would be Qmax = nF(3600M) 1 = 162.8 mA h g , where n is
1
ther polymer matrices nor liquid electrolytes. Alterna-
the number of Li+ ions in moles, F is the Faraday constant
= 96485 s A mol , and M is the molar mass of (Li2Fe)SeO =
1
2
3
4
tively, the recently reported solid-state electrolyte, involv-
ing Li-glass,26 can be used between the anode and the cath-
ode.
1
1
164.69 g mol . By the same calculation, (Li2Fe)SO theoret-
ically reaches even higher values of 227 mA h g (Figure
1
5
6
7
8
S10, Supporting Information). This can be compared with
1
experimental (theoretical) values of 160 (274) mA h g for
Li1‒xCoO2.24 The reason for presuming the stability of 50 %
delithiated (LiFe)ChO ( = vacancy, Ch = S, Se) is the ex-
istence of cation vacant (Fe2)SeO,19 where one third of the
cations are missing without crystal structure break-down.
Performed charges/discharges indicate that about 3/4 of
the theoretical charge was already obtained for (Li2Fe)SeO:
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
1
1
120 mA h g at a rate of about 30 mA g = 0.25C (Figure S9,
Supporting Information). The size of the atomic lattice
(unit cell parameter a) does not change significantly for a
charged (delithiated) material (Figure S11, Supporting In-
formation), which is a good indication of advantageous,
negligible lattice strain (volume change) for charge/dis-
charge processes.
Figure 5. Li+ migration paths in (a) olivine LiFePO4, (b)
delafossite LiCoO2, (c) spinel Li2Mn2O4, (d) anti-perovskite
(Li2Fe)ChO (Ch = S, Se), and (e) anti-perovskite (Li2Fe)SeO
with refined Li split-positions. All anions have been omitted
for clarity and the shortest distances (in Å) between two adja-
cent Li-sites are marked. Partial occupied sites are indicated
with corresponding filling of atom spheres.
4. Discussions
There are further promising Li-battery cathode materials
that are still being optimized. For example, LixV2O5, where
x can be even up to 3,27 has a very high charge density but
low charge rates, which were improved by increasing the
active surface28 or implementing it in a glassy composite.29
Unfortunately, the high charge capacity can only be re-
tained over few charge/discharge cycles. Moreover, vana-
dium is relatively expensive and its oxides are harmful to
the environment. In contrast, both Li2MnO330 and FeF331 are
environmentally viable and are also candidates for the use
as battery cathodes due to low costs and high energy den-
sities. However, both compounds suffer from strongly fad-
ing charge capacities during charge/discharge cycling, de-
spite the extensive topology optimizations, e.g. nano-wires
of FeF332 and nano-structured Li2MnO3.33 In contrast, the
cubic title compounds exhibit only faint capacity loss dur-
ing 80 charge/discharge cycles at high rates. However,
even longer experiments have to be performed to establish
the long-term stability of anti-perovskite cathodes.
To estimate the Goldschmidt tolerance factor13 for the
two cubic title compounds, an average ionic radius was as-
sumed for the (Li2Fe)-site. The calculated tolerance factors
and the ideal cubic cell parameters are smaller than obser-
vations (Figure S12, Supporting Information). This suggests
relatively large voids for the cations to occupy and agrees
with the extraordinary Li migration rate and thermal
atomic displacements in crystal structure descriptions.
As compared to delafossites LiTMO2 (TM = Co,6 Mn,7
Ni), the cubic anti-perovskite title compounds have +2
pristine oxidation states of Fe while TM is +3 in delafos-
sites. This lowers the work potential window for anti-per-
ovskite cathodes, and standard battery constituents re-
main stable: the anti-perovskites can be charged/dis-
charged without destroying anodes or electrolytes. This is
advantageous in comparison with high-voltage cathodes,
like Li1+xMn2O4,8 where a thermal run-away, due to over
voltage, decomposes the fluorine based electrolytes, which
are discussed as potential hazards for users and environ-
ment.25 Nevertheless, the working voltage of anti-perov-
skite batteries can be designed by selecting another anode
materials instead of graphite; this might increase the bat-
tery voltage and, thus, offer even higher energy densities.
In conclusion, our novel anti-perovskites can be readily
produced, are environmentally friendly, and perform well
enough as Li-battery cathodes to compete with Li1‒xCoO2.
(Li2Fe)ChO (Ch = S, Se) can be charged at high rates and
the material cost for (Li2Fe)SO is reduced by about 95 % in
comparison to Li1‒xCoO2. Hence, at viable costs and with
less environmental issues, the cubic anti-perovskite title
compounds can be used in larger energy storage stations
or power vehicles safely.
The cubic title compounds allow for isotropic 3D Li+ mi-
gration, which is similar to the situation in Li1+xMn2O4,8 but
more advantageous than Li+ migrations in layers of Li1‒
‒
5
x(Co,Mn)O26 7 and in columns of Li1‒xFePO4 (Figure 5). The
isotropic Li migration in investigated anti-perovskites is
stable against minor crystallographic faults, in contrast to
the high fault-sensitivity in Li1‒xFePO4.9 Moreover, due to
the structural similarities, an all-solid battery is possible
with any of the cubic title compounds as cathode, Li3XO (X
