3,5-Dialkyl effect on enantioselectivity in Pd chemistry: Applications involving both bidentate and monodentate auxiliaries

Article abstract of DOI:10.1021/om034381b

The structural 3,5-dialkylphenyl effect on enantioselectivity is demonstrated for several Pd-catalyzed reactions including a ring-opening transmetalation, Heck arylation, and allylic alkylation. For these homogeneously catalyzed reactions the observed enantiomeric excesses (ee's) are found to improve by more than 15%. The ligands tested include MeO-Biphep and a P,N-phosphino-oxazoline-bidentate ligand containing 3,5-di-tert-butylphenyl substituents. Further, several derivatives of the monodentate auxiliary MOP (CR)-2-diarylphosphino-1,1′-binaphthyl) have been modified to include 3,5-dialkylphenyl substituents and these auxiliaries have been tested in Pd-catalyzed enantioselective hydrosilylation chemistry. For some, but not all of these MOP ligands, enhanced ee's of the order of 40-50% are found. Variable-temperature and 2-D NMR studies have been carried out on new model complexes and reveal selected restricted rotation around a number of the P-C(ipso) aryl bonds. Solid-state structures for two of the new complexes, PdBrCp-NCCeHUXphosphino-oxazoline, 2b), 8b, and PdCl(C₆H ₄CH₂NMe₂)(MOP, 4b), 9b, have been determined.

Full text of DOI:10.1021/om034381b

Organometallics 2004, 23, 2295-2304
2295
3,5-Dia lk yl Effect on En a n tioselectivity in P d Ch em istr y:
Ap p lica tion s In volvin g Both Bid en ta te a n d Mon od en ta te
Au xilia r ies
Pascal Dotta, P. G. Anil Kumar, and Paul S. Pregosin*
Laboratory of Inorganic Chemistry, ETHZ, 8093 Zu¨rich, Switzerland
Alberto Albinati* and Silvia Rizzato
Department of Structural Chemistry (DCSSI) and Faculty of Pharmacy, University of Milan,
20133 Milan, Italy
Received December 17, 2003
The structural 3,5-dialkylphenyl effect on enantioselectivity is demonstrated for several
Pd-catalyzed reactions including a ring-opening transmetalation, Heck arylation, and allylic
alkylation. For these homogeneously catalyzed reactions the observed enantiomeric excesses
(ee’s) are found to improve by more than 15%. The ligands tested include MeO-Biphep and
a P,N-phosphino-oxazoline-bidentate ligand containing 3,5-di-tert-butylphenyl substituents.
Further, several derivatives of the monodentate auxiliary MOP ((R)-2-diarylphosphino-1,1′-
binaphthyl) have been modified to include 3,5-dialkylphenyl substituents and these
auxiliaries have been tested in Pd-catalyzed enantioselective hydrosilylation chemistry. For
some, but not all of these MOP ligands, enhanced ee’s of the order of 40-50% are found.
Variable-temperature and 2-D NMR studies have been carried out on new model complexes
and reveal selected restricted rotation around a number of the P-C(ipso) aryl bonds. Solid-
state structures for two of the new complexes, PdBr(p-NCC6H4)(phosphino-oxazoline, 2b),
8b, and PdCl(C6H4CH2NMe2)(MOP, 4b), 9b, have been determined.
In tr od u ction
the auxiliary (instead of the routine phenyl substituent)
enhances the ee’s in Heck and allylic alkylation chem-
istry. Specifically, we have used MeO-Biphep, 1,12 and
the phosphino-oxazolines, 2 (see Scheme 1),13,14 in the
There are now a number of readily available bidentate
chiral auxiliaries capable of achieving enantiomeric
excesses (ee’s) in excess of 90%, for a variety of enan-
tioselective transformations. The ligands Duphos1-3 and
Binap4 have been relatively successful in enantioselec-
tive homogeneous hydrogenation, whereas the TAD-
DOL5 series has been employed successfully in C-C
bond making reactions. Many chelating oxazoline
derivatives,6-11 with and without tertiary phosphine
donors, are now widely employed in a variety of catalytic
reactions.
(5) Seebach, D.; Plattner, D. A.; Beck, A. K.; Wang, Y. M.; Hunziker,
D.; Petter, W. Helv. Chim. Acta 1992, 75, 2171-2207. Ito, Y. N.; Ariza,
X.; Beck, A. K.; Bohac, A.; Ganter, C.; Gawley, R. E.; Ku¨hnle, F. N.
M.; Tuleja, J .; Seebach, D. Helv. Chim. Acta 1994, 77, 2071-2110.
Seebach, D.; J aeschke, G.; Pichota, A.; Audergon, L. Helv. Chim. Acta
1997, 80, 2515-2519. Heldmann, D. K.; Seebach, D. Helv. Chim. Acta
1999, 82, 1096-1110. Pichota, A.; Pregosin, P. S.; Valentini, M.; Wo¨rle,
M.; Seebach, D. Angew. Chem., Int. Ed. 2000, 112, 153-156.
(6) Goulioukina, N. S.; Dolgina, T. M.; Bondarenko, G. N.; Belet-
skaya, I. P.; Ilyin, M. M.; Davankov, V. A.; Pfaltz, A. Tetrahedron:
Asymmetry 2003, 14, 1397-1401. Pfaltz, A.; Blankenstein, J .; Hilgraf,
R.; Hormann, E.; McIntyre, S.; Menges, F.; Schonleber, M.; Smidt, S.
P.; Wustenberg, B.; Zimmermann, N. Adv. Synth. Catal. 2003, 345,
33-43. Lucking, U.; Pfaltz, A. Synlett 2000, 1261-1264. Escher, I. H.;
Pfaltz, A. Tetrahedron 2000, 56, 2879-2888. Bernardinelli, G. H.;
Kundig, E. P.; Meier, P.; Pfaltz, A.; Radkowski, K.; Zimmermann, N.;
Neuburger-Zehnder, M. Helv. Chim. Acta 2001, 84, 3233-3246. Preˆtot,
R.; Pfaltz, A. Angew. Chem. 1998, 337-339. Pfaltz, A. Acta Chim.
Scand. 1996, 50, 189-194. von Matt, P.; Lloyd-J ones, G. C.; Minidis,
A. B. E.; Pfaltz, A.; Macko, L.; Neuburger, M.; Zehnder, M.; Ru¨egger,
H.; Pregosin, P. S. Helv. Chim. Acta 1995, 78, 265. Lloyd-J ones, G. C.;
Pfaltz, A. Z. Naturforsch. 1995, 50b, 361-367.
In several studies,12-14 we have shown that introduc-
ing 3,5-di-tert-butylphenyl groups onto the P-donor of
(1) Burk, M. J .; Cross, M. F.; Martinez, J . P. J . Am. Chem. Soc. 1995,
117, 9375. Burk, M. J . Acc. Chem. Res. 2000, 33, 363-372. Burk, M.
J .; Pizzano, A.; Martin, J . A.; Liable-Sands, L. M.; Rheingold, A. L.
Organometallics 2000, 19, 250-260. Burk, M. J .; J ohnson, N. B.; Lee,
J . R. Tetrahedron Lett. 1999, 40, 6685-6688. Burk, M. J .; Bienewald,
F.; Challenger, S.; Derrick, A.; Ramsden, J . A. J . Org. Chem. 1999,
64, 3290-3298.
(2) Schlaf, M.; Lough, A. J .; Morris, R. H. Organometallics 1997,
16, 1253-1259.
(7) Sprinz, J .; Kiefer, M.; Helmchen, G.; Reggelein, M.; Huttner, G.;
Zsolnai, L. Tetrahedron Lett. 1994, 35, 1523-1526. Rieck, H.; Helm-
chen, G. Angew. Chem. 1995, 107, 2881-2883. Langer, T.; J anssen,
J .; Helmchen, G. Tetrahedron: Asymmetry 1996, 7, 1599-1602. Langer,
T.; Helmchen, G. Tetrahedron Lett. 1996, 37, 1381-1384. Steinhagen,
H.; Reggelin, M.; Helmchen, G. Angew. Chem. 1997, 109, 2199-2202.
Henning, S.; Reggelin, M.; Helmchen, G. Angew. Chem. 1997, 109,
2199-2202. Helmchen, G. J . Organomet. Chem. 1999, 576, 203-214.
Helmchen, G. J . Organomet. Chem. 1999, 576, 203-214. Helmchen,
G.; Pfaltz, A. Acc. Chem. Res. 2000, 33, 336-345. Kollmar, M.;
Goldfuss, B.; Reggelin, M.; Rominger, F.; Helmchen, G. Chem. Eur. J .
2001, 7, 4913-4927.
(3) Drago, D.; Pregosin, P. S. Organometallics 2002, 21, 1208-1215.
(4) Kumobayashi, H. Recl. Trav. Chim. Pays-Bas 1996, 115, 201-
210. Mashima, K.; Kusano, K.; Ohta, T.; Noyori, R.; Takaya, H. J .
Chem. Soc., Chem. Commun. 1989, 1208. Ohta, T.; Miyake, T.; Seido,
N.; Kumobayashi, H.; Takaya, H. J . Org. Chem. 1995, 60, 357-363.
Ohta, T.; Hidemasa, T.; Noyori, R. Inorg. Chem. 1988, 27, 566-569.
Ozawa, F.; Kubo, A.; Hayashi, T. J . Am. Chem. Soc. 1991, 113, 1417-
1419. Zhang, X.; Mashima, K.; Koyano, K.; Sayo, N.; Kumobayashi,
H.; Akutagawa, S.; Takaya, H. J . Chem. Soc., Perkin Trans. 1994,
2309-2322. J oshi, A. M.; Thorborn, I. S.; Rettig, S. J .; J ames, B. R.
Inorg. Chim. Acta 1992, 198-200, 283-296. Wiles, J . A.; Lee, C. E.;
McDonald, R.; Bergens, S., H. Organometallics 1996, 15, 3782-3784.
Wiles, J .; Bergens, S. H. J . Am. Chem. Soc. 1997, 119, 2940-2941.
(8) Bolm, C.; Kesselgruber, M.; Hermanns, N.; Hildebrand, J . P.;
Raabe, G. Angew. Chem., Int. Ed. 2001, 40, 1488-1490.
10.1021/om034381b CCC: $27.50 © 2004 American Chemical Society
Publication on Web 04/15/2004

2296 Organometallics, Vol. 23, No. 10, 2004
Dotta et al.
Sch em e 1
tert-butylphenyl and 3,5-dimethylphenyl substituents
can be effective and that Ru, Rh, and Ir catalysts also
show this 3,5-dialkyl effect on enantioselectivity.
For complexes of MeO-Biphep, 1,12 we have suggested
that this enhanced enantioselectivity arises due to
restricted rotation around the P-C(ipso) bonds of the
P(3,5-di-tert-butylphenyl) groups, as indicated in frag-
ment 3. This decrease in molecular freedom derives from
the restricted rotation due to the interaction of the
P-aryl substituent with the biaryl backbone and results
in a more rigid chiral pocket and thus improved cor-
relation between substrate and catalyst.
We report here (a) several new examples of this 3,5-
dialkyl effect on ee, involving palladium chemistry of
the ligands 1 and 2, (b) that the effect can be extended
to the monodentate auxiliary, MOP,20 4, and (c) new
detailed NMR and X-ray studies relevant to the P-C
restricted rotation for new complexes of 2 and MOP.
Resu lts
enantioselective Heck arylation of dihydrofuran (e.g., as
shown in eq 1), and found that 1b and 2b are signifi-
Rea ction s w ith 1a ,b a n d 2a ,b. Lautens and co-
workers21 have reported in detail on the Pd-catalyzed
ring-opening alkylation of the oxabenzonorbornadiene
shown in eq 2. The reaction is thought to involve a
cantly better than 1a and 2a in terms of enantioselec-
tivity with improvements of 10-20% rather routine.
Several other groups15-19 have found that both 3,5-di-
transmetalation from the dialkyl zinc to palladium,
followed by alkyl insertion into the complexed double
bond and Zn-assisted ring opening. One diastereomer
is strongly favored. The reaction conditions are mild and
yields are good. For dimethyl zinc, using (R)-Binap, (R)-
(9) Ghosh, A. K.; Mathivanan, P.; Cappiello, J . Tetrahedron: Asym-
metry 1998, 9, 1-45.
