Improved synthesis of enantiopure 4-hydroxy[2.2]paracyclophane

Article abstract of DOI:10.1021/jo100468s

(Figure presented) 4-Hydroxy[2.2]paracyclophane is readily prepared via an improved synthetic protocol from unsubstituted [2.2]paracyclophane. The key step is a Dakin oxidation of 4-formyl[2.2]paracyclophane. This allows a rapid access to large quantities of the product and an easy synthesis of the enantiopure form.

Full text of DOI:10.1021/jo100468s

pubs.acs.org/joc
aldehydes4 and imines,5 oxidations of thioethers,6 trime-
Improved Synthesis of Enantiopure
4-Hydroxy[2.2]paracyclophane
thylsilylcyanation,7 and allylboration.8
Most of such ligands can be described as derivatives of
4-hydroxy[2.2]paracyclophane (3) and are obtainable from
this compound.
€
Christian J. Friedmann, Sefer Ay, and Stefan Brase*
Since its first synthesis by Cram in 1955,9 much effort has
been made to develop more efficient synthesis protocols to
this compound.10,11 Today, 3 is usually prepared on a large
scale by a method developed by Krohn and Hopf (Scheme 1).12
Institute of Organic Chemistry, Karlsruhe
Institute of Technology, Fritz-Haber-Weg 6,
D-76131 Karlsruhe, Germany
braese@kit.edu
SCHEME 1. Conventional Synthesis of 312
Received March 20, 2010
Starting from unsubstituted [2.2]paracyclophane (1), an aro-
matic substitution with bromine under iron catalysis is carried
out. The obtained 4-bromo[2.2]paracyclophane (2) is then
converted into the desired product by a one-pot proce-
dure consisting of a Br-Li exchange, transmetalation onto
boron, and an oxidative workup with a mixture of potassium
hydroxide and hydrogen peroxide. Although this procedure is
accomplishable, the second step is usually critical, and the yield
ranges from 6513 to 82%.14
In order to obtain enantiopure material, the subsequent
resolution requires two additional steps. Auxiliaries known
in the literature15 for this purpose are acid chlorides, derived
from camphanic acid (4)16 and naproxene (5, Figure 1),17
which convert 3 into the corresponding diastereomeric
4-Hydroxy[2.2]paracyclophane is readily prepared via an
improved synthetic protocol from unsubstituted [2.2]para-
cyclophane. The key step is a Dakin oxidation of 4-formyl-
[2.2]paracyclophane. This allows a rapid access to large
quantities of the product and an easy synthesis of the
enantiopure form.
