130
F.G. Ferreira de Paula et al. / Catalysis Communications 42 (2013) 129–133
2.2. Catalytic tests
Reactions under air were carried out in a glass reactor (50 mL)
equipped with a magnetic stir bar and a septum. In a typical run, the
catalyst was dissolved in CH3OH (ca. 25 mL), the reactor temperature
was adjusted to 55 °C, and then substrate (12.5 mmol) was added and
the reaction started. All nitrate salts and the iron salts were used in
hydrated form as commercially available. When necessary, the system
was first evacuated and submitted to gas flux (i.e., dioxygen) at room
temperature and then pressurized to 0.10 MPa. Careful optimization
of the stirring rate excluded the possibility of controlling by diffusion.
Scheme 1. Main oxidation products of β-pinene by dioxygen in CH3OH solutions con-
taining Fe(NO3)3 in the presence or absence of palladium.
2.3. Reaction monitoring and product identification
with dioxygen in the presence or absence of Pd(OAc)2, were rigorously
the same.
Reactions were monitored by analyzing aliquots taken at regular
time intervals by gas chromatography (Varian 450 instrument, FID,
Carbowax 20 M capillary column). Conversions were estimated from
the corresponding peak areas in comparison with the corresponding
calibrating curves.
In general, the products were identified on a Shimadzu MS-QP
5050A mass spectrometer instrument operating at 70 eV, coupled
with a Shimadzu 17A GC, by comparing the corresponding retention
times with those of authentic samples and by inspecting the mass spec-
tra. The procedures to purification by silica column as well as the data
of NMR and FT-IR spectroscopy analyses of two main products are in
the supplementary material.
Although of Pd(OAc)2 catalyst has remained stable throughout reac-
tions (i.e., no Pd(0) formation was detected) (Exps. 1–3, Table 1), it was
inactive in the β-pinene oxidation. Actually, the highest conversion and
oxidation selectivity were reached in the only in the reactions where
Fe(NO3)3 was present, regardless of palladium presence. Thus, it can
be concluded that Pd(OAc)2 was an inactive catalyst in the β-pinene
oxidation by dioxygen in CH3OH. Moreover, regardless of the co-
oxidants concentration, only Fe(NO3)3 was an effective catalyst.
The major product of β-pinene oxidation was isolated and identi-
fied by 1H and 13C NMR spectroscopy as myrtenol methyl ether (1a),
a product previously obtained by us via Pd(II)-catalyzed oxidations
(Scheme 1) [15].
Remarkably, among the nitrate salts employed, only Fe(NO3)3 pro-
moted the oxidation of β-pinene by dioxygen. It should be noted that
the possibility of stoichiometric oxidation of β-pinene by NO−3 anions
is discarded because both LiNO3 and Cu(NO3)2 failed in the same reac-
tion, even when used in stoichiometric proportions (i.e., considering
the total reduction of NO−3 ions, entries 5 and 7, Table 1). Thus, it can
be concluded that Fe(NO3)3 salt truly acted as a catalyst in β-pinene
oxidation by dioxygen.
Beyond promoting β-pinene oxidation by dioxygen, Fe(NO3)3 cata-
lyst also provoked its isomerization into two other monoterpenes and
the conversion them into respective ethers (i.e., identified by GC-MS
analyses) (Scheme 2).
3. Results and discussion
3.1. General aspects
Fe(NO3)3 has been used as the reoxidant in the oxidation reactions
of monoterpenes by dioxygen using palladium catalysts [10]. Generally,
CH3COOH was used as solvent because the Pd(0) oxidation into Pd(II)
occurs more quickly in protic solvent. However, oxidation selectivity is
generally compromised by the solvent's acidity, which provokes con-
current reactions, such as carbon skeletal rearrangement followed by
nucleophilic addition, lowering the yield of oxidation products [9,10].
For these reasons, the first objective herein was investigating the effect
of CH3COOH replacement by CH3OH, in Pd(OAc)2/Fe(NO3)3-catalyzed
monoterpene oxidation by dioxygen.
3.3. Effect of Fe(NO3)3 catalyst concentration on the oxidation of β-pinene
3.2. β-Pinene oxidation by dioxygen in Pd(OAc)2/M(NO3)n/CH3OH
(M = Li (I), Cu(II) or Fe(III); n = 1, 2 or 3) system: Fe(III) cations
as the real catalysts
The discovery of Fe(NO3)3-catalyzed β-pinene oxidation by dioxygen
was extremely welcome because the Pd(OAc)2 is much more expensive
than Fe(NO3)3. The Fe(NO3)3 concentration effects on the conversion
and selectivity of β-pinene oxidation were assessed in a broad range of
concentrations (i.e., 0.010–1.200 mmol). The main results are summa-
rized in the Table 2.
As a general tendency, it can be observed that either conversion,
as well as the selectivity obtained from the oxidation of β-pinene
Table 1
β-pinene oxidation by dioxygen in Pd(OAc)2/M(NO3)n (M = Li(I), Cu(II) or Fe(III); n = 1, 2, or 3) system.a
Exp.
Nitrate
Concentration (mmol)
Conversion (%)
Products selectivity (%)
Isomersb
Ethersc
Myrtenol methyl ether
62
Othersd
1e
2e
3e
4
5
6
LiNO3
3.6
1.8
1.2
3.6
6.25
1.8
3.125
1.2
b3
b3
97
b3
b3
b3
3
100
100
6
100
100
100
100
5
Cu(NO3)2
Fe(NO3)3
LiNO3
12
20
20
Cu(NO3)2
Fe(NO3)3
7
8
97
13
62
a
Reaction conditions: β-pinene (12.5 mmol); methyl alcohol (25 mL); 55 °C; dioxygen (0.10 MPa); 8 hour reaction.
α and γ-terpinenes were formed in almost equimolar amounts.
α and γ-terpinyl methyl ethers were formed in almost equimolar amounts.
Complex mixture of non-identified minority products.
b
c
d
e
Reaction containing Pd(OAc)2 (0.010 mmol); no Pd(0) species were formed.
