Enrofloxacin behavior in presence of soil extracted organic matter: An
electrochemical approach
Monica Antilén*1,4, Camila Valencia2, Emilia Peralta2, Camila Canales1, Christian Espinosa-
Bustos1, Mauricio Escudey3,4
1 Pontificia Universidad Católica de Chile, Facultad de Química, Vicuña Mackenna 4860,
7820436, Santiago, Chile. +56226864745, mantilen@uc.cl
2 Universidad Tecnológica Metropolitana, Facultad de Ciencias Naturales, Matemáticas y del
Medioambiente, Av. José Pedro Alessandri 1242, Santiago, Chile.
3 Universidad de Santiago de Chile USACH, Av. L.B. O`Higgins 3363, Estación Central, Chile
Departamento de Química de los materiales, Facultad de Química y Biología,
4 Centro de Desarrollo de Nanociencia y Nanotecnología, CEDENNA, Av. B. O'Higgins 3363,
Santiago 7254758, Chile
Graphical abstract
1

ABSTRACT
In this work, a novel and simple method aimed at determining and quantifying Enrofloxacin in
presence of Natural Organic Matter (NOM) is proposed. The method was based on the
electrochemical oxidation of Enrofloxacin by using cyclic voltammetry as technique. It was
found that this analyte presents a good electroactivity, in absence and in presence of NOM.
However, this electrochemical behavior is highly pH-dependent, since the reaction is more
favorable when less acid the media is. At this point, different pH values were studied in order to
corroborate this phenomenon. Additionally, kinetic studies were done to determine the control of
the reaction, the number of transferred electrons in the entire process and the rate determining
step of the reaction by analyzing the Tafel slope. With these antecedents, a mechanism was
proposed and the final product of the reaction was corroborated by using LC-MS. Finally,
analytical parameters were studied with the aim of proposing this new method as an
electrochemical sensor of Enrofloxacin. It was found that the method is highly linear, precise and
accurate. Moreover, this method is not only sensitive but also selective to Enrofloxacin in
presence of NOM, in comparison to spectrophotometric methods previously reported.
KEYWORDS: Natural Organic Matter, Enrofloxacin electro-oxidation, volcanic soils,
Selectivity
2

1. INTRODUCTION
Agricultural soil management is frequently associated to an agricultural practice to incorporate
stabilizer amendments, as well as to the use of organic wastes as soil improvers. In this context,
the massive use of antibiotics at veterinary level [1,2] and the application of animal waste to
agricultural soils, impacts the role played by this kind of practices, becoming an incorporation
process and environmental pollution. In this regard, unlike waste from wastewater treatment
(biosolids), which have a pretreatment before its application to agricultural soils, animal waste
(guano) is not treated previous to re-use, causing a clear incorporation of antimicrobials into
agricultural soils. Reports in the 80's indicated that more than half of the antibiotics used in
animals are excreted through the feces in their original form [3]. Subsequently it was shown that
more than 90% of the drugs may be unloaded through animals feces and urine [4], being residues
of these drugs redistributed by a series of migration and degradation processes in soils and
groundwater. Therefore, the veterinary antibiotics are being incorporated into the environment,
mainly through the disposal of animal manure and/or biosolids over agricultural soils. In this
regard, recently the World Health Organization (WHO) has pointed out that the lack of
antimicrobial antibiotics availability now it is a reality and that therefore research related to these
drugs, even more at environmental level (environmental matrices), it is a critical and priority
research area.
On the other hand, fluoroquinolones are among the most persistent antibiotics in soil, remaining
in soil for months, with average half-life > 60 days [5,6] after a process of fertilization with
manure or biosolids, which represents a high risk of development of bacterial resistance [7].
Studies evaluating the sorption of fluoroquinolones (Enrofloxacin, Danofloxacin, Ciprofloxacin
3

and Norfloxacin) and sulfonamides (sulfadiazine, sulfachloropyridazine, sulfadimidine) in 13
Brazilian soils, demonstrated the existing influence on the adsorption process of the different
physical, chemical and mineralogical properties of this matrix. In addition that sorption was
higher for fluoroquinolones than for sulfonamides, where Norfloxacin showed the highest
sorption, whereas the enrofloxacin showed the lowest. The researchers point out that no leaching
exists, even in the worst-case scenario, i.e. a sandy and poor organic matter soil [8]. In addition,
high concentration of residues of fluoroquinolones (Enrofloxacin was the most often detected
compound) were detected in soils receiving organic waste from chickens, which again positions
such waste as a source of environmental pollution and fluoroquinolones as compounds with high
preference to remain in soils [9]. Fluoroquinolones have also been determined in activated and
urban sludge (ciprofloxacin, 426 mg kg-1); while norfloxacin and ciprofloxacin were found in
compost samples with 22 and 20 mg kg-1, respectively [10,11]. These studies and their results
represent a warning signal for the use of such amendments, indicating the need of accomplishing
a prior assessment regarding fluoroquinolones and establishing their behavior with the organic
matter present in soils, where volcanic ash derived soils represent the best scenario for
antimicrobial sorption, considering their high organic matter and clay content. Also due to the
increased use of antibiotics both at international and national levels, as well as progress in the
different analytical techniques, detection of antimicrobials has become more efficient in a variety
of agro-ecosystems such as soils, waters, sediments [12-15]. In this analytical context, natural
organic matter that is present in any of its forms (humic substances), in soil-solution samples,
becomes an important interference, if we consider that spectroscopic techniques such as
molecular absorbance, are highly used on the determination-quantification of this kind of
pharmaceuticals in environmental samples. Additionally, electrochemical techniques, such as
4

cyclic voltammetry (CV), often offer advantages versus other methods, because in general, they
are faster, cheaper, more secure and more sensitive than spectrometric methods. In this sense, a
recent study described a new method that can establish the adsorption capacity of nanoparticles
(or any other adsorbent), detected by an electrochemical technique, with the advantage that no
separation of the adsorbent from the adsorbate is required [16]. This method was used for
Ciprofloxacin [17], where analytical results of the electrochemical methodology were
statistically precise and accurate. Considering progress in electrochemical determination of this
kind of analytes, and the existence of these pharmaceuticals compounds in soil-solution samples,
the present work describes the development of a new and simple analytical method to directly
determine the enrofloxacin concentration in presence of natural organic matter, where the
analytical parameters such as linearity, precision and accuracy were evaluated.
Also, we established the electrochemical behavior and the oxidation mechanism of enrofloxacin
by using CV as technique. Furthermore, kinetic studies were done with the aim of calculate the
number of transferred electrons in the entire process and to know if it is controlled by adsorption
or diffusion; where Tafel plot was studied in order to propose a possible mechanism related to
the electro-oxidation of this analyte and the rate determining step of the main mechanism.
Finally, LC-MS studies were done to corroborate the final product of the reaction.
2. EXPERIMENTAL
2.1. Sample
Soils
Soil samples were collected from 0 to 0.20 m depth of uncultivated area of Frutillar (Fru) and
Ralun (Rln) (Andisols) in southern Chile. The samples were obtained with a stratified random
5

system, where soil sample is taken from a field that has been divided into several subunits from
which simple random cores are obtained. After, all samples were air dried and sifted through a 2-
mm mesh sieve.
Humic Acids Purification
Briefly, the solid sample was equilibrated with 1 mol L-1 HCl, obtaining a suspension whose pH
ranges between 1 and 2 at room temperature. The volume was then adjusted with 0.1 mol L-1
HCl to get a 10 mL liquid/1 g dry sample ratio. The suspension was centrifuged to separate the
sediment (R1) from the supernatant (Fulvic Acid, FA-1). R1 was neutralized (pH = 7.0) with a 1
mol L-1 NaOH solution, and then a volume of 0.1 mol L-1 NaOH was added under N2 atmosphere
to give a 10:1 final extractant to soil ratio. The extraction was carried out under N2 atmosphere
with occasional stirring for a minimum of 4 h. The alkaline suspension was left overnight and
then the supernatant was separated by centrifugation. Subsequently, the supernatant was
acidified with 6 mol L-1 HCl under constant stirring to get pH 1.0 and then allowed to stand for
12-16 h. The precipitated Humic Acid (HA) fractions and FA (FA-2) supernatant were separated
by centrifugation. The precipitated HA was redissolved in a minimum volume of 0.1 mol L-1
KOH under N2; solid KCl was then added to attain a 0.3 mol L-1 K+ concentration and then
centrifuged to remove the suspended solid. The HA was re-precipitated by adding 6 mol L-1 HCl
under constant stirring until a pH=1.0 was reached. The suspension was allowed to stand another
12 to 16 h, and then centrifuged, disregarding the supernatant. The HA precipitate was
suspended into a 0.1 mol L-1 HCl and 0.3 mol L-1 HF mixture and stirred overnight at room
temperature (if necessary, the acid treatment (HCl/HF) was repeat until the ash content be less
than 1%). After centrifugation, the precipitate was transferred to a dialysis tube (Visking, Co.)
6

using distilled water until the dialysed water gives a negative test for chloride (AgNO3). After
freeze-drying, the HA was kept refrigerated [18,19].
2.2. Solutions
Natural organic matter solution
100 mg L-1 stock solution was prepared by dissolving the natural humic acid extracted from soils
derived from volcanic materials (HA-Fru and HA-Rln) in 0.100 mol L-1 sodium hydroxide
solution. The humic acid solution (30 mg L-1) was prepared from the NOM stock solution by
dilution with a previously prepared 0.01 mol L-1 phosphate buffer solution pH=7.0 (PBS).
Particle size distribution of NOM solution
To determine the nanoparticle size distribution the dynamic light scattering (DLS) analysis was
used. The DLS data were collected on a Zeta sizer S-590 (Malvern Instrument, US). The
scattering angle was 108º and the laser wavelength 690 nm. The autocorrelator delay time (τ)
was 1 μs. A series of 120 scans were carried out on the sample, each one with a 1-s acquisition
time.
Enrofloxacin solutions
10.0 mmol L-1 stock standard solution was prepared by dissolving the solid chemical (Sigma
Aldrich) in 0.01 mol L-1 hydrochloric acid. This stock solution stored in dark place at 4°C was
stable for at least 1 month. All Enrofloxacin solutions (0.200 mmol L-1) were prepared from the
Enrofloxacin stock standard solution by dilution with a previously prepared 0.01 mol L-1
phosphate buffer solution pH=7.0 (PBS). Using this solution, constant ionic strength and pH are
maintained constant during the whole experiment.
7

2.3. Electrochemical and LC-MS experiments.
All electrochemical experiments were conducted on a VoltaLabPGZ100 potentiostat system in a
three-compartment/three-electrode glass cell, under a high purity argon atmosphere. Glassy
carbon electrode (GCE) was prepared and used as working electrode. A Pt wire was used as
counter electrode. All potentials quoted in this work are referred to an Ag/AgCl reference
electrode (CHI111, CHInstruments, Inc.) The prepared solutions were subsequently deaerated
with Ar at least for 20 min.
Enrofloxacin determination
The electrochemical determination of Enrofloxacin was conducted by cyclic voltammetry
between 0.00 mV and +1300 mV at 100 mV s-1 scan rate in a glass cell with 10 mL of
Enrofloxacin solution in PBS. The determination was carried out at pH 3.0; 5.0 and 7.0 in 10 mL
of phosphate buffer solution, where the PBS themselves were measured as blanks respectively.
Electro-kinetics studies
The determination of the electro-oxidation mechanism of Enrofloxacin was based on an
electrochemical study, which consisted on the analysis of the dependence of the current signal
when the scan rate changes. At this point, a 0.200 mmol L-1 Enrofloxacin solution (in PBS, pH
7.0) was oxidized at different scan rates, from 5 mV s-1 to 250 mV s-1.
LC-MS experiment
LC-MS experiment was carried out on an UHPLC Eksigent® coupled with MS detector
ABSciex®, Triple Quad 4500 model equipment.
8

A sample was taken from the electrochemical cell after the electro-oxidation of Enrofloxacin.
This sample was injected by using a syringe, and the data was collected in a range of 100.0 –
600.0 Da, at 200 Da s-1 and positive polarity.
2.4. Analytical Parameters.
Linearity
Using the above mentioned electrochemical system, a study was accomplished to establish the
relationship between current peak and Enrofloxacin concentration within the 3.0x10-4 to 3.0x10-3
mmol L-1 range. The electrochemical determination of Enrofloxacin was conducted by cyclic
voltammetry to test current peak vs. Enrofloxacin concentration linearity; six calibration curves
were constructed. The current peak (Ip) (oxidation and reduction) was recorded at constant
potential obtained from the respective voltammogram for each Enrofloxacin concentration. To
establish the limit of detection (LOD) and limit of quantification (LOQ) of the method, the
Enrofloxacin calibration curves were used. From these curves, the standard deviation of the
lineal model regression was calculated (sy/x), from which the LOD (3sy/x/m) and LOQ (10sy/x/m)
were obtained.
Accuracy and Precision
Pharmaceutical Enrofloxacin samples (Rostrum®, Drag Pharma) were analyzed to determine
accuracy through recovery experiments with water-PBS extraction, and precision of the
electrochemical method. For tablets analyses, 10 tablets were ground to fine powder and a
representative amount of Rostrum® Drag Pharma was dissolved into a previously prepared 0.01
mol L-1 hydrochloric acid solution. The relative error (Er), relative recoveries of the analyte (RR)
and relative standard deviation (RSD) were calculated for five replicates.
9

Selectivity
Selectivity was determined by comparing six voltammograms of 0.300 mmol L-1 of enrofloxacin
in PBS (pH=7.0) in presence or absence of natural organic matter solution (0.30 mg L-1). Also,
calibration curves of enrofloxacin in presence of natural organic matter were obtained at the
same range of concentration aforementioned.
3. RESULTS AND DISCUSSION
In the current study, Enrofloxacin quantitation was studied by the development of a new and
simple electrochemical method, using CV. This method allowed evaluating the NOM as a
possible analytical interferent. Moreover, the proposal of a mechanism by studying the
dependence of the enrofloxacin oxidation on scan rate was now feasible. Additionally, the
control of the oxidation reaction of Enrofloxacin (adsorption or diffusion) and the number of
transferred electrons of the total process could be determined.
3.1. Voltammetric studies
Voltammetric profile of enrofloxacin electro-oxidation
Figure 1 shows the electrochemical response of the enrofloxacin electro-oxidation, in
comparison with the same solution in absence of this analyte. This voltammogram shows that on
the anodic scan, two current peaks appear, while no signals showed up on the cathodic scan. This
finding evidenced an irreversible reaction. The presence of two current peaks is indicative of two
oxidation processes occurring at 900 mV and 1100 mV, respectively.
(FIGURE 1)
10

Influence of pH on enrofloxacin electro-oxidation
Enrofloxacin molecules may exist as cation (ENR+), anion (ENR-) or zwitterion (ENR±),
depending on the pH of the medium. For instance, this parameter is very important when the
adsorption processes and the electro-oxidation of this analyte is studied. Figure 2 shows the
voltammetric response towards the Enrofloxacin electro-oxidation at different pH. It is very
noticeable how the acidity of the media affects the electrochemical behavior, since the oxidation
peaks appear at different overpotentials. At this point, the reaction is more favorable when the
reaction occurs at pH 7.0 as Enrofloxacin requires less energy to be oxidized. The trend
demonstrated that the more acidic the medium, the less favorable the electro-oxidation of
Enrofloxacin becomes, and the current peaks are shifted towards more positive potentials. This
latter observation can be explained by understanding which species are present before the
electrochemical reaction starts.
(FIGURE 2)
At pH 7.0, the molecule is found as its neutral form, which is more susceptible to be oxidized,
since one proton is already removed. Then at pH 5.0, there is 80% of ENR+ + 20% of ENR±,
which implies that most of the specie is in its protonated form, and more energy will be needed
to oxidize the molecule, since a proton needs to be removed to let the oxidation to occur. Finally,
at pH 3.0, the Enrofloxacin is totally protonated and as it was aforementioned, it will require
more energy to generate the oxidation process. Additionally, it is important to notice that there is
a double-signal when the voltammogram is recorded at pH 5.0. This phenomenon can be
attributed to the existence of two main species in solution (ENR+ and ENR±), which are oxidized
at different potentials. Then, the first peak can be related to the electro-oxidation of the
11

zwitterion, while the second current peak would correspond to the electro-oxidation of the
protonated specie, which requires more energy (see inset Figure 2).
In terms of current, there is not a noticeable change on the magnitude of the signal, since the
three studies are done at the same concentration. The low increment on the current while
decreasing the pH, might be due to an increment on the capacitive current or solvent evolution.
Since the response does not vary significantly, this parameter is practically independent on the
variation of pH.
3.2. Kinetic studies
In order to determine if this oxidation process is diffusion-controlled or adsorption-controlled,
the slope obtained from the logarithm of the current peak (log Ip) versus the logarithm of the
scan rate (log v) was evaluated. With this information, it was possible to calculate the number of
transferred electrons (n). Additionally, Tafel plot was studied in order to determine the rate
determining step of the entire process.
Influence of the scan rate on enrofloxacin electro-oxidation
Figure 3 shows the value of the logarithm of the peak current (Ip) associated to the oxidation
response of Enrofloxacin towards the variation of the scan rate (logarithmic base), which is
studied between 5 mV s-1 and 250 mV s-1. As it is possible to observe, while the scan rate is
higher, the oxidation response has an increment as well. This latter behavior can be explained by
the interpretation of the Nernst – Planck equation (eq.1), where J corresponds to the matter flux
which has different contributions: first of all, there is a diffusion term, where (∂c/∂x) is the
concentration gradient at a distance x and time t. Secondly, there is a migration component due to
the electrical field, where z and c are the charge and the concentration of the specie, and (∂ø/∂x)
12

is the potential gradient. Finally, there is a convection term, where V(x,t) is the hydrodynamic
rate. F and D correspond to Faraday’s constant and the diffusion coefficient of the analyte, while
R is the gas constant and T the temperature. Then, at higher the scan rate, the oxidation of the
species that are reacting is being produced on sites that are closer to the electrode surface (x 
0). At these circumstances, the (∂c/∂x) value is each time higher, which results on the obtainment
of higher current peaks (i) [20], as it is observed on equation 1.1, where A is the electrode area
and n the number of transferred electrons.
(
(
)
) − (푧퐹퐷퐶
)
+ 퐶 푥, 푡 푉 (푥, 푡)
(1)
휕퐶 푥,푡
휕∅ 푥,푡
(
)
(
)
퐽 푥, 푡 = −퐷
휕푥
푅푇
휕푥
푖 = −푛퐹퐴퐽(푥, 푡)
(1.1)
As it is observed in figure 3a, the slope value is 0.466 (≈0.5), which implies that the process is
diffusion-controlled. In order to corroborate this observation, figure 3b shows the relation
between the peak current versus the square root of the scan rate, giving a linear correlation
coefficient (R2) close to the unity. This result gives evidence that, effectively, the system is
controlled by diffusional processes related to the migration of the analyte towards the electrodic
surface and vice versa. At this point, there are no considerable surface reactions (adsorption
control) in the range of the studied scan rates [21].
(FIGURE 3a and 3b)
Furthermore, the peak potential (Ep) is also dependent on the variation of the scan rate, where
the shifts on the peak potentials confirm the irreversibility of the reaction (160 mV). With this
information, the equation (2) (R2 = 0.98, n =8) can be obtained, which is consistent with an
13

electrochemical-chemical (EC) reaction mechanism that indicates that there is a charge transfer
process before a chemical step, which gives the irreversible nature to the reaction [22].
Ep-Enrofloxacin (V) = (0.080 ± 0.001)log v + 1.05
(2)
Then, it is possible to corroborate that the process is irreversible and diffusion-controlled.
Among these results, it is possible to calculate the number of transferred electrons by using the
Randles-Sevcik equation (3), which is associated to irreversible processes that are diffusion-
controlled [23,24].
5
퐼푝 = 2.99 × 10 푛[ 1−∝ 푛∝]1/2퐴퐶푏퐷1/2푣1/2
(3)
(
)
In equation (3), A is the electrode area (0.07 cm2), n and nα the number of transferred electrons in
the global process and in the determining step respectively, Cb corresponds to the analyte
concentration (2.0 x 10-4 mol L-1 = 2.0 x 10-7 mol cm-3) and D, the diffusional coefficient
associated to this kind of fluoroquinolones [25,26] (≈ 4 x 10-6 cm2 s-1).
Moreover, since it is necessary to know the value of [(1-∝) n∝], an approximation based on the
relationship between the peak potential (Ep) and the half-peak potential (Ep/2) is used (equation
4).
47.7 mV
(
)
[ 1− ∝ 푛∝] =
(4)
E − E
p
2
p
For instance, in this case:
[(
1 – ∝ 푛∝
) ]ퟏ/ퟐ
= 0.089
(4.1)
So, the number of electrons involved in the global reaction, n, is 4 electrons (3.98 calculated).
14

Determination of the mechanism
Additionally, the Tafel plot has a value close to 120 mV per decade, which means that the rate
determining step in the global reaction corresponds to an electrochemical step (E) before or after
a chemical step (intramolecular rearrangement).
Finally, the proposed mechanism is shown in scheme 1.
(SCHEME 1)
The electro-oxidation of enrofloxacin is favorable due to the existence of an ethyl group on the
piperazine nitrogen, where its alpha carbon atom is more susceptible to be oxidized, which
would imply, in a further step, the release of one equivalent of acetaldehyde as subproduct and
the formation of one equivalent of ciprofloxacin (fast chemical step). This latter observation was
corroborated by LC-MS (m/z = 332.7 Da) shown in figure 4. Then, there is a second oxidation
process that involves 2 electrons and the formation of a trihydroxilated derivative [27], which is
confirmed by mass spectrometry as well (m/z = 359.8 Da)
(FIGURE 4)
3.3. Analytical parameters
To study the analytical parameters of the CV-enrofloxacin assay, we estimated the linearity,
precision, and accuracy of the electrochemical method.
Linearity
15

From Figure 5a, it is seen that as the analyte concentration increases, the height of the anodic
peak increases, producing a linear relationship with enrofloxacin concentration. The system
linearity (Ip = 2.411 + 0.048xC) with regard to enrofloxacin concentration (Fig. 5b), makes
possible the use of glassy carbon electrodes as a prospective enrofloxacin amperometric sensor,
with detection (LOD) and quantification (LOQ) limits of 28x10-3 ± 4x10-3 and 95x10-3 ± 14x10-3
mmol L−1. Precision results (RSD) (n=6) showed 15% for LOD and LOQ. These data show a
good correlation between the peak current and the concentration of Enrofloxacin (R2=0.996;
n=6).
(FIGURE 5a and 5b)
Accuracy and precision
The voltammetric response (Ip) of the commercial product in comparison with standards can be
observed in Table 1, evidencing the absence of a matrix effect once the drug has been dissolved
in PBS. With these values of Ip it is evident that signals of both standard enrofloxacin (Sigma-
Aldrich) and commercial drug are equivalent.
(TABLE 1)
A 95.6 ± 0.8 % recovery indicates the good accuracy of the method (reported 52.2±0.4 mg of
enrofloxacin for a sample of 50 mg) that corresponds to 4.4± 0.8 % relative error, RSD = 18.1%,
which is an acceptable accuracy.
16

Selectivity
Natural organic matter from soils constitutes an important interferent, especially in analytical
determinations using spectrophotometric techniques. Furthermore, the linearity of the method is
very poor. This is confirmed by analyzing the absorbance vs. Enrofloxacin concentration, where
in the absence of NOM a R2 = 0.998 (y = 0.014 x C + 0.012, n = 7) was obtained, while in the
presence of NOM (30 mg L-1), the linear correlation decreases to R2 = 0.985, with cut-off values
on the y-axis much higher than those obtained in the absence of this interferent. However, the
observed sensitivity reduction is more significative, with slopes decreasing by half (y = 0.007xC
+ 0.399, n=7) that causes loss of the analytical quality of the obtained results. No other
electroanalytical techniques reported measure this kind antibiotic in presence of NOM.
The development of a new approach to overcome the existence of this interferent constitutes a
contribution to obtain information concerning the presence of antibiotics for veterinary use, such
as enrofloxacin in aqueous samples.
The voltammetric response of Enrofloxacin (300.0 μmol L-1) in the absence and presence of the
same type of NOM mentioned as interferent, is compared (Table 1) where the values of peak
current (Ip), analytical signal evaluated, are not modified more than 5%, indicating that the
presence of NOM does not constitute an interferent for the developed method. This was
corroborated by analyzing calibration curves in the absence (y = 0.052xC + 3.836, R2 = 0.997,
n= 7) and presence of NOM (y = 0.048xC + 3.302, R2 = 0.998, n = 7), with similarity in terms of
sensitivity and linear correlation coefficient.
Thus, it is interesting to know the type of NOM that interferes in spectroscopic methods but not
in the novel developed method. These humic substances have a very similar total acidity, ca. 8.9
17

mEq g-1, composed of more than 80% by carboxylic groups and about 20% of phenolic groups.
The above can be complemented with the sequence of relative abundance of functional groups,
obtained by solid state NMR, wherein O/N alkyl > Alkyl C > Aromatic> Carboxylic (data not
published). However, the particle size distribution indicates that this OM is constituted, under the
measurement conditions (pH 7.0; PBS), mainly of particles with a mean diameter of 90 nm
(64%) and 1 nm (36%). This characterization results corroborate the interferent is formed by
nanoparticles that in the presence of the established electrochemical disturbance, do not record a
response that may mean changes in the observed responses towards the analyte of interest.
4. CONCLUSIONS
A new and novel method was developed to determine and quantify Enrofloxacin in presence of
NOM. This method is highly pH-dependent, since Enrofloxacin may exist as different species.
At this point, at pH 7.0 the reaction is more favorable since the oxidation requires less energy to
be accomplished, and it is attributed to the existence of Enrofloxacin as zwitterion.
Additionally, kinetic studies were done. It was found that the electro-oxidation of Enrofloxacin
at pH 7.0 is diffusional-controlled and 4 electrons are transferred in the entire process. Also, the
rate determining step of the reaction corresponds to an electrochemical step associated to an
electronic transfer previous or after a chemical step. This latter result was corroborated by
studying the Tafel slope, which has a value of 120 mV per decade. Parallel to this, LC-MS
studies were done to corroborate the final product of the reaction, being the formation of a
trihydroxilated derivative. With these data, a mechanism involving the formation of
ciprofloxacin was proposed.
Analytical parameters were studied from this new electroanalytical method, which can be
considered accurate and precise, showing good linearity response, (n=6; R2 = 0.996) with
18

detection and quantification limits of 28x10-3 mmol L-1 and 95x10-3 mmol L-1 respectively. Also
recovery results (96% of recovery) and precision (RSD=18%) for a commercial product
(Rostrum®) were acceptable. In relation with selectivity, the new method show the same
electrochemical response in presence or absence of soil extracted organic matter, composed
mainly by nanoparticles around 90 nm with an important presence of carboxylic acidity, which is
not considered as an analytical interference. With this advance this method would allow us to
determine this analyte in environmental aqueous samples.
5. ACKNOWLEDGMENTS
Support from Fondecyt project 1130094 and Basal Funding for Scientific and Technological
Centers of Excellence FB0807 CEDENNA are kindly acknowledged.
19

6. REFERENCES
[1] A.K. Sarmah, M.T. Mayer, A.B. Boxall, A global perspective on the use, sales, exposure
pathways, occurrence, fate and effects of veterinary antibiotics (Vas) in the environment,
Chemosphere 65 (2006) 725.
[2] A. Millanao, M. Barrientos, C. Gomez, A. Tomova, A. Buschmann, H. Dölz, F. Cabello,
Uso inadecuado y excesivo de antibióticos: Salud pública y salmonicultura en Chile, Rev.
Med. Chile 139 (2011) 107.
[3] J.B. Addison, Antibiotics in sediments and run-off water from feedlots, Resid. Rev. 92
(1984) 1.
[4] R. Kroker, Aspekte zur ausscheidung animikrobiel wirksamer subsanzen nach der
chemoterapeutischem von nutztieren, Wiss. Umwelt 4 (1983) 305.
[5] E.M. Golet, I. Xifra, H. Siegrist, A.C. Alder, W. Giger, Environmental exposure assessment
of fluoroquinolone antibacterial agents from sewage to soil, Environ. Sci. Technol. 37
(2003) 3243.
[6] A.B. Boxall, P. Johnson, E.J. Smith, C.J. Sinclair, E. Stutt, L.S. Levy, Uptake of veterinary
medicines from soils into plants, J. Agric. Food Chem. 54 (2006) 2288.
[7] A. Ernervik, A risk analysis of the potential harm on the soil environment caused by
antibiotics in biosolids. Bachelor D. Dissertation, Lund University, Sweden, 2011.
[8] R.M.P. Leal, L.R. Alleoni, V.L. Tornisielo, J.B. Regitano, Sorption of fluoroquinolones and
sulfonamides in 13 Brazilian soils, Chemosphere 92 (2013) 979.
[9] R.M. Leal, R.F. Figueira, V.L. Tornisielo, J.B. Regitano, Occurrence and sorption of
fluoroquinolones in poultry litters and soils from São Paulo State. Braz, Sci. Total Environ.
432 (2012) 344.
[10]A. Gobel, A. Thomsen, C. McArdell, A. Joss, W. Giger, Occurrence and sorption behavior
of sulfonamides, macrolides, and trimethoprim in activated sludge treatment, Environ. Sci.
Technol. 39 (2005) 3981.
[11]M. Lillenberg, S. Yurchenko, K. Kipper, Presence of fluoroquinolones and sulfonamides in
urban sewage sludge and their degradation as a result of composting, Int. J. Environ. Sci.
Tech. 7 (2010) 307.
[12]D. Aga, S. O’Connor, S. Ensley, J.O. Payero, D. Snow, D. Tarkalson, Determination of the
persistence of tetracycline antibiotics and their degradates in manure-amended soil using
enzyme-linked immunosorbent assay and liquid chromatography-mass spectrometry, J.
Agric. Food Chem. 53 (2005) 7165.
20

[13]A. Batt, D. Snow, D. Aga, Occurrence of sulfonamide antimicrobials in private water wells
in Washington County, Idaho, USA, Chemosphere 64 (2006) 1963.
[14]A. Pruden, M. Arabi, H. Storteboom, Correlation between upstream human activities and
riverine antibiotic resistance genes, Environ. Sci. Technol. 46 (2012) 11541.
[15]Y. Zhang, C. Zhang, D. Parker, D. Snow, Z. Zhou, X. Li, Occurrence of antimicrobials and
antimicrobial resistance genes in beef cattle storage ponds and swine treatment lagoons,
Sci.Total Environ. 463-464 (2013) 631.
[16]M. Antilen, F. Amiama, M. Otaiza, F. Armijo, M. Escudey, C. Pizarro, N. Arancibia-
Miranda, A New Methodology to Evaluate Adsorption on Nanomaterials, J. Nano. Res. 17
(2015) 212.
[17]M. Antilen, O. Bustos, G. Ramirez, C. Canales, M. Faundez, M. Escudey, C. Pizarro,
Electrochemical Evaluation of Ciprofloxacin Adsorption on Soil Organic Matter, New J.
Chem. 40 (2016) 7132.
[18]M. de Nobili, G. Bragato, J. Alcaniz, A. Puigbo, L. Comellas, Characterization of
electrophoretic fractions of humic substances with different electrofocusing behavior. Soil
Sci. 150 (1990) 763.
[19]A. Watanabe, S. Kuwatsuka, Fractionation of soil fulvic acids using polyvinylpyrrolidone
and their ionization difference spectra. Soil Sci. Plant Nutr. 37 (1991) 611.
[20]F. Santamaría, Diffusion Equation, in: D. Jaeger, R. Jung (Eds.), Encyclopedia of
Computational Neuroscience, Springer, New York, 2015, p. 1018.
[21]N. Erk, Voltammetric behaviour and determination of moxifloxacin in pharmaceutical
products and human plasma, Anal. Bioanal. Chem. 378 (2004) 1351.
[22]B. Uslu, B. Bozal, M. Kuscu, Anodic Voltammetry of Ciprofloxacin and its Analytical
Applications, Open Chem. Biomed. Methods J. 3 (2010) 108.
[23]A. Bard, L. Faulkner, Electrochemical Methods: Fundamentals and Applications, Wiley,
New York, U.S.A., 2000.
[24]R. Ríos, A. Marín, G. Ramírez, Nitrite electro-oxidation mediated by Co(II)- [tetra(4-
aminophenyl) porphyrin]-modified electrodes: behavior as an amperometric sensor, J.
Coord. Chem. 63 (2010) 1283.
[25]M. Rizk, F. Belal, F. Ibrahim, S. Ahmed, N.M. EL-Enany, Voltammetric analysis of certain
4-quinolones in pharmaceuticals and biological fluids, J. Pharm. Biomed. Anal. 24 (2000)
211.
21

[26]P.A. Suci, M.W. Mittelman, F.P. Yu, G.G. Geesey, Investigation of Ciprofloxacin
Penetration into Pseudomonas aeruginosa Biofilms, Antimicrob. Agents Chemother. 38
(1994) 2125.
[27]V.S. Antonin, M.C. Santos, S. Garcia-Segura, E. Brillas, Electrochemical incineration of the
antibiotic ciprofloxacin in sulfate medium and synthetic urine matrix, Water Res. 83 (2015)
31.
22

Figures
Figure 1. Voltammetric response of 300 µmol L-1 Enrofloxacin in buffer phosphate solution, pH
7.0, purged in Ar. Scan rate 100 mV s-1
23

Figure 2. Voltammetric response of 200 µmol L-1 Enrofloxacin in buffer solutions, pH 7.0, 5.0
and 3.0, purged in Ar. Scan rate 100 mV s-1. In inset, the pH dependence of Ep values for
Enrofloxacin detection.
24

Figure 3. (a) Logarithm of the peak current (Ip) versus logarithm of the scan rate (v) and (b)
variation of the peak current (Ip) versus the square root of the scan rate (v1/2). 2.0 x 10-4 mol L-1
2-
of Enrofloxacin in buffer phosphate solution (H2PO4-/HPO4 ) pH 7.00, purged in Ar.
25

Figure 4. Mass spectrum of enrofloxacin after the oxidation process.
26

Figure 5. (a) GCE voltammetric response towards enrofloxacin concentration between 0.0V and
1.3V. v = 100 mV s-1 in a cell containing 10 mL of BPS-enrofloxacin; (b) Linear relationship
between current anodic peak (Iap) and Enrofloxacin concentration (30-300µmol L-1) (y=0.048xC
+ 2.411, R2= 0.996; n=6).
27

Scheme 1. Proposed mechanism for enrofloxacin electro-oxidation
28

Table 1.- Peak potentials (Ep) and peak currents (Ip) corresponding to accuracy and precision
tests associated to Enrofloxacin present in commercial drugs (Sigma – Aldrich and Drag –
Pharma) and its response in presence of different humic acids (HA)
Accuracy and
Assay
Ep
Ip
precision tests
(V)
(µA)
Commercial drugs
Sigma – Aldrich
Drag – Pharma
ENR
ENR + HA (commercial) 1.0
ENR + HA (FRU)
ENR + HA (RLN)
0.90
0.90
0.97
5.0
5.0
19.0
18.5
17.7
17.7
ENR + different HA
0.95
0.95
29
