Synthesis of Dense and Chiral Dendritic Polyols
Using Glyconanosynthon Scaffolds
Tze Chieh Shiao 1, Rabindra Rej 1, Mariécka Rose 1, Giovanni M. Pavan 2 and René Roy 1,
*
1
Pharmaqam and Nanoqam, Department of Chemistry, University of Québec a Montréal, P.O. Box 8888, Succ.
Centre-Ville, Montréal, QC H3C 3P8, Canada; chichi_shiao@hotmail.com (T.C.S.);
rabi.rej@hotmail.com (R.R.); mariecka.rose@hotmail.fr (M.R.)
Department of Innovative Technologies, University of Applied Sciences and Arts of Southern Switzerland,
Galleria 2, Manno CH-6928, Switzerland; giovanni.pavan@supsi.ch
2
*
Correspondence: roy.rene@uqam.ca; Tel.: +1-514-987-3000 (ext. 2546)
Academic Editor: Derek J. McPhee
Received: 1 March 2016; Accepted: 28 March 2016; Published: 4 April 2016
Abstract: Most classical dendrimers are frequently built-up from identical repeating units of low
valency (usually AB2 monomers). This strategy necessitates several generations to achieve a large
number of surface functionalities. In addition, these typical monomers are achiral. We propose
herein the use of sugar derivatives consisting of several and varied functionalities with their own
individual intrinsic chirality as both scaffolds/core as well as repeating units. This approach allows
the construction of chiral, dense dendrimers with a large number of surface groups at low dendrimer
generations. Perpropargylated
β-D-glucopyranoside, serving as an A5 core, together with various
derivatives, such as 2-azidoethyl tetra-O-allyl-β-D-glucopyranoside, serving as an AB4 repeating
moiety, were utilized to construct chiral dendrimers using “click chemistry” (CuAAC reaction). These
were further modified by thiol-ene and thiol-yne click reactions with alcohols to provide dendritic
polyols. Molecular dynamic simulation supported the assumption that the resulting polyols have a
dense structure.
Keywords: dendrimer; glycodendrimer; carbohydrate; click chemistry; CuAAAC; thiol-yne; thiol-ene
1. Introduction
Dendrimers are hyperbranched, globular shaped, well-defined macromolecules possessing a
wide range of applications in nanomedicine, novel dendrimer space concept in medicinal chemistry,
as multivalent carriers for drug delivery, material sciences, catalysis, and gene therapy [1–8]. During
the last three decades, there has been tremendous growth in this field motivating chemists and
material scientists to conceive new ways to synthesize these molecules more efficiently, rapidly, and
in a cost effective way. Most of the common synthetic methods start with low-valent scaffolds with
reactive functionalities followed by the build-up of higher generation architectures using repetitive
building blocks. The syntheses are accomplished either divergently or convergently. Unfortunately,
the introductions of a large number of surface groups are usually achieved at the expense of high
generation. To counterbalance this situation, only a handful of examples have been described to
generate dendrimers with a high number of end groups at low generation, and the use of sugars
(coined “glyconanosynthons”) has been recently reviewed to achieve this goal [5]. Hence, the use
of carbohydrates as either core or multivalent, high valency branching building blocks is clearly
immerging as an alternative approach to achieve higher numbers of surface groups in a fewer steps.
This approach [9–11] has not been systematically investigated, particularly in regard to their inherent
diversified stereochemical identities, functional group diversities and the chemical orthogonalities
these molecules can offer [5].
Molecules 2016, 21, 448; doi:10.3390/molecules21040448
www.mdpi.com/journal/molecules

Molecules 2016, 21, 448
2 of 16
In addition, an interesting and versatile “onion peel” strategy [12] has been recently added to the
arsenal of sophisticated methods towards dendrimer synthesis. In this case, each layer of the dendritic
macromolecule is constructed using different building blocks, rather than the same molecules, thus
providing much greater flexibility in the synthetic schemes and leading to novel dendritic architectures
and properties. Most importantly, an accelerated growth that necessitates less generation to arrive at
high surface densities can be consequently achieved [13].
Herein, we report a facile and efficient route for dendrimer synthesis that can introduce a
dense, chiral, and a large number of varied surface groups at low generation. To this end, a
perpropargylated carbohydrate derivative, propargyl tetra-O-propargyl-β-D-glucopyranoside (5),
constituting a dense all equatorial A5 core molecule, was used as a starting point. For the next layer
generation, orthogonal building blocks, representing AB4 layers, were readily prepared using classical
carbohydrate chemistry. Toward this goal, suitably functionalized 2-azidoethyl
β-D-glucopyranoside
derivatives were synthesized. These AB4 building blocks were linked to the core
5
employing highly
efficient, atom economical copper-catalyzed alkyne-azide cycloaddition (“click” reaction, CuAAc).
Lastly, thiol-ene and thiol-yne “click” reactions were next utilized to introduce the surface groups
constituted herein of polyols.
2. Results and Discussion
2.1. Dendrimer Synthesis
Dendrimers were constructed in a divergent manner using propargyl 2,3,4,6-tetra-O-propargyl-
β
-D-glucopyranoside (
D-glucopyranose ( ) (Scheme 1). Penta-O-acetyl-
procedure developed in our laboratory [14]. This was treated with propargyl alcohol in the presence of
BF3 etherate in DCM yielding propargyl 2,3,4,6-tetra-O-acetyl- -D-glucopyranoside [15] ( ), which
5
) as a pentavalent core (
A
5), which was synthesized from penta-O-acetyl-
β-
1
β-D-glucopyranose was prepared on a large scale by a
¨
β
4
was de-O-acetylated under Zemplén conditions using NaOMe in MeOH. The free sugar thus obtained
was treated with NaH in DMF to form the corresponding alkoxide which was perpropargylated
using propargyl bromide at 0 ˝C to produce propargyl tetra-O-propargyl-
β
-D-glucopyranoside
) at an excellent yield [16]. Other orthogonal building blocks needed for the dendrimer
construction were synthesized from the same precursor. Penta-O-acetyl- -D-glucopyranose was
treated with 2-bromoethanol in presence of BF3.etherate in DCM at room temperature, which produced
2-bromoethyl 2,3,4,6-tetra-O-acetyl- -D-glucopyranoside ( ) at a good yield [17]. The bromo derivative
thus obtained was converted to azido-derivative ( ) [18] (AB4) by heating with sodium azide in DMF at
85 C at an almost quantitative yield, which was used to construct the next level of the dendrimer ( 1).
A diagnostic peak of the azide was observed in the IR spectrum at 2104 cm´1. Two other building blocks
were synthesized from 2-azidoethyl 2,3,4,6-tetra-O-acetyl- -D-glucopyranoside ( ) by de-O-acetylation
under Zemplén conditions using NaOMe in MeOH. The unprotected sugar ( ) [19] thus obtained was
(5
β
β
2
3
˝
G
β
3
6
treated with sodium hydride in DMF to form the corresponding alkoxide, which was treated with allyl
bromide to obtain 2-azidoethyl 2,3,4,6-tetra-O-allyl-β-D-glucopyranoside (7) [20] and with propargyl
bromide to produce 2-azidoethyl 2,3,4,6-tetra-O-propargyl-
The propargyl functionalities of the tetra-propargylated derivative
silyl group [21 22] using silver chloride, chlorotrimethylsilane, and 1,8-diazabicyclo[5.4.0]undec-7-ene
DBU in DCM. TMS-derivative thus obtained was used as an orthogonal building block to construct
G1 dendrimer generation with access to propargyl-groups for further elaboration.
β-D-glucopyranoside (8) at excellent yields.
8
were protected with trimethyl
,
9

Molecules 2016, 21, 448
3 of 16
Scheme 1. Syntheses of the glyconanosynthons. Reagents and conditions: (i) 2-bromoethanol, BF3 OEt2,
¨
DCM, rt, 2.5 h, 84%; (ii) NaN3, DMF, 85 ˝C, 2 h, 94%; (iii) NaOMe, MeOH, rt, 2.5 h; (iv) DMF, 60% NaH,
rt, 0.5 h; allyl bromide, 0 ˝C, 1 h, then at rt, 3 h, 94%; (v) DMF, 60% NaH, rt, 15 min; 0 ˝C, propargyl
bromide, 2 h, 87%; (vi) DBU, DCM, AgCl, TMSCl, 45 ˝C, overnight, 83%; (vii) propargyl alcohol,
BF3
etherate, DCM, rt, 2 h, 92%; (viii) DMF, 60% NaH, 0–5 ˝C, 0.5 h, then propargyl bromide, 1 h at
¨
0–5 ˝C, 95%.
Propargyl 2,3,4,6-tetra-O-propargyl-
β
-D-glucopyranoside (
) (Scheme 2) using copper mediated CuAAC, reaction.
reacted with the azido-functionalities of forming five distinct triazole
rings. Indeed, NMR spectrum of the resulting product 10 showed four singlets at 8.04
(1H), 7.93 (1H) 7.88 (2H), 7.71 (1H) and absence of any residual propargyl signal. Similarly,
excess of 2-azido ethyl 2,3,4,6-tetra-O-allyl- -D-glucopyranoside ( ) was treated with propargyl
2,3,4,6-tetra-O-propargyl- -D-glucopyranoside ( ) under “Click” condition using CuI P(OEt)3 [16] in
dry toluene at 70 C under microwave yielding perallylated product 12. The presence of five signals at
8.08, 8.03, 7.98, 7.93 and 7.80 ppm due to five triazole rings and absence of signal at 2.41–2.51 ppm
5) was treated with excess 2-azidoethyl
2,3,4,6-tetra-O-acetyl-β-D-glucopyranoside (3
All propargyl groups of
5
3
δ
β
7
β
5
¨
˝
δ
due to propargyl groups in the NMR spectrum indicated complete conversion. Dendrimer (10) was
de-O-acetylated under Zemplén condition using NaOMe in MeOH-water mixture (9:1) yielding
perhydroxylated compound (11). This served as a common intermediate for the synthesis of both
perallylated (12) and perpropargylated 14 derivatives. Perallylation [23] of (11) was accomplished by
forming the anion from 11 using NaH in DMF first, then by reacting with excess allyl bromide at room
temperature for 18 h. Perallylated 12 was obtained in good yield (77%) and was identical in TLC and
NMR with the product obtained from the “Click” reaction involving
a perfect match in its ESI-HRMS spectrum.
5 and 7. Moreover, it also showed
Excess of TMS-protected propargyl derivative
9
was treated with perpropargylated
P(OEt)3) in the presence
glucopyranoside under “Click” condition using soluble copper reagent (CuI
5
¨
of Hunig’s base [22] at 70 ˝C for 20 h affording per-TMS-propargylated dendrimer 13 in 90% yield.
The use of Hunig’s base was necessary to avoid loss of TMS groups during the reaction and to improve
the yield. TMS-protected propargyl ethers were removed by treatment with tetrabutylammonium
fluoride (TBAF) [22] buffered with acetic acid in THF, yielding perpropargylated dendrimer (14) in
85% yield. The same perpropargylated product was obtained by direct propargylation [24] of the anion
derived from 11 by treating with NaH in DMF in presence of excess propargyl bromide in acceptable
yield (70%). Both the products were identical by TLC and by NMR spectroscopy (Figure 1) and showed
once again a perfect ESI-HRMS spectrum.

Molecules 2016, 21, 448
4 of 16
11, v
O
O
O
O
TMS
O
AB4
O
O
OAc
O
AB4
O
O
O
AcO
AcO
O
O
O
N3
TMS
OAc
N3
5
3
G0
R
9
TMS
TMS
R
RO
RO
OR
R
i
OR
AB4
O
O
O
O
O
O
i
O
R
O
O
R
RO
RO
O
OR
O
O
ii
R
O
RO
O
R
OR
OR
O
N3
N
N
N
R
O
O
RO
O
O
O
R
N
N
N
O
7
N
O
N
N
RO
O
O
O
N
O
O
O
O
N
N
N
N
O
O
R
O
O
O
N
R
O
N
O
N
O
N
N
O
N
O
O
O
O
N
N
O
O
O
RO
RO
RO
N
N
R
N
N
O
vi
R
N
O
O
O
N
O
OR
R
N
N
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
R
N
O
N
N
O
O
O
O
OR
O
O
R
R
RO
N
N
N
10 R = Ac
11 R = H
OR
O
O
O
RO
O
R
iv
O
N
O
O
N
O
N
R
O
N
G1 = 20-OH
13 R = TMS
14 R = H
N
O
R
iii
N
N
N
O
N
O
O
O
O
O
O
O
O
O
12
O
O
Scheme 2. Synthesis of glycodendrimer core. Reagents and conditions: (i) CuI
¨
P(OEt)3, toluene, 70 ˝C,
20 h; 85% for 10, 90% for 13 using Hunig’s base; (ii) CuI
¨
P(OEt)3, toluene, microwave, 70 ˝C, 4 h, 80%;
(iii) TBAF, THF, acetic acid, rt, 5 h, 85%; (iv) NaOMe, MeOH-water mixture (10:1), rt, 18 h, 98%; (v)
DMF, propargyl bromide, 0 ˝C, NaH 60% in oil added in four portions every hour, then at rt, 18 h, 70%;
(vi) DMF, NaH 60% in oil, 0 ˝C, 1 h, then at rt, 2 h; cooled to 0 ˝C, allyl bromide, then at rt, 18 h, 77%.
Figure 1. NMR spectra of key precursor
signals of 12.
5 and G1 dendrimers 10, 12 and 13. Insert: Expanded triazole

Molecules 2016, 21, 448
5 of 16
Finally, dendrimer 12 obtained above was progressed to the G2 generation by thiol-ene
click reaction using 2-mercaptoethanol and thio˝glycerol by heating with catalytic amount of
azobisisobutyronitrile (AIBN) in dioxane [25] at 100 C yielding dendritic polyols 15 and 16 having 20
and 40 hydroxyl groups, respectively (Scheme 3). Completion of the reaction was monitored by the clear
and complete disappearance of the signal at 5.72–5.98
δ due to allyl groups. Similarly, intermediate 14
was converted into dendrimers 17 and 18 containing 40 and 80 hydroxyl surface-groups by irradiating
under UV (365 nm) with 2-mercaptoethanol and thioglycerol in the presence of dimethoxyphenyl
acetophenone (DMPA). The reactions were monitored by the disappearance of all the propargyl signals
at
number of surface groups was incorporated into the dendrimer in just two steps from the monomeric
precursors. Sugar units were also introduced at the 2 level of the dendrimer by treating 14, having
20 propargyl groups, with 2-azidoethyl -D-glucopyranoside ( ) using CuAAC click reaction with
soluble CuI
P(OEt)3 as catalyst in DMF at 65–70 ˝C for 20 h yielding dendrimer 19 with 80 hydroxyl
end-groups (Scheme 4). Similarly, compound 20, with 80 acetyl surface-groups, can be easily prepared
from the same precursor (14) and 2-azidoethyl 2,3,4,6-tetra-O-acetyl- -D-glucopyranoside ( ) in an
δ 2.40–2.60 ppm. Thus, by introducing sugar at the core (G0) as well as at the G1 level, large
G
β
6
¨
β
3
efficient way using click reaction. Lastly, 80 allyl end-groups were introduced into the dendrimer by
treating 14 with 2-azidoethyl 2,3,4,6-tetra-O-allyl-β-D-glucopyranoside (7) under the click reaction to
give 21 in good yield (57%). Reactions were monitored by the complete disappearance of all propargyl
signals of 14 at δ 2.40–2.60 ppm.
Scheme 3. Syntheses of dendritic polyols. Reagents and conditions: (i) AIBN, dioxane, 100˝C, 15, 47%,
16, 60%; (ii) UV 365 nm, DMPA, 4 h and 6 h; 17, 56% and 18, 71%.

Molecules 2016, 21, 448
6 of 16
Scheme 4. Synthesis of G2 dendrimers. Reagents and conditions: (i) CuI
for 19; 67% for 20; 57% for 21.
¨
P(OEt)3, DMF, 70 ˝C, 20 h; 53%
All monomeric building blocks were properly characterized by NMR (1H, 13C and COSY), IR
and mass spectrometry. Dendrimers 10
,
11
,
12 and 14 showed correct mass corresponding to their
1
molecular formula in HRMS and exhibited good H-NMR and 13C-NMR in agreement with the
assigned structures. All dendrimers 15, 16, 17, 18, 19, 20, and 21 showed molecular ions in MALDI-TOF,
though in some cases M+ signals were broad signals, likely due to the facile loss of water molecules or
the presence of varied cations (Na+, K+, NH4+) in the polyols. Dendrimers 20 and 21 exhibited good
GPC curves (single peaks) indicating their mono-dispersity (see Supplementary Materials).
2.2. Molecular Dynamics Simulations
In order to gain additional insight into these interesting dense nanostructures, we created an
atomistic model for dendrimer 16 and have simulated it in a box filled of explicit water molecules
by means of all-atom molecular dynamics (MD) simulation. The initially extended conformation
of 16 has been equilibrated during 200 ns of MD simulation. During this time, the dendrimer
folded assuming a quasi-globular shape (Figures 2 and 3). The radius of gyration of 16 was found
to be Rg = 9.8 ˘ 0.5 Å, while the strong folding was found to be stable during the MD simulation
(see Supplementary Materials).
Figure 2. The MD simulation of 16, starting from an initially fully extended conformation. Dendrimer
16 rapidly rearranges into a 2 nm stable globular shape in water.

Molecules 2016, 21, 448
7 of 16
Figure 3. Stick representation of dendrimer 16 after equilibration by MD simulation (water molecules
not shown).
From the equilibrated phase MD trajectories, we obtained the radial distribution functions (g(r))
of the atoms of 16, of the surface groups, and of the water molecules calculated using the dendrimer’s
center of mass (Figure 4). The g(r) curves are indicative of the probability density for finding certain
groups of the dendrimer in space and are useful to understand the level of density in the various
regions of the dendrimer structure [26], of hydration and water penetration [27,28] into the scaffold
and also of the displacement of the surface groups at the dendrimer’s surface both in terms of surface
groups crowding and directionality [29,30].
Figure 4. MD characterization of dendrimer 16 in water. (
scaffold, red: OH-surface groups; ( ) radial distribution functions g(r) of the atoms of 16 (black) and of
the surface OH-groups (red) as a function of the distance from the dendrimer’s center of mass. The
hydrodynamic radius of 16 is calculated according to the model of a rigid sphere as: Rh 1.29 Rg [28];
) radial distribution functions, g(r), of the water molecules (black), and number of water molecules
(blue) as a function of the distance from 16’s center of mass.
a) Equilibrated configuration of 16—black:
b
«
(
c
It is interesting to note that the high level of branching in the scaffold of 16 produces high-density
in the dendrimer’s interior and reduced surface group backfolding. Seen in Figure 4b, the g(r) of
the surface OH-groups of the dendrimer (red) are most probably found at greater distance from the
dendrimer’s center than all other atoms of 16. This indicates that the surface groups well surround
the dendrimer scaffold. This picture of high interior density is well consistent with the g(r) of the
water molecules (Figure 4c), demonstrating that water penetration is present only close to the surface,
identified by Rg (no water penetration for R < 0.5 Rg).
Table S1 reports other interesting structural data for 16. In particular, comparison between
dendrimer’s Rg and solvent accessible surface area (SASA) provides an interesting cue on the level
of porosity of this dendrimer. Namely, SASA is the surface in contact with the solvent. From this
parameter, it is possible to obtain RSASA, which is the radius of a sphere having surface equivalent with
that of the dendrimer in contact with the solution as: RSASA = sqrt(SASA/4π). RSASA is larger than
Rg, because the dendrimer is not a rigid sphere but a porous soft macromolecule with a non-perfect

Molecules 2016, 21, 448
8 of 16
surface. Comparison between the volume of the voids in the dendrimer and the full one leads to a
quantification of 16’s porosity (0.78, see Table S1), which is slightly higher than that of Polyamidoamine
(PAMAM) G2 dendrimer (0.75), having SASA
«
3.5
ˆ
103 Å2 and Rg = 10.4 Å3. Compared to G2
PAMAM, the data from the MD simulation suggest that 16 is more heavy and dense in the interior
even if having a larger surface. This is consistent with the fact that 16 is slightly smaller than a G2
PAMAM (slightly smaller Rg) while the MW is higher (4581 Da for 16 vs. 3256 Da for G2 PAMAM)
and it has a larger number of surface groups: 20 vs. 16.
3. Materials and Methods
All reactions in organic medium were performed in standard oven dried glassware under an
inert atmosphere of nitrogen using freshly distilled solvents stored over molecular sieves. Solvents
were deoxygenated when necessary by bubbling nitrogen through the solution. All reagents
were used as supplied without prior purification and obtained from Sigma-Aldrich Chemical Co.
(Toronto, ON, Canada) Reactions were monitored by analytical thin-layer chromatography (TLC) using
silica gel 60 F254 precoated plates (E. Merck, Darmstadt, Germany) and compounds were visualized
by 254 nm light and/or by dipping into a mixture of sulfuric acid and methanol in water or into a
mixture of KMnO4 and K2CO3 in water followed by gentle warming with a heat-gun. Purifications
were performed by flash column chromatography using silica gel from Canadian Life Science (60 Å,
1
40–63
µ
m) (Peterborough, ON, Canada) with the indicated eluent. H-NMR and 13C-NMR spectra
were recorded at 300 and/or 600 MHz and 75 and/or 150 MHz, respectively, on a Bruker spectrometer
(300 MHz and 600 MHz) (Milton, ON, Canada) a˝nd Varian spectrometer (600 MHz) (Milton, ON,
Canada). All NMR spectra were measured at 25 C in indicated deuterated solvents. Proton and
carbon chemical shifts (δ) are reported in ppm and coupling constants (J) are reported in Hertz (Hz).
The resonance multiplicity in the 1H-NMR spectra are described as “s” (singlet), “d” (doublet), “t”
(triplet), and “m” (multiplet) and broad resonances are indicated by “broad”. Residual protic solvent
of CDCl3 (1H,
δ
7.27 ppm; 13C,
δ
77.0 ppm (central resonance of the triplet)), D2O (1H,
δ
4.80 ppm
and 30.9 ppm for CH3 of Acetone for 13C spectra), MeOD (1H,
δ
3.30 ppm and 13C,
δ
49.0 ppm).
Two-dimensional homonuclear correlation H-1H COSY experiments were used to confirm NMR
peak assignments. Fourier transform infrared (FTIR) spectra were obtained with Thermo-scientific,
Nicolet model 6700 (Mississauga, ON, Canada) equipped with Alternate Total Reflection (ATR).
The absorptions are given in wave numbers (cm´1). Accurate mass measurements (HRMS) were
performed on a LC-MSD-TOF instrument from Agilent Technologies (Santa Clara, CA, USA) in
positive electrospray mode. Either protonated molecular ions [M + nH]n+ or adducts [M + nX]n+
(X = Na, K, NH4) were used for empirical formula confirmation. Gel Permeation Chromatography
(GPC) was performed using chloroform and THF as the eluent, at 40 ˝C with a 1 mL/min flow rate
on a Viscotek VE 2001 GPCmax (SEC System) (Viscotek/Malvern Instruments Ltd, Worcestershire,
UK) with Wyatt DSP/Dawn EOS (Wyatt Technology, Santa Barbara, CA, USA) and refractive index
RI/LS system as detectors (Wyatt Technology, Santa Barbara, CA, USA). In addition, 2 PLGel mixed
1
B LS (10
µ
m, 300
ˆ
7.5 mm) and Light Scattering-Multiangle Laser Light Scattering (LS-MALLS)
detection with performances verified with polystyrene 100 kDa and 2000 kDa were used to determine
the number-average molecular weight (Mn) and polydispersity index (MW/Mn). Calculations were
performed with Zimm Plot (model).
Syntheses of 1,2,3,4,6-penta-O-acetyl-
β
-D-glucopyranose (
1
), 2-bromoethyl 2,3,4,6-tetra-O-acetyl-
-D-glucopyranoside ( ), 2-azidoethyl
) were performed following the literature procedures in
β
-D-glucopyranoside (2), 2-azidoethyl 2,3,4,6-tetra-O-acetyl-
β
3
2,3,4,6-tetra-O-allyl-
β-D-glucopyranoside (
7
good yields.
Propargyl 2,3,4,6-tetra-O-propargyl-
β
-D-glucopyranoside (
5
).
To a solution of prop-2-ynyl-β-D-
glucopyranoside (4a) (310 mg, 1.42 mmol) in DMF (5 mL) cooled to 0 ˝C was added sodium hydride
(60% in oil, 530 mg, 13.2 mmol). The mixture was stirred for 30 min at this temperature. Propargyl
bromide (3 mL, 20.2 mmol) was added dropwise. The mixture was stirred at 0–5 ˝C for 1 h. It was

Molecules 2016, 21, 448
9 of 16
quenched with NH4Cl solution. It was extracted with ethyl acetate and washed with brine. The
extract was dried over sodium sulfate and evaporated under vacuum. The crude product was
chromatographed over silica gel (hexane-ethyl acetate (0–30%) as eluent) yielding
5
as light yellow
(ppm)
oil (500 mg, 1.35 mmol, 95%). Rf = 0.22 (Hexanes/EtOAc 2:1); 1H-NMR (600 MHz, CDCl3):
δ
4.59–4.32 (m, 9H, H-1 and OCH2), 4.28–4.17 (m, 2H), 3.84 (dd, 1H, 3J6a,5 = 1.9 Hz, 3J6a = 10.8 Hz,
,6b
H-6a), 3.77 (dd, 1H, 3J6b,5 = 4.7 Hz, 3J6b,6a = 10.8 Hz, H-6b), 3.58 (dd, 1H, 3J3,2 = 8.8 Hz, 3J3,4 = 9.5 Hz,
H-3), 3.51–3.37 (m, 3H) and 2.51–2.41 (m, 5H). 13C-NMR (75 MHz, CDCl3):
δ (ppm) 100.7 (C-1), 83.2,
80.9, 80.0, 79.9, 79.7, 79.5, 78.6, 75.9, 75.1, 74.7, 74.4, 74.3, 74.2, 74.1, 68.3, 60.2, 60.0, 59.3, 58.6, 55.9.
´1
FT-IR:
ν
(neat)/cm 3289 (br, C
”
CH) and 2119 (
CH). ESI+-HRMS: [M + H]+ calcd for C21H23O6,
”
max
371.1467; found: 371.1480.
2-Azidoethyl 2,3,4,6-tetra-O-propargyl-
β
-D-glucopyranoside (8). 2-azidoethyl 2,3,4,6-tetra-O-acetyl-β-D-
glucopyranoside (300 mg, 0.72 mmol) was dissolved in dry methanol (6 mL) and NaOMe (1.1 M) was
added slowly to bring pH to 9. The mixture was stirred at room temperature for 2.5 h. Acidic resin
(IR-120) was added to neutralize the base. The mixture was filtered and evaporated to obtain fully
deprotected glucoside derivative. Before being used in the next step, it was placed under vacuum
˝
for 1 h. It was dissolved in DMF (3 mL) and the solution was cooled to 0 C. Sodium hydride
(60% in oil, 240 mg, 6.0 mmol) was added. The mixture was stirred at 0 ˝C for 15 min. Propargyl
bromide (80% in toluene, 1.5 mL, 10.1 mmol) was added dropwise. The mixture was stirred at
˝
0 C for 1 h. Saturated NH4Cl solution was added to quench the reaction. It was extracted with
ethyl acetate. The extract was washed with brine, dried over MgSO4 and evaporated. 2-Azidoethyl
2,3,4,6-tetra-O-propargyl-β-D-glucopyranoside (8) was obtained by flash chromatography over silica
1
gel (hexane-ethyl acetate (0–30%) as eluent) as light yellow oil (250 mg, 0.62 mmol, 87%). H-NMR
(300 MHz, CDCl3)
δ (ppm) 4.65–4.50 (m, 3H), 4.50–4.37 (m, 3H), 4.34 (d, J = 7.8 Hz, 1H), 4.31–4.16
(m, 2H), 4.04 (ddd, J = 10.6, 5.4, 3.8 Hz,1H), 3.86 (dd, J = 10.7, 1.8 Hz, 1H), 3.79 (d, J = 4.6 Hz, 1H),
3.77–3.65 (m, 1H), 3.63–3.54 (m, 1H), 3.52–3.35 (m, 5H), 2.53–2.42 (m, 4H); 13C NMR (150 MHz, CDCl3)
δ
(ppm) 103.1, 83.3, 81.2, 80.0, 79.9, 79.8, 79.5, 76.1, 74. 7, 74.4, 74.3, 74.30, 74.2, 68.5, 68.2, 60.3, 60.0, 59.5,
´1
58.7, 50.9. FT-IR:
ν
(neat)/cm 3290s (br, C
”
CH), 2104 (azide). ESI+-HRMS: [M + NH4]+ calcd for
max
C20H27N4O6, 419.1915; found: 419.1925.
2-Azidoethyl 2,3,4,6-tetra-O-trimethylsilylpropargyl-
2,3,4,6-tetra-O-propargyl- -D-glucopyranoside (
β
-D-glucopyranoside (9) A mixture of 2-azidoethyl
β
8) (700 mg, 1.74 mmol), AgCl (300 mg, 2.1 mmol)
and DBU (3.5 g, 23 mmol) in DCM (25 mL) was brought ˝to 40 ˝C. Chlorotrimethyl silane (3.1 mL,
24.4 mmol) was added dropwise. It was stirred at 45 C for 18 h. The reaction mixture was
diluted with DCM/H2O (300 mL, 2:1 v/v) and extracted with DCM (200 mL). The extract was
washed with water (50 mL) and with brine (50 mL), dried and evaporated. The crude material was
passed through a column of silica gel (hexane-ethyl acetate (0–10%) as eluent) to obtain 2-azidoethyl
2,3,4,6-tetra-O-trimethylsilylpropargyl-
1H-NMR (300 MHz, CDCl3)
(ppm) 4.63–4.28 (m, 7H), 4.22 (s, 2H), 4.03 (ddd, J = 10.6, 5.5, 4.0 Hz,
1H), 3.93 (d, J = 10.0 Hz, 1H), 3.76–3.60 (m, 2H), 3.60–3.39 (m, 5H), 3.33 (dd, J = 8.9, 7.9 Hz, 1H),
0.19 (s, 35H); 13C-NMR (150 MHz, CDCl3)
(ppm) 103.1, 102.1, 102.0, 101.8, 101.5, 91.5, 91.2, 91.1,
90.9, 83.7, 81.7, 75.9, 74.5, 69.3, 68.2, 61.0, 60.5, 60.4, 59.5, 50.9, 0.1. FT-IR:
(neat)/cm´1 2176
β-D-glucopyranoside (9) as colorless oil (1.0 g, 1.45 mmol, 83%).
δ
δ
´
ν
max
(substituted propargyl) and 2103 (azide). ESI+-HRMS: [M + NH4]+ calcd for C32H59N4O6Si4, 707.3487;
found: 707.3506.
Synthesis of 10. A mixture of
glucopyranoside ( ) (97 mg, 0.233 mmol) and CuI
held at 70 C with stirring for 20 h. It was cooled and diluted with ethyl acetate (100 mL). The solution
was washed with EDTA (2 5 mL) and with a mixture of aqueous NaHCO3 and brine (10 mL), dried
5
(13 mg, 0.035 mmol), 2-azidoethyl 2,3,4,6-tetra-O-acetyl-
β-D-
3
¨
P(OEt)3 (7 mg, 0.02 mmol) in dry toluene (2 mL) was
˝
ˆ
and evaporated. The crude material was passed through a column of silica gel with hexane-ethyl
acetate (1:1) and 0–6% MeOH in DCM as eluents yielding 10 as colorless oil (73 mg, 0.03 mmol, 85%).
1H-NMR (600 MHz, CDCl3)
δ (ppm) 8.04 (s, 1H), 7.93 (s, 1H), 7.88 (s, 2H), 7.71 (s, 1H), 5.22–5.13

Molecules 2016, 21, 448
10 of 16
(m,5H), 5.06 (td, J = 9.7, 5.4 Hz, 5H), 4.99–4.95 (m, 8H), 4.92–4.87 (m, 2H), 4.82 (d, J = 12.6 Hz, 1H),
4.78 (d, J = 12.0 Hz, 1H), 4.73 (d, J = 12.5 Hz, 1H), 4.69–4.48 (m, 18H), 4.44 (d, J = 7.8 Hz, 1H), 4.26–4.21
(m, 11H), 4.16–4.10 (m, 5H), 4.05–3.89 (m, 5H), 3.78 (br s, 2H), 3.76–3.69 (m, 5H), 3.55–3.43 (m, 2H),
3.43–3.29 (m, 2H), 2.37–1.71 (m, 60H); 13C-NMR (150 MHz, CDCl3)
δ (ppm) 170.6, 170.1, 169.4, 169.3,
169.2, 144.8, 144.7, 144.8, 144.5, 144.3, 124.8, 124.7, 124.6, 124.5, 124.2, 102.3, 100.6, 100.5, 100.4, 83.9, 81.7,
, 74.4, 72.6, 72.5, 72.5, 72.48, 72.4, 71.9, 71.8, 70.8, 70.7, 68.8, 68.3, 68.2, 67.8, 67.7, 67.6, 66.4, 65.7, 65.7,
64.5, 62.8, 61.7, 61.72, 61.69, 53.4, 49.8, 49.76, 49.70, 20.7, 20.6, 20.5. ESI+-HRMS: [M + 2H]2+ calcd for
C101H139N15O56, 1229.4246; found: 1229.4255.
Synthesis of 11. To a solution of 10 (40 mg, 0.016 mmol) in methanol-H2O (10:1) (3 mL) was
added sodium methoxide in methanol (0.59 M) slowly to bring pH to 9. It was stirred for 18 h at
room temperature. It was stirred with acidic resin (IR-120) to bring the pH around 7. The resin was
filtered off and filtrate was evaporated, dissolved in water and lyophilized to give 11 as a fluffy solid
1
(26 mg, 0.16 mmol, 98%). H-NMR (600 MHz, D2O)
δ (ppm) 8.14 (s, 1H), 8.13 (s, 1H), 8.05 (s, 1H), 8.04
(s, 1H), 8.01 (s, 1H), 4.97 (d, J = 12.7 Hz, 1H), 4.83 (ddd, J = 12.5, 8.9, 3.4 Hz, 4H), 4.74–4.58 (m, 16H),
4.59–4.50 (m, 1H), 4.48–4.37 (m, 6H), 4.35–4.23 (m, 6H), 4.15–4.02 (m, 6H), 3.91–3.84 (m, 6H), 3.74–3.61
(m, 9H), 3.60–3.55 (m, 1H), 3.52 (dd, J = 15.8, 6.8 Hz, 1H), 3.49–3.37 (m, 12H), 3.36–3.27 (m, 5H),
13C-NMR (150 MHz, D2O + acetond-d6)
3.26–3.16 (m, 5H); δ (ppm) 144.4, 144.1, 144.1, 144.0, 126.6,
126.5, 126.3, 126.2, 126.1, 103.0, 102.9, 102. 8, 102.1, 83.4, 81.3, 77.1, 76.5, 76.2, 76.1, 73.9, 73.5, 73.4, 73.4,
72.6, 70.1, 70.1, 68.6, 68.5, 68.3, 66.0, 65.3, 65.2, 63.8, 63.0, 62.7, 61.3, 50.9, 50.8, 50.8, 28.8. ESI+-HRMS:
[M + H]+ calcd for C61H98N15O36, 1616.6320; found: 1616.6293.
˝
Synthesis of 12. Procedure A: To a solution of 11 (12 mg, 0.007 mmol) in dry DMF (3 mL) at 0 C
was added sodium hydride (60% in oil, 80 mg, 2 mmol). It was stirred at this temperature for 1 h and
then at room temperature for another 2 h. The mixture was cooled back to 0 ˝C and allyl bromide
(200 µL 2.3 mmol) was added slowly. After the addition the mixture was stirred at room temperature
for 18 h. Saturated NH4Cl was added to quench the reaction. It was extracted with EtOAc (50 mL).
The extract was washed with brine (5 mL), dried over MgSO4 and evaporated. The crude material was
chromatographed over silica gel using hexane-EtOAc (3:2) and 5% to 10% methanol in DCM as eluents
yielding perallylated product 12 as colorless oil (14 mg, 0.058 mmol, 77%).
Procedure B: Compound 12 could also be obtained by treating
5
(15 mg, 0.04 mmol) and
7 (135 mg,
0.33 mmol) under CuAAC reaction condition using C˝u(I)
chromatography after usual work-up in 80% yield (78 mg, 0.032 mmol). H-NMR (300 MHz, CDCl3)
¨
P(OEt)3 (8 mg, 0.02 mmol) as catalyst in
toluene (2.4 mL) by irradiating under microwave at 70 C for 4 h. Product 12 was isolated by column
1
δ
(ppm) 8.08, 8.03, 7.98, 7.93 and 7.80 (5
(m, 8H), 4.71–4.53 (m, 13H), 4.43–4.41 (m, 2H), 4.35–4.19 (m, 24H), 4.13–3.96 (m, 29H), 3.76–3.58
(m, 12H), 3.49–3.47 (m, 3H), 3.35 (broad s, 17H), 3.18 (broad s, 6H); 13C-NMR (150 MHz, CDCl3)
ˆ
s, 5H), 5.98–5.72 (m, 20H), 5.29–5.06 (m, 39H), 4.99–4.75
δ
(ppm) 144.7, 135.2, 134.9, 134.8, 134.7, 134.6, 124.5, 117.2, 117.0, 116.9, 116.7, 103.2, 84.0, 81.2, 74.7, 74.4,
73.8, 73.5, 72.4, 68.7, 67.8, 50.1, 32.0, 29.7, 22.7. ESI+-HRMS: [M + 2H]2+ calcd for C121H179N15O36,
1209.6288; found: 1209.6329.
Synthesis of 13. A mixture of 2-azidoethyl 2,3,4,6-tetra-O-trimethylsilylpropargyl-
glucopyranoside ( ) (50 mg, 0.07 mmol), (3.5 mg, 0.01 mmol), CuI P(OEt)3 (3.5 mg, 0.01 mmol)
and N,N-diisopropylethylamine (DIPEA) (30 L, 0.17 mmol) in dry toluene (2 mL) was held at
65–70 C with stirring for 20 h. The mixture was cooled and diluted with ethyl acetate (100 mL). It was
washed with EDTA (3 5 mL), NaHCO3 solution (2 5 mL) and brine (5 mL). The extract was dried
β-D-
9
5
¨
µ
˝
ˆ
ˆ
over MgSO4 and evaporated. The crude was purified by column chromatography over silica gel
(hexane-ethyl acetate (1:1) and 2%–5% MeOH in toluene as eluents) yielding TMS-protected dendrimer
1
13 (32 mg, 0.009 mmol, 90%). H-NMR (300 MHz, CDCl3)
δ
(ppm) 8.14 (s, 1H), 8.09 (s, 1H), 7.99 (s, 2H),
7.84 (s, 1H), 5.03–4.74 (m, 9H), 4.73–4.36 (m, 35H), 4.36–4.11 (m, 30H), 4.07–3.85 (m, 11H), 3.84–3.55
(m, 9H), 3.54–3.29 (m, 24H), 0.17 (broad signal, 180H); 13C-NMR (150 MHz, CDCl3)
(ppm) 144.8,
δ
144.7, 144.5, 144.4, 144.2, 124. 7, 124.6, 124.4, 124.3, 124.0, 103.1, 103.0, 102.901, 102.0, 101.90, 101.80,
101.40, 91.2, 91.1, 91.0, 83.60, 81.1, 81.0, 80.9, 77.4, 75.9, 75.8, 74.5, 74.3, 68.9, 68.0, 67.9, 66.5, 65.9, 65.7,

Molecules 2016, 21, 448
11 of 16
´1
64.6, 62.9, 61.0, 60.6, 60.2, 60.1, 60.0, 59.5, 50.0, 49.9, 49.8, 49.8, 30.9, 29.7,
2177 (substituted propargyl).
´0.1. FT-IR:
ν
(neat)/cm
max
Synthesis of 14. To a solution of 13 (49 mg, 0.013 mmol) in THF (2 mL) was added TBAF (1 M in
THF, 300 L, 0.3 mmol) and 4 drops of glacial acetic acid (adjusted to pH 7). The mixture was stirred at
µ
room temperature for 5 h. It was evaporated and dissolved in EtOAc (50 mL). The solution was washed
with saturated NH4Cl solution (5 mL) and brine (5 mL) and dried over MgSO4. It was evaporated
and passed through a column of silica gel (hexane-ethyl acetate (1:1) and 5%–10% MeOH in toluene as
eluents) yielding perpropargylated dendrimer 14 as light yellow oil (26 mg, 0.011 mmol, 85%).
Synthesis of 14 by direct alkylation: To a solution of 11 (193 mg, 0.119 mmol) in DMF (15 mL)
˝
was added propargyl bromide (650 µL, 4.37 mmol). It was cooled to 0 C. Four portions of NaH (60% in
oil, 60 mg each, 1.5 mmol each) was added at an interval of one hour. After the additions, the ice-bath
was removed and the mixture was stirred at room temperature for 18 h. The reaction was quenched
with saturated NH4Cl solution and extracted with EtOAc (150 mL). The extract was washed with
brine and dried over MgSO4. The solvent was removed and the crude product was passed through a
column of silica gel (using hexane-EtOAc (1:1) and 0–10% MeOH in DCM as eluents) yielding mainly
fully propargylated (230 mg) (slightly impure) with a small amount of partially propargylated (57 mg)
product. Partially propargylated fraction was further propargylated using the above procedure with
propargyl bromide (0.1 mL, 1.1 mmol) and three portions of sodium hydride (60% in oil, 10 mg each,
0.25 mmol each) in THF (4 mL). The product thus obtained was combined with slightly impure fraction
(230 mg) and passed through a column of silica gel using hexane-EtOAc (1:1) and 4% methanol in
DCM as eluents yielding perpropargylated product, 14 as light yellow oil (198 mg, 0.08 mmol, 70%).
1H-NMR (600 MHz, CDCl3)
δ (ppm) 8.15 (s,1H), 8.11 (s, 1H), 8.05 (s, 1H), 8.01 (s, 1H), 7.89 (s, 1H),
5.01–4.97 (m, 3H), 4.93–4.88 (m, 2H), 4.82 (dd, J = 11.8, 8.9 Hz, 2H), 4.75 (d, J = 12.4 Hz, 1H), 4.71–4.56
(m, 14H), 4.54–4.37 (m, 25H), 4.35–4.10 (m, 36H), 4.04–3.97 (m, 6H), 3.86–3.79 (m, 6H), 3.78–3.71
(m, 8H), 3.54–3.48 (m, 8H), 3.47–3.29 (m, 20H), 2.60–2.40 (m, 20H); 13C-NMR (150 MHz, CDCl3)
δ
(ppm) 144.79, 144.72, 144.26, 128.97, 128.16, 125.23, 124.90, 124.84, 124.60, 102.98, 102.19, 84.01, 83.34,
75.01, 74.95, 74.´501, 74.44, 73.98, 68.39, 67.96, 65.73, 64.64, 62.86, 60.19, 59.93, 59.92, 59.34, 49.88. FT-IR:
ν
(neat)/cm 3283s (br, C
”
CH), 2118 (
CH). ESI+-HRMS: [M + 2H]2+ calcd for C121H139N15O36,
”
max
1189.4779; found: 1189.4764.
Synthesis of 15. A solution of perallylated intermediate 12 (8 mg, 0.003 mmol), mercaptoethanol
(28 mg, 0.036 mmol, 120 eq.) and a catalytic amount of AIBN in dioxane (2.0 mL) was stirred
at reflux for 1 h. The mixture was then diluted with H2O, dialysed against water over night,
and lyophilized to yield polyol G2 (15) as light yellow oil (5.6 mg, 0.0014 mmol, 47%). 1H-NMR
(600 MHz, D2O)
δ (ppm) 8.20–8.04 (5H, m), 5.05–4.86 (7H, m), 4.74–4.58 (13H, m), 4.49–4.21 (13H,
m), 4.17–3.97 (20H, m), 3.92–3.56 (73H, m), 3.54–3.23(26H, m), 3.21–2.92 (27H, m), 2.92–2.57 (47H, m),
2.56–2.41(5H, m), 2.20–2.01 (10H, broad signal), 1.99–1.81 (20H, broad signal), 1.75–1.57 (5H, broad
signal). MALDI-TOF-MS: C161H297N15O56S20; exact mass cald: 3976.52678; found: ~4000 (broad).
Synthesis of 16. The solution of perallylated 12 (10 mg, 0.004 mmol), thioglycerol (43
µL,
0.48 mmol, 120 equiv.) and a catalytic amount of AIBN in dioxane (2.0 mL) was stirred under reflux
for 1 h. The mixture was then diluted with H2O, dialysed against water overnight, and lyophilized
1
to yield polyol G2 (16) as yellow light oil (11 mg, 0.0024 mmol, 60%). H-NMR (600 MHz, D2O)
δ
8.18–8.00 (5H, m), 5.09–4.81 (6H, m), 4.68 (12H, broad signal), 4.51–4.22 (11H, m), 4.22–4.02 (11H, m),
4.02–3.19 (131H, m), 3.16–2.88 (21H, m), 2.88–2.38 (61H, m), 2.21–2.00 (7H, broad signal), 2.00–1.76
(24H, broad signal), 1.74–1.51 (8H, broad signal); 13C-NMR (150 MHz, D2O)
δ (ppm) 145.8, 145.4, 126.5,
103.7, 84.9, 82.7, 75.2, 73.5, 72.9, 72.7, 72.1, 71.1, 70.7, 70.3, 69.2, 68.2, 67.0, 66.3, 56.4, 55.6, 51.7, 49.7,
49.4, 35.8, 30.7, 29.9, 29.8, 24.6, 24.4, 24.3, 23.7. MALDI-TOF-MS: C181 H337N15O76S20; exact mass cald:
4576.73807; found: 4555.334.
Synthesis of 17. Perpropargylated 14 (10 mg, 0.004 mmol) and 2,2-dimethoxy-2-phenylacetophenone
(DMPA), (12 mg, 0.047 mmol) in DMF (200
µL) was added in a quartz photometer cell.
2-Mercaptoethanol (200 mg, 2.56 mmol) was added into the solution. The mixture was irradiated

Molecules 2016, 21, 448
12 of 16
under 365 nm light for 4 h. The mixture was then diluted with H2O, dialysed against water overnight,
and lyophilized to yield polyol G2 (17) as light yellow oil (13 mg, 0.002 mmol, 56%). 1H-NMR
(600 MHz, MeOD)
4.24–3.99 (34H, m), 3.96–3.56 (108H, m), 3.55–3.40 (14H, m), 3.28–2.63 (137H, m); 13C-NMR (150 MHz,
MeOD) (ppm) 127.1, 126.5, 105.6, 86.5, 84.1, 79.8, 77.5, 76.6, 76.2, 76.1, 75.2, 71.8, 70.0, 63.9, 63.5, 63.3,
δ (ppm) 8.25–8.11(5H, m), 5.10–4.93 (7H, m), 4.84–4.59 (19H, m), 4.50–4.27 (15H, m),
δ
57.3, 56.9, 52.6, 49.1, 48.8, 48.3, 37.3, 37.2, 37.0, 36.2, 36.0. MALDI-TOF-MS: C201H377N15O76S40; exact
mass: 5496.49249; found: 5590.
Synthesis of 18. To a solution of perpropargylated compound 14 (10 mg, 0.004 mmol) and DMPA
(12 mg, 0.047 mmol) in DMF (200 µL) in a quartz photometer cell was added thiolglycerol (400 mg,
3.70 mmol). The mixture was irradiated under 365 nm light for 6 h. The mixture was then diluted
with H2O, dialysed against water over night, and lyophilized yield polyol G2 (18) as light yellow solid
(20 mg, 0.003 mmol, 71%).1H-NMR (600 MHz, D2O)
δ
(ppm) 8.23–8.04 (5H, m), 5.11–4.89 (10H, m),
4.55–4.42 (8H, m), 4.40–4.28 (7H, m), 4.27–3.98 (26H, m), 3.95–3.31(171H, m), 3.30–3.12 (23H, m),
3.10–2.59 (114H, m); 13C-NMR (150 MHz, D2O)
(ppm) 145.1, 144.7, 126.3, 126.1, 103.2, 100.6, 100.4,
δ
84.4, 84.0, 82.4, 78.3, 75.2, 74.5, 73.4, 71.8, 71.6, 70.1, 68.5, 67.6, 67.5, 66. 5, 65.6, 51.1, 47.0, 46.7, 46.4,
36.11, 35.4, 34.8. MALDI-TOF-MS: C241H457N15O116S40; exact mass: 6696.91507; found: 6745.
Synthesis of polyol 19. A mixture of 2-azidoethyl
β-D-glucopyranoside (6) (34 mg, 0.136 mmol),
14 (8 mg, 0.003 mmol) and CuI
¨
P(OEt)3 (3 mg, 0.008 mmol) in dry DMF (1 mL) was held at 70 ˝C
for 21 h. It was cooled and diluted with water. The mixture was dialysed (in a dialysis bag with
1200 cut-off) against water (with frequent change of water at the start) for 72 h. The dialysed material
1
was lyophilized to give 19 (13 mg, 0.002 mmol, 53%). H-NMR (600 MHz, D2O)
δ (ppm) 8.07–7.95
(m, 25H), 4.69–4.51 and 4.48–4.34 (m, 116H), 4.29–4.17 (m, 28H), 4.12–3.91 (m, 27H), 3.88–3.80 (m, 22H),
3.69–3.57 (m, 32H), 3.45–3.36, 3.33–3.27, 3.22–3.16 (m, 97H); 13C-NMR (150 MHz, D2O + acetone-d6)
δ
(ppm) 144.2, 126.4, 103.1, 83.4, 81.3, 76.6, 76.3, 74.0, 73.62 70.3, 68.6, 66.0, 65.5, 63.9, 61.4, 51.0.
MALDI-TOF-MS: C281H437N75O156; exact mass: 7357.85677; found: 7519.337.
Synthesis of 20. A mixture of 14 (13 mg, 0.006 mmol), 2-azidoethyl 2,3,4,6-tetra-O-acetyl-β-D-
glucopyranoside (
was stirred at 65–70 ˝C for 20 h. It was cooled and evaporated. The reaction mixture was diluted
with EtOAc (100 mL), washed with EDTA (2 5 mL), NaHCO3 solution (2 5 mL) and brine, dried
3
) (86 mg, 0.20 mmol) and CuI P(OEt)3 (5.5 mg, 0.02 mmol) in dry DMF (1.3 mL)
¨
ˆ
ˆ
over MgSO4 and evaporated. The crude product was passed through a column of silica gel with
hexane-EtOAc (1:1), 3% to 5% MeOH in toluene and 5% to 8% MeOH in DCM as eluents yielding 20
1
as colorless oil (39 mg, 0.004 mmol, 67%). H-NMR (600 MHz, CDCl3)
δ (ppm) 8.13–7.61 (m, 25H),
5.20–5.14 (m, 22H), 5.09–5.04 (m, 19H), 4.99–4.82 (m, 37H), 4.80–4.47 (m, 95H), 4.39–4.33 (m, 9H),
4.31–4.17 (m, 44H), 4.17–4.08 (m, 20H), 4.07–3.97, 3.97–3.90 (m, 24 H), 3.81–3.68 (m, 30H), 3.53–3.44
(m, 10H), 3.41–3.26 (m, 15H), 2.07–1.91 (m, 240H); 13C-NMR (150 MHz, CDCl3)
δ (ppm) 170.6, 170.1,
169.4, 169.3, 169.2, 144.5, 124.6, 103.4, 100.5, 100.4, 83.7, 81.7, 74.2, 72.6, 72.5, 71.8, 70.9, 70.8, 68.3, 67.7,
65.7, 64. 5, 61.8, 49.7, 29.7, 20.7, 20.6. MALDI-TOF MS: C441H597N75O236; exact mass: 10,718.70195;
found: 10,747.228. See Supplementary Materials for GPC.
Synthesis of 21. A mixture of 2-azidoethyl 2,3,4,6-tetra-O-allyl-
0.20 mmol), 14 (13 mg, 0.006 mmol) and CuI P(OEt)3 (5.5 mg, 0.02 mmol) in dry DMF (1.3 mL) was
stirred at 65–70 ˝C for 20 h. The reaction mixture was evaporated and the residue was dissolved in
EtOAc (100 mL). It was washed with EDTA (2 5 mL), saturated NaHCO3 solution (2 7 mL) and
β-D-glucopyranoside (7) (85 mg,
¨
ˆ
ˆ
brine (5 mL), and dried over MgSO4. The solution was evaporated and passed through a column of
silica gel with hexane-EtOAc (1:1) and 2% to 10% MeOH in DCM as eluents yielding 21 as colorless oil
1
(33 mg, 0.003 mmol, 57%). H-NMR (600 MHz, CDCl3)
δ (ppm) 8.14–7.70 (m, 25H), 6.09–5.65 (m, 80H),
5.42–5.01 (m, 159H), 5.01–4.49 (m, 100H), 4.37–4.18 (m, 107H), 4.15–3.86 (m, 129H), 3.77–3.53 (m, 58H),
3.46 (broad signal, 17H), 3.34 (broad signal, 69H), 3.21–3.12 (m, 22H); 13C-NMR (150 MHz, CDCl3)
δ
(ppm) 144.67, 144.33, 135.21, 135.16, 135.05, 134.96, 134.87, 134.78, 134.61, 134.57, 124.39, 124.00, 117.16,
116.92, 116.84, 116.63, 103.41, 103.16, 83.97, 81.23, 74.72, 74.32, 73.75, 73.43, 72.40, 68.70, 67.77, 66.42,

Molecules 2016, 21, 448
13 of 16
65.81, 64.51, 49.96, 29.66, 22.65. MALDI-TOF-MS: C521H757N75O156; exact mass: 10,560.36078; found:
10,632.893. See SI for GPC.
Computational Methods. The computational approach used for this study is the same recently
adopted for the simulation of a variety of dendrimers in aqueous solution [26–30]. The simulation
work was conducted using the AMBER 12 software (version 12, University of California, San Francisco,
CA, USA, 2012) [31]. The molecular model for 16 has been parameterized according to the “general
AMBER force field (GAFF)” [32].
Dendrimer 16 was immersed in a simulation box filled with explicit TIP3P water molecules [33].
After preliminary energy minimization, the system has been thermalized through a short 100 ps MD
simulation in NVT (constant N: number of a˝toms, V: volume and T: temperature) periodic boundary
conditions to reach the temperature of 37 C (310 K). Then, dendrimer 16 has been equilibrated
through 200 ns of MD simulations NPT in periodic boundary condition (constant N: number of
atoms, P: pressure and T: temperature during the run) at 37 ˝C of temperature and 1 atm of pressure.
During this time, dendrimer 16 reached the equilibrium with good stability, as demonstrated by
the root mean square displacement (RMSD), radius of gyration (Rg) and enthalpy (H) data reported
in the SI. For the MD run, a 2 femtoseconds time step was used, the Langevin thermostat, a 8 Å
cutoff, the particle mesh Ewald [34] (PME) for long-range electrostatics, and the SHAKE algorithm
to treat bonds involving Hydrogen atoms [35] Enthalpy H was calculated through the MMPBSA
approach [36
,37] according to the same procedure followed previously [26–30]. Namely, H is the sum
of the total gas-phase in vacuo non-bonded energy (Egas) and a solvation term (Gsol = GPB + GNP) [38
]
The polar component of GPB was evaluated using the Poisson-Boltzmann [39] (PB) term while the
non-polar contribution to the solvation energy was calculated as GNP = a (SASA) + b, in which a
= 0.00542 kcal/Å2, b = 0.92 kcal/mol, and the SASA (solvent accessible surface area) was estimated
with the MOLSURF program included in AMBER 12 [40]. The last 100 ns of the MD trajectories were
considered as representative of the equilibrium condition for dendrimer 16 and used for the analysis
of the structural parameters reported in Table S1.
4. Conclusions
An efficient synthesis of dense and chiral dendritic polyols using sugars as multivalent
nanosynthons (glyconanosynthons) at the core and at the repeating units was established. The
click reactions worked best with a catalytic amount of the copper (I) organic catalyst CuI P(OEt)3.
¨
The high yielding synthetic strategy happens to be very versatile, as it permitted access to the
desired functionalized materials by many different alternatives, depending on the surface group
functionality of the building blocks chosen. In addition, the alkenyl and alkynyl surface groups could
be conveniently transformed into dendritic polyols using thiol-ene or thyol-yne reactions using either
thioethanol or thioglycerol, respectively. Hence, the number of OH-groups that could be added can
be readily doubled. Furthermore, in principle, the allyl end groups of 21 can be further transformed
by an additional layer of protected sugar derivative to reach the G3 level via a thiol-ene reaction to
afford dendrimers with 160 hydroxyl groups using thioglycerol and with 320 hydroxyl groups using
2-thiolethyl β-D-glucopyranoside, as shown previously [12,13]. It is also possible to add cysteamine to
the double bond of 21 to construct cationic dendrimers, which may find application as gene transfection
agents. Moreover, the synthesis is able to generate dendrimers with defined stereochemistry and
with more rigidity compared to the existing ones. For instance, polyol 16 had a diameter of 2 nm,
as calculated using molecular dynamic simulations. The strategy described herein can thus provide
dendrimers having a large number of surface functionalities at very low generation efficiently and
rapidly, hence simplifying the entire process of making complex architectures. Work is also in progress
with the cationic equivalents of these structures as gene transfecting agents [13] together with their
potential as chiral catalysts.

Molecules 2016, 21, 448
14 of 16
Supplementary Materials: The following are available online at http://www.mdpi.com/1420-3049/21/4/448/s1:
NMR, MS, IR spectra, GPCs, Table S1 and Figure S1.
Acknowledgments: This work was supported by grants from the Natural Science and Engineering Research
Council of Canada (NSERC) to R. Roy including a Canadian Research Chair.
Author Contributions: T. C. Shiao and R. Rej contributed equally to this work. M. Rose performed the scale-up
experiments; G. M. Pavan made the molecular dynamics simulations. R. Roy conceived the paper, designed the
thematic, and wrote the paper.
Conflicts of Interest: The authors declare no conflict of interest.
References
1.
2.
3.
Caminade, A.-M.; Ouali, A.; Laurent, R.; Olivier Turrin, C. Majoral, J.-P. The dendritic effect illustrated with
phosphorus dendrimers. Chem. Soc. Rev. 2015, 44, 3890–3899. [CrossRef] [PubMed]
Sharma, A.; Kakkar, A. Designing Dendrimer and Miktoarm Polymer Based Multi-Tasking Nanocarriers for
Efficient Medical Therapy. Molecules 2015, 20, 16987–17015. [CrossRef] [PubMed]
Tomalia, D.A.; Naylor, A.M.; Goddard, W.A. Starburst Dendrimers: Molecular-Level Control of Size, Shape,
Surface Chemistry, Topology, and Flexibility from Atoms to Macroscopic Matter. Angew. Chem. Int. Ed. 1990
,
29, 138–175. [CrossRef]
4.
Mignani, S.; El Kazzouli, S.; Bousmina, M.; Majoral, J.P. Expand classical drug administration ways by
emerging routes using dendrimer drug delivery systems: A concise overview. Adv. Drug Deliv. Rev. 2013, 65,
1316–1330. [CrossRef] [PubMed]
5.
6.
7.
8.
Roy, R.; Shiao, T.C. Glyconanosynthons as powerful scaffolds andbuilding blocks for the rapid construction
of multifaceted, dense and chiral dendrimers. Chem. Soc. Rev. 2015, 44, 3924–3941. [CrossRef] [PubMed]
Sowinska, M.; Urbanczyk-Lipkowska, Z. Advances in the chemistry of dendrimers. New J. Chem. 2014, 38,
2168–2203. [CrossRef]
Walter, M.V.; Malkoch, M. Simplifying the synthesis of dendrimers: Accelerated approaches. Chem. Soc. Rev.
2012, 41, 4593–4609. [CrossRef] [PubMed]
Astruc, D.; Boisselier, E.; Ornelas, C. Dendrimers designed for functions: From physical, photophysical,
and supramolecular properties to applications in sensing, catalysis, molecular electronics, photonics, and
nanomedicine. Chem. Rev. 2010, 110, 1857–1959. [CrossRef] [PubMed]
9.
Chabre, Y.M.; Roy, R. Design and creativity in synthesis of multivalent neoglycoconjugates. Adv. Carbohydr.
Chem. Biochem. 2010, 63, 165–393. [PubMed]
10. Chabre, Y.M.; Roy, R. Recent trends in glycodendrimer syntheses and apllications. Curr. Top. Med. Chem.
2008, 8, 1237–1285. [CrossRef] [PubMed]
11. Chabre, Y.M.; Roy, R. Multivalent glycoconjugate syntheses and applications using aromatic scaffolds.
Chem. Soc. Rev. 2013, 42, 4657–4708. [CrossRef] [PubMed]
12. Sharma, R.; Kottari, N.; Chabre, Y.M.; Rej, R.; Saadeh, N.K.; Roy, R. “Onion peel” dendrimers:
A straightforward synthetic approach towards highly diversified architectures. Polym. Chem. 2014, 5,
4321–4331. [CrossRef]
13. Sharma, R.; Zhang, I.; Shiao, T.C.; Pavan, G.M.; Maysinger, D.; Roy, R. Low generation polyamine dendrimers
bearing flexible tetraethylene glycol as nanocarriers for plasmids and siRNA. Nanoscale 2016, 8, 5106–5119.
[CrossRef] [PubMed]
14. Shiao, T.C.; Giguère, D.; Wisse, P.; Roy, R. Synthesis of Phenyl 2,3,4,6-Tetra-O-acetyl-1-thio-
β-D-
galactopyranoside. Carbohydr. Chem. Proven Synth. Methods 2014, 2, 269–274.
15. Mereyala, H.B.; Gurrala, S.R. A highly diastereoselective, practical synthesis of allyl, propargyl
2,3,4,6-tetra-O-acetyl- -D-gluco, -D-galactopyranosides and allyl, propargyl heptaacetyl- -D-lactosides.
Carbohydr. Res. 1998, 307, 351–354. [CrossRef]
β
β
β
16. Ortega-Munoz, M.; Morales-Sanfrutos, J.; Perez-Balderas, F.; Hernandez-Mateo, F.; Giron-Gonzalez, M.D.;
Sevillano-Tripero, N.; Salto-Gonzalez, R.; Santoyo-Gonzalez, F. Click multivalent neoglycoconjugates as
synthetic activators in cell adhesion and stimulation of monocyte/macrophage cell lines. Org. Biomol. Chem.
2007, 5, 2291–2301. [CrossRef] [PubMed]

Molecules 2016, 21, 448
15 of 16
17. Quagliotto, P.; Viscardi, G.; Barolo, C.; D’Angelo, D.; Barni, E.; Compari, C.; Duce, E.; Fisicaro, E. Synthesis
and Properties of New Glucocationic Surfactants: Model Structures for Marking Cationic Surfactants with
Carbohydrates. J. Org. Chem. 2005, 70, 9857–9866. [CrossRef] [PubMed]
18. Paterson, S.; Clark, J.; Stubbs, K.A.; Chirila, T.V.; Baker, M.V. Carbohydrate-based cross-linking agents:
Potential use in hydrogels. J. Polym. Sci. A Polym. Chem. 2011, 49, 4312–4315. [CrossRef]
19. Park, S.; Shin, I. Carbohydrate Microarrays for Assaying Galactosyltransferase Activity. Org. Lett. 2007, 9,
1675–1678. [CrossRef] [PubMed]
20. Kottari, N.; Chabre, Y.M.; Shiao, T.C.; Rej, R.; Roy, R. Efficient and accelerated growth of multifunctional
dendrimers using orthogonal thiol-ene and SN2 reactions. Chem. Commun. 2014, 50, 1983–1985. [CrossRef]
[PubMed]
21. Fleischmann, S.; Komber, H.; Voit, B. Diblock Copolymers as Scaffolds for Efficient Functionalization via
Click Chemistry. Macromolecules 2008, 41, 5255–5264. [CrossRef]
22. Binauld, S.; Hawker, C.J.; Fleury, E.; Drockenmuller, E. A Modular Approach to Functionalized and Expanded
Crown Ether Based Macrocycles Using Click Chemistry. Angew. Chem. Int. Ed. 2009, 48, 6654–6658.
[CrossRef] [PubMed]
23. Grayson, S.M.; Jayaraman, M.; Fréchet, J.M.J. Convergent synthesis and “surface” functionalization of a
dendritic analog of poly(ethylene glycol). Chem. Commun. 1999, 1329–1330. [CrossRef]
24. Papp, I.; Dernedde, J.; Enders, S.; Riese, S.B.; Shiao, T.C.; Roy, R.; Haag, R. Multivalent Presentation of
Mannose on Hyperbranched Polyglycerol and their Interaction with Concanavalin A Lectin. Chembiochem
2011, 12, 1075–1083. [CrossRef] [PubMed]
25. Goyard, D.; Shiao, T.C.; Giguère, D.; Roy, R. Thiol-yne coupling between propargyl 2,3,4,6-tetra-O-acetyl-β-D-
glucopyranoside and dodecanethiol. Access to mono- and bis-adducts. Carbohydr. Chem. Proven Synth. Methods
2015, 3, 117–125.
26. Pavan, G.M. Modeling the interaction between dendrimers and nucleic acids: A molecular perspective
through hierarchical scales. Chem. Med. Chem. 2014, 9, 2623–2631. [CrossRef] [PubMed]
27. Enciso, A.E.; Garzoni, M.; Pavan, G.M.; Simanek, E.E. Influence of linker groups on the solubility of triazine
dendrimers. New J. Chem. 2015, 39, 1247–1252. [CrossRef]
28. Pavan, G.M.; Barducci, A.; Albertazzi, L.; Parrinello, M. Combining metadynamics simulation and
experiments to characterize dendrimers in solution. Soft Matter 2013, 9, 2593–2597. [CrossRef]
29. Liu, Y.; Bryantsev, V.S.; Diallo, M.S.; Goddard, W.A. PAMAM dendrimers undergo pH responsive
conformational changes without swelling. J. Am. Chem. Soc. 2009, 131, 2798–2799. [CrossRef] [PubMed]
30. Caminade, A.M.; Fruchon, S.; Turrin, C.O.; Poupot, M.; Ouali, A.; Maraval, A.; Garzoni, M.; Maly, M.;
Furer, V.; Kovalenko, V.; et al. The key role of the scaffold on the efficiency of dendrimer nanodrugs.
Nat. Commun. 2015, 6. [CrossRef] [PubMed]
31. Case, D.A.; Darden, T.A.; Cheatham, T.E., III; Simmerling, C.L.; Wang, J.; Duke, R.E.; Luo, R.; Walker, R.C.;
Zhang, W.; Merz, K.M.; et al. AMBER 12; University of California: San Francisco, CA, USA, 2012.
32. Wang, J.; Wolf, R.M.; Caldwell, J.W.; Kollman, P.A.; Case, D.A. Development and testing of a general Amber
force field. J. Comput. Chem. 2004, 25, 1157–1174. [CrossRef] [PubMed]
33. Jorgensen, W.L.; Chandrasekhar, J.; Madura, J.D.; Impey, R.W.; Klein, M.L. Comparison of simple potential
functions for simulating liquid water. J. Chem. Phys. 1983, 79, 926–935. [CrossRef]
34. Darden, T.; York, D.; Pedersen, L. Particle mesh Ewald: An N
systems. J. Chem. Phys. 1993, 98, 10089–10092. [CrossRef]
¨
log(N) method for Ewald sums in large
35. Kräutler, V.; van Gunsteren, W.F.; Hunenberger, P.H. A fast SHAKE algorithm to solve distance constraint
equations for small molecules in molecular dynamics simulations. J. Comput. Chem. 2001, 22, 501–508.
[CrossRef]
36. Kollman, P.A.; Massova, I.; Reyes, C.; Kuhn, B.; Huo, S.H.; Chong, L.; Lee, M.; Lee, T.; Duan, Y.; Wang, W.;
et al. Calculating structures and free energies of complex molecules: Combining molecular mechanics and
continuum models. Acc. Chem. Res. 2000, 33, 889–897. [CrossRef] [PubMed]
37. Srinivasan, J.; Cheatham, T.E.; Cieplak, P.; Kollman, P.A.; Case, D.A. Continuum Solvent Studies of the
Stability of DNA, RNA, and Phosphoramidate-DNA Helices. J. Am. Chem. Soc. 1998, 120, 9401–9409.
[CrossRef]

Molecules 2016, 21, 448
16 of 16
38. Jayaram, B.; Sprous, D.; Beveridge, D.L. Solvation free energy of biomacromolecules: Parameters for a
modified generalized born model consistent with the AMBER force field. J. Phys. Chem. 1998, 102, 9571–9576.
[CrossRef]
39. Sitkoff, D.; Sharp, K.A.; Honig, B. Accurate calculation of hydration free energies using macroscopic solvent
models. J. Phys. Chem. 1994, 98, 1978–1988. [CrossRef]
40. Connolly, M.L. Analytical molecular surface calculation. J. Appl. Cryst. 1983, 16, 548–558. [CrossRef]
Sample Availability: Not available.
©
2016 by the authors; licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons by Attribution
(CC-BY) license (http://creativecommons.org/licenses/by/4.0/).
