Synthesis of heterocycles on the basis of arylation products of unsaturated compounds: XX. Reaction of 2-aryl-1,4-benzoquinones with potassium O-butyl carbonodithioate

Article abstract of DOI:10.1134/S1070428010030164

Reactions of 2-aryl-1,4-benzoquinones with potassium O-butyl carbonodithioate gave the corresponding 7-aryl-5-hydroxy-1,3-benzoxathiole-2- thiones. In some cases, 7-aryl-5-hydroxy-1,3-benzoxathiol-2-ones were also formed.

Full text of DOI:10.1134/S1070428010030164

ISSN 1070-4280, Russian Journal of Organic Chemistry, 2010, Vol. 46, No. 3, pp. 394–398. © Pleiades Publishing, Ltd., 2010.
Original Russian Text © R.L. Martyak, N.D. Obushak, V.S. Matiichuk, 2010, published in Zhurnal Organicheskoi Khimii, 2010, Vol. 46, No. 3, pp. 401–404.
Synthesis of Heterocycles on the Basis of Arylation Products
of Unsaturated Compounds: XX.* Reaction of 2-Aryl-1,4-benzo-
quinones with Potassium O-Butyl Carbonodithioate
R. L. Martyak, N. D. Obushak, and V. S. Matiichuk
Ivan Franko Lviv National University, ul. Kirilla i Mefodiya 6, Lviv, 79005 Ukraine
e-mail: obushak@in.lviv.ua
Received October 16, 2008
Abstract—Reactions of 2-aryl-1,4-benzoquinones with potassium O-butyl carbonodithioate gave the corre-
sponding 7-aryl-5-hydroxy-1,3-benzoxathiole-2-thiones. In some cases, 7-aryl-5-hydroxy-1,3-benzoxathiol-
2-ones were also formed.
DOI: 10.1134/S1070428010030164
Reactions of 1,4-quinones with nucleophilic re-
agents, in particular with nitrogen-, sulfur-, oxygen-,
and carbon-centered nucleophiles, play an important
role in the chemistry of these compounds [2–5]. Such
reactions generally follow 1,4-addition pattern, leading
to the formation of hydroquinone or 1,4-benzoquinone
derivatives which may be used in practice or as rea-
gents in organic synthesis. If a nucleophile possesses
two or more functional groups, its reactions with
1,4-quinones do not stop at the addition step but in-
volve subsequent intramolecular cyclization leading to
benzo-fused heterocyclic compounds [3]. Just that pat-
tern is typical of quinone reactions with difunctional
sulfur-centered nucleophiles [3, 6–9]. However, only
reactions with unsubstituted 1,4-benzoquinone were
studied in detail. Analogous reactions with monosub-
stituted quinones may be complicated due to possible
formation of different regioisomers. For example,
halogen-substituted quinones were reported to react
with thiourea to produce mixtures of three isomeric
halogen-substituted 5-hydroxy-1,3-benzoxathiol-2-
ones [10]. Reactions of alkylquinones with thiourea
were also nonselective [10, 11]. On the whole, the
regioselectivity of reactions of monosubstituted
1,4-benzoquinones with sulfur-centered nucleophiles
was studied poorly [3, 4]. Also, a few published data
are available on reactions of nucleophiles with 2-aryl-
1,4-benzoquinones, though the latter can readily be
obtained by arylation of 1,4-benzoquinone with arene-
diazonium chlorides [12, 13] or other reagents
[14–16]. We previously showed that reactions of
2-aryl-1,4-benzoquinones with thiourea in acid medi-
um are selective [17]: nucleophilic attack is directed at
position 6 of the quinone ring. Intermediate thiuronium
salt thus formed undergoes intramolecular cyclization
with formation of 7-aryl-5-hydroxy-1,3-benzoxathiol-
2-ones. The reactions of 2-aryl-1,4-benzoquinones
with dithiols gave 1,3-benzodithiole or 1,3-benzoxa-
thiole derivatives, depending on the substituent in the
aromatic ring [18]. In the present work we examined
reactions of 2-aryl-1,4-benzoquinones with potassium
O-butyl carbonodithioate.
Scheme 1.
O
Ar
Ar
Ar
HO
Ar
S
O
S
S
O
S
+
+
+
S
S
S
BuO
SK
O
HO
HO
O
I
II
A
B
C
* For communication XIX, see [1].
394

SYNTHESIS OF HETEROCYCLES ON THE BASIS OF ARYLATION PRODUCTS ... XX.
395
Scheme 2.
O
Ar
Ar
Ar
Ar
HO
S
O
S
S
O
S
+
+
+
S
S
O
BuO
SK
O
HO
HO
O
Ia–Ig
II
IIIa–IIIg
IVa
Va–Vc
I, III, Ar = 4-BrC6H4 (a), 4-ClC6H4 (b), 3,5-Cl2C6H3 (c), 4-O2NC6H4 (d), 4-MeC6H4 (e), 4-MeOC6H4 (f), 3-F3CC6H4 (g);
IVa, Ar = 4-O2NC6H4; V, Ar = 4-MeC6H4 (a), 4-MeOC6H4 (b), 3-F3CC6H4 (c).
We have found that reactions of 2-aryl-1,4-benzo-
quinones Ia–Ig with potassium O-butyl carbonodi-
thioate (II) on heating in acetic acid for a short time
lead to the formation of 1,3-benzoxathiole-2-thiones.
Theoretically, three isomeric compounds A–C
(Scheme 1) could be formed, depending on the regio-
selectivity of primary addition of nucleophile II to
quinones I. The reactions of arylquinones with thio-
urea gave 7-aryl-5-hydroxy-1,3-benzoxathiol-2-ones as
analogs of isomer A [17]. Analysis of the 1H NMR and
mass spectra of the products showed that 2-aryl-1,4-
benzoquinones Ia–Ig reacted with potassium O-butyl
carbonodithioate less selectively than with thiourea. In
all cases, 7-aryl-5-hydroxy-1,3-benzoxathiole-2-
thiones IIIa–IIIg (isomer A) were the major products
(Scheme 2). In the reactions of arylquinones Ia–Ic
with KSC(=S)OBu, other cyclization products were
also formed in insignificant amounts, and compounds
IIIa–IIIc were readily isolated by recrystallization.
The reactions of arylquinones Id–Ig with potassium
O-butyl carbonodithioate (II) gave two products in
comparable amounts. For example, the major product
in the reaction of 2-(4-nitrophenyl)-1,4-benzoquinone
(Id) with nucleophile II was compound IVa (isomer B;
J6,7 = 7.6 Hz). Arylquinones Ie–Ig reacted with II to
form compounds IIIe–IIIg as the major products and
significant amounts of 7-aryl-5-hydroxy-1,3-benzoxa-
thiol-2-ones Va–Vc. 1,3-Benzoxathiol-2-ones V were
also formed in the reactions with quinones Ia–Ic, but
their yields were very poor (2–3%). The product ratios
in the reactions of Id–Ig with II are listed below: Id
(R = 4-O2N), IIId : IVa = 30 : 70; Ie (R = 4-Me),
IIIe:Va = 50:50; If (R = 4-MeO), IIIf:Vb = 75:25;
Ig (R = 3-F3C), IIIg:Vc = 65:35.
Thus the main reaction direction is nucleophilic
attack by the anionic sulfur atom of potassium O-butyl
carbonodithioate at position 6 of the quinone ring. This
is confirmed by the long-range coupling constant for
the 4-H and 6-H protons (J = 2.0–2.4 Hz) appearing in
1
the H NMR spectrum as two doublets. Obviously,
compound IVa is formed as a result of primary nu-
cleophile addition at C3 (ortho position with respect to
the aryl substituent), which is likely to be favored by
electron-withdrawing effect of the nitro group.
Scheme 3 shows a probable mechanism of formation
of cyclization products III and V. Addition product of
potassium O-butyl carbonodithioate (II) to arylquinone
I, substituted hydroquinone VI, undergoes cyclization
to thiones III via intramolecular transesterification.
Unexpected formation of benzoxathiol-2-ones Va–Vc
Scheme 3.
Ar
O
S
S
–BuOH
OH
OH
OH
OH
HO
Ar
Ar
S
OBu
Ar
S
OH
IIIa–IIIg
H+
–BuOH
S
S
OH
Ar
S
O
O
S
O
VI
VII
SH
–H2S
HO
OH
VIII
Va–Vc
RUSSIAN JOURNAL OF ORGANIC CHEMISTRY Vol. 46 No. 3 2010

MARTYAK et al.
396
Scheme 4.
S
S
Br
Br
O
O
O
S
S
+
R
Cl
OH
OCOR
IIIa
IXa–IXc
Xa–Xc
R = Ph (a), 4-MeC6H4 (b), 4-MeOC6H4CH=CH (c).
may be rationalized assuming hydrolysis of butyl ester
VI to carbonodothioic O-acid VII, followed by thione–
thiol isomerization VII →VIII and intramolecular
cyclization. Thiones IIIa–IIIg can also be formed
through intermediate VII.
2.0 Hz), 7.61 d (2H, C6H4, J = 8.1 Hz), 7.74 d (2H,
C6H4, J = 8.1 Hz), 10.14 s (1H, OH). Mass spectrum,
m/z (Irel, %): 340/338 (100) [M]+, 199 (27), 183 (70),
171 (48), 155 (36), 127 (55), 115 (20), 101 (30).
Found, %: C 45.84; H 2.01; S 19.12. C13H7BrO2S2.
Calculated, %: C 46.03; H 2.08; S 18.90. M 339.23.
Compounds IIIa–IIIg readily undergo acylation
with carboxylic acid chlorides in the presence of
a base. The reaction of IIIa with acid chlorides IXa–
IXc gave the corresponding O-acyl derivatives Xa–Xc
(Scheme 4).
7-(4-Chlorophenyl)-5-hydroxy-1,3-benzoxa-
thiole-2-thione (IIIb). Yield 51%, mp 211–212°C
1
(from MeOH–H2O, 1:1). H NMR spectrum, δ, ppm:
6.95 d (1H, 4-H, J4,6 = 2.3 Hz), 7.19 d (1H, 6-H, J4,6
=
2.3 Hz), 7.60 d (2H, C6H4, J = 8.4 Hz), 7.68 d (2H,
C6H4, J = 8.4 Hz), 10.15 s (1H, OH). Mass spectrum,
m/z (Irel, %): 296 (44), 294 (100) [M]+, 183 (30), 171
(25), 162 (18), 115 (10). Found, %: C 53.21; H 2.48;
S 21.91. C13H7ClO2S2. Calculated, %: C 52.97; H 2.39;
S 21.75. M 294.78.
EXPERIMENTAL
The 1H NMR spectra were recorded on Bruker WP-
300 (300 MHz; IIIb, IIId–IIIg, IVa, Va–Vc) and
Bruker DRX-500 spectrometers (500 MHz; IIIa, IIIc,
Xa–Xc) using DMSO-d6 as solvent and tetramethyl-
silane as internal reference. The mass spectra (electron
impact, 70 eV) were obtained on a Finnigan MAT
Incos-50 GC–MS system.
7-(3,5-Dichlorophenyl)-5-hydroxy-1,3-benzoxa-
thiole-2-thione (IIIc, 1:1 solvate with DMF). Yield
69%, mp 238–239°C (from EtOH–DMF, 3:1). 1H NMR
spectrum, δ, ppm: 7.09 d (1H, 4-H, J4,6 = 2.4 Hz),
7.44–7.50 m (3H, 6-H, C6H3), 7.58 s (1H, C6H3),
10.24 s (1H, OH); DMF signals: 2.75 s (3H, CH3),
2.92 s (3H, CH3), 7.94 s (1H, CHO). Mass spectrum,
m/z (Irel, %): 332 (15), 330 (65), 328 (100) [M]+, 233
(38), 205 (36), 198 (13), 170 (12), 126 (14). Found, %:
C 47.45; H 3.11; S 16.12. C13H6Cl2O2S2·C3H7NO. Cal-
culated, %: C 47.77; H 3.26; S 15.94. M 329.23.
Initial 2-aryl-1,4-benzoquinones Ia–Ig were synthe-
sized as described in [12, 13, 18–20].
Reaction of 2-aryl-1,4-benzoquinones Ia–Ig with
potassium O-butyl carbonodithioate (II) (general
procedure). A suspension of 10 mmol of 2-aryl-1,4-
benzoquinone Ia–Ig in 20 ml of glacial acetic acid was
added under stirring to a solution of 2.1 g (11 mmol) of
potassium O-butyl carbonodithioate (II) in 10 ml of
water. The mixture was heated for 30 min at the
boiling point under stirring and cooled, and the precip-
itate was filtered off, washed with several portions of
water and with alcohol, and dried. The crude product
was analyzed by gas chromatography–mass spectrom-
5-Hydroxy-7-(4-nitrophenyl)-1,3-benzoxathiole-
1
2-thione (IIId). Yield 26%. H NMR spectrum, δ,
ppm: 7.03 d (1H, 4-H, J4,6 = 2.1 Hz), 7.28 d (1H, 6-H,
J4,6 = 2.1 Hz), 7.97 d (2H, C6H4, J = 7.8 Hz), 8.39 d
(2H, C6H4, J = 7.8 Hz), 10.25 s (1H, OH).
5-Hydroxy-4-(4-nitrophenyl)-1,3-benzoxathiole-
1
1
etry and H NMR to identify particular isomers and
determine their ratio.
2-thione (IVa). Yield 58%. H NMR spectrum, δ,
ppm: 7.15 d (1H, 6-H, J6,7 = 7.6 Hz), 7.59 d (1H, 7-H,
J6,7 = 7.6 Hz), 7.80 d (2H, C6H4, J = 7.8 Hz), 8.33 d
(2H, C6H4, J = 7.8 Hz), 10.48 s (1H, OH); Mass spec-
trum of mixture IIId/IVa, m/z (Irel, %): 305 (100) [M]+,
258 (11), 198 (13), 171 (22), 155 (18), 126 (25), 115
7-(4-Bromophenyl)-5-hydroxy-1,3-benzoxa-
thiole-2-thione (IIIa). Yield 61%, mp 215–216°C
1
(from EtOH–H2O, 1:1). H NMR spectrum, δ, ppm:
6.95 d (1H, 4-H, J4,6 = 2.0 Hz), 7.19 d (1H, 6-H, J4,6
=
RUSSIAN JOURNAL OF ORGANIC CHEMISTRY Vol. 46 No. 3 2010

SYNTHESIS OF HETEROCYCLES ON THE BASIS OF ARYLATION PRODUCTS ... XX.
397
(16). Found, %: C 51.10; H 2.23; N 4.70; S 21.21.
C13H7NO4S2. Calculated, %: C 51.14; H 2.31; N 4.59;
S 21.00. M 305.33.
and the mixture was heated for 1 h with stirring under
reflux. The mixture was cooled, the precipitate was
filtered off, the filtrate was evaporated, and the residue
was washed several times with water and purified by
recrystallization.
5-Hydroxy-7-(4-methylphenyl)-1,3-benzoxa-
thiole-2-thione (IIIe) and 5-hydroxy-7-(4-methyl-
phenyl)-1,3-benzoxathiol-2-one (Va) (1:1 mixture).
Yield 56%. 1H NMR spectrum, δ, ppm: 2.36 s (1.5H,
7-(4-Bromophenyl)-2-thioxo-1,3-benzoxathiol-
5-yl benzoate (Xa). Yield 53%, mp 175–176°C (from
1
EtOH–DMF, 2:1). H NMR spectrum, δ, ppm: 7.45 d
Me), 2.37 s (1.5H, Me), 6.85 d (0.5H, 4-H, J4,6
=
(1H, 4-H, J4,6 = 2.1 Hz), 7.58 t (2H, C6H4, J = 8.0 Hz),
2.4 Hz), 6.93 d (0.5H, 4-H, J4,6 = 2.1 Hz), 7.13 m (1H,
6-H), 7.25–7.39 m (2H, C6H4), 7.47–7.58 m (2H,
C6H4), 9.89 s (0.5H, OH), 10.11 s (0.5H, OH). Mass
spectrum, m/z (Irel, %): 274 (100) [M]+ (IIIe), 258 (90)
[M]+ (Va), 214 (17), 202 (45), 171 (12), 142 (15), 115
(27). Found, %: C 63.33; H 3.90; S 17.89. Calculated
for IIIe/Va (1:1), %: C 63.14; H 3.78; S 18.06.
M 274.36 (IIIe), 258.30 (Va).
7.62–7.72 m (5H, C6H5), 7.66 d (1H, 6-H, J4,6
=
2.1 Hz), 8.17 d (2H, C6H4, J = 7.8 Hz). Mass spectrum,
m/z (Irel, %): 444/442 (67) [M]+, 428/426 (12), 105
(100), 77 (37). Found, %: C 54.02; H 2.45; S 14.28.
C20H11BrO3S2. Calculated, %: C 54.18; H 2.50;
S 14.46. M 443.34.
7-(4-Bromophenyl)-2-thioxo-1,3-benzoxathiol-5-
yl 4-methylbenzoate (Xb). Yield 66%, mp 182–183°C
(from EtOH–DMF, 2:1). H NMR spectrum, δ, ppm:
5-Hydroxy-7-(4-methoxyphenyl)-1,3-benzoxa-
thiole-2-thione (IIIf) and 5-hydroxy-7-(4-methoxy-
phenyl)-1,3-benzoxathiol-2-one (Vb) (3:1 mixture).
1
7.36 d (2H, C6H4, J = 7.7 Hz), 7.43 d (1H, 4-H, J4,6
=
1
2.1 Hz), 7.64 d (1H, 6-H, J4,6 = 2.1 Hz), 7.68 s (4H,
C6H4), 8.05 d (2H, C6H4, J = 7.8 Hz). Mass spectrum,
m/z (Irel, %): 458/456 (46) [M]+, 442/440 (10), 119
(100), 91 (28). Found, %: C 55.34; H 2.96; S 13.88.
C21H13BrO3S2. Calculated, %: C 55.15; H 2.87;
S 14.02. M 457.37.
Yield 35 and 12% respectively. H NMR spectrum, δ,
ppm: 3.82 s (0.75H, MeO), 3.83 s (2.25H, MeO),
6.83 d (0.25H, 4-H, J4,6 = 2.4 Hz), 6.92 d (0.75H, 4-H,
J4,6 = 2.5 Hz), 7.04–7.15 m (3H, 6-H, C6H4), 7.53–
7.64 m (2H, C6H4), 9.87 s (0.25H, OH), 10.08 s
(0.75H, OH). Mass spectrum, m/z (Irel, %): 290 (100)
[M]+ (IIIf), 274 (45) [M]+ (Vb), 246 (15), 218 (37),
203 (40), 187 (13), 158 (14), 143 (15), 115 (33).
Found, %: C 58.97; H 3.67; S 19.35. Calculated for
IIIf/Vb (3:1), %: C 58.72; H 3.52; S 19.59. M 290.36
(IIIf), 274.30 (Vb).
7-(4-Bromophenyl)-2-thioxo-1,3-benzoxathiol-
5-yl (2E)-3-(4-methoxyphenyl)prop-2-enoate (Xc).
Yield 59%, mp 226–227°C (from EtOH–DMF, 2:1).
1H NMR spectrum, δ, ppm: 3.83 s (3H, MeO), 6.72 d
(1H, 3′-H, J = 15.0 Hz), 6.96 d (2H, C6H4, J = 7.6 Hz),
7.42 d (1H, 4-H, J4,6 = 2.0 Hz), 7.54 d (2H, C6H4, J =
7.6 Hz), 7.62 d (1H, 6-H, J4,6 = 2.0 Hz), 7.63 d (1H,
2′-H, J 15.0 Hz), 7.66–7.70 m (4H, C6H4). Mass spec-
trum, m/z (Irel, %): 500/498 (25) [M]+, 161 (100), 133
(16), 119 (15). Found, %: C 55.45; H 2.97; S 12.73.
C23H15BrO4S2. Calculated, %: C 55.32; H 3.03;
S 12.84. M 499.41.
5-Hydroxy-7-(3-trifluoromethylphenyl)-1,3-
benzoxathiole-2-thione (IIIg) and 5-hydroxy-7-(3-
trifluoromethylphenyl)-1,3-benzoxathiol-2-one (Vc)
(65:35 mixture). Yield 39 and 21%, respectively.
1H NMR spectrum, δ, ppm: 6.93 d (0.35H, 4-H, J4,6
=
2.1 Hz), 7.02 d (0.65H, 4-H, J4,6 = 2.1 Hz), 7.20 m
(1H, 6-H), 7.72–7.88 m (2H, C6H4), 7.90–8.04 m (2H,
C6H4), 9.99 s (0.35H, OH), 10.19 s (0.65H, OH). Mass
spectrum, m/z (Irel, %): 328 (100) [M]+ (IIIg), 312 (30)
[M]+ (Vc), 268 (14), 256 (48), 196 (20), 171 (23), 151
(20), 85 (30). Found, %: C 52.32; H 2.28; S 16.53.
Calculated for IIIg/Vc (65:35), %: C 52.11; H 2.19;
S 16.39. M 328.33 (IIIg), 312.27 (Vc).
REFERENCES
1. Matiichuk, V.S., Obushak, N.D., Lytvyn, R.Z., and
Gorak, Yu.I., Khim. Geterotsikl. Soedin., 2010, p. 61.
2. Katritzky, A.R., Fedoseyenko, D., Mohapatra, P.P., and
Steel, P.J., Synthesis, 2008, p. 777.
Reaction of 7-(4-bromophenyl)-5-hydroxy-1,3-
benzoxatiole-2-thione (IIIa) with carboxylic acid
chlorides IXa–IXc (general procedure). Compound
IIIa, 3.4 g (10 mmol), was dissolved in 30 ml of anhy-
drous benzene, 1 g (10 mmol) of N-methylmorpholine
and 10 mmol of acid chloride IXa–IXc were added,
3. Kutyrev, A.A. and Moskva, V.V., Usp. Khim., 1991,
vol. 60, p. 134.
4. Finley, K.T., The Chemistry of the Quinonoid Com-
pounds, Patai, S., Ed., London: Interscience, 1974,
vol. 2, p. 877.
5. Wikholm, R.J., J. Org. Chem., 1985, vol. 50, p. 382.
RUSSIAN JOURNAL OF ORGANIC CHEMISTRY Vol. 46 No. 3 2010

MARTYAK et al.
398
6. Klemm, K. and Geiger, B., Justus Liebigs Ann. Chem.,
14. Itahara, T., J. Chem. Soc., Chem. Commun., 1981,
1969, vol. 726, p. 103.
p. 859.
7. Fiedler, H., Chem. Ber., 1962, vol. 95, p. 1771.
8. Harris, R.L.N. and Oswald, L.T., Aust. J. Chem., 1974,
vol. 27, p. 1309.
15. Singh, P.K., Rohtagi, B.K., and Khanna, R.N., Synth.
Commun., 1992, vol. 22, p. 987.
16. Engler, T.A. and Reddy, J.P., J. Org. Chem., 1991,
vol. 56, p. 6491.
17. Obushak, N.D., Matiichuk, V.S., and Martyak, R.L.,
9. Fabian, K. and Hartmann, H., J. Prakt. Chem., 1971,
vol. 313, p. 722.
Khim. Geterotsikl. Soedin., 2001, p. 986.
18. Obushak, N.D., Martyak, R.L., and Matiichuk, V.S.,
10. Lau, P.T.S. and Kestner, M., J. Org. Chem., 1968,
vol. 33, p. 4426.
Russ. J. Org. Chem., 2005, vol. 41, p. 748.
11. Lau, P.T.S. and Gompf, T.E., J. Org. Chem., 1970,
vol. 35, p. 4103.
12. Kvalnes, D.E., J. Am. Chem. Soc., 1934, vol. 56,
p. 2478.
19. Amaro, A.R., Oakley, G.G., Bauer, U., Spielmann, H.P.,
and Robertson, L.W., Chem. Res. Toxicol., 1996, vol. 9,
p. 623.
13. Brassard, P. and L’Écuyer, P., Can. J. Chem., 1958,
20. Obushak, M.D., Martyak, R.L., and Matiychuk, V.S.,
vol. 36, p. 700.
Polish J. Chem., 2002, vol. 76, p. 1419.
RUSSIAN JOURNAL OF ORGANIC CHEMISTRY Vol. 46 No. 3 2010
