TOPICS IN LIGHTWAVE
Optical Layer Signaling:
How Much Is Really Needed?
Ori Gerstel, Nortel Networks
for management and control of large networks.
ABSTRACT
These approaches, which we call telecom-style and
Internet-style NM&C, were suited to the needs of
the technologies and customers for whom they
were meant: traditional telecom transport services
on one hand and the Internet on the other. Both
the telecom and Internet communities have tried
to extend their NM&C paradigms to the optical
layer. This is a very reasonable approach since
these paradigms were refined over years of experi-
ence, and as a result are much more robust than
some totally new approach. Even more important,
there are huge costs associated with changing the
mode of operation, training the craft personnel,
the operational software, and so on. In this spirit
the American National Standards Institute (ANSI)
and International Telecommunication Union —
Telecommunication Standardization Sector (ITU-
T) have drafted many proposals on functional
models for ONEs and how they should be man-
aged, based on the synchronous optical
network/synchronous digital hierarchy (SONET/
SDH) approach; see [1] for a survey on the topic.
At the same time, the Internet Engineering Task
Force (IETF) has proposed how to extend multi-
protocol label switching (MPLS) and related pro-
tocols to encompass the optical layer as another
type of MPLS switch [2]. Variants of this approach
have been adopted by the different optical layer
standardization bodies (including OIF and ODSI)
and are discussed in other articles in this issue.
This article challenges the emerging industry
trend of adopting Internet-style distributed net-
work-control with its full complexity for the optical
transport network. Instead, we argue that an
extensive telecom-style network management
interface augmented with a minimal control plane
and a service layer interface between management
systems is more appropriate for the real needs of
the optical layer. This approach will allow more
flexibility in extending the interoperability between
vendors and carriers as our understanding of these
networks grows, increase the reliability of the net-
work, and be a better fit for the telecom service
provider. On the other hand, the simplicity of use
and automation the Internet control plane promis-
es can just as easily be achieved with our proposal.
INTRODUCTION
Optical networking technology has become one
of the main promises for core transport network
architectures. As the technology matures, from
the simple point-to-point line systems of five
years ago to full-function optical cross-connects
a year from now, the optical network elements
(ONEs) support more and more functionality
and the need for sophisticated network manage-
ment and control (NM&C) grows.
Two main trends have evolved over the years
Definitions used in this article
Carrier
The company operating the network (sometimes called service provider or network
operator). This could be either a telco or an ISP
Control
The real time logic that is responsible for the operation of the NE, e.g., handling the
signaling protocols
Control plane
The combined control operation across different NEs
Network design The task of determining the nodes, the configuration per node, and the routes of light-
paths in the network. The latter part is sometimes referred to as "traffic engineering."
Network
management
The slower transactions between the NEs and the management systems (as opposed
to the fast control). The term "management" will be used as shorthand
Operator
The person in charge of the operation of the network through EMS and NMS GUIs.
Typically stationed at a NOC (Network Operations Center).
This article was written
before the author had
joined Xros and does not
necessarily represent the
opinion of his current or
previous employers.
Signaling
Telecom
Vendor
A fast distributed protocol between network elements. Part of the control plane
We restrict the discussion to high-speed telecom transport equipment.
The maker of the equipment
IEEE Communications Magazine • October 2000
154
0163-6804/00/$10.00 © 2000 IEEE

TL1/CORBA
TL1/Q3/SNMP
Manual intervention
Network view
The Internet had
a very different
goal: supporting
an open
Human
operators
NE1
NE2
NE4
NE3
NMS
NE1
environment with
infinite flexibility
to foster new
applications while
keeping the
EMS
View of entire network
Signaling interface
NE2
NE3
EMS
ꢀ Figure 2. Internet-style network management
and control.
NE4
network layer as
simple and
ꢀ Figure 1. Telecom-style network management
automatic as
the network layer as simple and automatic as pos-
sible. While succeeding phenomenally on this
front, the Internet neglected the other values,
which where central to telecom networks.
These differences imply very different
emphases on the role of NM&C subsystems.
Telecom NM&C is typically much more central-
ized in nature than in IP networks to allow very
tight human control of resources and good trou-
bleshooting tools, as one would expect in sup-
port of the reliability and optimality require-
ments above. To this end they require a large
number of operators at different levels.
Internet nodes emphasize distributed control,
and are skinnier on their management support.
They are also more automated and do not rely
on human assistance for the most part, at the
expense of resource overprovisioning.
In the next subsections we shall explore these
issues in more detail.
possible. While
succeeding
The dominance of the Internet and its associat-
ed protocols as a client layer on top of the optical
layer on one hand, and the failure of telecom
equipment to interoperate across vendor bound-
aries with the same ease of Internet gear, have
caused a new trend as well. The “bell heads” have
started to abandon the “traditional” telecom way
of managing networks through a hierarchy of man-
agement systems. Instead, they seem inclined
toward a more automated Internet-style approach
where the relatively dumb control plane is replaced
by much smarter distributed control [3]. This trend,
and the affection of the marketing and financial
communities for everything related to the Internet,
have pushed equipment vendors to follow suit.
This article takes a different view. After
explaining the difference between these two basic
approaches to NM&C, we claim that this new
technology and evolving customer needs deem
both approaches inadequate for the future optical
network. We then propose how to augment tele-
com-style NM&C with some of the Internet-style
features it lacks to achieve a combined approach
that provides the best fit for this layer. The
approach we advocate herein is not new, but it
seems to be somehow missing from most discus-
sions on optical layer interoperability standardiza-
tion, which is the main motivation of this article.
phenomenally on
this front, the
Internet neglected
the other values,
which where
central to
telecom networks.
TELECOM-STYLE MANAGEMENT AND CONTROL
In typical telecom networks, the network ele-
ments (NEs) are not very aware of the network
topology as a whole and are more focused on
their own operation. Well-defined network man-
agement interfaces connect the NEs to a whole
hierarchy of management systems, as defined by
numerous ITU-T and Bellcore (now Telcordia)
documents. These interfaces are based on the
legacy TL-1 text language, more modern Com-
mon Management Information Protocol (CMIP)
or Simple Network Management Protocol
(SNMP), and more recently, Common Object
Request Broker Architecture (CORBA). The
lowest level of such managers is concerned with
individual NEs; these are the element manage-
ment systems (EMSs). These systems still do not
have a view of the entire network and are con-
nected to managers that manage subnetworks of
elements of a similar type (subnetwork con-
trollers, SNCs), which in turn are connected to
systems that manage an entire diverse network as
a whole (network management systems, NMSs).
On top of these are systems that manage the vari-
ous services the network provides. This hierarchy
is called the telecommunications management
network (TMN), and is depicted in Fig. 1. Human
operators manage these systems according to the
dictates of planing organizations.
TWO EXISTING APPROACHES TO
MANAGING A NETWORK
Traditionally, the telecom and Internet communi-
ties had very different views on how a network
needs to operate. These differences stem from
the main role of the network in both cases. Tele-
com networks evolved to be a symbol of reliabili-
ty, allowing phone calls to go through even in the
face of power outages and natural disasters; pre-
dictable quality, supporting the same voice quality
regardless of network load; and optimized perfor-
mance, allowing efficient use of network
resources. The drawback of these networks was
their inflexibility: they really only supported voice
calls, and new applications were very hard to sup-
port. The Internet had a very different goal: sup-
porting an open environment with infinite
flexibility to foster new applications while keeping
Insofar as the control plane is concerned, con-
IEEE Communications Magazine • October 2000
155

trary to several recent arguments on the topic (e.g.,
[1]), telecom networks do have a nontrivial control
plane. In fact some of them, such as SONET bidi-
rectional line switched rings (BLSRs), even have
global understanding of their network topology
(arguably, this represents too much of a control
plane and is the reason SONET could never
achieve full interoperability). It is true that telecom
equipment standards try to minimize the extent of
the control plane as much as possible and place as
much functionality as possible in the management
realm. The advantages of this approach will be
articulated as part of the enhanced proposal later.
The latter approach does not require the
NEs to have such topology awareness.
Two of the main
functions of the
Internet control
plane are not
necessary for
optical networks
at this point in
time: topology
awareness at
every NE and
extended
• Fault propagation: The quick discovery of a
failure and its dissemination to the perti-
nent nodes in the network must rely on dis-
tributed signaling, for protection purposes
as well as fault isolation and correlation.
• Automatic protection switching: Clearly, the
signaling to coordinate the protection switch
must be fast and not rely on an MS. The setup
of the protection routes can be preprovisioned
into appropriate tables in the NEs at the time
of connection setup, or computed on the fly
when a failure occurs. The former approach
does not necessitate topology awareness or
fast connection setup since, upon a failure,
each node reconfigures itself based on its pre-
determined tables. The latter approach does
require such signaling; however, we claim that
it is not suitable for the optical layer due to
the lack of control on how the scarce protec-
tion bandwidth is utilized, and other reasons
beyond the scope of this article.
• Traffic engineering: The need to control the
routes of connections arose in MPLS net-
works [2] to in support for different qualities
of service. This need is even stronger in the
optical domain, since bandwidth resources
come in large quanta (i.e., wavelengths) and
the number of these wavelengths is fairly low
per fiber: 100 wavelengths in some commer-
cial systems, unlike the thousands of label-
switched path (LSP) connections in MPLS.
The inability of fully optical systems to
change the wavelength of a connection fur-
ther compounds the picture. As a result,
there is a need to carefully optimize the net-
work through sophisticated network design
tools that require manual intervention.
• Automatic setup of connections: The ability
to set a connection up in a relatively short
timeframe is becoming more and more
important. The bureaucratic and labor-
intensive process that causes weeks of delay
in current networks is clearly becoming
unacceptable. At the same time, going to
the other extreme, of requiring connection
setup in a matter of seconds is hard to justi-
fy either. Relaxing this setup time require-
ment allows this automation to be just as
well supported through a management sys-
tem (MS). The key to shortening the delay
in this case is not the use of the control
plane but automation of the process. This
point is further expanded below.
• Measuring the quality of connections: This
function typically requires an in-band over-
head and thus is part of the control plane.
• Good fault isolation tools: Due to the high
bandwidth carried over the network, such
tools will be needed even more for fast detec-
tion of misrouted connections and fault local-
ization. This requires detailed management
support to allow full visibility into the NE.
• Coarse-grained interoperability: It is theoreti-
cally conceivable to build a network where
each node is of a different make, and they all
interoperate to achieve optimal network func-
tionality. We refer to this as fine-grained inter-
operability. Real-life networks, however, are
INTERNET-STYLE MANAGEMENT AND CONTROL
The Internet paradigm places heavier weight on
the control than the management of the network.
It is based on automatic operation of the net-
work, with much less human intervention. When
a system is put into service it typically starts its
operation with comparatively little manual config-
uration commands (plug and play), discovers its
neighbors and the rest of its domain, and is ready
to ship packets in the general direction of their
destination. This functionality is achieved through
a set of topology discovery and routing protocols,
such as Open Shortest Path First (OSPF), Border
Gateway Protocol (BGP), and IS-IS, which run at
each node and create an awareness of the entire
network topology at each node (Fig. 2). The actu-
al handling of packets is mainly based on connec-
tionless IP forwarding to take the packet and
figure out how it reaches the next hop en route to
its destination. More recently, connection-orient-
ed support has been added in the form of MPLS,
but this has not yet changed the fundamentals of
how such systems are managed.
Network management is still needed for such
networks to allow operators to provision basic
parameters into the systems, intervene in case of
a failure, and analyze performance bottlenecks
and design for the future, but these interfaces
are not as comprehensive and well defined as
their telecom-style counterparts. The main pro-
tocols used for those are Cisco’s command lan-
guage interface (CLI), SNMP, and recently
Web-based HTML/Java management interfaces.
signaling for
automated dis-
tributed setup of
connections.
WHAT FUNCTIONALITY DOES THE
OPTICAL LAYER REQUIRE?
Before delving into a discussion on how each of
these styles fits the optical network, it is benefi-
cial to examine the real needs of this layer in
terms of control and management. In particular,
we shall try to examine if either of the two most
demanding signaling mechanisms is really need-
ed: support for topology awareness at the NEs
and signaling for automatic setup of connections:
• Automatic discovery of the network topolo-
gy: It is important to reflect to the operator
what the network looks like. Note that this
can be done via the control plane, using a
distributed protocol such as OSPF. On the
other hand, the topology could also be
auto-discovered in a central location (the
NMS) as long as each node knows who its
neighbors are (through exchange of hello
messages) and relays this data to the NMS.
IEEE Communications Magazine • October 2000
156

typically made up of more homogeneous
domains of NEs from one vendor, with tighter
coordination inside each domain and sparser
interfaces between these domains.1 This
allows exploiting the proprietary innovations
that distinguish one vendor from another.
One of the main perceived advantages of IP-
style NM&C for the optical layer is its automatic
connection setup support. We note that this
function brings with it many unresolved and
complex issues:
•The need for manually controlled traffic
engineering, as described above, contradicts
fully automated routing of connections and
therefore their automatic setup.
• The need to plan for known (or estimated)
future demands further complicates the
design and makes automation harder.
• One can argue that the need to carefully
optimize the network and the human inter-
vention it may require can be eliminated by
overprovisioning the network. However, the
cost associated with each channel (including
the wavelength-division multiplexing, WDM,
gear and crossconnect ports) may cause this
cost to be prohibitive in the short term.
• At the same time, some level of distributed
control is needed, but we claim it is very
limited in scope and far more limited than
what Internet-style control supports. A pro-
visioning interface between an MS and the
NEs will take care of all the rest while keep-
ing the interface straightforward, since
additional intelligence remains at the MS
level and does not affect the NEs and the
interface to/between them.
• Fully automated distributed setup of lightpaths
is premature. Beyond the aforementioned
technical issues, there are indications that cus-
tomer need for such services may not exist in
the near term since automated connection
setup is not even offered today for much
lower-speed connections (STS-1 and even T1).
• In summary, two of the main functions of
the control plane are not necessary for opti-
cal networks at this point in time:
The appropriate
solution for the
optical layer lies
in a careful mix
of the telecom
and Internet
management and
control styles,
augmented with
service-level
interoperability
through CORBA.
–Topology awareness at every NE (via
OSPF, BGP, etc.)
–Extended signaling for automatic distribut-
ed setup of connections (i.e., using RSVP
or CR-LDP to their full extent).
• Supporting protection at the optical layer
further complicates routing considerations.
Even the simple case of finding diverse
routes of working/protect connections is a
complex algorithmic problem, and support
for shared mesh protection poses additional
significant constraints.
ARE ANY OF THE STYLES A PERFECT
MATCH FOR THE OPTICAL LAYER?
In this section we investigate whether any of the
NM&C styles provides a good match for the
optical layer, and come up with less than satis-
factory results. This provides a motivation for
the section on how to merge these NM&C styles
into an appropriate NM&C layer.
• This issue becomes even more complex if
protection is supported at the client (e.g., IP)
layer instead of relying on the optical layer.
To this end, the optical layer will have to
ascertain that the client layer links supported
by it (which are mapped to optical layer con-
nections) are sufficiently disjoint and do not
all fail together. To some extent, this need
has been addressed in [4] via the concept of
an MPLS shared risk link group. Unfortu-
nately, this concept only supports simple sce-
narios in which different links are pairwise
disjoint. A realistic case that cannot be sup-
ported by this concept is presented in [5].
• Fast automatic setup becomes important if
the current mode for leased lines, connec-
tions that are always up, is replaced by part-
time connections set up on a need basis.
However, to exploit this property for
increased revenues, carriers must be able to
time share the bandwidth among different
customers. While this certainly works for low-
speed telephone connections, it is question-
able that it works for high-speed lightpaths.
• Finally, many other connection characteris-
tics, crucial to understand before standard-
izing an interface, have not been considered
and understood so far. An example of such
parameters can be found in a proposal for
an optical layer differentiated service [6].
WHAT IS BROKEN IN THE TELECOM STYLE?
The TMN hierarchy is ideal in theory for manag-
ing large and diverse networks. In practice, howev-
er, many critical components are missing or flawed:
• Network-level managers are not as ubiqui-
tous as one would expect. Telcordia pro-
vides a substantial set of such managers,
mainly for RBOCs. Most other carriers
have automated their systems via home-
grown tools. These systems include a monu-
mental amount of software, and are old and
cumbersome to use and very costly to
upgrade in support of new applications.
• Interoperability between managers (the so-
called X-interfaces in TMN) has not proven
itself yet. While the ITU has drafted several
Recommendations in this direction
(M.3208.1 through 4), and CORBA can
provide an excellent platform for such inter-
operability at the network or service layer,
this did not yet happen in practice. As a
result, setting up a connection that involves
more than one carrier requires separate
manual intervention for every carrier.
1 Note that we refer to peer
NEs at a given layer of the
network. These NEs may
well be connected through
NEs at a lower layer, but
this connectivity is trans-
parent to them. For exam-
ple, one may have a
domain of same-vendor
OXCs that interoperate
through proprietary
• For many of the new carriers, managers
above the EMS level are often missing,
requiring operators to repeat operations
such as provisioning the same circuit
through multiple EMSes. This is both error-
prone and labor-intensive.
means, carried over a
wavelength-division multi-
plexer layer of a different
make. This is still consid-
ered coarse-grained inter-
operability because the
interfaces between the dif-
ferent layers are minimal.
CONCLUSIONS
From the above discussion we draw the follow-
ing conclusions:
• Extensive management interfaces are need-
ed to allow human intervention for various
purposes. This is the case for both styles.
• Older systems do not even have a modern
point-and-click EMS. Instead they are man-
ually provisioned using the cryptic TL-1 text
IEEE Communications Magazine • October 2000
157

similar to what carriers require from their
vendors as part of acceptance of the equip-
ment into the network.
Internet-style control plane
Basic ON signaling
• Even worse, it is known from measurements
on the Internet that the performance of its
routing algorithms is far from perfect [8].
For example, the chances of a packet
encountering a severe routing pathology
(e.g., a long-lasting forwarding loop) were
3.3 percent at the end of 1995. This behavior
is less of an issue in IP networks due to
TCP-level retransmits, which compensate for
such packet losses. A routing failure will be
far more important for lightpaths since it
will cause permanent creation of the wrong
connection, even creation of a loop.
Router
2
Router
1
ON
domain
ON
domain
(c2)
(a) (c1)
(b)
(c3) (e1) (e2)
(g)
MS
MS
MS
MS
(d)
(f)
Common network/service layer management (CORBA)
ꢀ Figure 3. A combination of telecom- and Internet-style NM&C.
• While such problems can be dealt with when
turning up service (via testing of the con-
nection prior to running live traffic on it),
they represent a crucial problem for protec-
tion signaling, since the protection lightpath
has to work instantly.
• While the consensus seems to be that MPLS
will be adapted for optical networks (see [2]
and other articles in this issue), field experi-
ence with MPLS is not widespread. After
all, this is a very new paradigm for the
Internet community and is only deployed in
a small number of networks. This may be
an indication that it is too early to adopt it
and expect to reap the benefits of its matu-
rity (e.g., stability of the specification).
interface (similar to a UNIX/DOS com-
mand line).
IS THE INTERNET STYLE APPROPRIATE
FOR THE OPTICAL LAYER?
The Internet-style NM&C has evolved from a con-
nectionless best-effort traffic paradigm, and in this
sense is much farther apart from optical networks
than the telecom-style NM&C. However, the main
virtue of this style is that its developer community
and their standards body (IETF) are moving
extremely fast. Thus, they are expected to adapt
better to the changing requirements of a new tech-
nology. Another advantage of this community is
that their track record of interoperability between
complex systems is much better. The Internet-style
NM&C has some technical merits as well:
• The seamless integration of optical layer
lightpaths into MPLS allows for a uniform
control paradigm to span these different
technologies and create a single consolidated
network with lower operational expenses.
OUR PROPOSAL
Since none of the existing approaches provides a
good fit for the optical transport layer, it is natu-
ral to try and mix them to enjoy the best of both
worlds. This mix is made up of three parts, and
is graphically depicted in Fig. 3 as three large
rectangular shapes:
• The paradigm allows for fast setup of con-
nections (within seconds), which may be
needed sometime in the future.
• Interoperability may be based on existing
standards and avoid “reinventing the wheel”
(although the amount of proposed change
in support of the optical layer may deem
this point irrelevant).
• An extensive network management inter-
face, to allow maximum visibility into and
control of the network, including:
–Automatic discovery of node configuration
and network topology at the MS level
–Alarm reporting and fault isolation
–External control of the routing of connec-
tions (traffic engineering), either manually
or through a design tool
–Determination of protection policies and
routes
–All other management requirements with
which telecom NEs comply in the different
management areas (faults, configuration,
accounting, performance, and security, or
FCAPS)
• A finer granularity for interoperability is
possible: each ONE could potentially be of
a different make and still interoperate. In
the telecom-style NM&C islands of uniform
ONEs are needed to avoid having a sepa-
rate MS per NE.
The challenges, however, are daunting as well
and lie mainly in the reliability of the Internet
control plane. Assuming that for such high-band-
width connections the reliability requirements
will not go down, it is not clear how this style
will meet the 99.999 percent availability required
of the transport network. The gap may currently
be several orders of magnitude, as we shall see
below. A few indications of the problem are:
• Routing protocols are hard to design [7]
and even harder to fully test, given their
complex behavior. It is known, for instance,
that only a handful of implementations of
dynamic routing are robust and scalable. It
is also unclear how to prove their reliability,
• A flexible service-level interoperability
interface between MSs, based on a CORBA
platform to allow:
–Automatic setup of connections, possibly
with sophisticated attributes for quality of
service reliability, pricing, and so on
–Alarm propagation and trouble ticketing
between domains
–Billing support
–Service level agreement management
–Compatibility between different versions of
the interface to allow gradual upgrades of
one domain at a time
IEEE Communications Magazine • October 2000
158

• A fast, distributed control plane with mini-
mal functionality:
–Connection ID support for misconnection
detection
–Support for error detection and recovery:
bit error rate (BER), forward error correc-
tion (FEC), and so on
–Support for fast dissemination of failure
information (which resource has failed/
recovered)
–A very rudimentary connection setup pro-
tocol for automatic protection purposes.
This protocol should only specify the route
of the connection, without additional
advanced attributes, since the logic to deter-
mine the path is beyond the scope of the
ONEs themselves and supported by the ser-
vice-layer interface.
• Another related issue is inherent flexibility
of NE-MS and MS-MS interfaces vis-à-vis
the more rigid NE-NE signaling interfaces,
typically simpler due to the real-time
requirements on them. For example, many
MS interfaces use presentation-layer inter-
faces such as Abstract Syntax Notation 1
(ASN-1) to abstract the details of data
attribute formats between systems. They
may also allow new attributes to be added
to one system without having to immediate-
ly upgrade the other end. This is not the
case with most signaling protocols.
• CORBA is gaining momentum in many
industries (http://www.corba.org), and its
openness will allow reusing some of these
existing tools for the telecom industry as
well. For example, security tools developed
for online banking, such as certificate author-
ities and key management, can be reused to
secure automatic connection contracts [9].
• Much progress has been made defining
standards for interoperability between MSs.
Most notably, the TeleManagement Forum
(a global consortium of over 200 groups:
http://www.tmforum.org) is developing such
standards as part of its SMART TMN program.
It is easier to
change existing
MS software, in
part due to the
better tools,
which are also
more flexible
for future
enhancements.
For example,
the CORBA
This approach carries with it a few substantial
advantages:
architecture
• The tight human control this approach
allows for facilitates more optimized plan-
ning of NE configurations and traffic
routes. We argue that Internet networks
are moving closer to this approach as well
through support for traffic engineering
(e.g., CR-LDP).
facilitates very
flexible interfaces
between
subsystems.
• It also facilitates better and quicker fault
localization and troubleshooting, which
becoms increasingly important even for
Internet traffic with more mission-critical
traffic flowing through it.
• This hierarchy allows very diverse technolo-
gies to coexist in the same network and be
managed together. While each EMS can
provide tailored support for a specific tech-
nology, an MS higher in the hierarchy can
manage multiple technologies with an
appropriate level of abstraction.
EXAMPLE: SETUP OF A LIGHTPATH,
INITIATED BY ROUTERS
In order to understand how this proposal differs
from the full-scale Internet-style NM&C being
proposed by IETF and other standardization
bodies [2, 4], it may be helpful to consider how
both approaches support a typical futuristic sce-
nario of automatically setting up a connection.
We also consider how these scenarios change if
the setup is triggered manually.
• It is easier to develop sophisticated software
for management systems than for NEs. The
reason is that more advanced, non-real-
time operating systems are much more
prevalent for the MS, better middleware
(e.g., CORBA or Java) exists, and there is
more support for good debugging and main-
tenance tools. Although the software tech-
nology for embedded systems has improved
considerably over the last few years, many
sophisticated tools require large amounts of
memory and processing resources that many
embedded systems do not have.
• It is easier to change existing MS software, in
part due to the better tools, which are also
more flexible for future enhancements. For
example, the CORBA architecture facilitates
very flexible interfaces between subsystems,
which allow replacing of a subsystem on the fly
without taking the rest of the software down.
• The other reason for the ease of upgrade is
simply the fact that the number of manage-
ment systems to upgrade is much lower than
the number of NEs that must be upgraded.
Not only does the sheer number make a dif-
ference; also, if the upgrade implies changes
in the interface between systems (e.g., in the
signaling format), it may be required to simul-
taneously upgrade all the NEs, or else NEs
that still run the old version might not know
how to handle messages in a new format.
Consider an optical network that provides con-
nections to IP routers, in which a pair of routers
realizes that the amount of traffic between them
warrants a new lightpath to connect them directly.
In this case router 1 sets up the new lightpath to
router 2 through two separate domains of optical
networks (which represent either different ven-
dors or different carriers).
Our Combined Approach — Refer again to Fig.
3 for this case. The vertical arrows in the figure
represent messages in support of the scenario, and
the letters represent the following steps:
(a) Router 1 sends a notification to its MS
requesting for the new lightpath to router
2 (without having to specify the route that
the lightpath will take).
(b) The MS finds out, through the CORBA
service plane, which ON domains to use,
based on minimal cost, quality of service,
or survivability considerations.
(c) The MS of the first domain sends mes-
sages (c1, c2, and c3) to three OXCs in it
that have to be configured to support the
new lightpath. The OXCs themselves
need not know they are being considered
to be part of the route.
(d) This MS then sends a message to the MS
of the second optical domain.
(e) This MS sets up the route in its domain
via management messages e1 and e2.
IEEE Communications Magazine • October 2000
159

meant. However, new technologies and evolving
customer needs may make both approaches
insufficient in the future.
Common signaling layer between routers an ONE's
Indeed, in the above discussion we have tried
to show that none of the traditional NM&C styles
is a perfect fit for a reliable, flexible, efficient, and
automated optical transport network of the future.
We therefore believe that the appropriate solu-
tion lies in a careful mix of the two styles, aug-
mented with service-level interoperability through
CORBA. This mix allows keeping the NE-level
software simple, and builds on the inherent flexi-
bility and extensive feature set CORBA supports.
While this approach is by no means new, it did
not find its way into industry and standardization
discussions for optical networks, which is the
main motivation for this article.
A final disclaimer: one should not interpret
the above discussion as a prediction that the
industry is moving in the direction we have out-
lined. In fact, the opposite is more likely than
not. While we have reasoned that this is not the
appropriate step to take at this point in time for
technical reasons mainly, other considerations
such as marketing positioning are more likely to
drive many vendors and customers alike in the
opposite direction. A quick look at most of the
other articles on this topic will prove this point.
(a)
(b1) (b2) (b3) (c)
(d1)
ON
(d2)
(e)
Router
1
Router
2
ON
domain
domain
MS
MS
MS
MS
ꢀ Figure 4. Internet-style NM&C between optical networks and routers.
(f) Now, the MS of router 2 is informed that
the lightpath is ready.
(g) Finally, this MS configures router 2 to
start using the new lightpath.
Internet-Style Automatic Setup — We
assume that both the routers and ONEs are part
of one large control plane.2 The chain of events
is depicted in Fig. 4, as follows:
(a) Router 1 sends a lightpath setup request
to the adjacent ONE. Since the router
knows the entire topology of the network,
it can figure out independently how to
route the lightpath; this is conveyed as
part of the setup message (assuming, say,
CR-LDP for the protocol).
(b) This message propagates from node to
node in the first ON domain (messages
b1–b3).
(c) The message then propagates to the next
ON domain.
(d) Inside the second domain it sets up the
pertinent route using messages d1 and d2.
(e) Finally, router 2 receives the setup mes-
sage and the lightpath starts to be used.
The information on it is disseminated to
all the other nodes (say, using OSPF) so
that other routers are aware of which
resources are no longer at their disposal.
REFERENCES
[1] A. McGuire and P. Bonenfant, “Standards: The
Blueprints for Optical Networking,” IEEE Commun.
Mag., Feb. 1998.
[2] D. Awduche et al., “Multi-protocol Lambda Switching:
Combined MPLS Traffic Engineering Control with Opti-
cal Crossconnects,” IETF doc. draft-awduche-mpls-te-
optical-00.txt, Nov. 1999.
[3] A. Greenberg, G. Hjalmtysson, and J. Yates, “Smart
Routers - Simple Optics: A Network Architecture for IP
over WDM,” Proc. OFC 2000, Mar. 2000.
[4] K. Kompella et al., “Extensions to IS-IS/OSPF and RSVP
in Support of MPL(ambda)S,” IETF doc. draft-kompella-
mpls-optical-00.txt
[5] O. Crochat, J.-Y. Le Boudec, and O. Gerstel, “Protection
Interoperability for WDM Optical Networks,” IEEE/ACM
Trans. Net., June 2000.
[6] V. Paxson, “End-to-End Routing Behavior in the Inter-
net,” IEEE/ACM Trans. Net., vol. 5, no. 5, Oct. 1997,
pp. 601–15.
[7] Perlman and Varghese, “Pitfalls in the Design of Dis-
tributed Routing Algorithms,” SIGCOMM ’88, Aug.
1988, pp. 43–54.
[8] O. Gerstel and R. Ramaswami, “Optical Layer Survivability
— An Implementation Perspective,” JSAC, Sept., 2000.
[9] R. R. Iraschko, M. H. MacGregor, and W. D. Grover,
“Optimal Capacity Placement for Path Restoration in
STM and ATM Mesh-Survivable Networks,” IEEE/ACM
Trans. Net., vol. 6, no. 3, June 1998.
[10] S. Spencer and S. Woster, “Computer Industry Middle-
ware Offers A Management Solution Without Requiring
A Special Case for Telcos,” Telephony, Aug. 1998.
[11] N. Golmie, T. D. Ndousse, and D. H. Su, “A Differenti-
ated Optical Service Model for WDM Networks,” IEEE
Commun. Mag., Feb. 2000, pp. 68–73.
Manual Trigger for Setup — If, instead of
an automatic event, the setup event is triggered
by a human operator, both scenarios are very
similar to the above, except that the initial
setup request comes from an MS instead of
router 1. In the telecom style this translates to
a different message (a) being sent in the inverse
direction, from the MS of router 1 to the router
itself to notify the router of the new lightpath.
The rest of the messages are the same as in Fig.
3. In the Internet style, the lightpath setup mes-
sage originates at the MS of router 1 instead of
the router itself. This message triggers the
router to send message (a), and the rest of the
BIOGRAPHY
2 This is commonly
scenario follows.
ORNAN (ORI) GERSTEL (ori@ieee.org) received his B.A., M.Sc.,
and D.Sc. degrees from the Technion, Israel. After finishing
his D.Sc. he joined the Optical Network Systems Group at
IBM T. J. Watson Research Center and moved with the
group to develop optical networking products with Tellabs
Operations. There he served as the system and software
architect for the Tellabs Optical Networking Group, build-
ing the TITAN 6100 metro DWDM product line. Recently he
left Tellabs to join Xros (now Nortel), building all-optical
cross-connects, where he is a senior systems architect. His
research interests include network architecture, fault toler-
ance, and network design problems in optical networks.
referred to as the “peer
model”. Although a differ-
ent “client model” exists
as well, we ignore it here
to simplify the presenta-
tion. These differences are
secondary with respect to
the main topic of this arti-
cle.
SUMMARY
In this article we have surveyed the two main
trends that have evolved over the years for net-
work management and control. These approach-
es, which we call telecom-style and Internet-style
NM&C, were suited to the needs of the tech-
nologies and customers for which they were
IEEE Communications Magazine • October 2000
160
