Tetrazole-1-acetic acid as a ligand for copper-catalyzed N-arylation of
imidazoles with aryl iodides under mild conditions
*
Feng-Tian Wu, Ping Liu, Xiao-Wei Ma, Jian-Wei Xie , Bin Dai
School of Chemistry and Chemical Engineering/the Key Laboratory for Green Processing of Chemical Engineering of Xinjiang Bingtuan, Shihezi University,
Shihezi 832003, China
A R T I C L E I N F O
A B S T R A C T
Article history:
Tetrazole-1-acetic acid was found to serve as a superior ligand for CuI-catalyzed N-arylation of
imidazoles with aryl iodides under a low catalyst loading (5 mol% of CuI). A variety of aryl iodides could
be aminated to provide the N-arylated products in good to excellent yields without the need of an inert
atmosphere.
Received 3 May 2013
Received in revised form 20 May 2013
Accepted 22 May 2013
Available online 2 July 2013
ß 2013 Jian-Wei Xie. Published by Elsevier B.V. on behalf of Chinese Chemical Society. All rights reserved.
Keywords:
Tetrazole-1-acetic acid
N-Arylation
Imidazoles
Copper
Aryl iodides
1. Introduction
However, TZA, to our knowledge, has seldom been used as ligand in
copper-mediated cross-coupling reactions. In continuation of our
Copper-catalyzed carbon–nitrogen cross-coupling reactions
have been established as a powerful strategy for the preparation
of N-arylation of nitrogen nucleophiles, which play a vital role as
intermediates for agrochemicals, pharmaceuticals, energetic
materials and fine chemical industries [1]. Traditionally, these
reactions were often suffered from harsh reaction conditions
involving elevated temperatures and highly polar solvents, and
stoichiometric amounts of copper reagents [2]. Recently, pio-
neered by the Buchwald’s and Taillefer’s works [3], the process of
Cu-based C–N coupling reactions have reinvigorated by the
implementation of several classes of mono- and bidentate
chelating ligands [4]. However, more work still needs to be done
to identify new ligands to widen the scope of substrate tolerance,
lower copper loading, milder reaction conditions, enhanced
chemoselectivity and enantioselectivity of copper-catalyzed C–N
coupling reactions.
endeavors to develop copper-catalyzed cross couplings [10–12],
we report herein TZA as an accelerating ligand for copper-
catalyzed N-arylation of imidazoles with aryl iodides under mild
reaction conditions.
2. Experimental
All reagents were purchased from commercial suppliers and
used without further purification. All known products were
characterized by GC–MS, and 1H NMR, which were compared
with the previously reported dates. 1H NMR spectra were recorded
at room temperature on a Varian Inova-400 instrument at
400 MHz, and the chemical shifts were recorded in ppm (d) with
TMS as internal standard. Mass spectra were recorded on GC–MS
(Agilent 7890A/5975C) instrument under EI model.
General procedure for the N-arylation of imidazoles with aryl
halides: CuI (0.05 mmol), L1 (0.1 mmol), aryl halides (1.0 mmol),
imidazoles (1.5 mmol), NaOH (2 mmol), and DMSO (2 mL) were
added to a 10 mL of sealed tube. The reaction mixture was reacted
at 110 8C in a preheated oil bath for 12 h. The reaction mixture was
cooled to r.t., diluted with 10 mL H2O, and then the mixture was
extracted with ethyl acetate (3Â 20 mL). The combined organic
phases was washed with water and brine, dried over anhydrous
Na2SO4, and concentrated in vacuo. The residue was purified by
flash column chromatography on silica gel (ethyl acetate/petro-
leum ether, 2:1 to pure ethyl acetate) to afford the target products.
On the other hand, it is well-known that carboxylate O atoms
and tetrazolyl ring N atoms have good coordination capacities [5],
and tetrazole-1-acetic acid (TZA), with both a carboxylate and
tetrazolyl ring, is a multifunctional ligand. Therefore, it could bind
to several metals via N and/or O atoms to form multi-dimensional
coordination polymers with various coordination modes [6–9].
* Corresponding author.
E-mail address: cesxjw@gmail.com (J.-W. Xie).
1001-8417/$ – see front matter ß 2013 Jian-Wei Xie. Published by Elsevier B.V. on behalf of Chinese Chemical Society. All rights reserved.
http://dx.doi.org/10.1016/j.cclet.2013.05.037

894
F.-T. Wu et al. / Chinese Chemical Letters 24 (2013) 893–896
Table 1
Screening of the reaction conditions on the coupling reaction of 4-iodoanisole with imidazole.a
L2
L3
L4
L1
I
N
[Cu], L
N
N
N
N
N
N
N
N
N
N
H
O
Bases, solvents
N
N
N
N
O
COOH
COOH
COOH
COOH
b
Entry
[Cu]
Ligand
Solvent
Base
T (8C)
Yield (%)
1
2
CuI
L1
L2
L3
L4
–
DMSO
DMSO
DMSO
DMSO
DMSO
DMSO
DMSO
DMSO
DMSO
DMSO
DMSO
DMF
NaOH
NaOH
NaOH
NaOH
NaOH
NaOH
NaOH
NaOH
NaOH
NaOH
NaOH
NaOH
NaOH
NaOH
NaOH
KOH
110
110
110
110
110
110
110
110
110
110
110
110
110
110
110
110
110
110
110
100
80
93
CuI
84
3
CuI
77
4
CuI
88
5
CuI
75
6
CuO
CuSO4
Cu(OAc)2
CuCl
CuBr
–
L1
L1
L1
L1
L1
L1
L1
L1
L1
L1
L1
L1
L1
L1
L1
L1
L1
L1
81
7
71
8
83
9
87
10
11
12
13
14
15
16
17
18
19
20
21
22
23
89
0
CuI
48
CuI
DMAC
80
CuI
1,4-Dioxane
H2O
40
CuI
Trace
79
CuI
DMSO
DMSO
DMSO
DMSO
DMSO
DMSO
DMSO
DMSO
CuI
K3PO4
Cs2CO3
K2CO3
NaOH
NaOH
NaOH
NaOH
88
CuI
81
CuI
11
CuI
88
CuI
16
CuI
110
110
92c (70d)
80e
CuI
a
Reaction conditions: 4-iodoanisole (0.5 mmol), imidazole (0.75 mmol), [Cu] (10 mmol%), L (20 mmol%), base (1.0 mmol), solvent (1 mL), 12 h.
b
c
Isolated yield.
5 mol% CuI, 10 mol% L1.
5 mol% CuI, ligand-free.
2.5 mol% CuI, 5 mol% L1.
d
e
Table 2
CuI-catalyzed N-arylation of imidazoles with aryl iodides using tetrazole-1-acetic acid as ligand under mild conditions.a
5 mol% CuI
N
N
X
N-Het
10 mol% L1
N
N
R1
R1
Het-NH
L1 =
NaOH, DMSO
110 oC, 12 h
COOH
1-13
Entry
ArX
Het-NH
Product
MeO
Yield (%)b
92 (70c)
1
I
I
N
N
N
N
H
MeO
1
2
3
90
85
N
N
N
N
H
EtO
Me
EtO
2
3
I
N
N
N
N
N
H
Me
4
5
84 (71c)
91 (81c)
I
N
N
N
H
4
Me
I
N
N
Me
N
N
H
Me
5
Me

F.-T. Wu et al. / Chinese Chemical Letters 24 (2013) 893–896
895
Table 2 (Continued )
Entry
6
ArX
Het-NH
Product
Yield (%)b
76
MeO
I
N
N
MeO
N
N
H
6
7
8
75d (50c,d
75 (38c)
84
)
I
N
N
N
N
H
OMe
OMe
7
8
I
N
N
N
N
H
NH
2
NH
2
9
I
N
N
N
N
N
H
Ph
Cl
Ph
Cl
9
10
96 (83c)
I
N
N
N
H
10
11
12
82e
I
N
N
N
N
H
O N
2
O N
2
11
12
79 (0c)
N
N
I
I
N
N
H
Cl
Cl
Cl
13
74 (28c)
35 (15c)
N
N
N
H
Cl
13
14
Br
N
N
N
N
H
MeO
MeO
1
a
Reaction conditions: aryl halides (1.0 mmol), imidazoles (1.5 mmol), CuI (0.05 mmol), L1 (0.1 mmol), NaOH (2.0 mmol), DMSO (2 mL), 12 h.
b
c
Isolated yields.
Ligand-free.
d
e
Reaction time: 18 h.
90 8C, 6 h.
3. Results and discussion
and NaOH gave the best yields (entries 1, 16–19). Lowering the
reaction temperature can markedly decelerate the reaction rate
and led to lower yields (entries 1, 20 and 21). In addition, when the
loading of CuI was reduced from 10 mol% to 5 mol%, the excellent
yield was also afforded. However, when 2.5 mol% of CuI was
employed, the reaction yield decreased to 80% (entries 1, 22 and
23). In summary, the optimal conditions for the N-arylation of
imidazole with 4-iodoanisole involves the use of 5 mol% of CuI,
10 mol% of L1, and 2 equiv. of NaOH in DMSO at 110 8C for 12 h.
The scope of the CuI/L1 catalytic system was probed by using a
wide range of aryl iodides and N-heterocyclic substrates under the
optimized conditions, and the results are listed in Table 2. In
general, the N-arylation of imidazoles with most of electron-rich,
electron-neutral, and electron-poor aryl iodides afforded the
desired products in yield ranging from 74% to 96%. It is worth
noting that the sterically hindered o-iodoanisole reacted smoothly
only with prolonging the reaction time to 18 h (entry 7). In
addition, when other potentially reactive functional groups (e.g.,
amino) are present, high level of chemoselectivity was observed
Initially, 4-iodoanisole and imidazole were selected as the
model substrates to optimize the coupling reaction conditions
including copper source, ligand, solvent, bases and temperature
without the protection by an inert gas. The results are shown in
Table 1. Among the ligands used, TZA was more beneficial to the
catalysis than other N-heterocyclic-1-acetic acid, which gave the
desired product in 93% isolated yield (entries 1–4). This could be
attributed to the excellent coordination capacity of L1. In contrast,
the reaction was also carried out in the absence of ligand, and the
N-arylation product was obtained in moderate yield (entry 5).
Nevertheless, the effect of the ligands is obvious (entry 1 vs entry 5,
and entry 22). By using L1 as the ligand, different copper source
have then been examined, and CuII or CuI were more or less active,
and CuI demonstrated the highest yields (entries 6–10). Observa-
tion of the solvent indicated that DMSO is the most favorable
solvent for the model reaction (entries 1, 12–15). The bases,
including NaOH, KOH, K3PO4, Cs2CO3, and K2CO3 were explored,

896
F.-T. Wu et al. / Chinese Chemical Letters 24 (2013) 893–896
[2] (a) J. Lindley, Tetrahedron report number 163: copper assisted nucleophilic
substitution of aryl halogen, Tetrahedron 40 (1984) 1433–1456;
(b) A. Kiyomori, J.F. Marcoux, S.L. Buchwald, An efficient copper-catalyzed cou-
pling of aryl halides with imidzoles, Tetrahedron Lett. 40 (1999) 2657–2660;
(c) I. Antonini, G. Cristalli, P. Franchetti, M. Grifantini, S. Martelli, Synthesis of N1-
aryl- and N1-benzyl substituted imidazole-4-and imidazole-5-carbaldhydes, Syn-
thesis 1983 (1983) 47–49.
[3] (a) A. Klapars, J.C. Antilla, X. Huang, S.L. Buchwald, A general and efficient copper
catalyst for the amidation of aryl halides and the N-arylation of nitrogen hetero-
cycles, J. Am. Chem. Soc. 123 (2001) 7727–7729;
(b) M. Taillefer, H.J. Cristau, P. Cellier, J.F. Spindler, Relatively Low-Temperature
Catalytic Procedure For Arylation or Vinylation of Nitrogen-Containing Nucleo-
philic Compounds, Fr 2833947-WO 0353225 (Priority Number Fr 16547, 2001).
[4] (a) For some selected reviews, see: Z. Li, Z. Wu, H. Deng, X. Zhou, Progress in
copper-catalyzed Ullmann-type coupling reactions in water, Chin. J. Org. Chem.
33 (2013) 760–770 (in Chinese);
(entry 8). The N-arylation of imidazole with 4-nitroiodobenzene
gave the corresponding coupling product in 82% yield, which just
needed lower reaction temperature and shorter reaction time
(entry 11). We were pleased to find that the arylation reactions also
proceed with other nitrogen-containing heterocycles such as
benzimidazole and indole in good yields under standard conditions
(entries 12 and 13). Unfortunately, the N-arylation product was
obtained only in 35% yield, when 4-bromoanisole was used as the
substrate (entry 14). Furthermore, in comparison to ligand-free
condition, several blank experiments without any ligand of typical
substrates were carried out in the same conditions, and the results
confirmed that the ligand played an important role in this process
(entries 1, 4, 5, 7–8, 10, 12–14).
(b) F. Monnier, M. Taillefer, Catalytic C–C, C–N, and C–O Ullmann-type coupling
reactions, Angew. Chem. Int. Ed. 48 (2009) 6954–6971;
(c) J.D. Senra, L.C.S. Aguiar, A.B.C. Simas, Recent progress in transition-metal-
catalyzed C–N cross-couplings: emerging approaches towards sustainability,
Curr. Org. Synth. 8 (2011) 53–78;
4. Conclusion
(d) F. Monnier, M. Taillefer, Catalytic C–C, C–N, and C–O Ullmann-type coupling
In conclusion, we established tetrazole-1-acetic acid as a novel
ligand for copper-catalyzed N-arylation of various nitrogen
nucleophiles with differently substituted aryl iodides under mild
conditions. The low catalyst loading (5 mol% of CuI), the
commercial availability of the ligand and without the protection
of an inert gas are expected to be useful for a variety of synthetic
chemists.
reactions: copper makes
3096–3099;
a difference, Angew. Chem. Int. Ed. 47 (2008)
(e) Y. Wang, J. Zeng, X. Cui, Recent progress in copper-catalyzed C–N coupling
reactions, Chin. J. Org. Chem. 30 (2010) 181–199.
[5] J. Tao, Z.J. Ma, R.B. Huang, L.S. Zheng, Synthesis and characterization of a tetra-
zolate-bridged coordination framework encapsulating D2h-symmetric cyclic
(H2O)4 cluster arrays, Inorg. Chem. 43 (2004) 6133–6135.
[6] X.Q. Zhang, Q. Yu, H.D. Bian, X.G. Bao, H. Liang, Synthesis, structures, and
characterization of cadmium(II), cobalt(II), and copper(II) metal polymers with
tetrazole-1-acetate, J. Coord. Chem. 62 (2009) 2108–2117.
Acknowledgments
[7] B.D. Wu, G.T. Zhang, T.L. Zhang, et al., Preparation, crystal structure, thermal
decomposition and explosive properties of K2(tza)2(H2O) (tza = tetrazole-1-acetic
acid), Chin. J. Struct. Chem. 30 (2011) 431–437.
This work was supported financially by the National Basic
Research Program of China (973 Program, No. 2012CB722603) and
the Start-Up Foundation for Young Scientists of Shihezi University
(Nos. RCZX201012, RCZX201014, RCZX201015).
[8] Q. Yu, X. Zhang, H. Bian, et al., pH-dependent Cu(II) coordination polymers with
tetrazole-1-acetic acid: synthesis, crystal structures, EPR and magnetic proper-
ties, Cryst. Growth Des. 8 (2008) 1140–1146.
[9] Z. Tang, G.T. Zhang, T.L. Zhang, et al., Crystal structure, thermal properties,
sensitivity test and catalytic activity of an energetic compound [Cu(tza)2]n, Chem.
J. Chin. Univ. 32 (2011) 1870–1875 (in Chinese).
References
[10] Y. Jiao, N. Yan, J. Xie, et al., A simple and efficient copper(II) complex as a catalyst
for N-arylation of imidazoles, Chin. J. Chem. 31 (2013) 267–270.
[11] J. Xie, X. Zhu, M. Huang, et al., Pyrrole-2-carbohydrazides as ligands for Cu-
catalyzed amination of aryl halides with amines in pure water, Eur. J. Org. Chem.
(2010) 3219–3223.
[12] G. Chen, J. Xie, J. Weng, et al., CuI/PPh3/PEG-water: an efficient catalytic system for
cross coupling reaction of aryl iodides and alkynes, Synth. Commun. 41 (2011)
3123–3133.
[1] (a) For some selected reviews, see: H. Gao, J.M. Shreeve, Azole-based energetic
salts, Chem. Rev. 111 (2011) 7377–7436;
(b) Z. Jin, Muscarine, imidazole, oxazole and thiazole alkaloids, Nat. Prod. Rep. 22
(2005) 196–229;
(c) O. Ku¨hl, The chemistry of functionalized N-heterocyclic carbenes, Chem. Soc.
Rev. 36 (2007) 592–607.
