Full Paper
quenched by the addition of saturated ammonium chloride solu-
tion and the mixture left to warm to room temperature. The two
layers were separated, and the aqueous layer was extracted with
ethyl acetate (3 × 100 mL). The combined organic layers were dried
with MgSO4, filtered, and concentrated in vacuo. The crude product
was purified by column chromatography on silica gel by using hex-
ane/ethyl acetate (8:2, v/v). The product was obtained as a colorless
oil (16.7 mmol, 3.7 g, 45 %). 1H NMR (CDCl3, 400 MHz): δ = 7.30–
7.26 (m, 2 H, Ar), 7.21–7.16 (m, 3 H, Ar), 4.19–4.14 (q, J = 7.1 Hz, 2
H, OCH2CH3), 4.04–3.99 (td, J1 = 8.3, J2 = 4.2 Hz, 1 H, CHOH), 3.06
(br. s, 1 H, OH), 2.82–2.80 (m, 1 H, CH2), 2.72–2.66 (m, 1 H, CH2),
2.52–2.40 (m, 2 H, CH2), 1.91–1.78 (m, 1 H, CH2), 1.78–1.64 (m, 1 H,
CH2), 1.28–1.25 (t, J = 7.2 Hz, 3 H, OCH2CH3) ppm. 13C NMR (CDCl3,
100 MHz): δ = 172.9, 141.7, 128.4, 128.4, 125.9, 67.2, 60.7, 41.3, 38.1,
31.7, 14.1 ppm. C13H18O3 (222.3): calcd. C 70.24, H 8.16; found C
70.11, H 8.33. HPLC (C-18 Luna): tr = 21.5 min. HPLC (OD-H Chiralcel):
tr1 = 7.1 min, tr2 = 8.1 min.
tion optimization, both enantiomers of ethyl 3-hydroxy-5-
phenylpentanoate were obtained with excellent optical purities
and high yields. The utility of the identified catalysts was show-
cased by carrying out the reaction on a preparative scale.
Experimental Section
General Remarks: 1H and 13C NMR spectra were recorded in CDCl3
solution with a Varian Gemini 400 MHz spectrometer. Chemical
shifts are expressed in parts per million (ppm) by using TMS as
an internal standard. Recombinant dehydrogenases and whole-cell
biocatalysts are from the collection of the Institute of Chemistry –
Organic and Bioorganic Chemistry, University of Graz. All chemicals
were commercial products of analytical grade. TLC was performed
by using Kieselgel 60 F254 aluminium sheets (Merck). Optical-rota-
tion measurements were executed with a Jasco P-2000 polarimeter.
For the determination of product (1) yields and substrate (2) con-
versions, 1.2 mL samples dissolved in methanol were analyzed by
HPLC with a Shimadzu Prominence LC-20A series instrument cou-
pled to a UV/Vis detector. A LUNA C-18 column (Phenomenex,
250 mm × 4.6 mm × 5 μm) was used with the following conditions:
eluent water/acetonitrile; low-pressure gradient from 100 % of wa-
ter to 100 % of acetonitrile over 20 min, 100 % of acetonitrile for
5 min, back to 100 % water over 5 min, 100 % water for 2 min;
temperature 30 °C; flow 0.5 mL min–1; λ = 210 nm. For the determi-
nation of product (1) ee values, 1.2 mL samples dissolved in meth-
anol were analyzed by HPLC with a Shimadzu Prominence LC-20A
series instrument coupled with a UV/Vis detector. A Chiralcel OD-H
column (Daicel, 250 mm × 4.6 mm × 5 μm) was used with the fol-
lowing conditions: eluent heptane/2-propanol (90:10, v/v); tempera-
ture 30 °C; flow 1.0 mL min–1; λ = 210 nm.
Ethyl 3-Oxo-5-phenylpentanoate (2): Jones reagent was prepared
by the addition of concentrated H2SO4 (30 mL) to CrO3 (33.5 g)
followed by careful dilution with water to give 250 mL of total solu-
tion. Then Jones reagent (17 mL, 17 mmol) was added dropwise to
a stirred solution of ethyl 3-hydroxy-5-phenylpentanoate (16 mmol,
3.55 g) in acetone (70 mL) at 0 °C. The solution was left to warm to
room temperature and stirred for 3 h. After this time, methanol
(7 mL) was added to quench any excess of the Jones reagent. The
mixture was extracted with Et2O (70 mL), the organic layer was
washed with water (3 × 50 mL) and brine (50 mL) and dried with
MgSO4. The crude product was purified by column chromatography
on silica gel by using hexane/ethyl acetate (8:2, v/v). The product
was obtained as colorless oil (67 %, 10.7 mmol, 2.36 g). 1H NMR
(CDCl3, 400 MHz): δ = 7.30–7.26 (m, 2 H, Ar), 7.21–7.17 (m, 3 H, Ar),
4.20–4.15 (m, 2 H, OCH2CH3), 3.41 (s, 2 H, COCH2CO), 2.93–2.86 (m,
4 H, 2 CH2), 1.28–1.24 (t, J = 7.2 Hz, 3 H, OCH2CH3) ppm. 13C NMR
(CDCl3, 100 MHz): δ = 201.8, 167.1, 140.5, 128.5, 128.3, 126.2, 61.4,
49.4, 44.5, 29.4, 14.1 ppm. C13H16O3 (220.3): calcd. C 70.89, H 7.32;
found C 70.97, H 7.43. HPLC (C-18 Luna): tr = 22.8 min.
Screening Procedure: Whole-cell biocatalysts (10 mg) were sus-
pended in reaction solution (500 μL), containing glucose dehydro-
genase (1 mg mL–1), 20 m
M
glucose, 0.5 m
M
NADH, 0.5 m
M NADPH,
10 m
M
substrate in a mixture of 100 m
M Tris-HCl buffer pH 7.5/2-
propanol (90:10, v/v). Biotransformations were conducted at 30 °C
and 120 rpm in a thermoshaker for 20 h. After this time, the reaction
mixture was extracted with ethyl acetate, centrifuged, and the su-
pernatant was transferred to an HPLC vial. The solvent was evapo-
rated under an air flow, the residue was re-dissolved in HPLC-grade
MeOH, and the samples were analyzed by HPLC.
Acknowledgments
We gratefully acknowledge the financial support of the National
Science Center (project Harmonia, no. 2014/14/M/ST5/00030)
and COST Action (CM1303, Systems Biocatalysis).
Preparative-Scale Procedure: Whole-cell biocatalyst (2 g) was sus-
pended in reaction solution (100 mL), containing glucose dehydro-
Keywords: Biotransformations · Dehydrogenase ·
Bioreduction · Asymmetric synthesis · Hydroxy esters ·
Biocatalysis
genase (1 mg mL–1), 20 m
M
glucose, 0.5 m
M
NADH, 0.5 m
M NADPH,
1 mmol of substrate in a mixture of 100 m
M
Tris-HCl buffer pH 7.5/
2-propanol (90:10, v/v). Biotransformations were conducted at 30 °C
and 120 rpm in a thermoshaker for 48 h. After this time, the biocata-
lyst was removed by centrifugation, and the reaction mixture was
extracted with ethyl acetate. The organic phase was separated,
dried (MgSO4), concentrated under reduced pressure, and the prod-
uct was purified by column chromatography on silica gel with pe-
troleum ether/ethyl acetate as eluent.
[1] M. Zysk, A. Zadlo, A. Brodzka, C. Wisniewska, R. Ostaszewski, J. Mol. Catal.
B 2014, 102, 225–229.
[2] D. M. Tsachen, L. M. Fuentes, J. E. Lynch, W. L. Laswell, R. P. Volante, I.
Shinkai, Tetrahedron Lett. 1988, 29, 2779–2782.
[3] A. Kramer, H. Pfader, Helv. Chim. Acta 1982, 65, 293–301.
[4] K. Mori, Tetrahedron 1989, 45, 3233–3298.
[5] M. Reiter, S. Ropp, V. Gouverneur, Org. Lett. 2004, 6, 91–94.
[6] K. Toribatake, L. Zhou, A. Tsuruta, H. Nishiyama, Tetrahedron 2013, 69,
3551–3560.
[7] A. Kamal, T. Krishnaji, G. B. R. Khanna, Tetrahedron Lett. 2006, 47, 8657–
8660.
Ethyl 3-Hydroxy-5-phenylpentanoate (1): To a precooled solution
(0 °C) of diisopropylamine (9 mL, 63.4 mmol, 1.7 equiv.) in anhy-
drous THF (280 mL), was added nBuLi (2.7
M in heptane, 20.7 mL,
55.8 mmol) under argon. The resulting reaction mixture was stirred
at 0 °C for 30 min and then cooled to –78 °C. Ethyl acetate (5.4 mL,
55.8 mmol, 1.5 equiv.) in anhydrous THF was added dropwise, and
the mixture was stirred at –78 °C for 1 h. After this time, 3-phenyl-
propionaldehyde (5 mL, 37.2 mmol, 1 equiv.) in anhydrous THF
(10 mL) was added. After stirring at –78 °C for 3 h, the reaction was
[8] C. Wolfand, M. Moskowitz, J. Org. Chem. 2011, 76, 6372–6376.
[9] N. Athanasiou, A. J. Smallridge, M. A. Trewhella, J. Mol. Catal. B 2001, 11,
893–896.
[10] R. Csuk, B. I. Glaenzer, Chem. Rev. 1991, 91, 49–97.
