Probing Molecular Recognition in the Solid-State by Use of an
Enolizable Chromophoric Barbituric Acid
Ina Bolz,† Chulsoon Moon,‡ Volker Enkelmann,‡ Gunther Brunklaus,‡ and Stefan Spange*,†
Institut fu¨r Chemie, Technische UniVersita¨t Chemnitz, D-09107 Chemnitz, Germany, and
Max-Planck-Institut fu¨r Polymerforschung, Postfach 3148, D-55021 Mainz, Germany
stefan.spange@chemie.tu-chemnitz.de; brunklaus@mpip-mainz.mpg.de
ReceiVed July 19, 2007
Complex formation of the enolizable chromophor 1-n-butyl-5-(4-nitrophenyl)barbituric acid 1 with multiple
binding sites for supramolecular assemblies and its corresponding adducts produced with the Proton
Sponge (1,8-bis(dimethylamino)naphthalene), PS) and the adenine-mimetic 2,6-diacetamidopyridine (DAC)
have been studied by means of solid-state proton NMR spectroscopy under fast magic-angle spinning,
X-ray analysis, and UV/vis spectroscopy. Both NMR data and X-ray results reveal that the enolic
chromophor undergoes self-aggregation to hydrogen-bonded dimers which are involved in stacked
arrangements. Depending on the nature of the added base, this dimeric assembly is preserved in the
formed enolate anion but can be broken in the presence of complementary hydrogen-bonding pattern
leading to supramolecular complexes. Molecular recognition of these structural different bases significantly
influences the chromophoric π-system of 1.
I. Introduction
affinities at binding adenine or its derivatives, thereby yielding
strongly hydrogen-bonded complexes.4 However, the observed
biological activity of barbiturates is mainly attributed to
tautomerism, acid-base equilibriums, and to the nature of their
substituents.5 Recently, it has been shown that related Mero-
cyanine dyes create new self-assembled structures6 or are
effective sensitizers with interesting photophysical properties.7
More importantly, such dyes exhibit hydrogen-bonding patterns
with an ADA sequence (A ) hydrogen bond acceptor site,
Artificial chromophoric receptors for biologically active
molecules have attracted considerable attention from the view-
point of molecular recognition.1,2 In particular, interactions
mediated by hydrogen-bonding play an important role in both
chemical and biological systems.3 Barbiturates are important
members of the pyrimidine family and show very selective
