Synthesis of optically active 1,1′-binaphthyl-phthalocyanines linked via a crown ether unit

Article abstract of DOI:10.1016/S0957-4166(00)00480-8

Novel optically active metal and metal-free phthalocyanines, substituted with 1,1′-binaphthyl crown ether units, have been synthesized and characterized.

Full text of DOI:10.1016/S0957-4166(00)00480-8

TETRAHEDRON:
ASYMMETRY
Pergamon
Tetrahedron: Asymmetry 11 (2000) 4915–4922
Synthesis of optically active 1,1%-binaphthyl-phthalocyanines
linked via a crown ether unit
Hong-Wei Liu, Chuan-Fu Chen, Min Ai, Ai-Jun Gong, Jing Jiang and Fu Xi*
Center for Molecular Science, Institute of Chemistry, Chinese Academy of Sciences, Beijing 100080, PR China
Received 25 October 2000; accepted 27 November 2000
Abstract
Novel optically active metal and metal-free phthalocyanines, substituted with 1,1%-binaphthyl crown
ether units, have been synthesized and characterized. © 2001 Elsevier Science Ltd. All rights reserved.
1
. Introduction
There has been considerable recent work focusing on functionalizing the periphery of
phthalocyanines, with groups including alkyl, alkylamides, alkoxyl, porphyrins, oligo(ethyl-
eneoxy), benzyloxyethoxy, crown ether, dendrimers and tetrathiafulvalene to control the
supramolecular architecture and impart novel properties demanded in the fields of electronics,
1
–9
optoelectronics and charge transport. Up to now, few reports have explored the process of
10
combining chiral binaphthol groups with a phthalocyanine core. Since the first report on the
use of chiral binaphthyl-based crown ethers as hosts for molecular recognition, chiral binaphthol
has attracted much attention. Chiral macrocycles, metal complexes, linear oligomers and
polymers based on the 1,1%-binaphthyl structure have been synthesized for use in molecular
11
recognition, asymmetric catalysis and as new functional materials. Herein, the synthesis and
characterization of novel structural metal and metal-free phthalocyanines (R or S)-Pc (the
structure of (S)-Pc is shown in Scheme 1) substituted with optically active 1,1%-binaphthyl crown
ether units is presented.
2
. Results and discussion
The synthesis of the target optically active phthalocyanines was carried out as outlined in
Scheme 2. The structure of optically active phthalocyanine (R or S)-Pc can be considered to
*
Corresponding author.
0
957-4166/00/$ - see front matter © 2001 Elsevier Science Ltd. All rights reserved.
PII: S0957-4166(00)00480-8

4916
H.-W. Liu et al. / Tetrahedron: Asymmetry 11 (2000) 4915–4922
Scheme 1. The structure of optically active (S)-Pc
consist of three parts, i.e. phthalocyanine core, crown ether bridges and chiral binaphthyl end
5,13,14
groups. It was obtained from (R or S)-7, which was prepared by standard procedures
as
follows. Catechol 1 was brominated and subsequently alkylated with diethyleneglycol monotosyl-
ate 3 to give compound 4. Compound 5, prepared by tosylation of 4 with p-tosylchloride, was
converted into (R or S)-6 by reaction with optically active (R) or (S)-2,2%-dihydroxy-1,1%-binaph-
thyl. Then (R or S)-6 was treated with CuCN in DMF to give (R or S)-7. Finally, the (R or
S)-Pc-1 and (R or S)-Pc-2 were formed by treating (R or S)-7 with (N,N-dimethyl-
amino)ethanol, or with CuCN in DMF, respectively. In addition, (R or S)-Pc-2 could also be
prepared directly from (R or S)-6 by treatment with an excess of CuCN in DMF. Since the
target optically active phthalocyanines (R or S)-Pc were synthesized from optically pure starting
materials, it is important to avoid racemization during each step. According to the report by
1
4c
Cram et al. the chiral configuration of 1,1%-binaphthyl molecules is relatively stable at higher
temperature over extended periods of time. In our case, the possible racemization would take
place mainly in the preparation of (R)-7, (S)-7, (R)-Pc-2 and (S)-Pc-2. The experimental
conditions, refluxing in DMF at 153°C, or heating in (N,N-dimethylamino)ethanol for 20–40
hours, were relatively mild compared with the conditions employed by Cram. In order to check
that there was no racemization in these two steps, the unreacted starting materials, (R)-6, (S)-6,
(
R)-7 and (S)-7, were recovered and their optical rotation measured. The results showed that
their specific rotations were identical to the starting materials, demonstrating that there was no
1
configurational change. The new compounds were confirmed by H NMR, UV–vis, CD spectra
measurements and elemental analysis. The MALDI-TOF MS spectra of the optically active (R
or S)-Pc gave results consistent with the calculated molecular weights.

H.-W. Liu et al. / Tetrahedron: Asymmetry 11 (2000) 4915–4922
4917
Scheme 2. The synthesis of optically active (R or S)-Pc
Fig. 1 shows the CD and UV–vis spectra of (R)-Pc-1 and (S)-Pc-1 in CHCl . The UV–vis
3
spectrum of (S)-Pc-1, consisting of two closely spaced Q bands at 700 nm (m=333000) and 662
nm (m=272000), together with two associated vibrational overtones at 600 nm (m=57800) and
6
40 nm (m=102000), is characteristic of monomeric metal free phthalocyanines in dilute CHCl
3
−
5
15
solution (2×10 mol/L). In addition, a broad Soret absorption around 300 nm is observed,
and a weaker absorption in the 400–500 nm region may involve the ether oxygen lone pairs. The
−
4
CD spectra of (R)-Pc-1 and (S)-Pc-1 in CHCl (1×10 mol/L), display a strong absorption at
3
1
the B transition band, as well as a weak absorption at the Q band wavelength. In the case of
R)-Pc-1, the spectrum shows intense negative first and positive second Cotton effects at the B
b
1
(
b
1
transition band: 240 nm (Dm=930). On the other hand, the L transition around 290 nm
a
16
(
Dm=110) exhibits a single Cotton effect with weak intensity.
The CD and UV–vis spectra of (R)-Pc-2 and (S)-Pc-2 in CHCl are shown in Fig. 2.
3
Comparing the spectrum of (S)-Pc-2 with that of (S)-Pc-1, the difference appears at the Q band.
The sharp Q band absorption at 678 nm (m=337000), together with two weak absorptions in the
UV–vis spectrum of (S)-Pc-2, are assigned to a p–p* transition of the monomeric metallated
phthalocyanine.

4918
H.-W. Liu et al. / Tetrahedron: Asymmetry 11 (2000) 4915–4922
Figure 1. (a) CD and (b) UV–vis spectra of (i) (S)-Pc-1 and (ii) (R)-Pc-1 in CHCl3
16
According to chiral exciton coupling theory, the binaphthyl moieties of (R)-Pc-1 and
R)-Pc-2 are negative, which is correlated with a left-handed helicity between the two long axes
(
of naphthalene chromophores, while those of (S)-Pc-1 and (S)-Pc-2 are positive and of
right-handed helicity, judging from the CD pattern in the 220–300 nm region. The introduction
of the optically active binaphthyl moieties on the periphery of phthalocyanines induces the CD
10
absorption of (R)-Pc-1, (S)-Pc-1, (R)-Pc-2 and (S)-Pc-2 at Q bands and Soret bands.
3
. Experimental
All solvents were dried before use. Catechol was recrystallized from toluene. p-Toluenesul-
fonyl chloride was recrystallized from hexane. (N,N-Dimethylamino)ethanol and DMF were
freshly distilled before use. (±)-2,2%-Dihydroxy-1,1%-binaphthyl was resolved according to the
1
2
method reported by Cai and co-workers. (R)- and (S)-2,2%-dihydroxy-1,1%-binaphthyl were
obtained with specific rotations of [h] =+34.4 and [h] =−34.1 (c 1, THF), respectively.
D
D

H.-W. Liu et al. / Tetrahedron: Asymmetry 11 (2000) 4915–4922
4919
Figure 2. (a) CD and (b) UV–vis spectra of (i) (S)-Pc-2 and (ii) (R)-Pc-2 in CHCl3
13
4
,5-Dibromocatechol 2 was prepared according to a literature procedure. All other reagents
were used as supplied, without further purification.
1
H NMR spectra were recorded on a UNITY-200 instrument, with TMS as an internal
standard. MALDI-TOF MS was detected on an Instrum Biflex III spectrometer with a-cyano-4-
hydroxycinnamic acid (CCA) as a matrix. Optical rotations were determined on Perkin–Elmer
2
41 MC at 589 nm. Circular dichroism (CD) was measured at room temperature on a CD-6
spectropolarimeter. UV–vis spectra were obtained with a TU-120 spectrophotometer. Elemental
analyses were measured with a Heraeus CHN-RAPID instrument.
3
.1. 5-Tosyloxy-3-oxa-1-pentanol 3
-Toluenesulfonyl chloride (28.5 g, 0.15 mol) in methylene chloride (150 ml) was added
4
dropwise to a well-stirred ice-cooled solution of the diethylene glycol (60 ml, 0.63 mol),
triethylamine (80 ml, 0.57 mol) in methylene chloride (200 ml) over 1 h. The solution was stirred
at room temperature overnight, and then washed with 1N HCl and water. The organic layer was

4920
H.-W. Liu et al. / Tetrahedron: Asymmetry 11 (2000) 4915–4922
dried over anhydrous sodium sulfate and concentrated. The residue was dissolved in ethanol and
then cooled at 5°C. The diethylene glycol ditosylate was separated as white crystals with mp
8
7–89°C. After filtration, the filtrate was concentrated, and the residue was purified by silica gel
chromatography with 1:2 (v/v) ethyl acetate–petroleum ether (60–90°C) as the eluent to give the
1
product 3 as a yellowish oil (14 g, 36%). H NMR (CDCl ): l 2.4 (s, 3H, CH ), 3.4–3.7 (m, 6H,
3
3
CH ), 4.1–4.2 (m, 2H, CH ), 7.3–7.9 (m, 4H, ArH); elemental anal. calcd for C H O S: C,
2
2
11 16
5
5
0.77; H, 6.15. Found: C, 50.82; H, 6.44.
3
.2. 1,2-Bis[2%-(2%%-hydroxyethoxy)ethoxy]-4,5-dibromobenzene 4
Potassium carbonate (5.6 g, 40 mmol) was added under nitrogen to a stirred solution of
dibromocatechol 2 (5.36 g, 20 mmol) and 5-tosyloxy-3-oxa-1-pentanol 3 (11.3 g, 43 mmol) in
methyl cyanide (90 ml). The reaction mixture was refluxed for 24 h and then concentrated. The
residue was shaken with water and extracted with methylene chloride. The combined organic
layers were washed with brine, dried over anhydrous sodium sulfate and then concentrated. The
residue was purified by silica gel chromatography with 1:1 (v/v) ethyl acetate–petroleum ether
1
(
60–90°C) as the eluent to give the product 4 as a viscous oil (5.2 g, 59%). H NMR (CDCl ):
3
l 3.47 (s, 2H, OH), 3.6–4.2 (m, 16H, CH ), 7.1 (s, 2H, ArH); elemental anal. calcd for
2
C H O Br : C, 37.83; H, 4.50. Found: C, 37.49; H, 4.79.
1
4
20
6
2
3
.3. 1,2-Bis[2%-(2%%-(p-toluenesulfonyloxy)ethoxy)ethoxy]-4,5-dibromobenzene 5
p-Toluenesulfonyl chloride (17 g, 89 mmol) in pyridine (30 ml) was added to a solution of
,2-bis[2%-(2%%-hydroxyethoxy)ethoxy]-4,5-dibromobenzene 4 (16.6 g, 37.4 mmol) in pyridine (30
1
ml) with stirring at −18°C. The mixture was stirred for 48 h at −10°C, and then poured over ice,
acidified with aqueous HCl and extracted with methylene chloride. The combined organic layers
were washed with water, dried over anhydrous sodium sulfate and then concentrated. The
residue was purified by silica gel chromatography with 1:1 (v/v) ethyl acetate–petroleum ether
1
(
60–90°C) as the eluent to give the product 5 as a viscous oil (24.7 g, 88%). H NMR (CDCl ):
3
l 2.40 (s, 6H, CH ), 3.7–4.2 (m, 16H, CH ), 7.05 (s, 2H, ArH), 7.27 (d, 4H, ArH), 7.74 (d, 4H,
3
2
ArH); elemental anal. calcd for C H O Br S : C, 44.68; H, 4.26. Found: C, 44.56; H, 4.47.
2
8
32 10
2 2
3
2
.4. 2,3-(4%,5%-Dibromobenzo)-11,12:13,14-di(1%,2%-naphtho)-1,4,7,10,15,18-hexaoxacycloeicosa-
,11,13-triene (R or S)-6
1
,2-Bis[2%-(2%%-(p-toluenesulfonyloxy)ethoxy)ethoxy]-4,5-dibromobenzene 5 (9.9 g, 13.1 mmol)
was added dropwise to a mixture of (S)-2,2%-dihydroxy-1,1%-binaphthyl (3.76 g, 13.1 mmol) and
NaOH (1.15 g, 28.8 mmol) in boiling butanol (70 ml) stirred under nitrogen. The mixture was
refluxed for 16 h and evaporated under reduced pressure. The residue was shaken with water
and extracted with methylene chloride. The combined organic layers were washed with water,
dried over anhydrous sodium sulfate and then concentrated. The residue was purified by silica
gel chromatography with 5:1, and then 3:1 (v/v) ethyl acetate–petroleum ether (60–90°C) as the
eluent to give the product (S)-6 as a white foamy solid (4.6 g, 51%). Similarly, (R)-6 was
1
prepared (49%). H NMR (CDCl ): l 3.5–4.2 (m, 16H, CH ), 7.03 (s, 2H, ArH), 7.2–7.5 (m, 8H,
3
2
+
ArH), 7.8 (m, 4H, ArH); m/z (MALDI-TOF) 694.39 (M ); elemental anal. calcd for
C H O Br : C, 58.79; H, 4.32. Found: C, 58.89; H, 4.67 for (S)-6 and C, 59.00; H, 4.82 for
3
4
30
6
2

H.-W. Liu et al. / Tetrahedron: Asymmetry 11 (2000) 4915–4922
4921
(
R)-6; mp 81–83°C for (S)-6 and 82–83°C for (R)-6; [h] =−142 and 140 (c 1, CHCl ) for (S)-6
D
3
and (R)-6, respectively.
3
2
.5. 2,3-(4%,5%-Dicyanobenzo)-11,12:13,14-di(1%,2%-naphtho)-1,4,7,10,15,18-hexaoxacycloeicosa-
,11,13-triene (R or S)-7
A mixture of (S)-6 (1.39 g, 2 mmol), CuCN (0.54 g, 6 mmol), and pyridine (0.1 ml) in DMF
20 ml) was refluxed under nitrogen for 40 h. The mixture was cooled to room temperature and
(
then poured into aqueous ammonia. After stirring for 2 h, the mixture was extracted with
methylene chloride. The combined organic layers were washed with water, dried over anhydrous
sodium sulfate and then concentrated. The residue was purified by silica gel chromatography
with 3:1, and then 2:1 (v/v) ethyl acetate–petroleum ether (60–90°C) as the eluent to give the
1
product (S)-7 as a white foamy solid (0.86 g, 73%). Similarly, (R)-7 was prepared (70%). H
NMR (CDCl ): l 3.4–4.2 (m, 16H, CH ), 7.09–7.5 (m, 10H, ArH), 7.8 (m, 4H, ArH); elemental
3
2
anal. calcd for C H O N : C, 73.72; H, 5.12; N, 4.78. Found: C, 73.24; H, 5.46; N, 4.97 for
3
6
30
6
2
(
S)-7 and C, 73.73; H, 4.85; N, 4.95 for (R)-7; mp 100–102°C for (S)-7 and 98–101°C for (R)-7;
[
h] =−187 and 184 (c 1, CHCl ); for (S)-7 and (R)-7, respectively.
D
3
3
.6. Tetrakis[11,12:13,14-di(1%,2%-naphtho)-1,4,7,10,15,18-hexaoxacycloeicosa-2,11,13-trieno]-
phthalocyanine (R or S)-Pc-1
A mixture of (S)-7 (300 mg, 0.51 mmol) and (N,N-dimethylamino)ethanol (1.5 ml) was stirred
under nitrogen at 120°C for 20 h. After cooling to room temperature, it was purified by silica
gel chromatography with 1:0, 2:3, and then 3:7 (v/v) ethanol–chloroform as the eluent to give
the product (S)-Pc-1 as a dark green solid (88 mg, 29%). Similarly, (R)-Pc-1 was prepared
1
(
23%). H NMR (CDCl ): l 3.2–4.2 (br m, 64H, CH ), 6.9–8.2 (br m, 56H, ArH); mp >210°C;
3
2
+
+
m/z (MALDI-TOF) 2347.35 (M ) for (S)-Pc-1 and 2347.60 (M ) for (R)-Pc-1; UV–vis u
(
CHCl ), 700 nm (m=333000), 662 nm (m=272000), 640 nm (m=102000), 602 nm (m=57800), 425
3
nm (m=78100), 340 nm (m=213000), 294 nm (m=207000).
3
.7. Tetrakis[11,12:13,14-di(1%,2%-naphtho)-1,4,7,10,15,18-hexaoxacycloeicosa-2,11,13-trieno]-
phthalocyaninatocopper (R or S)-Pc-2
3.7.1. Procedure I
A mixture of (S)-7 (117 mg, 0.2 mmol) and CuCN (54 mg, 0.6 mmol) in DMF (0.5 ml) was
refluxed under nitrogen for 24 h. After cooling to room temperature, a small amount of
methylene chloride was added to dissolve any solid formed, and then the solution was poured
into aqueous ammonia. After stirring for 2 h, the mixture was extracted with methylene
chloride. The combined organic layers were washed with water, dried over anhydrous sodium
sulfate and concentrated. The residue was purified by silica gel chromatography with 1:0, 2:3
and then 3:7 (v/v) ethanol–chloroform as the eluent to give the product (S)-Pc-2 as a dark green
solid (50 mg, 42%). Similarly, (R)-Pc-2 was prepared (37%).
3
.7.2. Procedure II
A mixture of (S)-6 (694 mg, 1 mmol), CuCN (0.45 g, 5 mmol), and pyridine (0.15 ml) in DMF
2 ml) was refluxed under nitrogen for 24 h. After the same treatment as in Procedure I, the
(

4922
H.-W. Liu et al. / Tetrahedron: Asymmetry 11 (2000) 4915–4922
crude product was purified by silica gel chromatography with 1:0, 2:3 and then 3:7 (v/v)
ethanol–chloroform as the eluent to give the product (S)-Pc-2 as a dark green solid (420 mg,
1
7
6
2
0%). (R)-Pc-2 was prepared similarly (68%). H NMR (CDCl ): l 3.2–4.2 (br m, 64H, CH ),
3
2
+
.9–8.2 (br m, 56H, ArH); mp >260°C; m/z (MALDI-TOF) 2407.56 (M ) for (S)-Pc-2 and
407.60 (M ) for (R)-Pc-2; UV–vis u (CHCl ), 678 nm (m=337000), 656 nm (m=61300), 610 nm
+
3
(
m=63600), 410 nm (m=71700), 338 nm (m=221000), 283 nm (m=278000).
Acknowledgements
We are grateful to the support of the National Natural Science Foundation of China (contract
grant number: 29974034).
References
1. van Nostrum, C. F.; Nolte, R. J. M. J. Chem. Soc., Chem. Commun. 1996, 2385 and references cited therein.
2. Brewis, M.; Clarkson, G. J.; Holder, A. M.; Mckeown, N. B. J. Chem. Soc., Chem. Commun. 1998, 969.
3. Clarkson, G. J.; Mckeown, N. B.; Treacher, K. E. J. Chem. Soc., Perkin Trans. 1 1995, 1817.
4. Wang, C. S.; Bryce, M. R.; Batsanov, A. S.; Stanley, C. F.; Beeby, A.; Howard, J. A. K. J. Chem. Soc., Perkin
Trans. 2 1997, 1671.
5
6
7
8
. Engelkamp, H.; Middelbeek, S.; Nolte, R. J. M. Science 1999, 284, 785.
. Li, J.; Diers, J. R.; Seth, J.; Yang, S. I.; Bocian, D. F.; Holten, D.; Lindsey, J. S. J. Org. Chem. 1999, 64, 9090.
. Li, J.; Lindsey, J. S. J. Org. Chem. 1999, 64, 9101.
. Fox, J. M.; Katz, T. J.; Elshocht, S. V.; Verbiest, T.; Kauranen, M.; Persoons, A.; Thongpanchang, T.; Krauss,
T.; Brus, L. J. Am. Chem. Soc. 1999, 121, 3453.
9. Smolenyak, P.; Peterson, R.; Nebesny, K.; Torker, M.; O’Brien, D. F.; Armstrong, N. R. J. Am. Chem. Soc.
1
999, 121, 8628.
1
0. (a) Kobayashi, N. J. Chem. Soc., Chem. Commun. 1998, 487; (b) Kobayashi, N.; Kobayashi, Y.; Osa, T. J. Am.
Chem. Soc. 1993, 115, 10994; (c) Kobayashi, N.; Higashi, R.; Titeca, B. C.; Lamote, F.; Ceulemans, A. J. Am.
Chem. Soc. 1999, 121, 12018.
1
1
1
1
1. Pu, L. Chem. Rev. 1998, 98, 2405 and references cited therein.
2. Cai, D. W.; Hughes, D. L.; Verhoeven, T. R.; Reider, P. J. Tetrahedron Lett. 1995, 36, 7991.
3. van Nostrum, C. F.; Picken, S. J.; Schouten, A.-J.; Nolte, R. J. M. J. Am. Chem. Soc. 1995, 117, 9957.
4. (a) Pawlowski, G.; Hanack, M. Synthesis 1980, 287; (b) Borjesson, L.; Welch, C. J. Acta Chem. Scand. 1991, 45,
6
21; (c) Kyba, E. P.; Gokel, G. W.; Jong, F. D.; Koga, K.; Sousa, L. R.; Siegel, M. G.; Kaplan, L.; Sogah, G.
D. Y.; Cram, D. J. J. Org. Chem. 1977, 42, 4173.
1
1
5. Sielcken, O. E.; Van Tilborg, M. M.; Roks, M. F. M.; Hendriks, R.; Drenth, W.; Nolte, R. J. M. J. Am. Chem.
Soc. 1987, 109, 4261.
6. Harada, N.; Nakanishi, K. Circular Dichroic Spectroscopy, Exciton Coupling in Organic Stereochemistry;
University Science Books: New York, 1983.
.
.
