2. Experimental
2.1. Preparation of the materials
dried at 120 °C for 12 h and calcined at 400 °C for 1 h. For synthesis
under microwave irradiation, the reaction mixture was irradiated at
900 W for the specified time with an intermittent cooling interval of
2 min after every 1 min of microwave irradiation.
The MoO3–ZrO2 catalysts were prepared by coprecipitation method
using zirconium oxychloride and ammonium heptamolybdate (S.D.
Fine Chemicals, India, 99.9%) as precursor salts and liquid ammonia as
precipitating agent. Initially, 500 ml of double distilled water was
adjusted to pH 9.0 by addition of liquid ammonia. To this solution
required amount of precursor salt solution (0.5 M) was added drop wise
(20 ml/h) under constant stirring and pH condition. The resulting
aqueous mixture was stirred for 12 h, filtered and washed 5–6 times in
double distilled water (till Cl− free). The obtained material was dried at
120 °C for 12 h in a hot air oven and calcined at 500 °C for 2 h to obtain
the MoO3–ZrO2 catalyst. Using this procedure MoO3–ZrO2 material with
2, 5, 10, 20 and 50 mol% MoO3 were prepared. The MoO3–ZrO2 catalysts
were referred to as xMoZr in the subsequent text, where x represents
the mol% of MoO3 present in the composite oxide. For the sake of
comparison, the MoO3–ZrO2 catalysts were also prepared by wet
impregnation method. Required amount of ammonium heptamolyb-
date was added to ZrO2 aqueous suspension and stirred for 6 h. The
aqueous suspension was heated with constant stirring to remove water,
dried at 120 °C for 12 h followed by calcinations at 500 °C for 2 h. The
MoO3–ZrO2 catalysts prepared by this method were referred to as
xMoZrI in the text, where x represents the mol% of MoO3 in the
composite oxide and I stands for the impregnation method.
3. Results and discussion
3.1. Characterization of the MoO3−ZrO2 catalyst
The XRD patterns of the xMoZr and xMoZrI catalyst are presented in
Figs. 1 and 2. Pure ZrO2 shows intense and well defined diffraction peaks
at 2θ values of 28.3° and 31.5° corresponding to the reflections from the
ꢀ
ꢁ
111 and (111) planes of monoclinic zirconia phase (JCPDS-ICDD file
no. 83–0940) and at 30.2° corresponding to the reflections from the
(101) plane of tetragonal phase (JCPDS-ICDD file no. 81–1545) (Fig. 1a).
The percentage tetragonal phase in the ZrO2 sample is calculated to be
58%. The 2MoZr catalyst contains 69% tetragonal phase (Table 1, Fig. 1b).
Further increase in MoO3 content to 5 mol% and above resulted in the
complete formation of tetragonal phase. No separate crystalline phases
corresponding to MoO3 and Zr(MoO4)2 are detected in the XRD patterns
of the coprecipitated samples even for sample with higher MoO3
loading. This may be due to the presence of MoO3 phase as amorphous
or molecular-type species without well defined crystallinity in the
coprecipitated sample. Pure MoO3 shows well defined diffraction peaks
at 2θ values of 23.3°, 25.6°, 27.2° 33.6° and 49.2° corresponding to the
reflections from the (002), (012), (120), (202) and (400) planes
respectively (JCPDS-ICDD file no. 84–1360) (Fig. 1e). The selective
stabilization of the tetragonal phase was also noted for xMoZr-I samples,
however, the phase transformation is less pronounced. The 10MoZrI,
20MoZrI and 50MoZrI materials contain 69, 81 and 82% tetragonal
phase, respectively. Moreover at higher Mo content the presence of
crystalline MoO3 is clearly observed in the X-ray diffraction patterns of
the 20MoZrI and 50MoZrI samples. The selective formation of the
tetragonal phase can be ascribed to the reduction in the grain boundary
area which prevents the mobility of the ions during phase transforma-
tion. Srinivasan et al. has reported that in sulfated zirconia catalyst the
tetragonal phase is stabilized due to the preferential segregation of the
sulfate ions along the grain boundary [19]. It has also been reported that
there is a critical crystallite size of zirconia below which the tetragonal
phase is stabilized [11]. In the present study, it is believed that the
2.2. Characterization techniques
The XRD patterns of the samples were obtained using Philips PAN
analytical diffractometer fitted with a Ni filtered CuKα1 radiation. The
percentage tetragonal phase in the composite oxide was estimated
using the method described elsewhere [11]. The UV–Visible spectra
were recorded using a Shimadzu spectrophotometer (UV-2450) with
BaSO4 coated integration sphere. The confocal micro-Raman spectra
were recorded on a Horiba Jobin-Yvon LabRam HR spectrometer using a
17 mW internal He–Ne laser source with an excitation wavelength of
632.8 nm. The specific surface areas were determined by BET method
using N2 adsorption/desorption at 77 K employing Quantachrome
Autosorb gas sorption equipment. The composite oxide samples were
degassed at 120 °C for 12 h prior to the sorptometric studies.
Transmission electron micrographs of the samples were recorded
using PHILIPS CM 200 equipment using carbon coated copper grids. The
surface acidity of the MoZr catalysts was determined by employing
titration method [5]. The IR spectra were recorded on a Perkin-Elmer IR
spectrophotometer as KBr pellets. 1H NMR spectra were obtained using
a Bruker spectrometer at 400 MHz using TMS as internal standard. All
the reaction products are known compounds and are identified by
comparing their physical and spectral characteristics with the literature
reported values.
e
d
c
b
a
2.3. Synthesis of amidoalkyl naphthols
Typically, a mixture of β-naphthol (1 mmol), benzaldehyde
(1 mmol), benzamide (1.1 mmol) and 20MoZr (100 mg) was heated
at 80 °C under stirring for the required amount of time. The progress of
the reaction was checked periodically using TLC. After completion of the
reaction, 10 ml of methanol was added to the reaction mixture and the
heterogeneous catalyst wasfiltered. The filtrate was concentrated under
vacuum and the crude residue was purified by crystallization from
ethanol: water (1:1) to afford pure N-[(2-Hydroxynaphthalen-1-yl)
phenylmethyl] benzamide. MP. 241–242 °C; IR (KBr, cm−1): 3420,
3061, 3022, 1629, 1572, 1511, 1435, 1348, 1271, 1049, 822, 696; 1H NMR
(CDCl3, 400 MHz): δ=10.3 (s, 1H), 9.0 (d, 1H), 8.1 (d, 1H), 7.9 (d, 2H),
7.84(d, 1H), 7.8 (d, 1H), 7.6 (t, 1H), 7.4–7.5 (m, 3H), 7.2–7.4 (m, 8H). The
used catalyst was regenerated by washing with methanol (3×10 ml),
Fig. 1. X-ray diffraction patterns of (a) ZrO2, (b) 2MoZr, (c) 5MoZr (d) 10 MoZr and
(e) MoO3.
