Abstract: Spectroscopic, electrochemi-
cal and density functional theory
(DFT) methods have been employed
time studies and DFT calculations sug-
gest that multiple dp(Re)!p*(phen)
metal-to-ligand charge transfers
(MLCTs) exist for each complex, two
of which significantly absorb at about
340 and 385 nm, and one that emits at
approximately 540 nm. In the com-
plexes containing more-conjugated HT
ligands, non-emissive intraligand transi-
tions (IL(HT)) exist with energies be-
tween the ground and MLCT excited
states. The overlap of these IL(HT) tran-
sitions and the absorbing MLCT of
lowest energy deactivates emission re-
sulting from about 385 nm excitation,
and lowers the quantum yield and ex-
cited-state lifetimes of these complexes.
Cyclic voltammetry experiments indi-
cate that throughout the series investi-
gated, the highest occupied molecular
orbital (HOMO) of each complex is
centred on the HT ligand, while the oc-
cupied molecular orbitals localised on
the rhenium are lower in energy.
AHCTUNGTRENNUNG
to
investigate
a
group
complexes
of
[Re(CO)3(HT)ACHTUNGTRENNUNG
(phen)]+
(phen=1,10-phenanthroline), and in
particular the level of electronic com-
munication between various hole-trans-
porting (HT) ligands and the rhenium
centre. Here, the HT ligand consists of
a coordinating pyridine connected to
dimethylaniline group through a sin-
gle-, double- or triple-bond-connecting
system. Electronic absorption, reso-
nance Raman, and steady-state emis-
sion spectroscopy combined with life-
Keywords: electrochemistry · elec-
tronic structure · light-emitting di-
odes · UV/Vis spectroscopy · transi-
tion metals
Introduction
This study looks at an alternate approach to the design of
OLED materials in which the hole-transporting (HT), elec-
tron-transporting (ET) and emissive layers shown in
Figure 1 are reduced to functional groups within a trifunc-
tional molecule (Figure 2a). The hypothesis is that the tri-
Since the first organic light emitting diode (OLED) was
shown to exhibit high emission efficiency, fast response and
a low turn on voltage,[1] considerable research has focused
on developing OLED materials that further optimise these
parameters. The majority of those investigated have been
based on the multilayer device structure employed by Tang
and VanSlyke (similar to Figure 1).[1,2] However, while some
of these exhibit promising characteristics, the best often in-
volve layered structures more complex than that of Figure 1,
and there is still room for improvement in regards to the
key operation parameters.[3,4]
Figure 1. The basic structure of a typical multilayer OLED device. Elec-
trons and holes move through the electron-transporting (ET) and hole-
transporting (HT) layers, respectively, to recombine on the emitting
layer, form an exciton and radiatively decay.
Figure 2. The function of each moiety within a trifunctional OLED mole-
cule.
[a] D. M. Cleland, Dr. G. Irwin, Prof. K. C. Gordon
Department of Chemistry and
functional molecules act in a similar fashion to a multilayer
device. When a potential is applied, electrons are injected
into the lowest unoccupied molecular orbital (LUMO) of
the ET moiety and holes into the highest occupied molecu-
lar orbital (HOMO) of the HT moiety. These charges then
travel towards the emissive functional group where they re-
combine, form an exciton, and decay to produce the ob-
served light emission (Figure 2b).[5]
MacDiarmid Institute for Advanced Materials and Nanotechnology
University of Otago, Union Place
PO Box 56, Dunedin (New Zealand)
Fax : (+64)3-479-7906
[b] Dr. P. Wagner, Prof. D. L. Officer
ARC Centre of Excellence for Electromaterials Science
Intelligent Polymer Research Institute
University of Wollongong
Use of these trifunctional compounds will reduce the
number of layers required in OLEDs, resulting in simpler
Wollongong NSW 2522 (Australia)
Chem. Eur. J. 2009, 15, 3682 – 3690
ꢀ 2009 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
3683
