Rever sible Con tr ol of Assem bly a n d Disa ssem bly of In ter lock ed
Su p er m olecu les
Kyoung-J in Chang, Young-J ae An, Hyounsoo Uh, and Kyu-Sung J eong*
Center for Bioactive Molecular Hybrids and Department of Chemistry, Yonsei University,
Seoul 120-749, Korea
ksjeong@yonsei.ac.kr
Received J une 5, 2004
Two kinds of interlocked supramolecular complexes that display stimulus-responsive assembly and
disassembly have been described. One is a pseudorotaxane driven by hydrogen-bonding interactions
between rings 2a and 2b and rods 1a and 1b. The rods contain a binding site for the ring as well
as a stimulus-responsive diazo group, both of which are conformationally constrained in parallel
by connecting them to a rigid xanthene skeleton. The trans isomer of 1a bearing a rigid binding
site cannot form the pseudorotaxanes with the rings 2a and 2b because the neighboring diazophenyl
group sterically shields the binding site. However, when trans-1a was converted to the corresponding
cis-1a by UV light, the pseudorotaxanes are immediately formed with association constants of 70
( 10 M-1 and (1.1 ( 0.1) × 103 M-1 for 2a and 2b, respectively, in CDCl3 at 24 ( 1 °C. The
pseudorotaxanes are completely disassembled into their molecular component when heated at 80-
85 °C for 20 min. The assembly and disassembly processes can be reversibly cycled by repeating
irradiation and heating alternatively. In the case of the rod 1b that possesses a flexible binding
site, both cis and trans isomers can form the corresponding pseudorotaxanes with association
constants of (2.0 ( 0.3) × 102 M-1 for 2a and trans-1b and of (7.4 ( 0.5) × 102 M-1 for 2a and
cis-1b in CDCl3 at 24 ( 1 °C. In this system, therefore, external stimuli can modulate the relative
distribution of the pseudorotaxane and its components. Finally, the work was extended to the
construction of a kinetically more stable molecular machine based on a rotaxane-like complex 10‚
11 between a metallocycle 11 and a dumbbell 10. In this system, the complex and its components
1
showed separate sets of the signals, not the averaged, in H NMR spectroscopy as expected by the
increased kinetic stability.
In tr od u ction
components that cannot be separated without breaking
a covalent bond. Two components may reversibly change
their relative positions within the interlocked entities,
so-called co-conformations,2 to generate a thermodynam-
ically stable state when an external stimulus is applied.
On the other hand, the pseudorotaxane is a supramo-
lecular complex, and its assembly and disassembly may
be reversibly controlled at will. The switching capability
of these supermolecules is one of the most important
features required for construction of artificial molecular-
level machines.
The supramolecular states of the co-conformations
(rotaxanes and catenanes) or the assembly/disassembly
(pseudorotaxanes) can be controlled by modulation of
noncovalent interactions. The most widely used method
for this purpose is electro- and photochemical redox
chemistry3 that alters effectively the strength of nonco-
valent interactions including hydrogen bonds and metal
coordination. The other is the acid-base chemistry that
induces the protonation and deprotonation at the recog-
nition sites, thus greatly affecting the hydrogen-bonding
capability.4 Light energy has been also used for operation
Interlocked supermolecules such as rotaxanes, cat-
enanes, and pseudorotaxanes have attracted a great deal
of attention in recent years because of their potential
applications to molecular electronics in the future.1
Rotaxanes and catenanes are mechanically interlocked
supermolecules comprised of two distinct molecular
* To whom correspondence should be addressed. Fax: (+) 82-2-364-
7050. Tel: (+) 82-2-2123-2643.
(1) For recent reviews, see: (a) Amabilino, D. B.; Stoddart, J . F.
Chem. Rev. 1995, 95, 2725-2828. (b) J a¨ger, R.; Vo¨gle, F. Angew. Chem.,
Int. Ed. Engl. 1997, 36, 930-944. (c) Nepogodiev, S. A.; Stoddart, J .
F. Chem. Rev. 1998, 98, 1959-1976. (d) Sauvage, J .-P. Acc. Chem. Res.
1998, 31, 611-619. (e) Raymo, F. M.; Stoddart, J . F. Chem. Rev. 1999,
99, 1643-1663. (f) Blanco, M.-J .; J ime´nez, M. C.; Chambron, J .-C.;
Heitz, V.; Linke, M.; Sauvage, J .-P. Chem. Soc. Rev. 1999, 28, 293-
305. (g) Breault, G. A.; Hunter, C. A.; Mayers, P. C. Tetrahedron 1999,
55, 5265-5293. (h) Balzani, V.; Credi, A.; Raymo, F. M.; Stoddart, J .
F. Angew. Chem., Int. Ed. 2000, 39, 3348-3391. (i) Hubin, T. J .; Busch,
D. H. Coord. Chem. Rev. 2000, 200-202, 5-52. (j) Pease, A. R.;
J eppesen, J . O.; Stoddart, J . F.; Luo, Y.; Collier, C. P.; Heath, J . R.
Acc. Chem. Res. 2001, 34, 433-444. (k) Ballardini, R.; Balzani, V.;
Credi, A.; Gandolfi, M. T.; Venturi, M. Acc. Chem. Res. 2001, 34, 445-
455. (l) Harada, A. Acc. Chem. Res. 2001, 34, 456-464. (m) Schalley,
C. A.; Beizai, K. Vo¨gtle, F. Acc. Chem. Res. 2001, 34, 465-476. (n)
Collin, J .-P.; Dietrich-Buchecker, C.; Gavin˜a, P.; J imenez-Molero, M.
C.; Sauvage, J .-P. Acc. Chem. Res. 2001, 34, 477-487. (o) Kim, K.
Chem. Soc. Rev. 2002, 31, 96-107. (p) Balzani, V.; Credi, A.; Venturi,
M. Molecular Devices and Machines - A J ourney into the Nano World;
Wiley-VCH: Weinheim, 2003.
(2) For a definition of co-conformation, see: Fyfe, M. C. T.; Glink,
P. T.; Menzer, S.; Stoddart, J . F.; White, A. J . P.; Williams, D. J . Angew.
Chem., Int. Ed. Engl. 1997, 36, 2068-2070.
10.1021/jo0490548 CCC: $27.50 © 2004 American Chemical Society
Published on Web 09/01/2004
6556
J . Org. Chem. 2004, 69, 6556-6563

Assembly and Disassembly of Interlocked Supermolecules
of artificial molecular machines.5,6 In particular, in the
molecular machines based on the diazo functionality, the
trans isomer of the rod is nicely threaded but the cis
isomer poorly fitted in the ring owing to its inherent bent
shape.5
Herein we describe design, self-assembly, and proper-
ties of interlocked supramolecular complexes 1‚2 that
display stimulus-responsive assembly and disassembly
and therefore function like a molecular machine (Figure
1).7 Reversible switching of two supramolecular states
stems from trans-cis isomerization of the diazo func-
tionality in the rod components 1a and 1b, which can be
reversibly controlled by light and thermal stimulations.
The working principle of new molecular machines is
different from the previous diazo-based ones,5 and the
