Communication
doi.org/10.1002/chem.202003280
Chemistry—A European Journal
be obviated if g-carboxyacyl azides could be catalytically ac-
cessed via the desymmetrisation of meso-glutaric anhydrides
followed by a Curtius rearrangement in situ.
Table 1. Catalyst screening and optimisation of experimental conditions.
Reports examining the reactivity of azide towards cyclic an-
hydrides are sparse. Seminal work in 1966[15] described the
treatment of phthalic anhydride derivatives with azide, albeit
under forcing conditions (i.e. DMF/DMSO, >1508C, excess
NaN3), yielding benzimidazolones. The reaction mechanism
was purported to proceed via a cyclic intermediate b-N-car-
boxyanhydride (b-NCA, or ’Leuchs anhydride’).[16,17] More recent-
ly, NCAs have been investigated in the context of drug delivery
systems,[18] due to their capacity to form polypeptides on treat-
ment with a variety of basic or nucleophilic initiators.[19] Conse-
quently, a smaller subset of NCA literature broaches the syn-
thetic challenges of accessing aliphatic b-NCAs while avoiding
polymerisation by the treatment of succinic anhydride deriva-
tives with an excess of TMSN3.[19a,20] However a general, catalyt-
ic solution to this problem has proven elusive.
Entry[a]
Catalyst
Solvent
t
[h]
Yield 19
[%][b]
1[c]
2[d]
3[e]
4[f]
5[g]
6
7
8
9
10
11
12
13[h]
14
15
16[i]
–
–
–
–
–
–
PhMe
CHCl3
CH2Cl2
THF
72
72
72
72
96
24
24
24
24
16
16
6
0
0
0
0
0
6
0
5
MeCN
CHCl3
CHCl3
CHCl3
CHCl3
CHCl3
CHCl3
CHCl3
CHCl3
CHCl3
CHCl3
CHCl3
AcOH
Ph3P=O
DMF
14
63
76
97
82
>98
97
>98
DMAP
proton sponge
DIPEA
Herein, we report the first smooth catalytic desymmetrative
addition of TMSN3 to meso-glutaric anhydrides 13 to generate
14 after protonolysis (Figure 1C). Intermediate 14 is remarkably
versatile: it can either be isolated, or, after removal of a hetero-
geneous catalyst by filtration (and without purification) trans-
formed into either g-amino acids 15 or their N-protected car-
bamate derivates 16. The hemi-acyl azide 14 can also—with-
out the requirement for any activating agents—be converted
to synthetically-desirable g-lactams 17 in the presence of a nu-
cleophilic catalyst (Figure 1C).
DABCO
16
6
pyridine
DIPEA@PS
DIPEA@PS
3
1.5
[a] The reactions summarised in entries 1–5 were performed at room tem-
perature. [b] Determined by H NMR spectroscopic analysis using 4-iodoa-
1
nisole as an internal standard. [c] Carbamoyl azide 21 (28%) observed.
[d] Lactams 23 (28%) and 24 (4%) observed. [e] Lactams 23 (18%) and
24 (4%) recovered after chromatography. [f] Complex reaction mixture.
[g] Clean conversion to carbamoyl azide 21 (48%). The use of 2 equiva-
lents TMSN3 facilitated the isolation of 22 in 97% yield upon desilylation
of 21 with MeOH (10.0 equiv.). [h] Reaction time to complete conversion
<10 min with 5 mol% AcOH as co-catalyst (86%). [i] Reaction tempera-
ture À208C.
We began investigations by examining the reactivity of
TMSN3 (Caution: see the Supporting Information Section 2.3.1.)
towards 3-phenylglutaric anhydride (18) at room temperature;
intending to access amino acids and carbamates through inter-
mediate silylazidation of product 19 in a range of solvents
(Table 1, entries 1–5). Although thermal decomposition at
room temperature of acyl azide 19 was expected to yield the
corresponding isocyanate to some degree by Curtius rear-
rangement,[21] we were surprised to instead observe an array
of isocyanate-derived products 21–24. Carbamoyl azide forma-
tion from isocyanates has been known to occur only under
treatment with HN3 promoted by strong acids at elevated tem-
peratures,[22] and has not been observed in cases where succin-
ic anhydrides were used. In this case, carbamoyl azide forma-
tion is attributed to fast trapping of the intermediate isocya-
nate by a second equivalent of TMSN3 to form 21. This process
was found to occur less readily in toluene (entry 1) and chlori-
nated solvents (entries 2 and 3) compared to either of THF
(entry 4) or acetonitrile (97% yield of 21, entry 5). Furthermore,
we were initially surprised to observe concurrent formation of
lactams 23 and 24 in chlorinated solvents (vide infra).
ed acid catalysis of the silylazidation process lead to inhibition
relative to the uncatalysed reaction (entry 7) while Lewis bases
such as Ph3P=O and DMF were identified as weak promoters
(entries 8 and 9, respectively). DMAP was found to catalyse the
reaction to a significant extent (entry 10) and conventional
poorly-nucleophilic tertiary amines were subsequently exam-
ined in an effort to partition nucleophilic- from base catalysis
(entries 11 and 12). Although every subsequent amine evaluat-
ed behaved as an effective promoter (entries 12–13), weakly
Brønsted-basic pyridine was demonstrated to be the most effi-
cient homogeneous catalyst system (entry 14). Substitution of
pyridine for polystyrene-bound Hꢁnig’s base (DIPEA@PS,
entry 15) and raising the reaction temperature from À508C to
À208C (entry 16) not only shortened the reaction times signifi-
cantly, but provided a facile means to remove the catalyst
from the reaction after completion via filtration.
Although further manipulations of carbamoyl azides are
known to provide either N-protected or free amines,[22c,23] both
derivatisations would require the extrusion of volatile, explo-
sive and toxic hydrazoic acid (HN3). In the interest of safety
and synthetic utility, we pursued an alternative route utilising
equimolar TMSN3. Reduction of the reaction temperature to
circumvent thermal Curtius rearrangement provided 19 cleanly,
albeit with poor conversion (6%, entry 6). Attempts at Brønst-
Mechanistic investigations into the ring-opening process
(see the Supporting Information) supported the formation of
an ammonium azide, in situ-derived from the Brønsted basic
amine precatalyst and HN3 (pKa =4.72) present in commercial
supplies of TMSN3 which is produced in small amounts by hy-
drolysis with adventitious H2O. Anhydride 18 can undergo nu-
&
&
