Oligoether substituted bis-NHC palladium and platinum complexes
for aqueous SuzukieMiyaura coupling and hydrosilylation
Dominik Munz, Christoph Allolio, Dirk Meyer 1, Maik Micksch, Leonard Roessner,
Thomas Strassner*
€
Physikalische Organische Chemie, Technische Universitat Dresden, Bergstrasse 66, 01062 Dresden, Germany
a r t i c l e i n f o
a b s t r a c t
Article history:
The synthesis of four oligo ethylene glycol substituted, bis-NHC palladium(II) and platinum(II) com-
plexes is reported. Two of them were characterized by solid state structures. All complexes show
excellent solubility in a variety of organic solvents and water. The palladium complexes were tested in
the SuzukieMiyaura coupling reaction and the platinum complexes in the hydrosilylation reaction of
alkynes in aqueous solvent mixtures. All show a high catalytic activity at ppm level catalyst-loading
under very mild reaction conditions.
Received 10 December 2014
Received in revised form
17 March 2015
Accepted 27 March 2015
Available online xxx
© 2015 Elsevier B.V. All rights reserved.
Keywords:
Palladium
Platinum
NHC
SuzukieMiyaura coupling
Hydrosilylation
Water
ꢀ
ꢀ
Introduction
anions like BF4 or PF6 using the corresponding silver salts [24].
We found that the result was strongly dependent on the coun-
terion. Especially the anion metathesis with AgOAc lead to an
interesting result, since not the desired mononuclear complex, but
instead a trinuclear PdeAgePd carbene acetato complex was iso-
lated [29]. Furthermore, many organometallic reactions like also
the Heck reaction with chelating bis-NHC ligands either produce or
require nucleophilic ions [30]. In order to achieve high solubility
even in the presence of these coordinating counterions, a different
strategy is needed.
PEGylation is a widely used technique in pharmaceutical
chemistry [31,32] and well known for not only improving the solu-
bility, but also changing the physicochemical properties of transi-
tion metal complexes [33e36]. Therefore, we decided to synthesize
oligoether substituted bis-NHC complexes, which we expected to
show a significantly enhanced solubility in both organic solvents
and water.
The SuzukieMiyaura coupling is a very important reaction in
the field of organic synthesis [37,38] and due to safety issues,
environmental aspects, and increasing regulatory pressure, the
development of modern reaction protocols under aqueous condi-
tions has become more and more important in recent years
[39e41]. Therefore, the synthesis and application of water soluble
transition metal NHC complexes is currently of interest [42e46].
N-Heterocyclic carbene (NHC) ligands are ubiquitous in organo-
metallic chemistry [1e3] and have found widespread application in
cross coupling chemistry [4e8]. Chelated palladium and platinum
bis-NHC complexes show exceptional high chemical stability,
favorable electronic and steric properties, and have been shown to
be very efficient catalysts for a variety of organic transformations
[9e11]. They also showed very high catalytic activity in the Heck
reaction [12e14] and the SuzukieMiyaura coupling [15e17]. We
found that bis-NHC platinum complexes are very efficient catalysts
for the hydrosilylation of olefins [18,19], which is of extraordinary
importance for the silicon industry [20e23]. Unfortunately,
chelated palladium- and platinum-bis-NHC catalysts typically
show very limited solubility in solvents like dichloromethane,
tetrahydrofuran or water, which seriously complicates their use in
homogeneous catalysis and also hinders mechanistic organome-
tallic investigations [24e28]. To increase the solubility in organic
solvents, we exchanged the halide anions for non-coordinating
* Corresponding author.
E-mail address: thomas.strassner@chemie.tu-dresden.de (Th. Strassner).
X-ray analysis.
1
http://dx.doi.org/10.1016/j.jorganchem.2015.03.027
0022-328X/© 2015 Elsevier B.V. All rights reserved.
Please cite this article in press as: D. Munz, et al., Journal of Organometallic Chemistry (2015), http://dx.doi.org/10.1016/
j.jorganchem.2015.03.027

2
D. Munz et al. / Journal of Organometallic Chemistry xxx (2015) 1e6
Strategies to improve the activity of CeC coupling reactions in an
aqueous environment typically rely either on additives like phase
transfer agents [47,48], solid supported catalysts [48,49], or the
attachment of polar groups [50,51] to the ligand.
Reports on the hydrosilylation of olefins and alkynes in protic
solvents [52e55] or ionic liquids [19,56] and especially under
platinum catalysis [57e59] are, however, extremely rare.
Accordingly, we investigated the oligoether substituted palla-
dium complexes as catalysts in the SuzukieMiyaura coupling and
the corresponding platinum complexes in the hydrosilylation re-
action in aqueous solution.
Results and discussion
Synthesis
Fig. 1. Solid state structure of palladium bis-NHC complex 5. Second molecule of 5 and
hydrogen atoms are omitted for clarity. Ellipsoids are drawn at the 50% probability
level. Selected bond lengths (Å) and angles (ꢁ) for molecule A: Pd1AeBr1A 2.4975(7),
Pd1AeBr2A 2.4919(7), Pd1AeC2A 1.984(5), Pd1AeC5A 1.974(5), C2AePd1AeC5A
85.1(2), Br1AePd1AeBr2A 89.85(2). Selected bond lengths (Å) and angles (ꢁ) for
molecule B: Pd1BeBr1B 2.4902(7), Pd1BeBr2B 2.4933(7), Pd1BeC2B 1.983(5),
Pd1BeC5B 1.986(5), C2AePd1BeC5B 83.4(2), Br1BePd1BeBr2B 89.50(2).
The bisimidazolium salts were prepared in tetrahydrofuran (3)
and acetonitrile (4) by alkylation of the corresponding bisimida-
zoles 1 and 2 with 2-[2-(2-methoxyethoxy)ethoxy]ethylbromide in
93% (3) and 68% (4) yield (Scheme 1).
Scheme 1. Synthesis of the bisimidazolium salts.
Subsequently, the platinum and palladium complexes 5e8
could be synthesized from the bisimidazoliums salts with palla-
dium acetate (5, 6) or platinum acetylacetonate (7, 8) in DMSO
(Scheme 2).
Fig. 2. Solid state structure of platinum bis-NHC complex 7. Second molecule of 7 and
hydrogen atoms are omitted for clarity. Ellipsoids are drawn at the 50% probability
level. Selected bond lengths (Å) and angles (ꢁ) for molecule A: Pt1AeBr1A 2.4939(7),
Pt1AeBr2A 2.4966(7), Pt1AeC2A 1.970(5), Pt1AeC5A 1.974(5), C2AePt1AeC5A
85.6(2), Br1AePt1AeBr2A 88.63(2). Selected bond lengths (Å) and angles (ꢁ) for
molecule B: Pt1BeBr1B 2.4902(7), Pt1BeBr2B 2.4933(7), Pt1BeC2B 1.983(5),
Pt1BeC5B 1.986(5), C2AePt1BeC5B 83.4(2), Br1BePt1BeBr2B 89.50(2).
1.984(5) Å, 1.974(5) Å))ꢁ; molecule B: 1.983(5) Å, 1.986(5) Å) and the
Ptecarbene (molecule A: 1.970(5) Å, 1.974(5) Å)ꢁ; molecule B:
1.961(5) Å,1.967(5) Å) bond lengths seem to be slightly elongated in
comparison to the complexes with methyl substituents (CePd:
1.983(5) Å, 1.971(5) Å, CePt: 1.963(10) Å, 1.950(10) Å) [60,61].
Scheme 2. Synthesis of the palladium- and platinum-bis-NHC-complexes.
SuzukieMiyaura coupling
All four complexes are well soluble in a large variety of organic
solvents like tetrahydrofuran, dichloromethane, acetone, aceto-
nitrile or ethanol and show moderate solubility in toluene and
water. Single crystals of 5 and 7 were obtained by slow diffusion of
diethyl ether into a concentrated solution of the complexes in
methanol. The solid state structures of both complexes are iso-
structural (Figs. 1 and 2) and both asymmetric units contain two
independent metal complexes.
The palladium complexes 5 and 6 were tested as catalysts in the
Suzuki coupling of phenylboronic acid with 4-bromo toluene,
which is considered a challenging reactant in water due to its
hydrophobicity. We decided to test the catalysts first in a 1:1
mixture of methanol and water with K2CO3 as base, which had been
determined to be more or at least equally effective as Cs2CO3, KOH,
or K3PO4.
In both solid state structures, the oligo ethylene glycol chains are
coiled up and situated below the plane of the bis-NHC moiety. The
CePdeC (molecule A: 85.1(2)ꢁ; molecule B: 83.4(2)ꢁ) and CePteC
(molecule A: 85.6(2)ꢁ; molecule B: 84.4(2)ꢁ) bite angles of the li-
gands are considerably larger than these of the analogous bis-NHC
complexes with methyl substituents (CePdeC: 83.2(2)ꢁ, CePteC:
83.8(4)ꢁ) [60,61]. Likewise, the Pdecarbene (molecule A:
Initially, we investigated the catalyst loading with complex 5
(Table 1) and found for catalyst loadings up to 0.001 mol-% similar
yields of 80% at a reaction temperature of 100 ꢁC (entries 1e4)
demonstrating the high catalytic activity of our system with turn-
over numbers up to 81,000. Subsequently, we investigated the
reaction temperature with a catalyst loading of 0.1 mol-% and ob-
tained for temperatures of 40e100 ꢁC similar yields of around 80%
Please cite this article in press as: D. Munz, et al., Journal of Organometallic Chemistry (2015), http://dx.doi.org/10.1016/
j.jorganchem.2015.03.027

D. Munz et al. / Journal of Organometallic Chemistry xxx (2015) 1e6
3
Table 1
yield of 81% for 4-bromo anisole (entry 3) and of 61% for N,N-
dimethyl-4-bromo aniline (entry 4).
SuzukieMiyaura coupling in MeOH:H2O solvent mixture.a
The presence of ortho substituents at the aryl bromide did not
lead to a significant decrease of the yield as 1-bromo-2,4-dimethyl
benzene (entry 5) and 1-bromo-2,4,6-trimethyl benzene (entry 6)
could be converted in comparable yields. When the carboxylate
ester (Table 2, entry 7) was used the corresponding biphenyl
carboxylate ester was obtained in a yield of 72% with additional 8%
of the biphenyl carboxylic acid demonstrating that the hydrolysis of
the carboxylate ester occurred only to a small amount under the
reaction conditions.
We did not observe signs of the formation of palladium black at a
