–82% yield (Table 1). The condensation of aldehyde
2h yielded additional 27% of the mono adduct (E)-1-(dimethylaminostyryl)-
3-methyl-4,6-dinitrobenzene 3i (Sch. 2).
Scheme 1.

ORDER
REPRINTS
Microwave Assisted Condensation of Aromatic Methyl Groups
2217
Table 1. Chemical yields of dinitro bisstyryl benzenes upon reaction of 1,5 dinitro-m-
xylene with different aldehydes (2a–h).
Irradiation
time (min)a
Yield
(%)
Entry
Aldehyde
Dinitro bisstyryl benzene
a
3 ꢀ 3
90
82
54
b
c
2
2 ꢀ 3
d
3 ꢀ 3
75
e
f
3 ꢀ 3
3 ꢀ 3
54
82
g
3 ꢀ 3
3 ꢀ 3
73
h
32b
aThe reaction mixture was typically heated for 3 ꢀ 3 min and allowed to cool for
15 min between each heating.
bThe condensation of aldehyde 2h yielded additional 27% of the mono adduct (E)-1-
(dimethylaminostyryl)-3-methyl-4,6-dinitrobenzene 3i (Sch. 2).

ORDER
REPRINTS
2218
Moth-Poulsen et al.
Scheme 2.
CONCLUSION
A general method for the condensation of nitroxylenes with aromatic
carbonyl compounds by microwave irradiation has been developed. The reac-
tion times are considerably shorter than under the classical conditions and the
yields are satisfactory.
EXPERIMENTAL
Melting points were recorded on a hot stage calibrated using a set of
Reichert calibration substances. NMR spectra were recorded on a Bruker
AM250 or a Varian Unity 400 spectrometer. Mass spectra were recorded on
a 4 sector Jeol HX110/HX110. CHN analysis was recorded on a Carlo Elba
FLASH 1112 apparatus. The microwave irradiation was carried out using a
converted domestic microwave oven (OBH type 7510) operated at 350 W
(2450 MHz). The reaction flask was linked to an outside refluxing column
as described by Baghurst and Mingos.[7]
General Procedure
A 2 mmol (0.392 g) of 1,5-dinitro-m-xylene (1), 4 mmol of aldehyde
2a–h (all commercially available except 2f, which were prepared according
to published procedure[11]) and three drops of piperidine were typically heated
for 3 ꢀ 3 min at 350 W (allowed to cool for 15 min between each heating).
The resulting material was purified using dry column chromatography. The
resulting product was recrystallised from toluene.
(E,E)-1,3-bis(4-Methoxystyryl)-4,6-dinitrobenzene (3a). Yield: 90%.
1
Solid, m.p. 179.6–180.68C (litt.[5] 1798C); H NMR (CDCl3, 250 MHz) d:
3.8 (s, 6H), 6.9 (d, J ¼ 8.3 Hz, 4H), 7.2 (d, J ¼ 16.6 Hz, 2H), 7.5
(d, J ¼ 8.3 Hz, 4H), 7.55 (d, J ¼ 16.6 Hz, 2H), 8.0 (s, 1H), 8.64 (s, 1H); 13C
NMR (CDCl3, 62.9 MHz) d: 55.3, 114.4, 119.7, 122.8, 127.0, 128.5, 129.0,
136.7, 137.9, 144.6, 160.8.
EIMS: (m/z, relative intensity): 432 (Mþ, 98), 279 (40), 160 (50), 135
(64), 121 (100). UV-VIS (acetonitrile): 1387 ¼ 3.1 ꢀ 104 mol21 cm21
.

ORDER
REPRINTS
Microwave Assisted Condensation of Aromatic Methyl Groups
2219
(E,E)-1,3-bis(2,4-Dimethoxystyryl)-4,6-dinitrobenzene (3b). Yield:
82%. Solid, m.p. 207.1–208.78C; 1H NMR (CDCl3, 250 MHz) d: 3.79 (s, 6H),
3.84 (s, 6H), 6.43 (d, J ¼ 2.4 Hz, 2H), 6.5 (dd, J1 ¼ 2.4 Hz, J2 ¼ 9.0 Hz, 2H),
7.48 (d, J ¼ 16.2 Hz, 2H), 7.50 (d, J ¼ 8.5 Hz, 2H), 7.61 (d, J ¼ 16.2 Hz, 2H),
8.02 (s, 1H), 8.61 (s, 1H). 13C NMR (CDCl3, 62.9 MHz) d: 55.4, 55.5, 98.4,
105.3, 118.1, 120.1, 122.7, 127.1, 128.9, 132.0, 138.5, 144.3, 158.9, 162.0.
EIMS m/z (relative intensity): 492 (Mþ, 100), 309 (20), 165 (30). HRMS
(Mþ) calcd. 492.1533. Found 492.1544. Anal. calcd. for C26H24N2O8: C
63.41; H 4.91; N 5.69. Found C 63.32; H 4.83; N 5.73. UV-VIS (acetonitrile):
1403 ¼ 2.7 ꢀ 104 mol21 cm21
.
(E,E)-1,3-bis(3,5-Dimethoxystyryl)-4,6-dinitrobenzene (3c). Yield:
54%. Solid, m.p. 197.0–199.38C; 1H NMR (CDCl3, 250 MHz) d: 3.78
(s, 12H), 6.43 (t, J ¼ 2.3 Hz, 2H), 6.67 (d, J ¼ 2.3 Hz, 4H), 7.17
(d, J ¼ 16.0 Hz, 2H), 7.60 (d, J ¼ 16.1 Hz, 2H), 7.98 (s, 1H), 8.66 (s, 1H).
13C NMR (CDCl3, 62.9 MHz) d: 55.4, 101.7, 105.4, 122.5, 122.6, 128.0,
137.2, 137.5, 145.1, 161.1. FABþMS (m/z, relative intensity): 493 (MHþ,
4), 460 (3), 307 (20), 154 (100). HRMS (MHþ) calcd. 493.1611, found
493.1613. UV-VIS (acetonitrile): 1341 ¼ 2.7 ꢀ 104 mol21 cm21
.
(E,E)-1,3-bis(3,4,5-Trimethoxystyryl)-4,6-dinitrobenzene (3d). Yield:
75%. Solid, m.p. 122–1238C. 1H NMR (CDCl3, 250 MHz) d: 3.68 (s, 6H), 3.70
(s, 12H), 6.72 (s, 4H), 8.54 (d, J ¼ 8 Hz, 2H), 8.56 (s, 1H), 8.67 (d, J ¼ 8 Hz,
2H,), 9.80 (s, 1H). 13C NMR (CDCl3, 62.9 MHz) d: 39.4, 56.1, 56.3, 104.7,
105.0, 105.3, 120.5, 122.3, 131.0, 132.6, 137.2, 138.1, 139.4, 153.4.
Anal. calcd. for C28H28N2O10: C 60.87; H 5.11; N 5.07, found C 60.91; H
5.16; N 4.99. UV-VIS (acetonitrile): 1381 ¼ 1.4 ꢀ 104 mol21 cm21
.
(E,E)-1,3-bis(2,4,6-Trimethoxystyryl)-4,6-dinitrobenzene (3e). Yield:
1
56%. Solid, m.p. 189–1908C. H NMR (CDCl3, 250 MHz) d: 3.82 (s, 6H),
3.84 (s, 12H), 6.08 (s, 4H), 7.66 (d, J ¼ 16 Hz, 2H), 7.92 (s, 1H), 7.97
(d, J ¼ 16 Hz, 2H), 8.57 (s, 1H). 13C NMR (CDCl3, 62.9 MHz) d: 21.1,
55.3, 55.7, 90.5, 107.0, 121.4, 122.2, 128.7, 131.2, 138.4, 139.8, 145.4,
160.4, 162.1. Anal. calcd. for C28H28N2O10: C 60.87; H 5.11; N 5.07.
Found: C 60.93; H 5.05; N 5.06. UV-VIS (acetonitrile): 1417 ¼ 2.8 ꢀ
104 mol21 cm21
.
(E,E)-1,3-bis(2,5-Dimethoxy-4-methyl-styryl)-4,6-dinitrobenzene
(3f). Yield: 82%. Solid, m.p. 161–1638C. 1H NMR (CDCl3, 250 MHz) d: 2.10
(s, 6H), 3.80 (s, 12H), 6.65 (s, 2H), 7.0 (s, 2H), 7.50 (d, J ¼ 16 Hz, 2H), 7.60
(d, J ¼ 16 Hz, 2H), 8.00 (s, 1H), 8.60(s, 1H). 13C NMR (CDCl3, 62.9 MHz)
d: 16.6, 55.8, 56.1, 108.6, 114.4, 121.2, 121.6, 122.4, 122.6, 127.6, 128.9,
130.1, 132.2, 138.3, 144.5, 151.7, 152.0. HRMS (Mþ) calcd. 520.1846,
found 520.1842. UV-VIS (acetonitrile): 1413 ¼ 1.7 ꢀ 104 mol21 cm21
.
(E,E)-1,3-bis(2,3,4,5,6-Pentamethylstyryl)-4,6-dinitrobenzene (3g).
1
Yield: 73% Solid. m.p. 152–1538C. H NMR (CDCl3, 250 MHz) d: 2.10

ORDER
REPRINTS
2220
Moth-Poulsen et al.
(m, 30H), 6.9 (d, 2H J ¼ 8 Hz), 7.3 (s, J ¼ 8 Hz, 2H), 8.1 (s, 1H) 8.7 (s, 1H).
13C NMR (CDCl3, 62.9 MHz) d: 15.1, 15.6, 15.9, 16.6, 17.0, 121.3, 127.3,
127.7, 130.5, 131.9, 132.6, 134.1, 137.3, 144.1. HRMS (Mþ) calcd.
512.2675, found 512.2675. UV-VIS (acetonitrile): 1338 ¼ 1.5 ꢀ
104 mol21 cm21
.
(E,E)-1,3-bis(-Dimethylaminostyryl)-4,6-dinitrobenzene (3h). Yield
1
32%. Solid, m.p. 170–1738C. H NMR (CDCl3, 400 MHz) d: 2.98 (s, 12H),
6.64 (d, J ¼ 9.2 Hz, 4H), 7.17 (d, J ¼ 15.3 Hz 2H), 7.42 (d, J ¼ 9.2 Hz,
4H), 7.46 (d, J ¼ 15.3 Hz, 2H), 7.97 (s, 1H), 8.59 (s, 1H). 13C NMR
(CDCl3, 62.9 MHz) d: 40.1, 111.9, 116.9, 123.1, 123.9, 125.7, 129.0, 137.4,
138.2, 143.5, 151.2. FABþMS (m/z, relative intensity): 458 (Mþ, 10), 307
(30). Anal. calcd. for C26H26N4O4: C 68.11; H 5.72; N 12.22, found C
68.15; H 5.62 N 12.13. UV-VIS (acetonitrile): 1467 ¼ 3.6 ꢀ 104 mol21 cm21
.
(E)-1-(Dimethylaminostyryl)-3-methyl-4,6-dinitrobenzene (3i). Yield
27% (byproduct). Solid, m.p. 185.0–185.68C. 1H NMR (CDCl3, 400 MHz) d:
2.74 (s, 3H), 3.05 (s, 6H), 7.21 (d, J ¼ 16.1 Hz, 1H), 7.47 (d, J ¼ 7.88 Hz, 2H),
7.48, (d, J ¼ 16.1 Hz, 1H), 7.72 (s, 1H), 8.69 (s, 1H). 13C NMR (CDCl3,
62.9 MHz) d: 21.2, 40.1, 111.9, 115.7, 122.5, 123.6, 129.1, 131.0, 138.1,
138.6, 144.5, 145.4, 151.3 (13 of 14 expected signals after 19,100 scans).
FABþMS (m/z, relative intensity): 327 (Mþ, 25). Anal. calcd. for
C17H17N3O4: C 62.38; H 5.23; N 12.84, found C 62.25; H 5.12, N 12.70.
UV-VIS (acetonitrile): 1459 ¼ 2.2 ꢀ 104 mol21 cm21
.
REFERENCES
1. Tiemann, B.G.; Marder, S.R.; Perry, J.W.; Cheng, L.T. Molecular and
macroscopic second-order optical nonlinearities of substituted dinitrostil-
benes and related compounds. Chem. Mater. 1990, 2, 690.
2. Cho, B.R.; Lee, S.J.; Lee, S.H.; Son, K.H.; Kim, Y.H.; Doo, J.Y.;
Lee, G.J.; Kang, T.I.; Lee, Y.K.; Cho, M.H.; Jeon, S.J. Octupolar crystals
for nonlinear optics: 1,3,5-trinitro-2,4,6-tris(styryl)benzene derivatives.
Chem. Mater. 2001, 13, 1438.
3. Cho, B.R.; Lee, S.H.; Lim, J.C.; Kang, T.I.; Jeon, S.J. First hyperpolariz-
abilities of stilbenes derivatives. Mol. Cryst. Liq. Cryst. 2001, 370, 77.
4. Stuhr-Hansen, N.; Christensen, J.B.; Harrit, N.; Bjornholm, T. Novel syn-
thesis of protected thiol end-capped stilbenes and oligo(phenylenevinyl-
ene)s (OPVs). J. Org. Chem. 2002, 68, 1275.
5. Ruggli, P.; Zimmermann, A.; Thouvay, R. Condensation products of dini-
troxylene and aldehydes. Helv. Chim. Acta 1931, 14, 1250.
6. Baghurst, D.R.; Mingos, D.M.P. Superheating effects associated with
microwave dielectric heating. Chem. Commun. 1992, 674.

ORDER
REPRINTS
Microwave Assisted Condensation of Aromatic Methyl Groups
2221
7. Baghurst, D.R.; Mingos, D.M.P. Design and application of a reflux modi-
fication for the synthesis of organometallic compounds using microwave
dielectric loss heating effects. J. Organomet. Chem. 1990, 384, 57.
8. Kingston, H.M.; Haswell, S.J. Microwave-Enhanced Chemistry: Funda-
mentals, Sample Preparation and Applications; American Chemical
Society: Washington, D.C., 1997.
9. Kuhnert, N. Microwave-assisted reactions in organic synthesis—are there
any nonthermal microwave effects? Angew. Chem. Int. Edit. 2002, 41,
1863.
10. Pedersen, D.S.; Rosenbohm, C. Dry column vacuum chromatography.
Synthesis-Stuttgart 2001, 2431.
11. Lewin, A.H.; Parker, S.R.; Fleming, N.B.; Carroll, F.I. Formylation of
arenes by a,a-dichloromethyl methyl ether. An improved experimental
procedure. Org. Prep. Proced. Intl. 1978, 10, 201.
Received in the UK November 11, 2003

Request Permission or Order Reprints Instantly!
Interested in copying and sharing this article? In most cases, U.S. Copyright
Law requires that you get permission from the article’s rightsholder before
using copyrighted content.
All information and materials found in this article, including but not limited
to text, trademarks, patents, logos, graphics and images (the "Materials"), are
the copyrighted works and other forms of intellectual property of Marcel
Dekker, Inc., or its licensors. All rights not expressly granted are reserved.
Get permission to lawfully reproduce and distribute the Materials or order
reprints quickly and painlessly. Simply click on the "Request Permission/
Order Reprints" link below and follow the instructions. Visit the
U.S. Copyright Office for information on Fair Use limitations of U.S.
copyright law. Please refer to The Association of American Publishers’
Fair Use in the Classroom.
(AAP) website for guidelines on
The Materials are for your personal use only and cannot be reformatted,
reposted, resold or distributed by electronic means or otherwise without
permission from Marcel Dekker, Inc. Marcel Dekker, Inc. grants you the
limited right to display the Materials only on your personal computer or
personal wireless device, and to copy and download single copies of such
Materials provided that any copyright, trademark or other notice appearing
on such Materials is also retained by, displayed, copied or downloaded as
part of the Materials and is not removed or obscured, and provided you do
not edit, modify, alter or enhance the Materials. Please refer to our
Website
User Agreement for more details.
Request Permission/Order Reprints
Reprints of this article can also be ordered at
http://www.dekker.com/servlet/product/DOI/101081SCC120038503
