Synthesis and Antimicrobial Properties of a Ciprofloxacin and PAMAM-dendrimer Conjugate

Article abstract of DOI:10.3390/molecules25061389

Infections caused by bacteria resistant to antibiotics are an increasing problem. Multivalent antibiotics could be a solution. In the present study, a covalent conjugate between Ciprofloxacin and a G0-PAMAM dendrimer has been synthesized and tested against clinically relevant Gram-positive and Gram-negative bacteria. The conjugate has antimicrobial activity and there is a positive dendritic effect compared to Ciprofloxacin itself.

Full text of DOI:10.3390/molecules25061389

Article
Synthesis and Antimicrobial Properties of
a Ciprofloxacin and PAMAM-dendrimer Conjugate
1
2
1
1
Søren Wedel Svenningsen , Rikki Franklin Frederiksen , Claire Counil , Mario Ficker ,
2
1,
Jørgen J. Leisner and Jørn Bolstad Christensen *
1
Department of Chemistry, University of Copenhagen, Thorvaldsensvej 40,
DK-1871 Frederiksberg C, Denmark; swsvenningsen@gmail.com (S.W.S.); claire.counil@orange.fr (C.C.).;
mario.ficker@gmail.com (M.F.)
Department of Veterinary and Animal Sciences, Food Safety and Zoonoses, University of Copenhagen,
2
Grønnegårdsvej 15, DK-1870 Frederiksberg C, Denmark; rikki.fredriksen@umu.se (R.F.F.);
jjl@sund.ku.dk (J.L.L.)
* Correspondence: jbc@chem.ku.dk; Tel.: +45-3533-2452
Academic Editor: Jørn Bolstad Christensen
Received: 18 February 2020; Accepted: 17 March 2020; Published: 18 March 2020
Abstract: Infections caused by bacteria resistant to antibiotics are an increasing problem.
Multivalent antibiotics could be a solution. In the present study, a covalent conjugate between
Ciprofloxacin and a G0-PAMAM dendrimer has been synthesized and tested against clinically
relevant Gram-positive and Gram-negative bacteria. The conjugate has antimicrobial activity and
there is a positive dendritic effect compared to Ciprofloxacin itself.
Keywords: Antimicrobial compounds; dendrimers; Ciprofloxacin
1. Introduction
Antimicrobial resistance to antibiotics is an increasing problem worldwide. Accordingly, the
World Health Organization (WHO) has listed antibiotic resistance as one of the three most important
st
public health challenges in the 21 century [1]. Two major causes for the present situation are the over
prescription of antibiotics leading to resistance and the lack of new antibiotics. Bacterial resistance
occurs via different mechanisms including degradation of the antimicrobial compound, modification
of the antimicrobial target, decrease in drug uptake, global regulatory changes in metabolic
pathways, and the activation of efflux mechanisms [2,3]. Resistance due to the expression of efflux-
pumps is problematic, because such pumps are not very specific with respect to antibiotics, but are
capable of exporting a wide variety of different classes of antimicrobial compounds, potentially
causing multi-resistance [4–9].
A number of compounds which are inhibitors of efflux-pumps are known, and many of the
classical drugs ranging from antihistamines to CNS-active compounds from psychiatry have this
interesting side-effect, i.e., they are efflux-pump inhibitors at low concentrations but kill bacteria at
higher concentrations [10–14]. Apart from the effect on the central nervous system, a serious issue is
that the known efflux-pump inhibitors lack specificity for bacterial efflux pumps, but are also
inhibitors for pumps found in humans, like glycoprotein P, and can interfere with the hERG-channel
in the heart lengthening the QT-interval, increasing the risk of cardiac arrest [15,16].
A possible solution to efflux-mediated resistance could be modifications of known antibiotics so
they are not substrates for efflux-pumps while keeping the antimicrobial activity.
Molecules 2020, 25, 1389; doi:10.3390/molecules25061389
www.mdpi.com/journal/molecules

Molecules 2020, 25, 1389
2 of 13
D’Emanuele and coworkers [17] discovered that the beta-blocker propranolol covalently
conjugated to a PAMAM-dendrimer was internalized by human cells. This was interesting, because
propranolol itself is known to be a substrate for the glycoprotein P pump.
Since all families of efflux pumps [8] are highly promiscuous with respect to substrates, this led
us to the idea of using a conjugate between a dendrimer and an antibiotic to enter the bacteria and
prevent export by their efflux pumps.
The conjugation of an antibiotic to a dendrimer can be either non-covalent or covalent: Non-
covalent attachment requires the formation of a guest–host complex between the antibiotic and the
dendrimer that is sufficiently stable to survive the gastrointestinal system and in the blood stream,
while either having an antimicrobial effect as a complex or releasing the antibiotic once inside the
bacteria.
Xu and coworkers [18] studied the solubilization of the fluoroquinolones Nadifloxacin and
Prulifloxazin in amino-terminated ethylenediamine-core PAMAM-dendrimers (EDA-core PAMAM)
and found no effect on the solubility at low pH, which shows that a non-covalent complex could
dissociate in the stomach and undergo uptake as two separate entities. In vitro, there was an
enhanced antibacterial effect of combining Prulifloxacin with the G4-dendrimer (64 NH2-groups at
the surface) against E. coli. Wen and coworkers [19] found that the complex between amino-
terminated EDA-core PAMAM-dendrimers and Sulfomethoxazole showed enhanced activity in vitro
against E. coli. There have also been in vitro studies on the effect of co-administering antibiotics with
poly(propylene imine) dendrimers showing similar results [20]. Antimicrobial dendrimers are also
known and some examples are the quaternary silicon-dendrimers pioneered by de la Mata, Gomez
and coworkers [21–24] the small peptide-dendrons by Urbanczyk-Lipkowska and coworkers [25–28]
and the peptide dendrimers by Reymond and coworkers [29–32].
Covalent conjugates between antibiotics have been described by Kannan and coworkers [33],
who synthesized a covalent conjugate between Azithromycin and a hydroxyl-terminated generation
4 PAMAM-dendrimer that released the antibiotic after cellular uptake enabling treatment of
intracellular C. trachomatis in vitro. Baker and coworkers [34] described a photocleavable conjugate
between a dendrimer and Ciprofloxacin that released the drug upon illumination.
In the present work, we wanted to investigate if a dendrimer-antibiotic conjugate could have
antimicrobial activity in itself and not just be an advanced and expensive drug-delivery system. It
was important to choose an antibiotic, where the mechanism of activity was non-covalent interactions
with a target, because in that way it might be possible to kill many bacteria subsequently with the
same molecule in a “catalytic fashion”. The conjugate should optimally be active both towards Gram-
positive and Gram-negative bacteria. The dendrimer would have to be small, because access to the
interior of Gram-negative bacteria takes place through porines in the outer membrane that in general
excludes larger molecules from passage [35,36].
The fluoroquinolones (Figure 1) are often used for treatment of Gram-negative infections and a
lot is known regarding the effect of substitution on the ring systems. The carboxylic acid in position
3 and the carbonyl group in position 4 are essential for activity. Substitution in position 2 also leads
to reduced activity, while the substituent in position 1 controls specificity against Gram negative or
Gram positive bacteria. Position 7 is also important for specificity as well as serum half-life [37]
Figure 1. The basic structure of the fluoroquinolones.
2. Results
Ciprofloxacin (1) (Figure 2) was chosen because it is active both against Gram-positive and
Gram-negative bacteria and because it acts through non-covalent binding to topoisomerases.

Molecules 2020, 25, 1389
3 of 13
Ciprofloxacin targets primarily topoisomerase II in Gram-negatives and primarily topoisomerase IV
in Gram-positives. It has furthermore a natural handle for attachment of a linker (the piperazine
moiety) that should have minimal effect on the antimicrobial properties. A G0 DAB-core PAMAM-
dendrimer [38] (Figure 2) was chosen as a compromise between multivalency, solubility of the
conjugate and a wish to keep the molecular weight as low as possible.
The molecular design is shown in Figure 3 and involves the covalent attachment of Ciprofloxacin
via a linker to a small PAMAM-dendrimer.
Figure 2. Ciprofloxacin (1) and the PAMAM-dendrimer (2).
Figure 3. The Ciprofloxacin-derivative (3), dendrimer conjugate (4) and control dendrimer (5).
Compound (3) is the monovalent control fluoroquinolone for comparison of any multivalency effects.

Molecules 2020, 25, 1389
4 of 13
Scheme 1: Synthesis of the PAMAM-Ciprofloxacin conjugate (4) from Ciprofloxacin (1).
The synthesis is shown in Scheme 1 and started with protection of the piperazine in
Ciprofloxacin with a BOC-group converting the zwitterionic compound into the carboxylic acid (6)
followed by conversion into the fully protected ester (7), which was much easier to handle. Following
deprotection of the BOC-group, compound (8) was reacted with Phenyl acrylate [39] to give (9).
Phenyl esters have very high selectivity for acylation of primary versus secondary amines [40–42],
which is why Michael-addition is observed instead of acylation. Reaction of phenyl ester (9) with the

Molecules 2020, 25, 1389
5 of 13
dendrimer (2) gave the benzyl ester (10), which was deprotected by catalytic hydrogenation
(H2/Pd(OH)2) to give the desired product (4). The control compound (3) was synthesized by a similar
route (Scheme 2), but using benzyl acrylate [43] for the Michael addition and deprotection as for (4).
Scheme 2: Synthesis of the Ciprofloxacin control derivative (3) from Ciprofloxacin Benzyl ester (8).
The dendrimer-control was synthesized by acetylation of the dendrimer (2) with excess acetic
anhydride.
The compounds were tested against four different strains of clinically relevant pathogens for
which antibacterial resistance is a challenge representing two Gram-positive (Enterococcus faecalis and
Staphylococcus aureus) and two Gram-negative species (Pseudomonas aeruginosa and Salmonella
enterica). The S. aureus 8325-4 strain is a plasmid cured variant of the NTCT 8325 variant, an important
model strain used in laboratory research [44,45]. The E. faecalis V583 strain (ATCC 700802, GenBank
AE016830.1) is a vancomycin-resistant, clinical isolate from human blood [46,47]. The S. enterica
serovar Typhimurium 4/74 strain represent a serovar commonly implicated in human gastroenteritis
that is also used as a mouse model of human typhoid fever [48]. The P. aeruginosa PAO1 strain is a
commonly used research strain for this opportunistic pathogen [49,50]. MIC-values for these target
strains were determined by microbroth dilution assay in 96-well microtiter plates. The results are
shown in Table 1 and the minimal inhibitory concentrations (MIC values) are given both in mg/L and
in µmol/L.
Table 1. MIC-values of the compounds tested in four different strains of pathogenic bacteria. The
MIC-values are the median of three biological replicates.
Bacterial Strain
MIC
mg/L
MIC
µM
Compound
Gram-positive
1
3
4
5
1
3
4
5
0.25
0.5
16
>256
0.25
0.5
0.75
1.24
0.0069
>0.47
0.75
1.24
0.0069
>0.47
S. aureus 8325-4
E. faecalis V583
16
>256
Gram-negative
1
3
4
5
1
3
4
5
0.5
0.25
16
>256
0.25
0.5
1.5
0.62
0.0069
>0.47
0.75
1.24
0.014
>0.47
S. enterica serovar Typhimurium 4/74
P. aeruginosa PAO1
32
>256
Similar trends were observed for all four target organisms. However, our variant of the 4/74
strain exhibited an unusual lack of sensitivity towards Ciprofloxacin with only 0.8% of the Salmonella

Molecules 2020, 25, 1389
6 of 13
strains in the EUCAST database on antimicrobial wild type distributions exhibiting a similar or a
higher MIC value (https://mic.eucast.org/Eucast2/). The strain SL1344 that is a derivative of the 4/74
strain [48] has been reported as Ciprofloxacin sensitive [51,52]. Although the 4/74 variant used in our
study can in fact be described as resistant towards Ciprofloxacin it showed the same overall pattern
in sensitivities as the three other target species that were all sensitive to Ciprofloxacin according to
the EUCAST database.
The control dendrimer (5) lacked antimicrobial activity whereas the dendrimer Ciprofloxacin
conjugate (4) showed highest activity in terms of MIC values expressed in µM showing a clear
positive dendritic effect, which becomes even bigger if the MIC values are calculated relative to the
number of Ciprofloxacines. This result emphasizes the strong synergistic activity of the dendrimer
Ciprofloxacin conjugate. In conclusion, this compound contributes to the overall antimicrobial
activity of the conjugate that is of interest as it moves its application beyond that of being a drug
delivery vehicle.
3. Discussion
Successful penetration of the bacterial cell envelope is a prerequisite for the activity of antibiotics
having intracellular targets. At physiological pH, fluoroquinolones are known to coexist in a
zwitterionic and overall uncharged form and a neutral form, with only the latter form passively
diffusing through cell membranes, such as the cytoplasmic membrane of Gram-negatives and Gram-
positives [53]. For Gram-negatives, however, the outer membrane and its lipopolysaccharide (LPS)
layer constitute a second barrier. Penetration by fluoroquinolones of this barrier is suggested to be
mediated by three mechanisms: (i) by a hydrophilic pathway through porins, (ii) by a hydrophobic
pathway through the lipid bilayer, and (iii) by a “self-promoted” pathway involving displacement of
divalent cations bridging adjacent LPS molecules [54] such as seen for antimicrobial peptides. In
hydrophilic fluoroquinolones, such as Ciprofloxacin, uptake is mediated primarily by porins and by
the “self-promotion” pathway [55,56]. With Ciprofloxacin having a mass of 331 Da it is easily
imagined that this hydrophilic molecule can cross the water-filled porins as they generally have an
exclusion size of 600 Da [57]. However, the larger size of our dendrimer conjugate (876 Da), and the
absence of classical porins in Pseudomonas aeruginosa [58], suggests that these compounds are instead
transported by either the “self-promotion” pathway or by hijacking of specific channels and high
affinity receptors translocating larger nutrient molecules [57].
The mode of action of Ciprofloxacin is by stabilizing the complex of prokaryotic topoisomerase
II and IV enzymes, leading to DNA fragmentation and bacterial death [59,60]. The control dendrimer
showed in our study no antimicrobial activity which is in contrast with studies on PAMAM
dendrimers with terminated amino groups [61–63]. This result is most likely due to our control
dendrimer was equipped with terminal acetyl groups. The lack of antimicrobial activity of the control
dendrimer compared to the synergistic activity of the dendrimer Ciprofloxacin conjugate relative to
Ciprofloxacin suggest that the synergism is related to Ciprofloxacin mode of action. Here, it is of
interest that PAMAM dendrimers promote transfection of DNA in both mammalian cells [64] and in
prokaryotic cells as demonstrated for Anaplasma phagocytophilum, an obligate intracellular bacterium
[65]. Thus, the ability of PAMAM to bind DNA indicates that the dendrimer may interact with the
association of Ciprofloxacin with bacterial topoisomerases e.g., by binding to DNA fragments
generated by Ciprofloxacin activity.
We have not in our study compared the synergy effect observed for the dendrimer Ciprofloxacin
covalent conjugate with the antimicrobial activities of mixtures of the dendrimer and Ciprofloxacin.
A synergy effect has also been observed for mixtures of PAMAM and quinolones or sulfamethoxazole
but this result appeared to be a concentration-dependent effect of the PAMAM dendrimer on the
solubility of the antimicrobial compounds. For the mixture of PAMAM and quinolones this effect
was also pH dependent. It was hypothesized that this could be due to electrostatically interactions
between PAMAM and the carboxyl group in the quinolone molecules and in addition that both
quinolones and sulfamethoxazole might be kept in the cavities of the PAMAM dendrimer resulting
in increasing solubility of the small guest molecules [18,19]. Thus, the synergy mechanism in mixtures

Molecules 2020, 25, 1389
7 of 13
appears to differ from the mechanism for the covalent conjugate hypothesized above. This would
make it difficult to interpret the outcome of a potential comparative analysis
It will be of interest to examine further the mode of action of the dendrimer Ciprofloxacin
conjugate and to illuminate whether this compound may show antimicrobial activity towards
Ciprofloxacin resistant bacterial variants. Thus, it should be tested whether resistance due to
mutations in the protein targets of Ciprofloxacin might be circumvented by the potential DNA
binding abilities of the dendrimer. It is more straightforward to anticipate the overcome of resistance
due to efflux pumps by using PAMAM as the vehicle to transport Ciprofloxacin to the topoisomerase
targets but this also need to be tested experimentally. Such studies are in progress in our laboratories.
In conclusion, we have demonstrated proof of principle that the dendrimer Ciprofloxacin
conjugate exhibits increased antimicrobial activity and that PAMAM dendrimers have potential in
antimicrobial chemotherapy beyond acting as delivery vehicles. Such synergistic effects have been
described before for anionic/cationic dendrimers and levofloxacin, another fluoroquinolone in a non-
covalent system [66].
4. Experimental
4.1. Bacterial Cultures
Salmonella enterica serovar Typhimurium 4/74, Pseudomonas aeruginosa PAO1, Staphylococcus
aureus 8325-4 and Enterococcus faecalis V583 from the local collection at the Institute were grown
overnight with shaking (180 rpm) in 5 mL Luria-Bertani (LB) broth at 37 °C for 18 h before use for
MIC determinations.
4.2. MIC Determinations
MIC was determined by microbroth dilution assay in 96-well microtiter plates with LB broth
containing two-fold serial dilutions of test compounds. Test compounds were diluted in sterile water
and prepared for a testing concentration range of 0.25–256 μg/mL. Then, 50 μL from each dilution
was transferred into the well of a microtiter plate and inoculated with 50 μL of bacterial culture
prepared for a final concentration of approximately 106 CFU/mL corresponding roughly to OD600
0.00065. The microtiter plates were then incubated aerobically at 37 °C for 18–24 h with shaking (180
rpm). Growth in individual plate wells was defined as OD600 > 0.06. Wells containing only inoculums
were used as positive controls for bacterial growth, while wells with only media was used as negative
control for sterility of media.
The MIC values are the median of three biological replicates, and demonstrated good
reproducibility.
4.3. Synthetic Procedures
7-(4-(2-Carboxyethyl)piperazin-1-yl)-1-cyclopropyl-6-fluoro-4-oxo-1,4-dihydroquinoline-3-
carboxylic acid (3)
To a round bottom flask equipped with a magnetic stirring bar was added compound 8 (1.6 g,
3.79 mmol) and dissolved in dichloromethane (40 mL). Benzyl acrylate (960 mg, 4.19 mmol) was
added and the reaction was stirred at RT for 72 h under nitrogen atmosphere. The yellow solution
was evaporated in vacuo, and dried under high vacuum. The pale-yellow powder was washed with
Et2O (30 mL) and further dried in high vacuum. The intermediate compound (11) was obtained as
pale white solid (1.05 g), which was used directly for the next step.
Compound (11) (1.0 g; 17.1 mmol) was dissolved in a 1:1 mixture of ethanol and THF (50 mL in
total), 10% Pd(OH)2 on carbon (150 mg) was added and the mixture hydrogenated at 3 bar pressure
at room temperature for 16 h. The reaction mixture was filtered through Celite to remove the catalyst,
and compound (3) was obtained by removing all volatiles in vacuum. Yield: 580 mg (37%).
1
H NMR (300 MHz, DMSO-d6): δ = 1.20–1.28 (m, 2H), 1.34–1.43 (m, 2H), 2.81–2.92 (m, 2H), 2.38–
2.48 (m, 8 H), 2.57–2.58 (m, 2H), 3.85–3.95 (m, 1H), 7.60–6.69 (m, 1H), 7.92–8.05 (m, 1H), 8.68–8.75 (m,

Molecules 2020, 25, 1389
8 of 13
13
1H). C NMR (126 MHz, DMSO-d6): δ 176.30; 172.87; 165.86; 153,91; 151.93; 147.87; 144.14; 139.09;
19
118.69; 111.03; 106.69; 62.57; 52.58; 52.00; 51.64; 48.55; 47.11; 46.26; 42.40; 36.48; 35.93; 30.88; 7.54.
F
NMR (470 MHz, DMSO-d6): δ −121.57. HRMS: ESI (0.1% Formic acid in MeOH): 404.161 (calcd. for
+
C20H22FN3O5 : m/z: 404.162)
DAB-PAMAM-G0-(Cipro-COOH)4 ● 6HCl (4)
Compound (10) (0.27 g; 0.11 mmol) was dissolved in a mixture of THF and water (10:3 v/v; 60
mL) and added to 10% Pd(OH)2 on carbon (0.10 g) in a hydrogenation bottle. The mixture was
hydrogenated in a Parr-apparatus at 3.5 bar for 48 h. The catalyst was removed by filtration through
a bed of Celite and concentrated in vacuo. A solution of HCl in Methanol (1 M, 30 mL) was added
and the solution evaporated again. The hydrochloride was purified by size-exclusion
chromatography on Sephadex G25 (Pharmacia (Sweden) now GE Healthcare (US) using
Methanol:H2O (1:1 v/v) as eluent. After removal of the solvent, the product was obtained in a yield of
0.12 g (46%).
1
H-NMR (500 MHz, DMSO-d6): δ 15.10 (s, 3 H); 8.69–8.61 (m, 4 H); 7.96–7.84 (m, 4 H); 7.65–7.53
(m, 4 H); 3.89–3.82 (m, 4 H); 3.41–3.23 (m, 48 H); 3.14 (s, 16 H); 3.11–3.06 (m, 8 H); 2.90–2.85 (m, 3 H);
13
2.71–2.67 (m, 8 H); 1.80–1.73 (m, 4 H); 1.37–1.29 (m, 8 H); 1.22–1.13 (m, 8 H). C-NMR (126 MHz,
DMSO-d6): δ 176,29; 169.17; 165.79; 153.80; 151.80; 148.08; 139.03; 119.11; 111.18; 111.00; 106.80; 106.71;
19
51.56; 50.88; 48.61; 39.52; 38.41; 38.28; 36.49; 35.98; 29.39; 25.13; 7.63. F-NMR (470 MHz, DMSO-d6):
+
2+
δ −121.67. HRMS: ESI (0.1% Formic acid in MeOH): m/z [M + 2H ] : 1044.0084 (calcd. for
2+
+
3+
3+
C104H134F4N22O20 : 1044.0052); m/z [M + 3H ] : 696.3405. (calcd. for C104H135F4N22O20 : 696.3392); m/z
+
4+
3+
[M + 4H ] : 522.0033. (calcd. for C104H136F4N22O20 : 522.5062).
DAB-PAMAM-G0-(Acetamide)4 ● 2HCl (5)
DAB-PAMAM-G0-(NH2)4 [34] (1.00 g; 1.84 mmol) was dissolved in ethanol (25 mL). Acetic
anhydride (7.50 g; 73.5 mmol) was added and the reaction mixture was stirred at room temperature
for 16 h. The reaction mixture was evaporated in vacuo, dissolved in 1 M HCl in Methanol (25 mL)
and evaporated again. The residue was redissolved in 1 M HCl in Methanol (10 mL) and added
dropwise to Diethyl ether (200 mL) under stirring. The precipitated product was filtered and dried
in vacuum to give a white crispy solid. Yield: 1.44 g (quantitative). Ninhydrin-test for residual
primary amino groups (1% Ninhydrin in ethanol): Negative after 24 h.
1
H-NMR (500 MHz, D2O): δ 3.45-3.39 (m, 8 H); 3.25 (s, 20 H); 2.78–2.69 (m, 8 H); 1.93 (s, 12 H).
13
C-NMR (126 MHz, D2O): δ 174.37; 171.86; 52.46; 49.60; 38.68; 28.74; 28.70; 21.82; 20.54. HRMS
+
+
+ +
(MALDI, matrix: Dithranol): m/z [M+H ] : 713.4682 (calcd. for C32H60N10O6: 713.4686); [M + Na ] :
735.4503 (calcd. for. C32H60N10NaO6 : 735.4503); [M + K ] : 751.4155 (calcd. for. C32H60N10KO6 :
751.4277)
+
+
+
+
Benzyl 7-(4-tert-butoxycarbonyl)piperazin-1-yl)-1-cyclopropyl-6-fluoro-4-oxo-1,4-dihydroquinoline-
3-carboxylate (7)
To a flame dried round bottomed flask equipped with a magnetic stirring bar was added:
Ciprofloxacin (1) (1.50 g; 4.53 mmol); 1,4-dioxane (25 mL); Boc2O (1.19 g; 5.45 mmol) and Et3N (0.76
mL; 5.45 mmol). The reaction mixture was stirred at room temperature for 3 h and evaporated to
dryness in vacuo. The residue was dissolved in acetonitrile (50 mL) and benzyl chloride (0.69 g; 5.45
mmol), K2CO3 (0.75 g; 5.43 mmol) was added. This reaction mixture was refluxed for 10 h and
evaporated in vacuo to give a yellow powder, that was washed with heptane (100 mL), water (100
mL) and heptane (100 mL) followed by drying in high vacuum. White powder. Yield 2.23 (94%).
1
H-NMR (500 MHz, CDCl3): δ 8.50 (s, 1 H); 8.00 (d, J = 13.2 Hz, 1 H); 7.50 (d, J = 7.5 Hz, 2 H); 7.36
(t, J = 7.4 Hz, 2 H); 7.30 (t, J = 7.3 Hz, 2 H); 5.37 (s, 2 H); 3.65 (t, J = 5.1 Hz, 4 H); 3.47–3.41 (m, 1 H); 3.22
13
(t, J = 4.8 Hz, 4 H); 1.49 (s, 9 H); 1.28 (q, J = 6.9 Hz, 2 H), 1.10 (q, J = 6.6 Hz, 2 H). C-NMR (126 MHz,
CDCl3): δ 172.94; 165.63; 154.72; 154.48; 152.50; 148.44; 144.51; 138.15; 136.48; 128.64; 128.11; 128.05;
19
123.18; 113.55; 113.37; 110.07; 105.32; 80.34; 66.56; 50.10; 34.81; 28.54; 8.29. F-NMR (470 MHz, CDCl3):

Molecules 2020, 25, 1389
9 of 13
+
+
δ −123.48. HRMS: ESI (0.1% Trifluoroacetic acid in MeOH): m/z [M + H ] : 522.2356 (calcd. for
+
+
2+
+
C29H33FN3O5 : 522.2399); m/z [M + 2H ] : 261.1219 (calcd. for C29H33FN3O52 : 522.2399)
Benzyl 1-cyclopropyl-6-fluoro-4-oxo-piperazin-1-yl)-1,4-dihydroquinoline-3-carboxylate (8)
Compound (7) (0.53 g; 1.02 mmol) was dissolved in a mixture of trifluoroacetic acid and
dichloromethane (2:8 v/v, 5 mL) and stirred at room temperature for 24 h. The reaction mixture was
diluted with dichloromethane and washed with saturated aqueous NaHCO3 to remove the acid. The
organic phase was dried over MgSO4, filtered and evaporated in vacuo to give the deprotected amine
(8) as a powder. Yield: 0.39 g (90%).
1
H-NMR (500 MHz, CDCl3): δ 8.47 (s, 1 H); 7.95 (d, J = 13.2 Hz, 1 H); 7.49 (d, J = 7.0 Hz, 2 H); 7.36
(d, J = 7.6 Hz, 2 H); 7.31–7.27 (m, 1 H), 7.23 (d, J = 7.1 Hz, 1 H); 5.35 (s, 2 H); 3.42–3.37 (m, 1 H); 3.29–
13
3.22 (m, 4 H); 3.13–3.07 (m, 4 H); 2.59 (s, 1 H); 1.29–1.23 (m, 2 H), 1.11–1.06 (m, 2 H). C-NMR (126
MHz, CDCl3): δ 173.20; 165.46; 154.49; 152.51; 148.33; 138.07; 136.54; 128.60; 128.07; 128.01; 113.33;
19
113.14; 109.94; 104.93; 77.16; 66.40; 50.88; 45.88; 34.68; 8.22. F-NMR (470 MHz, CDCl3): δ −123.50.
+
+
HRMS: ESI (0.1% Trifluoroacetic acid in MeOH): m/z [M + H] : 422.1875 (calcd. for C24H25FN3O5 :
422.1875)
Benzyl 1-cyclopropyl-6-fluoro-4-oxo-7-(4-(3-oxo-3-phenoxypropyl)piperazin-1-yl)-1,4-
dihydroquinoline-3-carboxylate (9)
To a flame dried round bottomed flask equipped with a magnetic stirring bar was added:
Compound (8) (1.00 g; 2.37 mmol), dichloromethane (25 mL) and phenyl acrylate [35] (0.3885 g; 2.62
mmol). The mixture was stirred under N2 for 72 h and evaporated in vacuo. The residual powder was
washed with diethyl ether (20 mL) and dried in vacuum giving compound (9) as a white powder.
Yield: 1.27 g (94%).
1
H-NMR (500 MHz, CDCl3): δ 8.47 (s, 1 H); 7.95 (d, J = 13.3 Hz, 1 H); 7.50 (d, J = 7.0 Hz, 2 H); 7.39–
7.34 (m, 4 H); 7.31–7.27 (m, 1 H); 7.24–7.20 (m, 2 H); 7.11–7.08 (m, 2 H); 5.36 (s, 2 H); 3.41–3.37 (m, 1
H); 3.30 (t, J = 4.8 Hz, 4 H); 2.93 (t, J = 6.9 Hz, 2 H); 2.81 (t, J = 7.1 Hz, 2H); 2.79–2.75 (m, 4 H), 1.27–1.22
13
(m, 2 H); 1.10 (m, 2 H). C-NMR (126 MHz, CDCl3): δ 173.08; 170.90; 165.47; 154.40; 152.42; 150.76,
148.34; 138.03; 136.56; 129.53; 128.59; 128.04; 127.97; 125.97; 122.99; 122.93; 121.59; 113.28; 113.10;
19
109.99; 104.95; 77.16; 66.38; 53.50; 52.74; 49.90; 34.65; 32.60; 8.18. F-NMR (470 MHz, CDCl3): δ −123.41.
+
+
+
HRMS: ESI (0.1% Trifluoroacetic acid in MeOH): m/z [M+H ] : 570.2415 (calcd. for C23H33FN3O5 :
+
2+
2+
+ +
570.2399); m/z [M + 2H ] : 285.6224 (calcd. for C29H33FN3O5 : 285.6236); m/z [M + Na ] : 592.2235
+
+
+
+
(calcd. for C23H33FN3NaO5 : 592.2219); m/z [M + K ] : 608.1961 (calcd. for C23H33FN3KO5 : 608.7204).
DAB-PAMAM-G0-(Cipro-Bn)4 (10)
In a flame dried round bottomed flask equipped with a magnetic stirring bar was compound (8)
(0.50 g; 0.88 mmol) dissolved in dry DMSO (10 mL). The solution was heated to +40 °C and 4-
(Dimethylamino)pyridine (0.0108 g; 0.088 mmol) was added followed by dropwise addition of a
solution of DAB-PAMAM-G0-(NH2)4 [34] (0.100 g; 0.184 mmol). The reaction mixture was stirred for
4 days at 40 °C under a N2-atmosphere and then transferred to a dialysis bag (Regenerated cellulose,
molecular weight cut-off 1 kD) and dialyzed against 0.2 M HCl (2 × 2 L, 24 h each) followed by milliQ-
water (2 × 2 L, 24 h each). The content of the dialysis bag was then transferred to a round bottomed
flask and lyophilized to give the benzylester protected dendrimer conjugate (10), which contains
encapsulated phenol as evidenced from NMR. Yield 0.36 g (80%). Ninhydrin-test for residual primary
amino groups (1% Ninhydrin in ethanol): Negative after 24 h.
1
H-NMR (500 MHz, DMSO-d6): δ 8.44 (d, J = 19.7 Hz, 4 H); 8.38–8.20 (m, 5 H, included phenol);
7.73 (m, 4 H); 7.51–7.45 (m, 8 H); 7.45–7.42 (m, 3 H); 7.42–7.36 (m, 12 H); 7.34–7.30 (m, 4 H); 5.28–5.24
(m, 8 H); 3.67–3.62 (m, 4 H); 3.52–3.28 (m, 24 H); 3.25–3.17 (m, 8 H); 3.13 (s, 16 H); 3.10–2.85 (m, 24 H);
13
2.85–2.73 (m, 4 H); 2.66–2.58 (m, 8 H); 1.75–1.65 (m, 3 H); 1.26–1.21 (m, 8 H); 1.11–1.06 (m, 8 H). C-
NMR (126 MHz, DMSO-d6): δ 171,55; 171.47; 164.48; 164.44; 153.53; 153.38; 151.57; 151.42; 150.46
(phenol); 148.42; 137.99; 137.92; 136,61; 129.49 (phenol); 128.35; 127.73; 127.58; 125.81 (phenol); 122.11;

Molecules 2020, 25, 1389
10 of 13
121.76 (phenol); 111.70; 111.52; 108.79; 106.35; 65.22; 52.34; 51.90; 51.74; 51.54; 51.39; 49.33; 48.72; 48.27;
19
39.52; 38.45; 38.24; 36.47; 34.84; 30.41; 7.53. F-NMR (470 MHz, DMSO-d6): δ −124.29. HRMS: ESI
+
2+
2+
(0.1% Formic acid in MeOH): m/z [M + 2H ] : 1224.1091 (calcd. for C132H158F4N22O20 : 1224.0991); m/z
+
3+
3+
+ 4+
[M + 3H ] : 816.4073. (calcd. for C132H159F4N22O20 : 816.4018; m/z [M + 4H ] : 612.5532). (calcd. for
4+
C132H160F4N22O20 : 612.5532)
5. Conclusions
Ciprofloxacin has been conjugated to a DAB-core G0 PAMAM-dendrimer and the antimicrobial
activity has been tested on a selection of both Gram-positive and Gram-negative bacteria of clinical
relevance. A positive dendritic effect is observed for the conjugate in both types of bacteria. This is
an example of a dendrimer that adds to the antimicrobial activity of a conjugate which could lead to
new strategies for the treatment of infectious diseases.
Supplementary Material: The following are available online. NMR & MS spectra of the compounds.
Author Contributions: Conceptualization, J.B.C.; methodology, J.B.C., S.W.S., C.C. and M.F.; formal analysis,
R.F.F and J.L.L.; investigation, J. B. C., S. W. S., C. C., M. F., R. F. F..; data curation, S. W. S, J. B. C., R. F. F.;
writing—original draft preparation, J. B. C, R. F. F and J. L. L.; writing—review and editing, J. B. C, R. F. F., J. L.
L. and S. W. S.; supervision, J. B. C and J. L. L.; project administration, J. B. C.; funding acquisition, J. B. C. All
authors have read and agreed to the published version of the manuscript.
Funding: We would like to thank the Lundbeck foundation for support through grant 2009-4618 Rational
Design of Dendrimer-based Nanoantibiotics
Conflicts of interest: There are no conflicts to declare.
References
1.
1.
2.
World Health Organization. Antimicrobial resistance: Global report on surveillance 2014. Available online:
https://www.who.int/health-topics/antimicrobial-resistance (accessed on 18 March, 2020).
Levy, S.B.; Marshall, B. Antibacterial resistance worldwide: Causes, challenges and responses. Nat. Med.
2004, 10, S122–S129.
Davies, J.; Davies, D. Origins and Evolution of Antibiotic Resistance. Microbiol. Mol. Biol. Rev. 2010, 74, 417–
433.
3.
4.
Poole, K. Efflux pumps as antimicrobial resistance mechanisms, Ann. Med. 2007, 39, 162–176.
Amaral, L.; Martins, A.; Spengler, G.; Molnar, J. Efflux pumps of Gram-negative bacteria: What they do,
how they do it, with what and how to deal with them. Front. Pharmacol. 2015, 4, 168,
doi:10.3389/fphar.2013.00168.
5.
6.
7.
Poole, K. Outer membranes and efflux: The path to multidrug resistance in Gram-negative bacteria. Curr.
Pharm. Biotechnol. 2002, 3, 77–98.
Schindler, B.D.; Kaatz, G.W. Multidrug efflux pumps of Gram positive bacteria. Drug Res. Updates 2016, 27,
1–13.
Van Bambeke, F.; Balzi, E. and Tulkens, P.M. Antibiotic efflux pumps—Commentary. Biochem. Pharmacol.
2000, 60, 457–470.
8.
9.
Sikri, N.; Dalal, S.; Taneja, R. Efflux Pumps: An Overview. Int. J. Pharm. Sci. Res. 2018, 9, 854–861.
Wiese, M.; Pajeva, I.K. Structure-activity relationships of multidrug resistance reversers. Curr. Med. Chem.
2001, 8, 685–713.
10. Amaral, L.; Engi, H.; Viveiros, M.; Molnar, M. Comparison of multidrug resistant efflux pumps of cancer
and bacterial cells with respect to the same inhibitory agents. In Vivo 2007, 21, 237–244.
11. Martins, M.; Dastidar, S.G.; Fanning, S.; Kristiansen, J.E.; Molnar, J.; Pagès, J.-M.; Schelz, S.; Spengler, G.;
Viveiros, M.; Amaral, L. Potential role of non-antibiotics (helper compounds) in the treatment of multidrug-
resistant Gram-negative infections: Mechanisms for their direct and indirect activities. Int. J. Antimicrobial
Agents 2008, 31, 198–208.
12. Kristiansen, J.E.; Hendricks, O.; Delvin, T.; Butterworth, T.S.; Aagaard, L.; Christensen, J.B.; Flores, V.C.;
Keyzer, H. Reversal of resistance in microorganisms by help of non-antibiotics. J. Antimicrob. Chem. 2007,
59, 1271–1279.

Molecules 2020, 25, 1389
11 of 13
13. Palmeira, A.; Sousa, E.; Vasconcelos, M.H.; Pinto, M.M. Three Decades of P-gp Inhibitors: Skimming
Through Several Generations and Scaffolds. Curr. Med. Chem. 2012, 19, 1946–2025.
14. Raschi, E.; Ceccarini, L.; De Ponti, F.; Recanatini, M. hERG-related drug toxicity and models for predicting
hERG liability and QT prolongation. Expert Opin. Drug Metab. Tox. 2009, 5, 1005–1021.
+
15. Clancy, C.E.; Kurokawa, J.; Tateyama, M.; Wehrens, X.H.T.; Kass, R.S. K channel structure-activity
relationships and mechanisms of drug-induced QT prolongation. Ann. Rev. Pharm. Toxicol. 2003, 43, 441–
461.
16. Najlah, M.; Freeman, S.; Attwood, D.; D’Emanuele, A. Synthesis and assessment of first-generation
polyamidoamine dendrimer prodrugs to enhance the cellular permeability of P-gp substrates. Bioconj.
Chem. 2007, 18, 937–946.
17. Cheng, Y.; Cheng, Y.; Qu, H.; Ma, M.; Xu, Z.; Xu, P.; Fang, Y.; Xu, T. Polyamidoamine (PAMAM)
dendrimers as biocompatible carriers of quinolone antimicrobials: An in vitro study. Eur. J. Med. Chem.
2007, 42, 1032–1038.
18. Ma, M.; Cheng, Y.; Xu, Z.; Xu, P.; Qu, H.; Fang, Y.; Xu, T.; Wen, L. Evaluation of polyamidoamine (PAMAM)
dendrimers as drug carriers of anti-bacterial drugs using sulfamethoxazole (SMZ) as a model drug. Eur. J.
Med. Chem. 2007, 42, 93–98.
19. Felczak, A.; Wrońska, N.; Janaszewska, A.; Klajnert, B.; Bryszewska, M.; Appelhans, D.; Voit, B.; Różalska,
S.; Lisowska, K. Antimicrobial activity of poly(propylene imine) dendrimers. New J. Chem. 2012, 36, 2215–
2222.
20. Ortega, P.; Copa-Patiño, J.L.; Muñoz-Fernandez, M.A.; Soliveri, J.; Gomez, R.; de la Mata, F.J. Amine and
ammonium functionalization of chloromethylsilane-ended dendrimers. Antimicrobial activity studies.
Org. Biomol. Chem. 2008, 6, 3264–3269.
21. Fuentes-Paniagua, E.; Hernández-Ros, J.M.; Sánchez-Milla, M.; Camero, M.A.; Maly, M.; Pérez-Serrano, J.;
Copa-Patiño, J.L.; Sánchez-Nieves, J.; Soliveri, J.; Gómez, R.; et al. Carbosilane cationic dendrimers
synthesized by thiol-ene click chemistry and their use as antibacterial agents. RSC Adv. 2014, 4, 1256–1265.
22. Fuentes-Paniagua, E.; Hernández-Ros, J.M.; Sánchez-Milla, M.; Camero, M.A.; Maly, M.; Pérez-Serrano, J.;
Copa-Patiño, J.L.; Sánchez-Nieves, J.; Soliveri, J.; Gómez, R. et al. Structure-activity relationship study of
cationic carbosilane dendritic systems as antibacterial agents. RSC Adv. 2016, 6, 7022–7033.
23. Fernandez, J.; Acosta, G.; Pulido, D.; Malý, M.; Copa-Patiño, J.L.; Soliveri, J.; Royo, M.; Gómez, R.; Albericio,
F.; Ortega, P.; et al. Carbosilane Dendron-Peptide Nanoconjugates as Antimicrobial Agents. Mol. Pharm.
2019, 16, 2661–2674.
24. Janiszewska, J.; Swieton, J.; Lipkowski, A.W.; Urbanczyk-Lipkowska, Z. Low molecular mass peptide
dendrimers that express antimicrobial properties. Bioorg. Med. Chem. Lett. 2003, 13, 3711–3713.
25. Janiszewska, J.; Urbanczyk-Lipkowska, Z. Synthesis, antimicrobial activity and structural studies of low
molecular mass lysine dendrimers. Acta Biochim. Polonica 2006, 53, 77–82.
26. Klajnert, B.; Janiszewska, J.; Urbanczyk-Lipkowska, Z.; Bryszewska, M.; Shcharbin, D.; Labieniec, M.
Biological properties of low molecular mass peptide dendrimers. Int. J. Pharm. 2006, 309, 208–217.
27. Lind, T.K.; Zielińska, P.; Wacklin, H.P.; Urbańczyk-Lipkowska, Z.; Cárdenas, M. Continuous Flow Atomic
Force Microscopy Imaging Reveals Fluidity and Time-Dependent Interactions of Antimicrobial Dendrimer
with Model Lipid Membranes. ACS Nano 2014, 8, 396–408.
28. Stach, M.; Siriwardena, T.N.; Köhler, T.; van Delden, C.; Darbre, T.; Reymond, J.-L. Combining Topology
and Sequence Design for the Discovery of Potent Antimicrobial Peptide Dendrimers against Multidrug-
Resistant Pseudomonas aeruginosa. Ang. Chem. Int. Ed. 2014, 53, 12827–12831.
29. Michaud, G.; Visini, R.; Bergmann, M.; Salerno, G.; Bosco, R.; Gillon, E.; Richichi, B.; Nativi, C.; Imberty, A.;
Stocker, A.; et al. Overcoming antibiotic resistance in Pseudomonas aeruginosa biofilms using glycopeptide
dendrimers. Chem. Sci. 2016, 7, 166–182.
30. Bergmann, M.; Michaud, G.; Visini, R.; Jin, X.; Gillon, E.; Stocker, A.; Imberty, A.; Darbre, T.; Reymond, J.-
L. Multivalency effects on Pseudomonas aeruginosa biofilm inhibition and dispersal by glycopeptide
dendrimers targeting lectin LecA. Org. Biomol. Chem. 2016, 14, 138–148.
31. Siriwardena, T.N.; Stach, M.; He, R.; Gan, B.-H.; Javor, S.; Heitz, M.; Ma, L.; Cai, X.; Chen, P.; Wei, D.; et al.
Lipidated Peptide Dendrimers Killing Multidrug-Resistant Bacteria. J. Am. Chem. Soc. 2018, 140, 423–432.
32. Mishra, M.K.; Kotta, K.; Hali, M.; Wykes, S.; Gerard, H.C.; Hudson, A.P.; Whittum-Hudson, J.A.; Kannan,
R.M. PAMAM dendrimer-azithromycin conjugate nanodevices for the treatment of Chlamydia trachomatis
infections. Nanomed.-Nanotech. Biol. Med. 2011, 7, 935–944.

Molecules 2020, 25, 1389
12 of 13
33. Wong, P.T.; Tang, S.; Mukherjee, J.; Tang, K.; Gam, K.; Isham, D.; Murat, C.; Sun, R.; Baker, J.R., Jr.; Choi,
S.K. Light-controlled active release of photocaged Ciprofloxacin for lipopolysaccharide-targeted drug
delivery using dendrimer conjugates. Chem. Commun. (Cambridge UK) 2016, 52, 10357–10360.
34. Galdiero, S.; Falanga, A.; Cantisani, M.; Tarallo, R.; Elena Della Pepa, M.; D’Oriano, V.; Galdiero, M.
Microbe-Host Interactions: Structure and Role of Gram-Negative Bacterial Porins. Curr. Protein Pept. Sci.
2012, 13, 843–854.
35. Aguilella, V.M.; Queralt-Martín, M.; Alcaraz, A. Bacterial porins. In Electrophysiology of Unconventional
Channels and Pores; Delcour, H.A.; Springer International Publishing: Cham, Albania, 2015, pp. 101–121.
36. Tillotson, G.S. Quinolones: Structure-activity relationships and future predictions. J. Med. Microbiol. 1996,
44, 320–324.
37. Ficker, M.; Paolucci, V.; Christensen, J.B. Improved large-scale synthesis and characterization of small and
medium generation PAMAM dendrimers. Can. J. Chem. 2017, 95, 954–964.
38. Pang, Y.; Wan, L.; Huang, G.; Zhang, X.; Jin, X.; Xu, P.; Liu, Y.; Han, M.; Wu, G.-P.; Ji, S. Controlling Block
Copolymer-Substrate Interactions by Homopolymer Brushes/Mats. Macromolecules 2017, 50, 6733–6741.
39. Pittelkow, M.; Lewinsky, R.; Christensen, J.B. Selective synthesis of carbamate protected polyamines using
alkyl phenyl carbonates. Synthesis-Stuttgart 2002, 2195–2202.
40. Pittelkow, M.; Lewinsky, R.; Christensen, J.B. Mono Carbamate Protection of Aliphatic Diamines Using
Alkyl Phenyl Carbonates (2-Aminoethyl) carbamic acid tert-butyl ester Org. Synth. 2007, 84, 209–214.
41. Sølvhøj, A.B.; Tortzen, C.; Christensen, J.B. Monoprotection of Triamines with Alkyl Phenyl Carbonates.
Org. Prep. Proc. Int. 2012, 44, 397–400.
42. Pittelkow, M.; Christensen, J.B. Convergent Synthesis of Internally Branched PAMAM Dendrimers. Org.
Lett. 2005, 7, 1295–1298.
43. McNamara, P.J. Genetic manipulation of Staphylococcus aureus. In Staphylococcus Molecular Genetics;
Lindsay, J.A.; Caister Academic Press: Norfolk, UK, 2008; pp. 89–129.
44. O’Neill, A.J. Staphylococcus aureus SH1000 and 8325-4: Comparative genome sequences of key laboratory
strains in staphylococcal research. Lett. Appl. Microbiol. 2010, 51, 358–61.
45. Sahm, D.F.; Kissinger, J.; Gilmore, M.S.; Murray, P.R.; Mulder, R.; Solliday, J.; Clarke, B. In vitro
susceptibility studies of vancomycin-resistant Enterococcus faecalis. Antimicrob. Agents Chemother. 1989, 33,
1588–1591.
46. Paulsen, I.T.; Banerjei, L.; Myers, G.S.; Nelson, K.E.; Seshadri, R.; Read, T.D.; Fouts, D.E.; Eisen, J.A.; Gill,
S.R.; Heidelberg, J.F.; et al. Role of mobile DNA in the evolution of vancomycin-resistant Enterococcus
faecalis. Science 2003, 299, 2071–2074.
47. Richardson, E.J.; Limaye, B.; Inamdar, H.; Datta, A.; Manjari, K.S.; Pullinger, G.D.; Thomson, N.R.; Joshi,
R.R.; Watson, M.; Stevens, M.P. Genome sequences of Salmonella enterica serovar Typhimurium,
Choleraesuis, Dublin, and Gallinarum strains of well-defined virulence in food-producing animals. J.
Bacteriol. 2011,193, 3162-3163.
48. Cramariuc, O.; Rog, T.; Javanainen, M.; Monticelli, L.; Polishchuk, A.V.; Vattulainen, I.; Mechanism for
translocation of fluoroquinolones across lipid membranes. Biochim. Biophys. Acta-Biomem. 2012, 1818, 2563–
2571
49. Berlanga, M.; Montero, M.T.; Hernandez-Borrell, J.; Vinas, M. Influence of the cell wall on Ciprofloxacin
susceptibility in selected wild-type Gram-negative and Gram-positive bacteria. Int. J. Antimicrobial Agents
2004, 23, 627–630.
50. Ricci,V.; Coldham, N.C.; Piddock, L.J.V.; Buckley, A.; Tzakas, P. Ciprofloxacin-Resistant Salmonella enterica
Serovar Typhimurium Strains Are Difficult To Select in the Absence of AcrB and TolC. Antimicrob. Agents
Chemother. 2006, 50, 38–42.
51. Ricci, V.; Paddock, L.V.J. Ciprofloxacin selects for multidrug resistance in Salmonella enterica serovar
Typhimurium mediated by at least two different pathways. J. Antimicrob. Chemother. 2009, 63, 909–916.
52. Stover, C.K.; Pham, X.Q.; Erwin, A.L.; Mizoguchi, S.D.; Warrener, P.; Hickey, M.J.; Brinkman, F.S.L.;
Hufnagle, W.O.; Kowalik, D.J.; Lagrou, M.; et al. Complete genome sequence of Pseudomonas aeruginosa
PAO1, an opportunistic pathogen. Nature 2002, 406, 959–964.
53. Klockgether, J. Genome Diversity of Pseudomonas aeruginosa PAO1 Laboratory Strains. J. Bacteriol. 2010, 192,
1113–1121.
54. Chapman, J.S.; Georgopapadakou, N.H. Routes of Quinolone Permeation in Escherichia coli. Antimicrob.
Agents Chemother. 1988, 32, 438–442.

Molecules 2020, 25, 1389
13 of 13
55. Hirai, K.; Aoyama, H.; Irikura, T.; Iyobe, S.; Mitsuhashi, S.; Differences in Susceptibility to Quinolones of
Outer-Membrane Mutants of Salmonella Typhimurium and Escherichia coli. Antimicrob. Agents Chemother.
1986, 29, 535–538.
56. Nikaido, H. Porins and Specific Diffusion Channels in Bacterial Outer Membranes. J. Biol. Chem. 1994, 269,
3905–3908.
57. Chevalier, S.; Bouffartigues, E.; Bodilis, J.; Maillot, O.; Lesouhaitier, O.; Feuilloley, M.G.J.; Orange, N.;
Dufour, A.; Cornelis, P.; Structure, function and regulation of Pseudomonas aeruginosa porins. FEMS
Microbiol. Rev. 2017, 41, 698–722.
58. Fabrega, A.; Madurga, S.; Giralt, E.; Vila, J. Mechanisms of action and resistance to quinolones. Microb.
Biotechnol. 2009, 2, 40–61.
59. Idowu, T.; Schweizer, F. Ubiquitous nature of fluoroquinolones: The oscillation between antibacterial and
anticancer activities. Antibiotics 2017, 6, 26, doi:10.3390/antibiotics6040026.
60. Calabretta, M.K.; Kumar, A.; McDermott, A.M.; Cai, C. Antibacterial activities of poly(amidoamine)
dendrimers terminated with amino and poly(ethylene glycol) groups. Biomacromol. 2007, 8, 1807–1811.
61. Lopez, A.I.; Reins, R.Y.; McDermott, A.M.; Trautner, B.W.; Cai, C. Antibacterial activity and cytotoxicity of
PEGylated poly(amidoamine) dendrimers. Mol. Biosys. 2009, 5, 1148–1156.
62. Gholami, M.; Mohammadi, R.; Arzanlou, M.; Dourbash, F.A.; Kouhsari, E.; Majidi, G.; Mohseni, S.M.;
Nazari, S. In vitro antibacterial activity of poly (amidoamine)-G7 dendrimer. BMC Infect. Dis. 2017, 17, 395,
doi:10.1186/s12879-017-2513-7.
63. Fox, L.J.; Richardson, R.M.; Briscoe, W.H. PAMAM dendrimer—cell membrane interactions. Adv. Colloid
Interface Sci. 2018, 257, 1–18.
64. Oki, A.; Seidman, D.; Lacina III, M.G.; Mishra, M.K.; Kannan, R.M.; Yang, H.; Carlyon, J.A. Dendrimer-
enabled transformation of Anaplasma phagocytophilum. Microbes Infect. 2015, 17, 817–822.
65. Wrońska, N.; Majoral, J.P.; Appelhans, D.; Bryszewska, M.; Lisowska, K. Synergistic effects of
anionic/cationic dendrimers and levofloxacin on antibacterial activities. Molecules 2019, 24, 2894;
doi:10.3390/molecules24162894.
Sample Availability: Samples of the compounds are available from the authors.
© 2020 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC BY) license (http://creativecommons.org/licenses/by/4.0/).
