A highly reactive and magnetic recyclable catalyst based on silver
nanoparticles supported on ferrite for N‐monoalkylation of amines
with alcohols
Ahmad Bayat1
| Mehdi Shakourian‐Fard2 | Peyman Nouri1 |
Mohammad Mahmoodi Hashemi1
1 Department of Chemistry, Sharif University of
Fe3O4@SiO2‐Ag catalyst was found to be highly active and selective in the N‐alkyl-
Technology, PO Box 11465‐9516, Tehran, Iran
2 Department of Chemical Engineering, Birjand
University of Technology, POBox 97175/569
Birjand, Iran
ation of amines with a variety of aromatic and linear alcohols. The heterogeneous
nature of the Fe3O4@SiO2‐Ag catalyst allows easy recovery and regeneration by
applying an external magnet for six subsequent reaction cycles. The prepared cata-
lyst was characterized using electron microscopy techniques, X‐ray diffraction,
vibrating sample magnetometry and atomic absorption spectroscopy.
Correspondence
Ahmad Bayat, Department of Chemistry, Sharif
University of Technology, PO Box 11465‐9516,
Tehran, Iran.
Email: bayat@ch.sharif.ir
KEYWORDS
Mehdi Shakourian‐Fard, Department of Chemical
Engineering, Birjand University of Technology,
PO Box 97175/569, Birjand, Iran.
alcohol, green chemistry, magnetic nanoparticles, N‐alkylation of amines, silver
nanoparticles
Email: shakourian@birjandut.ac.ir
1
|
INTRODUCTION
One way to overcome these drawbacks is the use of an
inexpensive, recoverable and reusable catalyst to accomplish
The N‐alkylation of amines is considered to be a very impor-
tant reaction in synthetic organic chemistry. This process
allows access to higher amines that are widely used as fun-
damental materials, additives, dyes and biologically active
compounds.[1–4] N‐alkylamines are typically synthesized
using alkylating agents having a good leaving group such
as halide, tosylate, mesylate, triflate, etc. However, this pro-
cedure can be problematic due to over‐alkylation and the
toxic nature of many alkyl halides and related alkylating
agents.[5]
The use of alcohols instead of alkyl halides to obtain N‐
alkylamines is attractive because it produces only water as a
by‐product and does not need special equipment. A variety
of transition metal complexes such as those of ruthenium,
iridium, rhodium, platinum, gold, nickel, aluminium, copper,
iron and silver are known to be good catalysts for the N‐alkyl-
ation of amines with alcohols.[6–16]
the reaction. An immobilized catalytic system on the large
surface area of a solid carrier can solve the problems of
homogeneous systems. Although there are several reports of
the N‐alkylation process using heterogeneous catalysts, most
of them require high pressure and reaction temperature and
are limited in their substrate scopes.[20–24] Therefore, the
development of efficient heterogeneous catalysts for N‐alkyl-
ation of amines with alcohols is still a challenge.
As part of our continuing effort[25–29] to synthesize mag-
netic heterogeneous catalytic systems for various organic
transformations, we report a magnetic recyclable heteroge-
neous catalyst based on silver nanoparticles supported on fer-
rite for one‐pot selective N‐monoalkylation of amines with
alcohols. To the best of our knowledge, silver nanoparticles
supported on Fe3O4 magnetic nanoparticles have not been
reported so far for N‐monoalkylation of amines with alcohols.
Moreover, the use of the magnetic heterogeneous catalytic
systems enables separation from the reaction mixture using
an external magnet and reuse of the catalyst itself. This cata-
lyst system also shows exceptionally high activity for N‐
alkylation of amines with various alcohols.
Unfortunately, the recovery and reuse of expensive cata-
lysts is difficult and the indispensable use of co‐catalysts such
as stabilizing ligands is unavoidable for most of the known
homogeneous catalysts.[17–19]
Appl Organometal Chem 2017;e3720.
wileyonlinelibrary.com/journal/aoc
Copyright © 2017 John Wiley & Sons, Ltd.
1 of 7
https://doi.org/10.1002/aoc.3720

Evaluation Only. Created with Aspose.PDF. Copyright 2002-2021 Aspose Pty Ltd.
2 of 7
BAYAT ET AL.
2
|
RESULTS AND DISCUSSION
characteristic peaks for Ag nanoparticles (red peaks) are also
found at 38.45°, 44.43°, 64.67°, 77.48° and 81.56° which
correspond to (111), (200), (220), (311) and (222) planes
of Ag nanoparticles, respectively, in accordance with the
JCPDS card number. These peaks indicate the presence of
Ag nanoparticles in the SMNP‐Ag catalyst.[31] A compari-
son between XRD patterns of SMNP and the SMNP‐Ag cat-
alyst indicates that the main peaks in the XRD patterns do
not change after deposition of Ag nanoparticles, indicating
retention of crystalline structure during their deposition.
In order to investigate the morphology and particle size
of the SMNP‐Ag catalyst, scanning electron microscopy
(SEM) and transition electron microscopy (TEM) images
of the catalyst were obtained, as shown in Figure 2(a)
and (b), respectively. These images show that the size of
the SMNP‐Ag nanoparticles is between 20 and 50 nm,
and the nanoparticles are also semi‐spherically uniform.
Energy‐dispersive X‐ray spectroscopy (EDS) analysis of
the SMNP‐Ag catalyst confirms the presence of Si, Fe,
O, and Ag atoms in the catalyst structure (Figure 2c).
The remaining weak peaks are due to the presence of a thin
layer of gold on the sample surface. In addition, the
amount of Ag deposited on the SMNP nanoparticles was
measured using atomic absorption spectroscopy (AAS)
2.1 | Preparation and Characterization of
Fe3O4@SiO2‐Ag (SMNP‐Ag) Catalyst
In the first step, bare Fe3O4 nanoparticles were synthesized
via a conventional co‐precipitation method using a solution
of iron salts (FeCl3⋅6H2O and FeCl2⋅4H2O) (Scheme 1). In
order to protect the bare Fe3O4 nanoparticles from oxidation
and agglomeration, silica shell (SiO2) was used as an inert
and stabilizer material for coating the Fe3O4 nanoparticles.
Then, Ag nanoparticles were deposited on the Fe3O4@SiO2
(SMNP) core–shell via reduction of AgNO3 solution by
NaBH4 at room temperature to generate the SMNP‐Ag cata-
lyst (Scheme 1). Finally, the SMNP‐Ag catalyst was charac-
terized using various techniques.
The crystalline nature and surface state of SMNP‐Ag
catalyst were studied using powder X‐ray diffraction
(XRD), as shown in Figure 1. The peaks at 2θ values of
30.4°, 35.8°, 43.7°, 53.8°, 57.3° and 63.0° in the XRD pat-
terns of SMNP and SMNP‐Ag catalyst correspond to (220),
(311), (400), (422), (551) and (440) diffraction planes of
Fe3O4 nanoparticles, respectively. These peaks match well
with the standard XRD data of the Joint Committee on Pow-
der Diffraction Standards (JCPDS) card number and reveal a
cubic inverse spinel structure for Fe3O4 in SMNP and
SMNP‐Ag catalyst.[30] As seen in Figure 1, five
analysis at about 0.192 mmol g−1
.
Magnetic measurements of Fe3O4 nanoparticles and the
SMNP‐Ag catalyst were conducted using a vibrating
SCHEME
1
Synthesis of magnetically recoverable heterogeneous
nanocatalyst Fe3O4@SiO2‐Ag (SMNP‐Ag)
FIGURE 2 (a) SEM and (b) TEM images, and (c) EDS analysis of SMNP‐
FIGURE 1 XRD patterns of Fe3O4@SiO2 and SMNP‐Ag catalyst
Ag catalyst

Evaluation Only. Created with Aspose.PDF. Copyright 2002-2021 Aspose Pty Ltd.
BAYAT ET AL.
3 of 7
TABLE 2 Optimization of amount of SMNP‐Ag catalysta
Yield (%)b
4a 5a
Entry
Catalyst (mg)
Conversion (%)
3a
1
2
3
4
5
6
7
8
—
—
—
5
—
—
4
—
—
1
—
—
—
<1
<1
—
1
AgNO3 (85)
Fe3O4 (100)
SMNP‐Ag (2.6)
SMNP‐Ag (5.2)
SMNP‐Ag (26)
SMNP‐Ag (52)
SMNP‐Ag (104)
67
82
93
98
>99
64
78
89
92
93
2
3
4
5
6
<1
aReaction conditions: aniline (1 mmol), benzyl alcohol (1.5 mmol), KOH (20 mol
%), toluene (5 ml) at 100 °C for 18 h.
bGC yield.
FIGURE 3 Magnetization curves of (a) Fe3O4 and (b) SMNP‐Ag catalyst
