Substrate-Selective Supramolecular Tandem Assays:
Monitoring Enzyme Inhibition of Arginase and Diamine
Oxidase by Fluorescent Dye Displacement from Calixarene
and Cucurbituril Macrocycles
Werner M. Nau,* Garima Ghale, Andreas Hennig, Hu¨seyin Bakirci, and
David M. Bailey
School of Engineering and Science, Jacobs UniVersity Bremen, Campus Ring 1,
D-28759 Bremen, Germany
Received May 22, 2009; E-mail: w.nau@jacobs-university.de
Abstract: A combination of moderately selective host-guest binding with the impressive specificity of
enzymatic transformations allows the real-time monitoring of enzymatic reactions in a homogeneous solution.
The resulting enzyme assays (“supramolecular tandem assays”) exploit the dynamic binding of a fluorescent
dye with a macrocyclic host in competition with the binding of the substrate and product. Two examples of
enzymatic reactions were investigated: the hydrolysis of arginine to ornithine catalyzed by arginase and
the oxidation of cadaverine to 5-aminopentanal by diamine oxidase, in which the substrates have a higher
affinity to the macrocycle than the products (“substrate-selective assays”). The depletion of the substrate
allows the fluorescent dye to enter the macrocycle in the course of the enzymatic reaction, which leads to
the desired fluorescence response. For arginase, p-sulfonatocalix[4]arene was used as the macrocycle,
which displayed binding constants of 6400 M-1 with arginine, 550 M-1 with ornithine, and 60 000 M-1 with
the selected fluorescent dye (1-aminomethyl-2,3-diazabicyclo[2.2.2]oct-2-ene); the dye shows a weaker
fluorescence in its complexed state, which leads to a switch-off fluorescence response in the course of the
enzymatic reaction. For diamine oxidase, cucurbit[7]uril (CB7) was used as the macrocycle, which showed
binding constants of 4.5 × 106 M-1 with cadaverine, 1.1 × 105 M-1 with 1-aminopentane (as a model for
the thermally unstable 1-aminopentanal), and 2.9 × 105 M-1 with the selected fluorescent dye (acridine
orange, AO); AO shows a stronger fluorescence in its complexed state, which leads to a switch-on
fluorescence response upon enzymatic oxidation. It is demonstrated that tandem assays can be successfully
used to probe the inhibition of enzymes. Inhibition constants were estimated for the addition of known
inhibitors, i.e., S-(2-boronoethyl)-L-cysteine and 2(S)-amino-6-boronohexanoic acid for arginase and
potassium cyanide for diamine oxidase. Through the sequential coupling of a “product-selective” with a
“substrate-selective” assay it was furthermore possible to monitor a multistep biochemical pathway, namely
the decarboxylation of lysine to cadaverine by lysine decarboxylase followed by the oxidation of cadaverine
by diamine oxidase. This “domino tandem assay” was performed in the same solution with a single reporter
pair (CB7/AO).
Introduction
on the competitive encapsulation of a fluorescent dye and an
enzymatic product by macrocyclic hosts to monitor enzymatic
The monitoring of enzymatic processes is of fundamental
importance for the understanding of biological phenomena.1
Inspired by indicator displacement and synthetic pore strate-
gies,2-13 we have recently introduced a label-free method based
reactions (Scheme 1).14-16 In our previous examples, the
investigated enzymes transformed a weak competitor (substrate)
into a strong competitor (product) which displaced the fluores-
(9) Das, G.; Talukdar, P.; Matile, S. Science 2002, 298, 1600–1602.
(10) Sorde, N.; Das, G.; Matile, S. Proc. Natl. Acad. Sci. U.S.A. 2003,
100, 11964–11969.
(11) Litvinchuk, S.; Tanaka, H.; Miyatake, T.; Pasini, D.; Tanaka, T.;
Bollot, G.; Mareda, J.; Matile, S. Nat. Mater. 2007, 6, 576–580.
(12) Mora, F.; Tran, D.-H.; Oudry, N.; Hopfgartner, G.; Jeannerat, D.;
Sakai, N.; Matile, S. Chem.sEur. J. 2008, 14, 1947–1953.
(13) Sakai, N.; Mareda, J.; Matile, S. Acc. Chem. Res. 2008, 41, 1354–
1365.
(1) Reymond, J.-L.; Fluxa`, V. S.; Maillard, N. Chem. Commun. 2009,
34–46.
(2) Inouye, M.; Hashimoto, K.; Isagawa, K. J. Am. Chem. Soc. 1994,
116, 5517–5518.
(3) Koh, K. N.; Araki, K.; Ikeda, A.; Otsuka, H.; Shinkai, S. J. Am.
Chem. Soc. 1996, 118, 755–758.
(4) Niikura, K.; Anslyn, E. V. J. Chem. Soc., Perkin Trans. 2 1999, 2769–
2775.
(5) Wiskur, S. L.; Ait-Haddou, H.; Lavigne, J. J.; Anslyn, E. V. Acc.
Chem. Res. 2001, 34, 963–972.
(14) Hennig, A.; Bakirci, H.; Nau, W. M. Nat. Methods 2007, 4, 629–
632.
(6) Nguyen, B. T.; Anslyn, E. V. Coord. Chem. ReV. 2006, 250, 3118–
3127.
(15) Bailey, D. M.; Hennig, A.; Uzunova, V. D.; Nau, W. M. Chem.sEur.
J. 2008, 14, 6069–6077.
(7) Zhang, T.; Anslyn, E. V. Org. Lett. 2007, 9, 1627–1629.
(8) Zhu, L.; Anslyn, E. V. J. Am. Chem. Soc. 2004, 126, 3676–3677.
(16) Praetorius, A.; Bailey, D. M.; Schwarzlose, T.; Nau, W. M. Org.
Lett. 2008, 10, 4089–4092.
9
11558 J. AM. CHEM. SOC. 2009, 131, 11558–11570
10.1021/ja904165c CCC: $40.75  2009 American Chemical Society

Substrate-Selective Supramolecular Tandem Assays
A R T I C L E S
Scheme 1. Product- versus Substrate-Selective Tandem Assays for Monitoring Enzymatic Activity
cent dye from the macrocycle and effected a concomitant change
in its fluorescent properties. This method can be described as a
“product-selective supramolecular tandem assay”, because the
enzymatic product acts as the analyte responsible for the stronger
competitive binding and associated fluorescence response
(Scheme 1, top). We have further suggested that the macrocyclic
hosts in these types of continuous enzyme assays serve as cheap
substitutes for antibodies, which have become indispensable in
enzyme assays.17-20 We also demonstrated that the lower
selectivity of macrocycles14,15 (as opposed to highly specific
antibodies) toward the binding of different, structurally related
products21,22 can be used as an advantage in the development
of enzyme assays, because it allows access to several enzymes
affecting closely related functional group interconversions.
ably strong binding and slow release kinetics,23 which would
prevent a real-time response in a substrate-specific enzyme
assay. In contrast, macrocyclic receptors bind analytes more
weakly and reversibly through supramolecular interactions,
which is essential for substrate-selective tandem assays to be
performed.
Besides the conceptual advancement, our present study is
original in that we expand the range of tandem assays to two
new enzymes (arginase and diamine oxidase versus the previ-
ously studied amino acid decarboxylases) and two additional
enzyme classes (a hydrolase (EC3) and an oxidoreductase (EC1)
versus the previously documented examples of several lyases
(EC4)). Moreover, we apply an additional reporter pair, namely
cucurbit[7]uril (CB7)/acridine orange (AO)24 and demonstrate
for the first time the potential of tandem assays for inhibitor
screening. Finally, we show that the working principle of tandem
assays is not limited to enzymatic reactions in which the charge
status in substrate versus product is altered, and where several
orders of magnitude difference in binding constants apply.
Instead, it can be extended to more subtle structural variations,
such as the size or shape of substrate and product, which are
also associated with much smaller variations in affinity to the
macrocycle (factor of 10).
We now find that macrocycles in combination with simple
fluorescent dyes not only can substitute antibodies in product-
selective enzyme assays but also allow for a different line of
enzyme assays in which the substrate binds more tightly to the
receptor and competes with the fluorescent dye. This establishes
the concept of a “substrate-selective tandem assay” (Scheme 1,
bottom) in which the enzymatic reaction occurs with the
uncomplexed substrate. The latter is in a rapid dynamic
supramolecular equilibrium with the host-substrate complex,
allowing for a continuous fluorescence signaling of the ongoing
enzymatic reaction. The possibility of using substrate-selective
macrocycles substantially broadens the applicability of tandem
assays and opens new opportunities, because comparable
enzyme assays with continuous monitoring based on substrate-
specific antibodies are nonfeasible. Biological receptors bind
analytes through antibody-antigen interactions which, while
highly specific and exceedingly strong, suffer from an unfavor-
Results
Conceptual Approach. Once an enzymatic reaction of interest
has been identified for which a supramolecular tandem assay
should be set up according to Scheme 1, a suitable reporter pair
needs to be identified. The macrocyclic component of the
reporter pair must necessarily display a sufficiently large binding
differentiation between the substrate and the product of the
enzymatic reaction. As will be seen herein, even a rather small
variation in binding constants by 1 order of magnitude can be
sufficient to conduct the assay. Furthermore, it should display
a sizable binding with either the substrate (for a substrate-
