Catalytic oxidation of cycloalkanes by porphyrin cobalt(II) through efficient utilization of oxidation intermediates

Article abstract of DOI:10.1142/S1088424620500303

The catalytic oxidation of cycloalkanes using molecular oxygen employing porphyrin cobalt(II) as catalyst was enhanced through use of cycloalkyl hydroperoxides, which are the primary intermediates in oxidation of cycloalkanes, as additional oxidants to further oxidize cycloalkanes in the presence of porphyrin copper(II), especially for cyclohexane, for which the selectivity was enhanced from 88.6 to 97.2% to the KA oil; at the same time, the conversion of cyclohexane was enhanced from 3.88 to 4.41%. The enhanced efficiency and selectivity were mainly attributed to the avoided autoxidation of cycloalkanes and efficient utilization of oxidation intermediate cycloalkyl hydroperoxides as additional oxidants instead of conventional thermal decomposition. In addition to cyclohexane, the protocol presented in this research is also very applicable in the oxidation of other cycloalkanes such as cyclooctane, cycloheptane and cyclopentane, and can serve as a applicable and efficient strategy to boost the conversion and selectivity simultaneously in oxidation of alkanes. This work also is a very important reference for the extensive application of metalloporphyrins in catalysis chemistry.

Full text of DOI:10.1142/S1088424620500303

This is a JAM - Just Accepted Manuscript
Journal of Porphyrins and Phthalocyanines
Article Title:
Catalytic oxidation of cycloalkanes by porphyrin cobalt(II) through efficient
utilization of oxidation intermediates
Author(s):
DOI:
Hai M. Shen, Xiong Wang, A B. Guo, Long Zhang, Yuan B. She
10.1142/S1088424620500303
To be cited as:
Hai M. Shen, Xiong Wang, A B. Guo, Long Zhang, Yuan B. She, Catalytic oxidation of
cycloalkanes by porphyrin cobalt(II) through efficient utilization of oxidation intermediates,
Journal of Porphyrins and Phthalocyanines, doi: 10.1142/S1088424620500303
Received: 13 April 2020
Accepted: 17 June 2020
This is the accepted and unedited version of a newly accepted manuscript after peer-review evaluation. No
copyediting, typesetting or proof correction has been performed, so it is by no means the definitive final version of
the manuscript. This format allows a rapid display online with a DOI, which means that the manuscript is already
citable in a sustainable manner.
It has been uploaded in advance for the benefit of our customers. The manuscript will be copyedited, typeset and
proofread before it is released in the final form. As a result, the published copy may differ from the unedited version.
Readers should obtain the final version from the above link when it is published. The authors are responsible for
the content of this Accepted Article.
When the corrected proof will be available, the manuscript will move to the Online Ready page of the website. The
definitive version with page numbers will be available after publication of the issue in which it takes place.
Thanks to this free and optional opportunity, the newly accepted manuscript can be quickly shared with the
scientific community.
In no case, WorldScientific can be held responsible of mistakes in the content of use of this Just Accepted
Manuscript.

Accepted manuscript to appear in JPP
Catalytic oxidation of cycloalkanes by porphyrin cobalt(II)
through efficient utilization of oxidation intermediates
Hai M. Shen, Xiong Wang, A B. Guo, Long Zhang and Yuan B. She*
College of Chemical Engineering, Zhejiang University of Technology, Hangzhou 310014, China
Received date (to be automatically inserted after your manuscript is submitted)
Accepted date (to be automatically inserted after your manuscript is accepted)
ABSTRACT: The catalytic oxidation of cycloalkanes using molecular oxygen employing porphyrin cobalt
(II) as catalyst was enhanced through utilizing cycloalkyl hydroperoxides that are the primary intermediates in
oxidation of cycloalkanes, as additional oxidants to further oxidize cycloalkanes in the presence of porphyrin
copper (II), especially for the cyclohexane, for which the selectivity was enhanced from 88.6% to 97.2% to
the KA oil, at the same time, the conversion of cyclohexane was enhanced from 3.88% to 4.41%. The
enhanced efficiency and selectivity were mainly attributed to the avoided autoxidation of cycloalkanes and
efficient utilization of oxidation intermediates cycloalkyl hydroperoxides as additional oxidants instead of the
conventional thermal decomposition. Besides the cyclohexane, the protocol presented in this research is also
very applicable in the oxidation of other cycloalkanes, such as cyclooctane, cycloheptane and cyclopentane,
and can serve as a applicable and efficient strategy to boost the conversion and selectivity simultaneously in
oxidation of alkanes. And this work also is a very important reference for the extensive application of
metalloporphyrins in catalysis chemistry.
KEYWORDS: metalloporphyrin, oxidation, oxygen, cycloalkane, cycloalkyl hydroperoxide.
INTRODUCTION
The efficient, selective and practical oxidation of cycloalkanes is still of great urgency and challenge in chemical
industry for the extensive application of their oxygenated products and the high inertness of the C-H bond in cycloalkanes,
especially for cyclohexane, which has captured a continuous and significant interest from scientists in both theory
researches and application researches [1-5]. The oxygenated products of cyclohexane, which mainly refer to KA oil (a
mixture of cyclohexanol and cyclohexanone), are the indispensable raw materials in production of the intermediates for a
series of polymers, for example nylon-6 and nylon-66 [6-9]. In the oxidative functionalization of cycloalkanes, molecular
oxygen (O2) is regarded as the most promising oxidant for its readily availability, low cost and environmental harmlessness
[9-13], compared with others such as hydrogen peroxide [14,15], tert-butyl hydroperoxide [16,17], 3-chloroperbenzoic acid
[18,19], iodosylbenzene [20-23], iodosylbenzene diacetate [24,25] and so on [26], considering the demands of green
chemistry. Thus, the oxidation of cyclohexane in industry is carried out employing O2 as oxidant at present catalyzed by the
*Correspondence to: Yuan B. She. E-mail address: haimshen@zjut.edu.cn. Fax: (+86)571-8832-0533. Tel. : (+86)571-8832-0533.

Accepted manuscript to appear in JPP
homogeneous cobalt salt with the conversion of 3%~8% and selectivity of 80%~85% to KA oil, and in order to activate O2,
the industrial process is usually conducted at 150~170 ºC under the oxygen pressure of 1.0~2.0 MPa [8,27,28]. It is obvious
that the current process of cyclohexane oxidation suffers from low conversion, low selectivity and high temperature
seriously. And the low selectivity could be mainly ascribed to the high reaction temperature to some extent, since the
autoxidation of cyclohexane without selectivity would occur at high temperature, accompanied by the undesired thermal
decomposition of oxidation intermediate cyclohexyl hydroperoxide which is the primary intermediate product in oxidation
of cyclohexane [8,29-31]. Both of them can product a lot of undesired oxygenated products, such as hexanedioic acid,
which is a troublesome component to be separated from the obtained oxygenated mixtures. Therefore, it is a great urgency
to develop the process of cycloalkane oxidation with high conversion and selectivity under mild conditions.
With the purpose to boost the efficiency and selectivity in cycloalkane oxidation employing O2, and smooth the process,
a variety of catalytic systems have been developed, for example employing metal nanoparticles as catalysts [32,33], metal
oxides as catalysts [34,35], transition metal complexes as catalysts [36,37], molecular sieves as catalysts [38], biocatalysis
[39], photocatalysis [10,40], and so on. Among them, metalloporphyrins as transition metal complexes and chemical
structural analogues of cytochrome P-450, have been employed in the oxidation of cycloalkanes widely, which could
activate O2 efficiently and functionalize C-H bond selectively [13,22,23,41]. The conversion reached up to 39.8% reported
by Huang and co-workers in the oxidation of cyclohexane employing heterogeneous metalloporphyrins as catalysts, but the
selectivity was just 56.5% to the KA oil, and the reaction temperature range was 150~165 ºC [36,37,42,43]. In the report of
Liu and co-workers, the selectivity obtained was 72.1% to the KA oil in the conversion of 13.1% for cyclohexane catalyzed
by heterogeneous metalloporphyrins too [44]. And in the work of Yang and co-workers, the selectivity was 72.2% in the
conversion of 29.9% using porous polymeric metalloporphyrins as catalysts at 150 ºC [41]. Although the conversion of
cyclohexane was enhanced with the aid of metalloporphyrins, to boost the conversion and selectivity simultaneously in
catalytic oxidation of cycloalkanes has not been achieved, even in the presence of metalloporphyrins as catalysts, because of
the unselective autoxidation and thermal decomposition of oxidation intermediates cycloalkyl hydroperoxides at so high
reaction temperature. Therefore, it is still a very challenging task to realize the catalytic oxidation of cycloalkanes with high
selectivity and acceptable conversion employing molecular oxygen (O2) as oxidant under mild conditions.
In the exploration to boost the efficiency and selectivity in oxidative functionalization of cycloalkanes with O2
employing metalloporphyrins as catalysts [45-50], we focus on the catalytic transformation of cycloalkyl hydroperoxides
and the lower reaction temperature in order to avoid the unselective thermal decomposition of the oxidation intermediates
cycloalkyl hydroperoxides and autoxidation of cycloalkanes. Inspired by the high selectivity and low reaction temperature
in catalytic oxidation of cyclohexane using tert-butyl hydroperoxide as oxidant and copper (II) complexes as catalysts [51-
54], a strategy emerged in our minds to enhance the catalytic oxidation of cycloalkanes through efficient utilization of the
oxidation intermediates cycloalkyl hydroperoxides as additional oxidants to oxidize cycloalkanes employing porphyrin
copper (II) as catalyst. In order to activate O2, porphyrin cobalt (II) was introduced to this catalytic system, which was a
kind of very efficient catalyst in oxidation of various C-H bonds in hydrocarbon compounds [55,56]. Employed in the
oxidation of cyclohexane, this dual-metalloporphyrins catalytic system exhibited encouraging outcomes as expected. Not
only the selectivity was enhanced from 88.6% to 97.2% towards the KA oil, but also the conversion was improved from
3.88% to 4.41% simultaneously for cyclohexane. And for other cycloalkanes, this method was also very practical with
satisfying selectivity and conversion. Hence, herein we reported the efficient and selective oxidative functionalization of
cycloalkanes using O2 catalyzed by porphyrin cobalt (II) employing oxidation intermediates cycloalkyl hydroperoxides as

Accepted manuscript to appear in JPP
additional oxidants in the presence of porphyrin copper (II) (Equation 1). This work not only presented a practical strategy
to enhance the process of cycloalkanes oxidation, but also demonstrated a significant protocol for other alkanes' selective
oxidation. To the best of our knowledge, the research demonstrated in this paper is a very rare and significant
documentation for catalytic oxidation of alkanes, in which oxidation intermediates cycloalkyl hydroperoxides were utilized
as additional oxidants instead of the conventional thermal decomposition to increase the selectivity of target products and
the conversion of cycloalkanes substrates simultaneously in the presence of dual-metalloporphyrins catalytic system. And
this work also is a very important reference for the extensive application of metalloporphyrins in catalysis chemistry.
<Equation 1>
EXPERIMENTAL
Chemical reagents and materials
Cyclopentane (98%), cyclohexane (99%), cycloheptane (98%) and cyclooctane (99%) were purchased from Shanghai
Energy Chemical Co. Ltd., China, TCI Co. Ltd., Alfa Aesar Co. Ltd. respectively, and redistilled in the presence of sodium
before use. All of the oxygenated products employed as standard samples were analytical grade and purchased from TCI Co.
Ltd. All of the metalloporphyrins were synthesized as illustrated in supporting information. All of the other common
chemical reagents employed in this work were in analytical-grade and used as received without any further purification
unless noted otherwise.
Procedure of cycloalkane oxidation
The catalytic oxidation of cycloalkanes with O2 in the presence of metalloporphyrins as catalysts was conducted in an
autoclave reactor (100 mL) possessing an inner Teflon liner. In the typical procedure, cycloalkane (200 mmol) and
metalloporphyrin (1.2 ×10-3%, mol/mol) were sealed in the reactor, and heated with stirring to the set reaction temperature.
Then, molecular oxygen (O2) was introduced to reach up to the set pressure. The catalytic oxidation reaction was conducted
with stirring for 8.0 h under the set temperature and pressure. When the reaction finished, the reactor was transferred to ice
water to be cooled to room temperature. When the autoclave reactor was opened, triphenylphosphine (25 mmol, 6.5573 g)
was added to the obtained solution and stirred for 30 min at room temperature to reduce the residual oxidation intermediates
cycloalkyl hydroperoxides to alcohols quantitatively. Then the reaction mixture was shifted totally to a 100 mL volumetric
flask using acetone as solvent to calculate the yields of oxygenated products. The yields of alcohols and ketones were
calculated through GC analyses with toluene as internal standard. A small amount of residual hydroperoxides was obtained
based on the amount of O=PPh3 in GC analyses. The quantities of aliphatic diacids were calculated based on HPLC
analyses using benzoic acid as internal standard and employing a Amethyst C18-H liquid chromatography column (250 mm
× 4.6 mm × 0.25 µm). All of the substances in GC and HPLC analyses were identified through comparison with the
authentic samples purchased from TCI Co. Ltd.
RESULTS AND DISCUSSION

Accepted manuscript to appear in JPP
Catalytic oxidation of cyclohexane employing dual-metalloporphyrins system
In this work, considering the importance of oxygenated products in chemical industry, cyclohexane was selected as the
representative to carry out the catalytic oxidation of cycloalkanes to verify our design and expectation. In order to avoid the
autoxidation of cyclohexane without selectivity, the reaction temperature was set at 120 ºC, at which the autoxidation would
not occur as illustrated in our previous work [49]. T(4-Cl)PPFe (5, 10, 15, 20-tetrakis(4-chlorophenyl)porphyrin iron(II)),
T(4-Cl)PPMn, T(4-Cl)PPCo, T(3-Cl)PPCo, T(2-Cl)PPCo were selected to activate O2, and T(4-Cl)PPCu (5, 10, 15, 20-
tetrakis(4-chlorophenyl)porphyrin copper(II)) was prepared to enhance the oxidizing ability of cyclohexyl hydroperoxide.
The catalytic test was carried out under solvent-free conditions using O2 as oxidant. And in this work, the amount of
cyclohexyl hydroperoxide was calculated into the selectivity of KA oil for cyclohexyl hydroperoxide in a small amount
could be transformed to KA oil smoothly when the reaction was completed. It was demonstrated in Table 1 and Table S1 in
the supporting information that, the autoxidation of cyclohexane could not happen at 120 ºC without the presence of
metalloporphyrins (Table 1, Entry 1). When metalloporphyrins were employed as catalysts, the conversion reached up to
3.88% for T(2-Cl)PPCo as catalyst under the same reaction conditions with an acceptable selectivity of 88.6% towards KA
oil. Other metalloporphyrins involved also exhibited obvious catalytic activity expect for T(4-Cl)PPCu in oxidation of
cyclohexane, which meant that T(4-Cl)PPCu could not activate molecular oxygen under current reaction conditions.
However, when T(4-Cl)PPCu was introduced to the cyclohexane oxidation employing other metalloporphyrins mentioned
above as catalysts to form dual-metalloporphyrins system, the efficiency and selectivity were enhanced obviously for most
metalloporphyrins involved, especially for T(2-Cl)PPCo. The conversion was boosted from 3.88% to 4.41% for
cyclohexane, and more importantly the selectivity of KA oil was enhanced from 88.6% to 97.2% (Entry 2, Entry 6) owing
to the introduction of T(4-Cl)PPCu. The simultaneous increase in selectivity and conversion were realized as expected,
especially in the dual-metalloporphyrins catalytic system constituted by T(4-Cl)PPCu and T(2-Cl)PPCo. In above dual-
metalloporphyrins catalytic system constituted by T(4-Cl)PPCu and T(2-Cl)PPCo, the oxidation intermediate cyclohexyl
hydroperoxide was employed as secondary oxidant to transform cyclohexane to cyclohexanol and cyclohexanone catalyzed
by T(4-Cl)PPCu, in which not only the thermal decomposition of cyclohexyl hydroperoxide was avoided, resulted in the
higher selectivity towards KA oil, but also the conversion of cyclohexane was boosted obviously, resulted in the
simultaneous enhancement in conversion and selectivity. As for the catalytic system composed by T(4-Cl)PPCu and T(4-
Cl)PPMn, the unsatisfying catalytic efficiency and selectivity could be attributed to the adverse intermolecular interactions
between two metalloporphyrins, which had been illustrated as dimerization of two metalloporphyrins and intermolecular
redox [57,58].
<Table 1>
Effect of proportion between two metalloporphyrins and the function of T(4-Cl)PPCu
With the optimized catalytic system obtained, the molar proportion of two metalloporphyrins in dual-
metalloporphyrins system was explored thoroughly. Firstly the amount of T(2-Cl)PPCo was set at 6.0 × 10-4% (mol/mol),
then the proportion between T(2-Cl)PPCo and T(4-Cl)PPCu was changed from 1.0 : 1.0 to 1.0 : 3.0, and the reaction time
was set as 8.0 h based on our previous exploratory experiments in which no obvious induction period was observed because
the oxidation of cycloalkanes in this work was mainly conducted through the catalytic route, not the non-selective free

Accepted manuscript to appear in JPP
radical path. As illustrated in Table 2 that, satisfying selectivity (97.2%) towards KA oil in acceptable conversion of
cyclohexane (4.41%) was achieved when the proportion between T(2-Cl)PPCo and T(4-Cl)PPCu was 1.0 : 1.0. Further
raising the amount of T(4-Cl)PPCu, no enhanced efficiency and selectivity was obtained and the conversion of cyclohexane
exhibited some decrease because of the adverse intermolecular interactions between metalloporphyrins. Thus, the satisfying
proportion between T(2-Cl)PPCo and T(4-Cl)PPCu was set as 1.0 : 1.0. As mentioned above, the enhanced efficiency and
selectivity in catalytic oxidation of cyclohexane could be mostly ascribed to the avoided autoxidation of cyclohexane and
efficient transformation of cyclohexyl hydroperoxide, which was realized through utilization of cyclohexyl hydroperoxide
as an additional oxidant to oxidize cyclohexane employing T(4-Cl)PPCu as catalyst. The autoxidation of cyclohexane under
current conditions has been inhibited as demonstrated in Table 1. The performance of cyclohexyl hydroperoxide in
oxidation of cyclohexane employing T(4-Cl)PPCu as catalyst was confirmed through using tert-butyl hydroperoxide as the
analogue of cyclohexyl hydroperoxide in our work. As demonstrated in Table 3, when the oxidation of cyclohexane was
conducted at 60 ºC for 4.0 h with tert-butyl hydroperoxide, no oxygenated product was produced without the presence of
metalloporphyrins (Table 3, Entry 1). But as T(4-Cl)PPCu, T(2-Cl)PPCo or their physical mixture were applied as catalysts,
obvious cyclohexanol and cyclohexanone were detected, which illustrated that all of T(4-Cl)PPCu, T(2-Cl)PPCo and their
physical mixture could enhance the oxidizing ability of cyclohexyl hydroperoxide, and T(4-Cl)PPCu exhibited higher
performance than T(2-Cl)PPCo. Obviously, the existence of T(4-Cl)PPCu promoted the efficient utilization of cyclohexyl
hydroperoxide as oxidant and decreased the unselective thermal decomposition, resulting in the enhanced efficiency and
selectivity.
<Table 2>
<Table 3>
Substrate scope
In order to check the applicability of the dual-metalloporphyrins catalytic system investigated here, cyclopentane (C5),
cycloheptane (C7) and cyclooctane (C8) besides cyclohexane (C6) were selected as cycloalkanes substrates, and the
oxidative conversion were carried out at the temperature at which autoxidation would not happen. It was illustrated in Table
4, except for the cyclopentane, all the other cycloalkanes could be transformed to corresponding alcohols, ketones and
hydroperoxides with satisfying selectivity above 97% in acceptable conversion. The poor selectivity in cyclopentane
oxidation could be primarily ascribed to the higher strain in cyclopentane. As demonstrated in Table S2 and Table S5, in the
oxidation of cycloheptane, the main oxygenated product is pentanedioic acid. Based on the satisfying substrate tolerance, it
is considered as a practical and efficient strategy to promote the catalytic oxidation of cycloalkanes through utilizing
oxidation intermediates cycloalkyl hydroperoxides as additional oxidants catalyzed by dual-metalloporphyrins system,
which will be a helpful reference in the enhancement of catalytic oxidation of other alkanes too.
<Table 4>

Accepted manuscript to appear in JPP
Comparison with existing cyclohexane oxidation systems
At last, for the importance of oxygenated products in chemical industry, the dual-metalloporphyrins catalysis system
presented herein was compared with a number of existing oxidation systems for cyclohexane catalyzed by
metalloporphyrins or others with O2 as oxidant. The results were listed in Table 5. It is obvious that, the major superiorities
of our protocol were the lower reaction temperature, higher selectivity for the KA oil, solvent-free and additive-free
conditions, and simpler catalysts. The strategy was proven to be very effective to boost the catalytic oxidation of
cyclohexane through employing oxidation intermediate cyclohexyl hydroperoxide as additional oxidant and dual-
metalloporphyrins as catalysts, with satisfying selectivity of 97.2% towards KA oil and acceptable conversion of 4.41%,
which was very comparable to the level of cyclohexane conversion in industry. Although the conversion in other catalytic
systems was higher than ours, the higher conversion consumed the selectivity, resulting in lower selectivity of
34.2%~91.0% towards KA oil. The lower selectivity will not only bring enormous difficulty to the separation process in
industry, but also increase the amount of chemical waste discharged to the environment, which is incompatible with the
urgent requirements of green chemistry. Therefore, taking the requirements of chemical process and green chemistry into
account, our reported procedure is a very promising and competitive choice to enhance the oxidation of cycloalkane through
efficient utilization of oxidation intermediates cycloalkyl hydroperoxides as additional oxidants under the catalysis of dual-
metalloporphyrins system. At last, the endeavor to simultaneously boost the selectivity and conversion in cycloalkanes
oxidation further is still being conducted in our group.
<Table 5>
In summary, a practical and efficient strategy to simultaneously increase the efficiency and selectivity in cycloalkanes
oxidation with metalloporphyrins as catalysts was provided in this research, in which the oxidation intermediates cycloalkyl
hydroperoxides were employed as additional oxidants to oxidize cycloalkanes further under the catalysis of T(4-Cl)PPCu.
Both of the conversion and selectivity were boosted, especially for cyclohexane, and in the catalytic oxidation of
cyclohexane, the selectivity was enhanced from 88.6% to 97.2% for the KA oil, at the same time the conversion was
enhanced from 3.88% to 4.41%. The enhanced efficiency and selectivity were mainly ascribed to the suppressed
autoxidation of cycloalkanes and the efficient utilization of oxidation intermediates cycloalkyl hydroperoxides as additional
oxidants. To the best of our knowledge, the protocol demonstrated in this research is a very rare and significant example in
catalytic oxidation of C-H bond in various alkanes through efficient utilization of their intermediate products as additional
oxidants to promote the conversion and selectivity, and will serve as an important reference not only for industrial oxidation
of alkanes, but also for the efficient construction of other catalytic oxidation systems employing metalloporphyrins. And
this work also is a very important reference for the extensive application of metalloporphyrins in catalysis chemistry.
Acknowledgements
This work was supported by the National Natural Science Foundation of China (Grant No. 21878275, 21776259,
21476270, 21306176).
Supporting information

Accepted manuscript to appear in JPP
A full list of experimental procedure, supplementary experimental data and characterization spectra are given in the
supplementary material. This material is available at http://www.u-bourgogne.fr/jpp/.
REFERENCES
1. Tateno H, Iguchi S, Miseki Y and Sayama K. Angew. Chem. Int. Edit. 2018; 57: 11238-11241.
2. Guan J, Wriglesworth A, Sun XZ, Brothers EN, Zaric SD, Evans ME, Jones WD, Towrie M, Hall MB and George
MW. J. Am. Chem. Soc. 2018; 140: 1842-1854.
3. Kal S, Draksharapu A and Que L. J. Am. Chem. Soc. 2018; 140: 5798-5804.
4. Unnarkat AP, Sridhar T, Wang HT, Mahajani S and Suresh AK. AIChE J. 2016; 62: 4384-4402.
5. Wang LY, Zhang YB, Du RF, Yuan HR, Wang YT, Yao J and Li HR. ChemCatChem 2019; 11: 2260-2264.
6. Jian J, You KY, Duan XZ, Gao HX, Luo Q, Deng RJ, Liu PL, Ai QH and Luo HA. Chem. Commun. 2016; 52: 3320-
3323.
7. Yang DX, Wu TB, Chen CJ, Guo WW, Liu HZ and Han BX. Green Chem. 2017; 19: 311-318.
8. Alshehri AA, Alhanash AM, Eissa M and Hamdy MS. Appl. Catal. A-Gen. 2018; 554: 71-79.
9. Liu LC, Arenal R, Meira DM and Corma A. Chem. Commun. 2019; 55: 1607-1610.
10. Laudadio G, Govaerts S, Wang Y, Ravelli D, Koolman HF, Fagnoni M, Djuric SW and Noel T. Angew. Chem. Int.
Edit. 2018; 57: 4078-4082.
11. Li LY, Yang QH, Chen S, Hou XD, Liu B, Lu JL and Jiang HL. Chem. Commun. 2017; 53: 10026-10029.
12. Wan YL, Guo Q, Wang K and Wang XT. Chem. Eng. Sci. 2019; 203: 163-172.
13. Pamin K, Tabor E, Gorecka S, Kubiak WW, Rutkowska-Zbik D and Poltowicz J. ChemSusChem 2019; 12: 684-691.
14. Alshaheri AA, Tahir MIM, Rahman MBA, Ravoof TBSA and Saleh TA. Chem. Eng. J. 2017; 327: 423-430.
15. Wei QH, Fan HL, Qin FF, Ma QX and Shen WZ. Carbon 2018; 133: 6-13.
16. Ribeiro APC, Martins LMDRS, Carabineiro SAC, Buijnsters JG, Figueiredo JL and Pombeiro AJL. ChemCatChem
2018; 10: 1821-1828.
17. Mncube SG and Bala MD. Polyhedron 2019; 157: 467-473.
18. Balamurugan M, Suresh E and Palaniandavar M. Dalton T. 2016; 45: 11422-11436.
19. Sankaralingam M, Vadivelu P and Palaniandavar M. Dalton T. 2017; 46: 7181-7193.
20. Pinto VHA, Reboucas JS, Ucoski GM, de Faria EH, Ferreira BF, Gil RASS and Nakagaki S. Appl. Catal. A-Gen. 2016;
526: 9-20.
21. Ucoski GM, Pinto VHA, DeFreitas-Silva G, Reboucas JS, Mazzaro I, Nunes FS and Nakagaki S. ChemistrySelect
2017; 2: 3703-3715.
22. Ucoski GM, Pinto VHA, DeFreitas-Silva G, Reboucas JS, da Silva RM, Mazzaro I, Nunes FS and Nakagaki S.
Micropor. Mesopor. Mat. 2018; 265: 84-97.
23. Antonangelo AR, Bezzu CG, McKeown NB and Nakagaki S. J. Catal. 2019; 369: 133-142.
24. da Silva VS, Vieira WCD, Meireles AM, Ucoski GM, Nakagaki S, Idemori YM and DeFreitas-Silva G. New J. Chem.
2017; 41: 997-1006.
25. da Silva VS, Idemori YM and DeFreitas-Silva G. Appl. Catal. A-Gen. 2015; 498: 54-62.
26. Shul'pin GB, Koziov YN, Shul'pina LS and Pombeiro AJL. Tetrahedron 2012; 68: 8589-8599.

Accepted manuscript to appear in JPP
27. Liu X, Conte M, He Q, Knight DW, Murphy DM, Taylor SH, Whiston K, Kiely CJ and Hutchings GJ. Chem. Eur. J.
2017; 23: 11834 –11842.
28. Carabineiro SAC, Martins LMDRS, Pombeiro AJL, Figueiredo JL. ChemCatChem 2018; 10: 1804-1813.
29. Lopez-Ausens T, Boronat M, Concepcion P, Chouzier S, Mastroianni S and Corma A. J. Catal. 2016; 344: 334-345.
30. Zaltariov MF, Vieru V, Zalibera M, Cazacu M, Martins NMR, Martins LMDRS, Rapta P, Novitchi G, Shova S,
Pombeiro AJL and Arion VB. Eur. J. Inorg. Chem. 2017; 4324-4332.
31. Zheng X, Ma JP, Wang M, Shi S, Sun ZQ and Xu J. Catal. Commun. 2017; 101: 77-80.
32. Chen LF, Zhou YY, Gui ZY, Cheng HY and Qi ZW. J. Mater. Sci. 2017; 52: 7186-7198.
33. Wu PP, Cao YX, Wang Y, Xing W, Zhong ZY, Bai P and Yan ZF. Appl. Surf. Sci. 2018; 457: 580-590.
34. Zhao XX, Zhang Y, Qiu P, Wen P, Wang H, Xu G and Han Y. J. Mater. Sci. 2018; 53: 6552-6561.
35. Unnarkat AP, Sridhar T, Wang HT, Mahajani SM and Suresh AK. Catal. Today 2018; 310: 116-129.
36. Huang G, Wang WL, Ning XX, Liu Y, Zhao SK, Guo YA, Wei SJ and Zhou H. Ind. Eng. Chem. Res. 2016; 55: 2959-
2969.
37. Huang G, Liu Y, Cai JL, Chen XF, Zhao SK, Guo YA, Wei SJ and Li X. Appl. Surf. Sci. 2017; 402: 436-443.
38. Duan XG, Liu WM, Yue LM, Fu W, Ha MN, Li J and Lu GZ. Dalton T. 2015; 44: 17381-17388.
39. Hoschek A, Heuschkel I, Schmid A, Buhler B, Karande R and Buhler K. Bioresour. Technol. 2019; 282: 171-178.
40. Xiang LP, Fan JJ, Zhong WZ, Mao LQ, You KY and Yin DL. Appl. Catal. A-Gen. 2019; 575: 120-131.
41. Li YJ, Liu CR and Yang WJ. New J. Chem. 2017; 41: 8214-8221.
42. Jiang YX, Su TM, Qin ZZ and Huang G. RSC Adv. 2015; 5: 24788-24794.
43. Huang G, Mo LQ, Cai JL, Cao X, Peng Y, Guo YA and Wei SJ. Appl. Catal. B-Environ. 2015; 162: 364-371.
44. Xie YJ, Zhang FY, Liu PL, Hao F and Luo H. Ind. Eng. Chem. Res. 2015; 54: 2425-2430.
45. Li H, She Y and Wang T. Front. Chem. Sci. Eng. 2012; 6: 356-368.
46. Cao MJ, She YB, Fu HY, Yu YM, Li H and Wang T. Mol. Simulat. 2015; 41: 262-270.
47. Li H, She YB, Fu HY, Cao MJ, Wang J and Wang T. Can. J. Chem. 2015; 93: 696-701.
48. Wang T, She YB, Fu HY and Li H. Catal. Today 2016; 264: 185-190.
49. Shen HM, Wang Y, Deng JH, Zhang L and She YB. Chin. J. Chem. Eng. 2018; 26: 1064-1070.
50. She YB, Deng JH, Zhang L and Shen HM. Prog. Chem. 2018; 30: 124-136.
51. Khare S and Shrivastava P. J. Mol. Catal. A-Chem. 2016; 411: 279-289.
52. Saha M, Vyas KM, Martins LMDRS, Martins NMR, Pombeiro AJL, Mobin SM, Bhattacherjee D, Bhabak KP and
Mukhopadhyay S. Polyhedron 2017; 132: 53-63.
53. Kirillova MV, Santos CIM, Wu WY, Tang Y and Kirillov AM. J. Mol. Catal. A-Chem. 2017; 426: 343-349.
54. Jlassi R, Ribeiro APC, Alegria ECBA, Naili H, Tiago GAO, Ruffer T, Lang H, Zubkov FI, Pombeiro AL and Rekik W.
Inorg. Chim. Acta 2018; 471: 658-663.
55. Fukuzumi S, Tanii K and Tanaka T. J. Chem. Soc., Perkin Trans. 2 1989; 2035-2039.
56. Fukuzumi S, Lee YM, Jung J and Nam W. Green Chem. 2018; 20: 948-963.
57. Castro KADF, de Lima FHC, Simoes MMQ, Neves MGPMS, Paz FAA, Mendes RF, Nakagaki S and Cavaleiro JAS.
Inorg. Chim. Acta 2017; 455: 575-583.
58. Antonangelo AR, Bezzu CG, Mughal SS, Malewschik T, McKeown NB and Nakagaki S. Catal. Commun. 2017; 99:
100-104.

Accepted manuscript to appear in JPP
59. Wang Z, Wu Y, Wu C, Xie J, Gu X, Yu P, Zong M, Gates ID, Liu H and Rong J. Catal. Sci. Technol. 2020; 10: 332-
336.
60. Ye JH, Tang JJ, Zhao YJ and Wu CD. Inorg. Chem. 2020; 59: 767-776.
61. Lisicki D and Orlinska B. Chem. Pap. 2020; 74: 711-716.
62. Guo Y, Ying T, Liu XH, Shi BF and Wang YQ. Mol. Catal. 2019; 479: 170-175.
63. Sun W, Gao LF, Feng X, Sun X and Zheng GX. Eur. J. Org. Chem. 2018; 1121-1129.
64. Zhang P, Wang J, Jia Y, Li WQ, Tan XL, Zhang D, Xu SN, Zhang PP, Wei CD and Miao SD. Appl. Clay Sci. 2019;
181: 105226.
65. Hong Y, Fang YXO, Zhou XT, Du G, Mai JJ, Sun DL and Shao ZP. Ind. Eng. Chem. Res. 2019; 58: 19832-19838.
66. Liu P, You KY, Deng RJ, Chen ZP, Jian J, Zhao FF, Liu PL, Ai QH and Luo H. Mol. Catal. 2019; 466: 130-137.
67. Wang S, Sun ZX, Zou XY, Zhang ZJ, Fu GY, Li L, Zhang X and Luo F. New J. Chem. 2019; 43: 14527-14535.
68. Mo LQ, Huang XF, Huang G, Yuan GP and Wei SJ. ChemistryOpen 2019; 8: 104-113.
69. Huang G, Wang P, Shen L, Wei YX, Zeng K and Wei SJ. Mater. Sci. Eng., C 2015; 49: 844-850.
70. Feng Z, Xie YJ, Hao F, Liu PL and Luo H. J. Mol. Catal. A-Chem. 2015; 410: 221-225.
71. Shen HM, Zhang L, Deng JH, Sun J and She YB. Catal. Commun. 2019; 132: 105809.

Accepted manuscript to appear in JPP
Equation 1:

Accepted manuscript to appear in JPP
a
Table 1. Oxidation of cyclohexane using metalloporphyrins as catalysts with O2 .
Selectivity, %
Entry
1
Catalysts
Conversion, %
N. D.
Alcohol
N. D.
Ketone
N. D.
Hydroperoxide
Total
N. D.
N. D.b
∕
2
3
4
5
T(2-Cl)PPCo
T(3-Cl)PPCo
T(4-Cl)PPCo
T(4-Cl)PPCu
T(2-Cl)PPCo
T(4-Cl)PPCu
T(3-Cl)PPCo
T(4-Cl)PPCu
T(4-Cl)PPCo
T(4-Cl)PPCu
3.88
3.72
3.43
N. D.
39.9
45.2
42.3
N. D.
44.3
41.1
43.4
N. D.
4.4
4.0
88.6
90.3
90.7
N. D.
5.0
N. D.
6c
4.41
3.74
3.52
46.6
50.9
46.5
43.0
41.2
44.6
7.6
6.1
3.6
97.2
98.2
94.7
7
8
a
Reaction conditions: cyclohexane (200 mmol, 16.83 g), metalloporphyrin (1.2 × 10-3%, mol/mol),
1.40 MPa, 120 ºC , 8.0 h.
b
c
No obvious reaction.
The molar proportion of two metalloporphyrins, 1:1.

Accepted manuscript to appear in JPP
Table 2. Effect of proportion between two metalloporphyrinsa.
Selectivity, %
Entry Molar proportionb
Conversion, %
Alcohol
46.6
Ketone
Hydroperoxide
Total
97.2
97.0
97.2
99.6
98.8
1
2
3
4
5
1.0 : 1.0
1.0 : 1.5
1.0 : 2.0
1.0 : 2.5
1.0 : 3.0
4.41
4.21
3.52
3.70
3.18
43.0
54.4
50.9
50.0
49.7
7.6
7.5
7.3
9.2
6.0
35.1
39.0
40.4
43.1
a
Reaction conditions: cyclohexane (200 mmol, 16.83 g), T(4-Cl)PPCu as shown in table,
T(2-Cl)PPCo (6.0 × 10-4%, mol/mol), O2 (1.40 MPa), 120 ºC , 8.0 h.
Molar proportion of T(2-Cl)PPCo to T(4-Cl)PPCu.
b

Accepted manuscript to appear in JPP
Table 3. Oxidation of cyclohexane by tert-butyl hydroperoxidea.
Yield, %
Entry Metalloporphyrins
Cyclohexanol
N. D.
Cyclohexanone
1
2
3
/
0.08
1.16
0.48
T(4-Cl)PPCu
T(2-Cl)PPCo
T(2-Cl)PPCo
T(4-Cl)PPCu
1.65
1.25
4
2.81
2.03
a
Reaction conditions: cyclohexane (20 mmol, 16.83 g), 5 mol/L t-BuOOH
in decane (4.0 mmol, 0.80 mL), metalloporphyrin (1.2 × 10-2%, mol/mol),
60 ºC , 4.0 h.

Accepted manuscript to appear in JPP
Table 4. Catalytic oxidation of cycloalkanes with O2 in the presence of T(2-Cl)PPCo
and T(4-Cl)PPCua.
Selectivity, %
Entry Cycloalkanes Conversion, %
Alcohol Ketone Hydroperoxide Total
1b
2b
2.29
4.41
11.8
46.6
32.7
43.0
3.1
7.6
47.6
97.2
3c
5.17
7.7
25.7
46.0
65.6
51.9
99.0
97.9
4c
23.99
N. D.
a Reaction conditions: cycloalkane (200 mmol), 1.40 MPa, 8.0 h.
b T(2-Cl)PPCo (6.0 × 10-4%, mol/mol), T(4-Cl)PPCu (6.0 × 10-4%, mol/mol), 120 ºC.
c T(2-Cl)PPCo (6.0 × 10-4%, mol/mol), T(4-Cl)PPCu (6.0 × 10-4%, mol/mol), 110 ºC.

Accepted manuscript to appear in JPP
Table 5. Comparison with some reported systems in cyclohexane oxidation employing O2 as oxidant.
Entry
1
Conditions
Conversion, %
8.57
Selectivitya, %
76.2
References
[59]
Annealed carbon nanotubes, 130
ºC, 1.50 MPa, Acetone
Porous cobalt silica materials,
120 ºC, 1.00 MPa, Acetonitrile
2
3
14.3
10.2
94.2
94.1
[60]
[61]
NHPI/Co(II)/Fe(II), 150 ºC, O2
0.50 MPa, scCO2 9.50 MPa
Partially graphitic carbon, 125
ºC, 1.50 MPa, Cyclohexanone,
Acetonitrile
4
5
6
7
54.8
34.5
17.2
9.7
44.4
89.2
95.3
92.2
[62]
[63]
[64]
[65]
Copper nanoparticles on N-
doped Grapheme, 115 ºC, 0.40
MPa, NHPI, Acetone
Co-based spinel nanocrystals in
Laponite cages, 150 ºC, 2.00
MPa
Ionic liquid-modified cobalt-
containing ZSM-5 zeolites, 150
ºC, 1.50 MPa air
Hydrotalcite-derived Co-
MgAlO, 150 ºC, 0.60 MPa
8
9
9.1
82.0
99.0
[66]
[67]
V16 based MOF, 150 ºC, 1.00
MPa
24.6
Cobalt molybdenum oxide
supported on mesoporous
silica,150 ºC, 1.00 MPa
10
8.3
85.5
[35]
11
12
13
TPFPPCo, 165 ºC, 0.80 MPa
25.7
38.5
14.6
72.0
62.8
73.5
[68]
[68]
[69]
TPFPPCo on nanoporous
chitosan, 165 ºC, 0.80 MPa
T(4-COOH)PPMnCl, 155 ºC,

Accepted manuscript to appear in JPP
0.90 MPa
T(4-COOH)PPMnCl
14
15
16
immobilized onto porous
chitosan, 155 ºC, 0.90 MPa
14.7
16.5
17.3
76.9
75.8
75.3
[69]
[69]
[69]
T(4-COOH)PPFeCl, 155 ºC,
0.80 MPa
T(4-COOH)PPFeCl immobilized
onto porous chitosan, 155 ºC,
0.80 MPa
T(4-NO2)PPMn, 150 ºC, 1.00
MPa
17
18
9.76
7.98
74.7
91.0
[70]
[70]
T(4-NO2)PPMn immobilized
onto ZnO, 150 ºC, 1.00 MPa
T(4-COOH)PPFeCl immobilized
onto ZnS, 160 ºC, 0.80 MPa
19
20
21
64.9
23.4
39.8
37.6
64.0
56.5
[42]
[43]
[43]
TPFPPFeCl, 150 ºC, 0.70 MPa
TPFPPFeCl immobilized onto
ZnO, 150 ºC, 0.70 MPa
D(4-Cl)PPCoCl immobilized
onto ZnO, 155 ºC, 1.00 MPa
22
23
24
25
26
27
28
6.23
21.9
46.1
38.9
67.8
12.5
29.9
89.4
62.1
46.1
51.7
34.2
84.8
72.3
[44]
[36]
[36]
[36]
[36]
[41]
[41]
T(4-COOH)PPMn, 160 ºC, 0.80
MPa
T(4-COOH)PPMn immobilized
onto ZnS, 160 ºC, 0.80 MPa
T(4-COOH)PPCo, 165 ºC, 0.90
MPa
T(4-COOH)PPCo immobilized
onto ZnS, 165 ºC, 0.90 MPa
Porous organic framework T(4-
Br)PPMnCl, 135 ºC, 0.80 MPa
Porous organic framework T(4-
Br)PPMnCl, 150 ºC, 0.80 MPa

Accepted manuscript to appear in JPP
Porous organic framework T(4-
Br)PPFeCl, 150 ºC, 0.80 MPa
29
30
31
32
27.5
29.2
51.4
4.18
69.8
32.5
55.8
96.4
[41]
[37]
[37]
[71]
T(4-SO3H)PPFeCl, 155 ºC, 0.80
MPa
T(4-SO3H)PPFeCl immobilized
onto chitosan, 155 ºC, 0.80 MPa
T(4-Cl)PPCo & T(4-Cl)PPZn,
120 ºC, 1.40 MPa
33
34
T(3-Cl)PPCo, 120 ºC, 1.40 MPa
T(2-Cl)PPCo, 120 ºC, 1.40 MPa
3.72
3.88
90.3
88.6
This work
This work
T(2-Cl)PPCo & T(4-Cl)PPCu,
120 ºC, 1.40 MPa
35
4.41
97.2
This work
a
Selectivity towards the KA oil.

Accepted manuscript to appear in JPP
Catalytic oxidation of cycloalkanes by porphyrin cobalt(II) through efficient utilization of
oxidation intermediates
Hai M. Shen, Xiong Wang, A B. Guo, Long Zhang and Yuan B. She*
College of Chemical Engineering, Zhejiang University of Technology, Hangzhou 310014, China
The oxidative functionalization of cycloalkanes using O2 catalyzed by porphyrin cobalt (II) was enhanced through employing
oxidation intermediates cycloalkyl hydroperoxides as additional oxidants to further oxidize cycloalkanes in the presence of porphyrin
copper (II), especially for cyclohexane with the selectivity of 97.2% towards KA oil in the conversion of 4.41%.
*Correspondence to: Yuan B. She. E-mail address: haimshen@zjut.edu.cn. Fax: (+86)571-8832-0533. Tel. : (+86)571-8832-0533.
