Article
BULLETIN OF THE
ISSN (Print) 0253-2964 | (Online) 1229-5949
KOREAN CHEMICAL SOCIETY
Calcd for C44H77B10N: C, 72.57; H, 10.66; N, 1.92%.
Found: C, 72.21; H, 10.81, N, 1.98%.
[Bu4N][1-(Mes2B)-4-(8-iPr-7,8-nido-C2B9H10)-5-
1
MeC6H3] (nido-3). Yield = 59%. H NMR (acetone-d6): δ
7.26 (d, J = 7.8 Hz, 1H), 7.21 (s, 1H), 7.11–7.04 (m, 1H),
6.82 (s, 4H), 3.50–1.50 (br, 9H, B-H), 3.40 (t, J = 8.6 Hz,
8H), 2.49 (s, 3H), 2.28 (s, 6H, Mes-CH3), 1.98 (s, 12H,
Mes-CH3), 1.81 (quint, J = 7.2 8H), 1.43 (sext, J = 7.5 Hz,
8H), 1.21 (sept, J = 6.6 Hz, 1H), 0.99 (t, J = 7.2 Hz, 12H),
0.95 (d, J = 2.1 Hz, 3H),), 0.58 (t, J = 8.3 Hz, 3H), −2.60
(br s, 1H, B-H-B). 13C NMR (acetone-d6): δ 146.2, 142.6,
141.2, 140.5, 138.8, 134.7, 130.1, 128.9, 59.4 (NBu4),
26.2, 25.3, 24.4 (NBu4), 23.7, 23.6, 21.2, 20.4 (NBu4),
13.8 (NBu4). 11B NMR (acetone-d6): δ 78.3 (br s), −7.9
(2B), −14.2 (1B), −15.9 (2B), −18.6 (2B), −32.8 (1B),
−35.1 (1B). mp = 181ꢀC. Anal. Calcd for C46H81B10N: C,
73.06; H, 10.80; N, 1.85%. Found: C, 73.12; H,
10.69; N, 1.88%.
Chart 1. Meta- and para-nido-carborane-substituted triarylboranes.
those of the unsubstituted conjugates, verifying the rational-
ity of the proposed approach.
Experimental Section
General Synthesis of p-Nido-Carborane-Substituted
Triarylboranes, nido-1-3. Closo-carborane compounds
(0.2 mmol) and tetrabutylammonium fluoride (n-Bu4NF,
TBAF) (1.0 mmol) were combined in tetrahydrofuran
(THF) (20 mL) and the mixture was heated to reflux for
4 days. The mixture was cooled down to room temperature
and the solvent was evaporated. The remaining residue was
subjected to column chromatography on alumina using
CH2Cl2/hexane (1:1, v/v) followed by acetone to afford a
white powder of nido-carborane derivatives (nido-1-3). The
product was further recrystallized from CH2Cl2/hexane.
[Bu4N][1-(Mes2B)-4-(8-H-7,8-nido-C2B9H10)-5-
Photophysical Measurements. Ultraviolet/Visible (UV/
Vis) absorption and photoluminescence (PL) spectroscopic
studies were performed on a Varian Cary 100 and FS5
spectrophotometer, respectively. Photoluminescence quan-
tum yields (PLQYs, ΦPL) of all solution and film samples
were measured on an absolute PL quantum yield spectro-
photometer (Quantaurus-QY C11347-11, Hamamatsu Pho-
tonics, Japan) equipped with a 3.3 inch integrating sphere.
Transient PL decay was recorded on a FS5 spectrophotom-
eter (Edinburgh Instruments, Livingston, UK) using a time-
correlated single-photon counting (TCSPC) method (EPL-
375 ps pulsed diode laser as a light source).
1
MeC6H3] (nido-1). Yield = 65%. H NMR (acetone-d6): δ
7.25 (d, J = 7.8 Hz, 1H), 7.18 (s, 1H), 7.08 (d, J = 7.7 Hz,
1H), 6.82 (s, 4H), 3.5–1.5 (br, 9H, B-H), 3.47 (t, J = 9 Hz,
8H), 2.40 (s, 3H), 2.28 (s, 6H), 1.98 (s, 12H), 1.84 (quint,
J = 9, 8H), 1.68 (s, 1H, CCb-H),1.44 (sext, J = 7.8, Hz,
8H), 0.99 (t, J = 7.5 Hz, 12H), −2.53 (br s, 1H, B-H-B).
13C NMR (acetone-d6): δ 149.9, 140.3, 138.7, 138.1,
137.4, 133.1, 128.1, 128.0, 58.4 (Bu4N), 23.5 (Bu4N),
22.8, 20.3, 19.6, 19.5 (Bu4N), 13.0 (Bu4N). 11B NMR (ace-
tone-d6): δ 79.1 (br s), −8.2 (1B), −9.7 (1B), −13.0 (1B),
−15.4 (1B), −18.1 (2B), −22.9 (1B), −32.4 (1B), −35.2
(1B). mp = 228ꢀC. Anal. Calcd for C43H75B10N: C,
72.32; H, 10.59; N, 1.96%. Found: C, 72.16; H,
10.83, N, 2.01%.
Results and Discussion
Synthesis and Characterization. The synthesis of p-nido-
carborane-triarylborane conjugates (nido-1-3) was achieved
using the analogous methods established previously for the
meta-systems (Scheme 1).32,33 To investigate the substitu-
ent effect on the photophysical properties, we also intro-
i
duced various 8-R groups such as H, Me, and Pr groups
into the 8-position of the nido-carborane cage. The car-
borane cage of the corresponding closo-1-3 was
deboronated with TBAF in refluxing THF, producing nido-
1-3 in good yields (59%–83%, see the SI for details). The
synthesis of closo-1-3 compounds proceeded with slightly
different routes depending on the 8-R group. The 8-H
substituted closo-1 was prepared by the cage forming reac-
tion between (4-ethynylphenyl)dimesitylborane (1b) and
decaborane (B10H14) in the presence of excess Et2S in
refluxing toluene. In the synthesis of closo-2 and -3, a
BMes2 moiety was finally introduced into the 4-
[Bu4N][1-(Mes2B)-4-(8-Me-7,8-nido-C2B9H10)-5-
1
MeC6H3] (nido-2). Yield = 83%. H NMR (acetone-d6): δ
7.25–7.19 (m, 2H), 7.10 (d, J = 7.8 Hz, 1H), 6.82 (s, 1H)
3.5–1.5 (br, 9H, B-H), 3.45 (t, J = 8.9 Hz, 8H), 2.40 (s,
3H), 2.28 (s, 6H), 1.98 (s, 12H), 1.81 (quint, J = 8.3, 8H),
1.45 (sext, J = 7.5, Hz, 8H), 1.01 (s, 3H, CCb-CH3), 0.98 (t,
J = 7.3 Hz, 12H), −2.45 (br s, 1H, B-H-B). 13C NMR (ace-
tone-d6): δ 147.6, 140.4, 139.5, 138.0, 137.1, 132.9, 129.5,
128.1, 58.5 (Bu4N), 23.5 (Bu4N), 22.7, 22.5, 21.0, 20.4,
19.5 (Bu4N), 13.0 (Bu4N). 11B NMR (acetone-d6): δ 78.3
(br s), −6.5 (1B), −9.9 (2B), −13.6 (1B), −15.3 (1B),
−19.7 (2B), −33.2 (1B), −35.6 (1B). mp = 228ꢀC. Anal.
i
bromobenzene intermediates having an 8-R (R = Me, Pr)
substituted closo-carborane (2b and 3b), which could be
obtained via deprotonation of 8-H in 2a with NaH,
followed by reaction with a respective alkyl iodide.
The formation of the closo- and nido-compounds was
identified by nuclear magnetic resonance (NMR)
Bull. Korean Chem. Soc. 2020
