Uptake and metabolism of β-apo-8′-carotenal, β-apo-10′-carotenal, and β-apo-13-carotenone in Caco-2 cells

Article abstract of DOI:10.1194/jlr.M093161

β-Apocarotenoids are eccentric cleavage products of carotenoids formed by chemical and enzymatic oxidations. They occur in foods containing carotenoids and thus might be directly absorbed from the diet. However, there is limited information about their in

Full text of DOI:10.1194/jlr.M093161

Uptake and Metabolism of β-apo-8′-carotenal, β-apo-10′-carotenal, and β-apo-13-carotenone in
Caco-2 cells
Boluwatiwi O. Durojaye1, Kenneth M. Riedl2, Robert W. Curley, Jr.3, Earl H. Harrison1
1Department of Human Sciences, 2Department of Food Science and Technology, and 3College of Pharmacy,
The Ohio State University, Columbus OH 43210
Corresponding author:
Earl H. Harrison
1787 Neil Avenue, 314 Campbell Hall,
Columbus, OH 43210 USA.
614-292-8189; harrison.304@osu.edu
Running title: Uptake and Metabolism of β-apocarotenoids in Caco-2 cells
Abbreviations: BCO1: β-carotene 15, 15′-oxygenase, BCO2: β-carotene 9′, 10′-oxygenase, DAD: diode
array detector, MTBE: methyl tert-butyl ether, QTOF: quadrupole time-of-flight, RA: retinoic acid, RAR:
retinoic acid receptor, RT: retention time, RXRα: retinoid X receptor alpha.
1

ABSTRACT
β-Apocarotenoids are eccentric cleavage products of carotenoids formed by chemical and enzymatic
oxidations. They occur in foods containing carotenoids and thus might be directly absorbed from the diet.
However, there is limited information about their intestinal absorption. The present research examined the
kinetics of uptake and metabolism of β-apocarotenoids. Caco-2 cells were grown on six-well plastic plates
until a differentiated cell monolayer was achieved. β-Apocarotenoids were prepared in Tween 40 micelles,
delivered to differentiated cells in serum-free media, and incubated at 37 °C for up to 8 hours. There was
rapid uptake of β-apo-8′-carotenal into cells and β-apo-8′-carotenal was largely converted to β-apo-8′-
carotenoic acid and a minor metabolite that we identified as 5, 6-epoxy-β-apo-8′-carotenol. There was also
rapid uptake of β-apo-10′-carotenal into cells and β-apo-10′-carotenal was converted into a major metabolite
identified as 5, 6-epoxy-β-apo-10′-carotenol and a minor metabolite that is likely a dihydro-β-apo-10′-
carotenol. Finally, there was rapid cellular uptake of β-apo-13-carotenone and this compound was
extensively degraded. These results suggest that dietary β-apocarotenals are extensively metabolized in
intestinal cells via pathways similar to the metabolism of retinal. Thus, they are likely not absorbed directly
from the diet.
Keywords: β-carotene, Absorption, Cell uptake, Carotenoid metabolism, Dietary lipids, Intestine,
Nutrition/Lipids, Vitamin A
2

INTRODUCTION
Vitamin A is a general term for structurally related compounds that have the functional activity of
retinol (1). De novo synthesis of provitamin A carotenoids occurs almost exclusively in plants and some
microorganisms such as algae and fungi (2, 3). Dietary vitamin A can be obtained in two major forms:
preformed vitamin A (retinol and retinyl esters) and provitamin A carotenoids (β-carotene, α-carotene, and
β-cryptoxanthin) (1, 2). Preformed vitamin A is present in animal derived products such as liver, eggs, and
dairy products. In contrast, plant food sources (mostly fruits and vegetables) account for significant intake
of dietary provitamin A carotenoids (2, 3). Sweet potatoes and pumpkin, for example, provide high amounts
of α-carotene; oranges, papaya, and peppers are excellent sources of β-cryptoxanthin; and carrots, squash,
and dark-leafy vegetables are important sources of β-carotene (3, 4).
β-Carotene is an excellent precursor of vitamin A and exhibits this provitamin A activity because
it has two unsubstituted β-ionone rings as well as the correct number and position of methyl groups in its
long hydrocarbon chain (2). Two important enzymes, β-carotene 15, 15′-oxygenase (BCO1) and β-carotene
9′, 10′-oxygenase (BCO2), catalyze the oxidative cleavage of β-carotene to produce biologically active
metabolites (Figure 1) (5). BCO1, localized in the cytosol (6), cleaves β-carotene to give two molecules of
retinal, which can be converted to retinoic acid (RA) or retinol (2, 7). On the other hand, BCO2, localized
in the mitochondria (6, 8), cleaves β-carotene to yield β-ionone and β-apo-10′-carotenal, which can be
converted to retinal by BCO1 (2, 9). Peroxidases and lipoxygenases have been suggested as enzymes that
could catalyze the formation of β-apocarotenoids other than β-apo-10′-carotenal (10). Apocarotenoids are
also formed non-enzymatically via chemical oxidation during food processing and cooking or in tissues
under conditions of oxidative stress.
β-Apocarotenoids have biological activity and previous studies suggest that they may elicit their
functions through gene regulation (5, 7). Retinoic acid receptors (RAR) are a family of transcription factors
that activate genes with retinoic acid response elements as part of their promoter sequence (7, 11). A number
of studies have investigated the binding affinity and effects of β-apocarotenoids on these transcription
3

factors. Work by Eroglu et al. (7) demonstrated that some β-apocarotenoids are potent antagonists of α, β,
and γ isoforms of RARs. β-Apo-14′-carotenoic acid, β-apo-14′-carotenal, and β-apo-13-carotenone were
high affinity ligands for RARs α, β, and γ and significantly antagonized the transactivation of all three RAR
isoforms by RA. Also, these β-apocarotenoids effectively decreased the RA-induced upregulation of RARβ
and cytochrome P450-26A1 in HepG2 cells. In addition, Eroglu et al. (12) examined the effects of β-
apocarotenoids on the activation and signaling of retinoid X receptor alpha (RXRα). β-Apo-13-carotenone
significantly inhibited the 9-cis-RA induced activation of RXRα and its transcriptional response. Molecular
modeling and ligand binding studies showed that β-apo-13-carotenone directly binds to the ligand binding
domain of RXRα.
The exact mechanisms of formation of β-apocarotenoids, other than β-apo-10′-carotenal and
retinal, from β-carotene and other carotenoids consumed in the diet by humans are not fully understood (10,
13). However, these eccentric cleavage products are present in a carotenoid-rich diet. Harrison and
colleagues (14) identified several β-apocarotenoids in cantaloupe and orange-fleshed honeydew melons.
The quantities of β-apo-8′-carotenal, β-apo-10′-carotenal, β-apo-12′-carotenal, β-apo-14′-carotenal, and β-
apo-13-carotenone detected using HPLC-MS were approximately 1.5% of β-carotene in both melons. In
addition, our laboratory has evidence that these β-apocarotenoids are present in pumpkin, sweet potato, and
yellow squash at about 2.5%, 0.4%, and 3% of β-carotene respectively (Fleshman, M.K. and Harrison, E.H.,
Unpublished data). Thus, it is possible that β-apocarotenoids might be directly absorbed from the diet (13).
However, there is limited knowledge about their bioavailability and intestinal absorption.
The Caco-2 intestinal cell line is a well-established in vitro model that has been used to study the
absorption of the C40 carotenes and xanthophylls (15, 16). Differentiated cells have morphological and
functional characteristics comparable to enterocytes (17, 18) and these include very well developed brush
border membranes and tight junctions that decrease the probability of transport of molecules between cells
(19). Thus, Caco-2 cells are a good model to study the apical uptake and metabolism of β-apocarotenoids.
In the present study, we investigated the uptake and metabolism of β-apo-8′-carotenal, β-apo-10′-carotenal,
and β-apo-13-carotenone using Caco-2 cells as a model. We focused specifically on these β-apocarotenoids
4

because β-apo-8′-carotenal is commercially available and is routinely utilized as a food colorant; β-apo-
10′-carotenal is the major product of BCO2 cleavage of β-carotene; and β-apo-13-carotenone, with a similar
structure to retinol, has been shown to be a potent antagonist of vitamin A signaling.
5

MATERIALS AND METHODS
Chemicals and Supplies
Unless otherwise stated, all chemicals and supplies were purchased from Sigma-Aldrich (St. Louis,
MO) or Fisher Scientific (Pittsburgh, PA). Cell culture reagents were obtained from Gibco® Life
Technologies Corporation (Grand Island, NY). TLC plates were purchased from Analtech (Newark, DE).
Plates were 20 cm by 20 cm glass backed with a 1000 micron layer of silica gel containing a fluorescent
indicator. The synthesis of β-apo-8′-carotenoic acid, β-apo-10′-carotenal, β-apo-10′-carotenoic acid, β-apo-
12′-carotenal, and β-apo-13-carotenone have been described previously (7). In addition, β-apo-10′-
carotenol was synthesized as described elsewhere (20). Finally, β-apo-8′-carotenol and 5, 6-epoxy-β-apo-
8′-carotenol were synthesized according to the methods described below.
Synthesis of β-Apocarotenoids
Synthesis of β-apo-8′-carotenol
5 mg of β-apo-8′-carotenal, 15 mg (3.3 equiv.) of sodium borohydride, 5 mL of absolute ethanol,
and 2 mL of toluene were mixed in a dry round bottom flask under argon with magnetic stirring. After 30
minutes, the color of the mixture had not changed. After 1 hour, the mixture became a little lighter colored.
More sodium borohydride was added, the reaction mixture stirred for 30 minutes, and 1 mL of 4 °C
saturated ammonium chloride was added. The mixture was now still lighter in color and was partitioned
between saturated sodium chloride and ethyl acetate. The ethyl acetate layer was dried over sodium sulfate,
filtered, and concentrated under reduced pressure. The dried residue was resolubilized in ethyl acetate,
spread onto a preparative TLC plate, and allowed to develop for 40 minutes using 20% ethyl
acetate/hexanes as mobile phase. The lower band, tentatively identified as β-apo-8′-carotenol was
suspended and stirred in acetone for 20 minutes, filtered, and concentrated under reduced pressure. The
newly synthesized compound was then characterized by NMR and HPLC (see HPLC analysis - method 1).
Synthesis of 5, 6-epoxy-β-apo-8′-carotenol
6

13.6 mg of previously synthesized β-apo-8′-carotenol was dissolved in approximately 10 mL of
dichloromethane and placed in an oven dried round bottom flask with a magnetic stirrer and an argon inlet.
After cooling to 4 °C, 8.9 mg (1.2 equiv.) of meta-chloroperoxybenzoic acid was added. The mixture lost
its color immediately. The ice bath was removed and stirring continued for 4 hours. The solution was
washed twice with saturated sodium bicarbonate, then with distilled water followed by saturated sodium
chloride, and dried over sodium sulfate. Filtration and concentration under reduced pressure afforded crude
product, which was purified by preparative TLC and characterized as for β-apo-8′-carotenol.
Cell Culture Conditions
Caco-2 cells were obtained from the American Type Culture Collection (Rockville, MD). Cells
were grown and maintained as described elsewhere (21). Briefly, 75 cm2 flasks were seeded with 0.4 × 106
cells and grown in DMEM containing 25 mM glucose, 15% heat-inactivated FBS, 1% penicillin-
streptomycin, 1% L-glutamine (200 mM), 1% non-essential amino acids, and 1% fungizone. Cells were
incubated at 37 °C in an atmosphere of air/CO2 (95:5 v/v) and cells were passaged every 7 days or when
cells were at 75–80% confluency.
Preparation of β-Apocarotenoids for Uptake Studies
We prepared β-apocarotenoids in Tween 40 as previously described (15) with some changes and
delivered them in serum-free media to cells (see description below). Briefly, β-apocarotenoids were
solubilized in either hexane or ethanol to prepare a stock solution of the pure compounds. The required
volume of each β-apocarotenoid dissolved in appropriate solvent, 22.5 µL of 10% v/v Tween 40 (in
ethanol), and 400 µL of acetone were placed into a 4 mL glass vial. The resulting mixture was dried under
stream of nitrogen gas at 30–40 °C, resolubilized in 200 µL of acetone, and dried again. Dried residues
were solubilized in 1 mL of serum-free media, vortexed briefly, and sonicated for 1 minute. The resulting
mixture was dissolved in additional serum-free media to yield the desired test concentrations of the clear
micellar solutions.
7

Stability of β-Apocarotenoids during Incubation in Cell Culture Conditions
Previous studies have shown that carotenoids are susceptible to spontaneous chemical oxidation
and degradation during incubation in cell culture environment (22, 23). Thus, we investigated the stability
of the β-apocarotenoids in the same cell culture conditions as were used for the cell uptake experiments.
The method for preparing β-apocarotenoids in Tween 40 has been described above. For the stability
experiments, 2 mL of serum-free media, containing the individual β-apocarotenoids (β-apo-8′-carotenal, β-
apo-10′-carotenal, and β-apo-13-carotenone), was added to six-well plates without Caco-2 cells and
incubated at 37 °C for time points up to 8 hours. Aliquots of media at 0, 1, 4, and 8 hours were collected
and stored at –80 °C before extraction and HPLC analysis.
Uptake of β-Apocarotenoids into Caco-2 Cells
For experiments, six-well plates were seeded with 0.15 × 106 cells and maintained in cell culture
conditions described above until a confluent monolayer was achieved. Once confluent, the amount of FBS
used in media was decreased to 7.5% and the media was regularly replaced after 2 days. Cell cultures used
for experiments were between passages 22–40 when monolayers were 10–14 days post-confluent (i.e. fully
differentiated). At the start of each experiment, cell monolayers were washed once with basal DMEM. 2
mL of serum-free media, containing a known concentration of each β-apocarotenoid (β-apo-8′-carotenal,
β-apo-10′-carotenal, and β-apo-13-carotenone), was added to each well and incubated at 37 °C.
After incubation, the integrity of the monolayer was examined by phase contrast microscopy and
media containing the test compound was collected into a 15 mL centrifuge tube. There were no observed
changes in morphology of cell monolayers after treatment with any β-apocarotenoids. Cell monolayers
were washed once with 2 mL of ice-cold PBS containing 2 g/L bovine serum albumin and twice with 2 mL
of ice-cold PBS to remove extracellular β-apocarotenoids. 2 mL of ice-cold PBS was added to each well
and cells were harvested into 15 mL centrifuge tubes using a plastic scraper. Tubes were then centrifuged
8

at 1000 × g for 10 minutes at 4 °C. The supernatant was discarded and the cell pellets were stored under
nitrogen gas at –80 °C before extraction and HPLC analysis (24).
Extraction of β-Apocarotenoids
Extraction from media
Cell culture media samples before and after incubation were extracted according to the method of
Kopec et al. (25) with slight modifications. Briefly, 1 mL of media and 1 mL of acetone were placed in a
15 mL centrifuge tube and vortexed for 1 minute. 4 mL of hexanes was added and the mixture was vortexed
again for 1 minute. The resulting mixture was then centrifuged at 3000 × g for 10 minutes at 4 °C. The
upper layer was transferred into an 11 mL screw cap glass vial and solvent was dried under a stream of
nitrogen gas at 30–40 °C. Extracts were then stored at –80 °C before HPLC analysis.
Extraction from cell monolayer
Cell pellets were resuspended in 1 mL of PBS and probe sonicated for 20 seconds. 1 mL of acetone
was added and the tube was vortexed for 1 minute. 4 mL of hexanes was added and the mixture was vortexed
again for 1 minute. The resulting solution was then centrifuged at 3000 × g for 10 minutes at 4 °C. The
upper layer was transferred into an 11 mL screw cap glass vial and solvent was dried under a stream of
nitrogen gas at 30–40 °C. Extracts were stored at –80 °C before HPLC analysis.
HPLC Analysis
Method 1: Analysis of β-apo-8′-carotenal and β-apo-10′-carotenal
Sample extracts were solubilized in 200 µL of 1:1 v/v methanol/methyl tert-butyl ether (MTBE),
syringe filtered (0.22 µm pores; Millipore), and 20 µL of the extract was injected for analysis. Separation
of β-apocarotenoids was achieved using a YMC C30 column (4.6 × 150 mm, 5 µm; Waters, Ireland) on an
Agilent 1200 series HPLC system coupled to a diode array detector (DAD) (Agilent Technologies, Santa
Clara, CA) with a mobile phase of 98:2 v/v methanol/1 M ammonium acetate pH 4.6 (solvent A) and MTBE
(solvent B). The flow rate was set at 0.8 mL/minute and a column temperature of 35 °C was maintained.
9

Analytes were separated with a linear gradient from 15% B to 40% B over 10 minutes, followed by elution
at 40% B for 10 minutes before re-equilibrating to the initial conditions for 4.1 minutes. Elution was
monitored at 380 nm, 450 nm, and 460 nm for β-apo-8′-carotenal and at 380 nm and 438 nm for β-apo-10′-
carotenal. β-Apocarotenoids in samples were quantified by comparing the peak area against a standard
curve prepared with pure standard compounds.
Method 2: Analysis of β-apo-13-carotenone
Sample extracts were dissolved in 200 µL of 1:1 v/v methanol/HPLC-MS grade water, syringe
filtered (0.22 µm pores; Millipore), and 20 µL of the extract was injected for analysis. The HPLC system
and column used for this analysis were described in method 1. The composition of the mobile phase was
methanol (solvent A) and HPLC-MS grade water (solvent B). The flow rate was set at 0.8 mL/minute and
a column temperature of 35 °C was maintained. Analytes were separated with 15% B for 15 minutes and
elution was monitored at 345 nm. β-Apo-13-carotenone in samples was quantified by comparing the peak
area against a standard curve prepared with known concentrations of pure β-apo-13-carotenone.
UHPLC-MS Analysis of Cellular Metabolites
Method 1: Analysis of cellular metabolites of β-apo-8'-carotenal
Cellular metabolites of β-apo-8'-carotenal were separated by an Agilent 1290 Infinity I UHPLC
(Agilent Technologies, Santa Clara, CA) using a YMC C30 column (2.0 × 150 mm, S3; Waters
Corporation, Milford, MA) with a mobile phase of 80% methanol/20% water (solvent A) and 78%
MTBE/20% methanol/2% water (solvent B) where both mobile phases contained 2% (w/v) ammonium
acetate. The flow rate was set at 0.4 mL/minute and ramped up linearly from 0% B to 60% B over 7 minutes
and re-equilibrated over the subsequent 5 minutes. The column temperature was maintained at 45 °C. The
entire eluent flow was introduced to an Agilent 6550 quadrupole time-of-flight (QTOF) mass spectrometer
(Agilent Technologies, Santa Clara, CA) with positive ion electrospray source parameters of 400 °C sheath
gas at 12 L/minute, 150 °C drying gas at 18 L/minute, 30 psi nebulizer, 3 kV Vcap, and 1.5 kV nozzle. Ion
10

funnel settings were 90 V low pressure funnel, 200 V high pressure funnel. Also, there was a DAD inline
to collect UV-vis spectra from 230 nm through 640 nm.
Method 2: Analysis of cellular metabolites of β-apo-10'-carotenal
Cellular metabolites of β-apo-10'-carotenal were analyzed by an Agilent 1290 Infinity I UHPLC
(Agilent Technologies, Santa Clara, CA) using an ACE super C18 column (2.1 × 150 mm, 2 µm; Advanced
Chromatography Technologies, Scotland) with a mobile phase of 80% methanol/20% water (solvent A)
and 78% MTBE/20% methanol/2% water (solvent B) where both mobile phases contained 2% (w/v)
ammonium acetate. The flow rate was set at 0.5 mL/minute and a column temperature of 45 °C was
maintained. Analytes were separated with 10% B for 1.5 minutes, followed by a linear gradient over 7
minutes to 65% B and subsequently to 100% B over 2 minutes before re-equilibrating to the initial
conditions for 2 minutes. The entire eluent flow was introduced to an Agilent 6550 QTOF mass
spectrometer (Agilent Technologies, Santa Clara, CA) with positive ion electrospray source parameters of
400 °C sheath gas at 12 L/minute, 150 °C drying gas at 18 L/minute, 30 psi nebulizer, 3 kV Vcap, and 1.5
kV nozzle. Ion funnel settings were 90 V low pressure funnel, 200 V high pressure funnel. Also, there was
a DAD inline to collect UV-vis spectra from 230 nm through 640 nm.
Statistical Analyses
All data are presented as means and standard deviations. Means and standard deviations were
calculated using Microsoft Excel 2013 (Microsoft Corporation, Redmond, WA). Graphs were produced
using GraphPad Prism version 4.00 for Windows (GraphPad Software, San Diego, CA).
11

RESULTS
Stability of β-Apo-8′-carotenal, β-Apo-10′-carotenal, and β-Apo-13-carotenone
Given that β-apocarotenoids can undergo chemical oxidation and degradation during incubation in
cell culture, we investigated the stability of these compounds in the same conditions as were used for the
cell uptake experiments. Serum-free media containing 1 µM or 5 µM of individual β-apocarotenoids (β-
apo-8′-carotenal, β-apo-10′-carotenal, and β-apo-13-carotenone) were incubated in six-well plates without
cells for up to 8 hours. Percentage recovery of β-apocarotenoids was calculated relative to the concentration
of β-apocarotenoids in serum-free media at the start of the experiment. Figure 2 summarizes the results for
the stability of β-apocarotenoids in cell culture conditions. After 1 hour of incubation, the recovery of 1 µM
β-apo-8′-carotenal in serum-free media was 97.9% whereas the recovery of 5 µM β-apo-8′-carotenal was
93.3% at the same incubation time. There was a slight degradation of β-apo-8′-carotenal as incubation time
increased but our recovery of this β-apocarotenal was still good. Specifically, the recovery of 1 µM β-apo-
8′-carotenal in serum-free media was 86.1% after 8 hours of incubation. We obtained similar results for the
stability of 5 µM β-apo-8′-carotenal after 8 hours of incubation.
Similarly, the recovery of β-apo-10′-carotenal at early time points was very good. The recovery of
1 µM β-apo-10′-carotenal in serum-free media was 106.0% after 1 hour of incubation while the recovery
of 5 µM β-apo-10′-carotenal was 102.2% after 1 hour of incubation. As with β-apo-8′-carotenal, there was
also minimal degradation of β-apo-10′-carotenal as incubation time increased. The recovery of 1 µM β-
apo-10′-carotenal in serum-free media was 73.7% after 8 hours of incubation. On the other hand, we
obtained a higher recovery (85.2%) after 8 hours of incubation for 5 µM β-apo-10′-carotenal. Furthermore,
after 1 hour of incubation, the recovery of 1 µM β-apo-13-carotenone in serum-free media was 91.3% while
the recovery of 5 µM β-apo-13-carotenone was 93.9% at the same incubation time. There was some
degradation of β-apo-13-carotenone in serum-free media as incubation time increased. Specifically, the
recovery of 1 µM β-apo-13-carotenone in media was 76.6% after 8 hours of incubation. In contrast, the
recovery of 5 µM β-apo-13-carotenone was 86.8%. The results of these stability experiments are important
12

because they established that these compounds are very stable under cell culture conditions and do not
rapidly degrade before we incubate them with cells.
Kinetics of Uptake of β-Apo-8′-carotenal: Effect of Incubation Time and Initial β-Apo-8′-carotenal
Concentration
We investigated the kinetics of uptake of β-apo-8′-carotenal as a function of incubation time and
concentration. Figures 3 - 6 summarize the results. Figure 3a shows a representative chromatogram of the
uptake of β-apo-8′-carotenal into Caco-2 cells. The UV absorption spectra of the indicated peaks are also
given (Figure 3b). When cells were incubated with β-apo-8′-carotenal for 1 hour, we detected two peaks
(initially named compounds X and Y) in addition to β-apo-8′-carotenal. Compound X was the major peak
detected while compound Y and β-apo-8′-carotenal were present in small amounts. Our HPLC conditions
enabled us to resolve both cellular metabolites from the parent apocarotenal. We also observed that
compounds X and Y do not get released into the media after they are formed within cells. We then
determined the identities of the cellular metabolites detected. The components of cell extracts obtained after
incubation with β-apo-8′-carotenal were separated by UHPLC (Figure 4a) and the accurate masses of the
cellular metabolites were determined using a high resolution mass spectrometer. The major peak, compound
X, differed from β-apo-8′-carotenal by a mass of +16 while the minor peak, compound Y, differed from β-
apo-8′-carotenal by a mass of +18 (Figure 4b, Table 1).
Based on this UHPLC-MS analysis, we proposed putative compounds that could be metabolites X
and Y. The proposed compounds were synthesized, purified by TLC, and characterized by NMR
spectroscopy. Subsequently, we analyzed the synthetic compounds by HPLC-DAD (see HPLC analysis -
method 1) and compared their retention times (RT) and UV absorption spectra to those of the cellular
metabolites of β-apo-8′-carotenal. Based on accurate mass as well as identical RT and UV absorption
spectrum of an authentic standard, compound X was confirmed as β-apo-8′-carotenoic acid. In addition, we
identified the minor peak (Y) as 5, 6-epoxy-β-apo-8′-carotenol based on its accurate mass, RT, and UV
absorption spectrum showing fine structure consistent with an alcohol and a hypsochromic shift in
13

absorption maximum consistent with the loss of a double bond (Figure 3b, Table 1). Figure 5a shows the
kinetics of uptake of β-apo-8′-carotenal for an individual experiment. Fully differentiated Caco-2 cells were
incubated with 1 µM β-apo-8′-carotenal for 30 minutes - 8 hours. As mentioned previously, we observed
the rapid accumulation of β-apo-8′-carotenal in cells and detected two metabolites, the major one of which
was confirmed as β-apo-8′-carotenoic acid and the other we identified as 5, 6-epoxy-β-apo-8′-carotenol.
We observed that the formation of β-apo-8′-carotenoic acid in cells increased as a function of incubation
time and this corresponds with a decrease in the concentration of β-apo-8′-carotenal that accumulated within
cells. In addition, we observed the disappearance of β-apo-8′-carotenal from media as a function of
incubation time (Figure 5b).
Taken together with the cell uptake data, we calculated the percent recovery of β-apo-8′-carotenal
at each incubation time point. In preliminary experiments, we observed the rapid uptake of β-apo-8′-
carotenal into cells but we could only account for about 10% of this apocarotenal after 24 hours of
incubation (data not shown). Thus, we reduced our maximum incubation time to 8 hours. β-Apo-8′-
carotenal and β-apo-8′-carotenoic acid accounted for 97.3% of the initial β-apo-8′-carotenal concentration
after 30 minutes of incubation and both of those compounds accounted for 83.2% of the initial β-apo-8′-
carotenal concentration after 1 hour of incubation. These recovery values were expected because there is
some degradation of β-apo-8′-carotenal with increasing incubation time. Also, the amount of 5, 6-epoxy-β-
apo-8′-carotenol that accumulated in Caco-2 cells was much lower than that of β-apo-8′-carotenoic acid
based on peak height comparisons (Figure 3a). We also studied the uptake of β-apo-8′-carotenal as a
function of concentration. Figure 6 describes the dose dependent accumulation of β-apo-8′-carotenal into
Caco-2 cells. When differentiated monolayers were incubated with β-apo-8′-carotenal (1–5 µM) for 4
hours, we observed that the amount of β-apo-8′-carotenal in cells increased with increasing initial
concentration of β-apo-8′-carotenal. Also, we observed that the formation of β-apo-8′-carotenoic acid in
cells increased linearly. Similarly to the time course experiments, the amount of 5, 6-epoxy-β-apo-8′-
carotenol formed within cells was much lower than that of β-apo-8′-carotenoic acid based on peak height
comparisons for the different levels of concentration we studied (data not shown).
14

Kinetics of Uptake of β-Apo-10′-carotenal: Effects of Incubation Time
We investigated the kinetics of uptake of β-apo-10′-carotenal into Caco-2 cells as a function of
incubation time. Figure 7a is a representative chromatogram of the uptake and metabolism of β-apo-10′-
carotenal in Caco-2 cells. The UV absorption spectra of the indicated peaks are also shown (Figure 7b).
When cells were incubated with β-apo-10′-carotenal for 30 minutes, two peaks (initially named compounds
A and B) were detected along with β-apo-10′-carotenal. Compound A was the major peak detected whereas
compound B and β-apo-10′-carotenal were present in minor amounts. We also observed that compounds A
and B do not get released into the media after they are formed within cells. We next established the identities
of cellular metabolites A and B. Compound A elutes at 3.63 minutes and its UV absorption spectrum has a
fine structure with absorption maxima at 378 nm and 394 nm. On the other hand, compound B elutes at
4.01 minutes and its UV absorption spectrum has a fine structure with absorption maxima at 379 nm and
395 nm. This indicates that both compounds are more hydrophilic than β-apo-10′-carotenal. We initially
thought that the cellular metabolites of β-apo-10′-carotenal would be similar to those observed with β-apo-
8′-carotenal. Hence, we analyzed several short-chain β-apocarotenoids in the same HPLC-DAD conditions
used to separate β-apo-10′-carotenal and its metabolites. The standard compounds examined were β-apo-
13-carotenone, retinal, retinoic acid, β-apo-12′-carotenal, β-apo-10′-carotenoic acid, and β-apo-10′-
carotenol. However, none of these compounds eluted at the same RT as A or B (Figure 8).
We then determined the accurate masses of both metabolites using a high resolution mass
spectrometer. The major peak, compound A, differed from β-apo-10′-carotenal by a mass of +18 whereas
the minor peak, compound B, differed from β-apo-10′-carotenal by a mass of +4 (Table 2). Based on
accurate mass, RT, and UV absorption spectra showing fine structure consistent with an alcohol and a
hypsochromic shift in absorption maximum consistent with the loss of a double bond, compound A was
identified as 5, 6-epoxy-β-apo-10ʹ-carotenol while compound B is likely a dihydro-β-apo-10ʹ-carotenol
(Figure 7b, Table 2). Figure 9a shows the kinetics of uptake of β-apo-10′-carotenal for an individual
experiment. We observed the rapid uptake of β-apo-10′-carotenal into cells up to 1 hour. There was a
15

subsequent decrease in cellular accumulation of β-apo-10′-carotenal with increasing incubation time (data
not shown). Also, we observed the disappearance of β-apo-10′-carotenal from media as a function of time
(Figure 9b). We then determined the recovery of β-apo-10′-carotenal in cells and media after incubation.
The percent recovery of β-apo-10′-carotenal after incubation was about 75.5% at 15 minutes, 71.0% at 30
minutes, 73.6% at 45 minutes, and 57.6% at 1 hour.
Effects of Incubation Time and Initial β-Apo-13-carotenone Concentration on the Uptake and
Metabolism of β-Apo-13-carotenone
We investigated the kinetics of uptake of β-apo-13-carotenone into Caco-2 cells as a function of
incubation time and concentration. Figure 10a is a representative chromatogram of the uptake of β-apo-13-
carotenone into Caco-2 cells. The UV absorption spectra of the indicated peaks are also given (Figure 10b).
In contrast to the β-apocarotenals, we did not detect any UV-absorbing metabolites when cells were
incubated with 5 µM β-apo-13-carotenone for 30 minutes or 8 hours. Figure 11a summarizes the kinetics
of uptake of β-apo-13-carotenone as a function of incubation time. We observed the rapid uptake of β-apo-
13-carotenone into cells but subsequent extensive degradation with increasing incubation time. Also, we
observed the disappearance of β-apo-13-carotenone from media as a function of time (Figure 11b). In
addition, we determined the recovery of β-apo-13-carotenone in cells after incubation. Initial experiments
had shown that β-apo-13-carotenone recovery in cells after 4 hours of incubation was less than 5% (data
not shown). Thus, we reduced our maximum incubation time to 1 hour. The percent recovery of β-apo-13-
carotenone after incubation was about 62.1% at 15 minutes, 59.2% at 30 minutes, 53.1% at 45 minutes, and
49.6% at 1 hour. These recovery values were expected because there is some degradation of β-apo-13-
carotenone with increasing incubation time. Figure 12 summarizes the dose dependent accumulation of β-
apo-13-carotenone into Caco-2 cells. Fully differentiated monolayers of Caco-2 cells were incubated for 45
minutes with β-apo-13-carotenone (1–5 µM). We observed that the cellular accumulation of β-apo-13-
carotenone increased with increasing initial concentration of β-apo-13-carotenone.
16

DISCUSSION
β-Apocarotenoids are eccentric cleavage products of carotenoids formed by chemical and
enzymatic oxidations. These cleavage products demonstrate potent bioactivity in different experimental
models. β-Apocarotenoids inhibit the cell proliferation of breast tumor cells via an RAR-independent
mechanism (26) and human leukemia cell line HL-60 (27). These compounds have also been shown to
upregulate the gene expression of adipocyte markers during the differentiation of 3T3-L1 cells (28). In
addition, β-apocarotenoids can bind to retinoid- and/or lipid-responsive transcription factors and may
modulate these proteins’ abilities to stimulate transcription of target genes (7, 11, 12). The presence of β-
apocarotenoids in carotenoid-rich fruits, vegetables, and other plant food items has been reported by our
laboratory (14) and others (29-31). Furthermore, numerous lines of evidence demonstrate that these
eccentric cleavage products are detected in the serum or tissues of WT (32-34) and BCO knockout animals
(34, 35) as well as the plasma of humans consuming diets containing carotenoids or given a bolus of β-
carotene (7, 36). Collectively, these data suggest that β-apocarotenoids might be directly absorbed from the
diet. Here, we have examined the uptake of β-apo-8′-carotenal, β-apo-10′-carotenal, and β-apo-13-
carotenone into Caco-2 cells. Also, we have demonstrated the metabolism of these eccentric cleavage
products after cellular uptake.
When cells were incubated with β-apo-8′-carotenal for 1 hour, we detected two peaks (initially
named compounds X and Y) in addition to β-apo-8′-carotenal. Compound X was the major peak detected
while compound Y and β-apo-8′-carotenal were present in minor amounts (Figure 3a). Based on accurate
mass as well as identical RT and UV absorption spectrum of an authentic standard, compound X was
confirmed as β-apo-8ʹ-carotenoic acid. Compound Y was identified as 5, 6-epoxy-β-apo-8ʹ-carotenol based
on its accurate mass, RT, and UV absorption spectrum showing fine structure consistent with an alcohol
and a hypsochromic shift in absorption maximum consistent with the loss of a double bond (Figure 3b,
Table 1). The results presented here are in agreement with previous studies that examined the absorption of
β-apo-8′-carotenal in different species. Early work detected β-apo-8ʹ-carotenoic acid as a urinary metabolite
in dogs given a daily dose of β-apo-8ʹ-carotenal (37). Subsequent work by multiple research groups also
17

corroborate that this apocarotenoic acid is a major metabolite present in the serum and tissues of animals
fed β-apo-8ʹ-carotenal (38, 39). In one of those studies, the intact aldehyde and β-apo-8ʹ-carotenol were
also present in minor amounts (38). This is similar to what is observed in the present study - the difference
being that we detected 5, 6-epoxy-β-apo-8ʹ-carotenol.
Although there is limited evidence, it is not too far-fetched to suggest that β-apo-8ʹ-carotenal is
similarly converted to β-apo-8ʹ-carotenoic acid in humans. Olson and colleagues (40) examined the uptake
and metabolism of a single dose of β-apo-8ʹ-carotenal in healthy male volunteers with adequate vitamin A
status. β-Apo-8ʹ-carotenal was rapidly absorbed and was extensively metabolized in all subjects. Serum
metabolites observed were β-apo-8ʹ-carotenoic acid, β-apo-8ʹ-carotenol, β-apo-8ʹ-carotenyl palmitate, β-
apo-10ʹ-carotenol, and β-apo-12ʹ-carotenal. Unsurprisingly, the unchanged aldehyde was only detected in
minor amounts. Taken together, these data suggest that the major proportion of β-apo-8ʹ-carotenal is
metabolized to the corresponding β-apocarotenoic acid (38). This metabolic conversion is similarly
observed with retinal, which can be converted to retinol or retinoic acid. Previous studies also demonstrate
the formation of epoxy metabolites of vitamin A in vivo (41, 42). Thus, we propose that β-apo-8ʹ-carotenal
taken up from carotenoid-rich foods is metabolized by intestinal cells according to the pathway shown in
Figure 13.
We next investigated the uptake and metabolism of β-apo-10′-carotenal in cells. In vitro enzymatic
assays show that β-apo-10′-carotenal is the major product of eccentric cleavage of β-carotene by BCO2 (43,
44). The unchanged aldehyde has been detected in the plasma and tissues of mice on a β-carotene containing
diet (45). The corresponding alcohol and acid are also generated in vivo (35). WT and BCO1-/- but not
BCO2-/- and BCO1-/-/BCO2-/- mice accumulate β-apo-10′-carotenol, mainly in its esterified form, and β-
apo-10′-carotenoic acid in their livers when given a diet with β-carotene as the only vitamin A source (35,
44). There is renewed interest in β-apo-10′-carotenoids because of emerging reports about the role these
compounds play in embryogenesis. Costabile et al. (20) showed that β-apo-10′-carotenal and β-apo-10′-
carotenol are biologically active metabolites that regulate placental lipoprotein biosynthesis and allow for
effective transport of β-carotene from the maternal circulation to the embryo independent of changes to the
18

mRNA expression of RA target genes. Instead, these β-apocarotenoids activate hepatic nuclear factor 4α,
which in turn upregulates the gene expression and activity of the placental microsomal triglyceride transfer
protein (20), which is important for the assembly and secretion of apoB containing lipoproteins (46, 47).
Recently, Quadro and colleagues showed that β-apo-10′-carotenal can support normal embryonic
development during periods of vitamin A deficiency (48).
Caco-2 cells incubated with β-apo-10′-carotenal for 30 minutes produced two peaks detected by
HPLC-DAD (Figure 7a). The two metabolites, appearing at RT 3.63 minutes (compound A) and 4.01
minutes (compound B) both have UV absorption spectra with fine structure. Compound A has absorption
maxima at 378 nm and 394 nm whereas compound B has absorption maxima at 379 nm and 395 nm. We
initially thought that the cellular metabolites of β-apo-10′-carotenal would be similar to those observed with
β-apo-8′-carotenal. Thus, we analyzed β-apo-13-carotenone, retinal, retinoic acid, β-apo-12′-carotenal, β-
apo-10′-carotenoic acid, and β-apo-10′-carotenol by HPLC-DAD. However, none of the compounds tested
had the RT or absorption maxima of the metabolites (Figure 8). We then determined the accurate masses
of both metabolites using a high resolution mass spectrometer. Based on accurate mass, RT, and UV
absorption spectrum showing fine structure consistent with an alcohol and a hypsochromic shift in
absorption maximum consistent with the loss of a double bond, compound A was identified as 5, 6-epoxy-
β-apo-10ʹ-carotenol whereas compound B is likely a dihydro-β-apo-10ʹ-carotenol (Figure 7b, Table 2).
Several studies suggest that β-oxidation, involving the stepwise cleavage of two carbons, is a
possible pathway for the metabolism of β-apocarotenoids to shorter chain β-apocarotenoids, retinal, and
retinoic acid. Wang et al. (49) showed that β-apo-10′-carotenoic acid, β-apo-12′-carotenoic acid, and β-apo-
14′-carotenoic acid are produced following in vitro incubation of β-apo-8′-carotenoic acid with
mitochondrial fractions isolated from rabbit livers. Similarly, Al-Hasani et al. (39) reported the formation
of β-apo-10′-carotenoic acid and β-apo-12′-carotenoic acid in the serum and tissues of vitamin A-depleted
quails maintained on a diet with β-apo-10′-carotenal as the only source of provitamin A activity. We have
now proposed two additional metabolites (5, 6-epoxy-β-apo-10ʹ-carotenol and a dihydro-β-apo-10ʹ-
19

carotenol) that may be formed when β-apo-10ʹ-carotenal taken up from carotenoid-rich foods is metabolized
by intestinal cells. The chemical structures for the newly proposed metabolites are shown in Figure 14.
We also examined the uptake and metabolism of β-apo-13-carotenone. Caco-2 cells incubated with
β-apo-13-carotenone for 30 minutes produced an individual peak with RT and absorption maximum
equivalent to authentic β-apo-13-carotenone standard. On the other hand, when cells were incubated with
β-apo-13-carotenone for 4 or 8 hours, no peaks were detected (Figure 10). One possible explanation is that
the β-apo-13-carotenone might be metabolized to short chain metabolites with limited UV absorption. We
also cannot rule out the possibility that the compound was converted into metabolites with UV absorption
but that once the metabolites were generated, they were rapidly degraded.
In summary, our results are consistent with a recent clinical trial showing a lack of direct absorption
of β-apocarotenals in healthy volunteers consuming a daily dose of high β-carotene tomato juice, containing
precisely quantitated amounts of β-apocarotenals, for 4 weeks (31). The findings from that study also
support our conclusions that β-apocarotenals are rapidly metabolized in the intestine. In contrast to the β-
apocarotenals, β-apo-13-carotenone was quantitatively detected in all subjects including the control group
consuming a carotenoid-free juice. Thus, the authors of that study concluded that β-apo-13-carotenone
could possibly be formed from the oxidative cleavage of preformed vitamin A. Further research is required
to understand the mechanisms of absorption and metabolism of β-apocarotenoids in animal models and
humans.
20

ACKNOWLEDGEMENTS/GRANT SUPPORT
We thank Dr. Mark L. Failla for his expert technical assistance and contributions to the successful
completion of this research project. We also thank Dr. Chureeporn Chitchumroonchokchai for laboratory
training in aseptic cell culture techniques and assistance with carotenoid extraction protocols. This work
was supported by funds from the National Institutes of Health Grant R01-HL049879 and the Virginia M.
Vivian Graduate Student Research Award (College of Education and Human Ecology, The Ohio State
University). The content is solely the responsibility of the authors and does not necessarily represent the
official views of the National Institutes of Health. The authors declare that they have no conflict of interest.
All authors have reviewed and approved the final manuscript.
21

REFERENCES
1.
Ross, C. A., and E. H. Harrison. 2007. Vitamin A: Nutritional Aspects of Retinoids and
Carotenoids. In Handbook of Vitamins. J. Zempleni, R. B. Rucker, D. B. McCormick, and J. W. Suttie,
editors. CRC Press, Boca Raton, FL. 2-30.
2.
Harrison, E. H. 2012. Mechanisms involved in the intestinal absorption of dietary vitamin A and
provitamin A carotenoids. Biochim. Biophys. Acta 1821: 70-77.
3.
During, A., and E. H. Harrison. 2004. Intestinal absorption and metabolism of carotenoids: insights
from cell culture. Arch. Biochem. Biophys. 430: 77-88.
4.
Weber, D., and T. Grune. 2012. The contribution of beta-carotene to vitamin A supply of humans.
Mol. Nutr. Food Res. 56: 251-258.
5.
Sharoni, Y., K. Linnewiel-Hermoni, M. Khanin, H. Salman, A. Veprik, M. Danilenko, and J. Levy.
2012. Carotenoids and apocarotenoids in cellular signaling related to cancer: a review. Mol. Nutr. Food
Res. 56: 259-269.
6.
Raghuvanshi, S., V. Reed, W. S. Blaner, and E. H. Harrison. 2015. Cellular localization of beta-
carotene 15,15' oxygenase-1 (BCO1) and beta-carotene 9',10' oxygenase-2 (BCO2) in rat liver and intestine.
Arch. Biochem. Biophys. 572: 19-27.
7.
Eroglu, A., D. P. Hruszkewycz, C. dela Sena, S. Narayanasamy, K. M. Riedl, R. E. Kopec, S. J.
Schwartz, R. W. Curley, Jr., and E. H. Harrison. 2012. Naturally occurring eccentric cleavage products of
provitamin A beta-carotene function as antagonists of retinoic acid receptors. J. Biol. Chem. 287: 15886-
15895.
22

8.
Amengual, J., G. P. Lobo, M. Golczak, H. N. Li, T. Klimova, C. L. Hoppel, A. Wyss, K.
Palczewski, and J. von Lintig. 2011. A mitochondrial enzyme degrades carotenoids and protects against
oxidative stress. FASEB J. 25: 948-959.
9.
dela Sena, C., S. Narayanasamy, K. M. Riedl, R. W. Curley, Jr., S. J. Schwartz, and E. H. Harrison.
2013. Substrate specificity of purified recombinant human beta-carotene 15,15'-oxygenase (BCO1). J. Biol.
Chem. 288: 37094-37103.
10.
Harrison, E. H., C. dela Sena, A. Eroglu, and M. K. Fleshman. 2012. The formation, occurrence,
and function of beta-apocarotenoids: beta-carotene metabolites that may modulate nuclear receptor
signaling. Am. J. Clin. Nutr. 96: 1189S-1192S.
11.
Ziouzenkova, O., G. Orasanu, G. Sukhova, E. Lau, J. P. Berger, G. Tang, N. I. Krinsky, G. G.
Dolnikowski, and J. Plutzky. 2007. Asymmetric cleavage of beta-carotene yields a transcriptional repressor
of retinoid X receptor and peroxisome proliferator-activated receptor responses. Mol. Endocrinol. 21: 77-
88.
12.
Eroglu, A., D. P. Hruszkewycz, R. W. Curley, Jr., and E. H. Harrison. 2010. The eccentric cleavage
product of beta-carotene, beta-apo-13-carotenone, functions as an antagonist of RXRalpha. Arch. Biochem.
Biophys. 504: 11-16.
13.
Eroglu, A., and E. H. Harrison. 2013. Carotenoid metabolism in mammals, including man:
formation, occurrence, and function of apocarotenoids. J. Lipid Res. 54: 1719-1730.
14.
Fleshman, M. K., G. E. Lester, K. M. Riedl, R. E. Kopec, S. Narayanasamy, R. W. Curley, Jr., S.
J. Schwartz, and E. H. Harrison. 2011. Carotene and novel apocarotenoid concentrations in orange-fleshed
Cucumis melo melons: determinations of beta-carotene bioaccessibility and bioavailability. J. Agric. Food
Chem. 59: 4448-4454.
23

15.
During, A., M. M. Hussain, D. W. Morel, and E. H. Harrison. 2002. Carotenoid uptake and
secretion by CaCo-2 cells: beta-carotene isomer selectivity and carotenoid interactions. J. Lipid Res. 43:
1086-1095.
16.
During, A., and E. H. Harrison. 2007. Mechanisms of provitamin A (carotenoid) and vitamin A
(retinol) transport into and out of intestinal Caco-2 cells. J. Lipid Res. 48: 2283-2294.
17.
Quick, T. C., and D. E. Ong. 1990. Vitamin A metabolism in the human intestinal Caco-2 cell line.
Biochemistry 29: 11116-11123.
18.
Delie, F., and W. Rubas. 1997. A human colonic cell line sharing similarities with enterocytes as a
model to examine oral absorption: advantages and limitations of the Caco-2 model. Crit. Rev. Ther. Drug
Carrier Syst. 14: 221-286.
19.
Garrett, D. A., M. L. Failla, R. J. Sarama, and N. Craft. 1999. Accumulation and retention of
micellar beta-carotene and lutein by Caco-2 human intestinal cells. J. Nutr. Biochem. 10: 573-581.
20.
Costabile, B. K., Y. K. Kim, J. Iqbal, M. V. Zuccaro, L. Wassef, S. Narayanasamy, R. W. Curley,
Jr., E. H. Harrison, M. M. Hussain, and L. Quadro. 2016. beta-Apo-10'-carotenoids Modulate Placental
Microsomal Triglyceride Transfer Protein Expression and Function to Optimize Transport of Intact beta-
Carotene to the Embryo. J. Biol. Chem. 291: 18525-18535.
21.
Failla, M. L., C. Chitchumroonchokchai, D. Siritunga, F. F. De Moura, M. Fregene, M. J. Manary,
and R. T. Sayre. 2012. Retention during processing and bioaccessibility of beta-carotene in high beta-
carotene transgenic cassava root. J. Agric. Food Chem. 60: 3861-3866.
22.
Lornejad-Schafer, M. R., C. Lambert, D. E. Breithaupt, H. K. Biesalski, and J. Frank. 2007.
Solubility, uptake and biocompatibility of lutein and zeaxanthin delivered to cultured human retinal
pigment epithelial cells in tween40 micelles. Eur. J. Nutr. 46: 79-86.
24

23.
O'Sullivan, S. M., J. A. Woods, and N. M. O'Brien. 2004. Use of Tween 40 and Tween 80 to deliver
a mixture of phytochemicals to human colonic adenocarcinoma cell (CaCo-2) monolayers. Br. J. Nutr. 91:
757-764.
24.
Berni, P., C. Chitchumroonchokchai, S. G. Canniatti-Brazaca, F. F. De Moura, and M. L. Failla.
2014. Impact of Genotype and Cooking Style on the Content, Retention, and Bioacessibility of beta-
Carotene in Biofortified Cassava (Manihot esculenta Crantz) Conventionally Bred in Brazil. J. Agric. Food
Chem. 62: 6677-6686.
25.
Kopec, R. E., J. L. Cooperstone, R. M. Schweiggert, G. S. Young, E. H. Harrison, D. M. Francis,
S. K. Clinton, and S. J. Schwartz. 2014. Avocado Consumption Enhances Human Postprandial Provitamin
A Absorption and Conversion from a Novel High-beta-Carotene Tomato Sauce and from Carrots. J. Nutr.
144: 1158-1166.
26.
Tibaduiza, E. C., J. C. Fleet, R. M. Russell, and N. I. Krinsky. 2002. Excentric cleavage products
of beta-carotene inhibit estrogen receptor positive and negative breast tumor cell growth in vitro and inhibit
activator protein-1-mediated transcriptional activation. J. Nutr. 132: 1368-1375.
27.
Suzuki, T., M. Matsui, and A. Murayama. 1995. Biological activity of (all-E)-beta-apo-12'-
carotenoic acid and the geometrical isomers on human acute promyelocytic leukemia cell line HL-60. J.
Nutr. Sci. Vitaminol. (Tokyo) 41: 575-585.
28.
Wang, C. X., H. Jiang, J. J. Yuen, S. A. Lee, S. Narayanasamy, R. W. Curley, Jr., E. H. Harrison,
and W. S. Blaner. 2015. Actions of beta-apo-carotenoids in differentiating cells: differential effects in P19
cells and 3T3-L1 adipocytes. Arch. Biochem. Biophys. 572: 2-10.
29.
Minguez-Mosquera, M. I., D. Hornero-Mendez, and J. Garrido-Fernandez. 1995. Detection of
bixin, lycopene, canthaxanthin, and β-apo-8'-carotenal in products derived from red pepper. J. AOAC Int.
78: 491-496.
25

30.
Schaub, P., F. Wust, J. Koschmieder, Q. Yu, P. Virk, J. Tohme, and P. Beyer. 2017. Nonenzymatic
beta-Carotene Degradation in Provitamin A-Biofortified Crop Plants. J. Agric. Food Chem. 65: 6588-6598.
31.
Cooperstone, J. L., J. A. Novotny, K. M. Riedl, M. J. Cichon, D. M. Francis, R. W. Curley, Jr., S.
J. Schwartz, and E. H. Harrison. 2018. Limited appearance of apocarotenoids is observed in plasma after
consumption of tomato juices: a randomized human clinical trial. Am. J. Clin. Nutr. 108: 784-792.
32.
Sharma, R. V., S. N. Mathur, A. A. Dmitrovskii, R. C. Das, and J. Ganguly. 1976. Studies on the
metabolism of beta-carotene and apo-beta-carotenoids in rats and chickens. Biochim. Biophys. Acta 486:
183-194.
33.
Wang, X. D., C. Liu, R. T. Bronson, D. E. Smith, N. I. Krinsky, and M. Russell. 1999. Retinoid
signaling and activator protein-1 expression in ferrets given beta-carotene supplements and exposed to
tobacco smoke. J. Natl. Cancer Inst. 91: 60-66.
34.
Shmarakov, I., M. K. Fleshman, D. N. D'Ambrosio, R. Piantedosi, K. M. Riedl, S. J. Schwartz, R.
W. Curley, Jr., J. von Lintig, L. P. Rubin, E. H. Harrison, and W. S. Blaner. 2010. Hepatic stellate cells are
an important cellular site for beta-carotene conversion to retinoid. Arch. Biochem. Biophys. 504: 3-10.
35.
Amengual, J., M. A. Widjaja-Adhi, S. Rodriguez-Santiago, S. Hessel, M. Golczak, K. Palczewski,
and J. von Lintig. 2013. Two carotenoid oxygenases contribute to mammalian provitamin A metabolism.
J. Biol. Chem. 288: 34081-34096.
36.
Ho, C. C., F. F. de Moura, S. H. Kim, and A. J. Clifford. 2007. Excentral cleavage of beta-carotene
in vivo in a healthy man. Am. J. Clin. Nutr. 85: 770-777.
37.
Bagdon, R. E., C. Impellizzeri, and M. Osadca. 1962. Studies on the toxicity and metabolism of
beta-apo-8' -carotenal in dogs. Toxicol. Appl. Pharmacol. 4: 444-456.
26

38.
Sharma, R. V., S. N. Mathur, and J. Ganguly. 1976. Studies on the relative biopotencies and
intestinal absorption of different apo-beta-carotenoids in rats and chickens. Biochem. J. 158: 377-383.
39.
al-Hasani, S. M., and D. B. Parrish. 1972. Forms of vitamin A and of carotenoids in tissues, blood
serum and yolk of eggs from Cotournix coturnix japonica fed -apo-carotenals. J. Nutr. 102: 1437-1440.
40.
Zeng, S., H. C. Furr, and J. A. Olson. 1992. Metabolism of carotenoid analogs in humans. Am. J.
Clin. Nutr. 56: 433-439.
41.
McCormick, A. M., J. L. Napoli, H. K. Schnoes, and H. F. DeLuca. 1978. Isolation and
identification of 5, 6-epoxyretinoic acid: a biologically active metabolite of retinoic acid. Biochemistry 17:
4085-4090.
42.
McCormick, A. M., J. L. Napoli, S. Yoshizawa, and H. F. DeLuca. 1980. 5,6-epoxyretinoic acid is
a physiological metabolite of retinoic acid in the rat. Biochem. J. 186: 475-481.
43.
Mein, J. R., G. G. Dolnikowski, H. Ernst, R. M. Russell, and X. D. Wang. 2011. Enzymatic
formation of apo-carotenoids from the xanthophyll carotenoids lutein, zeaxanthin and beta-cryptoxanthin
by ferret carotene-9',10'-monooxygenase. Arch. Biochem. Biophys. 506: 109-121.
44.
Dela Sena, C., J. Sun, S. Narayanasamy, K. M. Riedl, Y. Yuan, R. W. Curley, Jr., S. J. Schwartz,
and E. H. Harrison. 2016. Substrate Specificity of Purified Recombinant Chicken beta-Carotene 9',10'-
Oxygenase (BCO2). J. Biol. Chem. 291: 14609-14619.
45.
Lee, S. A., H. Jiang, C. M. Trent, J. J. Yuen, S. Narayanasamy, R. W. Curley, Jr., E. H. Harrison,
I. J. Goldberg, M. S. Maurer, and W. S. Blaner. 2014. Cardiac dysfunction in beta-carotene-15,15'-
dioxygenase-deficient mice is associated with altered retinoid and lipid metabolism. Am. J. Physiol. Heart
Circ. Physiol. 307: H1675-H1684.
27

46.
Jamil, H., J. K. Dickson, Jr., C. H. Chu, M. W. Lago, J. K. Rinehart, S. A. Biller, R. E. Gregg, and
J. R. Wetterau. 1995. Microsomal triglyceride transfer protein. Specificity of lipid binding and transport. J.
Biol. Chem. 270: 6549-6554.
47.
Hussain, M. M., J. Shi, and P. Dreizen. 2003. Microsomal triglyceride transfer protein and its role
in apoB-lipoprotein assembly. J. Lipid Res. 44: 22-32.
48.
Spiegler, E., Y. K. Kim, B. Hoyos, S. Narayanasamy, H. Jiang, N. Savio, R. W. Curley, Jr., E. H.
Harrison, U. Hammerling, and L. Quadro. 2018. beta-apo-10'-carotenoids support normal embryonic
development during vitamin A deficiency. Sci. Rep. 8: 8834.
49.
Wang, X. D., R. M. Russell, C. Liu, F. Stickel, D. E. Smith, and N. I. Krinsky. 1996. Beta-oxidation
in rabbit liver in vitro and in the perfused ferret liver contributes to retinoic acid biosynthesis from beta-
apocarotenoic acids. J. Biol. Chem. 271: 26490-26498.
28

TABLES
Table 1. Mass for β-apo-8′-carotenal and the cellular metabolites of β-apo-8′-carotenal.
Compound
β-apo-8′-carotenal
Compound X
Mass (g/mol)
416.6490a
433.3101b
435.3258b
Compound Y
a Value indicates nominal mass.
b Value indicates accurate mass as determined by UHPLC-MS.
29

Table 2. Mass for β-apo-10′-carotenal and the cellular metabolites of β-apo-10′-carotenal.
Compound
β-apo-10′-carotenal
Compound A
Mass (g/mol)
376.5840a
394.2866b
395.2935b
380.3072b
Compound B
a Value indicates nominal mass.
b Value indicates accurate mass as determined by UHPLC-MS.
30
