Infrared Spectroscopy of Bis(4-nitrophenyl) Disulfide Grown on a Pb Layer
M. D. McCluskey, D. I. Grover, and K. K. Zhuravlev
Department of Physics, Washington State University, Pullman, Washington 99164-2814, U.S.A.
(Received August 16, 2002; CL-020697)
Crystal whiskers of bis(4-nitrophenyl) disulfide have been
grown ona 100-nm thick Pb film from a supersaturated solution of
p-nitrothiophenol. The whiskers preferentially grow on Pb but not
on Si, In, or Ag. The crystals were characterized by electron
microscopy and infrared spectroscopy. The optimized structure
of the molecule was determined by ab initio calculations.
Surface-enhanced infrared absorption (SEIRA) is a phenom-
enon where the infrared (IR) absorption of molecules is enhanced
by the presence of a metal surface.1 P-nitrobenzoic acid ( p-NBA)
and p-nitrothiophenol ( p-NTP) are common examples of
molecules that exhibit SEIRA. Although Ag and Au are generally
used as metals in these studies, recently it was reported that p-
NBA on Pb showed evidence of SEIRA that depended strongly on
the thickness of the Pb film.2
In this letter, we present the results of the growth and
characterization of crystals grown from a p-NTP solution on Pb
films. Unlike Ag or Au layers, self-assembled monolayers were
not observed on thin (10 nm) Pb layers. On 100-nm thick Pb
layers, however, we obtained evidence for the growth of bis(4-
nitrophenyl) disulfide (NPD) crystals. Scanning electron micro-
scopy (SEM) revealed that the crystals were present in the form of
crystal whiskers a few microns in diameter and tens or hundreds
of microns long. The IR transmission spectra of these whiskers are
in good agreement with the published spectrum for NPD. In our
experiments, no direct evidence for surface enhancement was
found, perhaps due to oxidation of the Pb surface. Instead, the
larger IR absorption on the 100-nm thick Pb layer as compared to
the 10-nm layer was due to the fact that large crystals simply did
not grow on the thin layer. The thin layer likely consisted of Pb
islands, surrounded by Si which inhibited the growth of large
NPD crystals.
Figure 1. SEM micrograph of NPD grown on a Pb/Si substrate.
The dark region, where no crystals grew, is bare Si.
taken near the edge of the Pb film. The dark region, where no
crystals grew, is bare Si. This fact was verified by energy
dispersive X-ray (EDX) analysis, which showed no Pb signal in
the dark region. It is therefore apparent that the crystal whiskers
grow preferentially on Pb but not on Si. Other experiments were
performed with 100-nm layers of Ag and In, but crystals did not
grow on those metals.
An IR absorbance spectrum of the NPD sample is shown in
Figure 2. A bare Si substrate, with neither Pb nor NPD, was used
as the reference. The absence of a S–H mode at 2549 cmÀ1
indicates that the crystals are not p-NTP. Merklin et al.3 found a
Pb films were deposited on (100) Si substrates in a Perkin-
Elmer ion-pump vacuum deposition system at a pressure of
10À7 Torr. No steps were taken to remove the oxide layer from the
Si. A quartz gauge was used to monitor the Pb thickness during the
deposition. NPD crystals were grown, at room temperature, from
a supersaturated solution of p-NTP in methanol. It was found that
NPD crystals did not grow on bare Si. When Si coated with a 100-
nm layer of Pb was placed in the solution, however, the crystals
grew within a few minutes. The crystals were yellow in
appearance, and only weakly adhered to the Pb layer. To analyze
the crystal morphology, we used a JEOL 6400 SEM with a 20 keV
electron beam. The IR spectrum was obtained at room
temperature with a Bomem DA8 Fourier transform infrared
(FTIR) spectrometer with a KBr beamsplitter and mercury-
cadmium-telluride (MCT) detector. The spectral resolution was
0.7
0.6
C-H bend
0.5
0.4
0.3
0.2
0.1
0.0
C-H stretch
NO2
500
1000
1500
2000
2500
3000
3500
Wave numbers (cm-1)
2cm À1
.
Figure 2. IR spectrum of NPD grown on a Pb/Si substrate. Peaks
indicated by asterisks (Ã) are due to the instrumental background.
C–H and NO2 modes arising from the NPD molecules are
indicated by arrows.
An SEM micrograph of the NPD crystals is shown in Figure
1. It can be seen that the crystal whiskers are approximately 3
microns wide and 30–100 microns long. The micrograph was
