Evaluation of the anti-inflammatory effect of chalcone and chalcone analogues in a Zebrafish model

Article abstract of DOI:10.3390/molecules18022052

The aim of this study was to investigate novel chalcones with potent anti-inflammatory activities in vivo. Chalcone and two chalcone analogues (compound 5 and 9) were evaluated using a caudal fin-wounded transgenic zebrafish line Tg(mpx:gfp) to visualize the effect of neutrophil recruitment dynamically. Results showed that treatment with compound 9 not only affected wound-induced neutrophil recruitment, but also affected Mpx enzymatic activity. Moreover, protein expression levels of pro-inflammatory factors (Mpx, NFκB, and TNFα) were also regulated by compound 9. Taken together, our results provide in vivo evidence of the anti-inflammatory effects of synthesized chalcone analogues on wound-induced inflammation.

Full text of DOI:10.3390/molecules18022052

Molecules 2013, 18, 2052-2060; doi:10.3390/molecules18022052
OPEN ACCESS
molecules
ISSN 1420-3049
www.mdpi.com/journal/molecules
Article
Evaluation of the Anti-Inflammatory Effect of Chalcone and
Chalcone Analogues in a Zebrafish Model
Yau-Hung Chen 1,*, Wei-Hua Wang 1, Yun-Hsin Wang 2, Zi-Yu Lin 1, Chi-Chung Wen 3 and
Ching-Yuh Chern 4,*
1
Department of Chemistry, Tamkang University, 151, Yingzhuan Road, Danshui Dist.,
New Taipei City 25137, Taiwan; E-Mails: faoxmax@hotmail.com (W.H.W.);
shes060215@yahoo.com.tw (Z.Y.L.)
2
Division of Basic Research, Koo Foundation Sun Yat-Sen Cancer Center, Taipei 11259, Taiwan;
E-Mail: yunhsin_wkimo@yahoo.com.tw
3
Department of Mathematics, Tamkang University, Danshui Dist., New Taipei City 25137, Taiwan;
E-Mail: ccwen@mail.tku.edu.tw
4
Department of Applied Chemistry, National Chia-Yi University, Chia-Yi 60004, Taiwan
* Authors to whom correspondence should be addressed; E-Mails: yauhung@mail.tku.edu.tw (Y.-H.C.);
cychern@mail.ncyu.edu.tw (C.-Y.C.); Tel.: +886-2-26215656 (ext. 3009); Fax: +886-2-26209924.
Received: 18 December 2012; in revised form: 29 January 2013 / Accepted: 29 January 2013 /
Published: 5 February 2013
Abstract: The aim of this study was to investigate novel chalcones with potent
anti-inflammatory activities in vivo. Chalcone and two chalcone analogues (compound 5
and 9) were evaluated using a caudal fin-wounded transgenic zebrafish line “Tg(mpx:gfp)”
to visualize the effect of neutrophil recruitment dynamically. Results showed that treatment
with compound 9 not only affected wound-induced neutrophil recruitment, but also
affected Mpx enzymatic activity. Moreover, protein expression levels of pro-inflammatory
factors (Mpx, NFκB, and TNFα) were also regulated by compound 9. Taken together, our
results provide in vivo evidence of the anti-inflammatory effects of synthesized chalcone
analogues on wound-induced inflammation.
Keywords: anti-inflammation; chalcone; fin; zebrafish

Molecules 2013, 18
2053
1. Introduction
Chalcone (1,3-diphenyl-2-propen-1-one), is a phenolic compound abundant in vegetables. Natural
occurring chalcones as well as synthetic chalcone analogues have demonstrated many pharmaceutical
effects, including anti-inflammatory, anti-oxidant, anti-parasite, and anti-tumor activities [1–7].
Recently studies revealed that chalcones (chalcone and synthetic chalcone analogues) can inhibit NO
synthesis and inducible NO synthetase (iNOS) and cycloxygenase 2 (COX-2) protein expression in
lipopolysaccharide (LPS)-stimulated cells, and indicated the importance of chalcones as anti-inflammatory
agents [8]. However, current knowledge regarding the anti-inflammatory effects of chalcones in
vertebrates has all been reported in vitro. Thus, it is essential to establish an effective animal model to
study the in vivo the anti-inflammatory effects of chalcones.
Inflammation is a complex biological event of a tissue response to a harmful stimulus (bacterial
infection, burn or wound, for example). Acute inflammation usually involves dynamic regulation of
pro-inflammatory mediators (Mpx, NFκB, TNFα) and the recruitment of white blood cells to harmed
sites [9]. Neutrophils are one type of white blood cells which can migrate towards the harmed sites and
are considered as the hallmark of acute inflammation [9]. For this reason, monitoring the number and
the migration activity of neutrophils is an efficient way to evaluate acute inflammatory responses.
The optical transparency of zebrafish embryos allows noninvasive and dynamic imaging of the
inflammation process in vivo. Especially, a transgenic zebrafish line Tg (mpx:gfp) expressing green
fluorescent protein (GFP) under the control of neutrophil-specific mpx promoter enables us to count
the number and to monitor the migration activity of neutrophils more efficiently [10]. In this study, a
wounded zebrafish model was used to assess the anti-inflammatory effects of chalcones (chalcone and
chalcone analogues) on wound-induced inflammation in vivo. We also evaluated the Mpx expression
by histochemical staining, and examined the protein levels of three evolutionarily conserved
pro-inflammatory factors (Mpx, NFκB, and TNFα) upon chalcones treatment.
2. Results and Discussion
2.1. Chemistry
For this study, we have developed simple methods for the synthesis of chalcone derivatives 5 and 9
from O-isoproxyacetophenones 2 and 7. These two compounds are known compounds [11,12]. The
aldol intermediates were obtained by using the similar procedure described previously [13].
Unfortunately, the reaction yield using this method was very low (~15%). Yields didn’t improve on
using different bases (KOH/NaOH). It is possible that intramolecular hydrogen bonding such as that
observed in 1 or 6 prevents the aldol reaction. Therefore, O-isoproxyacetophenones 2 and 7 were used
as the starting material for our synthesis. The preparation of O-isoproxyacetophenones 2 and 7 was
straightforward. Acetophenones 1 and 6 were protected with isopropyl bromide and potassium
carbonate in DMF in excellent yield. (Figure 1, Schemes 1 and 2) The isolated product 2 and 7 were
then reacted with appropriate benzaldehydes with 5N KOH whereupon intermediates 4 and 8 were
isolated in 76% and 90% yields. The O-isopropyl ether was removed quantitatively with BCl3 to afford
the target chalcones 5 and 9. Inspection of the 1H-NMR spectra of chalcones clearly indicated that they
were trans configured (JHH = 15–16 Hz).

Molecules 2013, 18
2054
Figure 1. Synthesis of compound 5 and compound 9.
2.2. Effects of Chalcones on Wound-Induced Neutrophil Recruitment and Mpx Enzymatic Activity
We have previously developed a protocol to detect the level of wound-induced neutrophil
recruitment in transgenic zebrafish Tg (mpx:gfp) embryos [14]. The same protocol was employed to
evaluate the newly synthesized chalcone analogoes 5, and 9 with chalcone for comparison (Figure 2).
Figure 2. Schematic representation of experimental protocols performed in this study. Fins
of Tg(mpx:gfp) zebrafish embryos were amputated by 72 hpf, and were cultivated with
(chalcone, compound 5, and 9) or without chemicals (mock control) for 8 h. By 80 hpf,
embryos were collected for fluorescent recording, Mpx staining or western blotting
experiments. Structures of chalcone, compound 5 and compound 9 were listed in the bottom.
As shown in Figure 3, green fluorescent neutrophils (hereafter referred to as Mpx:GFP(+) cells)
tended to migrate toward the wound site upon fin amputation in wounded zebrafish (Figure 3A,
Mock). Upon treatment with 1 ppm of chalcone and compound 5 for 8 h, no obvious increase in
Mpx:GFP(+) cells was observed (Figure 3B,C) compared with the wounded mock control group
(Figure 3A). In contrast, the difference between the compound 9-treated group (Figure 3D) and
wounded mock control control (Figure 3A) was reduced. Statically, the ANOVA method was first
applied to examine the effect of treatment (‘Mock’, ‘chalcone’, ‘5’, ‘9’; n = 15) on the mean number of

Molecules 2013, 18
2055
Mpx. Of primary interest here is a test of the hypothesis of no difference in mean numbers of Mpx
between treatment groups. The test reports a p-value of 0.0007, indicating a highly significant
difference between treatment groups. To pinpoint which treatment means are significantly different
from each other, the Tukey-Kramer HSD test was further used for pairwise comparisons. Figure 3E
presents the mean numbers of Mpx and their 95% confidence intervals for four treatment groups. It
reports the mean numbers of Mpx for ‘Mock’, ‘chalcone’, ‘5’, ‘9’ groups are 26.93, 25.00, 26.64, and
17.21 with common stand error being 1.78, and also identified the mean number of Mpx for ‘Mock’
group differs significantly from the ‘9’ group at familywise error rate 0.05.
We further treated wounded zebrafish with different doses of compound 9, followed by statistical
analysis. The ANOVA method for examining the effect of compound 9 dose (‘0’, ‘0.1’, ‘0.5’ and ‘1’
ppm) on the mean number of Mpx reported a highly significant difference between compound 9
dosage groups (p-value < 0.0001). The Tukey-Kramer HSD test for pairwise comparisons of dosage
groups reported the mean numbers of Mpx (standard error, sample size) for four dose groups (‘0’,
‘0.1’, ‘0.5’ and ‘1’) are 25.21 (1.22, n = 14), 23.14 (1.22, n = 14), 18.00 (1.22, n = 14), and 15.14
(1.22, n = 14), respectively. Figure 4 presents the mean number of Mpx and their 95% confidence
interval for these dosage groups and concludes that the mean number of Mpx for ‘0.5’ and ‘1’ groups
differ significantly from the ‘0’ group at familywise error rate 0.05. These in vivo results demonstrated
that wound-induced neutrophil recruitment in living zebrafish was attenuated by chalcone analogue
(compound 9) treatment in a dose-dependent manner.
Figure 3. Myeloperoxidase (Mpx) expression in zebrafish larvae in response to wounding
or chalcones (chalcone, compound 5 and 9) treatment. (A–D) The distribution of
neutrophils in living Tg(mpx:gfp) zebrafish larvae using GFP fluorescence as a marker.
Dashed line outlines the region of caudal fin. (E) The Tukey-Kramer HSD reports the
mean numbers of Mpx and their 95% confidence intervals for four treatment groups
(‘Mock’, ‘chalcone’, ‘5’, ‘9’).
To further evaluate the effect of chalcone (chalcone, 5 and 9) treatment on Mpx enzymatic activity
in neutrophils, endogenous Mpx enzymatic activity in the zebrafish embryos derived from each
experimental group was observed by histochemical staining with peroxidase substrate benzidine.
Positively-stained cells [hereafter indicated as Mpx(+) cells] revealed endogenous Mpx enzymatic
activities in vivo and in situ. As shown in Figure 5A, an increased cell number of Mpx(+) was
observed in wounded zebrafish (Figure 5A, Mock), revealed an increase in Mpx enzymatic activity.
Upon compound 5 treatment, no evident decrease of the Mpx(+) cells was observed in compound

Molecules 2013, 18
2056
5-treated group (Figure 5B) versus mock control (Figure 5A). However, a decrease of the Mpx(+) cells
was observed both in chalcone and compound 9-treated group (Figure 5C,D, vs. 5A). Taken together,
we suggest that: (1) chalcone is able to attenuate endogenous Mpx enzymatic activity rather than the
wound-induced neutrophil recruitment in vivo; and (2), compound 9 is able to suppress Mpx enzymatic
activity as well as neutrophil recruitment.
Figure 4. The Tukey-Kramer HSD test reports the mean numbers of Mpx:GFP (+) and
their 95% confidence intervals for each group which were treated with different doses of
compound 9 (0, 0.1, 0.05 and 1 ppm).
Figure 5. Endogenous myeloperoxidase (Mpx) activity in zebrafish larvae in response to
wounding or chalcones (chalcone, compound 5 and 9) treatment. Fin-amputated zebrafish
embryos derived from the mock control (A) or the chemicals-treated groups (B–D) were
stained with benzidine dihydrochloride to visualize endogenous Mpx activities.

Molecules 2013, 18
2057
2.3. Molecular Mechanism of Anti-inflammatory Effects of Compound 9
To further investigate the molecular mechanism of anti-inflammatory effects of compound 9, we
examined the effects of compound 9 on Mpx, NFκB and TNFα at the protein level (Figure 6). The
protein expression level of Mpx in zebrafish larvae at 80-hpf (8 hours post-treatment) were detected by
whole-mount immunostaining using antibody against Mpx (Figure 6A,B). After fin amputation
followed by compound 9 treatment, Mpx expression appeared to decrease compared with mock control
(no-treatment) group (Figure 6A vs. 6B). These immunostaining results revealed that compound 9
slightly attenuated the protein expression of Mpx in wound-induced inflammation, which is consistent
with the above-mentioned Mpx enzymatic activity revealed by histochemical staining. On the other
hand, western blotting results revealed that the protein expression amount of NFκB and TNFα change
little, but amount of Mpx is reduced (Figure 6C). Taken together, our results suggested that the
anti-inflammatory effects of compound 9 on wound-induced inflammation were mediated through the
regulation of Mpx.
Figure 6. Effects of compound 9 on fin-amputated zebrafish larvae. Fin-amputated
zebrafish embryos derived from the mock control (A) or the compound 9-treated groups
(B) were stained with antibody against Mpx. (C) Results of western blot analysis of the
mock control and the compound 9-treated embryonic lysates using antibodies against Mpx,
NFκB, TNFα and GAPDH.
3. Experimental
3.1. General
Proton NMR spectra were recorded at 300 MHz Varian Mercury-300 NMR spectrometer. Carbon
NMR spectra were recorded at 75 MHz Varian Mercury-300 NMR spectrometer. Proton and carbon
chemical shifts are reported on the delta scale as parts per million (ppm) downfield from
tetramethylsilane (TMS) as internal reference. All reagents were used as obtained commercially.

Molecules 2013, 18
2058
3.2. Synthesis of New Chalcone Analogues
Synthesis procedure examples:
3-(4-Hydroxyphenyl)-1-(2-hydroxyphenyl)propenone (5).1H-NMR (CDCl3, 300MHz) δ: 13.96 (1H, s,
-OH), 7.93 (1H, d, J = 8.7 Hz), 7.90 (1H, d, J = 15.8 Hz), 7.57 (2H, d, J = 8.7 Hz), 7.52 (1H, d,
13
J = 15.8 Hz), 7.49 (1H, t, J = 8.7 Hz), 7.0–6.8 (4H, m); C-NMR (CDCl3, 75MHz) δ: 193.8, 163.5,
158.3, 145.4, 136.3, 130.8, 129.6, 124.6, 122.2, 118.8, 118.6, 116.1, 115.9
1-(2,6-Dihydroxy-4-methoxyphenyl)-3-phenylpropenone (9): 1H-NMR (d6-acetone, 300 MHz) δ: 12.07
(2H, bs, -OH), 8.25 (1H, d, J = 15.6Hz), 7.73 (1H, d, J = 15.6 Hz), 7.71–7.66 (2H, m), 7.46–7.40 (3H,
13
m), 6.04 (2H, s), 3.81 (3H, s); C-NMR (d6-acetone, 75MHz) : 193.4, 167.2, 165.4, 142.9, 136.4,
130.9, 129.8, 129.1, 128.3, 106.2, 94.6, 55.8
3.3. Zebrafish Larvae, Fin Amputation and Chalcones Treatment
Zebrafish larvae (wild-type, WT; AB strain) and Tg(mpx:gfp) were raised at 28.5 °C and staged
according to standard protocols [15,16]. Fin amputation was carried out by cutting out half of the
caudal fin as shown in Figure 2. Chalcone (C15H12O, Sigma-Aldrich), compound 5 and 9 were
dissolved in dimethylsulfoxide (DMSO) as stock solution (2,500 ppm), and diluted to 1 ppm for
treatment. Wounded zebrafish larvae were randomly divided into no-treatment “control” group
(Mock), chalcone, compound 5, and compound 9-“treated” group (chalcone, 5, 9). Each group was
exposed to DMSO (no treatment, Mock) or chalcones (chalcone, 5, 9) in the dark at 28.5 °C for
8 h (Figure 2).
3.4. Myeloperoxidase Staining, Antibody Labeling and Western Blotting
Myeloperoxidase staining and antibody labeling experiments were performed as previously
described with minor modifications [14,17–21]. Western blotting followed standard procedures except
for the use of antibodies against Mpx (AnaSpec), NFκB (AnaSpec), TNFα (AnaSpec) or GAPDH
(Santa Cruz) as primary antibodies.
3.5. Statistical Analysis
All analyses in this study were carried out according to Matlab software (version 7.7 R2008b). The
ANOVA (analysis of variance) test was applied to examine the effect of treatment (or dosage) on the
mean number of Mpx. The p-value reported by ANOVA method associates with the null hypotheses
that samples in all treatment (or dosage) groups are drawn from the same population. The Tukey-Kramer
HSD (honestly significant difference) test was further used to compare the population marginal mean
number of Mpx for each treatment (or dosage) group. A significance level 0.05 was used in all statistic
analyses and a familywise error rate 0.05 was controlled for Tukey-Kramer HSD test.

Molecules 2013, 18
2059
4. Conclusions
This zebrafish model of wound-induced inflammation can be readily applied to in vivo screening of
the therapeutic potential of anti-inflammatory compounds. This study suggested that some chalcones,
especially compound 9, may have the potential to be developed as an anti-inflammatory agent.
However, further studies are necessary to establish such as examination of the underlying molecular
mechanisms and direct targets at the transcriptional or post-transcriptional level in mammals.
Acknowledgments
We thank Stephen A. Renshaw (University of Sheffield, UK) for generously providing
Tg (mpx:gfp) zebrafish. This project was supported by the National Science Council
(NSC 100-2313-B-032-001).
References
1. Go, M.L.; Wu, X.; Liu, X.L. Chalcones: An update on cytotoxic and chemoprotective properties.
Curr. Med. Chem. 2005, 12, 483–499.
2. Kontogiorgis, C.; Mantzanidou, M.; Hadjipavlou-Litina, D. Chalcones and their potential role in
inflammation. Mini Rev. Med. Chem. 2008, 8, 1224–1242.
3. Kamal, A.; Ramakrishna, G.; Raju, P.; Viswanath, A.; Janaki Ramaiah, M.; Balakishan, G.;
Pal-Bhadra, M. Synthesis and anti-cancer activity of chalcone linked imidazolones.
Bioorg. Med. Chem. 2010, 20, 4865–4869.
4. Bashir, R.; Ovais, S.; Yaseen, S.; Hamid, H.; Alam, M.S.; Samim, M.; Singh, S.; Javed, K.
Synthesis of some new 1,3,5-trisubstituted pyrazolines bearing benzene sulfonamide as anticancer
and anti-inflammatory agents. Bioorg. Med. Chem. Lett. 2011, 21, 4301–4305.
5. Kumar, V.; Kumar, S.; Hassan, M.; Wu, H.; Thimmulappa, R.K.; Kumar, A.; Sharma, S.K.;
Parmar, V.S.; Biswal, S.; Malhotra, S.V. Novel chalcone derivatives as potent Nrf2 activators in
mice and human lung epithelial cells. J. Med. Chem. 2011, 54, 4147–4159.
6. Bukhari, S.N.A.; Jasamai, M.; Jantan, I. Synthesis and biological evaluation of chalcone
derivatives. Mini-Rev. Med. Chem. 2012, 12, 1394–1403.
7. Bukhari, S.N.A.; Jantan, I.; Jasamai, M. Anti-inflammatory trends of 1, 3-Diphenyl-2-propen-1-one
derivatives. Mini-Rev. Med. Chem. 2013, 13, 87–94.
8. Wu, J.; Lee, J.; Cai, Y.; Pan, Y.; Ye, F.; Zhang, Y.; Zhao, Y.; Yang, S.; Li, X.; Liang, G.
Evaluation and discovery of novel synthetic chalcone derivatives as anti-Inflammatory agents.
J. Med. Chem. 2011, 54, 8110–8123.
9. Witko-Sarsat, V.; Rieu, P.; Descamps-Latscha, B.; Lesavre, P.; Halbwachs-Mecarelli, L.
Neutrophils: Molecules, functions and pathophysiological aspects. Lab. Invest. 2000, 80, 617–653.
10. Renshaw, S.A.; Loynes, C.A.; Trushell, D.M.; Elworthy, S.; Ingham, P.W.; Whyte, M.K.
A transgenic zebrafish model of neutrophilic inflammation. Blood 2006, 108, 3976–3978.
11. Moorthy, N.S.H.N.; Singh, R.J.; Singh, H.P.; Gupta, S.D. Synthesis, biological evaluation and in
silico metabolic and toxicity prediction of some flavanone derivatives. Chem. Pharm. Bull. 2006,
10, 1384–1390.

Molecules 2013, 18
2060
12. Pouget, C.; Lauthier, F.; Simon, A.; Fagnere, C.; Basly, J.-P.; Delage, C.; Chulia, A.-J.
Flavonoids: Structural requirements for antiproliferative activity on breast cancer cells.
Bioorg. Med. Chem. Lett. 2001, 11, 3095–3097.
13. Chawla, H.M.; Chakrabarty, K. Dye-sensitized photo-oxygenation of chalcones. J. Chem. Soc.
Perkin Trans. I 1984, 1511–1513.
14. Liao, Y.F.; Chiou, M.C.; Tsai, J.N.; Wen, C.C.; Wang, Y.H.; Cheng, C.C.; Chen, Y.H.
Resveratrol treatment attenuates the wound-induced inflammation in zebrafish larvae through the
suppression of myeloperoxidase expression. J. Food Drug Anal. 2011, 19, 167–173.
15. Westerfield, M. The Zebrafish Book, 3rd ed.; University of Oregon Press: Eugene, OR,
USA, 1995.
16. Kimmel, C.; Ballard, W.W.; Kimmel, S.R.; Ullmann, B.; Schilling, T.F. Stages of embryonic
development in the zebrafish. Dev. Dyn. 1995, 203, 253–310.
17. Kaplow, L.S. Simplified myeloperoxidase stain using benzidine dihydrochloride. Blood 1965, 26,
215–219.
18. Chen, Y.H.; Lin, J.S. A novel zebrafish mutant with wavy-notochord: An effective biological
index for monitoring the copper pollution of water from natural resources. Environ. Toxicol. 2011,
26, 103–109.
19. Chou, C.Y.; Hsu, C.H.; Wang, Y.H.; Chang, M.Y.; Chen, L.C.; Cheng, S.C.; Chen, Y.H.
Biochemical and structural properties of zebrafish Capsulin produced by Escherichia coli.
Protein Expr. Purif. 2011, 75, 21–27.
20. Lee, G.H.; Chang, M.Y.; Hsu, C.H.; Chen, Y.H. Essential roles of basic helix-loop-helix
transcription factors, Capsulin and Musculin, during craniofacial myogenesis of zebrafish.
Cell. Mol. Life Sci. 2011, 68, 4065–4078.
21. Ding, Y.J.; Chen, Y.H. Developmental nephrotoxicity of aristolochic acid in a zebrafish model.
Toxicol. Appl. Pharmacol. 2012, 261, 59–65.
Sample Availability: Samples of the compound 5 and 9 are available from the authors.
© 2013 by the authors; licensee MDPI, Basel, Switzerland. This article is an open access article
distributed under the terms and conditions of the Creative Commons Attribution license
(http://creativecommons.org/licenses/by/3.0/).
