Optimization of ultrasound-assisted extraction of okra (Abelmoschus esculentus (L.) Moench) polysaccharides based on response surface methodology and antioxidant activity

Article abstract of DOI:10.1016/j.ijbiomac.2018.03.145

This study determined the optimal conditions for ultrasound-assisted extraction of a water-soluble polysaccharide, Raw Okra Polysaccharide, from the fruit of okra using response surface methodology. The optimal extraction temperature, extraction time and ultrasonic power were 59 °C, 30 min and 522 W, respectively, giving a yield of 10.35 ± 0.11%. ROP was further isolated, lyophilized and purified using a DEAE-Sepharose Fast Flow column and Sepharose CL-6B column, revealing three elution peaks subsequently designated ROP ?1, ?2, and ?3, respectively. Of these, ROP-2 showed the highest yield, and was therefore selected for physicochemical analysis and evaluation of antioxidant activity. Gas chromatography, fourier transform infrared spectroscopy, and high-performance liquid chromatography were used to characterize the primary structural features and molecular weight, revealing that ROP-2 is composed of glucose, mannose, galactose, arabinose, xylose, fructose, and rhamnose (molar percentages: 28.8, 12.5, 13.1, 15.9, 9.2, 13.7, and 6.8%, respectively) and has an average molecular weight of 1.92 × 105 Da. A superoxide radical scavenging assay and DPPH radical scavenging assay further revealed the significant in vitro antioxidant activity of ROP-2. These findings present an effective technique for extraction of the natural antioxidant ROP-2, warranting further analysis of its potential application in the food industry.

Full text of DOI:10.1016/j.ijbiomac.2018.03.145

Accepted Manuscript
Optimization of ultrasound-assisted extraction of okra
(Abelmoschus esculentus (L.) Moench) polysaccharides based on
response surface methodology and antioxidant activity
Kunli Wang, Mo Li, Xin Wen, Xiaosong Chen, Zhengyu He,
Yuanying Ni
PII:
S0141-8130(18)30047-3
doi:10.1016/j.ijbiomac.2018.03.145
BIOMAC 9367
DOI:
Reference:
To appear in:
Received date:
Revised date:
Accepted date:
4 January 2018
26 January 2018
23 March 2018
Please cite this article as: Kunli Wang, Mo Li, Xin Wen, Xiaosong Chen, Zhengyu
He, Yuanying Ni , Optimization of ultrasound-assisted extraction of okra (Abelmoschus
esculentus (L.) Moench) polysaccharides based on response surface methodology and
antioxidant activity. The address for the corresponding author was captured as affiliation
for all authors. Please check if appropriate. Biomac(2017), doi:10.1016/
j.ijbiomac.2018.03.145
This is a PDF file of an unedited manuscript that has been accepted for publication. As
a service to our customers we are providing this early version of the manuscript. The
manuscript will undergo copyediting, typesetting, and review of the resulting proof before
it is published in its final form. Please note that during the production process errors may
be discovered which could affect the content, and all legal disclaimers that apply to the
journal pertain.

ACCEPTED MANUSCRIPT
Optimization of ultrasound-assisted extraction of okra (Abelmoschus esculentus (L.) Moench)
polysaccharides based on response surface methodology and antioxidant activity
a, b, c
a, b, c
a, b, c
a, b, c
a, b, c
a,
Kunli Wang
b, c, *
, Mo Li
, Xin Wen
, Xiaosong Chen
, Zhengyu He
, Yuanying Ni
a
College of Food Science and Nutritional Engineering, China Agricultural University, Beijing
00083, China
1
b
National Engineering Research Center for Fruits and Vegetables Processing, Beijing 100083,
China
c
Key Laboratory of Fruits and Vegetables Processing, Ministry of Agriculture, Beijing 100083,
China
*
Corresponding author at: College of Food Science and Nutritional Engineering, China
Agricultural University, Box 303, No. 17 Tsinghua East Road, Beijing 100083, China.
E-mail address: niyycau@hotmail.com (Y. Ni)
Abstract
This study determined the optimal conditions for ultrasound-assisted extraction of a water-soluble
polysaccharide, Raw Okra Polysaccharide, from the fruit of okra using response surface
methodology. The optimal extraction temperature, extraction time and ultrasonic power were
59 °C, 30 min and 522 W, respectively, giving a yield of 10.35 ± 0.11 %. ROP was further isolated,
lyophilized and purified using a DEAE-Sepharose Fast Flow column and Sepharose CL-6B
column, revealing three elution peaks subsequently designated ROP-1, -2, and -3, respectively. Of
these, ROP-2 showed the highest yield, and was therefore selected for physicochemical analysis
and evaluation of antioxidant activity. Gas chromatography, fourier transform infrared
spectroscopy, and high-performance liquid chromatography were used to characterize the primary
1

ACCEPTED MANUSCRIPT
structural features and molecular weight, revealing that ROP-2 is composed of glucose, mannose,
galactose, arabinose, xylose, fructose, and rhamnose (molar percentages: 28.8, 12.5, 13.1, 15.9,
9.2, 13.7, and 6.8 %, respectively) and has an average molecular weight of 1.92 × 105 Da. A
superoxide radical scavenging assay and DPPH radical scavenging assay further revealed the
significant in vitro antioxidant activity of ROP-2. These findings present an effective technique for
extraction of the natural antioxidant ROP-2, warranting further analysis of its potential application
in the food industry.
Keywords: Okra polysaccharides, ultrasonic-assisted extraction, response surface methodology,
optimization, antioxidant activity
2

ACCEPTED MANUSCRIPT
1. Introduction
Okra, Abelmoschus esculentus (L.) Moench, is an annual herb grown in tropical and
Mediterranean climates such as Southeast Asia, Africa, southern states of the USA, and the Middle
East; however, okra also has a wide growth potential in other countries [1, 2]. The okra pod is
eaten as a vegetable, while its extract is used to thicken stews and soup [3, 4]. Water-soluble
polysaccharides from okra are also used in ice-cream, potato chips, and baked goods, providing a
healthy option and more stable shelf-life [5-7]. Interest in okra is therefore growing, with many of
its components (flavonoids, polysaccharides and vitamins) possessing significant biological
activities [8] such as antioxidant, hypoglycemic, antineoplastic, and hypolipidemic [9-12].
Of these compounds, polysaccharides are among the most important, having been found to
possess immunomodulatory, antioxidant, and antiproliferative activities [13]. However, while the
backbone, molecular weight, composition, and biological activity of okra polysaccharides have
been examined [2], little is known about their extraction and antioxidant activities.
Extraction methods tend to influence the yield, chemical structure and biological activity of
polysaccharides [14, 15]. Hot water extraction is traditionally used to isolate bioactive materials;
however, it has disadvantages including a high extraction temperature, long extraction time, and
high consumption rate of solvents and energy [16, 17]. Various new techniques for polysaccharide
extraction have therefore been developed such as supercritical fluid, enzyme-assisted,
microwave-assisted, and ultrasonic-assisted extraction [18], all of which have advantages and
disadvantages. Ultrasound extraction technology has a moderate solvent requirement, relatively
short extraction time, and reasonably high extraction yield, and has therefore been used widely to
extract highly bioactive polysaccharides from plant materials with a minimal impact on biological
3

ACCEPTED MANUSCRIPT
activity [19-22].
In this study, we chose the ultrasound extraction technique to optimize the extraction yield of okra
polysaccharide (Raw Okra Polysaccharide, ROP). To do so, three extraction factors (temperature,
time, and ultrasonic power) were examined based on single factor experiments. ROP was then
deproteinized, lyophilized, and purified using a diethylaminoethyl (DEAE)-Sepharose Fast Flow
column and Sepharose CL-6B column, and the purified fraction characterized along with
evaluation of in vitro antioxidant activity.
2
2
. Materials and methods
.1 Reagents and materials
Fresh okra was purchased from Gansu Province, China. Bovine serum albumin (BVA), dextran
T-series standards and monosaccharide standards were obtained from Sigma Chemical Co. (St.
Louis, MO, USA). DEAE-Sepharose Fast Flow and Sepharose CL-6B were purchased from
Pharmacia. Remaining chemicals were of analytical grade.
2
2
.2 Extraction of ROP
.2.1 Pretreatment of okra
The plant material was freeze-dried (-56 °C, 36 h), pulverized using a mechanical disintegrator
then screened through a 40-mesh sieve. The resulting powder was subjected to heat circumfluence
extraction at 50 °C for 6 h to remove oligosaccharides, colored substances and lipids using 95 %
ethanol–petroleum ether at 1:1 (v/v) as the refluxing solvent. After centrifugation, the residue was
collected then dried to a constant weight at 40 °C for ROP extraction.
2.2.2 ROP extraction
4

ACCEPTED MANUSCRIPT
Ultrasound-assisted extraction was carried out in an ultrasonic cleaning bath (KQ-500DE,
Kunshan Ultrasonic Instrument Co. Ltd., Jiangsu, China) using distilled water to extract the
pretreated sample (10 g). Water extraction solutions were obtained by centrifugation (CR21GIII,
Hitachi Koki Instrument Development Co., Ltd.) at 8000 rpm for 8 min. Polysaccharides were
measured based on the phenol-sulfuric acid method using D-glucose as a standard [23] and the
protein content measured according to the Bradford method using BSA as a standard [24]. ROP
extraction yield (%) was then calculated as follows:
퐶
Y (%) = × 100%
푊
Where C is the polysaccharide content and W is the sample dry weight.
2.2.3 Single-factor design
The initial range of the following three extraction factors was determined using a single factor
design: extraction temperature (40 - 80 °C), extraction time (10 - 30 min), and ultrasonic power
(360 - 720 W). The dependent variable was ROP extraction yield. Preliminary experiments
revealed a high extraction yield under a liquid-solid ratio of 30:1, with no significant
improvements thereafter. A liquid-solid ratio of 30:1 was therefore selected.
2.2.4 Optimization of ROP extraction
Using the results of the single factor experiments, Design Expert (Trial Version 8.0.6.1, Stat-Ease
Inc., USA) was used for experimental design, data analysis and model building. Three
independent variables (extraction temperature (A), extraction time (B), and ultrasonic power (C))
at three levels were then used to perform Box-Behnken design (BBD) analysis to determine the
best combination for ROP extraction. Seventeen experimental points were determined using the
design results and the level of each variable, all of which were included in a random order (Table
5

ACCEPTED MANUSCRIPT
1). A computer-generated nonlinear quadratic model was then used to fit the data as follows:
퐾
퐾
2
푗
Y = 퐴 + ∑ 퐴 푋 + ∑ 퐴 푋 + ∑ ∑ 퐴 푋 푋
푗푗 푖 푗
ꢀ
푗
푗
푗푗
푗−ꢁ
푗−ꢁ
푖<푗
where Y is the ROP yield, 퐴 , 퐴 , 퐴 and 퐴푖푗 are regression coefficients of variables
ꢀ
푗
푗푗
representing intercept, linear, quadratic and interaction terms, and 푋 and 푋 are the independent
푖
푗
coded variables (i ≠ j).
.3 Purification of ROP
2
Based on the results of optimal extraction, the water extraction solutions were combined then
concentrated to 1/3 volume at 50 °C using a rotary evaporator (R-100, BUCHI) under reduced
pressure. Sevag reagent (chloroform: butyl alcohol, 4:1 v/v) [25] was then used to remove proteins
from the ROP fraction until there was no precipitate at the junction of the two phases. The solution
was then concentrated and precipitated with the addition of ethanol (3 times the volume of
aqueous extract) at 4 °C for 12 h then centrifuged at 8000 rpm for 20 min. The flocculent
precipitates were then dialyzed in double-distilled water for three days followed by lyophilization
to a constant weight. The resulting powder was dissolved in 50 ml Tris-HCl buffer (pH 7.4) at 5
mg / ml and filtered through a 0.45 µm membrane (Nucleopore). The solution was then loaded
onto a DEAE-Sepharose Fast Flow column (2.6 × 20 cm) pre-equilibrated with Tris-HCl buffer
(pH 7.4). After elution with 150 mL Tris-HCl buffer (pH 7.4), stepwise elution with increasing
concentrations of sodium chloride solution (0 - 0.6 M) was carried out at a flow rate of 4 mL / min
and 8 mL fractions collected using an automatic fraction collector (BSZ-100, Shanghai Huxi
Instrument Factory, Shanghai, China). The total polysaccharide content in each fraction was then
measured at 490 nm using the phenol-sulfuric acid method. Three large, overlapping elution peaks
were subsequently revealed in the elution profiles, and designated ROP-1, ROP-2, and ROP-3,
6

ACCEPTED MANUSCRIPT
respectively. Of these, ROP-2 showed the highest yield and was therefore selected for further
analysis. It was collected, concentrated, dialyzed against distilled water then further purified using
a Sepharose CL-6B column eluted with 0.15 M NaCl. A single elution peak was subsequently
generated, and the responsible fraction dialyzed against distilled water and freeze-dried for further
analysis.
2
2
.4 Characterization
.4.1 Homogeneity and molecular weight
The molecular weight of the purified ROP-2 fraction was determined by gel permeation
chromatography using Shodex SB-805HQ with an injection volume of the sample (5 mg / mL) of
2
0 µL. The column was eluted using 0.1 M NaNO at a flow rate of 0.8 mL / min The molecular
3
weight was calculated by comparison with a standard curve established using T-series Dextran
standards (1, 7, 10, 40, 500, and 1000 KD).
2.4.2 UV spectroscopy
For UV spectroscopy, 1.0 mg ROP-2 / mL distilled water was used. Ultraviolet absorption spectra
were recorded within a wavelength range of 190–350 nm using a T6 UV spectrometer (Beijing
Puxi General Instrument Co. Ltd., Beijing, China).
2.4.3 FT-IR spectroscopy
Fourier transform infrared (FT-IR) spectroscopy was performed using a Nicolet Nexus FT-IR
spectrometer (Thermo Electron, Madison, WI, USA), and absorption spectra recorded at
−
1
wavelengths of 4000 to 400 cm . The ROP-2 was ground with KBr powder and pressed into
pellets.
2.4.4 Starch, phenolic substance, and reducing sugar contents
7

ACCEPTED MANUSCRIPT
Starch was estimated using the iodine - potassium iodide reaction [26], phenolic substances using
the ferric chloride reaction [27], and reducing sugar using the Fehling’s test [28].
2.4.5 Monosaccharide composition
To determine the monosaccharide composition, ROP-2 (10 mg) was dissolved in trifluoroacetic
acid (TFA, 2 M, 2 mL) then hydrolyzed at 120 °C for 2 h. The resulting hydrolysate was
co-concentrated with methanol repeatedly then successively dissolved in distilled water and
freeze-dried. The freeze-dried hydrolysate of the above procedure was then dissolved in pyridine
(0.3 mL), and after the addition of trimethylchlorosilane (0.4 ml) and hexamethyldisilazane (0.2
ml) shaken vigorously for 30s. Distilled water (1 ml) was then added and the mixture centrifuged
for 5 min at 10,000 rpm to remove any white precipitates. The supernatant was then analyzed by
gas chromatography – mass spectrometry (GC–MS) using a fused silica capillary column
(DB-5MS, 30 m × 0.25 mm × 0.25 μm). The column oven was first cooled to 50 °C for 2 min then
the temperature increased to 100 °C at 15 °C / min, 170 °C at 10 °C / min and 300 °C at 3 °C /
min, and maintained for 3 min. The temperatures of the injection port, detector, and ion-source
were 250, 280, and 200 °C, respectively [29].
2
2
.5 In vitro antioxidant activity
.5.1 Hydroxyl radical scavenging assay
The hydroxyl radical scavenging activity of ROP-2 was measured using the Fenton’s reaction.
Samples were prepared in a series of concentrations (0.157, 0.313, 0.625, 1.250, 2.500, 5.000 mg /
mL) using distilled water. The reaction mixture contained 1 mL polysaccharide solution, 1 mL
hydrogen peroxide (1 % v/v), 1 mL orthophenanthroline (6 mM in ethanol), and 1 mL iron sulfate
(
FeSO , 2 mM in water), and was incubated at 37 °C for 1 h. Absorbance was then measured at
4
8

ACCEPTED MANUSCRIPT
526 nm. Vitamin C diluted in distilled water was used as a positive control. Hydroxyl radical
scavenging activity (%) was then calculated as follows:
퐴푖 ꢃ 퐴푗
퐴푐
Hydroxyl radical scavenging activity(%) = ꢂ1 ꢃ
ꢄ × 100%
where 퐴 is the absorbance of the control reaction in which distilled water was used, 퐴 is the
푐
푖
absorbance of the reaction mixture using the polysaccharide sample, and 퐴 is the absorbance of
푗
the control reaction in which orthophenanthroline (in ethanol) was replaced with ethanol [30].
2.5.2 Superoxide radical scavenging assay
The superoxide radical scavenging capacity of ROP-2 was determined using a pyrogallic acid
auto-oxidation system as described previously with slight modifications [31]. The ROP-2 sample
was prepared in a series of concentrations (0.157, 0.313, 0.625, 1.250, 2.500, 5.000 mg / mL)
using distilled water. Tris–HCl buffer (4.5 mL, 0.05 mol / L, pH 8.2) was incubated at 25 °C for
20 min then mixed with 1 mL of sample solution at each concentration and 25 mM pyrogallic acid
(0.4 mL). After rapid shaking, the resulting mixture was incubated at 25 °C for 4 min. The
reaction was terminated by adding 8M HCl and the absorbance measured at 299 nm. Vitamin C
diluted in distilled water was used as a positive control. The superoxide radical scavenging
percentage was calculated as follows:
퐴푐 ꢃ 퐴푖
Superoxide radical scavenging activity(%) =
× 100%
퐴푐
where 퐴 is the absorbance of the control reaction in which deionized water was used and 퐴 is
푐
푖
the absorbance of the reaction mixture containing the polysaccharide sample.
2.5.3 DPPH (1,1-diphenyl-2-picrylhydrazyl) radical scavenging assay
The ability of ROP-2 to scavenge DPPH free radicals was determined as described previously [32]
with slight modifications. The ROP-2 sample was prepared in a series of concentrations (0.157,
9

ACCEPTED MANUSCRIPT
0.313, 0.625, 1.250, 2.500, 5.000 mg/mL) using distilled water. Freshly prepared DPPH (2 ml, 0.2
mg / mL in ethanol), 1.5 mL of sample solution, and 0.5 mL of distilled water comprised the
reaction mixture. After vigorous shaking, the mixture was incubated at 25 °C for 30 min in the
dark then the absorbance determined at 517 nm. Vitamin C diluted in distilled water was used as a
positive control. DPPH scavenging ability (%) was then calculated as follows:
퐴푖 ꢃ 퐴푗
DPPH scavenging activity(%) = ꢂ1 ꢃ
ꢄ × 100%
퐴푐
where 퐴 is the absorbance of the control reaction in which deionized water was used 퐴 is the
푐
푖
absorbance of the reaction mixture containing the polysaccharide sample, and 퐴 is the
푗
absorbance of the control reaction in which the DPPH (in ethanol) was replaced by ethanol.
2
.6 Statistical analysis
All experiments were carried a minimum of three times. Data were analyzed using SPSS software
Version 20, SPSS Inc., IL, USA). Duncan’s test was used to determine the statistical significance
(
between groups. All values are expressed as the mean ± SD with p < 0.05 used to determine
statistical significance.
3
3
3
. Results and Discussion
.1 Single factor experimental analysis
.1.1 Effect of extraction temperature on ROP yield
Fig. 1A shows the effect of extraction temperature on the yield of ROP. As previously reported,
extraction temperature directly affects the yield of polysaccharides [33]. Here, a significant
increase in extraction yield was observed with increasing extraction temperature from 40 - 60 °C
(p < 0.05) with a decrease thereafter. Increasing extraction temperature reduces the viscosity of the
solvent and increases molecular movement, accelerating the mass transfer of intracellular
10

ACCEPTED MANUSCRIPT
substances [34]. However, excessively high temperatures can also cause degradation of certain
thermo-sensitive materials, resulting in a decrease in yield [35]. A temperature range of 55 – 65 °C
was therefore selected as the optimal extraction temperature.
3.1.2 Effect of extraction time on ROP yield
Fig. 1B shows the effect of extraction time on the extraction yield of ROP. Yield increased with
increasing extraction time, reaching a maximum at 25 min and decreasing slightly thereafter,
albeit it in an insignificant manner. This slight decrease was possibly due to overexposure of ROP
to the release medium, the liquid dissolving ROP and then ROP diffusing out from the raw
materials [36]. These findings suggest that if the extraction time is too long degradation of the
polysaccharides occur [37]. An optimal extraction time of 20 - 30 min was therefore selected.
3.1.3 Effect of ultrasonic power on ROP yield
Fig. 1C shows the effect of ultrasonic power on the extraction yield of ROP. Yield increased
significantly with increasing power from 360 - 540 W decreasing slightly thereafter. This slight
decrease was possibly due to acceleration in mass transfer of intracellular substances. Thus, as
with the previous two variables, if the ultrasonic power is too high degradation of the
polysaccharides can occur. An optimal ultrasonic power of 360 - 540W was therefore selected.
3
3
.2 Model fitting and optimization of ROP extraction
.2.1 Model fitting
Table 2 shows the design matrix and the results of analysis of adequacy, variance and fitness of the
model obtained. Using the following second-order polynomial equation, multiple regression
analysis of the experimental data was then used to correlate the test variables and response
variable (extraction yield of ROP). In this statistical analysis section, ANOVA was carried out:
11

ACCEPTED MANUSCRIPT
2
2
2
Y = 10.21 - 0.029A + 0.19B - 0.18C - 0.25AB - 0.13AC - 0.16BC - 0.44A + 0.086B - 0.93C
where Y represents yield, and A, B and C represent the extraction temperature, extraction time,
and ultrasonic power, respectively.
Analysis of variance of the quadratic regression model (Table 2) revealed a determination
2
2
coefficient (R ) and adjusted determination coefficient (R Adj) of 0.9497 and 0.8851, respectively.
Thus, the total variance was explained by the model and the model was highly significant. In line
with this, the P-value of the model was 0.0009, suggesting extremely significant fitness (p <
0.001), while the lack-of-fit value was 0.0776; in other words, insignificant (p > 0.05). The model
was therefore proven to be adequate for prediction with the range of experimental variables
determined here. As a result, the linear coefficients (B and C), cross coefficient (AB), and
2
2
quadratic coefficients (A and C ) were all found to significantly affect yield of ROP (p < 0.05)
using the coefficient estimates for optimization.
3.2.2 Optimization of ROP extraction
Fig. 2 shows the three-dimensional (3D) response surface of the model, giving an understanding
of the interactions between test variables and confirming the optimal conditions for maximum
yield [35]. As shown, the optimal test variables providing a ROP extraction yield of 10.56 % were:
extraction temperature: 58.5 °C, extraction time: 30 min, and ultrasonic power: 525.6 W. However,
considering actual production operation, modification of the optimal conditions was subsequently
carried out as follows: extraction temperature: 59 °C, extraction time: 30min, and ultrasonic
power: 522 W. A verification experiment was subsequently carried out under these optimal
conditions to verify the rationality of the model equations. As a result, an experimental extraction
yield of 10.35 ± 0.11 % (n = 3) was obtained, in strong agreement with the predicted value. This
12

ACCEPTED MANUSCRIPT
finding suggests that the regression model was accurate and can be used to predict ROP extraction
yield. The polysaccharide and protein contents of ROP were subsequently determined as 47.92±
1.27 % and 2.13 ± 0.09 %, respectively.
3.3. ROP separation and purification
After determining the optimal extraction conditions, the ROP sample was purified using a
DEAE-Sepharose Fast Flow cellulose anion-exchange column and a Sepharose CL-6B column,
resulting in three large elution peaks (Fig. 3A). The peaks were detected using the phenol-sulfuric
acid method and subsequently named ROP-1, -2, and -3 accordingly. The resulting fractions were
collected, concentrated, dialyzed and lyophilized. As a result, yields of ROP-1 and ROP-3 were
found to be too low for further analysis; therefore, the ROP-2 fraction was collected for
identification of physicochemical properties and antioxidant activity.
3
3
.4 Characterization of ROP-2
.4.1 Physicochemical properties of ROP-2
Fig. 3B shows the homogeneity and molecular weight of ROP-2 as determined by
high-performance liquid chromatography (HPLC). ROP-2 had a single symmetrical sharp peak,
indicating homogeneity. The regression equation was LogMw = -1.2827X + 20.136 with a
2
correlation coefficient (R ) of 0.9989. The average molecular weight was represented by Mw, and
the elution volume was represented by X. According to the equation, the average molecular weight
of ROP-2 was calculated as 1.92 × 105 Da. A maximum absorption peak around 200 nm was
displayed in the UV–Vis spectrum of ROP-2, confirming that it is a polysaccharide. Moreover,
there was no absorption peak between 250 and 350 nm, suggesting no protein or nucleic acid [38,
39].
13

ACCEPTED MANUSCRIPT
Fig. 3C shows the FT-IR spectrum of the ROP-2 sample. An intense broad absorption peak
−
1
around 3340 cm was attributed to O-H stretching vibration, which is common to all
−
1
polysaccharides [40], while the weak band near 2922 cm was assigned to C-H asymmetric
stretching vibration [41]. Both absorption bands are characteristic of polysaccharides [42]. There
−
1
was also a characteristic weak peak at 1700–1750 cm , suggesting the existence of uronic acids
-1
[
43], while signals at 1373 and 1152-995 cm represent araboxylan [44, 45]. The bands at
−
1
approximately 890cm suggest a β anomeric configuration [46]. Thus, ROP-2 does not contain
proteins, nucleic acids, starch, phenolic substances, raw sugar, or reducing sugar.
3.4.2 Monosaccharide composition
Fig. 4 shows the monosaccharide composition of ROP-2. Peaks were identified by comparing
retention times to those of monosaccharide standards. The results show that ROP-2 is composed
of glucose, mannose, galactose, arabinose, xylose, fructose, and rhamnose with molar percentages
of 28.8, 12.5, 13.1, 15.9, 9.2, 13.7, and 6.8c%, respectively.
3
3
.5 Antioxidant activity of ROP-2
.5.1 Hydroxyl radical scavenging activity
Hydroxyl radicals are considered the most harmful of all reactive oxygen species, since they can
damage human biomolecules such as proteins, lipids, carbohydrates, and DNA [47, 48]. The
removal of hydroxyl radicals is therefore thought to help protect the body against
oxidization-related injury. As shown in Fig. 5A, the hydroxyl radical scavenging activity of ROP-2
was concentration dependent. At 5 mg / mL, the scavenging activity was 19.38 % with an IC of
5
0
11.99 mg / mL, Compared to the activity of ascorbic acid (100 %), these results suggest that
ROP-2 has only a weak hydroxyl radical scavenging ability.
14

ACCEPTED MANUSCRIPT
3.5.2 Superoxide radical scavenging activity
The superoxide anion is a weak free radical, generated by the mitochondrial electron transport
system. However, importantly, it can create other strong free radicals that increase the risk of
various types of disease [49-51]. As shown in Fig. 5B, the superoxide radical scavenging activity
of ROP-2 was also concentration dependent. At 5 mg / mL, the scavenging rate was 61.18 % with
an IC50 of 3.12 mg / mL. Compared with the scavenging rate of ascorbic acid (100 %), the
superoxide radical scavenging ability of ROP-2 is relatively low.
3.5.3 DPPH radical scavenging activity
Although DPPH is a relatively stable free radical, antioxidants can be used to reduce levels by
providing electrons or hydrogen atoms. The DPPH radical can therefore be used to evaluate
antioxidant free radical scavenging activity [52, 53]. As shown in Fig. 5C, the DPPH radical
scavenging activity of ROP-2 was also concentration dependent. At 5 mg / mL, the DPPH radical
scavenging activity was 79.82 % with an IC50 value of 1.87 mg / mL. Compared with ascorbic
acid (100%) these findings suggest that ROP-2 can provide hydrogen atoms or for DPPH radical
scavenging.
4. Conclusions
Extraction methods have a significant impact on the quantity of the extract obtained. Here,
ultrasound-assisted extraction was successfully applied to extraction of the oligosaccharide ROP
from okra. Under optimal extraction conditions (extraction temperature: 59 °C, extraction time: 30
min, and ultrasonic power: 522W), the extraction yield of ROP was 10.35 ± 0.11 %, which
strongly agreed with the predicted value. ROP was further purified using a DEAE-Sepharose Fast
Flow column and a Sepharose CL-6B column, indicating three separate fractions. Of these, ROP-2
15

ACCEPTED MANUSCRIPT
5
showed the highest yield, with an average molecular weight of 1.92 × 10 Da, and composed of
glucose, mannose, galactose, arabinose, xylose, fructose, and rhamnose at molar percentages of
28.8, 12.5, 13.1, 15.9, 9.2, 13.7, and 6.8 %, respectively. The UV and FT-IR spectrum of ROP-2
were also evaluated, and the strong scavenging activities against superoxide radicals and DPPH
and weak scavenging activity against hydroxyl radicals revealed. Overall, these findings suggest
that ultrasound-assisted extraction technology can be successfully applied to polysaccharide
extraction from okra. The obtained polysaccharide (ROP-2) can now be examined for its potential
as a functional food ingredient. Accordingly, further experiments on the relationship between
structure and bioactivity are now under way.
Acknowledgements
We would like to thank the native English speaking scientists of Elixigen Company (Huntington
Beach, California) for editing our manuscript. This work was supported by the Special Fund for
Agro-scientific Research in the Public Interest [grant number 201503142].
References
[
1] İ. Doymaz, Drying characteristics and kinetics of okra, Journal of Food Engineering 69(3) (2005)
75-279.
2] N. Sengkhamparn, L.M.C. Sagis, R. de Vries, H.A. Schols, T. Sajjaanantakul, A.G.J. Voragen,
2
[
Physicochemical properties of pectins from okra (Abelmoschus esculentus (L.) Moench), Food
Hydrocolloids 24(1) (2010) 35-41.
[
3] J.N. Bemiller, R.L. Whistler, D.G. Barkalow, C.-C. Chen, CHAPTER 9 - ALOE, CHIA,
FLAXSEED, OKRA, PSYLLIUM SEED, QUINCE SEED, AND TAMARIND GUMS, Industrial
Gums (Third Edition), Academic Press, London, 1993, pp. 227-256.
[
(
4] M.L. Woolfe, M.F. Chaplin, G. Otchere, Studies on the mucilages extracted from okra fruits
Hibiscus esculentus L.) and baobab leaves (Adansonia digitata L.), Journal of the Science of Food &
Agriculture 28(6) (1977) 519-529.
5] G. Archana, P. Azhagu Saravana Babu, K. Sudharsan, K. Sabina, R. Palpandi Raja, M. Sivarajan, M.
[
16

ACCEPTED MANUSCRIPT
Sukumar, Evaluation of Fat Uptake of Polysaccharide Coatings on Deep-Fat Fried Potato Chips by
Confocal Laser Scanning Microscopy, International Journal of Food Properties 19(7) (2015)
1
583-1592.
6] S.-M. Hu, H.-S. Lai, Developing Low-Fat Banana Bread by Using Okra Gum as a Fat Replacer,
Journal of Culinary Science & Technology 15(1) (2016) 36-42.
7] P. Yuennan, T. Sajjaanantakul, H.D. Goff, Effect of okra cell wall and polysaccharide on physical
properties and stability of ice cream, J Food Sci 79(8) (2014) E1522-7.
8] F.O. Adetuyi, T.A. Ibrahim, Effect of Fermentation Time on the Phenolic, Flavonoid and Vitamin C
Contents and Antioxidant Activities of Okra (Abelmoschus esculentus) Seeds, Nigerian Food Journal
2(2) (2014) 128-137.
9] B.T. Ahmed, S.A. Kumar, Antioxidant and Antidiabetic properties of Abelmoschus esculentus
extract - an in vitro assay, 11(3) (2016) 34-41.
10] S. Fan, Y. Zhang, Q. Sun, L. Yu, M. Li, B. Zheng, X. Wu, B. Yang, Y. Li, C. Huang, Extract of
[
[
[
3
[
[
okra lowers blood glucose and serum lipids in high-fat diet-induced obese C57BL/6 mice, J Nutr
Biochem 25(7) (2014) 702-9.
[
11] Z.H. Tian, F.T. Miao, X. Zhang, Q.H. Wang, N. Lei, L.C. Guo, Therapeutic effect of okra extract
on gestational diabetes mellitus rats induced by streptozotocin, Asian Pac J Trop Med 8(12) (2015)
038-1042.
12] H. Ying, H. Jiang, H. Liu, F. Chen, Q. Du, Ethyl acetate-n-butanol gradient solvent system for
high-speed countercurrent chromatography to screen bioactive substances in okra, J Chromatogr A
359 (2014) 117-23.
13] H. Chen, H. Jiao, Y. Cheng, K. Xu, X. Jia, Q. Shi, S. Guo, M. Wang, L. Du, F. Wang, In Vitro and
1
[
1
[
In Vivo Immunomodulatory Activity of Okra (Abelmoschus esculentus L.) Polysaccharides, J Med
Food 19(3) (2016) 253-65.
[
14] H. Dong, S. Lin, Q. Zhang, H. Chen, W. Lan, H. Li, J. He, W. Qin, Effect of extraction methods on
the properties and antioxidant activities of Chuanminshen violaceum polysaccharides, Int J Biol
Macromol 93(Pt A) (2016) 179-185.
[
15] Z.Y. Zhu, F. Dong, X. Liu, Q. Lv, YingYang, F. Liu, L. Chen, T. Wang, Z. Wang, Y. Zhang, Effects
of extraction methods on the yield, chemical structure and anti-tumor activity of polysaccharides from
Cordyceps gunnii mycelia, Carbohydr Polym 140 (2016) 461-71.
[
16] J.L. Wang, Z. Ji, B.T. Zhao, X.F. Wang, Y.Q. Wu, Y. Jian, A comparison study on
microwave-assisted extraction of Potentilla anserina L. Polysaccharides with conventional method:
Molecule weight and antioxidant-activities evaluation, Carbohydrate Polymers 80(1) (2010) 84-93.
[
17] Y. Yuan, D. Macquarrie, Microwave assisted extraction of sulfated polysaccharides (fucoidan)
from Ascophyllum nodosum and its antioxidant activity, Carbohydr Polym 129 (2015) 101-7.
18] Y. Qu, C. Li, C. Zhang, R. Zeng, C. Fu, Optimization of infrared-assisted extraction of Bletilla
[
striata polysaccharides based on response surface methodology and their antioxidant activities,
Carbohydr Polym 148 (2016) 345-53.
[
19] Z. Hromádková, A. Ebringerová, Ultrasonic extraction of plant materials––investigation of
hemicellulose release from buckwheat hulls, Ultrasonics Sonochemistry 10(3) (2003) 127-133.
20] Y. Pan, Y. Hao, T. Chu, C. Li, Z. Zhang, Y. Zhou, Ultrasonic-assisted extraction, chemical
[
characterization of polysaccharides from Yunzhi mushroom and its effect on osteoblast cells,
Carbohydrate Polymers 80(3) (2010) 922-926.
[
21] Y. Zhi, H. Xiaoxiang, L. Jianrong, Ultrasound-assisted extraction of polysaccharides from
17

ACCEPTED MANUSCRIPT
mulberry leaves, Food Chemistry 127(3) (2011) 1273-1279.
22] Z.Y. Zhao, Q. Zhang, Y.F. Li, L.L. Dong, S.L. Liu, Optimization of ultrasound extraction of
[
Alisma orientalis polysaccharides by response surface methodology and their antioxidant activities,
Carbohydr Polym 119 (2015) 101-9.
[
23] M. Dubois, K.A. Gilles, J.K. Hamilton, P.A. Rebers, F. Smith, Colorimetric Method for
Determination of Sugars and Related Substances, Analytical Chemistry 28(3) (1956) 350-356.
24] M.M. Bradford, A rapid and sensitive method for the quantitation of microgram quantities of
protein utilizing the principle of protein-dye binding, Analytical Biochemistry 72(1) (1976) 248-254.
25] X. Jia, C. Ding, S. Yuan, Z. Zhang, Y. Chen, L. Du, M. Yuan, Extraction, purification and
characterization of polysaccharides from Hawk tea, Carbohydr Polym 99 (2014) 319-24.
26] B.D.E. Gaillard, N.S. Thompson, A.J. Morak, The interaction of polysaccharides with iodine : Part
I. Investigation of the general nature of the reaction, Carbohydrate Research 11(4) (1969) 509-519.
27] O.E. Adelakun, O.J. Oyelade, B.I.O. Ade-Omowaye, I.A. Adeyemi, M. Van de Venter, Chemical
[
[
[
[
composition and the antioxidative properties of Nigerian Okra Seed (Abelmoschus esculentus Moench)
Flour, Food and Chemical Toxicology 47(6) (2009) 1123-1126.
[
28] H. Maclean, ON ANOMALOUS REACTIONS OBTAINED IN TESTING URINE FOR SUGAR
WITH FEHLING'S SOLUTION, The Lancet 171(4402) (1908) 85-90.
29] Q. Li, Y. Xie, J. Su, Q. Ye, Z. Jia, Isolation and structural characterization of a neutral
polysaccharide from the stems of Dendrobium densiflorum, Int J Biol Macromol 50(5) (2012) 1207-11.
30] J.Z. He, Q.M. Ru, D.D. Dong, P.L. Sun, Chemical characteristics and antioxidant properties of
crude water soluble polysaccharides from four common edible mushrooms, Molecules 17(4) (2012)
373-87.
31] Z. Wang, Y. Zhao, T. Su, Extraction and antioxidant activity of polysaccharides from Rana
chensinensis skin, Carbohydr Polym 115 (2015) 25-31.
32] S.-h. Zhou, Z.-x. Fang, Y. Lü, J.-c. Chen, D.-h. Liu, X.-q. Ye, Phenolics and antioxidant properties
of bayberry (Myrica rubra Sieb. et Zucc.) pomace, Food Chemistry 112(2) (2009) 394-399.
33] X. Yin, Q. You, Z. Jiang, X. Zhou, Optimization for ultrasonic-microwave synergistic extraction of
polysaccharides from Cornus officinalis and characterization of polysaccharides, Int J Biol Macromol
3 (2016) 226-32.
34] S. Tsubaki, K. Oono, M. Hiraoka, A. Onda, T. Mitani, Microwave-assisted hydrothermal
extraction of sulfated polysaccharides from Ulva spp. and Monostroma latissimum, Food Chem 210
[
[
4
[
[
[
8
[
(
[
2016) 311-6.
35] C. Chen, L.J. You, A.M. Abbasi, X. Fu, R.H. Liu, Optimization for ultrasound extraction of
polysaccharides from mulberry fruits with antioxidant and hyperglycemic activity in vitro, Carbohydr
Polym 130 (2015) 122-32.
[
36] V. Samavati, Polysaccharide extraction from Abelmoschus esculentus: optimization by response
surface methodology, Carbohydrate Polymers 95(1) (2013) 588-597.
37] A. Raza, F. Li, X. Xu, J. Tang, Optimization of ultrasonic-assisted extraction of antioxidant
[
polysaccharides from the stem of Trapa quadrispinosa using response surface methodology, Int J Biol
Macromol 94(Pt A) (2017) 335-344.
[
38] B. Yang, Y. Jiang, M. Zhao, J. Shi, L. Wang, Effects of ultrasonic extraction on the physical and
chemical properties of polysaccharides from longan fruit pericarp, Polymer Degradation and Stability
3(1) (2008) 268-272.
39] R. He, Y. Zhao, R. Zhao, P. Sun, Antioxidant and antitumor activities in vitro of polysaccharides
9
[
18

ACCEPTED MANUSCRIPT
from E. sipunculoides, Int J Biol Macromol 78 (2015) 56-61.
40] M. Miao, A. Bai, B. Jiang, Y. Song, S.W. Cui, T. Zhang, Characterisation of a novel water-soluble
polysaccharide from Leuconostoc citreum SK24.002, Food Hydrocolloids 36 (2014) 265-272.
41] R. Wang, P. Chen, F. Jia, J. Tang, F. Ma, Optimization of polysaccharides from Panax japonicus
C.A. Meyer by RSM and its anti-oxidant activity, Int J Biol Macromol 50(2) (2012) 331-6.
42] M. Chylinska, M. Szymanska-Chargot, A. Zdunek, FT-IR and FT-Raman characterization of
non-cellulosic polysaccharides fractions isolated from plant cell wall, Carbohydr Polym 154 (2016)
8-54.
43] W.C. Zeng, Z. Zhang, H. Gao, L.R. Jia, W.Y. Chen, Characterization of antioxidant
polysaccharides from Auricularia auricular using microwave-assisted extraction, Carbohydr Polym
9(2) (2012) 694-700.
44] M. KacUráková, P. Capek, V. Sasinková, N. Wellner, A. Ebringerová, FT-IR study of plant cell
wall model compounds: pectic polysaccharides and hemicelluloses, Carbohydrate Polymers 43(2)
[
[
[
4
[
8
[
̆
(
[
2000) 195-203.
45] S.N. Sun, T.Q. Yuan, M.F. Li, X.F. Cao, F. Xu, Q.Y. Liu, Structural characterization of
hemicelluloses from bamboo culms (neosinocalamusaffinis), Cellulose Chemistry & Technology 46(3)
(
[
2012) 165-176.
46] Y.F. Zheng, Q. Zhang, X.M. Liu, L. Ma, F. Lai, Extraction of polysaccharides and its antitumor
activity on Magnolia kwangsiensis Figlar & Noot, Carbohydr Polym 142 (2016) 98-104.
47] J.-F. Yuan, Z.-Q. Zhang, Z.-C. Fan, J.-X. Yang, Antioxidant effects and cytotoxicity of three
purified polysaccharides from Ligusticum chuanxiong Hort, Carbohydrate Polymers 74(4) (2008)
22-827.
48] R.J. Reiter, D. Melchiorri, E. Sewerynek, B. Poeggeler, L. Barlow-Walden, J. Chuang, G.G. Ortiz,
[
8
[
D. Acuña-Castroviejo, A review of the evidence supporting melatonin's role as an antioxidant, Journal
of Pineal Research 18(1) (2010) 1-11.
[
49] G.H. Naik, K.I. Priyadarsini, J.G. Satav, M.M. Banavalikar, D.P. Sohoni, M.K. Biyani, H. Mohan,
Comparative antioxidant activity of individual herbal components used in Ayurvedic medicine,
Phytochemistry 63(1) (2003) 97-104.
[
50] J.A. Vaz, L. Barros, A. Martins, C. Santos-Buelga, M.H. Vasconcelos, I.C.F.R. Ferreira, Chemical
composition of wild edible mushrooms and antioxidant properties of their water soluble
polysaccharidic and ethanolic fractions, Food Chemistry 126(2) (2011) 610-616.
[
51] Q. Zhang, X.C. Liang, [Progress in study of antioxidant effects of Coptis chinensis and its major
contributions to diabetes treatment/therapy], Zhongguo Zhong yao za zhi = Zhongguo zhongyao zazhi
China journal of Chinese materia medica 40(12) (2015) 2285.
=
[
(
[
52] C.L. Ye, Q. Huang, Extraction of polysaccharides from herbal Scutellaria barbata D. Don
Ban-Zhi-Lian) and their antioxidant activity, Carbohydrate Polymers 89(4) (2012) 1131-1137.
53] Q. Li, N. Yu, Y. Wang, Y. Sun, K. Lu, W. Guan, Extraction optimization of Bruguiera gymnorrhiza
polysaccharides with radical scavenging activities, Carbohydr Polym 96(1) (2013) 148-55.
19

ACCEPTED MANUSCRIPT
Table 1
Box-Behnken experimental design and results of each set of variables on ROP extraction yield.
Variable
NO.
Yield (%)
A: extraction temp. (°C)
B: extraction time (min)
C: ultrasonic power (W)
1
2
3
4
5
6
7
8
9
-1(55)
1(30)
0(540)
10.13
0(60)
0(25)
0
10.24
10.09
8.28
1(65)
1
-1(20)
0
0
1(630)
0
0
0
10.31
9.37
-1
1
-1
1
0
0
9.83
-1
0
0
-1(450)
9.13
-1
0
-1
1
9.03
1
0
-1
1
8.87
11
0
-1
0
9.06
1
1
1
1
1
1
2
3
4
5
6
7
0
0
10.32
9.88
0
1
-1
1
0
-1
1
9.17
0
1
9.36
0
0
0
10.01
10.18
0
0
0
20

ACCEPTED MANUSCRIPT
Table 2
ANOVA of the response surface quadratic model of ROP yield.
a
b
c
Source
Model
A
SS
df
MS
F-value
14.69
P-value
0.0009
Significance
5
6
0
0
0
0
0
0
0
3
0
0
0
5
0
.67
9
0.63
**
-
003
.962E
.30
1
1
1
1
1
1
1
1
1
7
3
4
6.962E-003
0.30
0.16
6.91
5.86
5.97
1.62
2.51
19.21
0.72
85.41
0.6991
0.0340
0.0461
0.0446
0.2432
0.1574
0.0032
0.4228
< 0.0001
*
*
*
B
.25
0.25
C
.26
0.26
AB
AC
BC
.070
.11
0.070
0.11
2
*
.82
0.82
A
2
.031
.67
0.031
3.67
B
2
**
C
.30
0.043
0.079
0.016
Residual
.24
4.97
0.0776
Lack of fit
Pure error
Correlation
.064
.98
16
2
2
.9497
R
0.8851
R
Adj
a Sum of Squares; b Degree of Freedom; c Mean Square; * Means significant (p < 0.05; ** extremely significant
p < 0.01)
(
21

ACCEPTED MANUSCRIPT
Figure legends
Fig. 1. Effect of extraction temperature (A), extraction time (B), and ultrasonic power (C) om
ROP extraction yield according to single-factor experiments.
22

ACCEPTED MANUSCRIPT
Fig. 2. Response surface plots showing the individual and mutual effects of extraction temperature
(A), extraction time (B), and ultrasonic power (C) on the extraction yield of ROP.
23

ACCEPTED MANUSCRIPT
Fig. 3. (A) DEAE-Sepharose Fast Flow cellulose anion-exchange column elution profile of ROP.
(B) HPSEC elution curve of ROP-2. (C) FT-IR spectrum of ROP-2.
24

ACCEPTED MANUSCRIPT
Fig. 4. Monosaccharide composition of ROP-2 1: glucose, 2: mannose, 3: galactose, 4: arabinose,
5: xylose, 6: fructose, and 7: rhamnose)
25

ACCEPTED MANUSCRIPT
Fig. 5. (A) Hydroxyl radical scavenging activity, (B) superoxide radical scavenging activity, and
(C) DPPH scavenging activity of ROP-2.
26
