enantiopure CF7 and racemic CF8 are good gelators, while racemic
CF7 and enantiopure CF8 are too crystalline. According to the
model derived from the VCD results, the cyclohexyl rings of
gelators were stacked as a central core with all trans-perfluorinated
chains ejecting outwards. Thus the observed reversal of chirality
effects might be rationalized in terms of the terminal effects of
perfluorinated chains on the inter-aggregate interactions. The main
influence of the elongation of one –CF2– unit was the decrease in
cohesion energy among the racemic aggregates, leading to the
increase in gelation ability of racemic CF8. Similar effects of the
end group of an alkyl chain on cohesion energy were reported
previously.12
Notes and references
1 Low Molecular Mass Gelators Design, Self-Assembly, Function,
ed. F. Fages, Springer, Berlin, Heidelberg, 2005; Molecular Gels,
ed. R. G. Weiss and P. Terech, Springer, Netherlands, 2006;
A. Ajayaghosh and V. K. Praveen, Acc. Chem. Res., 2007, 40, 644;
J. H. van Esch and B. L. Feringa, Angew. Chem., Int. Ed., 2000,
39, 2263; P. Terech and R. G. Weiss, Chem. Rev., 1997, 97, 3133;
M.-O. M. Piepenbrock, G. O. Lyoyd, N. Clarke and J. W. Steed,
Chem. Rev., 2010, 110, 1960; T. Tachibana, T. Mori and K. Hori,
Nature, 1979, 278, 578; L. Frkanec and M. Zinic
2010, 46, 522.
2 J. Mkarevic, M. Jokic
M. Zinic, Chem.–Eur. J., 2003, 9, 5567; V. Caplar, L. Frkanec,
N. S. Vujicic and M. Zinic, Chem.–Eur. J., 2010, 16, 3066;
V. Caplar, M. Zinic, J.-L. Pozzo, F. Fages, G. M. Gumdert and
´
, Chem. Commun.,
´
, Z. Raza, Z. Stefanic, B. Kojic-Prodic and
´ ´ ´ ´
´
´
´
´
Another notable feature in CF8 was the formation of
helically coiled fibrils at ee = 0.2 (see ESIw)–0.4 (Fig. 2(c)
and (d)). Helicity with a pitch less than 300 nm was related to
the absolute configuration of the major enantiomeric components.
Therefore the results are considered to be an example of the
Majority Rule of chirality amplification.13 According to the PXRD
results, the characteristic peaks due to racemic aggregates disap-
peared rapidly with the increase in ee, while the peaks due to
homochiral aggregates maintained their intensity throughout the
range of ee = 0.2–0.8. We noticed that the coiled fibrils existed
predominantly at ee = 0.4, at which the racemic peak nearly
disappeared. In other words, the generation of helically coiled
fibrils was realized by the disappearance of racemic aggregates
in the presence of a surplus amount of homochiral aggregates.
In the present case, it is noted that no helical fibril was formed
at ee larger than 0.8.
F. Votle, Eur. J. Org. Chem., 2004, 4048; A. R. Hirst, D. K. Smith,
¨
M. C. Ferters and H. P. M. Geurts, Chem.–Eur. J., 2004, 10, 5901.
3 I. Hisaki, H. Shigemitsu, Y. Sakamoto, Y. Hasegawa, Y. Okajima,
K. Nakano, N. Tohnai and M. Miyata, Angew. Chem., 2009, 121, 5573.
4 M. George, S. L. Snyder, P. Terech, C. J. Glinka and R. G. Weiss,
J. Am. Chem. Soc., 2003, 125, 10275; M. George, S. L. Snyder,
P. J. Terech and R. G. Weiss, Langmuir, 2005, 21, 9970; M. Cote,
T. Nicholls, D. W. Knight, L. R. Morgan, P. G. A. Rogueda,
S. M. King, R. K. Heenan and P. C. Griffiths, Langmuir, 2009,
25, 8678; M. Yamanaka, Y. Miyake, S. Akita and K. Nakano, Chem.
Mater., 2008, 20, 2072; M. Yamanaka, K. Sada, M. Miyata,
K. Hanabusa and K. Nakano, Chem. Commun., 2006, 2248; J. Gan,
M. El. Bakkari, C. Belin, C. Margottin, P. Godard, J.-L. Posso and
J.-M. Vincent, Chem. Commun., 2009, 5133; J. Loiseau, M. Lescanne,
A. Colin, F. Fages, J.-B. Verhac and J.-M. Vincent, Tetrahedron, 2002,
58, 4049.
5 K. Hanabusa, M. Yamada, M. Kimura and H. Shirai, Angew.
Chem., Int. Ed., 1996, 35, 1949.
6 N. Zweep, A. Hopkunson, A. Meetsma, W. R. Browne,
B. L. Feringa and J. H. van Esch, Langmuir, 2009, 25, 8802.
7 T. Kawauchi, J. Kumaki, A. Kitaura, K. Okoshi, H. Kusanagi,
K. Kobayashi, T. Sugai, H. Shinohara and E. Yashima, Angew.
Chem., Int. Ed., 2008, 47, 515; B. Berthier, T. Buffeteau,
There are two possible roles of optical antipodes in the
formation of helically coiled fibrils; (i) to retard the transformation
rate of the homochiral aggregates into tape-like fibrils and (ii) to
participate as a minor component in the homochiral aggregates to
induce the helical winding in the range of 50–300 nm. If the effects
of antipodes were limited to possibility (i), it is difficult to
rationalize the fact that helical fibrils existed predominantly in
the narrow ee region (ee = 0.2–0.4). We suspect that, under the
assumption of possibility, (ii) homochiral RR- and SS-aggregates
were associated at an unequal ratio to form hybridized helically
coiled fibrils. One example is schematically shown in ESIw, in
which RR- and SS-aggregates combine at a 12 : 7 ratio to form a
hexagonal lattice in fibrils. Similar hybridization with unequal
amounts of optical isomers is reported for the formation of
stereo-complexes in stereoregular polymers or the columnar
liquid crystal phases consisting of chiral tris(chelated) metal
complexes.14 The validity of the above assumption would
be verified if the molecular stacking structures in the helical
fibrils are revealed by means of atomic force microscopy, for
example.15
J.-M. Le
124, 13486; V. Setnicka, J. Novy
M. Urbanova and K. Volka, Langmuir, 2008, 24, 7520.
´
ger, R. Oda and I. Huc, J. Am. Chem. Soc., 2002,
´
, S. Bohm, N. Sreenivasachary,
¨
´
8 H. Sato, T. Yajima and A. Yamagishi, Chem. Commun., 2011, 47, 3736.
9 H. Sato, T. Nakae, K. Morimoto and K. Tamura, Org. Biomol.
Chem., 2012, 10, 1581.
10 J. Bayardon, D. Sinou, O. Holczknecht, L. Mercs and G. Pozzi,
Tetrahedron: Asymmetry, 2005, 16, 2319.
11 C. W. Bunn and E. R. Howells, Nature, 1954, 174, 549; K. Ute,
R. Kinoshita, K. Matsui, K. Miyatake and K. Hatada, Chem.
Lett., 1992, 1337.
12 T. Sumiyoshi, K. Nishimuara, M. Nakano, T. Handa, Y. Miwa
and K. Tomioka, J. Am. Chem. Soc., 2003, 125, 12137.
13 D. Ogata, T. Shikata and K. Hanabusa, J. Phys. Chem. B, 2004,
108, 15503; H. van Gestel, A. R. A. Oalmans, B. Titulaer, J. A. J. M.
Vekemans and E. W. Meijer, J. Am. Chem. Soc., 2005, 127, 5490.
14 S. T. Trzaska, H.-F. Hsu and T. M. Swager, J. Am. Chem. Soc.,
1999, 121, 4518; X. Zhang, H. Chen and H. Zhang, Chem.
Commun., 2007, 1395; H. Nouailhas, A. El. Ghzaoui, S. Li and
J. Coudane, J. Appl. Polym. Sci., 2011, 122, 1599.
15 J. Kumaki, S. Sakurai and E. Yashima, Chem. Soc. Rev., 2009,
38, 671.
