Title: Mediated electrolysis of vicinal diols by neocuproine
palladium catalysts
Authors: J. Lybaert, K. Abbaspour Tehrani, K. De Wael
PII:
S0013-4686(17)31461-5
DOI:
Reference:
http://dx.doi.org/doi:10.1016/j.electacta.2017.07.044
EA 29861
To appear in:
Electrochimica Acta
Received date:
Revised date:
Accepted date:
13-3-2017
4-7-2017
6-7-2017
Please cite this article as: J.Lybaert, K.Abbaspour Tehrani, K.De Wael, Mediated
electrolysis of vicinal diols by neocuproine palladium catalysts, Electrochimica
Actahttp://dx.doi.org/10.1016/j.electacta.2017.07.044
This is a PDF file of an unedited manuscript that has been accepted for publication.
As a service to our customers we are providing this early version of the manuscript.
The manuscript will undergo copyediting, typesetting, and review of the resulting proof
before it is published in its final form. Please note that during the production process
errors may be discovered which could affect the content, and all legal disclaimers that
apply to the journal pertain.

Mediated electrolysis of vicinal diols by neocuproine palladium catalysts
J. Lybaerta,b,1, K. Abbaspour Tehranib, K. De Waela,1
aAXES, Department of Chemistry, University of Antwerp, Groenenborgerlaan 171, B-2020
Antwerp (Belgium)
bOrganic synthesis, Department of Chemistry, University of Antwerp, Groenenborgerlaan
171, B-2020 Antwerp (Belgium)
1ISE member
E-mail: kourosch.abbaspourtehrani@uantwerpen.be; karolien.dewael@uantwerpen.be
1

Abstract
Synthetic electrochemistry agrees well with the principles of sustainable chemistry,
therefore it is considered as a more environmentally friendly approach than some current
synthetic methods. Here, we present a new strategy for the chemoselective oxidation of
vicinal diols, viz. the integration of neocuproine palladium catalysts and electrosynthesis.
Benzoquinones are used as an effective mediator as the reduced species (hydroquinones)
can be easily reoxidized at relative low potentials at an electrode surface.
NeocuproinePd(OAc)2 efficiently works as a catalyst in an electrolysis reaction for vicinal diols
at room temperature. This is a remarkable observation given the fact that aerobic oxidation
reactions of alcohols typically need a more complex catalyst, i.e. [neocuproinePdOAc]2[OTf]2.
In this article we describe the optimization of the electrolysis conditions for the
neocuproinePd(OAc)2 catalyst to selectively oxidize diols. The suggested approach leads to
conversion of alcohols with high yields and provides an interesting alternative to perform
oxidation reactions under mild conditions by the aid of electrochemistry.
Keywords: palladium; benzoquinone; neocuproine ligand; alcohol oxidation;
electrosynthesis
2

1. Introduction
Chemoselective oxidation reaction pathways aim to selectively oxidize an alcohol
functionality in the presence of other alcohols. The oxidation of vicinal diols to the
corresponding α-hydroxyketone functionality is of particular interest as this functionality is
present in antitumor antibiotics such as kurasoin A and B [1] and in different natural
products such as olivomycin A [2]. The α-hydroxyketone group also plays an important role
in the modification of carbohydrates and other reaction schemes in general organic
synthesis [3].
Different (non-electrochemical) methods have been proposed to achieve a chemoselective
reaction of vicinal diols. The use of peroxotungstophosphates in combination with hydrogen
peroxide is reported to give a selective oxidation of different vicinal diols [4]. Also, the
stoichiometric use of dioxiranes results in chemoselectivity [5]. Another oxidation pathway
consisting of NaBrO3 with NaHSO3 is described in literature to selectively oxidize cyclic vicinal
diols to the corresponding hydroxyl ketones [6]. Focusing on catalytic systems using metal
catalysts, the combination of RuCl3 with buffered oxone as the stoichiometric oxidant is
reported to oxidize different vicinal diols to the corresponding α-hydroxyketones [7]. Other
catalysts are organotin compounds in combination with stoichiometric oxidants like Br2 or N-
iodosuccinimide (NIS) [8]. Those organotin catalysts can be also replaced by boronic acids
[9], or used in combination with electrochemical oxidized bromo species (Br+) [8,9].
In general, catalysts for alcohol oxidation can be immobilized on (modified) electrode
surfaces, for example a carbon supported platinum electrode modified with bismuth. Using
such an electrode glycerol is oxidized to dihydroxyacetone with high selectivity [10]. A
second electrochemical approach includes TEMPO as a mediator and a similar selective
3

oxidation of glycerol to dihydroxyacetone can be obtained by reoxidizing TEMPO at the
electrode surface. However, only a yield of 25 % is reported [11].
Palladium catalysts have been investigated thoroughly for the aerobic non-electrochemical
oxidation of alcohols. Catalysts such as Pd carbene catalyst [12] or cationic pyridine based
palladium complexes [13] have been reported for selective oxidation reactions with oxygen
as stoichiometric oxidant. Another example of a palladium catalyst that can selectively
oxidize vicinal diols is the cationic palladium complex using neocuproine as a ligand,
developed by Waymouth et al [14].
The beneficial use of neocuproine as a ligand for palladium catalysts was first investigated by
Sheldon et al. [15], they reasoned that the methyl groups on the 2 and 9 position of the
phenanthroline ligand cause steric hindrance and thus prevent the formation of dimeric
structures, resulting in a more active catalyst for oxidation reactions. The highest activity for
the aerobic oxidation of alcohols was achieved by using the palladium catalyst
neocuproinePd(OAc)2 (Scheme 1, structure 1) which has a phenanthroline with two methyl
groups substituents at the 2 and 9 position (neocuproine).
Scheme 1
Later, this catalyst was used as a basis for the synthesis of a new cationic palladium complex
using neocuproine as a ligand [16]. It was reasoned that a cationic palladium complex with
non-coordinating counter anions could increase the rate of aerobic alcohol oxidation. The
dimeric acetate bridged [neocuproinePdOAc]2[OTf]2 (Scheme 1, structure 2) was synthesized
by conproportionation of neocuproinePd(OAc)2 and the ditriflate analogue
neocuproinePd(MeCN)2(OTf)2. This catalyst 2 proved to have faster initial rates for the
4

aerobic oxidation of alcohols at room temperature. In comparison, catalyst 1 needs 80
degrees Celsius for an efficient conversion [15].
Interestingly, catalyst 2 allowed the selective oxidization of polyols [14]. More specific, in
vicinal diols only the secondary alcohol is oxidized to the corresponding α-hydroxyketone.
Also glycerol can be selectively oxidized to the corresponding dihydroxyacetone under mild
conditions [17]. In those approaches both oxygen and p-benzoquinone are used as
stoichiometric oxidants. Additionally, it was mentioned that catalyst 2 may convert
unprotected pyranosyl glucosides to the corresponding ketosaccharides. Here, the catalyst
can discriminate between different secondary hydroxyl groups, only the one at the C3
position is oxidized to the ketone by using 2,6-dichlorobenzoquinone as stoichiometric
oxidants [18].
The drawback of using oxygen as the stoichiometric oxidant in combination with catalyst 2 is
the fact that it may lead to the oxidation of the neocuproine ligand and corresponding losses
in reactivity over time [16]. To avoid this, other catalysts have been synthesized. Waymouth
et al. reported on a catalyst having a trifluoromethyl substituted phenanthroline ligand
instead of neocuproine and studied its oxidation potential of 2-heptanol [19]. The results
were not convincing, although the turnover number of this catalyst doubled and no ligand
oxidation was observed, the initial rate, however, was 3.7 times lower compared to catalyst
2. Furthermore, the ligand is much more difficult to synthesize. Recently, a deuteration of
the methyl substituents in the neocuproine ligand was suggested to obtain a more resistant
ligand against oxidation [20].
In this article, an electrocatalytic approach by using catalyst 1 and 2 is suggested. By working
in an inert gas atmosphere, the possible degradation of the catalyst by oxygen is prevented.
5

Secondly, the electrochemical recycling avoids the use of a stoichiometric amount (or
excess) of the oxidants, making it a more sustainable alternative. In an electrocatalytic
oxidation reaction, a mediator gets oxidized at the electrode surface at a low potential
followed by the oxidation of the target molecule [21]. Mediators of interest are
benzoquinones as it is known that the reduced species (hydroquinones) can be easily
reoxidized at relative low potentials [22-26].
The selective oxidation of vicinal diols directly to -hydroxy ketones is of utmost importance
when looking for an atom-economical reaction. For the first time, palladium catalysts with
neocuproine ligands are combined with the electrochemical recycling of benzoquinones. A
selective electrochemical oxidation of diols under mild conditions and high yield is now
presented.
2. Experimental
Synthesis of neocuproinePd(OAc)2 (catalyst 1)
A solution of neocuproine (5.5 mmol, 1.25 g) in anhydrous CH2Cl2 (20 mL) was added to a
solution of Pd(OAc)2 (5.0 mmol, 1.12 g) in anhydrous toluene (100 mL) at room temperature
under nitrogen. The mixture was stirred overnight and heptane was added to precipitate the
complex. A yellow solid was filtered off, washed with acetone and dried under vacuum;
yield: 1.78 g (4.0 mmol, 80%).
Synthesis of neocuproinePd(CH3CN)2(OTf)2
To a slurry of catalyst 1 (0.221 g, 0.511 mmol) in acetonitrile (1.0 mL) was added a solution
of triflic acid in acetonitrile (0.33 M, 3.8 mL, 2.5 equiv). The solution was stirred briefly and
then precipitated with diethyl ether to give a yellow solid. This solid was isolated by
6

centrifugation, precipitated two more times from acetonitrile using diethyl ether, and dried
under vacuum to give a light yellow solid (0.090 g). Additional triflic acid (0.33 M, 1.0 mL)
was added to the original supernatant, followed by brief stirring and precipitation with
diethyl ether. The resulting yellow solid was subjected to the same workup as described
above to give additional product (0.021 g). The pure solids were combined (0.111 g, 0.160
mmol, 31% yield).
Synthesis of [neocuproinePdOAc]2[OTf]2 (catalyst 2)
To a 25 mL round-bottom flask with a stirbar was added catalyst 1 (0.0400 g, 0.0924 mmol),
neocuproinePd(CH3CN)2(OTf)2 (0.0642 g, 0.0924 mmol), and acetonitrile (10.0 mL). The
resulting mixture was stirred until all solids dissolved and then precipitated with diethyl
ether to give an orange solid. This solid was isolated by centrifugation, washed with diethyl
ether, and dried under vacuum to give 1 as an orange solid (0.0589 g, 0.0563 mmol, 61%
yield).
Electrochemical measurements
All electrochemical measurements were performed by using a Potentiostat/Galvanostat
PGSTAT 30 from Metrohm Autolab, connected with a PC provided with NOVA 1.11 software.
Cyclic voltammetry measurements were performed using a three electrode cell with a glassy
carbon working electrode of 3 mm diameter (Metrohm, the Netherlands), a platinum sheet
counter electrode and a bridged Ag/AgCl reference electrode with 2 M LiCl ethanol solution
as inner solution and a 0.1 M Bu4NBF4 DMSO as bridge solution, all potentials mentioned are
relative to this reference electrode which has a voltage difference of +150 mV versus a
standard hydrogen electrode (SHE). The working electrode was pretreated by mechanical
polishing. It was subjected to sequential polishing with a cloth covered with alumina powder
7

of 1 and 0.05 mm particle size (SPI supplies, USA) for 10 min. To remove any adherent Al2O3
particles, the electrode surface was rinsed thoroughly with deionized water and cleaned in
an ultrasonic bath containing deionized water for 2 min. Next, the electrode was rinsed with
acetone and dried. Solutions of 0.1 M Bu4NBF4 in DMSO were freshly made and purged with
nitrogen gas for 10 minutes to remove oxygen before each measurement.
Electrolysis
A homemade airtight electrolysis cell was used equipped with a reticulated vitreous carbon
(RVC) as working electrode (basi, USA), a bridged Ag/AgCl reference electrode with 2 M LiCl
ethanol solution as inner solution and a 0.1 M Bu4NBF4 DMSO as bridge solution was used
and the counter electrode, a platinum rod electrode, was put in a divided cell separated
from the anodic part by a ceramic frit. In a typical electrolysis experiment 4 mL of a 0.2 M
Bu4NBF4 DMSO solution was added to the divided part followed by the addition of 200 µL of
acetic acid. In the anodic part neocuproinePd(OAc)2 (0.1 equivalent), 2,6-
dimethoxybenzoquinone (0.6 equivalent) and the alcohol (0.7 mmol) was added to a 14 mL
solution of 0.2 M Bu4NBF4 in DMSO. The cell was closed and put under an argon atmosphere.
Stirring was started, next a potential of 0.7 V was applied. After the appropriate reaction
time 30 mL of water was added to the reaction mixture. The resulting mixture was extracted
with tert-butylmethylether (3 times 25 mL). The collected organic layer was washed with 15
mL of water to further remove DMSO. Next the organic layer was dried with MgSO4 filtered
and evaporated. The resulting solution was examined with NMR. Isolated products were
obtained using column chromatography with heptane/ethylacetate (7/3) as eluent.
8

3. Results and discussion
A first set of experiments was performed to evaluate the reactivity of different palladium
precursors for the selective oxidation of 1,2-octanediol, in combination with the
electrochemical recycling of 2,6-dimethoxybenzoquinone. During the constant potential
electrolysis (electrolysis cell equipped with a reticulated vitreous carbon (RVC) as working
electrode) a current could be obtained and selective oxidation to the hydroxy ketone was
observed (Table 1, entry 1).
The different palladium catalysts could convert the alcohol into the hydroxyl ketone during
the electrolysis procedure. All three neocuproine ligated palladium catalysts gave a similar
yield, as can be seen in Table 1. Only the palladium acetate (Table 1, entry 4) was not active,
as almost no current was detected during the electrolysis. Next, both catalysts 1 and 2 were
further tested in different solvents (DMSO, DMF and acetonitrile) (see Table S1). It was
observed that DMSO is the solvent leading to the highest conversion. In DMF catalyst 1
seems to be not active while catalyst 2 is less active. In acetonitrile both catalysts seems to
be inactive.
Surprisingly, neocuproinePd(OAc)2 (catalyst 1) was also active in the electrolysis experiment
at room temperature. Until now, only the aerobic oxidation of alcohols using this catalyst is
reported at 80 degrees Celsius with the addition of a base. Only [neocuproinePdOAc]2[OTf]2
(catalyst 2) is reported to be active at room temperature with an excess of 2,6-
dimethoxybenzoquinone. So, we expected an efficient electrochemical conversion at room
temperature only for catalyst 2. Simultaneoulsy, we raised the question whether catalyst 1 is
also reactive at room temperature with an excess of 2,6-dimethoxybenzoquinone (without
9

electrolysis). For this reason, different stoichiometric oxidations of 1,2-octanediol were
performed with 2,6-dimethoxybenzoquinone and neocuproinePd(OAc)2 at room
temperature.
In literature, reoxidation of catalyst 2 is performed with p-benzoquinone instead of 2,6-
dimethoxybenzoquinone as mediator. Therefore, a reaction was also tested with three
equivalents of p-benzoquinone (Table 2, entry 3), no difference was observed between both
mediators.
The oxidation reaction of 1,2-octanediol was further tested with three equivalents or 0.6
equivalents of 2,6-dimethoxybenzoquinone. In both cases only the stoichiometric oxidation
of 1,2-octanediol was observed.
So, based on the comparison between electrolysis (Table 1) and stoichiometric oxidation
(Table 2) of 1,2-octanediol, the electrochemistry clearly aids the facile conversion with high
yield of the alcohol at room temperature in the presence of both catalyst 1 and catalyst 2.
10

To further examine the reactions responsible for the electrochemical oxidation of the
alcohol, cyclic voltammetric experiments were performed. First, neocuproinePd(OAc)2 was
added to a DMSO electrolyte solution and scanned between the potentials of interest during
the electrolysis. No redox peaks could be detected in a potential window from 0 to 1.0 V
(Figure 1), at ca 1V a Pd feature occurs so this potential is further avoided to retain the
activity of the catalyst. Next an excess of 1,2-octanediol is added to this solution and
scanned in the same potential range with no observed redox processes. Finally 2,6-
dimethoxybenzoquinone is added and here a redox peak could be detected around 0.6 V
explained as the oxidation peak of 2,6-dimethoxyhydroquine. This reoxidation phenomenon
explains the current monitored during the electrolysis experiment. A peculiar observation is
the fact that the peak height is not in correlation with the concentration of the
benzoquinone added elucidating a slow reoxidation process of the mediator.
Figure 1
With [neocuproinePdOAc]2[OTf]2 a similar experiment is conducted, resulting in a peak
current which is ten times higher for the oxidation of 2,6-dimethoxyhydroquinone (Figure 2).
A much more efficient reoxidation process of the mediator is thus taking place.
Figure 2
Experiments with a rotating disk electrode were performed. It can be seen that the limiting
current (Il) increases with the rotation rate (Figure 3). A linear relation between the limiting
current and the square root of the rotation rate is detected which is according to the Levich
equation (inset Figure 3).
Figure 3
11

Although the cyclic voltammetric experiments reveal differences of the two catalysts on a
short time scale, a similar result (yield) is obtained during an electrolysis (ca seven hours)
experiment under similar conditions. Probably, catalyst 1 has only a slower activation in the
starting phase but at longer times a similar conversion is obtained. Faster initial rates with
catalyst 2 were also observed in aerobic oxidation processes [16].
Since a similar yield is obtained during electrolysis, there is no advantage in using catalyst 2,
being much more expensive and time-consuming synthesis. It was decided to further explore
and optimize the electrolysis procedure using catalyst 1, the precursor of catalyst 2.
It has been shown in Table 1 that the electrolysis, combining neocuproinePd(OAc)2 and 2,6-
dimethoxybenzoquinone, results in the selective oxidation of 1,2-octanediol into the
hydroxyl ketone. A conversion of ca 50% could be obtained. To optimize the reaction
conditions during the electrolysis, different concentrations of 2,6-dimethoxybenzoquinone
were added to examine the influence on the alcohol conversion.
From Table 3 it is clear that the addition of 2,6-dimethoxybenzoquinone is crucial to obtain
an efficient oxidation reaction. The higher the concentration of benzoquinone, the more
efficient the palladium catalyst can be reoxidized. As a result, the formed hydroquinone can
be more efficiently oxidized at the electrode surface, proven by a higher charge obtained
during the electrolysis. The optimized reaction conditions take place with 0.6 equivalents of
2,6-dimethoxybenzoquinone added, as a quasi-full conversion of the alcohol to the hydroxy
ketone is detected (Table 3, entry 5).
12

Next, the influence of the concentration of the palladium catalyst on the conversion was
examined. Lowering the concentration of the palladium catalyst results in a lower yield and
hence in a lower charge; enough palladium catalyst should be present to obtain an efficient
oxidation reaction. From Table 3 (entry 5-8) it is clear that 0.1 equivalents are needed to
obtain an optimal conversion, ca. 85%.
Additionally, the influence of the nature of the mediator, benzoquinone, was investigated.
An electrolysis reaction was performed using p-benzoquinone instead of 2,6-
dimethoxybenzoquinone (Table 3, entry 3). As the oxidation potential of p-hydroquinone is
shifted over +0.2 V compared to the one of 2,6-dimethoxyhydroquinone, a constant
potential of 0.9 V instead of 0.7 V was applied. Comparable yields and efficiencies were
found using these two quinones. Further optimization was conducted and also the influence
of temperature was examined (Table 3, entry 9). A similar yield was obtained at 40 degrees
Celsius as a reaction at room temperature so there is no benefit in using higher temperature.
The addition of a base was examined as it is known from literature that a high concentration
of acetate is crucial to reoxidize the palladium catalyst in stoichiometric conversions using
oxygen as stoichiometric oxidant. To our surprise, by adding 0.1 M of acetate (Table 3, entry
10) no electrolysis current could be detected and no oxidation of the 1,2-octanediol was
observed. We noticed that the addition of acetate anions is making the palladium catalyst
inactive. Also the addition of trimethylamine was tried (Table 3, entry 11) but again no
current could be detected and only a small amount of the hydroxy ketone was formed.
The optimized procedure using 0.1 equivalents of catalyst 1 and 0.6 equivalents of 2,6-
dimethoxybenzoquinone at room temperature under a constant potential of 0.7 V for 8
hours was expanded to different alcohols, firstly to elucidate the difference in conversion
13

between diols and singular alcohols. A primary and secondary aliphatic alcohol, 1-octanol
(Table 4, entry 2) and 2-nonanol (Table 4, entry 3), were tested. Only an electrolysis current
could be detected with 1-octanol, no current was detected with 2-nonanol. After work up,
the aldehyde octanal was detected as a reaction product of the oxidation of 1-octanol and
for the electrolysis of 2-nonanol the start product was mainly recovered. A test was also
performed with 1-nonanol (Table 4, entry 4) and again oxidation of the alcohol took place
with formation of the aldehyde nonanal in reasonable yield. So, the neocuproine catalyst
seems capable to catalyze the oxidation of both vicinal diols (chemoselective) and also
primary aliphatic alcohols.
Then, a primary and secondary benzylic alcohol were tested. A similar behavior was
observed as with the oxidation of aliphatic alcohols. For benzyl alcohol (Table 4, entry 6),
benzaldehyde was found as the oxidation product in a reasonable yield. In contrast, for 1-
phenylethanol (Table 4, entry 5) no electrolysis could be detected, the starting alcohol was
mostly recovered unaffected.
Comparing the results of the singular alcohols with 1,2-octanediol, the diol shows a better
reactivity during the electrolysis (higher charge-yield). The presence of the two alcohol
functions seems to be more easily activated by catalyst 1, an easier complexation is possible
between the catalyst and the diol.
To further expand the scope of the suggested procedure, different diols were tested.
Electrolysis of 1,2-hexanediol was performed (Table 5, entry 2) and a selective oxidation of
the secondary alcohol was detected in a comparable yield as with 1,2-octanediol. Similar
results were obtained with 1,2-decanediol (Table 5, entry 3).
14

By testing cyclohexanediol, the influence of two vicinal secondary alcohols instead of one
primary and one secondary is studied. Using the standard electrolysis procedure also these
alcohols were selectively oxidized to the hydroxy ketone. Similar yields of hydroxyl ketone
were obtained starting from cis-cylcohexanediol and from trans-cyclohexanediol, illustrating
that there is no preference for a certain configuration of the alcohol functionalities on the
cyclohexane structure.
4. Conclusions
Neocuproine palladium based catalysts are of interest for the oxidation of vicinal diols in an
electrolysis setup based on the electrochemical reoxidation of benzoquinone mediators.
The use of electrolysis in organic synthesis is an interesting pathway to obtain more green
and sustainable synthesis procedures. Electricity and in essence electrons are used as a
reagent and when combined with sustainable electricity generation this can lead to good
alternatives for chemical oxidants.
The remarkable activity of the palladium catalyst neocuproinePd(OAc)2 in the electrolysis
procedure provides an interesting alternative for the selective oxidation of vicinal alcohols at
room temperature. Because of the reactivity of neocuproinePd(OAc)2 at room temperature,
the cumbersome synthesis of more exotic Pd based catalysts is avoided while providing a
similar reactivity using the same procedure.
The electrolysis procedure was evaluated and optimized by focusing on different singular
and vicinal diols. For singular alcohols only the primary alcohols were oxidized. For the
15

vicinal diols, all tested compounds were active and a selective oxidation with good yield was
obtained using the suggested electrolysis procedure.
16

References:
[1] R. Masuma, R. Uchida, K. Shiomi, T. Sunazuka, J. Inokoshi, T. Kawakubo, et al., Kurasoins
A and B, New Protein Farnesyltransferase Inhibitors Produced by Paecilomyces sp. FO-3684.
II. Structure Elucidation and Total Synthesis, J. Antibiot. 49 (1996) 886.
[2] V. Kumar, W.A. Remers, W.T. Bradner, Preparation and antitumor activity of olivomycin A
analogs, J. Med. Chem. 23 (1980) 376–379.
[3] A. Minnaard, M. Witte, N. Eisink, Chemo- and Regioselective Oxidation of Secondary
Alcohols in Vicinal Diols, Synthesis. 49 (2017) A–H.
[4] Y. Sakata, Y. Ishii, A versatile transformation of vic-diols into .alpha.-hydroxy ketones with
hydrogen peroxide catalyzed by peroxotungstophosphates, J. Org. Chem. 56 (1991) 6233–
6235.
[5] L. D'Accolti, A. Detomaso, C. Fusco, A. Rosa, R. Curci, Selective oxidation of optically
active sec,sec-1,2-diols by dioxiranes. A practical method for the synthesis of homochiral
.alpha.-hydroxy ketones in high optical purity, J. Org. Chem. 58 (1993) 3600–3601.
[6] M. Bierenstiel, P.J. D'Hondt, M. Schlaf, Investigations into the selective oxidation of
vicinal diols to α-hydroxy ketones with the NaBrO3/NaHSO3 reagent: pH dependence,
stoichiometry, substrates and origin of selectivity, Tetrahedron. 61 (2005) 4911–4917.
[7] B. Plietker, B. Plietker, The RuO 4 -Catalyzed Ketohydroxylation. Part 1. Development,
Scope, and Limitation, J. Org. Chem. 69 (2004) 8287–8296.
[8] T. Maki, S. Iikawa, G. Mogami, H. Harasawa, Y. Matsumura, O. Onomura, Efficient
Oxidation of 1,2-Diols into α-Hydroxyketones Catalyzed by Organotin Compounds, Chem. –
Eur. J. 15 (2009) 5364–5370.
[9] M. Kuriyama, O. Onomura, Boronic Acid-Catalyzed Selective Oxidation of 1,2-Diols to α-
Hydroxy Ketones in Water, Adv. Synth. Catal. 356 (2014) 934–940.
[10] Y. Kwon, Y. Birdja, I. Spanos, P. Rodriguez, M.T.M. Koper, Highly Selective Electro-
Oxidation of Glycerol to Dihydroxyacetone on Platinum in the Presence of Bismuth, ACS
Catal. 2 (2012) 759–764.
[11] R. Ciriminna, G. Palmisano, C. Della Pina, M. Rossi, M. Pagliaro, One-pot electrocatalytic
oxidation of glycerol to DHA, Tetrahedron Lett. 47 (2006) 6993–6995.
[12] L. Bettucci, C. Bianchini, W. Oberhauser, T.-H. Hsiao, H.M. Lee, Chemoselective aerobic
oxidation of unprotected diols catalyzed by Pd–(NHC) (NHC=N-heterocyclic carbene)
complexes, J. Mol. Catal. A: Chem. 322 (2010) 63–72.
17

[13] L. Bettucci, C. Bianchini, J. Filippi, A. Lavacchi, W. Oberhauser, Chemoselective Aerobic
Diol Oxidation by Palladium(II)–Pyridine Catalysis, Eur. J. Inorg. Chem. 2011 (2011) 1797–
1805.
[14] K. Chung, S.M. Banik, A.G. de Crisci, D.M. Pearson, T.R. Blake, J.V. Olsson, et al.,
Chemoselective Pd-Catalyzed Oxidation of Polyols: Synthetic Scope and Mechanistic Studies,
J. Am. Chem. Soc. 135 (2013) 7593–7602.
[15] G.-J. ten Brink, I.C. . Arends, M. Hoogenraad, G. Verspui, R. Sheldon, Catalytic
Conversions in Water. Part 23: Steric Effects and Increased Substrate Scope in the Palladium-
Neocuproine Catalyzed Aerobic Oxidation of Alcohols in Aqueous Solvents, Adv. Synth. Catal.
345 (2003) 1341–1352.
[16] N.R. Conley, L.A. Labios, D.M. Pearson, C.C.L. McCrory, R.M. Waymouth, Aerobic Alcohol
Oxidation with Cationic Palladium Complexes:ꢀ Insights into Catalyst Design and
Decomposition, Organometallics. 26 (2007) 5447–5453.
[17] R.M. Painter, D.M. Pearson, R.M. Waymouth, Selective Catalytic Oxidation of Glycerol to
Dihydroxyacetone, Angew. Chem., Int. Ed. 49 (2010) 9456–9459.
[18] M. Jäger, M. Hartmann, A.J. Minnaard, Catalytic Regioselective Oxidation of Glycosides,
Angew. Chem., Int. Ed. 52 (2013) 7809–7812.
[19] D.M. Pearson, N.R. Conley, R.M. Waymouth, Oxidatively Resistant Ligands for
Palladium-Catalyzed Aerobic Alcohol Oxidation, Organometallics. 30 (2011) 1445–1453.
[20] N. Armenise, N. Tahiri, N.N.H.M. Eisink, M. Denis, M. Jäger, J.G. de Vries, et al.,
Deuteration enhances catalyst lifetime in palladium-catalysed alcohol oxidation, Chem.
Commun. 52 (2016) 2189–2191.
[21] R. Francke, R.D. Little, Redox catalysis in organic electrosynthesis: basic principles and
recent developments, Chem. Soc. Rev. 43 (2014) 2492–2521.
[22] C. Amatore, C. Cammoun, A. Jutand, Pd(OAc)2/p-Benzoquinone-Catalyzed Anaerobic
Electrooxidative Homocoupling of Arylboronic Acids, Arylboronates and Aryltrifluoroborates
in DMF and/or Water, Eur. J. Org. Chem. 2008 (2008) 4567–4570.
[23] J. Lybaert, S. Trashin, B.U.W. Maes, K. De Wael, K.A. Tehrani, Cooperative
Electrocatalytic and Chemoselective Alcohol Oxidation by Shvo's Catalyst, Adv. Synth. Catal.
359 (2017) 919-925.
[24] C. Amatore, C. Cammoun, A. Jutand, Electrochemical Recycling of Benzoquinone in the
Pd/Benzoquinone-Catalyzed Heck-Type Reactions from Arenes, Adv. Synth. Catal. 349 (2007)
292–296.
18

[25] C. Amatore, C. Cammoun, A. Jutand, Palladium/Benzoquinone-Catalyzed
Electrochemical Oxidation of Alcohols Under Anaerobic Conditions, Synlett. (2007) 2173–
2178.
[26] P. Röse, S. Emge, C.A. König, G. Hilt, Efficient Oxidative Coupling of Arenes via
Electrochemical Regeneration of 2,3-Dichloro-5,6-dicyano-1,4-benzoquinone (DDQ) under
Mild Reaction Conditions, Adv. Synth. Catal. 359 (2017) 1359-1372.
19

Captions:
Figure 1. Cyclic voltammograms with a scan rate of 100 mVs-1 of an 0.1 M Bu4NBF4 DMSO
solution at 20° C (blue); with addition of 0.9 mM neocuproinePd(OAc)2 (black); with addition
of 50 mM 1,2-octanediol (red); with addition of 8.9 mM 2,6-dimethoxybenzoquinone
(green).
Figure 2. Cyclic voltammograms with a scan rate of 100 mVs-1 of an 0.1 M Bu4NBF4 DMSO
solution at 20° C (blue); with addition of 0.9 mM [neocuproinePdOAc]2[OTf]2 (black); with
addition of 50 mM 1,2-octanediol (red); with addition of 8.9 mM 2,6-
dimethoxybenzoquinone (green).
Figure 3. Cyclic voltammograms with a scan rate of 100 mVs-1 of an 0.1 M Bu4NBF4 DMSO
solution at 20° C with 0.9 mM [neocuproinePdOAc]2[OTf]2; 50 mM 1,2-octanediol (red); 8.9
mM 2,6-dimethoxybenzoquinone at different rotation rates: 500 (a); 1000 (b); 1500 (c); 2000
(d); 2500 (e) and 3000 (f) rpm. Inset: Il versus (ω)1/2.
Scheme 1. Two neocuproine palladium catalysts: neocuproinePd(OAc)2 (1) and
[neocuproinePdOAc]2[OTf]2 (2).
20

Figure 1
21

Figure 2
22

Figure 3
Scheme 1
23

Table 1. Oxidation of 1,2-octanediol with different palladium catalysts with electrochemical
recycling of 2,6-dimethoxybenzoquinone.
Yield
[%]b
Recovered
alcohol [%]b
Charge
[Coulomb]
Entrya)
Palladium Catalyst
Time [h]
neocuproinePd(OAc)2
1
2c
3
7
5
5
5
49
53
40
5
34
36
48
90
70
74
58
4
[neocuproinePdOAc]2[OTf]2
NeocuproinePd(CH3CN)2(OTf)2
Pd(OAc)2
4
a) reaction conditions: 0.7 mmol alcohol with 0.05 equivalents of palladium catalyst and 0.25 equivalents of 2,6-
dimethoxybenzoquinone in 14 mL DMSO with 0.2 M Bu4NBF4 at room temperature with constant potential of
0.7 V under argon atmosphere.
b) NMR yields calculated after extraction with the addition of 1,3,5-trimethoxybenzene as an internal standard.
c) With 0.025 equivalents of (neocuproinePdOAc)2(OTf)2
24

Table 2. Stoichiometric oxidation of 1,2-octanediol with 2,6-dimethoxybenzoquinone.
Equivalent
Benzoquinone
Recovered
Entrya
Time [h]
Potential
Yield [%]b
4
alcohol [%]b
No
potential
No
potential
No
potential
No
potential
1c
2
6
6
7
8
3 equiv.
3 equiv.
3 equiv.
0.6 equiv.
95
11
13
9
87
83
87
3d
4
a) reaction conditions: 0.7 mmol alcohol with 0.1 equivalents of neocuproinePd(OAc)2 and x equivalents of 2,6-
dimethoxybenzoquinone in 14 mL DMSO with 0.2 M Bu4NBF4 at room temperature under argon atmosphere.
b) NMR yields calculated after extraction with the addition of 1,3,5-trimethoxybenzene as an internal standard.
c) Without 0.2 M Bu4NBF4
d) With 3 equivalents of p-benzoquinone instead of 2,6-dimethoxybenzoquinone.
25

Table 3. Optimization of the electrolysis reaction of 1,2-octanediol.
Entry
Equivalent
catalyst 1
of Time
[h]
Yield
[%]
Recovered Charge
Equivalent
Benzoquinone
alcohol
[%]
[Coulomb]
0 equiv.
0.1 equiv.
0.1 equiv.
0.1 equiv.
0.1 equiv.
21
63
65
76
85
73
9
68
66
88
108
1
7
7
7
8
8
7
0.25 equiv.
0.25 equiv.
0.40 equiv.
0.60 equiv.
26
24
9
2
3a
4
2
0.1 equiv.
0 equiv.
5
6
0.60 equiv.
0.60 equiv.
0
92
70
0
7
8
0.01 equiv.
7
22
26
0.60 equiv.
0.40 equiv.
0.25 equiv.
0.05 equiv.
0.1 equiv.
0.1 equiv.
7
8
5
71
71
1
22
11
97
95
98
6
9b
10c
11d
0.1 equiv.
4
6
90
6
0.25 equiv.
a) With 0.25 equivalents of p-benzoquinone instead of 2,6-dimethoxybenzoquinone, with a potential of 0.9 V
instead of 0.7 V.
b) Electrolysis at 40 degrees Celsius.
c) With the addition of 0.1 M of Bu4NOAc.
d) With the addition of 2 equivalents of Et3N.
26

Table 4. Oxidation of singular alcohols.
Potential
(V)
Recovered
Charge
Entrya
Alcohol
1,2-octanediol
1-octanol
Yield [%]b
alcohol [%]b [Coulomb]
1
2
3
4
5
6
0,7
0,7
0,7
0,7
0,7
0,7
85
64
8
2
108
86
3
16
90
17
85
25
2-nonanol
1-nonanol
60
10
60
99
2
1-phenylethanol
benzylalcohol
72
a) reaction conditions: 0.7 mmol alcohol with 0.1 equivalents of neocuproinePd(OAc)2 and 0.6 equivalents of
2,6-dimethoxybenzoquinone in 14 mL DMSO with 0.2 M Bu4NBF4 at room temperature with constant potential
of 0.7 V for 8 hours under argon atmosphere.
b) NMR yields calculated after extraction with the addition of 1,3,5-trimethoxybenzene as an internal standard.
27

Table 5. Oxidation of diols.
Potential
(V)
Recovered
Charge
Entrya
Alcohol
Yield [%]b
85
alcohol [%]b [Coulomb]
1
2
3
4
5
1,2-octanediol
0,7
2
108
1,2-hexanediol
1,2-decanediol
0,7
0,7
0,7
0,7
79
88
57
58
n.d.
3
95
101
106
91
Cis-cyclohexanediol
n.d.
Trans-cyclohexanediol
n. d.
a) reaction conditions: 0.7 mmol alcohol with 0.1 equivalents of neocuproinePd(OAc)2 and 0.6 equivalents of
2,6-dimethoxybenzoquinone in 14 mL DMSO with 0.2 M Bu4NBF4 at room temperature with constant potential
of 0.7 V for 8 hours under argon atmosphere.
b) NMR yields calculated after extraction with the addition of 1,3,5-trimethoxybenzene as an internal standard.
28
