Arkivoc 2018, part vii, 0-0
Synthesis of chiral tripodal receptors under solvent-free conditions using
microwave irradiation for investigation of anion and cation recognition
properties
Şeref Kaplan, Gülşen Öztürk*, Sevil Ş. Azizoglu, Mahmut Togrul and Yılmaz Turgut
University of Dicle, Faculty of Science, Department of Chemistry, 21280, Diyarbakir, Turkey
E-mail. gozturk@dicle.edu.tr
Received 09-19-2018
Accepted 12-14-2018
Published on line 12-27-2018
Abstract
Amide based chiral tripodal receptor derivatives were synthesized under microwave irradiation in quite high
1
yields (76%- 84%) and they were characterized by IR and 1D, 2D, H- and 13C-NMR spectroscopies. The
recognition properties of these tripodal receptors towards some anions and organic ammonium salts were
1
investigated by H-NMR titration in DMSO-d6. The tripodal (S)-phenyl receptor demonstrated a highly
significant enantiomeric selectivity towards the (S)-(-)-1-phenyletylammonium perchlorate (ERF= 91.74 S).
Keywords: Molecular recognition, tripodal receptors, cation and anion recognition, microwave, NMR titration
DOI: https://doi.org/10.24820/ark.5550190.p010.759
Page 1
©ARKAT USA, Inc

Arkivoc 2018, vii, 0-0
Kaplan, Ş. et al.
Introduction
Recognition of anionic substrates has contributed strongly to the development of supramolecular chemistry in
the last decades1,2,3 and subsequently the subject has a wide range of applications, such as in biological,
industrial and environmental areas1. For this purpose, it is important to properly design and synthesize
versatile receptors for recognition of anions and cations. Recently, simple molecular clefts have been shown as
viable systems for binding anions due to their structural flexibility in the organization of binding sites4-9.
Indeed, a high degree of selectivity could be achieved by a careful design of a host with a pre-organized cavity
for a guest.10
There are some considerations in the design of anion receptors: (i) host–guest geometric structures, (ii)
nature of non-covalent interactions, (iii) basicity of the anionic guests, (iv) the solvent used.11,12 In terms of
their electrostatic charge, two different types of anion receptors have been developed: cationic and neutral
receptors. As to neutral receptors, the most common motifs involve ureas13, thioureas14-16, amides, etc.17
Selectivity of a tripodal receptor largely depends on cavity size and rigidity of the side arms 18,19 and, therefore,
they are known to exhibit several advantages over those of monopodal and bipodal receptors. Tripodal
receptors usually bind metal ions very strongly as a result of their enhanced chelating influence. In addition,
the bulkiness of tripodal ligands make them more reactive towards metal ions. Because of the distinctive
features of synthetic tripodal receptor systems, their design and development remain a very active field of
study in supramolecular chemistry.20-23
Amide functional groups are important in the recognition of anions. Therefore, the synthesis of
compounds containing amide functionality is of great interest in synthetic chemistry. The use of microwave
technology in organic chemistry has widely been investigated in the past decade, and hence a great number of
papers reported that many chemical transformations can be carried out successfully by this technique. The
microwave technique significantly reduces reaction time thus providing high yield, less by-product formation,
consistent with green chemistry, solvent free organic conversion, atom economy and selective reactivity.24
Therefore, the synthesis of tripodal receptors based on amide formation has been carried out by condensation
of carboxylic acids and amines, employing the microwave technique that allows direct conversion of carboxylic
acids to amides. Otherwise, conversion of carboxylic acids to more reactive intermediates would be necessary
to obtain amides. 24-30
Herein, we report the synthesis of a series of novel chiral tripodal receptors based on the formation of
amide bonds under microwave irradiation, and an evaluation of their molecular recognition abilities towards a
-
-
-
-
-
wide range of anions (H2PO4 , HSO4 , C6H5CO2 , CH3CO2 , ClO4 , F-, Cl-, Br-). The study also involves the
investigation of chiral discrimination abilities of these receptors against chiral organic ammonium salts, AM1
1
(phenylethylammonium perchlorate) and AM2 (naphthylethylammonium perchlorate). H-NMR titration
method was employed to obtain binding constants between receptors and anions as well as cations.
Results and Discussion
Synthesis
Amide-based tripodal receptor ligands (1-4) were synthesized under microwave irradiation (Scheme 1), and
-
-
-
-
-
the binding affinities of anions (H2PO4 , HSO4 , C6H5CO2 , CH3CO2 , ClO4 , F-, Cl-, Br-) as tetrabutylammonium
1
(TBA) salts as well as against two chiral organic ammonium salts were investigated using the H-NMR titration
method. Structures of the synthesised compounds were elucidated using IR, H-NMR, 13C-NMR, DEPT, 2D NMR
1
Page 2
©ARKAT USA, Inc

Arkivoc 2018, vii, 0-0
Kaplan, Ş. et al.
(COSY, HETCOR) spectroscopic techniques. All three receptors showed amide first band between at around
1650 cm-1 and the amide second band 1550 cm-1 in IR spectrum. The chiral hydrogen of tripodal receptors
showed pentet at around 5.74 ppm in 1H NMR spectrum.
The reactions were performed using microwave irradiation, at atmospheric pressure, using a 1000 W
o
microwave lab-station at 150 C for maximum 42 minutes (generally 2-3 drops of water were added). All
amides were obtained with very high yields (76%-84%) (Scheme 1). Products were purified using crystallisation
and chromatographic methods.
Scheme 1. Synthesis of chiral tripodal-based ligands (1-4).
1H-NMR Titration
Many methods have been reported for the determination of complexation constants. 31,32 1H-NMR spectra
were recorded monitoring the proton chemical shift in the tripodal receptors as a function of the
1
concentrations of the guest ions. A representative example is illustrated in Figure 1 depicting the H-NMR
spectra of the enantiomeric (R)-tripodal receptor 3 obtained at different concentrations of the guest acetate
anion. It indicates that significant chemical shift displacement (Δδ) corresponding to the –NH proton of
receptor 3 that take place upon the addition of the anion solution. For cation recognition, the chemical shift
(δ) of the methine (-CH) proton in the tripodal receptor 3 was monitored against cation concentration.
Determination of the stoichiometry of the complex formation between host (H, the receptor) and guest
(G, being an anion or a cation) is crucial for estimation of the binding constants of host-guest (H.G) complexes
in molecular and enantiomeric recognition studies.29,33 Although a variety of methods have been used for this
purpose, the Job’s Plot method has become the most commonly used. A typical Job’s Plot of the proton
chemical shift displacement (Δδ) of the tripodal receptor multiplied by the host mole fraction (H) against the
respective mole fraction (H) in DMSO-d6 shows the maximum at a molar fraction of 0.5 [Figure 2: tripodal
-
receptor 3 complexing with the dihydrogen phosphate anion (H2PO4 ) and; Figure 3: tripodal receptor 3
complexing with the chiral phenylethyl ammonium cation of (S)-AM1]. Both figures suggest that tripodal
receptors complex with anionic and/ or cationic guests with a 1:1 stoichiometry. Similar results were obtained
for all tripodal receptors used in this work. The dissociation constants (Kd) of the complexes of anion and
cation guests with tripodal receptors 1-4 were calculated by nonlinear curve fitting, using Eq. 4 below (derived
from Eqs. 1-3), as described in literature.33
Page 3
©ARKAT USA, Inc

Arkivoc 2018, vii, 0-0
Kaplan, Ş. et al.
R +G0
Kd=[R] [G0]/ [R.G0]
G0= Gfree + Gcomplexs
Δδ = (δ0Kd + δmaxGtot)/(Kd + Gtot)
A range of stock solutions of the guests (0-6x10-3M) containing a constant amount of the tripodal
receptors (1x10-3 M) in DMSO-d6 was prepared and their H NMR were collected at 298 K at ambient probe
R.G0
(1)
(2)
(3)
(4)
1
temperature and calibrated using tetramethylsilane as an internal reference. The proton chemical shift
displacements (Δδ) of the tripodal receptor, such as that of amide proton (–NH), are normally monitored
against the corresponding guest concentration then fitted to Eq. 4, derived from Eqs. [1-3].
-
Typical plot of Δδ versus Go for the complex of tripodal receptor 3 with the H2PO4 anion guest from
(TBAH2PO4) is shown in Figure 4. The calculated Δδ values are plotted against Go to yield what looks like a
nonlinear relationship (Figures 7 and 8 ). The chemical shift of the –CH (methine, δ = 4.9633 ppm) resonance
of the phenylethylammonium perchlorate salt was monitored against the corresponding salt concentration.
1
The two H-NMR spectral segments depicting the chemical shift displacements (Δδ) of the -CH (methine)
proton, corresponding to the two guest enantiomeric forms (R)-AM1(left) and (S)-AM1 (right), on
complexation with tripodal receptor 3 are shown in Figure 5. During titration, the resonance of the chiral -CH
(methine) proton of the phenylethylammonium cation of AM1 shifted downfield on complexation with the
tripodal receptor 3 molecules (Figure 5).
The 1H NMR titration technique was employed to estimate the binding constants for complexes of tripodal
-
-
receptors 1-4 with guest anions using their tetrabutylammonium salts [n-Bu4N]+A- (A- = H2PO4 , HSO4 ,
-
-
-
C6H5CO2 , CH3CO2 , ClO4 , F-, Cl-, Br-) and guest chiral organic ammonium cations (AM1: 1-
phenylethylammonium perchlorate and AM2: 1-(1-)-naphthylethylammonium perchlorate). The results are
listed in Table 1 and Table 2 respectively.
Anion recognition
The topology of the receptor is of importance in determining the overall receptor-ion interactions. Tripodal
receptors, occupy a class somewhere in between cyclic and acyclic ligands with regards to preorganization, are
believed to be able to complex with ions more effectively than analogous acyclic ligands. The molecular design
allows a rational control of their binding properties such as complex stability and selectivity. The selectivity of
a tripodal receptor largely depends on the rigidity of its arm sites and cavity size. As a recognition motif,
tripodal-based receptors have been reported to be successfully used as recognition components in ion-
selective electrode membranes and optical sensors.
The main features for the design of tripodal anion receptors are: (i) There is a sufficient number of
positively charged or neutral electron-deficient groups in the ligand to serve as interaction sites. (ii) Receptors
with a flexible tripodal structure have a strong affinity for trigonal oxoanions, such as carbonate, phosphate
and chlorate, because the geometry and the orientation of the host molecules favour the formation of a stable
21,22
host-guest complex.
In addition to the proton donor properties of the tripodal amides, they also have
proton acceptor properties. Therefore, this offers them double binding effect on the anions and opposite
-
cations recognition. The results indicate that tripodal receptors exhibit a better affinity towards HSO4 and
-
-
-
-
H2PO4 anions followed by CH3CO2 . However, they do not bind to ClO4 and only weakly bind to C6H5CO2
anions. As to the halide (F-, Cl- and Br-) anions, their affinities towards the four tripodal receptors vary with no
apparent trend (Table 1).
Page 4
©ARKAT USA, Inc

Arkivoc 2018, vii, 0-0
Kaplan, Ş. et al.
1
Figure 1. Section A of the H-NMR spectra represent an expanded part (δ 8.71 and 8.89 ppm) of the larger
spectrum B corresponding to the tripodal receptor 3, showing the chemical shift displacements caused by an
increase in the acetate anion concentration, on the addition of the tetrabutyl ammonium acetate
-
[Bu4N]+CH3CO2 salt at an increasing initial concentration (0, 0.2, 0.3, 0.7, 1.0, 2.0, 3.0, 4.0, 5.0, 6.0 mM), while
holding the initial concentration of Tripodal Receptor 3 constant at 1 mM.
Table 1. Dissociation constant (Kd, M) of tripodal receptors 1-4 with various anions in DMSO-d6 collected at 25
± 0.1 ⁰C
Kd (M)
Entry Anion*
1
2
0.86±0.14
nd
3
7.86±4.39
0.50±1.95
nd
4
nd
-
1
2
3
4
5
6
7
8
H2PO4
18.71±9.09
1.58±1.23
52.24±42.45
21.66±7.30
nd
-
HSO4
0.99±0.67
314.5±5.71
19.81±8.19
nd
-
C6H5CO2
0.50±0.11
13.02±2.10
17.65±9.45
nd
-
CH3CO2
8.76±2.10
nd
-
ClO4
F-
nd
nd
5.75±2.49
15.41±68.29
nd
Cl-
Br-
nd
3.81±1.577
nd
nd
5.850±4.06
nd
nd: Not determined; *Anions were used as tetrabutylammonium salts form
Page 5
©ARKAT USA, Inc

Arkivoc 2018, vii, 0-0
Kaplan, Ş. et al.
Figure 2. Job’s Plots of tripodal receptor 3 with TBAH2PO4.
Figure 3. Job’s Plots of tripodal receptor 3 with (S)-AM1.
8.85
8.80
8.75
8.70
8.65
8.60
0
1
2
3
4
5
6
Go (mM)
Figure 4. A nonlinear plot of ∆δ versus Go for the complex of tripodal receptor 3 with TBAH2PO4 salt, serving as
-
the source of H2PO4 guest.
Page 6
©ARKAT USA, Inc

Arkivoc 2018, vii, 0-0
Kaplan, Ş. et al.
The observed better affinity of a receptor towards the acetate anion may be associated with the presence
of favorable π-CH interactions. In addition, acetate ion acts as a stronger base than benzoate anion. Therefore
causes stronger binding. It is well established that compounds containing –N(H) or –O(H) hydrogen bond
groups can undergo a deprotonation process upon the addition of an acetate anion. In summary, we have
synthesized and characterized a simple tripodal receptor which binds fluoride, chloride, bromide, acetate,
benzoate, dihydrogen phosphate, and hydrogen sulfate anions showing strong selectivity for the acetate and
dihydrogen phosphate in DMSO-d6. The host-guest affinity results from non-covalent interactions, including
electrostatic interactions, hydrogen bonding, Van der Waals, coordination to a metal ion, and a combination
of these interactions. As to the anions, their size, shape, hydrogen bonding capability, acid/base properties
and the number of interaction sites available should also be considered.
Cation recognition
The design of amide-based tripodals for a cation requires a receptor unit that selectively interacts with organic
ammonium salts. Owing to the special structure of their three flexible donor-atom-containing chains, tripodal
receptors can form complexes with many organic ammonium cations.29 Enantiomeric recognition studies of
amine or protonated amine salts are considered important, because these molecules are basic building blocks
of biological materials. Since, the tripodal receptors are highly symmetric and relatively rigid due to amide
moieties, they are used in the enantioselective discrimination of phenylethylammonium [(R)-AM1 and (S)-
1
AM1] and naphthylethylammonium [(R)-AM2 and (S)-AM2] salts by H NMR titration method. Extensive
studies on molecular recognition by receptors have shown that an important characteristic of complexation is
the simultaneous operation of several weak forces working between the guest and receptors, which
determine how the size and shape of a guest molecule fit into the host cavity.
1
Figure 5. Stack plots of H-NMR titration spectra of corresponding chemical shift in chiral -CH group in the
guests from the complex between tripodal receptor 3 and the chiral ammonium cation guests: (R)-AM1(left)
and (S)-AM1 (right).
Page 7
©ARKAT USA, Inc

Arkivoc 2018, vii, 0-0
Kaplan, Ş. et al.
The dissociation constants of the receptors (1-4) with an enantiomeric cation of organic ammonium salts
are presented in Table 2. The data indicate that the tripodal receptors form modest stable complexes with all
enantiomeric ammonium cation guests (except tripodal receptor 2 with (R)-AM-1 and tripodal receptor 3 with
(S)-AM1) (Table 2). This may be attributed to the strict geometrical complementary relationship between the
tripodal receptor cavity and organic ammonium cations.22
In Table 2 the results demonstrate that the hosts 2 and 3 form stronger complexes with ammonium cation
salts than those of hosts 1 and 4, which is likely due to the naphthyl group being more aromatic favoring
stronger π-π and cation-π interaction than the phenyl group. The highest enantioselectivity was observed in
the tripodal receptor 2. Tripodal receptor 2 prefers to bind S-enantiomer of AM1 with ERF of 91.74% (Kd= 1.53
R
S
mM, Kd /Kd = 0.09). Another striking point comes from the discrimination of AM1 salt by receptor 1, which
R
S
preferably bind to S enantiomer with ERF of 72.14% (Kd= 1.53 mM, Kd /Kd = 2.59).
Table 2. Enantiomeric recognition studies of tripodal receptors 1-4 towards organic ammonium salts in DMSO-
d6 at 25 ± 0.1 ⁰C
R
S
Tripodal
Receptor
1
Cation
Kd (mM) Kd /Kd
ERF
%
72.14 (R)
(R)-AM-1 3.7±032
(S)-AM1 1.43±0.07
(R)-AM-2 2.52±0.27 1.56
0.64 (Kd /Kd )
2.59
39.06 (S)
S
R
(S)-AM2
(R)-AM-1 0.14±0.08 0.09
(S)-AM1 1.53±0.21
(R)-AM-2 1.02±0.37 1.01
(S)-AM2 1.01±0.38
(R)-AM-1 2.61±0.38 2.55
0.39 (Kd /Kd )
1.6±0.17
2
3
91.74 (S)
49.75 (S)
71.83 (R)
S
R
(S)-AM1
(R)-AM-2 1.98±0.10 0.92
(S)-AM2 2.14±0.29
(R)-AM-1 3.92±0.15 0.92
(S)-AM1 21.72±1.66
(R)-AM-2 3.92±0.32 2.58
(S)-AM-2 1.52±1.01
1.02±0.005
52.08 (S)
52.08 (S)
72.07 (R)
4
*AM1: Phenylethylammoniumperchlorate; AM2: Naphthylethylammoniumperchlorate
R
S
R
S
ERF: Enantiomer Recognition Factor: Calculated from Kd +Kd = 100 and Kd /Kd ratio
On the other hand 4 shows better enantioselectivity for naphthylethylammonium cation compared with 1,
R
S
2, 3 particularly for (R)-AM-2 (Kd /Kd = 2.58 Table 2). It was found that both hosts bind and discriminate
organic ammonium cations, possibly due to stronger π-π and π-cation interactions between tripodal receptors
(hosts) and ammonium cations (guests) molecules in addition to weaker non-covalent interactions (hydrogen
Page 8
©ARKAT USA, Inc

Arkivoc 2018, vii, 0-0
Kaplan, Ş. et al.
bonding, Van der Waals, dipole-dipole etc.). This indicates that increased π-π interaction and the phenyl-
naphthyl state are the best fit between the tripodal receptor cavity and organic ammonium cations (Fig. 6).
Figure 6. Proposed mechanism of tripodal receptor 3 and (S)-AM1.
Considering the values in Table 1, it can be noted that (S)-configurated tripodal receptors show better
selectivity for the (R)-, while the (R)- configurable tripodal receptors exhibit better selectivity for the (S)-
ammonium salts. It seems that the size and shape of the guest molecule and the structural change of the host
molecule administrate the complexation phenomena to some extent. Hence, the induced fit and the
geometrical complement between the host and the guest play a crucial role in the chiral recognition of organic
ammonium cations.
1.51
1.50
1.49
1.48
1.47
1.46
1.45
0
1
2
3
4
5
6
Go (mM)
Figure 7. Nonlinear plots of δ versus Go for the complex of tripodal receptor 3 with (S)-AM1.
Page 9
©ARKAT USA, Inc

Arkivoc 2018, vii, 0-0
Kaplan, Ş. et al.
1.51
1.50
1.49
1.48
1.47
1.46
1.45
0
1
2
3
4
5
6
Go (mM)
Figure 8. Nonlinear plots of δ versus Go for the complex of tripodal receptor 3 with (R)-AM1
Conclusions
Four receptors possess high affinity for dihydrogenphosphate, benzoate and acetate anions. The tripodal
receptors 1 and 2 show a relatively weak affinity towards all anions, while tripodal receptor 3 and 4 do not
-
bind to ClO4 and Br- anions at all. The results also show that receptors can discriminate between the
enantiomers of AM1 and AM2 salts. The data may be relevant in the understanding of the main driving forces
in anion and cation recognition in living cells. They may also be used in the development of anion and cation
sensors.
Experimental Section
General. Melting points were determined with a GALLENKAMP Model apparatus with open capillaries and are
uncorrected. Infrared spectra were recorded on a MIDAC-FTIR Model 1700 spectrometer. Elemental analyses
were obtained with CARLO-ERBA Model 1108 apparatus. Optical rotations were taken on a Perkin-Elmer 341
1
Model polarimeter. H (400.1 MHz), 13C (100.6 MHz) and 2D NMR (DEPT, COSY, HETCOR, HMQC, HMBC)
spectra were recorded on a BRUKER AV400 NMR spectrometer in the indicated solvents. Chemical shifts are
expressed in part per million (δ) using residual solvent protons as internal standards.
Synthesis of the tripodal receptors
The synthesis of tripodal receptors were carried out at optimum reaction conditions (temperature, time and
power). The determination of optimization reaction conditions were given our previous paper. The best yields
of tripodal receptors were found between 76%- 84% at 900 W, 25 minutes, atmospheric pressure and 150 oC.
(R)-Tripodal Receptor 1: Nitrilotriacetic acid (0.52 g, 2.6 mmol) and (0.95 g, 7.9 mmol) (R)-(+)-1-
Phenylethylamine were activated by irradiation with microwave. The crude product was crystallized with
Page 10
©ARKAT USA, Inc

Arkivoc 2018, vii, 0-0
Kaplan, Ş. et al.
0
21
EtOAc:hexane (3:1) to obtain 1 as a white solid (1.02 g, 78%). Mp. 156-157 C, [α]D = +720 (c 1.0, CHCl3); IR
(KBr, cm-1) v 3282 (N-H), 3083 (Ar-H), 3028 (Ar-H), 1657 (amide first band), 1554 (amide second band). 1H NMR
(400 MHz, CDCl3) δ (ppm): 1.44 (d, 9H, J 6.8 Hz), 3.13 (s, 6H), 5.09 (pentet, 3H, J 6.8 Hz), 7.23-7.30 (m, 15H),
7.95 (d, 3H, J 8.0 Hz); 13C NMR (100 Hz, CDCl3) δ (ppm): 22.14, 49.05, 60.86, 126.19, 127.35, 128.67, 143.29,
169.53; Anal. Calcd for C30H36N4O3: C, 71.97; N, 11.19; H, 7.26; Found: C, 71.82; N, 11.12; H, 7.28.
(S)-Tripodal receptor 2. Nitrilotriacetic acid (0.51g, 2.6 mmol) and (0.95 g, 7.9 mmol) (S)-(-)-1-phenyletylamine
were activated by irradiation with microwave. The crude product was crystallized with EtOAc:hexane (3:1) to
0
obtain 2 as a white solid (1.05g, 80%). Mp. 157-158 C, [α]D21= -760 (c 1.0, CHCl3); IR (KBr, cm-1) v 3282 (N-H),
3083 (Ar-H), 3028 (Ar-H), 1656 (amide first band), 1555 (amide second band),1H NMR (400 MHz, CDCl3) δ
(ppm): 1.31 (d, 9H, J 7.2 Hz), 3.24 (s, 6H), 5.09 (pentet, 3H, J 7.2 Hz), 7.24-7.32 (m, 15H), 7.61 (d, 3H, J 8.0 Hz);
13C NMR (100 Hz, CDCl3): δ 22.06, 49.02, 60.74, 126.18, 127.40, 128.71, 143.14, 169.34; Anal. Calcd for
C30H36N4O3: C, 71.97; N, 11.19; H, 7.25. Found: C, 71.84; N, 11.13; H, 7.24.
(R)-Tripodal receptor 3. Nitrilotriacetic acid (0.50 g, 2.6 mmol) and (1.34 g, 7.9 mmol) (R)-(+)-1-(1-
Naphthyl)ethylamine were activated by irradiation with microwave. The crude product was purified by flash
column chromatography on silica gel using with EtOAc:hexane (8:1) to obtain for tripodal receptor 3 as a white
solid (1.29 g, 76%). Mp. 114-115 0C, [α]D21= +23.70 (c 1.0, CHCl3); IR (KBr, cm-1) v 3267 (N-H), 3054 (Ar-H), 2973
1
(Ar-H), 1648 (amide first band), 1539 (amide second band), H NMR (400 MHz, CDCl3) δ ( ppm): 1.44 (d, 9H, J
6.8 Hz), 3.34 (s, 6H), 5.74 (pentet, 3H, J 6.8 Hz), 7.35-7.82 (m, 15H), 7.93-8.11 (m, 6H) 8.76 (d, 3H, J 8.0 Hz); 13C
NMR (100 Hz, CDCl3): δ (ppm) 22.11, 44.35, 58.23, 122.79, 123.48, 125.88, 126.08, 126.67, 127.72, 129.12,
130.74, 133.80, 169.88, 140.43; Anal. Calcd for C42H42N4O3: C, 77.51; N, 8.60; H, 6.50. Found: C, 77.57; N, 8.56;
H, 6.53.
(S)-Tripodal receptor 4. Nitrilotriacetic acid (0.50 g, 2.6 mmol) and (1.34 g, 7.9 mmol) (S)-(-)-1-(1-
Naphthyl)ethylamine were activated by irradiation with microwave. The crude product was purified by flash
column chromatography on silica gel using with EtOAc:hexane (8:1) to obtain for tripodal receptor 4 as a white
solid (1.29 g, 76%). Mp. 113-115 0C, [α]D21 = +23.00 (c 1.0, CHCl3); IR (KBr, cm-1) v 3277 (N-H), 3056 (Ar-H), 2971
1
(Ar-H), 1650 (amide first band), 1542 (amide second band), H NMR (400 MHz, CDCl3): δ (ppm): 1.45 (d, 9H, J
13
6.8 Hz), 3.10 (s, 6H), 5.84 (pentet, 3H, J 6.8 Hz), 7.28-7.44 (m, 15H), 7.70-7.80 (m, 6H) 7.82 (d, 3H, J 8 Hz); C
NMR (100 Hz, CDCl3), δ (ppm): 21.07, 44.48, 59.81, 122.57, 123.03, 125.33, 125.81, 126.46, 128.14, 128.85,
130.79, 133.83, 138.42, 169.00; Anal. Calcd for: C42H42N4O3: C, 77.51; N, 8.60; H, 6.50. Found: C, 77.48; N, 8.53;
H, 6.55.
Acknowledgements
We would like to thank The Scientific and Technological Research Council of Turkey (TUBITAK) for financially
supporting this research (Project No: 109 T 787).
Supplementary Material
IR, 1H (400 MHz), 13C (100 MHz), 1H-1H (COSY) and 1H-13C (HETCOR) and DEPT NMR spectrums of tripodal
receptors in DMSO-d6 are given in the Supplementary Data file.
Page 11
©ARKAT USA, Inc

Arkivoc 2018, vii, 0-0
Kaplan, Ş. et al.
References
1. Caltagirone, C.; Gale, P. A. Chem. Soc. Rev. 2009, 38, 520-563.
https://doi.org/10.1039/B806422A
2. Wenzel, M.; Hiscock, J. R.; Gale, P. A. Chem. Soc. Rev. 2012, 41, 480-520.
https://doi.org/10.1039/C1CS15257B
3. Carvalho, S.; Delgado, R.; Drew, M.G.B.; Calisto, V and Félix, V. Tetrahedron 2008, 64, 5392-5403.
https://doi.org/10.1016/j.tet.2008.03.002
4. Ghosh, K.; Saha, I.; Masanta, G.; Wang, E. B.; Parish, C. A. Tetrahedron Lett. 2010, 51, 343-347.
https://doi.org/10.1016/j.tetlet.2009.11.021
5. Ghosh, K.; Masanta, G.; Chattopadhyay, A. P. Eur. J. Org. Chem. 2009, 26, 4515-4524.
https://doi.org/10.1002/ejoc.200900471
6. Liu, W. X.; Jiang, Y. B. J. Org. Chem. 2008, 73, 1124-1127.
https://doi.org/10.1021/jo702159r
7. Liu, S. Y.; Fang, L.; He, Y. B.; Chan, W. H.; Yeung, K. T.; Cheng, Y. K.; Yang, R. H. Org. Lett. 2005, 7, 5825-
5828.
https://doi.org/10.1021/ol052341t
8. Bardwaj, V. K.; Sharma, S.; Singh, N.; Hundal, M. S.; Hundal, G. Supramol. Chem. 2011, 23, 790-800.
https://doi.org/10.1080/10610278.2011.593629
9. Boyle, E. M.; Comby, S.; Molloy, J. K.; Gunnlaugsson, T. J. Org. Chem. 2013, 78, 8312-8319.
https://doi.org/10.1021/jo4008942
10. Basaran, I.; Wang, X.; Alamgir, A.; Wang, J.; Haque, Syed A.; Zhang, A.; Powell, D. R.; Leszczynski, J.;
Hossain, M. A. Tetrahedron Lett. 2015, 56, 657-661.
https://doi.org/10.1016/j.tetlet.2014.12.015
11. Beer, P. D.; Gale, P. A. Angew. Chem. Int. Ed. 2001, 40, 486-516.
https://doi.org/10.1002/1521-3773(20010202)40:3<486::AID-ANIE486>3.0.CO;2-P
12. Alcalde, E.; Dinares, I.; İbanez, A.; Mesquida, N. Chem. Commun. 2011, 47, 3266-3268.
https://doi.org/10.1039/c0cc05350c
13. Zhou, Y. P.; Zhang, M.; Li, Y. H.; Guan, Q. R.; Wang, F.; Lin, Z. J.; Lam, C. K.; Feng, X. L.; Chao, H. Y. Inorg.
Chem. 2012, 51, 5099-5109.
https://doi.org/10.1021/ic202608r
14. Pérez-Casas, C.; Höpfl, H.; Yatsimirsky, A. J. Incl. Phenom. Macrocycl. Chem. 2010, 68, 387-398.
https://doi.org/10.1007/s10847-010-9798-0
15. Duke, R. M.; McCabe, T.; Schmitt, W.; Gunnlaugsson, T. J. Org. Chem. 2012, 77, 3115-3126.
https://doi.org/10.1021/jo202332h
16. Krishnamurthi, J.; Ono, T.; Amemori, S.; Komatsu, H.; Shinkai, S.; Sada,K. Chem. Commun. 2011, 5, 1571-
1573.
https://doi.org/10.1039/C0CC03256E
17. Montoya, C.; Cervantes, R.; Tiburci, J. Tetrahedron Lett. 2015, 56, 6177-6182.
https://doi.org/10.1016/j.tetlet.2015.09.075
18. Sato, K.; Arai, S.; Yamagishi, T. Tetrahedron Lett. 1999, 40, 5219-5222.
https://doi.org/10.1016/S0040-4039(99)00942-9
19. Ballester, P.; Costa, A.; Deyâ, P.M.; Vega, M.; Morey, J. Tetrahedron Lett. 1999, 40, 171-174.
https://doi.org/10.1016/S0040-4039(98)80050-6
Page 12
©ARKAT USA, Inc

Arkivoc 2018, vii, 0-0
Kaplan, Ş. et al.
20. Kuswandi, B.; Nuriman, N. A.; Verboom, W.; Reinhoudt, D.N. 2006, 6, 978-1017.
21. Dey, S. K.; Das, G. Chem. Commun. 2011, 47, 4983–4985.
https://doi.org/10.1039/c0cc05430e
22. Izatt, R. M.; Wang, T.; Hathaway, J. K.; Zhang, X. X.; Curtis, J. C.; Bradshaw, J. S.; Zhu, C. Y.; Huszthy, P. J.
Incl. Phenom. Macrocycl. Chem. 1994, 17, 157-175.
https://doi.org/10.1007/BF00711856
23. Murugesan, K.; Jeyasingh, V.; Lakshminarayanan, S.; Govindaraj, T. S.; Paulraj, M. S.; Narayanan,
S.; Piramuthu, L. Spectrochim Acta A Mol Biomol Spectrosc. 2018, 331, 309-314.
https://doi.org/10.1016/j.saa.2018.03.011
24. Perreux, L.; Loupy, A.; Volatran, F. Tetrahedron. 2002, 58, 2155-2162.
https://doi.org/10.1016/S0040-4020(02)00085-6
25. Chaouchi, M.; Loupy, A.; Marque, S.; Petit A. Eur. J. Org. Chem. 2002, 1278-21283.
https://doi.org/10.1002/1099-0690(200204)2002:7<1278::AID-EJOC1278>3.0.CO;2-B
26. Gelens, E.; Smeets, L.; Sliedregt, L. A. J. M.; van Steen, B. J.; Kruse, C. G.; Leurs, R.; Orru, R. V. A.
Tetrahedron Lett. 2005, 46, 3751-3754.
https://doi.org/10.1016/j.tetlet.2005.03.146
27. Grbovic, L.; Vasiljevic, B.; Pavlovic, K.; Hajnal-Jafari, T.; Duric, S.; Popsavin, M.; Kevresan, S. Maced. J.
Chem. Chem. Eng. 2018, 37,13-20.
https://doi.org/10.20450/mjcce.2018.1371
28. Sribalan, R.; Lavanya, A.; Kirubavathi, M.; Padmini, V. J Saudi Chem Soc. 2018, 22, 198-207.
https://doi.org/10.1016/j.jscs.2016.03.004
29. Azizoglu Şeker, S. ; Kaplan, Ş.; Ozturk, G. Turgut, Y,; Togrul, M. Arkivoc 2016, (iv) 44-58.
http://dx.doi.org/10.3998/ark.5550190.p009.434
30. Ozturk, G.; Subari, S.; Şeker, S.; Togrul, M.; Kocakaya, Ş.; Ercan, S.; Pirinccioglu, N. J Mol Model. 2017, 23,
249.
https://doi.org/10.1007/s00894-017-3390-0
31. Connors, K. A. in Binding Constants; Wiley:New York, 1987.
Benesi, H. A.; Hildebrand, J. H. J. Am. Chem. Soc. 1949, 71, 2703-2707.
https://doi.org/10.1021/ja01176a030
32. Özhan Kocakaya, S.; Turgut, Y.; Pirinççioglu, J. Mol Model. 2015, 21, 55.
Page 13
©ARKAT USA, Inc
